78 Results Found
704-841-2001
WEEKE BHX 050 CNC MACHINING CENTER (VERTICAL): -- Specifications: Flexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space, in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for "X" axis is 98.4" (2,500 mm); "Y" axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The "BHX 050" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axes & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW), Variable speed from 1,500 - 7,500 RPM motor, (6) independent spindles with: (4) spindles in "X" axis & (2) spindles in "Y" axis.Boring block has QUICK-CHANGE spindle system. -- Operator & Machine Control:WEEKE "POWER CONTROL" + Windows + WoodWOP 5.0 + Operating System; "IntelCore 2 DUO" Processor.17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include: Max. workable part size for "X" axis is 120" (3,050 mm. (1) "X" Axis grooving saw; 9,000 RPM, saw blade dia. 100 mm. (1) 7 HP (5 kW) Electrospindle router with hydraulic "QUICK-CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE - BHX 050.
WEEKE - BHX 050: CNC Machining Center (Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 meter² of valuable floor space in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for: "X" Axis: 98.4" (2,500 mm); "Y" axis: 33.4" (850 mm); max. part thickness: 2.4" (60 mm). -- Min. worktable part size for: "X" Axis: 7.8" (200 mm); "Y" axis: 2.7" (70 mm); min. part thickness of: 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The BHX 050 reaches movement speeds of: 164 FPM (50 MPM) in "X" & "Y" axis; 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit(1) 2.4 HP (1.8 kW); Variable speed from: 1,500 - 7,500 RPM motor; (8) independent spindles with: (4) Spindles in "X" axis & (4) spindles in "Y" axis. -- (6) Horizontal spindles with: (2 + 2) In "X" axis; (1 + 1) in "Y" axis. -- Boring block has "QUICK CHANGE" Spindle System. -- Operator InterfaceWEEKE "POWER CONTROL" + Windows + WoodWOP 5.0 + Operating System; "IntelCore 2 DUO" Processor. -- 17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 Serial ports; USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive; modem; Ethernet connection. -- Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include: (1) "X" Axis grooving saw with: 9,000 RPM Motor; max. saw blade dia. 100 mm. (1) 7 HP (5 kW) Electrospindle router with: Hydraulic "QUICK CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE BHX 050
WEEKE - BHX 055: CNC Boring Machine (P to P Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space in addition to an innovative panel handling system. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm); "Y" axis 33.4" (850 mm), max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning SpeedThe "BHX 055" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axis & 50 FPM (15 MPM) in "Z" axis with total safety - providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW) Variable speed from 1,500 - 7,500 RPM motor; (13) independent spindles with: (8) Spindles in "X" axis & (5) spindles in "Y" axis.(4) Horizontal spindles with: (1 + 1) in "X" Axis & (1 + 1) in "Y" axis.Boring block with "Quick Change" vertical spindle system. -- Operator & Machine Control:WEEKE "Power Control PC 85" + Windows + WoodWOP 6.0 Operating System; Intel Core "2 DUO" Processor.17" TFT Monitor: International keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive: modem, Ethernet connection.Real time multitask processing: Programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:(1) "X" Axis grooving saw, 9,000 RPM, max. saw blade dia. 100 mm.
Call for Price
WEEKE - BHX 055: CNC Machining Center (Vertical) -- SpecificationsFlexible "Vertical" Machining Center uses less than 5 sq/m of valuable floor space in addition to an innovative panel handling system. -- Working Cap.Max. workable part size for "X" axis: 120" (3,050 mm); "Y" axis: 33.4" (850 mm); max. part thickness: 2.4" (60 mm).Min. worktable part size for "X" axis: 7.8" (200 mm); "Y" axis: 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the: LH or RH side. -- Positioning Speed"BHX 055" Movement speeds: 164 FPM (50 MPM) in "X" & "Y" axis; 50 FPM (15 MPM) in "Z" axis with: Total safety; unmatched working capacity. -- Boring Unit(1) 3 HP (2.3 kW) Variable speed from: 1,500 - 7,500 RPM motor; (15) independent vertical spindles with: (10) Spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with: (2 + 2) in "X" Axis; (1 + 1) in "Y" axis.Boring block with: "Quick Change" vertical spindle system. -- Operator InterfaceWEEKE "Power Control PC 85" + Windows + WoodWOP 6.0 Operating System; Intel Core "2 DUO" Processor.17" TFT Monitor: International keyboard; soft touch keypad; ;industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive: Modem, Ethernet connection.Real time multitask processing: Programs transfer via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options include: (1) "X" Axis grooving saw with: 9,000 RPM Motor; max. saw blade dia. 100 mm. (1) 4-position ATC Changer. (1) 7 HP (5 kW) Electrospindle router with:HSK F63 Adaptor; variable speed from 6,000 - 18,000 RPM.
