AUTOQUIP 36S128 DL Double Long Scissor Lift.12,800 Lbs. max. cap. with standard 24" x 98" smooth steel platform top. -- 36" Travel with a 7-1/4" height and 43-1/4" raised height; (35) Sec up and down speed. Base frame 24" x 98". -- Power unit with 5 HP remote Super Torque Motor, 240/480 V, 3-Ph, fan-cooled, Intermittent (2 minute) duty. -- Polyethylene hydraulic fluid reservoir with a capacity of 5 gallons. Supply voltage must be specified. -- Complete with; -- Hand held up/down push button control with 10' cord, velocity fuse on cylinder, and maintenance locks on baseframe, -- Options; Guarded foot pedal control, Accordion skirt, larger platforms available. NOTE: Surface mounted lift. Unit is painted AQ black; Pricing subject to change.

AUTOQUIP 36S25 Scissor Lift. 2,500 Lbs Capacity and 48" x 48" Platform with 24" x 48" base frame. -- 12-Second travel time. -- 6-1/2" Lowered height. -- 36" Travel to raised height of 42-1/2". -- Electro-hydraulic, 1-Cylinder design. -- Internally mounted Super Torque 1.5 HP TENV motor with prewired motor starter. -- 24 Volt Control transformer, -- 10' Straight SO cord with hand held up/down 24 V push button. -- 10' SO Power cord. -- Options: Foot pedal control, oversized platform up to a max. of 48" x 72".

AUTOQUIP 36S40 Scissor Lift.4,000 Lbs Cap., Electro-hydraulic operation. -- 36" x 60" smooth steel platform . Base frame is 24" x 48". -- 6.5" Lowered height, 17 Sec travel speed to a raised height of 42.5"; Internally mounted 1.5 HP Super Torque motor, 1-cylinder design. -- Complete with: Optional guarded foot control, velocity fuse on cylinder, and maintenance locks on base frame.

AUTOQUIP 36S40 DL Double Long Scissor Lift.4,000 Lbs. max. cap. with 48" x 120" smooth steel platform top. -- 36" Travel with a 6.5" lowered height and a 42.5" raised height; (25) Sec up and down speed. Base frame 24" x 98". -- Power unit with 1.5 HP Super Torque Motor, 208-230-460V - 3 Ph - 60 Cy, fan-cooled, Intermittent (2 minute) duty. -- Polyethylene hydraulic fluid reservoir with a capacity of 5 gallons. Supply voltage must be specified. -- Complete with; Hand held up/down push button control with 10' cord, velocity fuse on cylinder, and maintenance locks on baseframe, -- Option; Guarded foot pedal control.. NOTE: Surface mounted lift. Unit is painted AQ black;

AUTOQUIP 36S60 Scissor Lift;6,000 Lbs. Capacity and electro-hydraulic operation. -- 36" x 60" Smooth steel platform. Base frame is 24" x 48". -- 6.5" Lowered height, 25 Sec travel speed to a raised height of 42.5"; Internally mounted 1.5 HP Super Torque motor, 2-cylinder design. -- Complete with: Hand held control pendant.

AUTOQUIP 48S25 Scissor Lift.2,500 Lbs, Electro-hydraulic, 24" x 64" standard platform and 24" x 64" base frame. -- 7" Lowered height, 48" travel to raised height of 55"; .75 HP TENV motor, 1-cylinder design. -- Complete with: Hand held push button control with 10' cord. -- Options: Max. platform size up to 48" x 96", foot pedal control, accordion skirt ask for pricing.(Standard specs)

AUTOQUIP 48S40 Scissor Lift.4,000 Lbs Cap., Electro-hydraulic operation. -- 48" x 96" Smooth steel platform. Base frame 24" x 64". -- 7" Lowered height, 48" travel to raised height of 55"; internally mounted 1.5 HP Super Torque TENV motor, 1-cylinder design. -- Complete with: Hand held up/down push button control with 10' cord, velocity fuse on cylinder, and maintenance locks on base frame. -- Options: Up to 48" x 96" smooth steel platform, guarded foot pedal control, accordion skirt. -- AUTOQUIP Series 35, Surface mounted lift. Unit is painted AQ Black;

