VIET (BIESSE) OPERA 5-3.3 XLL Denibbing Sander with 53" Width Capacity:53" Width cap. Denibbing Sander with a patented combination of rollers and rotating/oscillating discs make the VIET Opera Sanding Machine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet goods, shutters, face frames, furniture, and much more. Ideal solution for all sanding applications including whitewood, stain, and sealer coats. Head Configuration: -- 1st Unit: (11) Rotating discs with Slide out system for easy setup. 15 HP Electronic Inverter. -- 2nd & 3rd Units: 300 mm dia. Roller Brushes (Hub for 36 strips). Oscillating System with electronic 7.5 HP inverter. Specifications: -- Working Width: 1,350 mm (53.15"). -- Constant Pass Line TM (Fixed Table). -- Working Height Opening: 200 mm (7.87"). -- Laser Electronic Positioning for working thickness. -- Min. processing thickness 3 mm, Max. processing thickness 200 mm. -- (2) Longitudinal rotating brush-backed sanding rollers. -- 5" Rotating sanding discs. -- Forward speed 3-16 m/Min. -- Vacuum Table with 5.5 HP Motor, Electronic System, IPC Control. -- 50-Shore Rubber Conveyor. -- Front & Rear Extension Rollers. -- Emergency stop.Equipped with: -- IPC Touch-screen control: Simple & user-friendly "TOUCH SCREEN" IPC control with a color monitor. This control system supports the management of all machine parameters. -- PC processor provides control and feedback information to the machine in real time. -- The software version can be configured for right and left-handed operation. -- Text-free user interface; icons facilitate the operator's task. -- Optional rotating blower attachment at the back to blow off dust particles as items come off the machine. -- Includes matching transformer for 600 V to 460 V.

BIESSE-VIET OPERA 5-3.3 Denibbing Sander with 53" Width Capacity:53" Width cap. Denibbing Sander with a patented combination of rollers and rotating/oscillating discs make the VIET Opera Sanding Machine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet goods, shutters, face frames, furniture, and much more. Ideal solution for all sanding applications including whitewood, stain, and sealer coats. Sanding Drums - Made of steel, mounted on eccentric Shaft, to adjust the sanding belt thickness - Drum rubber with helicoidally grooves, balanced and rectified - Dust collection hoods with special design for best performance - Pneumatic ON/OFF of unit from panel control - Sanding belt tension rollers made of steel, balanced and rectified - Front pressure rubberized roller (1 roller) - Back pressure rubberized roller (1 roller)Head Configuration: -- 1st Unit: (15) Rotating discs with Slide-out system for easy setup. 11 kW (15 HP) Electronic Inverter with inverter speed control. -- 2nd & 3rd Units: 300 mm dia. Teflon hub for 36 strips. Oscillating System with electronic 4 kW (5.5 HP) inverter speed controlled. Specifications: -- Working Width: 1,350 mm (53.15"). -- Constant Pass Line TM (Fixed Table). -- Working Height Opening: 200 mm (7.87"). -- Laser Electronic Positioning for working thickness. -- Min. processing thickness 3 mm, Max. processing thickness 200 mm. -- (2) Longitudinal rotating brush-backed sanding rollers. -- 5" Rotating sanding discs. -- Forward speed 3-16 m/Min. -- Vacuum Table with 7.5 kW (10 HP) Motor, Electronic System, IPC Control. -- 60-Shore Rubber Conveyor belt with ground laminair surface. Pneumatic belt tracking -- Front & Rear Extension tables with rollers. -- Emergency stop.Equipped with: -- IPC Touch-screen control: Simple & user-friendly "TOUCH SCREEN" IPC control with a color monitor. This control system supports the management of all machine parameters. -- PC processor provides control and feedback information to the machine in real-time. -- The software version can be configured for right and left-handed operation. -- Text-free user interface; icons facilitate the operator's task. -- Optional rotating blower attachment at the back to blow off dust particles as items come off the machine. Electric Cabinet: -- "Check panel" alarms with LED - Automatic Star/Delta starter for main motors - Pad-lockable main switch - Thermal relay protections on all motors - Amperometer for all main motors - Electronic digital readout with automatic thickness positioning - Motor protection IP 54Actual model is OPERA 5-3.3 XLL. Year on nameplate is 2020 but not connected until 2021. Weight is 4600 KG (10,200 Lbs).This machine works great and has been very lightly used in a small shop that found with the small volume of work this machine was Too High in capacity so better off hand sanding.

