Description:

BIESSE AKRON 440 AX EDGEBANDER (W/PRE-MILL & CORNER ROUNDING: -- Specifications: Material infeed for strips & coiled edge material like PVC, ABS, veneer, and solid wood. -- Edge & Workpiece Capacity: 0.4 - 3 mm (0.016 - 0.12") Edge; 10 - 60 mm (0.39 - 2.36") panel thickness; 140 mm (5-1/2") min. panel length, and 85 mm (3.3") min. width. -- Working Units:Pre-milling Station: (2) 3 kW (4 HP) - 150 Hz, 9,000 RPM Motors; equipped with panel blow off device and SIKO digital counters for adjustments. -- EVA Gluing Unit: Edge Feeding & Pressing Unit; automatic loading of tape in rolls and strips; quick-change glue pot system. -- Pressure Section: (1) Large 150 mm dia. driven & (5) idle pressure rollers. -- Feed Speeds: Operating feed speeds 12 & 18 MPM (39 & 60 FPM). -- Workstations: Double Motor End Trim; tiltable from 0° - 15°; each motor 0.8 kW (1 HP) - 12,000 RPM; sliding in a slicing motion on a 45° precision guide bar with oversized bearing blocks. -- Top & Bottom Trimming: (2) Motors 0.65 kW (0.87 HP) each; "Pro-Nesting" copiers; cutters R=2 mm. -- Fine Trim/Corner Rounding Unit: (2) Motors; each 0.65 kW (0.87 HP) - 12,000 RPM; motors carry out Corner Rounding and Top & Bottom Trimming on panel edge with PVC, ABS, etc. material, and wood edge banding up to 3 mm max. edge thickness. -- Top & Bottom Flat Glue Scrapper: To remove potential glue squeeze out. -- Buffing Station: Top & Bottom, (2) motors, each 0.37 kW (0.5 HP) - 2,800 RPM. -- Operator Interface:Operator Control Panel, "HDI" High-Definition touchscreen control, Windows XP based. -- User-friendly graphic user interface with diagnostic and assisted maintenance. -- USB and Ethernet port; 1.44 MB floppy drive, automatic or manual startup. -- Complete with:High frequency motors (200 HZ): Padded sound enclosure. -- Top pressure beam with staggered double-row hold-down wheels mounted on ball bearings. -- Actual Model is: BIESSE AKRON 440 AX
