CAM-WOOD DC-102 Dust CollectorSmall radial-finned Dust Collector mounted on wheels for portability.Features & Specifications: -- Large 13-1/2" fan that produces 2,100 CFM. -- Heavy Duty 3 HP motor pre-wired at 230 Volts. -- Large capacity dual station cloth top bags of 31.2 sq. ft. total cloth filter area. -- Low sound level of 75 - 90 dB.

CAM-WOOD DC535 DUST COLLECTOR 2900 CFM5 HP Motor and 14" Dia. Radial-fin type steel impeller to get the best efficiency usage.Specifications: -- Two top filters and two collection bags. -- Heavy-duty motor for powerful operation. -- Larger size impeller and extra long top air exhaust bags enabling to collect sawdust and wood chips more easily. -- Standard steel spring clamps to secure the bags with the body without leaking dust. -- Low sound levels keep the working area quiet. -- Replacement bags or 5 micron bags for fine dust are available. Optional connect bags for barrels are available.

CAM-WOOD DC-8075 Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 5,800 CFM.Includes: -- Heavy Duty 7.5 HP motor pre-wired at 220 V. -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 db. keeps the work area quiet. -- Optional connection for using barrels.

CAM-WOOD DC-8100X Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 7400 CFM.Includes: -- Heavy Duty 10 HP motor pre-wired at 230 V. -- 10" Inlet -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 Db keeps the work area quiet. -- Optional connection for using collection barrels.Note: 230 or 460 Volt, 60 Cy, 3-Ph please advise.

CAM-WOOD BX-1212-HR-TNX Two-Head Band Resaw Can be used to cut boards, cants, or reclaim slabs; max. working height up to 12" H under pressure roller x 12" W; 1/4" - 10-5/8" between blade and conveyor; VFD controlled variable speed from 0 - 90 FPM.Equipped with: -- 20 HP Saw Motor, 28" x 2" dynamically balanced cast iron band wheels, 201" x 2" - 3" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Automatic moisture cooling system for cooling and lubricating the saw blade for cleaning the blade tooth and longer blade life; -- Blade guard is easily lifted up, supported by two nitrogen gas cylinders for convenient blade change. Complete with: -- 3 HP Drive motor; variable feed speed 0 - 90 FPM; digital controller for convenient and accurate thickness setting; -- 1/2 HP Blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by a gear rack.Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1212BEEX Single Bottom Head Band Resaw.Can be used to cut boards, cants, or reclaim slabs; Specifications: -- Can process up to 12" H x 12" W; 5/16" - 5-1/4" from blade to conveyor. -- 2 HP Electric motor controlled variable speed from 12 - 80 FPM. -- This Model BX-1212BEE is equipped with: -- 20 HP Saw Motor, 28" x 1" band wheels, 168" x 1" band saw blade (not included). Features: -- Hand-wheel blade tensioning; manual elevation adjustment; 2 HP hydraulic system pump motor. Complete with: -- Spring-loaded steel and rubber upper-pressure rolls; 11" X 215" conveyor belt.