WEB MECAHNICAL JET 10M Jet Air Oven Supply Side complete with the following: -- 400,000 BTUH rating, 3,200 CFM forward curved blower, 5 HP motor 575 V /3 Ph /60 Cy. -- Inlet filter section HEPA 99% DOP rated, Magnehelic gauge across the filter section. -- Thermometer to show outlet temperature, Thermostat to set and control temperature design from 60° -70° C, -- Jets designed to control flow across the belts. Exhaust Side complete with the following: -- Vane axial fan set to exhaust 600 CFM,1/2 HP motor. -- Direct drive fan with motor out of air stream, external grease fittings for lubrication.Heating Module: -- Air makeup sized for 3,200 CFM, 2 HP motor, rated for 400,000 BTUH. --Fan to exhaust through 2"; pleated filter and 12"; HEPA filter, Down discharge,3 HP motor, 3,200 CFM @ 2.0"; E.S.P. -- Engineered for 90° F temperature rise, 0.4 MBTU/hr hydronic coil, features FUJI temperature selector. Conveyor: -- Robust 10-gage steel frame, Novo 40 grey belt designed for up to 90° C and with Auto tracking mechanism. -- Large size 6"; driver and idler pulleys, Support pulleys 3"; as required. -- Heavy duty NORD gear box and a 2 HP direct coupled motor. OPTIONAL (Not included in Price):IR Adder (Lamps): -- Three (3) MW IR lamps in the center of the oven, Three (3) MW IR lamps at the end of the oven, -- Heated length of lamps 54";, dual gold plated element, 3,200 watts per bulb. -- Lamps are designed to sit between the jets on the oven with lamps 8"; (200 mm) above belt and 8"; apart. - Please add ...$ 7,700Control Panel for the above (600 V - Electric) complete with: -- Line interlock, E-stop, fuses, disconnect switch, DC power supply. -- Phase angle controller to control two (2) banks of three (3) lamps. CSA approved panel. - Please add ...$ 12,100BOILER: -- One (1) RBI dominator boiler "DB 600" to supply up to 600,000 BTUH. - Please add ...$ 18,900

WEB MECHANICAL HYDRONIC OVEN - Low Velocity Flash Off - STAGE # 1 and High Velocity Bake Oven - STAGE # 2 STAGE # 1, Low Velocity Flash Off Oven. -- The oven consist of one (1) only hot water oven, 14' wide x 9' high x 30' long with Air flow requirement of 30 FPM/ 9,000 CFM.Supply side complete with the following: -- 400 000 BTUH heat exchanger -- Motor/blower, 2 HP 575 V / 3 Ph / 60 Hz -- Thermometer to show outlet temperature -- Thermostat to set and control temperature to design temperature -- RTD's (1) for accurate oven dispersion temperature -- Eighteen gage galvanized steel panels -- Perforated metal side walls for even air distribution -- Design temperature of 30 -40°C -- Adjustable inlet mixing damper with intake filter (70% recycle) -- Exhaust fan for combustible gasesExhaust will be complete with the following: -- Size 14 direct drive aluminum fan wheelset to exhaust 30% of the contaminated airflow (2,500 CFM) -- Direct drive with the motor out of air stream -- External grease fittings -- Fan module c/w aluminum extrusions and galvanized panels, and will be complete with HEPA style filter, -- DWDI fan, space for hot water heat exchanger STAGE 2 HIGH-VELOCITY OVEN BAKEThe oven consist of one (1) only hot water oven, 14' wide x 9' high x 20' long with Air flow requirement of 50 FPM/ 9,000 CFM Supply side will be complete with the following: -- 1,500,000 BTUH heat exchanger -- 10,000 CFM -- Motor/ blower 5 HP 575v / 3 Ph / 60 Hz -- Thermometer to show outlet temperature -- Thermostat to set and control temperature to design temperature -- Eighteen gage galvanized steel panels c/w 3" insulation -- Perforated metal side walls for even air distribution -- Design temperature of 40 - 60C 104 - 140 F -- Adjustable inlet mixing damper with intake filter (85% recycle) -- Exhaust fan for combustible gases Exhaust will be complete with the following: -- -- -- Size 12 direct drive aluminum fan wheelset to exhaust 15% of the contaminated airflow (1,500) CFM) -- Direct drive with motor out of air stream -- External grease fittings There will be two (2) air knives one at start of the oven and one art the exit to control heat and fume exhaust Air knives will be complete with Multivee filters for inlet air Fan module c/w aluminum extrusions and galvanized panels will be complete with HEPA style filters, DWDI fan, space for hot water heat exchanger.

