Clamp Carriers For Sale

QUICK 6-SECTION, 12-1/2' Wide Pneumatic "Standard" Clamp Carrier: 6-Section Clamp, typically produces (144) high-quality edge glued panels per day (3 panels per section x 6 sections x 8 hours). Equipped with: -- (6) Sections with (9) clamps per section and 12-1/2' width capacity. -- (54) Clamps with 38" opening and 2-1/2" high x 4-3/4" wide jaws with 1° inward draft. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. -- Rocker Plates are available as optional equipment for face gluing. Features: -- Semi-automatic electric motor drive. -- Pneumatic Panel Flattener for 10-1/2' wide Carrier with easy-to-use controls. -- Pneumatic Clamp Tightener with a 3,000 RPM air wrench is (5 -10) times faster than competitive tighteners; the 2-handed, trigger-activated tightener is more confidence-inspiring than the older, ergonomically awkward "swing-style" clamp tighteners. -- Fast tightening and full-length clamp screws eliminate the need for manual adjustment of rear clamp jaws. Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, and automatic air line oiler; -- High-quality Urethane finish coating, and tool box with spare parts & tools.Floor space requirement: 195"W X 125" H X 127"D

QUICK 6-SECTION, 10'-1/2' Wide Pneumatic "Standard" Clamp Carrier: 6-Section Clamp typically produces (48) high quality edge glued panels per day (3 panels per section x 6 sections x 8 hours). Equipped with: -- (6) Sections with (8) clamps per section and 10-1/2' width capacity. -- (48) Clamps with 50" opening and 2-1/2" high x 4-3/4" wide jaws with 1° inward draft. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. Features: -- Electric motor drive. -- Pneumatic Panel Flattener for 10-1/2' wide Carrier with easy to use controls. -- Pneumatic Clamp Tightener with 3,000 RPM air wrench is (5 -10) times faster than competitive tighteners; 2-handed, trigger activated tightener is more confidence inspiring than the older, ergonomically awkward "swing-style" clamp tighteners. -- Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality Urethane finish coating, and tool box with spare parts & tools. --

Quick Heavy Duty Pneumatic Clamp Carrier with 20-sections and 12-1/2' width capacity. -- (8) Heavy Duty zinc plated clamps per section for 10 section, clamp opening 44" -- (10) Heavy Duty zinc plated clamps per section for 10 section, clamp opening 44" -- Includes 180 clamps with 44" openings and 3.5" high x 4-3/4" wide jaws with 1° inward draft. -- Pneumatic overhead panel flattener along with tightener -- Pneumatic panel flattener for second operator -- Semi-Automatic Pneumatic clamp tightener . -- Semi-Automatic panel tightener for second operator -- Single button automatic electric motor rotation cycle with indexing. -- Heavy Duty frame with 3" diameter shafts and 6" I-beam legs. -- Includes foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating and tool box with spare parts & tools.

QUICK 14-Section Heavy Duty Hydraulic Clamp Carrier with 20-1/2' width capacity With (16) Standard zinc plated clamps per section (224) clamps total), 38" opening on clamps Standard Features include: -- Clamps jaws are 3-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- Pneumatic Panel Flattener with easy to use controls. -- Pneumatic panel flattener for second operator -- Hydraulic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. -- Hydraulic clamp tightener for second operator -- Electric Motor Rotation; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time! Complete with:Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools. 14-Section Clamp will produce 300 panels

Quick Heavy Duty 14-Section Hydraulic Clamp Carrier, 16-1/2' Wide -- 14-Section Clamp Carrier 16-1/2' width cap.. -- (12) Heavy Duty zinc plated clamps per section for (168) total clamps. -- 38" opening on clamps; jaw sizes on clamps are 3-1/2" high x 4-3/4" wide with 1° inward draft. Equipped with: -- Dual Overhead Pneumatic Panel Flatteners for (2) operators -- Dual Hydraulic Clamp Tighteners for (2) operators -- Automatic Electric Motor Rotation with Indexing. -- Standard features include: Foot levelers, coiled air lines where used and flexible conduit for wires.

²QUICK 14-Section Pneumatic Clamp Carrier with 12-1/2' width capacity With (8) Standard zinc plated clamps per section (112) clamps total), 38" opening on clamps Standard Features include: Clamps jaws are 3-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment Panel Flattener with easy to use controls.Pneumatic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. Electric Motor Rotation; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time! Complete with:Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools. 14-Section Clamp will produce 300 panels

QUICK 40-Section Heavy Duty Clamp Carrier 12.5' with Auto Clamp Loosener -- With (9) Standard zinc plated clamps per section (320 clamps total), 32" opening on clamps.Standard Features include: -- Clamps jaws are 3-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- (2) Hydraulic Semi Automatic Clamp Tightener/Panel Flattener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. -- Hydraulic Upper Auto Clamp loosener for 12.5' wide -- Electric Motor Rotation; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time!Complete with: -- Conveyorized glue spreader 20" wide with 10' infeed and 13' outfeed -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools.

