$80,900
CAM-WOOD SM-623L Moulder, Feed Through 6-Head (B-R-L-T-T-B), working cap. 9-3/4" x 5-1/4". Head sequence: -- Bottom 10 HP, right 10 HP, left 10 HP, top 20 HP, top 15 HP, and bottom 20 HP motor. -- Spindle dia. 40 mm with a cutter-head speed of 7,200 RPM. All spindles with mechanical digital readouts. -- Feed: Variable speed of 26 - 119 FPM, with 7-1/2 HP feed drive motor. Powered feed rollers top and bottom. -- Infeed Straightening table 2M (6'6"), with side pressure roller and table lubrication pump. -- Dust outlet Diameters are 5" X 6" outlets. Includes: -- Hard chrome-plated fences and table, -- Operator/spare parts manuals, -- Centralized control panel, -- Sound and safety enclosure, -- Short stock feeding mechanism (9 1/2" min length), -- Power elevation (1-1/2 HP beam.)Options:Training and installation, tooling & rigging are optional. -- SM-KFST Knife Setting Stand ...$1,970.00The machine base is one piece coated from high-quality cast iron (FC-25) for maximum stability of the structure. Base is machined by CNC machine equipment to ensure the utmost working accuracy. Net weight 11,220 Lbs Shipping weight 12,300 Lbs.
$174,900
CAM-WOOD SM-632 HS 6-Heads High-Speed Through Feed Moulder(6) Heads (B-R-L-T-T-B), working cap. 12-1/2" x 6-1/4"".Specifications: -- Max/Min working width 12 " - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic Jointer for all (6) heads add: ...$46,900 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications) -- For 6 heads machine add $82,800 -- For 7 heads machine add $ 90,600
$132,900
CAM-WOOD SM-632LX 6-Head Feed Through Moulder[6-Head (B-R-L-T-T-B), working cap. 12-1/2" x 6"]Specifications: -- Max/Min working width 12-1/2" - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 25 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with a cutterhead speed of 7,600 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on left and top spindles. Mechanical readouts for pressure elements and chip breakers; all chip breakers and pressure elements with pneumatics. -- Feed works: Inverter driven 10 HP feed system with feed speeds of 38 - 98 FPM. (up to 120 FPM available)Infeed table 2M (6'6"), chromed tables and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 98' per minute are a standard feature. -- The full safety enclosure covers as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows to fit several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- SM Automatic feed magazine -- DC Automatic digital control -- SM Knife setting stand
$201,200
CAM-WOOD SM-732 HS 7-Heads High-Speed Trough Feed Moulder(7) Heads (B-R-L-T-T- T-B), working cap. 111 13/16" x 6-1/4"".Specifications: -- Max/Min working width 11 13/16" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 20 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP, top 15 HP and bottom 15 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,000 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- PNEUMATIC LOAD INFEED SIDE PRESSUREWhile high speed feeding, the side pressure on infeed table ensures every timber close to the fence even under different width. It's convenient to adjust quickly. --OVER HEiGHT PROTECTIONIn case workpiece exceeds the rated maximum height, it will be restricted by the over height protection device provided at the workpiece infeed end. -- HYDRAULIC OUT-BOARD BEARING SUPPORT TOP AND BOTTOM SPINDLESpecially designed hydraulic supports on the top and bottom spindles assure maximum stability while performing high speed and heavy duty machining. -- PNEUMATIC LOAD SIDE PRESSURE WHEELS The front side air pressure wheel on left vertical spindle fully eliminates problem when feeding short or narrow stock not smoothly. The pressure plate is easy and quickly to adjust. -- PNEUMATIC LOAD TOP PRESSURE PLATEThe front pressure plate for top spindle is available to apply an air loading device ensuring maximum stability while performing high speed cutting -- CENTERAL LUBRICATION POINTThe lubrication point are located at the centralized plate for convenience. -- POWERED INFEED TABLE ROLLER The roller in the infeed table is powered, providing a smooth feeding effect for feed stock. -- VERTICAL SPINDLE AXIAL ADJUSTMENT UP TO 60MMIt allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. The 60mm spindle adjustment provides full utilization for a single cutter. -- CENTRALIZED PRESSURE ADJUSTMENT• All pressure regulations for the entire pneumatic system are centralized at the front of the machine for added convenience in pressure adjustment, and sectional pressure adjustments for all pressure rollers ensure consistent pressure.• Clear numerical indicators are provided to correspond directly to the pneumatic mechanisms on the machine, allowing operators to make adjustments based on different processing requirementsAvailable options: -- Automatic Jointer for all (6) heads add: ...$45,600 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control sys