APEX LS-TS 300 Brush / Denibbing Sander;The Apex LS line of lineal sanders are designed for effective multi-sanding in one pass with a working width of 12"; (300 mm). The LS-T sander has two top sanding heads, one left and one right sanding head with a motorized conveyor. Machine is designed to process the top side of product in a single pass.Function: -- The sanding units are adjustable in height, width, rotation and RPM, in order to set them exactly to suit different shaped profiles and applications. The LS-TS lineal sander incorporates large diameter sanding heads to increase sanding dwell time to achieve aggressive whitewood sanding at increased feed speeds. -- All sanding heads are reversible and can be fitted with double sided abrasives to accommodate for multiple applications such as raw wood sanding, sealer / primer sanding or wire brushing/ distressing. Standard Features: -- Heavy-duty frame design -- Counter rotating large diameter sanding heads -- Conveyor belt feed with four spring loaded hold-down rollers -- Constant height of through feed -- Digital readout counter for sanding heads -- Four – 4"; (100 mm) dust extraction outlets -- All sanding heads have reversible rotation -- Machine can easily be moved with pallet jack, fork lift or rolled on casters Specifications: Thickness of Work-piece 0"; - 4";, 100 mm Conveyor Belt Width 12"; - 300 mm Motor on each spindle 1-1/4 HP Conveyor motor 1 HP Speed of Spindles 100 - 500 RPM Brush height 12"; Top heads / 4"; side heads Feed Belt Speed 10 - 50 FPM – variable 480 Volt / 3 Phase / 60 Hz Total amps - 23 Machine Weight 1,950 Lbs Machine comes with aluminum hubs and loaded with abrasives

This listing is for a commercial grade heater that can be used for heating your facility or if outside air is ducted in can be an air make-up unit This is designed for inside installation. It was not originally used as air make up but in mild climates will be able to be used that way with duct work that needs to be built on site by a contractor. Foot print size of the unit is 46" x 46" Height 144 "Natural gasCFM 7,500BTUH input 400,000BTUH output 320,000Fan Type belt drivenHP (1) 2 HP fanFlue size 8" qty (1)Unit weight 1,250 lbs

BINKS - COMET 3, ...Paint PumpMounted on a roll-around cart.

Infra Red heating unit designed to be used over a conveyor (not included). Currently set up to roll a shop cart under to assist us in some finishing processes. This is a two zone unit with an overall heating area of 56 sq ft. between the two infrared panels. Each section of infrared panels is 4'x7' allowing you an array of options to meet your needs. They do however, get controlled off the same control panel. --Unit has a mechanical percentage timer in control cabinet that is used to cycle power on and off as a means to control temperature. Controlling the distance from emitters to work surface is your other form of temperature control. The patented Black Body emitter consists of a serpentine configuration of NiChrome wire embedded in a refractory pad that is 12 inches square and approx.3/8" thick and coated with a high-emissivity black coating. -- Unit is complete and will need some retrofitting to meet your specific requirements.