Call for Price
WEEKE BHX 200-25 OPTIMAT CNC MACHINING CENTER (VERTICAL): + PANEL RETURN SYSTEM + CLAMEX-P PROCESSING: -- Specifications: Flexible "Vertical" Machining Center that uses less than 10 sq/m of valuable floor space in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm); "Y" axis 49.2" (1,250 mm) max. part thickness 3.1" (80 mm).Min. worktable part size for "X" axis is 13.8" (350 mm); "Y" axis 2.36" (60 mm); min. part thickness of 0.31" (8 mm) automatic infeed & outfeed. -- Positioning Speed:The BHX 200 can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axes & 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW) Motor, variable speed from 1,500 - 7,500 RPM; (15) independent spindles with: (9) Spindles in "X" axis & (6) spindles in "Y" axis.(10) Horizontal spindles with: (3 + 3) in "X" axis & (2 + 2) in "Y" axis; boring block has "QUICK CHANGE" spindle system. -- Operator & Machine Control:WEEKE "POWERTOUCH" + Windows "7"+ WoodWOP Operating System; "i5" Processor.21.5" HD multitouch Wide Screen Display Monitor; soft-touch keypad & USB connection; Digital Field Bus System; RS-232 Serial ports, Ethernet connection.Real-time multitask processing; programs can be transferred via USB or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:(1) NC Controlled 0° - 90° "X/Y" Grooving Saw for max. 125 mm dia. x 5 mm thick blade.(1) 13.4 HP (10 kW) Air-Cooled electrospindle router with HSK F3 adaptor; variable speed from 1,500 - 24,000 RPM.(1) 4-Position ATC tool rack mounted on the side of the machine base.(1) "CLAMEX-P Connecting Hardware Processing System; ...watch the Literature Video @ 3:45!(1) NC Controlled Panel Return System; ...watch the Literature Video @ 4:30! -- Actual Model is: WEEKE - BHX 200-25 OPTIMAT
Call for Price
WEEKE BHX 200 OPTIMAT CNC MACHINING CENTER (VERTICAL W/ATC). -- Specifications:Flexible "Vertical" Machining Center with "ATC" that uses less than 5 meter² of valuable floor space in addition to an innovative panel handling system. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm), "Y" axis 49.2" (1,250 mm), and max. part thickness 3.1" (80 mm).Min. worktable part size for "X" axis is 7.8" (200 mm), "Y" axis 2" (50 mm), min. part thickness of 0.31" (8 mm). Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The BHX 200 can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axis & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring unit:(1) 3 HP (2.3 kW), variable speed from 1,500 - 7,500 RPM motor, Split Head, (20) independent Vertical spindles, with (14) spindles in "X" axis & (6) spindles in "Y" axis.(16) Split Head, Horizontal spindles, with (6+6) in "X" axis & (2+2) in "Y" axis; Boring block has "QUICK CHANGE" spindle system, -- Operator Interface:Weeke "POWERTOUCH" + Windows + WoodWOP 6.1 + operating system; "IntelCore 2 DUO" Processor;17" TFT Monitor; international keyboard, soft-touch keypad & industrial mouse; RS-232 Serial ports, USB ports; modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include:(1) NC controlled 0° - 90° "X/Y" grooving saw; 9,000 RPM, saw blade dia. 100 mm;(1) 13.4 HP (10 kW) Electro spindle router with HSK F3 adaptor, variable speed from 6,000 - 24,000 RPM.(1) 4-position ATC tool rack mounted on the side of the machine base.(1) Barcode Scanner.(1) AC unit for Electrical cabinet. -- Actual Model is WEEKE BHX 200 OPTIMAT
Call for Price
