Equipment For Sale

2001 Diamond Z 1463B Tub Grinder, Frame hours are unknown at this time. 400 hours since 3412 rebuild. Everything runs as it should. Grates supports will need to be address as some point. Weight 98,000 Length 46' Width 11'11" Height 14' Disclaimer The information is the best of our knowledge at the time of the listing. The price may change without notice and additional charges may apply, including freight, taxes, duties, tariffs, quarantine, etc.

ZERO SALES TAX FOR OUT OF STATE SALES! ZERO DEALERSHIP FEES! ZERO NONSENSE! ULTRA LOW RATE IN HOUSE FINANCING FOR BUSINESS AND INDIVIDUALS! 2 YEAR/2,000 HOUR WARRANTY!! 113 HP Kubota 4 cyl Turbo Diesel w/ top speed of 22mph, All wheel steer/control, Operating weight 26,676 lb. This model is capable of lifting up to 8,500 lbs with a max lift of 44ft. Dual outriggers and single hand, muti-function operator joystick. Hydrostatic drive Shipping not included! Call for Pricing!!!!

ZERO SALES TAX FOR OUT OF STATE SALES! ZERO DEALERSHIP FEES! ZERO NONSENSE! ULTRA LOW RATE IN HOUSE FINANCING FOR BUSINESS AND INDIVIDUALS! 2 YEAR/2,000 HOUR WARRANTY!! 113 HP Kubota 4 cyl Turbo Diesel w/ top speed of 22mph, All wheel steer/control, Operating weight 27,029lbs. This model is capable of lifting 4300lb over 54 feet and 8,300 close up. Dual outriggers and single hand, muti-function operator joystick. Hydrostatic drive Shipping not included! Call for Pricing!!!!

ZERO SALES TAX FOR OUT OF STATE SALES! ZERO DEALERSHIP FEES! ZERO NONSENSE! ULTRA LOW RATE IN HOUSE FINANCING FOR BUSINESS AND INDIVIDUALS! Enclosed Cab, Air Conditioner, 44 ft Max Lift Height, 10000 lb Max Lift Capacity, US EPA Label, 60 in Forks, Manual Coupler, Outriggers, Frame Leveling, Auxiliary Hydraulic Plumbing, 10.00x20 Tires

Hex 45" Whole Log Metal Detector

DIEHL STRAIGHT LINE RIP

MLS Number 10682943 DIEHL SL52 STRAIGHT LINE RIP SAW Bottom arbor 4-1/4"X8-1/2" capacity 15 HP 3,545 RPM arbor drive motor Infeed speed up to 200 FPM Serial# 10/88M-5312-4728 Voltage: 460/60/3 phase Amps: 21.7 Wiring diagram # 2-9000-0026 Was removed from service in November 2020

DIEHL 990 GANGRIP SAW Product No. 1001 30 HP - 3600 RPM arbor motor-AB size 4 starter-110 volt controls 12 " arbor width with 3-1/2" maximum thickness 8 roll feed - 4 top (powered) - 4 bottom Anti-kick back fingers : top and bottom One (1) saw cartridge-2 3/4 " saw blade bore New arbor bearings 5 HP feed: single speed Rip fence Outboard bearing on arbor 3" throat capacity to 1st saw blade Cleaned, painted and checked Serial # : 54174 Year: 1958

Diehl model MR-90 Gang Rip Saw Twelve ( 12 ) inch saw arbor width capacity- Roll feed 50 HP 3600 RPM arbor motor -direct coupled wired 480 volts, 3 phase- new motor bearings 2 HP variable speed feed motor 50 to 150 FPM feed speed-variable Four powered top feed rolls- Excellant feed roll gears 12 inch arbor with one (1) sleeve with spacers Adjustable rip fence Serial number : 66M-1668 Cleaned , checked , and painted

Diehl SL 50 Straight Line rip saw with adjustable infeed speed controller 15HP 480 volt 14” saw blade feed chain 8 ¼” wide, Table dimensions: 80” x 57” Serial # 65M1297570 We also have available a Diehl SL 52 in our inventory A wooden pallet/crate will be built for shipping at no charge Contact us for price including freight. Can test run saw with video upon request. Stored in our warehouse for prompt delivery.

