LHI RFPR-72/14 "HEAVY DUTY" MULTI-BLADE PANEL RIP SAW: -- Specifications(1) 30 HP Main arbor motor for 1" min. - 4" max. material thickness;14" Dia max. blade capacity with 1.25" minimum spacing between the blades;Minimum panel length 30" with 72" of usable width cutting capacity.3-15/16" Dia. arbor with 1-15/16" precision arbor bearings;Positive powered steel contact feed rollers with (8) adjustable Polyurethane drive rollers;Variable feed speed to max 80 FPM.Available Options Include:Single point height adjustment for materials from 1" to 5" thickness using customer supplied 16" dia blades(note: Ripping widths can never be less than one-half the material thickness).(1) "Quick Change" arbor cart trolley and blade box for QC set ups.(12) Saw collars to attach the customer supplied 16" dia. diamond blades to the arbors(1) In-feed Scissors Lift with auto cycle controls(1) In-feed 6' conveyor with alignment fence and powered assist feed(1) Auto sheet feeder with auto cycle controls(1) Out-feed Scissors Lift with 4 x 8 roller top.Installation technical assistance for $125/Hr plus travel time and expenses, payable upon competition of services. NOTE:Quote is valid for 30-days;Quoted price is FOB, Factory;Customer is responsible for off-rigging cost at their facility;Customer is responsible for spotting the machine to its final resting place with adequate floor foundationCustomer is responsible for adequate electric, air & dust control supply upon technician's request:Warranty: 1-yr mechanical parts (electrical controls excluded);Delivery to Customer's facility is approx 17 weeks from receipt of funds;Quote assumes customer will deliver material for testing & run-off procedures (if required);NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI AUTOMATIC RAKE FEEDER with the following equipment: -- Panel Feeder with up to 18' Long x 5' Wide x 1" Thick Sheet Capacity (with 4' min. sheet length) -- Feeder loads from right side when viewed from the End of the Scissors Lift -- Auto-cycle for Rake Feeder -- 6' Line-Up conveyor with Fence & Powered Pinch Wheel -- 8000 Lbs. Tandem Scissors Lift with 5' x 17' top, 600-Volt, 3-phase, 2 HP motor -- 5-Section Gravity Rollers on Scissors Lifts -- 12' Powered 5 Strand Chain Conveyor Feeds Tilt Lift w/forward/ reverse, jog controls -- Wired for 600-Volt/3-Phase/60-Cycle Operation (other voltages available) -- Arranged for Customer Provided MultiScore Panel Ripper with right side arbor loading