BLACK BROTHERS - 22-D-875-56, ...Roller Coater56" Nominal length; 8-3/4" dia. applicator, Chrome doctor roll, upper elevator and top only. -- Setup to 0" - 6" thick. -- Smooth EPDM applicator rolls and Chrome doctor rolls. -- Variable feed speed drive, pass line height 34". -- Drip Pan, Feed Pan, Continuous Flow Trough to be Stainless Steel or Teflon Coated. -- Trough for continuous flow 1" pneumatic pump and hose to supply product.Complete With: -- NEMA-12 Electrical enclosure, operating control bars, magnetic brake, electrical interlocks, reverse lockout and cleanup pan.

BLACK BROTHERS - 22-D-875-56, ...Roller Coater56" Nominal length; 8-3/4" dia. applicator, Chrome doctor roll, upper elevator & top only. -- Setup to 0" - 6" thick. -- Smooth Chrome applicator rolls and Chrome doctor rolls. -- Stationary feed speed drive, passline height 34". -- Drip Pan, Feed Pan, Continuous Flow Through. -- Trough for continuous flow 1" pneumatic pump and hose to supply product. -- (30) Day warranty for workmanship and manufacture's warranty for all parts used.Complete with: -- NEMA-12 Electrical enclosure, operating control bars, magnetic brake, electrical interlocks, reverse lockout, and cleanup pan.

BURKLE - VBM 1688, ...Stain Wiping MachineSingle sided machine, 1,600 mm wide; 2-Brush Panel Cleaner (TAMPICO brushes). Features: &#9679 Heads can be positioned as needed spacing between the brushes by sliding brackets. &#9679 Brush raising & lowering accomplished by means of handwheel adjustment. &#9679 Brushes are removed at side of machine by sliding out of shroud/channel support rail. &#9679 Safety bar checks part thickness for overthickness parts. &#9679 SIEMENS Control to set rotation speeds & feed belt speed. &#9679 Rigid Aluminum bolted base construction. &#9679 Solid feed belt (NO vacuum holddown)

BURKLE - Roll Coat, ...Lacquering Line with: UV Curing & HEESEMAN Sander. General Line Data:Working width: 1,300 mm (51")Working height: 900 mm +/- 20 mm (35 - 36")Production speed: 10 MPMPassing height 3 - 80 mm (3/16" - 3-1/4")Shortest length of boards 350 mm (14")Operating side: Right-hand side Electric:Operating voltage: 480 Volt, AC, 60 Cycles, 3-PhaseControl voltage 24 Volt, DC LINE CONFIGURATION:STATION #1 - 2-Roll Coating Machine - "SAS 1300" (Filling Machine) For single-sided application of base coating materials suitable for circulation. The machine is suited for base coating veneered, boardlike workpieces or solid components simultaneously filling fine grain or hairline cracks in the veneer by means of the Reversing Smoothing Roller. Application Unit:- Separate, infinitely adjustable frequency-controlled direct drive for the application roll. Rubber-covered application roll of double thickness of the rubber covering, with corrosion-resisting roller ends.- Quickchange coupling for the application roll with hinged bearings and an OLDHAM coupling. Oscillating scraper blade for the application and doctor rolls with an ergonomically designed scraper blade support is quickly removable for cleaning, and can easily be placed back by a self-locking worm gear.- Separate, infinitely adjustable frequency-controlled direct drive for the reversing Doctor Roller. - Change of rotation of the Forward Doctor Roll by an electric reversing switch in the Control Panel.- Hard chromium-plated doctor roll with a fine adjustment by a worm gear gap adjustment via a mechanical digital indicator in the handwheel.- Hood, which can easily be opened, features integrated radiation protection. Smoothing Unit: - Hard chromium plated smoothing roll with an infinitely adjustable, frequency-controlled direct drive. - Scraper blade for the smoothing roll with an exchangeable plastic blade. - Distance from the smoothing roll to the application roll approx. 0.5 mm, for the automatic return of the material, readjustable when regrinding the application roll. Material Circulation System:- Pneumatic double diaphragm pump (R 1“) with pressure reducing valve & stop for careful lacquer feed, particularly suited for very viscous and solvent-free lacquer systems.- Material supply by means of a chemical resistant hose and special steel pipe, ergonomically designed and fitted underneath the hood, with discharge hose and stop.- Large-dimensioned lateral collecting troughs and return gutter made of special steel.- Spring-loaded end plates with exchangeable screwed-on plastic coverings.- Suitable for one way containers of 30 liters contents (max. height 400 mm). Motorized Height Adjustment:- (2) Separate, motorized precision lifting gears wit