WEEKE BHX 500 OPTIMAT - CNC Machining Center (2-Head): -- Specifications: Flexible "TOP & BOTTOM" Machining Center that uses an innovative panel handling system. -- Working Capacity: Max. Workable part size "X" axis is 98.4" (2,500 mm), "Y" axis 39.37" (1,000 mm), max. material thickness 3.1" (80 mm).Min. workable part size "X" axis is 7.8" (200 mm), "Y" axis 2.7" (70 mm), min. part thickness 0.157" (4 mm). -- Positioning Speed:The "BHX 500 OPTIMAT" can reach movement speeds of 452 FPM (138 MPM) in "X" axis, 262 FPM (80 MPM) in "Y" axis & 164 FPM (50 MPM) in "Z" axis providing an unmatched working capacity with total safety. -- Worktables:Automatic RH infeed air table, automatic LH outfeed transfer conveyor with belts; both infeed & outfeed are "Robot Ready". -- Boring Units:(1) Top mounted boring block, 4.2 HP (3 kW), variable speed from 1,500 - 7,500 RPM & "QUICK CHANGE" drill bit adaptors.(19) Independent vertical spindles with 19-spindles in "X" axis.(8) Horizontal spindles with (4+4) spindles in "X" axis & (1+1) horizontal spindles in "Y" axis.(1) Bottom mounted boring block, 4.2 HP (3 kW), variable speed from 1,500 - 7,500 RPM & "QUICK CHANGE" drill bit adaptors.(19) Independent vertical spindles with 19-spindles in "X" axis.(8) Horizontal spindles with (4+4) spindles in "X" axis & (1+1) horizontal spindles in "Y" axis. -- Machining Units: (1) Top mounted 9 HP (6.7 kW) "ETP 25" router spindle, 1,200 - 18,000 RPM with RH rotation; uses "ETP 25" tool holders & ERC-32 collets.(1) Bottom mounted 9 HP (6.7 kW) "ETP 25" router spindle, 1,200 - 24,000 RPM with RH rotation; uses "ETP 25" tool holders & ERC-32 collets. -- Operator & Machine Control:WEEKE "PC85T Power Control" + Windows + WoodWOP 5.0 operating system; 17" TFT monitor; international keyboard, soft-touch keypad & industrial mouse.RS-232 Serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem; Ethernet connection, all mounted in a separate control console. - Real-time multitask processing; programs can be transferred via diskette or downloaded by wire. Control cabinet with built-in 1,500 Watt air conditioner for constant temperature & dust-free environment. -- Complete with:(2) Pneumatic part clamping devices; hand-held pendant control; sound enclosure, safety mats & safety fences/devices. -- Machine Features: The machine can work the panel from above & below at the same time and can produce (2) identical or mirrored panels per cycle with no difficulty.The "BHX 500 OPTIMAT" can also machine porous materials since the pieces are held with grippers directly managed by the numerical control; it can even process small pieces and carry out "through" machining.(4) Operating modes at each cycle, it can change automatically from top machining to bottom machining, to top & bottom machining together, either on (1 or 2) stacked panels. -- Actual Model is WEEKE - BHX 500 Optimat.
Call for Price
WEEKE VENTURE 08M CNC MACHINING CENTER (W/ATC, "C" AXIS); -- Specifications:Working Capacity "X" Axis is 127.9" (3,250 mm), "Y" axis is 49.2" (1,250 mm) for boring & 52.2" (1,325 mm) for routing, "Z" axis stroke is 7.2" (185 mm), max. material thickness 4.9" (125 mm). -- Positioning Speed: "X" & "Y" Axis 263 FPM (80 MPM, "Z" axis 66 FPM (20 MPM); The machine head travels on THK linear motion guides on all axes. -- Worktable:(6) Movable K-Table support rails w/side mounted raise-and-lower panel feeding rails, (2) vacuum pods per rail; (6) pneumatic backstops, (2) pneumatic side stops create (2) working zones.Setup assistance through the PC control display for precise rail & vacuum pod positioning. -- Boring Unit:3 HP (2.2 kW) Motor, variable speed from 1,500 - 7,500 RPM; (12) vertical "QUICK CHANGE" drill spindles, (8) spindles in "X" axis & (4) in "Y" axis.(6) Horizontal spindles with (2 + 2) in "X" axis & (1 + 1) in "Y" axis; -- Machining: (1) 12 HP (9 kW) Liquid cooled electro-spindle router with HSK F63 adaptor, w/programmable 1,250 - 24,000 RPM, constant torque from 9,000 - 24,000 RPM, RH or LH rotation; powered by a 11 KVA frequency inverter.(1) NC Controlled "C" axis for 360° horizontal processing; (18) Total ATC positions with (1) 8-position ATC tool changer plate mounted on the head for "on the fly" ATC & (1) 10-position ATC rack mounted at the RH side of the machine base. -- Operator & Machine control: WEEKE IPC "PC 85T Power Control" + Windows "XP" + WoodWOP 5.0 operating system; "Beckoff" PLC for (3) axes with linear, circular & helical interpolation.15" TFT Monitor with 2D / 3D "REAL TIME" graphics, industrial keyboard for data entry, CD R/W & 1.44 MB floppy drives, modem, USB slot, RS-232 serial interface for possible simple PC connection; all mounted in separate free-standing control panel. -- Complete with:(1) 100 m³/Hr Vacuum Pump, 2-zone safety mats (will stop machine if operator enters work area), safety fences, scrap conveyor, hand held pendant controller. -- Actual Model is WEEKE VENTURE 08 M BHC