LHI 96" x 60" ANGULAR TYPE RIP & CROSS-CUT SYSTEM: Specifications: -- Automatic Angular Rip & Crosscut 5-Position System; max. panel size of 8' (96") long x 5' (60") wide x 1" - 4" thick; 1.25" minimum spacing between the blades; variable feed speed from 0 - 150 FPM. This system will process a unit of material in approx. (7) Min. -- Pos. # 1: LHI Automatic Staging/Infeed/Transfer & Panel Rake Feeding System: 10' (120") Long, powered 3-chain staging conveyor; (2) units can be preloaded while (1) unit is in process. Automatic up-indexing 4,500 Lbs capacity Scissors Lift with auto. rake infeed system: infeed rake system designed with a thin material device that can automatically load material as thin a 1/8". -- Pos. # 2: LHI "72": 72" Arbor length designed for panels up to max. of 5' (60") wide, min. panel length 30"; 40 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation. 2-3/4" Dia. arbor with 1-15/16" "Fafnir" arbor bearings; positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia. vertical dust outlets with an easy access strip separator box. -- Pos. # 3: LHI Cross-Transfer System: Transfer conveyor with panel hold-down & chain drive system to change direction 90° & automatically feed LHI 102". -- Pos. # 4: LHI "102": 102" Arbor length designed for panels up to max. 8' (96") long; 30 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation; 2-3/4" dia. arbor with 1-15/16" "Fafnir" arbor bearings. Positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia vertical dust outlets with an easy access strip separator box. -- Pos. # 5: LHI Stacking & Outfeed Transfer System: Auto. down-indexing 4,500 Lbs cap. Scissor Lift; (4) adjustable alignment posts & (4) bin separators to keep processed stacks square. 98' (96") Long outfeed gravity conveyor.Operating System: -- (1) LHI ALLEN-BRADLEY "Inter-Link" PLC for simple single-operator management of the entire system from (1) central control.NOTE: ...Attached description & pictures are for INFO purposes only; ...a NEW System can be modified to your exact specifications!NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI MODEL RFPR ROLL FEED PANEL RIP SAWWith the following Standard and Optional Equipment: -- Roll Feed Panel Rip Saw - 72" Arbor - 50 HP motor -- 10 to 80 FPM (4-speed programmable or potentiometer) -- (8) Polyurethane feed rollers -- 10" Dia. blades (thickness-1/8" to 1-1/4") Infeed Scissors Lift 4,500 Lbs capacity -- 4' x 8' top -- (3) 2"; x 3"; support tubes for fork access -- 110 VAC / 1-Ph power unit -- Foot pedal control -- Automatic up-indexingOutfeed Scissors Lift 4,500 Lbs capacity -- 4' x 8' top -- (3) Support ramp/cross-bars to allow for access -- Auto down indexing -- 110 VAC / 1 Ph power unit -- Foot pedal controlSawblades: -- (10) 10" x 40T x 4-3/16 Bore, TGC Blades -- (10) Blade Collars, 3-15/16" ID x 4.18" bore x 1.25" wide Quick-change arbor setup with the second arbor: -- Arbor change cart (included with the arbor setup that comes with the saw to allow roll-out) Second Arbor Setup Includes: -- Cart -- Blade Box -- Arbor, Bearing -- Sheave -- Throat Plate Rack -- (6) Throat Plates Quick Change Kit: -- Belt Guide -- Belt Tensioner -- Hyd. Arbor Lock Quick Change Kit permits the operator to release the belt and unlock the arbor from the front side of the machine. Without the kit, the operator must open the rear guard to remove the belt and unlock the arbor -- (10) Blades for the second setup -- (10) Collars for the second setup 16-week ESTIMATED delivery: -- Delivery assumes order and down payment are received within (1) week of the date of quotation. Installation technical assistance for $115/Hr plus travel time and expenses Customer responsible for rigging Quote assumes customer will deliver material for testing (if required) Warranty: (1) Year mechanical parts (electrical controls excluded) This quotation is valid for 30 days. ESTIMATED DELIVERY DATE:The delivery date is quoted as 'estimated' because the equipment we manufacture is built to order and to our customer's specifications. This estimate is made under the assumption that there will be no interruptions of labor, material shortages, or any environmental or other unforeseen circumstances. LHI is not responsible for any installation or production costs resulting from actual delivery dates which exceed the quoted estimated delivery dates. Accurate dates for the delivery will not be available until the equipment is in the manufacturing phase. If there are custom features for the quoted equipment then accurate delivery dates will be available when testing is complete. Please consult with the factory for updates to the expected delivery date.NOTE: PRICING DOES NOT REFLECT FACTORY'S 7% MATERIALS SURCHARGE

LHI MODEL RFPR ROLL FEED PANEL RIP SAW WITH THE FOLLOWING STANDARD AND SPECIAL EQUIPMENT: Specifications: -- 72" Useable Arbor and 50 HP Arbor Motor -- 14 - 80 FPM Variable Speed Feed Rate (4-speed programmable or potentiometer) -- (8) Polyurethane feed rollers -- Arranged for 14" dia. blades and 4"; max cutting thickness -- Single Point Thickness Adjustment from 1/2" to 4" -- Arbor Quick-Change KitComplete with: -- Additional Arbor Setup, Includes: Cart, Blade Box, Arbor, Bearings, Sheave, Throat Plate Rack, and (6) Throat Plates -- (15) Blade Collars: 3-15/16" ID x 4.18" bore x 1.25" wide -- (15) 14" Carbide Tipped Blades: 40 Tooth with 4.188 bore -- Delivery ESTIMATED at (14) weeks; assumes order and down payment are received within (30) days of the date of this quotation. -- Technical Installation assistance - $125/Hr plus travel time and expenses -- Buyer is responsible for rigging -- Quote assumes customer will deliver material for testing (if required) -- Warranty: 1 Year mechanical parts (electrical controls excluded) -- This quotation is valid for 30 days.