CEFLA ROCTRE D Automatic Spray Finishing Machine for HIGH VOLUME PRODUCTION and includes (2) two integrated cleaning trolleysThickness: Max. 50 mm (2"); Min. 5 mm (0.2").Maximum Line speed: 20 MPM (65 FMP).Equipment Specifications:CEFLA, model ROC 3 D. Is a Two-arm reciprocating Spray Machine: -- Parts are fed under the Part Reading Bar to measure size and spray parameters on a continuous CFB belt conveying system. -- Lacquer recovery and belt cleaning are accomplished by means of a "cleaning trolley" located under the existing end feed belt. Made up of counter-rotating rollers with scraper and belt cleaning unit, with (3) rollers and stainless-steel troughs: all the rollers are fitted on the motorized trolley longitudinally removable by hand pulling of trolley out. -- Powered outfeed tilt-able belt lifts to approach the cleaning trolley. -- (2) Oscillating arms equipped to accept a maximum of (8) guns, four per arm, and driven by a Brushless servo motor.There are (2) Separate lacquer feeding circuits with recycling system. -- This is a fully pressurized spray cabin with an exhaust air filtering system for overspray using a double dry filter set, primary filter, and secondary. -- Electronic control cabinet to monitor spraying functions.The booth consists of sandwich paneling, and air is pushed in through (2) air intake ducts (positioned between guns) above the slanted perforated top panels made of fine filter material, which help to reduce turbulence. Parts running through the sprayer can be viewed by means of a large front viewing window/access panel, which can be lifted to access the guns and interior of the sprayer. Photos show equipment while it was still in service - currently being reconditioned.Note: EX-FACTORY’s Logistics Department is experienced and set up to provide “Full Service Logistics"; from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door).

CEFLA EASY 2000D Reciprocating Feed Through Sprayer and Vertical Oven Finishing Line:This line is still in operation with the original owners, it have never run full time, there are weeks when it is 1 day per week. It is recommended with a line of this age to do a full recondition prior to or as it is being installed. If that is not possible, it is still running and can be seen that way. CEFLA Complete 52" (1,300 mm) Finishing Line with: SORBINI Panel Cleaner, "EASY D 2000 W" Reciprocating Sprayer, Conveyor(s), and CEFLA Hot Water Vertical Oven. The line is composed of the following:001) Belt conveyor CEFLA "TN 2500"002) Panel cleaning / brushing machine SORBINI "VS 33"003) Automatic spraying machine CEFLA "EASY 2000 DRY SYSTEM" with pressurized cabin004) Transfer conveyor005) CEFLA PIEFFE PF2 VL/6 7500 pass through oven006) Vertical Oven, (3) chambers with belts CEFLA "VN 2000"007) Unloading Conveyors