Call for Price
AES SIRIUS 950M ATC CNC MACHINING CENTER (FEED THRU): -- Specifications:Automatic CNC feed through Point to Point Boring Machine that combines flexibility and high productivity.A perfectly suited solution for small to midsize companies & artisans in need of an automatic solution for precision drilling with a low-cost investment.Parts can be discharged at the opposite end of the machine for automated material handling or returned to the Operator for manual unloading. -- Working Capacity:Max. panel size on X-Axis is unlimited; Y-axis is 37.4" (950 mm); Z-axis is 2-3/4" (70 mm).Min. panel on size X-axis is 9.84" (250 mm); Y-axis is 3.14" (80 mm); Z-axis is 0.31" (8 mm). -- Positioning Speed: Panel feeding speed of 229 FPM (70 MPM); Y-axis at 229 FPM (70 MPM); Z-axis at 65 FPM (20 MPM).Axes positioning by AC drives & brushless Servo motors; the Panel moves in X-axis & the boring head moves in Y & Z-axes. -- Work Area:NC Controlled "Optical Material Sensor" creates a zero-panel reference point by reading the panel ends; this ensures that RH & LH (mirror image) panels will always be symmetrical.High precision clamping automatically positions the workpiece. Automatic presser moves independently and adjusts to workpiece thickness. Pneumatic side pusher makes locating workpiece accurate and efficient. LH Side pressure clamp with automatic adjustment & pneumatic locking according to the panel width.Scratch resistant air floatation tables make for ease of loading and unloading from either side of the machine. -- Boring Unit:HSD Drilling head; 3 HP (2.2 kW), variable speed from 4,500 - 8,000 RPM motor. (10) Independent vertical spindles on 32 mm centers; (5) spindles in X-axis & (5) spindles in Y-axis.(6) Horizontal spindles with (2 + 2) in X-axis & (1 + 1) in Y-axis.(1) X-Axis grooving saw for max. 120 mm dia. blade; variable speed from 5,500 - 10,000 RPM. -- Machining:HSD 7 HP (5.5 kW) spindle; variable speed from 1,000 - 18,000 RPM with manual tool change system.(1) 6-Position ATC Automatic Tool Change system with ATC rotary magazine. -- Operator & Machine Control: PC Based user-friendly, icon-driven control housed on the main machine base; displays programming graphics, functions, and machine data. -- Complete with: Users & Maintenance Manuals; ALPHACAM "Essential" is provided with machine for ease of programming at the Controller. -- Software Disclaimer:EX-FACTORY INC. offers NO warranty or support, written or implied concerning any/all "optional" or "additional" manufacturer or 3rd party software supplied with this machine. All software related issues including re-licensing fees/requirements/functionality & training is ultimately the sole responsibility of the "Buyer".Actual Model is: AES SIRIUS 950M - ATC
AYEN - SKB-50: Construction Hole Boring Machine for 32 mm System Boring -- (50) Spindles total. (2) Swivel heads with: (25) Spindles each; drills vertically from top & horizontally from rear; drills at any angle between: 0° - 90° with a positive stop at 45°. -- Equipped with 50-Spindle swivel head assembly.Converts quickly into: (2) 25-Spindle heads for double line boring; 5-1/8" min. distance between heads when line boring. -- Features: 3 HP - 3,450 RPM Gear box motor; 39" panel width cap. with: a 30-1/4" Drilling width. -- Complete with: (2) 39" Fences with flip stops; (3) pneumatic quick-set holddown clamps; quick fence setting gauge; foot pedal control for drilling cycle/head positioning.Seller states it was in good working condition when taken from service.