LHI RFPR ROLL FEED PANEL RIPPER - "BUILT TO ORDER SYSTEM" with the following equipment: -- Ripsaw: -- 72" Arbor - 50 HP arbore motor and 14 to 80 FPM Variable Speed Feed Rate (4-speed programmable via VFD) -- (8) Polyurethane Feed Rollers -- Arranged for 10" dia. blades to rip panel thickness from 1/8" to 1-1/2"; -- Single Point Thickness Adjustment -- Quick-Change Arbor Kit Additional Arbor Setup Including: -- (1) Arbor Cart, (1) Blade Box, (1) Arbor Shaft, (1 set) Bearings, (1) Arbor Sheave, and (1) Throat Plate Rack Automatic Infeed System: -- 4,500 Lbs. Capacity Hydraulic Scissors Lift with (4) loading ramps to feed and align 4’ x 8’ sheets into Panel Saw -- 110VAC/1PH Scissors Lift power unit -- Auto-Cycling Rake Feeder -- 6’ Line-Up Conveyor With Power Pinch WheelOutfeed Scissors Lift: -- 4,500 Lb. Capacity Hydraulic Scissors Lift with 4' x 8' top, (3) support ramps/cross-bars to allow fork access -- 110VAC / 1Phase power unit -- Auto Down Indexing -- Auxiliary Foot Pedal Control Blades, Collars and Throat Plates: 10" x 40T x 4 3/16 Bore, TGC, $105 eachBlade Collars: 3-15/16" ID x 4.18" bore x 1.25" wide, $135 eachAluminum Throat Plates, $35 each TERMS AND CONDITIONS: -- Delivery: 16-18 Week ESTIMATED delivery date assumes your order is received within one week of date of this quotation. -- A 5% Tooling & Steel Surcharge to be added to the machinery price when the total is known -- Installation technical assistance, $125/hr. plus travel time and expenses (if required) -- Customer responsible for own rigging -- Quote assumes customer will deliver material for testing (if required) -- Warranty: 1-year mechanical parts (electrical controls excluded) -- FOB: Shannon, MS 38868. ESTIMATED SHIPPING DATE: 16 TO 18-WEEKS --The delivery date is quoted as “estimated"; because the equipment manufactured is built to our customer's specifications. This estimate is made under the assumption that there will be no interruptions of labor, material shortages, or any environmental or other unforeseen circumstances. -- LHI is not responsible for any installation or production costs resulting from actual delivery dates which exceed the quoted estimated delivery dates. Accurate dates for the delivery will not be available until the equipment is in the manufacturing phase. If there are custom features for the quoted equipment then accurate delivery dates will be available when testing is complete. Please consult with the factory for updates to the expected delivery date.NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI 72" RFPR Wide Arbor Roll Feed Gang Panel Ripper with Custom 5' x 16' Automated Infeed -- Specifications: -- Panel Ripper with 30 HP Arbor Motor; 1/8" min. to 1-1/4" max. material thickness and 72" cutting width. -- Machine configured for arbor removal from the right side of the Saw when facing the Saw's Infeed (opposite of standard) -- Electricals arranged for 600-volt/60-cycle/3-Phase operation -- 10" Dia. blade design will cut thru max. 1-1/4" thickness; -- 3-15/16" dia. arbor with 72" of usable width cutting capacity, min. panel length 30". -- 1-15/16" FAFNIR arbor bearings; with (8) steel feed rollers on 6" centers; fixed feed speed of 80 FPM -- 47-1/4" working (passline) height -- (1) Arbor Cart is included -- (2) 4" Dia. dust collection ports on top and (1) 8" dust collection port on bottom. Recommended 1,500 CFM Includes the Following Optional Items: -- 5-Strand powered Chain Deck; 12' long; arranged to feed 5' x 16' packages onto the Scissors Lift. Complete with controls for forward, reverse, and jog. -- 5-Sections of Gravity Rollers on Scissors Lift Deck -- 8,000 lbs. Infeed Tandem Scissors Lift with 5' x 17' Deck and 2-HP, 3-Phase Motor. Lift includes a backstop for initial alignment at the Rake Feeder -- (8) Polyurethane Feed Rollers on 6" centers -- Variable Feed Speeds from 10 to 80 FPM. -- Rake Feeder for 16' long panels -- Auto-cycle for Rake Feeder. -- 6' Line Up Conveyor with Fence and Powered Pinch Roll Included Tooling: -- (36) Standard Saw Collars for Ripping -- (72) Standard 10" Sawblades for Ripping (Includes a spare set) -- (37) Standard Throat Plates for RippingQuick Setup Kit Included, Contains the Following -- Belt guide -- Belt Tensioner -- Hydraulic Arbor LockAdditional Arbor Setup Included. Contains the Following: -- Includes cart, blade box, arbor, bearing, sheave, throat plate rack, and(6) throat plates -- Blade Box -- Arbor -- Bearings -- Sheave -- Throat Plate Rack -- (6) Throat Plates SYSTEM TOTAL ............….……$174,495 7% ($12,214) materials surcharge on $174,495 = $186,709