$126,900
CAM-WOOD SM-623-HS 6-Head High-Speed Trough Feed Moulder(6)-Heads (B-R-L-T-T-B), working cap. 9" x 6-1/4".Specifications: -- Max/Min working width 9-3/4" -- Max/Min thickness 6-1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 10 HP, right 10 HP, left 10 HP, top 15 HP, top 15 HP and bottom 15 HP motor. -- Spindle dia. 40 mm (or by request) with cutterhead speed of 6,200 RPM. -- Feed works: Inverter driven, 10 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2 M (6'6"), chromed tables, and fences. Side pressure roller mounted at the infeed. Features and complete with: -- SM-237-DG where the last bottom spindle can be used for cutter head or saws with inverter RPM control -- HMI Touch Screen Control for all the head positions -- Automatic setting from 2nd to 6th heads, (2) axis positions and thickness control by servo control movement -- 200 sets of memory (Extendable) -- Feed speeds ranging from 20' ~ 260' per minute are standard specifications. -- Hard chrome-plated table for maximum wear resistance. -- Full enclosure safety hood reduces noise and completely prevents chips from splashing. -- Anti-impact plate for over-width and over-thickness protection. -- Oversize top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard features maximum durability and is impact resistance. -- The three independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers canbe set with individual pressure allowing for consistent feeding results and outstanding effect. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Exclusively designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate with table feeding roller design, provides smooth and precise cutting of dry and wetwood, reducing the possibility of material jams. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic jointer head for all (6) heads add ...$ 58,500 -- Siko encoder with digital display for all axis add ...$ 4,200 per head -- Automatic lateral chain feeder P.O.R.
CAM-WOOD MRS-340-1M Dip Chain Gang Ripsaw with one Shifting Blade:Specifications: -- Cutting width up to 13";; machine will pass thru 25-1/2"; -- 3"; Maximum depth of cut with 12"; diameter blades. - Will cut 4"; thick with 14"; blades (optional). -- With 70 mm saw spindle; accepts 90 mm bore sawblades -- With air-loaded pressure rolls, standard fence, and feed chain. -- Urethane Chain Pads and Pad Holders optional -- With (1) powered moveable blade and fixed blades. -- Moveable blade controlled with a joystick. -- With (10) push buttons for pre-programmed selective ripping -- The shifting blade moves at 20 to 80 mm/second (up to 3"; per second). -- Moveable saw blade traverses from 0.59" thru 13.38" -- 50 HP Saw arbor motor; -- 3 HP Feed motor with feed speeds from 15 to 130 FPM -- (2) 1/2 HP Lift motors for pressure rolls and saw arborOptional Equipment when ordered with the machine: -- TRS-FT AUTOMATIC INFEED CONVEYOR SYSTEM, with Movable Fence with Digital Display and Shifting Laser Light for Rip Width Setting: .. -- Hydraulic Quick Lock Spindle Assembly. The hydraulic locking spindle assembly is designed to provide for quick changeover between various ripping requirements. Simply turn the locking knob to pressurize the arbor and lock the blades in position. Turn it in the opposite direction to unlock the blades. The sawblades are mounted to solid steel blade collars: ... -- Additional Quick Set Mechanically-Locked Saw Collars for fast, accurate, sure holding of saw blades in any stationary position ... -- 60 HP Saw Arbor Motor: -- Additional 30 MW Laser Unit with Bracket & Wiring: ... -- Pneumatic Pressure to Hold Down Feed Rollers (In lieu of spring pressure). Provides better control of the product being fed. Each pressure roll is controlled by an individual pressure regulator: .. -- Short stock feeding device for 14"; blades (see specifications for cutting capacity information): -- Feed Chain with (69) Easily Replaceable Bolt in Cast Iron Pads. Allows for changing chain pads as they wear or get cut into rather than replacing the complete chain assembly. NOTE: Specially ground down to 0.06"; square tip for optimum hold with virtually no marking: ... -- Feed Chain with (69) Easily Replaceable Urethane Non-Marking Strip Inserts. Urethane is vulcanized to metal backing bars and bolted in place: ... -- 12" Dia. carbide tipped ripsaw blades, cuts up to 3" material: ... -- 14" Dia. carbide tipped ripsaw blades, cut's up to 4" material: ...NOTE: Foot Pedal seen in the photo is only used with a powered Infeed Table and is designed to release boards from the Feed Table.