CAM-WOOD BX-1212HR-1 Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; Specifications: -- Max. working height up to 12" H under pressure roller x 12" W; 1/4" - 10-5/8" between blade and conveyor; -- VFD controlled variable speed from 0 - 60 FPM. Equipped with: -- 20 HP Saw Motor, 24" x 2" dynamically balanced cast iron band wheels, 184" x 1" to 1-1/2" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 10-5/8" x 165-1/2" infeed conveyor from 0° - 30° with side support for bevel cutting; 3 HP drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor.Complete with: -- Programmable Digital Controller for convenient and accurate thickness setting; -- 1/4 HP Blade elevation motor moves blade and saw head; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. Includes: Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1616HR-TN Two-Head Band Resaw Can be used to cut boards, cants, or reclaim slabs; max. working height up to 16" H under pressure roller x 16" W; 1/4" - 12" between blade and conveyor; VFD controlled variable speed from 0 - 90 FPM.Equipped with: -- 30 HP Saw Motor (each head), 28" x 2" dynamically balanced cast iron band wheels, 201" x 2" - 3" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Automatic moisture cooling system for cooling and lubricating the saw blade for cleaning the blade tooth and longer blade life; Blade guard is easily lifted up, supported by two nitrogen gas cylinders for convenient blade change. Complete with: -- 3 HP Drive motor; variable feed speed 0 - 90 FPM; digital controller for convenient and accurate thickness setting; 1/2 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack.Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-1616HR Single-Head Band Resaw w/Return ConveyorCan be used to cut boards, cants, or reclaim slabs; max. working height up to 16" under pressure roller x 16-1/2" Widths; 1/4" - 12" between blade and conveyor; VFD controlled variable speed from 0 - 60 ft./min.Equipped with: -- 30 HP Saw Motor, 32" x 2" dynamically balanced cast iron band wheels, 230-1/4" x 2" - 4" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- 3 HP Variable Frequency Drive motor; variable feed speed 0 - 60 FPM; return gravity roller conveyor; a side support is applied for safe and stable cutting operations.. -- Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD BX-2410HR Single-Head Band Resaw w/30° Bevel CuttingCan be used to cut boards, cants, or reclaim slabs; max. working height up to 10" H under pressure roller x 24" W; 5/32" - 10" between blade and conveyor; VFD controlled variable speed from 0 - 82 FPM.Equipped with: -- 30 HP Saw Motor, 28" x 2" dynamically balanced cast iron band wheels, 195-1/2" x 2-1/8" x 3/64" band saw blade (not included); hand wheel adjustment for blade tension with tensioning scale. -- Tilting 23" x 215" infeed conveyor from 0° - 30° with side support for bevel cutting; hydraulic infeed and outfeed conveyor drive motor; variable feed speed 0 - 82 FPM; return gravity roller conveyor. -- Complete with: -- Digital controller for convenient and accurate thickness setting; 1/4 HP blade elevation motor; infeed and outfeed spring-loaded pressure rolls, easily adjusted by gear rack. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD AC-100120 Piston Air CompressorHeavy Duty unit with a 10 HP induction motor.Features & Specifications: -- 34.2 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 120-Gal. horizontal tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD AC-5080 Piston Air CompressorCompact unit with a 5 HP induction motor.Features & Specifications: -- 18 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 80-Gal. vertical tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD AC-7580 Piston Air CompressorCompact unit with a 7.5 HP induction motor.Features & Specifications: -- 22 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 80-Gal. vertical tank that meets ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD 1AM-1150 Pallet NotcherSpecification: -- 10 HP Motor (remanufactured w/ new bearings) currently wired 220V, 3-Ph (440V, 3-Ph available). -- Maximum notch size 9" L x 2.5" H x 1-5/8" D. -- New design cutter-head with (4) straight HSS knives installed. -- Approximately 400 to 600 notches /Hr. -- Wired magnetic starter with on/off switch. -- (6) Months warranty on manufacturing defects on mechanical parts only. Machine Floor Dimensions: 48" L x 36" W x 40" H - Weight 665 Lbs.Palletized Shipping Dimensions: 48" L x 40 W x 44" H - Weight 720 Lbs.

CAM-WOOD 1AM-1180 Pallet NotcherSpecification: -- 10 HP Motor (remanufactured w/ new bearings) currently wired 220V, 3-Ph (440V, 3-Ph available). -- Maximum notch size 9" L x 3" H x 3" D. -- Cutter-head with (40) insert replaceable tip knife cutters for recycled wood. -- Approximately 400 to 600 notches / Hr. -- Wired magnetic starter with on/off switch. -- 6-Month warranty on manufacturing defects on mechanical parts. Machine Floor Dimensions: 48" L x 36" W x 40" H - Weight 720 Lbs.Palletized Shipping Dimensions: 48" L x 40" W x 44" H - Weight 772 Lbs.