LHI MODEL RFPR AUTOMATED PANEL RIP SYSTEM --Arranged for up to 5/8"; Thick x 52"; Wide x 18’ Long Panels as follows: AUTOIMATIC INFEED SYSTEM, INCLUDES: --Rake Feeder for up to 18’ Long Sheets --Automated Feed Cycle Controls --Turnkey Controls, Plug it in and Run --1 HP, 3-Phase, 460-Volt Operation 6’ ALIGNMENT CONVEYOR, INCLUDES: --Gravity Roller Frame with 60"; Wide Rollers --Alignment Fence --Spring Loaded “Feather"; to Keep Sheets Tight to the Alignment Fence --Powered Feed Wheel to Push Sheets into the Ripsaw --2 HP, 3-Phase, 460-Volt Operation TANDEM INFEED SCISSORS LIFT --8,000 LBS. Capacity --30"; x 204"; Platform With 62"; Rails Mounted Across the Lift for Fork Lift Entry. Rails are Evenly Spaced Down the Length of the Lift --62"; x 204"; Useable Deck Size. --Automatically Raised and Lowered by Signals from the Sheet Feeder --2 HP, 3-Phase, 460-Volt Operation TANDEM OUTFEED SCISSORS LIFT --8,000 LBS. Capacity --30"; x 204"; Platform With 62"; Long Rails Mounted Across the Lift for Fork Lift Entry. Rails are Evenly Spaced Down the Length of the Lift --62"; x 204"; Useable Deck Size. --Automatically Lowers by Signals from Auto-Down Index Control Unit --2 HP, 3-Phase, 460-Volt Operation --OPTIONAL: 4-Sided “Accordion Skirts"; for each Tandem Lift Table, add $2.650 per lift RFPR" ROLL FEED PANEL GANG RIP SAW --50 HP Main Arbor Motor --1/8" Min. To 1-1/4" Max. Material Thickness x 72" Cutting Width --10" Dia Blade Design; 3-15/16" Dia. Arbor with 72" of Usable Width Cutting Capacity --Min. Panel Length 30". --1-15/16" FAFNIR Arbor Bearings --(8) Polyurethane Feed Rollers on 6" Centers --Variable Feed Speeds Via VFD --(1) Quick Blade Change-Out Kit --(1) Additional Arbor Cart --(2) 4" Dia. Dust Collection Ports on Top and (1) 8" Dust Collection Port on Bottom. Total Recommended 1,500 CFM. TOOLING: --(20) Saw Collars, Mount Directly to the Arbor with a Set Screw --(20) Saw Blades Configured for Clean Cuts on Your Panels

LHI 72" RFPR Wide Arbor Roll Feed Gang Panel Ripper with Custom 5' x 16' Automated Infeed -- Specifications: -- 30 HP Arbor Motor; 1/8" min. to 1-1/4" max. material thickness and 72" cutting width. -- 10" Dia. blade design cuts thru max. 2" thickness; -- 3-15/16" dia. arbor with 72" of usable width cutting capacity, min. panel length 30". -- 1-15/16" FAFNIR arbor bearings; with (8) steel feed rollers on 6" centers; fixed feed speed of 80 FPM -- 47-1/4" working height -- (1) Arbor Cart is included -- (2) 4" Dia. dust collection ports on top and (1) 8" dust collection port on bottom. Recommended 1,500 CFM Includes the Following Optional Items: -- 5-Strand powered Chain Deck; 12' long; arranged to feed 5' x 16' packages onto the Scissors Lift. Complete with controls for forward, reverse, and jog. -- 5-Sections of Gravity Rollers on Scissors Lift Deck -- 8,000 lbs. Infeed Tandem Scissors Lift with 5' x 17' Deck and 2-HP, 3-Phase Motor. Lift includes a backstop for initial alignment at the Rake Feeder -- (8) Polyurethane Rollers on 6" centers -- Variable Feed Speeds from 10 to 80 FPM. -- Rake Feeder for 16' long panels -- Auto-cycle for Rake Feeder. -- 6' Line Up Conveyor with Fence and Powered Pinch Roll Included Tooling: -- (36) Standard Saw Collars for Ripping -- (72) Standard 10" Sawblades for Ripping (Includes a spare set) -- (37) Standard Throat Plates for RippingQuick Setup Kit Included, Contains the Following -- Belt guide -- Belt Tensioner -- Hydraulic Arbor LockAdditional Arbor Setup Included. Contains the Following: -- Arbor Cart -- Cart -- Blade Box -- Arbor -- Bearings -- Sheave -- Throat Plate Rack -- (6) Throat Plates PRICE REFLECTS FACTORY'S 7% MATERIALS SURCHARGE ON $156,995, OR $10,990

