Description:

ITALPRESSE - XL/6 30-13 120T: Veneer Hot PressPlaten Dimension: 3,000 mm x 1,300 mm (118" x 51"). Design allows loading from all (4) sides. -- 350 mm (13.8") Max. single daylight opening with infinitely variable stroke adjustment. -- (6) Hydraulic 85 mm dia. Chromium Plated upstroke cylinders. -- 120 Metric tons total pressure; 2.2 kW (3 HP) Hydraulic pump motor, dual stage & speed w/automatic pressure readjustment. -- Features a Rack & Pinion guide system made of self-lubricating material insures parallel closing of the platens. Equipped with: -- Patented, electrically heated platens w/automatic temperature adjustment; integrated electric heating system can heat up to 120°C max. platen temperature. Operating temperature 90° C. Power requirement: 19 kW (25 HP). -- Manual Open & Close or automatic open with adjustable cycle timer. -- Perimeter safety stop wire: On all (4) sides of Press; safety lockout for maintenance; safety circuit with 2-hand operation. -- Construction: Heavy I-beam; welded steel frame; cylinders have chromium plated steel pistons with Teflon bronze guides in cylinder.