BIESSE SKIPPER 100 2-Head CNC Machining Center, with Infeed & Outfeed Tables – Seller states that machine was run (2) shifts from 2005 - 2021, then only a few hours per day since!Specifications: -- Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system.Working Capacity: -- "X" Axis 3,000 mm (118.11"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). -- Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31").Work Table: -- Left-hand infeed & Right-hand outfeed, Each with 20-1/2"; x 66"; x 35-1/2"; H infeed & outfeed areas with Fixed caster-type conveyor rails.Positioning Speed: -- "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM).Boring Units: -- (1) Top & (1) Bottom boring blocks, Each with: 3 kW (4 HP) Motor, Boring spindle speed 4,000 RPM, (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 3 kW (4 HP) Motor, Blade speed 5,000 RPM, & Blade diameter 150 mm (5.91").Machining: -- (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets.Operator & Machine Control: -- Mobile Control Console, with PC-Based Control, 18" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. -- Pedestal & Pendant controls.Equipped with: -- Universal transformer, 200 - 600 V, 50/60 Cy, 3-Ph., Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & TAPESWITCH "CONTROLMAT CKP" 24" x 72" Heavy-duty ribbed pressure-sensitive safety mat.Complete with: -- 7’ x 9’ x 35-1/2"; H Infeed Table, with Rails & Pusher. -- 6-1/2’ x 8’ x 35-1/2"; H Outfeed Table, with Transfer Belts. -- Handheld Bar Code Reader. -- Dust Manifold.Dimensions including Safety Fence: 307" x 184" x 98" H.
BIESSE SKIPPER 100 2-Head CNC Machining Center, with Infeed & Outfeed Tables – Seller states that machine was run (2) shifts from 2005 - 2021, then only a few hours per day since!Specifications: -- Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system.Working Capacity: -- "X" Axis 3,000 mm (118.11"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). -- Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31").Work Table: -- Left-hand infeed & Right-hand outfeed, Each with 20-1/2"; x 66"; x 35-1/2"; H infeed & outfeed areas with Fixed caster-type conveyor rails.Positioning Speed: -- "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM).Boring Units: -- (1) Top & (1) Bottom boring blocks, Each with: 3 kW (4 HP) Motor, Boring spindle speed 4,000 RPM, (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 3 kW (4 HP) Motor, Blade speed 5,000 RPM, & Blade diameter 150 mm (5.91").Machining: -- (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets.Operator & Machine Control: -- Mobile Control Console, with PC-Based Control, 18" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. -- Pedestal & Pendant controls.Equipped with: -- Universal transformer, 200 - 600 V, 50/60 Cy, 3-Ph., Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & TAPESWITCH "CONTROLMAT CKP" 24" x 72" Heavy-duty ribbed pressure-sensitive safety mat.Complete with: -- 7’ x 9’ x 35-1/2"; H Infeed Table, with Rails & Pusher. -- 6-1/2’ x 8’ x 35-1/2"; H right Outfeed Table, with Transfer Belts. -- (2) Handheld Bar Code Readers. -- Dust Manifold.Dimensions including Safety Fence: 307" x 184" x 98" H.
Call for Price
BIESSE SKIPPER 100 2-Head CNC Machining Center, with Outfeed TableSpecifications: -- Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system.Working Capacity: -- "X" Axis 2,500 mm (98.43"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). -- Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31").Work Table: -- Left-hand infeed & Right-hand outfeed Y-Beam with Clamps. -- 22"; W x 71"; L x 34-1/2"; H Air flotation loading table. -- 24"; W x 8’ L Unloading table, with 1-1/16"; Dia. Coated rollers on 9-1/8"; centers.Positioning Speed: -- "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM).Boring Units: -- (1) Top & (1) Bottom boring blocks, 1.7 kW (2-1/4 HP) Motor, Variable spindle speeds 4,000 - 6,000 RPM, Each with: (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 1.7 kW (2-1/4 HP) Motor, Blade speed 5,000 RPM, Right-hand rotation, & Blade diameter 150 mm (5.91").Machining: -- (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, Max. tool dia. 40 mm (1.57"), HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets.Operator & Machine Control: -- Mobile Control Console, with PC-Based Control, 19" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. -- Pendant control.Equipped with: -- Universal transformer, Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & 3-1/2’ x 12-1/2’ Coin pattern pressure-sensitive safety mat.Complete with: -- User Manual. -- 6-1/2’ x 8’ x 35"; H Outfeed Table, with (9) 1/2"; W Transfer Belts.Dimensions including Safety Fence: 292" x 196" x 87" H.