LHI 4,500 # Scissor LiftSimple Design, Low Cost, High Performance w/ Off-The-Shelf Parts so you can keep it running years from now Specification: -- 4,500 Lbs weight capacity. -- 48" x 96" Smooth steel platform. -- Lowered height 9-1/2" raised height 49". -- Travel speed: 1/2" per second up -- Foot pedal control.Available Options: -- Automatic Down Indexing -- Automatic Up Indexing -- Automatic Up/Down Indexing

LHI 6,000 # Scissor LiftSimple Design, Low Cost, High Performance w/ Off-The-Shelf Parts so you can keep it running years from now Specification: -- 6,000 Lbs weight capacity. -- 48" x 96" Smooth steel platform. -- Lowered height 9-1/2" raised height 49". -- Travel speed: 1/2" per second up -- Foot pedal control.Available Options: -- Automatic Down Indexing -- Automatic Up Indexing -- Automatic Up/Down Indexing

LAUDERDALE-HAMILTON - 62" RFPR: Multi-Blade Panel SawSpecifications -- (1) 50 HP Main arbor motor for: 0.125" min. - 1-1/4" max. material thickness; 10" dia. max. blade cap. with: 1-1/4" min. spacing between the blades. -- Min. panel length of: 30"; 62" usable width capacity. -- 3.9" Dia. arbor with: 1.9" FAFNIR Arbor bearings; positive powered steel contact feed rollers; fixed feed speed of 79 FPM. -- On average, this machine cuts: Bundle of (42) sheets of 3/4" plywood; LVL, PB, MDF or OSB into narrow strips in (4) minutes or less.

LHI POWER RIPPER Straight Line "Rip Saw":Will perform 80% of the jobs done by other Straight-line Rips costing up to four times as much.Specifications: -- 10 HP arbor motor - 230V 1-Phase or 220/440V 3-Phase -- 1 HP feed motor and integral feed unit. -- Variable speed drive or 50 to 180 FPM; fixed feed speeds available (150 FPM standard). -- Cogged steel drive wheels, optional non-marking Polyurethane wheels. -- Easy to change 12" dia. blade - just drop the arbor frame, loosen the arbor nut and change blade. -- Fully enclosed blade plus heavy-duty kickback fingers and heavy gauge belt and chain guards. -- Easy-adjust fence with hand crank and positive lock clamps. -- 4' x 5' Table size with right or left-hand fence available.Options & Features: -- Can be set up to rip hardwoods or softwoods up to 2.75" thick and 3/4" plywood or particleboard up to 4' x 8' in size. -- Available with Quick-Set Fence and digital readouts for lightning-fast size changes.Digital readout, add $2,495

LIGMATECH MPH 450/25/09 CASE CLAMP (SEMI-AUTOMATIC)The LIGMATECH MPH 450/25/09 is a manually operated case clamp. Because of the machines unique design, set up for different size cases is virtually eliminated. The MPH-450 incorporates (2) sets of steel pressure beams, one set horizontal and one vertical. As a result of their alternating construction these beams provide contact all across both sides of the case.Specifications:• Vertical & Horizontal Beams with Variable Pressure Capacity• (2) Selectable clamping speeds (fixed): 22 mm/Sec (4.9 fpm) and 50 mm/Sec (9.8 fpm)Working Capacity:• Case Length: 2,540 mm (100") max & 250 mm (9.8") min• Case Height: 1,397 mm (55") max & 150 mm (5.9") min• Case Depth: 914.4 mm (36") max & 250 mm (9.8") minOptions Include:Built in dwell timer & foot pedal activated pneumatic popup rollers to aid in loading/unloading.

