BALESTRINI MINI C 2500 DOUBLE SIDED TEMPLATE PROFILE SHAPERSpecifications: -- (2) Offset shaping heads with 10 HP (7.5 kW), 230/460 volt three phase drives. (1 each side) -- Maximum reciprocating length 98" (2500 mm). -- Maximum height 7" (180 mm). -- Maximum width between spindles 8", and shaping heads are staggered for full end rounding. -- 1¼"; Diameter work arbors with 7″ under the nut capacity, and Spindle speed of 8400 RPM -- Hydraulic stroke of 9-3/4″ wide x 110″ long tee slotted work table, with feed speeds of 3 - 49 feet per minute (1-15 m/Min.) powered by 3 HP, 230/460 volt three phase hydraulic pump -- Overhead beam clamp bar with (4) adjustable clamps. -- Push button operator control station.

CAM-WOOD M5412-SCX Tenoner & End Matching MachineTenoning/Coping machine for straight or miter material. Great machine for miter door production or stile and rail stock. Equipped with: -- 6" High stackable spindle by pneumatic up & down with (3) different stops; easily and accurately setup for each cutter position.One shaper head at each side of the table. -- Table moves from right to left by variable speed Pneumatic-Hydraulic power to achieve the full cutting power. -- Twin table moves in and out separated for tongue and groove, end-match application. -- Twin heavy-duty pneumatic pistons hold down the work pieces tightly to the table during the cutting process.Features: -- Rigid construction on the heavy sheet metal frame, cast iron table & base for durability usage. -- Heavy duty industrial motor is suitable for heavy-duty cutting under full load. -- Linear guide rails and bearings let the operator move the table smoothly. -- Cast iron fence locks in the table groove to finish 45° cut easily. -- Automatic cycle function, just place the material against the stops, the machine will automatically clamp, move in for shaping/tenoning, come out and release the hold down.

CAM-WOOD RD-5412-SC Tenoner with Dowel DrillTenoning/Coping machine for straight or miter material. Great machine for miter door production or stile and rail stock. Equipped with: -- 6" High stackable spindle by pneumatic up & down with (3) different stops; easily and accurately setup for each cutter position. -- Drill heads for dowel hole at each end. -- One shaper head at each side of the table. -- Table moves from right to left by variable speed Pneumatic-Hydraulic power to achieve the fully cutting power. -- Twin table moves in and out separated for tongue and groove, end match application. -- Twin heavy-duty pneumatic pistons hold down the workpieces tightly to the table during the cutting process.Features: -- Rigid construction on the heavy sheet metal frame, cast iron table & base for durability usage. -- Heavy-duty industrial motor is suitable for heavy duty cutting under full load. -- Linear guide rails and bearings let the operator moving the table smoothly. -- Cast iron fence locks in the table groove to finish 45° cut easily. -- Automatic cycle function, just place the material against the stops, the machine will automatically clamp, move in for shaping/tenoning, come out and release the hold down.

CAM-WOOD SP-30 Fixed Spindle ShaperA Shaper with plenty of cast iron... a solid piece of machinery!Features & Specifications: -- 5 HP Motor with reversing switch. -- Interchangeable spindle as standard with a 1" & 3/4" spindles. -- Spindle with 4" under nut. -- (2) Spindle speeds of 8,000 & 10,000 RPM. -- Large 30" x 28" cast iron precision ground table. -- 7" Max. table ring. -- Easily locked spindle for cutter change. -- Micro-adjustable back fence with material spring holddowns. -- Includes Miter gauge, cutterhead guard assembly, and operators manual.NOTE: Available in 3-Phase and 1-Phase electric.SP-305C 2-PCS ROUTER BIT COLLECTOR SET $ 89.00.

CAM-WOOD SP-35G Fixed Spindle ShaperA Shaper with plenty of cast iron... a solid piece of machinery!Features & Specifications: -- .Precision ground cast iron table and T-slot miter gauge slot. -- Perfect alignment, rigid spindle supported by a power transfer system for accuracy. -- Individual micro adjustment fence on both sides of the spindle by hand wheels. -- Large hand wheel for fast movement and lock protection. -- Magnetic switch for overload protection. -- Spindle travel is operated by a rack and scroll gear. -- Two spindle speeds for versatile cutting. -- Forward and reverse switch for cutting directions. -- Heavy gauge metal cabinet base. -- Alloy steel spindle for durability usage. -- Sealed long-life ball bearings. -- Standard equipment: Full power motor, dust chute, table insert, spring hold-downs, miter gauge. -- Table Dimensions: 30" x 40". -- 1-1/4" Standard Spindle Dia. --Spindle Speed: 4,000 - 10,000 RPM. -- 5 HP Motor. -- 4" Dust Hood.