Call for Price
BIESSE - SKIPPER 100 L, ...CNC Machining Center (2-Head): -- SpecificationsFlexible "Top & Bottom" Machining Center that uses an innovative panel handling system. -- Workable Part Size"X" Axis is 118" (3,000 mm); "Y" axis is 39.4" (1,000 mm); max. part thickness of 2.4" (60 mm).Min. workable part size in "X" axis is 3-1/2" (90 mm); "Y" axis is 2.7" (70 mm); "Z" axis is 0.3" (8 mm). -- WorktableAutomatic LH infeed transfer conveyor with: Belts & rollers; Automatic RH outfeed transfer conveyor with: Belts & rollers; Infeed/outfeed table is: "Robot Ready". -- Positioning Speed"X" Axis is 394 FPM (120 MPM); "Y" axis 295 FPM (MPM); "Z" axis is 98 FPM (30 MPM). -- Boring Units (1) Top mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (29) vertical spindles: (17) Spindles in "X" axis & (12) spindles in "Y" axis. -- (10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis. -- (1) "X" Axis grooving saw with: 2.2 HP (1.7 kW) Motor - 5,000 RPM; 150 mm dia. blade. -- (1) Bottom mounted boring block: 4.2 HP (3 kW), 4,000 RPM; (29) Vertical spindles: (17) Spindles in "X" axis & (12) spindles in "Y" axis. -- (10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis. -- (1) "X" Axis grooving saw with: 2.2 HP (1.7 kW) Motor - 5,000 RPM; 150 mm dia. blade. -- Machining(1) Top mounted 4.8 HP (3.5 kW) electro-spindle; 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change; ERC-32 tool holders & RC-32 collets. -- (1) Bottom mounted 4.8 HP (3.5 kW) electro-spindle; 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change; ERC-32 tool holders & RC-32 collets. -- Operator InterfacePC Front-End with: "BIESSE Work" + Windows Operating System; 15" color monitor; international keyboard with soft touch keypad & industrial mouse.RS-232 Serial ports for possible downloading from an office PC; USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with: Built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Universal transformer for voltages from: 200 - 600 Volts, 50/60 Hz, 3-Phase; automatic lubrication system for guides & ways; sound enclosure and complete set of safety fences/devices; machine docs & manuals.
Call for Price
BIESSE - SKIPPER 130: CNC Machining Center (2-Head) -- Specifications Flexible "Top & Bottom" Machining Center that: Uses an innovative panel handling system. -- Working Cap.Max. workable part size: "X" Axis is 118" (3,000 mm); "Y" axis is 51.1" (1,300 mm); max. part thickness of 3.5" (90 mm).Min. workable part size: "X" Axis is 3-1/2" (90 mm); "Y" axis is 2.7" (70 mm); "Z" axis 0.3" (8 mm). -- WorktableLH Infeed air cushion transfer table & part clamping devices; automatic RH outfeed transfer conveyor with belts; outfeed is "Robot Ready". -- Positioning Speed"X" Axis is: 394 FPM (120 MPM); "Y" axis: 295 FPM (MPM); "Z" axis: 98 FPM (30 MPM). -- Boring Units(1) Top mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (31) vertical spindles; (18) spindles in "X" axis & (13) spindles in "Y" axis.(10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis; (1) "X" axis grooving Saw with 2.2 HP (1.7 kW) motor - 5,000 RPM; 150 mm dia. blade.(1) Bottom mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (31) Vertical spindles; (18) spindles in "X" axis & (13) spindles in "Y" axis.(10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis; (1) "X" axis grooving Saw with 2.2 HP (1.7 kW) motor - 5,000 RPM; 150 mm dia. blade. -- Machining(1) Top mounted 6 HP (4.5 kW) electro spindle; 1,800 - 24,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change.(1) Bottom mounted 6 HP (4.5 kW) electro-spindle; 1,800 - 24,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change. -- Operator & Machine ControlPC Front-End with: BIESSE "WORKS" + Windows "XP" Operating System; 15" color monitor; international keyboard with soft touch keypad & industrial mouse.RS-232 Serial ports for possible downloading from an office PC; USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with a built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Pneumatic part clamping: Air table infeed & motorized outfeed transfer conveyors; universal transformer for voltages from: 200 - 600 Volts; 50/60 Hz; 3-Phase; automatic lubrication system for: Guides & ways; safety mats/fences/devices; machine docs & manuals.