CAM-WOOD MRS-340-1M Dip Chain Gang Ripsaw with one Shifting Blade:Specifications: -- Cutting width up to 13";; machine will pass thru 25-1/2"; -- 3"; Maximum depth of cut with 12"; diameter blades. - Will cut 4"; thick with 14"; blades (optional). -- With 70 mm saw spindle; accepts 90 mm bore sawblades -- With air-loaded pressure rolls, standard fence, and feed chain. -- Urethane Chain Pads and Pad Holders optional -- With (1) powered moveable blade and fixed blades. -- Moveable blade controlled with a joystick. -- With (10) push buttons for pre-programmed selective ripping -- The shifting blade moves at 20 to 80 mm/second (up to 3"; per second). -- Moveable saw blade traverses from 0.59" thru 13.38" -- 50 HP Saw arbor motor; -- 3 HP Feed motor with feed speeds from 15 to 130 FPM -- (2) 1/2 HP Lift motors for pressure rolls and saw arborOptional Equipment when ordered with the machine: -- TRS-FT AUTOMATIC INFEED CONVEYOR SYSTEM, with Movable Fence with Digital Display and Shifting Laser Light for Rip Width Setting: .. -- Hydraulic Quick Lock Spindle Assembly. The hydraulic locking spindle assembly is designed to provide for quick changeover between various ripping requirements. Simply turn the locking knob to pressurize the arbor and lock the blades in position. Turn it in the opposite direction to unlock the blades. The sawblades are mounted to solid steel blade collars: ... -- Additional Quick Set Mechanically-Locked Saw Collars for fast, accurate, sure holding of saw blades in any stationary position ... -- 60 HP Saw Arbor Motor: -- Additional 30 MW Laser Unit with Bracket & Wiring: ... -- Pneumatic Pressure to Hold Down Feed Rollers (In lieu of spring pressure). Provides better control of the product being fed. Each pressure roll is controlled by an individual pressure regulator: .. -- Short stock feeding device for 14"; blades (see specifications for cutting capacity information): -- Feed Chain with (69) Easily Replaceable Bolt in Cast Iron Pads. Allows for changing chain pads as they wear or get cut into rather than replacing the complete chain assembly. NOTE: Specially ground down to 0.06"; square tip for optimum hold with virtually no marking: ... -- Feed Chain with (69) Easily Replaceable Urethane Non-Marking Strip Inserts. Urethane is vulcanized to metal backing bars and bolted in place: ... -- 12" Dia. carbide tipped ripsaw blades, cuts up to 3" material: ... -- 14" Dia. carbide tipped ripsaw blades, cut's up to 4" material: ...NOTE: Foot Pedal seen in the photo is only used with a powered Infeed Table and is designed to release boards from the Feed Table.

CAM-WOOD MODEL TRS-1200TB SLAT RIPPER - (1) Top & (1) Bottom Rip Spindle.The machine can plane or shape the wood on two surfaces and then rip it. Ideal for shutters, louver slats, yardstick blanks, etc.Features: -- Special profile hold down & groove table for slat ripping, optional -- Designed to meet the exacting standards required for high-quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- All of these features combine to show what a true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy between cutterheads & fence and is equipped with a measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy-duty industrial TEFC motor ensures full-depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allow the machine to meet the cutting requirements of different materials. -- Saw head built to precise tolerances assures accuracy for all straight-line ripping operations and provides a stellar quality of cut. -- Top & bottom powered pneumatically tensioned feed rolls for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat treated, precision ground, and balanced providing precise cutting performance.SPECIFICATIONS: -- 8"; Max. Cutting Width -- 5"; Max. Cutting Depth -- 10"; Min. Workpiece Length -- 4"; to 6"; Dia. Top Spindle Sawblade Size -- 8"; to 12"; Dia. Bottom Spindle Sawblade Size -- 6,000 RPM Top & Bottom Moulder Spindle Speed -- 8"; Spindle Length -- 40 mm Rip Saw Arbor Diameter (with key) -- 10 HP Top Rip Saw Motor -- 15 HP Bottom Rip Saw Motor -- 12 to 60 FPM Feeding Speed (Variable) -- 1/2 HP Feed Roll & Top Head Elevating Motor -- 1/2 HP Rip Saw Arbor Elevating Motor -- 3 HP Feed Motor

CAM-WOOD TRS 150F Frame SawCAM-WOOD Frame Saws are engineered and designed to make extremely accurate cuts, cutting products with very tight tolerances up to 0.004" and often eliminating sanding before proceeding to the next step . The unique thin frame saw design accepts different saw frames, blade combinations, and allows multiple saw fence configurations to produce single, double or multiple cuts in a single pass.Specifications: -- 3/4" Min. to 6" max. working width; 1-1/4" min. to 7-3/4" max. working thickness (height); 7-1/2" minimum length; finished material > 0.1094". -- 0.043" to 0.055" Saw blade thickness; runs up to (22) blades at one time at (450) stroke/minute with a 8-1/4" stroke length; accommodates blades 1.575" wide x 19.685" long. -- Saw blade frame is powered by a 15 HP motor. Feed speeds of 1 to 5 FPM by 1 HP motor. -- Features automatic oil lubrication system requiring 90 PSI air pressure. Cooling system via water and air. -- Minimum kerf multi-blade frame saw designed to maximize production and minimize material losses to kerf. -- Machine supplied with PLC controller to allow operator fast, instant set-up changes. -- All controls are centrally located for the operator to easily adjust & control operation. -- Material waste reductions of up to 20% are achievable by use of the thin kerf blades (0.043" ~ 0.055"). -- A special air blast system cools the blade for longer service intervals and removes saw dust from the gullet of the blade to reduce temperature and increase blade life.Note: Frames are available in different configurations.

