sawmill Equipment For Sale

MDI Metal Detector Mdl CCW-75 w/Search Coil & Chassis S/N 8985

Meadows sawmill New parts from MFG: Saw Arbor, Live belt conveyor, misc parts Computer setworks 225 HP Detroit Diesel

MEADOWS MILLS 36 DELUXE STATIONARY BOARD EDGER -- Handset board edger, all mechanical functions, and fixed feed speed -- Welded steel frame constructed with 6 inch channel and including legs -- Working height may be determined by buyer, standard is 36" -- Overall length of frame is 14 feet, bay is 36"; wide -- Four live bottom feed rolls and two overhead gravity pressure rolls -- Unison shifting saw collars, each with a 16"; diameter split carbide saw -- 30 HP electric motor mounted on edger -- 480 volt magnetic motor starter -- Belt drive with belt guard -- Infeed table with dead rolls -- Tailing device up to 16' long added to outfeed -- Laser lights aligned with each saw

MEADOWS MILLS 36 DELUXE STATIONARY BOARD EDGER -- Handset board edger, all mechanical functions, and fixed feed speed -- Welded steel frame constructed with 6 inch channel and including legs -- Working height may be determined by buyer, standard is 36" -- Overall length of frame is 20 feet, bay is 36"; wide -- Four live bottom feed rolls and two overhead gravity pressure rolls -- One stationary saw collar and one shifting saw collar, each with a 16"; diameter split carbide saw -- 30 HP electric motor mounted on edger -- 480 volt magnetic motor starter -- Belt drive with belt guard -- Infeed and outfeed tables with dead rolls -- Laser lights aligned with each saw

MEADOWS MILLS 36 DELUXE STATIONARY BOARD EDGER -- Hydraulic board edger, all push button functions, and variable feed speed with flow control -- Complete hydraulic power source belt driven from mandrel of edger, includes oil tank and oil cooler -- Welded steel frame constructed with 6 inch channel and including legs -- Working height may be determined by buyer, standard is 36" -- Overall length of frame is 20 feet, bay is 36"; wide -- Four live bottom feed rolls and two overhead gravity pressure rolls -- One stationary saw collar and one shifting saw collar, each with a 16"; diameter split carbide saw -- 60 HP electric motor mounted on edger -- 480 volt magnetic motor starter -- Belt drive with belt guard -- Infeed table and outfeed tables with dead rolls -- Laser lights aligned with each saw

MEADOWS MILLS 120H Chain Log TurnerSpecifications: -- Hydraulic Cylinders: Two 2" x 12" with 1-1/2" diameter rod -- Turning Chain: #120 chain with 1" dog width and 13 bits -- Drive: H80TB13 sprocket with bushing, 80Q25 sprocket with bushing, #80 drive chain, and chain guard -- Drive Shaft: 2-3/16" diameter 1018 cold roll -- Idler Shaft: 2-3/16" diameter 1018 cold roll. Construction: -- Frame: Base constructed from 10" x 25.4 Lbs beam, feet constructed from 4" x 6" tubing, head frame: Constructed from 8" x 3" x 4" tubing -- Drive Motor: Charlyn 104-1253 hydraulic motor (or equivalent motor from alternate manufacturer) -- Hydraulic Requirements: 12 GPM & 950 PSI -- Controls: not included in the base price

MEADOWS MILLS 100H CHAIN LOG TURNER -- Hydraulic Cylinders: One 2" x 12" with 1 1/2" rod -- Turning Chain: #100 chain with 3/4" dog width and 13 bits -- Drive: H60TB13 sprocket with bushing, H60SDS25 sprocket with bushing, #60 drive chain, and chain guard -- Drive Shaft: 1 11/16" diameter 1018 cold roll -- Idler Shaft: 1 11/16" diameter 1018 cold roll -- Frame: Base constructed from 3" x 4" tubing, uprights constructed from 8" channel and 4" channel, head frame constructed from 3" x 4" x 3/8" angle and various flat bar -- Drive Motor: Charlyn 103-1032 hydraulic motor (or equivalent motor from alternate manufacturer) -- Hydraulic Requirements: 10 gpm & 950 psi -- Controls: not included in base price

MEADOWS MILLS 2-STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 3 STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 4 STRAND SAWMILL STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Sawmill style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 2 STRAND DEBARKER STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Debarker style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS MILLS 3 STRAND DEBARKER STOP-N-LOAD LOG DECK -- Deck strands constructed with 4" x 8" x 1/4" wall tubing -- Chains run in 4" channel lined with UHMW wear strips -- Hydraulic Cylinder: One 2" x 12" with 1 1/2" rod -- Chain is WR-78 -- Front and rear crossbars are constructed with 6" wide flange beam -- Debarker style stop-n-load -- Hydraulic drive with Auburn (or equivalent gear box from alternate manufacturer) gear box -- Strand spacing is determined by buyer, standard is 6 feet -- Controls: not included in base price -- Legs may be included for an additional cost -- Log decks are disassembled and bundled for shipment

MEADOWS #1 Automatic Sawmill;Complete with the following components and features: -- 15' Long 4 HB Carriage. -- Operator’s Cab, . -- Drive & Turner. -- Computer Setworks. -- YAMANI 4" Band Headrig. -- MEADOWS Titan 4" combo Edger also new in 2001; -- 30' x 24" Live Rolls. -- Electrical Switchgear. -- 33" Dia max. log. -- Capacity: 6,000 to 8,000 BF per day.NOTES: &#9679 Can be seen in operation.

Meadows LH 3 Knee Circle Saw Mill 3 Head Block, Carriage. Track. Cab & Controls 52" Blade With Electric Motors. Believe it is a #2

Meadows Chain Turner

The Model 120H log turner utilizes two (2) 2 inch by 12 inch hydraulic cylinders with 1 1/2 inch bores to lift its head. The log turner chain comes standard with 13 teeth that are 1 inch wide. The head is chain driven by a Char-lyn 104-1253 hydraulic motor (included). The drive includes a 13 teeth and 25 teeth sprocket and number 80 chain with chain guard included. Controls, not included, with hoses sell for $2,490.00. 20 GPM Hydraulic power sources, not included, sell for $7,320.00. All prices are FOB North Wilkesboro, NC 28659. For questions please send an email to [email protected] or call 1-800-626-2282, ask to speak with Brian Hege. To place an order please call 1-800-626-2282, ask to speak with Brian Hege.

Meadows #2 - 3HB Modular Mill w/Husk Frame, Offing Belt, Overhead Mud Saw, 4 x 5 Control Cab, Computer Setworks & Hyd Drive System, Log Turner, 56" Saw Blade, 100HP Motor, Debarker for Saw Cut. Out and Ready to Ship

Meadows 16' 3 Strand Log Deck w/Drive

Saw Mill Saw Cabin Track (3) peace’s Drop belt Saw Log Turner and transition Log deck 200 HP motor for saw mill

Meadows 4 headblock carriage, Model; #3 DELUXE, good working condition