Quick Pneumatic Clamp Carrier with 20-sections and 12-1/2' width capacity. -- (8) Heavy Duty zinc plated clamps per section with 52" opening. -- Includes 160 clamps with 52" openings and 3.5" high x 4-3/4" wide jaws with 1° inward draft. -- Pneumatic overhead panel flattener riding along with tightener -- Semi-Automatic Pneumatic clamp tightener . -- Single button automatic electric motor rotation cycle with indexing. -- Heavy Duty frame with 3" diameter shafts and 6" I-beam legs. -- Includes foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating and tool box with spare parts & tools.

QUICK Clamp Rack 8' -- Description: The QUICK Clamp Rack features a cleanly-designed, exceptionally strong frame, with massive 4" x 4" structural tubing cross beams and feet, and 4" x 6" structural tubing legs.The innovative “two-sided"; frame design allows for either one-sided or two-sided operation, at the shop owner’s discretion. The one-sided configuration allows for placement of the frame tightly against a wall, for maximum compactness. The two-sided configuration doubles the amount of easily-accessible clamping area, for industry-leading “room to work."; The Rack is configured by choosing either of the two available foot mounting positions. -- Specifications:96" Wide (36) Clamps 3.5" X 40" opening

RITTER R-200 E/A Face Frame Assembly Easel Dimensions 5' x 12' with 45° Bed angle;Specifications: -- Hold-down beam with (5) adjustable hold down cylinders. -- Squaring bars on left, right and bottom sides. -- 1" Thick laminated surfaced table. -- Heavy duty steel frame. -- (1) Coil-hose for pneumatic screw gun (screw gun not included). -- Air pressure required 100 PSI. -- Footprint: 165"l x 48" D.Shipping dimensions: 68" x 169" x 30" H. Shipping weight 1,250 Lbs.NOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

RITTER - Face Frame Assembly EaselDimensions 5' x 8' -- Bed angle 45° --Hold-down beam with: (3) Adjustable hold-down cylinders. -- Squaring bars on left, right, and bottom sides. -- 1" Thick laminated surfaced table. -- Heavy Duty steel frame. -- (1) Coil hose for pneumatic screw gun (screw gun not included); 100 PSI air pressure required. Shipping dimension: 68" x 120" x 30" HShipping weight: 1,716 LbsNOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. - PRICING SUBJECT TO CONFIRMATION.

RITTER - R-275 E/A, ...Face Frame & Door Assembly SystemDimensions: 4' x 8' --Bed angle: 45° -- Hold down beam clamping arm with: (3) Adjustable hold down cylinders. -- (4) Universal clamping cylinders with: 3" Bore housings and manifold. --2" Grid pattern, perforated holes in steel table to mount cylinders. --Squaring bars on left, right, and bottom sides. --Pressure actuated by foot pedal. -- Adjustable air pressure from 20 to 130 PSI. --Heavy Duty steel frame.Shipping dimensions: 56" x 169" x 30"HShipping weight: 1,602 Lbs.NOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

RITTER R-375 V Door and Panel Clamp4' X 8' Cap., 45 Degree Vertical Assembly Easel.Standard Features: -- (6) Universal Clamping Cylinders & Cylinder Manifold. -- (2) Squaring Bars on Left and Right Sides. -- 2" Cylinder Position Grid Pattern. -- 3" Bore Clamp Cylinder Housing. -- Perforated Steel Table. -- (6) Port Manifold with 1/4" NPT Regulator/Gage. -- Adjustable pressure from 20 to 130 PSI. -- Foot Treadle operated.Shipping Dimensions: 53" X 106" X 30" HShipping Weight: 778 LBSNOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

RITTER R-300 V Door and Panel Clamp6' x 12' Assembly Easel - VerticalStandard Features: -- (10) Universal Clamping Cylinders and Cylinder Manifold. -- Foot Treadle operated. -- (4) Material Hold-Down Dogs. -- (3) Adjustable Material Positioning Stops. -- (2) Squaring Bars on Left and Right Sides. -- 2" Cylinder Position Grid Pattern. -- 3" Bore Clamp Cylinder Housing. -- Perforated Steel Table. -- (12) Port Manifold with 1/4" NPT Regulator/Gage. -- Adjustable pressure from 20 to 130 PSIShipping Dimensions: 151" L x 77" W x 30" HShipping Weight: 1,643 LBSNOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

RITTER R-250 E/A Face Frame & Cabinet Door Clamp6' x 12' Framemaster Face Frame Frame and Door Assembly EaselIncludes: -- 6’x12′ Face Frame and Door Assembly Table. -- (5) Cylinder Clamp Arm. -- (10) Universal Clamp Cylinders & Manifold. -- Foot Treadle. -- (4) Material Hold-down Dog. -- (3) Adjustable Material Positioning StopsNOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