CAM-WOOD TRS-190-2VS 7.5"; x 6"; VERTICAL SPINDLE MOULDER FOR SMOOTH SLAT RIPPINGIncludes one setup including Splitter Set, Holddown Plate, Fence, Sawblades, and Spacers WORKING CAPACITY -- Working width: 3"; to 7-1/2"; -- Working height: 3/4"; to 6"; RIGHT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. LEFT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. SPINDLE COMPONENTS AND ASSEMBLY -- Precision spindles are manufactured from SCM-4 tool steel imported from MITSUBISHI Japan, heat treated to HR 46° (ROCKWELL C Scale) fitted with class 6 -- SKF-matched ball bearings then mated to precision machined spindle housings. -- The spindle body and bearing housing are burnished. -- Spindle hardness and accuracy, high precision SKF bearings, and precise spindle housing and bearing installation by SHEN KO provides a spindle assembly -- Capable of speeds to 9,000 RPM and will meet every user’s requirement. -- Spindles are powered by V-shaped belts (MITSUBISHI) without slippage. FEED SYSTEM -- Powered with a 5 HP motor -- Feed speed is infinitely variable by inverter drive from 20 to 120 FPM -- Infeed rolls consist of (3) top and (2) bottom-powered feed rolls. -- Outfeed with (1) set of top and bottom-powered feed rolls -- Pneumatic pressure to all (4) top feed rolls -- Top rolls with independent pressure adjustment -- All top and bottom feed are driven by a universal joint drive -- Feed rolls are 5-1/2"; diameter TABLE AND FENCE -- 4’ infeed table with (1) driven roller above the tablet -- Table is harden and chromed. -- Fence is harden PRESSURE ELEMENTS -- A pneumatic pressure plate assures stability during slicing -- Precision splitting wedge guide for saw kerf SETUP FEATURES -- Mechanical digital read-outs -- Mobile jog box for ease of setting up -- Central lubrication system for spindles -- Oil pump to remove the resin from table -- Each table has (2) holes for lubrication ELECTRICAL -- Operating voltage 230.460/575/600-volt, 60-cycle, 3-phase -- All “name brand"; electric components. -- Operating panel separate from motor control cabinet for ease of operation MISCELLANEOUS -- Machine cover/hood with a lamp for ease of set up -- Includes a toolbox and operator’s manual

CAM-WOOD MODEL TRS-3000TB.12" SLAT RIPPER - (1) top & (1) bottom rip spindle.CAM-WOOD MODEL TRS-2050TB.8" SLAT RIPPER - (1) top & (1) bottom rip spindle - DEDUCT $8,000FEATURES: -- The machine can plane or shape the wood at two surfaces then rip it. Ideal for shutters, louver slats, yard stick blanks, etc.. -- Special profile hold down & groove table for slat ripping, optional -- Designed to meet the exacting standards required for high quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances, and feature the newest designs for operator safety and volume production. -- All of these features combine to show what a true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy between cutterheads & fence and is equipped with measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy duty industrial TEFC motor ensures full depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allows the machine to meet the cutting requirements of different materials. -- Saw heads built to precise tolerances assures accuracy for all ripping and profiling operations provide a stellar quality of cut. -- Top & bottom powered pneumatically tensioned pressure rollers for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance.SPECIFICATIONS: -- 12"; Max. Cutting Width (TRS2050 WITH 8" MAX. WIDTH) -- 4-3/4"; Max. Cutting Depth -- Min. Cutting Depth Limited by Thin Material Breakup -- 10"; Min. Workpiece Length -- 14"; Dia. Max. Sawblade Size on Top Spindle -- 10" to 16"; Dia. Sawblade Size on Bottom Spindle (TRS2050 WITH 16" DIAMETER) -- 4,000 RPM Top & Bottom Spindle Speed -- 12"; Spindle Length (TRS2050 WITH 8" SPINDLE LENGTH) -- 40mm Arbor Diameters with 2-Keyways (TRS 2050TB WITH 70MM ARBORS) -- 15 HP Top Rip Saw Motor (TRS 2050 WITH 10 HP MOTOR) -- 30 HP Bottom Rip Saw Motor -- (6) Upper and (2) lower Feed Rolls -- 12 to 60 FPM Feeding Speed (Variable) -- 1 HP Feed Roll & Top Head Elevating Motor -- 1/2 HP Lower Saw Arbor Elevating Motor -- 7-1/2 HP Feed Motor (TRS2050 WITH 3 HP MOTOR) -- Dimensions (L x W x H) 96" x 64" x 55"