CAM-WOOD WX-1502H Horizontal GrinderFeatures: Impact-resistant tooling with excellent wear capability. Specifications: -- Horizontal feed, 20 HP - 1,750 RPM drive motor; 15-3/8" x 2-3/8" infeed chute; 8" dia. air discharge. Equipped with: -- (18) Rotary cutter sets with cutter head angle to allow aggressive cutting rates and high-speed shredding of waste; (4) stationary cutter sets; 10" dia. rotor; 575 RPM. -- The shaft rest for the cutter head is constructed by round hollow with special angle for cooling during production. Complete with: -- Removable screen for easy cleanup and chip size changes from standard 1/2". Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.
CAM-WOOD WX-1504HC Horizontal Grinder w/ConveyorImpact resistant tooling with excellent wear capability. Specifications: -- Horizontal feed with (2) 1 HP infeed roller motors; 20 HP - 1,750 RPM drive motor; -- 15-3/8" x 4" Infeed chute; 8" dia. air discharge.Equipped with: -- (18) Rotary cutter sets with cutter head angle to allow aggressive cutting rates and high-speed shredding of waste; -- (4) Stationary cutter sets; 10" dia. rotor; 680 RPM. -- The shaft rest for the cutter head is constructed by a round hollow with a special angle for cooling during production. Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.
CAM-WOOD WX-1510 Vertical Grinder-ShredderImpact resistant tooling with excellent wear capability. Specifications & features: -- Vertical-feed Chute, 10 HP - 1,750 RPM drive motor; 15" x 11" infeed chute; (6) rotary cutter sets & (2) counter-knives with cutter head angle to allow aggressive cutting rates and high speed shredding of waste. -- The shaft rest for the cutter head is constructed by round hollow with special angle for cooling during production. -- Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". -- OutPut: -- 300 - 900 Lbs/Hr, depending on material and moisture content. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.
CAM-WOOD WX-2404HCX Horizontal Grinder w/ConveyorImpact resistant tooling with excellent wear capability. Specifications: -- Horizontal feed with (2) 1 HP infeed roller motors; 30 HP - 1,750 RPM drive motor; -- 24" x 4" Infeed chute; 8" dia. air discharge.Equipped with: -- (30) Rotary cutter sets with cutter head angle to allow aggressive cutting rates and high-speed shredding of waste; -- (4) Stationary cutter sets; 10" dia. rotor; 680 RPM. -- The shaft rest for the cutter head is constructed by a round hollow with a special angle for cooling during production. Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.
CAM-WOOD WX-4150 Vertical Grinder-ShredderImpact resistant tooling with excellent wear capability. Specifications & features: -- Vertical-feed Chute, 50 HP - 1,750 RPM drive motor; 41" x 12" infeed chute; (12) rotary cutter sets with cutter head angle to allow aggressive cutting rates and high speed shredding of waste. -- The shaft rest for the cutter head is constructed by round hollow with special angle for cooling during production. -- Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". -- OutPut: -- 1,300 - 1,800 Lbs/Hr, depending on material and moisture content. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.