CAM-WOOD SP-750 Heavy Duty Shaper. 7.5 HPSpecifications: -- Table size: 48 x 36.5'' -- Height of Working Table: 35-1.2". -- Spindle 1'',1.25''. -- Motor: 7.5 HP (10 HP Opt.). -- Speed (RPM): 3,000/4,500/7,500/10,000. -- Dimensions: 53' 'x 43'' x 51''. Weight: 1480 LbsFeatures: --Designed for heavy industrial work. -- Industrial powerful motor for maximum cutting capacity. -- Quick-change spindles. -- Forward / reverse switch. -- Individual two-sided micro adjustable fence. -- Precision ground large cast iron table. -- Three spindle speeds for versatile cutting. -- Sealed long-life ball bearing. -- Metal 4"; dust hood. Heavy sheet metal cabinet base for durability usage. -- Magnetic control for overload protection. Note: Actual Model SP-750

CAM-WOOD UAA04-SC Automatic ShaperManufactures raised panel cabinet doors with (1) operator; max. 40" doors. -- Equipped with:10 HP Main motor drives 1-1/4" Dia. x 6" high stackable multi-cutter spindle @ 9,000 RPM to mill stile, rails, and raised panel profiles.Stackable cutter spindle with (3) pneumatic stop indexing significantly reduces setup time as each position is preset; the change from one cutter to another is achieved via a select switch for each operation. -- Features:Table movements from left to right are hydraulically powered for powerful cutting and cutting speed variability. Table movements in and out are pneumatically powered to assure that the template is followed sensitively, and the shape is copied correctly.

CANTEK SS-512TSB Tilting Spindle and Sliding Table Shaper:7.5 HP - 3-Phase motor, overall table dimensions 31.50" x 39.40", sliding table 10.25" x 39.40". -- Spindle stroke 7"; 1-1/4" dia. spindle with 5 MT receiver and 4-3/4" cap. under the nut. Spindle tilts -5° & +45°. -- (5) Spindle speeds: 3,000, 4,000, 6,000, 8,000 & 10,000 RPM.Complete with: Spindle reversing switch, micro-adjustable fence 6" x 43", thermal overload protection and dust hood.16 weeks delivery.

CANTEK SS512CSB HEAVY DUTY SLIDING TABLE TILTING SPINDLE SHAPER Features: -- Cast iron sliding table runs on ball bearing for smooth table transition. -- Cast iron ground & polished table with insert rings; table size: 31- ½"; x 39.4″. -- Precision ground and electronically balanced spindle. -- 7.5HP V-belt drive with (5) feed speeds is easily accessed from the front of the machine. -- Electric spindle brake for added safety. -- Spindle lock - with limit switch safety, machine will not start with lock engage. -- Micro spindle height adjustment with dial indicator. -- Interchangeable cutter spindle. -- Forward/reverse spindle rotation. -- Adjustable "finger" type fence Independent micro-fence adjustment on both sides. -- Includes the following standard equipment: 1- 1/4" Spindle, (1) 5"; dust chute on guard & (1) 4"; dust chute in the table, safety guard, Miter tenon jig, and Telemecanique magnetic controls.

CANTEK - SS512TB Tilting Spindle ShaperSpecifications: --Tilting spindle from -5° to +45° and 6" x 43" fence. --1-1/4" interchangeable spindle is standard (other sizes available). -- Large cast-iron table is ground and polished for maximum stability and durability. -- Powerful 7.5 HP motor for even the most demanding profiling work. -- Five spindle speeds can be easily adjusted to suit your tool diameter. -- 5-1/2" Useable spindle length, above table 13-¼"; below table 8-¼". -- Electronic spindle brake for added safety and facilitates fast changeover. -- Precision fence assembly with micro-infeed and outfeed fence adjustment. -- The finger-style fence allows the fence to be adjusted around the cutter for added safety and workpiece stability. -- Table size 31 ½"; x 39.4″. -- Dust port (1) 5″ on guard, (1) 4" into the table.

--In Auction: https://exfactoryauctions.com/Detail/SA-231009/event/A122024$1 --No RESERVE!-- CHIA LUNG KR-30 2-Spindle Dual Table Automatic Rotary Copy Shaper Equipped with: (2) 19” Dia. x 35-1/2” H Tables. (2) 6-1/4” Dia. Center clamp plates.

COMEC - FAS/2, ...Corner Milling MachineCOMEC FAS is a dedicated milling machine with: Inclinable heads for machining the corner of chair seats. Specifications: -- (2) Heads with: 5.5 HP motor and 40 mm spindle shaft. -- Max. cutter size: 150 mm (5.9"). -- Tilting of milling units: 20°/ +45° in horizontal plane. -- Fixed left hand column to support head unit. -- Max. working height: 200 mm (7.8").

FLETCHER EZ-DOOR Raised Panel Door MachineThis freestanding machine can produce an entire 5-piece door in a matter of minutes. Easy to operate, the E-Z Door has a 4-position configuration to produce raised panels, cope/stile profiles and mullions for glass doors. Cathedral doors are produced by using a quick change template system.Specifications: -- Select cutter and material stop with the press of one button. -- Simple four position one spindle design. -- PLC controlled pneumatics. -- Rigid lubricated spindle assembly. -- Re-circulating ball bearing slides. -- 10 HP 230 or 460V/60HZ spindle motor – (460V/3PH=17FLA) – (230V/3PH=33FLA) -- 6,500 RPM spindle speed. -- 62 inch travel length standard with circulating ball bearing slides, cut rails to 59"; and panels to 55"; -- Includes: (4) Standard cutters (shape to be decided), others optional. -- Includes: one template of customers choice. -- 1-¼"; Arbor. -- CFM requirement is 392.Made in North Carolina, USA!