AUTOQUIP 48S40 DL Double Long Scissor Lift.4,000 Lbs. max. cap. with 48" x 144" smooth steel platform top. -- 48" Travel with a 7" lowered height and a 55" raised height; (32) Sec up and down speed. Base frame 24" x 130". -- Power unit with 1.5 HP Super Torque Motor, 208-230-460V - 3 Ph - 60 Cy, fan-cooled, Intermittent (2 minute) duty. -- Polyethylene hydraulic fluid reservoir with a capacity of 5 gallons. Supply voltage must be specified. -- Complete with; Hand held up/down push button control with 10' cord, velocity fuse on cylinder, and maintenance locks on baseframe, -- Option; Guarded foot pedal control.. NOTE: Surface mounted lift. Unit is painted AQ black;

AUTOQUIP 48S60 SCISSOR LIFT.6,000 Lbs Cap., electro-hydraulic operation. -- With 48" x 96" smooth steel platform. -- 7" Lowered height, 48" travel to raised height of 55"; internally mounted 1.5 HP Super Torque TENV motor, 2-cylinder design, (33) Sec travel time up-or-down. -- Complete with: Guarded foot pedal control, velocity fuse on cylinders, and maintenance locks on base frame. -- Unit is painted AQ black; .Options: Up to 48" x 96" smooth steel platform, hand held control, accordion skirt. .

AUTOQUIP 48S60 SCISSOR LIFTThe Series 35 Scissor Lift Tables are designed and built to provide long-service life, durability, and outstanding lifting power. Series 35 models range in travel from 24″ to 60″ with lifting capacities up to 15,000 lbs. More models and standard options than any other competitive lift table allows for easy customization to meet your specific needs. Single-piece, steel reinforced legs and a 1/4- to 3/8-inch-thick steel platform make for extremely solid construction and easy adaptability. Solid steel leg and added stiffeners provide optimal overall stability and straight, repeatable tracking of the rollers as the lift raises and lowers.Specifications -- 6,000 Lbs Cap., electro-hydraulic operation. -- With 48" x 64" smooth steel platform. -- 7" Lowered height, 48" travel to raised height of 55"; -- 2-Cylinder design -- Complete with: Velocity fuse on cylinders, and maintenance locks on base frame. -- Unit is painted AQ black; .Please note: -- Autoquip to supply recommended GPM flow to achieve a 60 sec. lift time when all (4) lifts are operated at the same time. -- There will still need to be a mechanism to switch on/off (sequence) 1, 2, 3 or 4 lifts at a single time and there may need to be valving to ensure level lifting. -- AUTOQUIP cannot ensure the latter or warranty these lifts since AUTOQUIP is not supplying the complete lifts.

AUTOQUIP 48S80 SCISSOR LIFT.8,000 Lbs Cap., electro-hydraulic operation. -- Standard 24" x 64" smooth steel platform. -- 7.5" Lowered height, 48" travel to raised height of 55.5"; internally mounted 1.5 HP Super Torque TENV motor, 2-cylinder design, (33) Sec travel time up-or-down. -- Complete with: Hand held up/down push button control with 10' cord, velocity fuse on cylinder, and maintenance locks on baseframe. -- Options: Up to 48" x 96" smooth steel platform, guarded foot pedal control, accordion skirt. -- Autoquip Series 35, Surface mounted lift. Unit is painted AQ black;

BISHAMON EZ LOADER Rotating Scissor LiftSelf-Leveling capacity range of 250 - 3,500 Lbs. Max. load capacity is 4,000 Lbs. Collapsed capacity range. -- 10-1/2" Lowered height, 21-1/4" travel, 30" raised height. -- 43" Dia. rotating circular platform. -- Secured ball bearing center pivot on rotator ring along; entrapped rollers in base for smooth even rotation. -- FIRESTONE Air stroke actuator to automatically decrease platform height according to the weight on it. -- No mechanical springs; captivated air to pressurize the air stroke actuator; bleed valve for capacity adjustments. -- Easy to move by forklift without the need for forklift pockets, weight 500 Lbs.