Call for Price
BIESSE ROVER 20 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working field: "X" Axis 113.9" (2,893 mm); "Y" axis 37.4" (950 mm); "Z" axis stroke is 3.9" (100 mm), max. panel thickness 2-1/2" (65 mm). -- Positioning Speed:"X" Axis at 246 FPM (75 MPM); "Y" axis 147 FPM (45 MPM); "Z" axis 49 FPM (15 MPM)."X" Axis moves on high precision prismatic guides and ground helical rack; "Y" & "Z" axis via hardened ground ball screw. -- Worktable:(6) Pneumatically locked & manually positioned panel supports with (2) vacuum cups each.(2) Working zones with: (6) Pneumatic backstops; (2) pneumatic side & (2) center stops; stops raised & lowered automatically by start/stop of machining cycle. -- Boring Unit:(1) 2.3 HP - 5,135 RPM Motor; (10) vertical spindles independently operated with (6) in "X" axis & (4) in "Y" axis.(6) Horizontal spindles: (2 +2) in "X" Axis & (1 + 1) in "Y" axis; 2-1/2" (65 mm) max. boring depth.(1) "X" Axis grooving saw with: 120 mm Dia. blade - 5,200 RPM. -- Machining: Equipped with: (1) 9 HP (6.6 kW) Air-cooled "Quick Change" electro spindle with ISO 30 adaptor.Router is driven by: 10.2 HP (7.5 kW) Inverter for variable speed from 1,000 - 24,000 RPM; RH & LH rotation.(1) 3-Position automatic tool changer mounted at the back of the machine for "on the fly" ATC. -- Operator & Machine Control: Separate Control Console with: CNi "NC 410" Operating System housed in air-conditioned cabinet.8" LCD Monitor: Displays programming graphics, numerical & function keyboard; 512 KB RAM memory; (1) "UPGRADED" USB drive.RS-422 Serial port for PC and RS-425 port for inverter connection; EPROM for machine data & subroutines; machine runs production programs while programming and editing. -- Complete with:Stabilized autotransformer for voltages between 200 - 600 Volt 50/60 Hz; (1) 100 cbm/Hr Vacuum Pump; triple photocell barrier; assortment of misc. parts and tooling; Users operator/maintenance manuals & backup disks. -- Actual Model is: BIESSE - ROVER 20.
BIESSE ROVER - A 3.30: CNC Machining Center (w/ATC/Boring) -- SPECIFICATIONSWorking cap. - "X" Axis: 118" (3,000 mm) any unit; "Y" Axis: For routing, 45.2" (1,150 mm; "Y" Axis for: Boring; 49.6" (1,260 mm); "Z" Axis stroke: 7.8" (198 mm); max. material thickness: 5.9" (150 mm). -- Positioning Speed Both "X & Y" Axis is: 262 FPM (80 MPM); "Z": 111 FPM (34 MPM); helical rack & pinion drive: On "X" axis; precision ball screw on: "Y & Z" Axes. -- Worktable (6) Support rails with: (3) Vacuum pods per rail; (6) pop-up back stops, (4) pop-up side-stops; (2) independent working areas.Prepared for (optional) "quick fit" vacuum outlets for: Optional clamping of small or awkward shaped parts; each work zone with (1) "Quick connect" vacuum outlet: For custom vacuum fixtures. -- Boring Unit(14) Independent vertical boring spindles forming an L-configuration with: (7) Spindles in "X" Axis & (7) spindles in "Y" Axis.(6) Horizontal spindles with: (2 + 2) in "X" axis; (1 + 1) in "Y" Axis; (1) "X" Axis grooving saw for: Max. 120 mm dia. blade. -- Machining (1) 9.5 HP (7 kW) Vertically mounted HSD electrospindle router with: HSK F63 Adaptor.Inverter driven 1,000 - 24,000 RPM with: Max. torque from 12,000 - 24,000 RPM. (1) 18-Position "Ride-Along", "on the fly" automatic tool changer. -- Operator & Machine ControlPC Front-End with: BIESSE "XP600" + Windows "XP" + BIESSE "WORKS" Operating System.INTEL "Celeron" 2.0 GHz Processor; 4 GB Hard drive; 15" color monitor; international keyboard; soft touch keypad & industrial mouse; RS-232 serial port; (1) 1.44 MB floppy disk drive.BiesseWORKS: An easy CAD program that can be done from the office or at the machine; Operating System: Real-Time multitask processing; programs can be transferred via diskette or downloaded by wire. -- Complete with: (1) 250 M³/Hr Vacuum Pump; 11 KVA stabilized autotransformer for voltages between: 220 - 600 Volts. Equipped with: Centralized manual Lubrication System for guides & ball screw; built-in 1,500 W air conditioner for constant temperature & dust-free environment. Emergency stop rope & sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Actual model: BIESSE ROVER - A 3.30