LIGNA 8X40 Multi-Blade Edger/Gang Saw. 40" Wide by 8" high opening. Specifications: -- Bottom saw edger with (5) blades. Powered by a 125 HP TEFC motor. -- Features stacked air cylinder setworks with independent shifting on (3) blades. -- Infeed table with pop-up chains and fence, outfeed rollcase. -- Includes: Powered infeed and outfeed steel roll conveyors.

LIMTECH ORION-510 Flat Table CNC Router with Tool Changer & Boring:5' x 10' Capacity, great for "Nested Base Manufacturing" or just about any type of 3-Axis work.Axes travel range & feed speed: -- X-Axis 61" (1,550 mm), Y-axis with 121" (3,073 mm) and Z-axis 11.8" (300 mm). -- Working Table: 61" (1,550 mm) x 121" (3,073 mm); includes (3) pop-up stops to aid in panel positioning & a manual valve controlled 6-zone special high flow vacuum table system. -- X- & Y-Axis speeds are 2,165 IPM and Z-axis is 1,000 IPM for quick traverse positioning that reduces total CNC machining time between cutting cycles. -- DELTA Servo drive powers the axes movement.Machine bed/base: -- The welded structurally engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- X-, Y- and Z-Axis travel: The moving gantry bridge travels on 1.2" (30 mm) thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high speed traverse and accurate cutting. -- Tool gantry & bridge movement by 1" (25 mm) rack & pinion; the vertical Z-axis travels on precision ball screw for smooth consistent and highly accurate movement.Routing/Machining: -- (1) 12 HP (8.8 kW) Air cooled "HSD" Router spindle with: HSK Tool holders, variable programming speeds from 1,000 to 24,000 RPM. -- Tools are loaded into the "HSD" spindle by (1) 8-position, side mount on the fly tool changer carrousel . -- Tool heights can be set using the Tool Length Setting Gauge (included); machine uses ER-32 tool collets.Drilling/Boring: -- (1) 9-vertical drills spindle head in L-shape configuration for 32 mm contstruction hole & line boring.CNC Control & Operator Interface: -- The "SYNTEC" INDUSTRY CONTROL System, gives the operator an easy to use interface and the flexibility to customize to user specifications; is Network-ready via Ethernet and with USB flash drive. -- Features: Canned cycle, Tool length-diameter compensation, Work Coordinates-Offsets, Spindle-Feed rate overrides, Program size up to flash drive size, DNC or drip feed operation and Unlimited offset registrations. -- Compatible with virtually all CAD/CAM programming software on the market; you choose the software that best suits your needs.Complete with & Includes: -- Dust hood with 6" manifold connection; (4) HSK tool holders; Tool Length Setting Gauge; MPG hand held wheel remote. -- 235 CFM Dry Vacuum Pump; 7.5 kW (10 HP) Vacuum Pump with ON/OFF pre-plumbed to control pane. -- Other Features: Machine Central lubrication, Safety light beams and Automatic homing operation. -- Machine weighs approx. 8,000 Lbs; 15 CFM air consumption at 90 PSI; machine power supply is wired for 220 Volts, 60 Cy, 3-Phase.Includes: Installation & Training by Factory Technician, and (1) Year Parts & Labor Warranty.

