Description:

COMEVA G-300 4-Axes CNC Controlled Door Frame/Jamb Milling Machine: Designed for cutting and milling the stiles and rails (headers) of door frames/jambs using a saw blade which rotates from +/- 45° & 90° straight cuts (rabbet-step cuts) and a router head for the milling pockets of all types of hinges and locks. -- Specifications: Maximum frame length 110" (2800 mm); Maximum frame thickness of 1.3" (33 mm); Max. frame width of 7.01" (180 mm). Saw cut positions at +45, 90, -45°. Saw blade diameter 11.8" (300 mm). Milling/Saw Group: Cutting and milling with (4) axes, X, Y, Z, & A each with servo motors controlled by CNC. Components from reputable manufacturers for guaranteed reliability, performance and quality. -- Milling motor: 1.5 KW (2 HP), and 3.5 KW (4.7HP), 18,000 RPM. -- Saw motor: 4 KW (5.3 HP), 5500 RPM -- Axes Speeds X & Y: Axes: 70 m/min (approx 230 FPM; Z- Axis 25 m/min (approx. 82 FPM).NC Control: NC Controls for X, Y, Z, & A axes for tool positioning & processing. axis movement via hardened round ways & ground ball screws. Advanced NC control powered by OSAI CNC which is set up to control the (4) Interpolated axes. Comes with a PC with 19" touch screen.Rails//Workholding: (4) sliding rail units with (4) pneumatic fixturing clamps (aluminum and plastic) that can be moved for all frame sizes. -- NOTE : Works well with COMEVA G300 Door jamb machine. Listed separately as DM-010598. -- Comes with: CE approved optical barrier and security fence. -- Includes: Owner’s Manual with mechanical & electrical schematics. -- Overall machine dimensions with 183" x " x 70" x 98" high (4640 x 1700 mm x 2450 mm)