BIESSE ROVERB 4.35 CNC MACHINING CENTER (W/ATC & BORING) -- Specifications:Working capacity "X" Axis is 126" (3,200 mm) any unit, "Y" axis for routing is 51.7" (1,315 mm), vertical drilling "Y" axis is 59" (1,495 mm), "Z" axis stroke 6.3" (160 mm). -- Positioning speed:"X" & "Y" Axis is 262 FPM (80 MPM) & "Z" axis is 66 FPM (60 MPM). -- Worktable:(6) Panel support rails with (4) lifting bars to assist with panel loading/unloading, (3) "ATS" vacuum pods per panel support; digital display readouts for rail & pod placement according to the programs, -- (2) Independent working areas with pop-up locating pins for positioning of parts on the worktable; prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick Connect" vacuum outlet for custom vacuum fixtures. -- Boring unit:(1) 2.5 HP (1.7 kW) motor, variable speed up to 6,000 RPM: (12) Independent vertical boring spindles with (6) spindles in "X" axis & (6) spindles in "Y" axis. -- (6) Horizontal spindles with: (2 + 2) in "X" axis & (1 + 1) in "Y" axis; (1) "X" axis grooving saw with 120 mm dia. blade. -- Machining Unit:(1) 10 HP (7.5 kW) Vertically mounted HSD "Electro-Spindle" Router with HSK-F63 adapter, inverter driven 1,000 - 20,000 RPM with max. torque from 12,000 - 20,000 RPM. -- (1) 10-Position ride-along ATC for "on the fly" tool change. -- Operator Interface:PC Front-End with: BIESSE "XP 600" + Windows "XP" operating system; INTEL "Celeron" 2.0 GHz processor; 4 GB Hard drive; --15" Color monitor, international keyboard, soft touch keypad & industrial mouse, RS-232 serial port, USB ports, CD ROM & 1.44 MB disk drives. -- Separate control panel with built-in 1,500 W air conditioner for constant temperature & dust-free environment; 11 KVA Stabilized auto-transformer for voltages between 200 - 600 Volts. -- Complete With:(1) 100 m³/Hr Vacuum Pump; centralized manual lubrication system for guides & ball screw; emergency stop rope; safety mat protection barrier & sound absorbing protective head enclosure with debris curtain around bottom edge. -- Option Included: Pre-arranged for a "C" axis for 360° horizontal processing capabilities. -- Actual Model is BIESSE ROVERB 4.35
Call for Price
BIESSE - TECHNO-LOGIC: Feed Through Boring Machine Specifications -- 125.9" (3,200 mm) Max. opening cap.; 7" (180 mm) min. opening. -- Right & left horizontal boring unit with: (20) Spindles ea. (right unit motorized). -- (8) Bottom vertical supports; each support accommodates (2) Boring blocks driven by: (2) 1.8 HP Motors (2,800 RPM); all boring blocks: 96 mm wide; 0 - 90° swivel; pneumatic locking of the drill block. -- (2) Top vertical supports; each support accommodates:(2) Boring blocks driven by: (2) 1.8 HP Motors (2,800 RPM); all boring blocks: 96 mm wide; 0 - 90° swivel; pneumatic locking of the drill block. -- All supports equipped with MICRO-DIAL Indicator for: Positioning, pneumatic locking; individual adjustment for boring block: Distance; boring depth; hydraulic brakes.Equipped with: -- Double belt through feed Conveyor with: Pneumatic squaring. -- (2) Side pressure clamps; (6) top pressure clamps. NOTE: (2) Machines available!
BUSELLATO JET 100 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications:Working field: "X" Axis 120" (3,048 mm); "Y" axis 49" (1,244 mm); "Z" axis 3.9" (100 mm). -- Positioning Speed:"X & Y" Axes 328 FPM (100 MPM) each; "Z" axis 98 FPM (30 MPM); sll units ride on precision guides & ways."X" Axis uses a helical rack-and-pinion system; "Y & Z" axes use ball screws; all axes are driven by digital, brushless AC Servo motors. -- Worktable:(6) Panel supports with: (4) Lifting bars & digital readouts for manual rail & pod locations according to the program. (4) Vacuum pods per support rail; (2) independent working areas. -- Boring Unit:TF 20 Boring head with (14) vertical spindles: (8) Spindles in "X" axis & (6) spindles in "Y" axis.(4) Horizontal spindles with: (1 + 1) in "X" & (1 + 1) in "Y"; (1) "X" axis grooving saw for max 120 mm blade. -- Machining:(1) ISO-30 Spindle(1) 15-Position ATC tool changer mounted at the rear of the machine. -- Operator & Machine Control:PC-Based control with "GENESIS" + Windows "2000" Operating System.Includes Color CRT monitor, full keyboard & mouse; 256 MB RAM, 10 GB hard disk, CD ROM (52X), 1.44 MB floppy drive; (4) serial ports, (1) parallel port, (2) USB ports. "GENESIS" Operating System with: Large onboard program storage, ethernet connection, specific function controls, and internet troubleshooting capabilities. -- Complete with:(1) 100 m³/Hr Vacuum Pump, Bar Code Scanner, Belt Conveyor for scrap removal. -- Actual Model is BUSELLATO JET 100