CAM-WOOD WX-4751 Vertical Grinder-Shredder Specially designed with push ram, powerful crusher for different materials such as wood, MDF, particle board, plastic, rubber, corn cob, etc. Specifications & features: -- Vertical Hopper 47" x 51"; 50 HP - 1,750 RPM drive motor; (96) rotary cutter sets & (6) stationary cutter sets; cutter-head angle cutting design allows aggressive cutting rates & high speed shredding of waste with maximum durability; 85 RPM rotor speed. -- The shaft rest for the cutterhead is constructed by round hollow with special angle to keep cooling for long hours of usage. -- Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.
CAM-WOOD - XL 300, ...Dip Chain Gang Rip Saw: Short Stock version12" Width cap.; 3/8" min. to 3-3/4"; max. cutting depth; 7" min. stock length.Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0.25 mm (see drawing after the "literature link); with 12"; usable cutting width. -- Accepts saw blades from 10"; - 12"; dia.; arbor is powered by a 40 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 - 100 FPM; feed chain is 12"; wide. -- Table: 28"; Wide x 67"; with 12"; between the column and the 1st saw blade. - Integrated 6"; dia. dust extraction connection.General Description: -- Designed for high-quality Production Line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence; equipped with: Measuring ruler gauge. -- Triple anti-kickback fingers mounted at the infeed side provide max. safety protection; (2) rows from the top and (1) row from the bottom. -- Heavy-Duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision-built saw head ensures accuracy for straight-line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- Power raise & lower to the arbor. -- (4) Pressure rollers & (2) holddown plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for max. motor power output and guarantees Heavy-Duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radial rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or longer length boards.
CAM-WOOD XL300/5116 DIP CHAIN GANG RIPSAW12" Width cap.; 5-5/8"; max. cutting depth; 14"; min. stock length; Designed to meet the exacting standards required for high quality production line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances, and feature the newest designs for operator safety and volume productionSpecifications: -- Accepts saw blades from 12"; to 16"; diameter. -- Arbor is 70mm dia. with (2) keyways -- Saw arbor is powered by a 60 HP motor driving the spindle at 3,200 RPM; Soft start starters and low voltage controls are standard equipment. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 8 to 80 FPM; feed chain is 12"; wide -- Table is 28"; wide x 67"; and 12"; between the column and the 1st saw blade. -- (2) Integrated 6"; dia. dust extraction connections.Complete With: -- (1) 70 mm ID saw sleeve with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0,25 mm (see drawing after the "literature link). -- Two (2) rows of anti-kickback fingers mounted on the top and one (1) row from the bottom (total 3 rows) provides maximum safety protection. Equipped with: -- Precision fence ensures absolute accuracy between blade & fence, equipped with measuring ruler gauge. -- Power raise and lower to the arbor. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frame for durability usage. -- Variable feed speeds enables the machine to meet different work requirements. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain longevity smoothness -- Automatic chain lubrication device equipped with an alarm that sends signals upon a lack of lubrication oil. Features: -- Precision built saw head ensures accuracy for straight line rip saw operations. -- Four (4) bearing spindle ensures rigidity & long life. -- Saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue; spindle is heat treated, precision ground and balanced to provide the utmost in precision cutting performance -- Four (4) pressure rollers & two (2) hold-down plates for precise cutting of large and small workpieces. -- Ten (10) groove pulley and V-Belt arrangement ensures maximum motor output, excellent HP delivery to the saw spindle, and guarantees proper power transmission for heavy-duty multiple rip cutting. -- Adjustable guide rollers make cutting straight for slight radials material; they also secure glue joint at short pieces or long stacks.Options when ordered with machine: -- Additional saw sleeves (sleeve only), each, $415 -- Additional saw with spacer set consisting of: -- (2) 50 mm -- (3) 25 mm -- (4) 10 MM, -- (18) 1 MM -- (10) 0.5 MM -- (8) 0.25 MM -- Add per Sleeve with Spacer Set, $795 -- Laser Light with Mounting Bracket, each $1,190 -- Power raise & lower of the hold-down system when ordered with
CAM-WOOD TG-923 1:1 Profile Knife GrinderEconomical model built for shops with 1 or 3 Moulders or a series of Spindle Shapers.Features: -- Work table and cutterhead moves front to back and left and right. -- Table travels on linear bearing with cross roller rail sets. -- Table travel is designed for extreme accuracy. -- Template holder setup is fast and simple for copy tracer. -- Grinding angle is adjusted on dovetail ways. -- Grinding center DOES NOT change with knife angle adjustments. -- Includes stainless steel water splash guard, coolant tank; with pump and filter, easy and efficient to operate. -- Heavy steel cabinet and stand. -- Cast iron Grinder body. -- Built for high precision and durability.Specifications: -- Grinding Capacity: 12"; dia. x 10"; long. -- Grinding Wheel Size: 7.5" dia. with 60 mm bore. -- Grinding Head Travel: 13". -- Grinding Wheel Speed: infinitely variable from 1,500 to 4,500 RPM. -- Grinding Wheel Motor: 2 HP. -- Coolant Pump Motor: 1/8 HP. -- Net Weight: 1,100 Lbs.