Diehl SL50 Straight Line Rip Saw 240 volt 3 phase Variable speed control SN: 51108

DIEHL - TFM-68, ...4"; x 8"; 5-Head High Speed Jointed Moulder5-Head (B-R-L-R-T-B) with 8-5/8" x 4-1/2" capacity. Head sequence: Bottom 15 HP, Right 10 HP, Left 10 HP, Right 10 HP, Top 15 HP, and Bottom 20 HP motor.1st Bottom and 1st right side run at 3,600 RPM; all the other spindles run at 6,000 RPM utilizing the included Frequency Changer.Side heads tilt 35° inward and 5° outward. Specifications: -- Spindle diameter: Vertical 1-13/16"; Horizontal 2-1/8" dia. for top spindle only. -- Built-in straight & profile jointers on spindles 2 - 3 - 4 & 5. -- Variable feed speed from 20 - 150 FPM via 15 HP feed drive. -- Cardan Shaft driven. -- WAXLIT Pump and groove bed with groove cutters for 1st bottom. -- Air chipbreakers and feed roll tensioning. -- Starting panel and transformer included.Weight: Approx. 14,000 Lbs

DIEHL - 990, ...Gang Rip Saw (Roll Feed)Specifications: -- 30 HP - 3,600 RPM arbor motor, ALLEN-BRADLEY "Size 4" Starter, 110 volt controls. -- 12" Arbor width with: 3-1/2" Max. thickness cap. -- 8-Roll feed: (4) Top (powered) & (4) Bottom. -- Antikickback fingers: Top & Bottom. -- (1) Saw Cartridge: 2-3/4" Saw blade bore. -- New arbor bearings.Equipped with & Features: -- 5 HP Feed: single speed. -- Rip fence. -- Outboard bearing on arbor. -- 3" Throat capacity to 1st saw blade.

20 HP Motor - 3,450 RPM belt driven fixed arbor, 14" - 18" blade dia., 4-1/2" max. thickness; 3 HP - 1,800 RPM feed drive, variable feed speed of 70 - 200 FPM. -- 24" Throat depth to right of blade, 18" of table to left of blade, 78" long table, cast iron pressure bar arms with ball bearing rollers, 60" guaranteed glue joint accurate. -- Multi-V, fully machined, pyramid corrugated single feed chain. -- Complete with: Adjustable rip fence, self-adjusting upper anti-kickback fingers with cam height control & lower anti-kickback fingers in table, pressure beam outfeed guard with pivoting side pressure, automatic pneumatic lubrication of feed chain & race, full overload & under voltage protection, automatic brake for arbor protection, and pressure bar curtain. -- Option: Diode laser & mounting bracket, please add ...$ 1645.

DIEHL STRAIGHT LINE RIP SAW SL30-19 Specifications: -- 10 HP Motor - 3,450 RPM belt driven fixed arbor, 14" - 16" blade dia., 2-1/2" max. thickness; 1.5 HP - 1,800 RPM feed drive, single fixed feed speed of 60 FPM. -- 19" Throat depth to right of blade, 18" of table to left of blade, 56" long table, cast iron pressure bar arms with ball bearing rollers, 60" guaranteed glue joint accurate. -- Multi-V, fully machined, pyramid corrugated single feed chain.Complete with: -- Adjustable rip fence, self-adjusting upper anti-kickback fingers with cam height control & lower anti-kickback fingers in table. -- Pressure beam outfeed guard with pivoting side pressure, automatic pneumatic lubrication of feed chain & race. -- Full overload & under voltage protection. -- Automatic brake for arbor protection, and pressure bar curtain. Options: Diode laser & mounting bracket; 15 HP motor, 20 HP motor.