BISHAMON LX-200WM Scissor Lift 4,400 Lbs. load capacity. -- 45-1/2" x 61-1/2" Platform. -- 4.3" Lowered height. -- 35.1" travel to raised height of 39.4". -- 34-Second upward travel time when loaded. -- 26-Second downward travel time. -- Electro-hydraulic. -- 1 HP TENV Motor. -- Hand control with 8' long cord. -- Options: Foot switch and long loading ramp. Please ask for pricing.

BLUE GIANT SFSRH33/575 Scissor LiftHydraulic 3,000 Lbs. scissors lift -- 34" x 108" platform with idle roller -- Low 9" x high 53",Hydraulic pumping unit with 3 HP motor.

JOYCE WHJS60-36-48-72 Scissor LiftSpecification -- 6,000 Lbs Cap.; electro-hydraulic operation; 48" x 72" platform with: (3) Steel tube spacers to allow loading & unloading via forklift; lowered height 12"; approx. 46" raised height. -- Includes: Foot pedal control.(2) Units Available: S/N SCL024958 & SCL025876.

KNIGHT l76119 Scissor LiftSpecifications: -- Pneumatically operated 4,000 Lbs. capacity. -- 75-3/4" x 118-1/3" Top platform. -- Lowered height 8-1/2", raised height 26" for total travel of 17-1/2". -- Full safety skirt with pneumatic control pedestal.

LHI 6,000 # Scissor LiftSimple Design, Low Cost, High Performance w/ Off-The-Shelf Parts so you can keep it running years from now Specification: -- 6,000 Lbs weight capacity. -- 48" x 96" Smooth steel platform. -- Lowered height 9-1/2" raised height 49". -- Travel speed: 1/2" per second up -- Foot pedal control.Available Options: -- Automatic Down Indexing -- Automatic Up Indexing -- Automatic Up/Down Indexing

LHI 4,500 # Scissor LiftSimple Design, Low Cost, High Performance w/ Off-The-Shelf Parts so you can keep it running years from now Specification: -- 4,500 Lbs weight capacity. -- 48" x 96" Smooth steel platform. -- Lowered height 9-1/2" raised height 49". -- Travel speed: 1/2" per second up -- Foot pedal control.Available Options: -- Automatic Down Indexing -- Automatic Up Indexing -- Automatic Up/Down Indexing

PRESTO XL36-20 Scissor Lift2,000 Lbs load capacity for evenly balanced load. -- 7-1/4" Lowered height. -- 36" Travel to raised height of 43". -- 17 Seconds travel time. -- Hinged platform for access to cylinders and internal power unit in collapsed position. -- 24" x 48" standard platform size. -- 3/4" Steel plate scissor legs. -- Heavy Duty hydraulic cylinders with chrome plated rams. -- Lifetime lubricated bearings on all rollers and pivot points. -- Electro-hydraulic 1 HP motor. -- Standard hand control pendant. -- Standard safety velocity fuses. -- Safety maintenance device.

PRESTO XL60-60 Scissor Lift6,000 Lbs. load capacity for evenly balanced load.Specifications: -- 10" Lowered height. -- 60" Travel to raised height of 70". -- 30 Seconds travel time. -- Hinged platform for access to cylinders and internal power unit in the collapsed position. -- 48" W x 96" L platform size, base 24" W x 86" L. -- 3/4" Steel plate scissor legs. -- Heavy Duty hydraulic cylinders with chrome-plated rams. -- Lifetime lubricated bearings on all rollers and pivot points. -- Electro-hydraulic 3.2 HP motor. -- Standard hand control pendant. -- Standard safety velocity fuses. -- Safety maintenance device.