RITTER R220T Double Spindle Counterbore TubSpecifications: -- 1.5 HP Spindle Drive Motor, TEFC. -- 1"; Spindle Centers. -- 14 Degree Double Spindle -- Manual Controls, 110 V, TEFC. -- Foot Actuated Boring Cycle. -- Tooling included. -- 14 Degree Double Spindle. -- 1"; Spindle Centers. -- 6,100 RPM Spindle Speed. -- Ball Bearing Collet Guide Bushing Block. -- 24"; X 30"; Table Area. -- Adjustable Fence with (2) StopsOptions: -- R220T3 – 1.5 H.P. 3-Phase 230/460 VoltNOT IN STOCK - CALL OR EMAIL FOR CURRENT LEAD TIME TO SHIP. PRICING SUBJECT TO CONFIRMATION.

RITTER R-1207P2 Door and Panel ClampSpecifications: -- Table working area: 146"; x 61"; approx. -- Steep pegboard style table. -- Motorized travers top beam of pneumatic down-acting clamps. -- (24) Pneumatic down-acting clamp cylinders. -- 6"; x 6"; clamps pads. -- (2) Position adjustable side pressure clamps. -- 5"; diameter nylon pads. -- 6"; x 6"; nylon pads. -- Clamp is setup in two equal zones. -- Pedestal mounted controls (One left and one for the right zone). -- Side pressure cylinders have approx. 5"; of stroke. -- Top down pressure cylinders have approx.. 4"; of stroke

SAFETY SPEED SPM-301 Screw Pocket MachineUnlike others of its kind, the SAFETY SPEED SPM-301 features cam-driven action providing fast, smooth cutting action under complete mechanical control throughout the machine cycle. The pilot drill and ball end mill produce superior low-angle screw pockets. The SPM301’s mechanical linkage allows the pilot drill bit and router bit to cut at the same time, reducing cycle time without sacrificing cut quality. Manufactured completely in the USA, the SPM301 showcases heavy duty construction;Advantages: -- FENCE ADJUSTMENT: Simple back fence and stop rail make pocket adjustments for different screw lengths quick and easy. -- CONTROLLED FAST CUT: Mechanical CAM linkage allows pilot drill bit and router bit to be cutting at the same time, reducing cycle time without sacrificing cut quality. Controlled cut increases tool life. -- DEPTH GAUGE: Simple device makes it a snap to see pocket depth before you cut. -- POCKET DEPTH ADJUSTMENT: The SPM301 has the ability to change depth of pocket for different material thickness quickly with the simple crank of a handle. -- EASY ACCESS TO TOOLING: The SPM301 has top down access to the tooling for quick bit changes and adjustments.Specifications: -- Router Motor 2-1/4 HP @ 27,500 RPM. -- Compact router drill @ 16,000 - 27,000 RPM. -- Vacuum requirement 220 CFM, 3" hose connection. -- Air requirements 1-2 CFM @ 80 PSI Option: Table extension provides 48" working surface...add $499

SAFETY SPEED SPM-301HD Screw Pocket MachineThe SPM-301HD showcases an all-new heavy-duty, direct drive continuous electric spindle motor for those jobs that just keep on coming. .Just like your CNC spindle, this motor runs continuously with little maintenance required.Unlike others of its kind, the SPM-301HD features the proven 301 cam-driven action providing fast, smooth cutting action under complete mechanical control throughout the machine cycle. The new pilot air drill and high end spindle cutter produce superior low-angle 6 degree screw pockets. Features: -- Direct drive continuous electric spindle motor. -- Smooth mechanical controlled action vs. pneumatic. -- Half the cycle time compared to other machines on the market, two actions in one cycle. -- Easy top access for tooling changes and maintenance. -- Built in adjustments for depth and length of pocket. -- Easy adjustment dial for cycle speed for different wood species, creating the perfect pocket every time.Specifications: -- Spindle Motor - 5 amp/18,000 RPM, 3/8" (ER20) Collet. -- Air Drill - 0.7 Hp, 25,000 RPM, ¼"; Collet. -- Vacuum Requirement - 220 CFM, 3" Hose Connection. -- Air Requirement - 30 CFM at 80 PSIOption: Table extension provides 48" working surface...add $499

TAYLOR 40 Section Clamp Carrier.Specifications: -- 40-Section, 8-1/2' width capacity -- Average 4/5 clamps per section (175 clamps total), all with 32" max. clamp opening. -- Equipped with (175) clamps plus a pallet of spares that require repair, 32" clamps with 2-1/2" high jaws .Complete with: -- Heavy Duty Drive for rotation,& clamp tightening. -- Foot pedal control. -- Includes a glue applicator.