15 HP Motor - 3,450 RPM belt driven fixed arbor, 14" - 16" blade dia., 2-1/2" max. thickness; 2 HP - 1,800 RPM feed drive, variable feed speed of 50 - 140 FPM. -- 30" Throat depth to right of blade, 18" of table to left of blade, 56" long table, cast iron pressure bar arms with ball bearing rollers, 60" guaranteed glue joint accurate. -- Multi-V, fully machined, pyramid corrugated single feed chain. -- Complete with: Adjustable rip fence, self-adjusting upper anti-kickback fingers with cam height control & lower anti-kickback fingers in table, pressure beam outfeed guard with pivoting side pressure, automatic pneumatic lubrication of feed chain & race, full overload & under voltage protection, automatic brake for arbor protection, and pressure bar curtain. -- Options: Diode laser & mounting bracket, please add ...$2195.00, 20 HP motor, add ...$2,035.00 208, 240, or 480 Volt

15 HP Motor - 3,450 RPM belt driven fixed arbor, 14" - 16" blade dia., 2-1/2" max. thickness; 1 HP - 1,800 RPM feed drive, variable feed speed of 50 - 140 FPM. -- 19" Throat depth to right of blade, 18" of table to left of blade, 56" long table, cast iron pressure bar arms with ball bearing rollers, 60" guaranteed glue joint accurate. -- 1.5 HP feed motor, Multi-V, fully machined, pyramid corrugated single feed chain. -- Complete with: Adjustable rip fence, self-adjusting upper anti-kickback fingers with cam height control & lower anti-kickback fingers in table, pressure beam outfeed guard with pivoting side pressure, automatic pneumatic lubrication of feed chain & race, full overload & under voltage protection, automatic brake for arbor protection, and pressure bar curtain. -- Options: Diode laser & mounting bracket, please add ...$ 1,195; 20 HP motor, add ...$ 1,365.

DIEHL SL 65-19 Straight Line Rip Saw: 20 HP Motor - 3,450 RPM belt driven fixed arbor, 14" - 18" blade dia., 4-1/2" max. thickness; Features: -- 3 HP - 1,800 RPM Feed drive, variable feed speed of 70 - 200 FPM. -- 19" Throat depth to right of blade, 18" of table to left of blade, 78" long table, cast iron pressure bar arms with ball bearing rollers, 60" guaranteed glue joint accurate. -- Multi-V, fully machined, pyramid corrugated single feed chain. Equipped with: -- Adjustable rip fence, self-adjusting upper anti-kickback fingers with cam height control & lower anti-kickback fingers in table. -- Pressure beam outfeed guard with pivoting side pressure. -- Automatic pneumatic lubrication of feed chain & race. -- Full overload & under voltage protection. -- Automatic brake for arbor protection, and pressure bar curtain. Option: Diode laser & mounting bracket, please add ...$ 1,745.

DIEHL - SL 50, ...Straight Line Rip SawSpecifications: -- 15 HP - 3,450 RPM Direct drive arbor motor, 2" dia. arbor. -- 16" Blade cap., 2-1/2" max. depth of cut. -- 10" Min. part length. -- 49" Width of table to the right of blade & 26-5/16" to the left. -- 57" x 79" Tabletop size. -- 2 HP Feed drive, feed speed of 65 - 195 FPM.Equipped with & Features: -- Twin chain drive. -- Automatic dip lubrication. -- Top pressure system with: (6) Full width rollers & (2) split rollers over blade. -- Rip fence. -- Push buttons and magnetic starters. -- Floating rip fence. -- Self-adjusting antikickback fingers. -- Full overload & undervoltage protection.

DIEHL - SL-52, ...Straight Line Rip SawSpecifications: -- 15 HP - 3,600 RPM belt driven motor, fixed 2" arbor. -- 14" - 18" Blade diameter. -- 4-1/4" Max. thickness with 18" blade diameter. -- 2 HP - 1,800 RPM feed drive, variable feed speed from 65 to 190 FPM. -- 25" Throat depth to right of blade; 25" of table to left of blade. --Table size of 78" x 64".Equipped with & Features: -- Cast iron pressure bar arms with ball bearing rollers. -- Adjustable rip fence. -- Self-adjusting antikickback fingers with control cam. -- Automatic lubrication of feed chain & race. -- Full overload and under voltage protection. -- Manual arbor brake for safety with interlock; 34".Shipping Dimensions: 7-1/2' L x 7' W x 5-1/2' H; weight: 5,000 Lbs.