CAM-WOOD TRS 150F Frame SawCAM-WOOD Frame Saws are engineered and designed to make extremely accurate cuts, cutting products with very tight tolerances up to 0.004" and often eliminating sanding before proceeding to the next step . The unique thin frame saw design accepts different saw frames, blade combinations, and allows multiple saw fence configurations to produce single, double or multiple cuts in a single pass.Specifications: -- 3/4" Min. to 6" max. working width; 1-1/4" min. to 7-3/4" max. working thickness (height); 7-1/2" minimum length; finished material > 0.1094". -- 0.043" to 0.055" Saw blade thickness; runs up to (22) blades at one time at (450) stroke/minute with a 8-1/4" stroke length; accommodates blades 1.575" wide x 19.685" long. -- Saw blade frame is powered by a 15 HP motor. Feed speeds of 1 to 5 FPM by 1 HP motor. -- Features automatic oil lubrication system requiring 90 PSI air pressure. Cooling system via water and air. -- Minimum kerf multi-blade frame saw designed to maximize production and minimize material losses to kerf. -- Machine supplied with PLC controller to allow operator fast, instant set-up changes. -- All controls are centrally located for the operator to easily adjust & control operation. -- Material waste reductions of up to 20% are achievable with thin-kerf blades (0.043" ~ 0.055"). -- A special air blast system cools the blade for longer service intervals and removes sawdust from the gullet of the blade to reduce temperature and increase blade life.Note: Frames are available in different configurations.
Call for Price
COMEVA C-600 TOP CNC Door Milling Machine with (7) Axes and Rotary style (ATC) Automatic Tool Changer. The faster and more versatile version of the COMEVA NICRON DOOR models which can perform two jobs simultaneously on the door, ie. mill the hinges and machining the lock at the same time.Milling all types of hinges, including security locks and the recess for the bezel, the longitudinal recess for safety lock, front holes for knob handle, lock, digital locks, peepholes, machined holes or windows (stained glass), and floating probe. Operations performed in minimal time via two separate working channels. Will machine the top and bottom, resize, and bevel doors. Also available with optional loading and unloading of doors. -- Construction: Heavy duty Bridge configuration with two drives, one on end of the Gantry which ensures maximum reliability in the movement of the machine without any oscillation at minimum clearances. Top quality component brands for all linear guides, bearings, brushless servo and reducer. -- General Specifications: Maximum door length 118.1" (3,000 mm). Maximum door width 51.18" (1,300 mm); Minimum door width 15.75" (400 mm). Max door thickness 3.15" (80 mm). Gantry movement, the X axis, max. speed is up to 230 FPM (70 m/Min). Machine features (7) interpolated axes with (2) channels that work independently. -- Horizontal Heads - Hinge & Lock Milling: (2) high frequency motors at 2 HP (1.5KW) on the left and right side. -- Horizontal heads - Top and Bottom of doors: Top/bottom of doors is achieved with one 3 HP (2.2 KW) double-end head which swivels 180°. -- Vertical Milling Router: HSD Motor with ISO 30 ATC of 12 HP (9 KW) for routing hole for handle, crank, standard lock, security lock, electronic locks for hotels/commercial doors; milling or grooving work on the upper side of the door, with upper sensor for automatic measurement.The main milling router with variable speed from 1,000 to 24,000 RPM from the CNC programmable. Ceramic bearings are installed and it has right-left turn. The 10-position ATC is a the Rotary style mounted on the vertical head. -- Vertical