CEFLA - MITO, ...Complete Spraying System with SORBINI Cleaning Brush.Reciprocating Feed Through System for Waterborne & Solvent-Borne Coatings: The max. flexibility and technology for the continuous spraying of any kind of raised panels.Features: -- Machine designed with a solid structure: LASER 3D; full accessibility, thanks to the wide use of glass superficies, access doors, and extractable parts. -- Conveying System with: CFB Belt with sealed edge, driven by inverter. -- Axis driven by the powerful brushless motor and by a sophisticated toothed belt handling system, with recycling sphere bearings. The best performances in speed, acceleration, and the softness in guns motion allows to achieve the max. application quality. -- The central axis holds: (1) Gun supporting arm (removable), equipped with quick-release (predisposed for max. 4 guns); complete with: Manual height adjustment, (3) high pressure lacquer feeding circuits with recycle; lacquer filters with stainless steel fittings. -- Exclusive pressurization flows analysis and sophisticated air diffusion plenum with double fan for air intake and filtration results in: Higher lacquer saving, better machine cleaning. Circulation provided by floor mounted MZ RLQ 560, Direct-drive 4 KW , 1755 RPM motor. -- Tanks with supporting areas for filters by COLUMBUS or ANDREAS-type filters.Electronic Scanner for: Shape reading and workpieces positioning; max. efficiency in managing the guns' spraying.TECHNICAL FEATURES:Total length of the machine: 4,650 mmTotal width of the machine: 3,850 mm (4,210 mm with fan)Machine structure height: 2,500 mmElectronic control unit with: PLC and software for machine managing.Main control cabinet: Pressurized, placed at the machine infeed, along the service side complete of cable and wiring system for connection to all the users.Spraying parameters management is operated by PLC:Working programs setup, measurements of the lacquered surface & lacquer consumption, 5" color touchscreen display for diagnostic and control; possibility to exchange data from and to PLC managing complete Lines.Possibility to manage pumps for color change/washing (up to 4 pumps). -- Comes with: 2006 SORBINI/CEFLA VS/33-ACT-F, 460/3/60 Panel Cleaning Brush with brush for the top roll followed by a nozzle blow off station. (1) Head, 53" width cap. Top brush head; features timed rotating air blowers, air liner blower with nozzles. Upper mounted Anti-static ionization bar; 400 RPM brush speed.With CEFLA TM 3000, 600/3/60 V, infeed belt conveyor. -- Line is disconnected/dismantled per last (8) photos.

CEFLA "ROTOSTAIN RT 2000 10 + 10 Rotary Stain Machine with: -- 20 Guns; utilized for automatic application of stain material on workpieces; the "Roto-Stain ROT 10 + 10" represents a new generation Spray Machine from CEFLA, the leader in CEFLA "ROTOSTAIN RT 2000 10 + 10 Rotary Stain Machine with: -- 20 Guns; utilized for automatic application of stain material on workpieces; the "Roto-Stain 2000 10 + 10" represents a new generation Spray Machine from CEFLA, the leader in technology development for spraying applications. -- The "Roto-Stain 2000 10 + 10" incorporates CEFLA's previous innovative developments into a machine with maximum capabilities (line speed and production output) for stain application. -- Continuous 65" width carbon fiber belt enables the recovery of over sprayed coating material for reuse. -- Cefla's patented conveyor belt system for coating recovery and belt cleaning is controlled by the PLC and recovers approximately 98% of the coating material deposited on the belt, which is then automatically cleaned with "Coating Appropriate Solvents" -- The automatic air flow system monitors and maintains consistent air flow/pressurization through spray booth. When filters become too plugged to maintain sufficient air flow, system operation is ceased --electronic control unit utilizes a 60 cell photodiode bar to monitor and regulate spray application, further maximizing application transfer efficiency -- Spraying is performed through a rotary system designed for the installation of ten plus ten (10 + 10) guns in (2) coating supply circuits with recycle.TECHNICAL SPECIFICATIONS: Working width from 0 - 1300mm ( 0 - 51") Minimum workpiece length 305mm (12") Speed range from 2 - 11 m/min (6.6 - 36 ft/min) Power consumption 10.7 kW Compressed air required 50 NI/min (1.8 cfm) Exhausted solvent /air mix 10000 mc/h (5886 cfm)

CEFLA ROCTRE D Automatic Spray Finishing Machine: for HIGH VOLUME PRODUCTIONThickness: Max. 50 mm (2"); Min. 5 mm (0.2").Maximum Line speed: 20 MPM (65 FMP).Equipment Specifications:CEFLA, model ROC 3 D. Is a Two Arm reciprocating Spray Machine: -- Parts are fed under the Part Reading Bar to measure size and spray parameters on a continuous CFB belt conveying system. -- Lacquer recovery and belt cleaning are accomplished by means of a "cleaning trolley" located under the exist end feed belt. Made up of counter-rotating rollers with scraper and belt cleaning unit, with 3 rollers and stainless-steel troughs: all the rollers are fitted on the motorized trolley longitudinally removable by hand pulling of trolley out. -- Powered outfeed tilt able belt lifts to approach the cleaning trolley. -- (2) Oscillating arms equipped to accept a maximum of (8) guns, four per arm and driven by a Brushless servo motor.There are (2) Separate lacquer feeding circuits with recycling system. -- This is a fully pressurized spray cabin with an exhaust air filtering system for overspray using double dry filters set, primary filter and secondary . -- Electronic control cabinet to monitor spraying functions.Booth consists of sandwich paneling and air is pushed in through (2) air intake ducts (positioned between guns) above the slanted perforated top panels made up of fine filter material help to reduce turbulence. parts running through the sprayer can be viewed by means of a large front viewing window/access panel which can be lifted to access the guns and interior of the sprayer. Note: EX-FACTORY’s Logistic Department is experienced and set up to provide “Full Service Logistic"; from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.

