Description:

LAGUNA SMART SHOP 2 PRO CNC Router, 5' X 10' with ATC & 82 Hours Only! (Purchased & Delivered in March 2024):60" x 120" Moving gantry, fixed table design in a front-to-back configuration with a 6-zone vacuum table with T-slot table including manual controls. -- Specifications: Machine travel 61" x 121" x 9.5" axis travel with 12" clearance under the gantry, Speeds of 900 IPM rapid travel with 600 IPM max. cutting speed. -- Equipped with:(1) 9.6 kW (12.87 HP) Electrospindle ISO-30 (ATC), 5,000 - 24,000 RPM Range, Ceramic Spindle Bearings supported by Automatic Tool Changer with (8) tool position tool rack; Includes assorted ISO-30 tool holders, collets, and precision collet nuts. -- All axesRide on 25 mm heavy-duty HiWin HG Series linear bearings and rails on all axis rack. "Helical" rack-and-pinion drives on "X" and "Y" axis, and precision-ground ball screw drive on "Z" axis. Gantry is driven on each end (two "helical" rack-and-pinion drives on "Y" axis). -- Control:SYNTEC TECHNOLOGY controller and drive components for easy diagnosis and exceptional reliability. Machine features the networking, connectivity and online troubleshooting typically found in Windows environments without the Windows baggage. -- Runs industry standard G-CodeThat can be created from any CAM software package. Program transfer to the controller can be accomplished with USB, or via Ethernet transfer. -- Complete with:Expandable control system for custom applications, Spindle speed control through programming, Manual overrides of spindle speed and feed speeds during run. -- Centralized lubrication system for all axis. -- (2) 7.5 kW (10.06 HP) Vacuum Pump blowers with Vacuum monitoring gauge, assorted tool holders. -- LAGUNA "CFLUX:3" 3 HP Cyclone Dust Collector.