GOMAD - DFFA-5: Tilting Arbor Shaper Specifications -- 40" x 39" Table size. -- Spindle tilts from: 10° Rear/past vertical to +45° front. -- 7-1/2 HP Main motor. -- 1-1/4" Tilting spindle. -- 4,000 /6,000/ 8,000 / 10,000 RPM; holddown springs; reversing switch. -- Adjustable shaper fence. -- Foot motor brake.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i62 GRIZZLY G7214Z Shaper Specifications: 1-1/4" Dia. interchangeable spindle, 7.5 HP - 3,450 RPM motor; 3,600, 5,100, 8,000 & 10,000 RPM spindle speeds via 4-step V-pulley. 5-1/8" Cap. under nut when using the 1-1/4" spindle, 3-1/4" spindle travel, 34-3/4" x 35-1/2" cast iron table, 43" working height. Table Counterbore: 7" dia. x 5/8" deep Complete with: Adjustable Fence with integrated 4" dust collection shroud, reversing switch & magnetic controls, 3-roll power feeder

HOLYTEK SS-512 TS Shaper with Tilting Spindle, and Power FeederSpecifications: -- 1-1/4" Interchangeable spindle, 7.5 HP motor with (5) spindle speed settings of 3,000 - 4,000 - 6,000 - 8,000, & 10,000 RPM. -- Approx. 6" max. cap. under nut, 31" x 39" cast iron table. -- Insert ring diameters 2.8", 4/3", 6" and 8". -- Tilting spindle +10° and -45° -- Vertical movement of the spindle 7" -- sliding tableComplete with: -- Reverse rotation switch, adjustable fence assembly, and dust hood. -- 3-Roll Power Feeder

JENKINS - JSM, NC Controlled Shaper & MortiserNC Controlled with: (1) Shaper head with ATC (18) tools, (1) tenon head, and (1) mortising head.Machine Specifications: -- Total X-travel: 122". -- Y-Axis (useful zone-1 only): 8". -- Min. length rail: 4". -- Max. length rail (Zone 2, 3 only): 96". -- Min. width rail: 1-1/4". -- Max. width rail: 12". -- Min. stock thickness: 1/2". -- Max. stock thickness: 2-1/4". -- Max. arch height (Zone 1 only): 6".Spindles: -- (1) 10 HP - 12,000 RPM non-tilting Cope spindle. -- (1) 10 HP - 18,000 RPM non-tilting high-speed Tenon spindle. -- (1) 5 HP - 18,000 RPM non-tilting, high-speed Mortise spindle. -- Tool Changer Capacity: (18) Tools.Controls: -- Industrial PC: Base powered by NEXCOM PEAK "760VL2" all-in-one computer card, industrial-grade computer chassis, LCD color touchscreen. -- YASKAWA Model "V1000": Adjustable AC frequency drives. -- ALLEN-BRADLEY: AC Servo Plus drive model "Ultra 3000".Over all dimensions: -- 16-1/2' Length. -- 120" Width. -- Floor-to-top guarding: 55". -- Floor to tabletop: 37-1/2".

LAGUNA S-45T SLIDING TABLE, TILTING SPINDLE SHAPERThe Laguna S-45T Industrial Shaper was designed to be a heavy duty industrial workhorse for commercial applications. Specifications: -- 5 HP 1 Phase motor. -- Spindle Tilt: 45° Backwards, 10° Forward. -- Sliding Table: 10-1/4″ x 39″. -- Sliding Table Stroke: 18-3/4″. -- Main Table Incl. S/T: 39-1/2″ x 31-5/8″ -- Tenoning Table:13-3/4″ x 18-1/2″ -- Spindle Speeds: 3,000/4,000/6,000/8,000 and 10,000 RPMIncludes: 4-Roll 8-Speed Power Feeder.

LAGUNA PRO SHAPER SINGLE PHASE SHAPER The Laguna Pro Shaper combines a precision shaper with features normally found only in much higher priced machines.Specifications: -- 5HP 1 Phase 220V. -- Table size: 39-5/16″ x 31-7/16″ x 3-1/2″, -- Spindle travel: 4″ -- Spindle Sizes: 3/4″ and 1-1/4″Includes: 4 Roll 8 Speed Feeder

The Model 390 Automatic Shaper is a New concept in shapers. -- This "New Shaper" is conveyor fed, making it ideal for shaping small parts which could not be fed with a conventional Power Feeder. -- The 7.5 HP inverter controlled variable speed shaper can shape pre-arched panels automatically. Using a Template, it can also hog out arched panels. -- Horizontal and Vertical shaper adjustments with digital position indicators and the 5-position fence make profile changeovers extremely quick and simple. -- Standard stack tooling spindle -- Optional upgrade to 460 V, additional $ 250.