CEFLA EASY 2000/D Automatic Spray Finishing Machine: 2010 CEFLA "EASY 2000 D" Reciprocating Sprayer: -- Sprayer fabricated using coated sheet panels, uses a Centrifugal fan for intake of room air to upper air diffusion hood inside of cabin to pressurize the spray area. -- Conveyor speeds variable from 2 - 8 MPM. Belt width capable to carry 1,600 mm (5') wide charge through the machine. -- Machine is PLC Controlled. The Superior Coating application is achieved by utilizing a "back spray" technique. The machine uses a slide-out material recovery system consisting of (2) rollers. -- Infeed & outfeed Conveyors with lift cylinders. -- Includes: (2) Reciprocating arms traveling on polished rods, hydraulic shock absorber provides smooth operation. -- Parts are read at the Infeed of the Conveyor by a photodiode light bar that reads the size of the part and sends that information to the PLC to control the Spray Gun action. -- Machine is equipped with (2) paint circuits.

CEFLA PRIMA 1,300 mm (51.18") W Single-Arm Automatic Oscillating Spray Coating System, with (4) Spray Guns & (2) PumpsSpecifications: -- For water or solvent-based coating of wood, plastic, glass, & metal. -- Feeds right-to-left. -- Working width 1300 mm (51.18"), Min. panel length 250 mm (9.84"). Max. panel thickness 60 mm (2.36"). -- Paper roll width 1520 mm (59.84"), Paper roll length: 2400 M (7,874'), Paper roll dia. 520 mm (20.47"). -- Conveyor speeds 1 - 3 MPM (3 - 10 FPM). -- Chamber size 11’ W x 6’ L x 3-1/2’ H.Equipped with: -- Heavy-duty spray arm, with (4) C.A. TECHNOLOGIES "BOBCAT "66-250" Automatic air assisted airless spray guns with Max. fluid pressure 2,500 PSI, (2) High pressure feeding circuits, & Electronically-controlled oscillation speed. -- 11’ L Disposable paper-covered vacuum belt conveyor, with 2-1/4"; Dia. Infeed & Outfeed rollers on 4-3/8"; Centers, & Vacuum unit. -- Automatic paper payoff & take-up system, with Unwinder with adjustable mechanical brake & Winder with Air motor. -- Automatic panel shape & panel detection system. -- Removable overspray tanks with Filters. -- Natural air inlet, with 2-Stage Large-surface dry filters. -- 4.6 kW (6 HP) High efficiency exhaust fan. -- Dual chamber lights. -- Control, with PLC, SCHNEIDER ELECTRIC "MAGELIS" Graphic Terminal with 6" Color LCD touchscreen, & Diagnostics.Complete with: -- Manual. -- (2) C.A. TECHNOLOGIES Finish Pumps, Each with Fluid volume 2 GPM at 60 Cycles/Min, Max. fluid pressure 2,000 PSI, Max. air pressure 100 PSI, & 5 Gallon Siphon hose assembly. -- C.A. TECHNOLOGIES "54-405" 5 Gallon Pail-Mounted Stainless Steel Mixer. -- 60"; W x 3’ L x 36"; H Infeed & Outfeed Motorized Roller Conveyors, Each with 1-7/8"; Dia. Coated rollers on 4"; Centers & 1/4 HP - 1,700 RPM Motor.

CEFLA TR3500/CT RUBBER ROLLER CONVEYOR48" infeed/outfeed power conveyor, 140" long, rubber roller conveyor.