LIMTECH ORION-512 Flat Table CNC Router with Tool Changer & Boring:5' x 12' Capacity, great for "Nested Base Manufacturing" or just about any type of 3-Axis work.Axes travel range & feed speed: -- X-Axis 61" (1,550 mm), Y-axis with 145" (3,700 mm) and Z-axis 11.8" (300 mm). -- Working Table: 61" (1,550 mm) x 145" (3,700 mm); includes (3) pop-up stops to aid in panel positioning & a manual valve controlled 6-zone special high flow vacuum table system. -- X- & Y-Axis speeds are 2,165 IPM and Z-axis is 1,000 IPM for quick traverse positioning that reduces total CNC machining time between cutting cycles. -- DELTA Servo Drive powers the axes movement.Machine bed/base: -- The welded structurally engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- X-, Y- and Z-Axis travel: The moving gantry bridge travels on 1.2" (30 mm) thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high speed traverse and accurate cutting. -- Tool gantry & bridge movement by 1" (25 mm) rack & pinion; the vertical Z-axis travels on precision ball screw for smooth consistent and highly accurate movement.Routing/Machining: -- (1) 12 HP (8.8 kW) Air cooled "HSD" Router spindle with: HSK Tool holders, variable programming speeds from 1,000 to 24,000 RPM. -- Tools are loaded into the "HSD" spindle by (1) 8-position, side mounted on the fly tool changer. -- Tool heights can be set using the Tool Length Setting Gauge (included); machine uses ER-32 tool collets.Drilling/Boring: -- (1) Vertical 9-head spindle drills in L-shape configuration for 32 mm contstruction hole & line boring.CNC Control & Operator Interface: -- The "SYNTEC" INDUSTRY CONTROL System provides the operator an easy to use interface and the flexibility to customize to user specifications; Network-ready via Ethernet and USB flash drive. -- Features: Canned cycle, tool length diameter compensation, work coordinates-offsets, spindle feed rate overrides, program size up to flash drive size, DNC or drip feed operation and unlimited offset registrations. -- Compatible with virtually all CAD/CAM programming software on the market; you choose the software that best suits your needs.Complete with & Includes: -- Dust hood with 6" manifold connection; (4) HSK tool holders; Tool Length Setting Gauge; MPG hand held wheel remote. -- Vacuum Pump; 8 kW (11.5 HP) Vacuum Pump with ON/OFF pre-plumbed to control panel. -- Other Features: Machine Central lubrication, safety light beams and automatic homing operation. -- Machine weighs approx. 8,500 Lbs; 15 CFM air consumption at 90 PSI; machine power supply is wired for 220 Volts, 60 Cy, 3-Phase. Includes: Installation & Training by Factory Technician, and (1) Year Parts & Labor Warranty.

100 HP - 1800 RPM Belt driven. -- Jacketed water-cooled requiring 14 Gpm. -- All stainless wetting surfaces and replaceable stainless tools. -- 24" Inside diameter x 102" inside length. -- 14-1/2" x 18" inlet and 12" x 30" outlet. -- Capacity rating is 6,600 to 26,400 pounds per hour at 6 pound density.

LMC 144FTD10 Pulse Jet Dust Collector with Rotary Airlock.24,000 CFM @ 14" SPWG, 10:1 air-to-cloth ratio, contains (144), 144" long bags @ 120" long (2400) sq feet filter area) pulse jet filter. --÷ Complete with: 270 BCS-SW TWIN CITY FAN, Air Handling, Class 17 belt-driven by 60 HPTEFC motor. Volume control damper on fan discharge. NOTE: Fan is 27" and undersized for 24K CFM as was running at lower ACR. Filter to fan ducting, support legs, access ladder, explosion relief panel, -- Includes: 110 V Timer board in NEMA-4 enclosure, GOYEN diaphraghm valves, compressed air header with drain, magnehelic differential pressure gauge 0" - 10" SPWG. -- Was installed with approx. 32" trunk line. Flanged inlet, outlet, and body; perimeter railing, galvanized bag cages with Venturi's, 16 oz. singed polyester filter bags. -- Comes with: 60° Hopper, access panel into hopper, gearmotor powered LMC Rotary Air Lock, easy lift lugs. Clean air plenum with top for filter bag service, service platform. Transfer Blower is included -- 12-Ga. carbon steel construction, enclosure rated to 17" SPWG, top access cover with side door for poor weather access. --÷ Filter Dimensions: 106" x 106" x 335" high. Ready to load on a truck.

LOCATELLI "OMK-300" Automatic Lathe with Sanding; From automatic feeding to finished product ejection - a complete "Turning & Sanding" System. -- 11-13/16" Max. between centers, 3-1/8" max. & 5/16" min. stock dia., 5.5 HP spindle motor with (3) spindle rotations of 3,020 - 4,580 & 6,400 RPM.6-Station Rotary Carousel/Drum with the following operations: -- Station 1: Pickup and centering of workpiece. -- Station 2: Turning with hydraulically operated roughing & finishing gouge. -- Station 3: Finish turning with hydraulically operated finishing gouge; rough & finish gouges advance via 1.5 HP hydraulic motor at a rate of 0.33 - 52 FPM. -- Station 4: Initial sanding with adjustable 0.5 HP vibrating brush. -- Station 5: Secondary sanding with adjustable 0.5 HP vibrating brush. -- Station 6: Ejection of finished workpiece. -- PLC Function for immediate fault detection and facilitates setup. Complies with CE high standards for operator safety. -- Features: Billet capacity has been increased to a special 5.9" x 5.9" (150 mm square). -- Complete with: Separate operator control panel. -- Includes: Inventory of spare parts and tooling. -- Machine kept under power but has not been used for production for several years.