Floating Motor: Vertical group also has a floating milling motor head for machining lines or groves top face of the door. Motor is 0.5 HP (0.37 KW). -- Vacuum Unit: BECKER vacuum producer at 100 m³/Hr. -- Production capacity: C-600 max. productivity can be less than one minute per door. Machine has an automatic calibration and automatic detection system of the door, plus roller guides to help load the door.The horizontal working groups on both sides (hinge and lock) work simultaneously allowing time for milling standard doors below (1) minute, approximately. -- Numerical Control/CAD Software: Advanced numerical control type S500 ETX 800 LX AMD PC (or equal) for the control of its (7) interpolated axes. It comes with a 19" display screen. The included COMEVA DOOR software is a special purpose package designed to facilitate the machining of all door ele
$47,900
COMEVA - C-250, ...Programmable Door Milling Machine Specifications: -- Working field "X-axis" 90.55" (2,300 mm) max. door length. -- Working field "Y-axis" 23.6" - 39.3" (600 - 1,000 mm) min/max. door width. -- Working field "Z-axis" 1.18" - 2.36" (30 - 60 mm) min/max. door thickness. -- Positioning:NC Controlled working table for "X", "Y", and "Z" part positioning & processing."X", "Y", and "Z" Axis movement via hardened round ways & ground ball screws. -- Worktables:(2) NC Controlled extruded aluminum support rails with: (4) Non-marking manually positioned pneumatic panel clamps.(1) NC Controlled extruded aluminum support table for "Hinge Plate" router spindles -- Machining: (4) NC Controlled 0.5 HP (0.37 kW), 12,000 RPM air cooled "Hinge Plate" router spindles with: ERC 32 Collets & manual spacing adjustment, RH rotation.(1) NC Controlled 3 HP (2.2 kW) air-cooled 12,000 RPM horizontal "Case Lock" router spindles with ERC 32 collets, RH rotation.(1) NC Controlled 2 HP (1.5 kW) air-cooled 12,000 RPM vertical "Hardware" router spindles with ERC 32 collets, RH rotation. -- Operator & Machine Control: Separate control console with: "DELTA" 12" TFT touch screen control with numerical and function keyboard;Monitor displays programming graphics, machine data & subroutines, runs production programs while programming, and editing.Programming storage for (30) individual programs. -- Complete with: 1-Year Mfg. Warranty, User's operator/maintenance manuals & backup disks. -- Available Options at additional cost:Additional 0.5 HP (0.37 kW), 12,000 RPM air-cooled "Hinge Plate" router spindles with ERC 32 collets = $ 1,976.00 each.Additional 2 HP (1.5 kW) air-cooled 12,000 RPM vertical "Hardware" router spindles with ERC 32 collets = $ 3,240.00 each.Actual Model is COMEVA - C-250, ...CNC DOOR MILLING MACHINEIncludes: Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts.
Call for Price
COMEVA BR-605E 5-Axes CNC Controlled Door Frame Milling Machine with ATC: Designed for cutting and milling wood and aluminum stiles and rails (headers) of door frames/jambs using a saw blade which rotates approx. 270° (universal) for straight cuts (rabbet-step cuts), router for the milling pockets of all types of hinges and locks, and other tooling stored in the approx (8) Position Rotary Tool Magazine. -- Specifications: Frame length is 15.72" (450 mm) to unlimited; Maximum frame thickness of 2.36" (60 mm); Door frame width from 2.36" (60 mm) to 7.08" (180 mm). Saw cut positions at almost any angle. Saw blade diameter approx. 12".Universal Milling Group: HITECO 11.4 HP (8.5 KW) 24,000 RPM 5-axes head. Cutting and milling with axes, X, Y, Z, A (for parts feeder) and B Universal rotation. with servo motors controlled by CNC.Feed Servomotor: Automatic parts feeding system composed of (2) movable clamps driven by servomotors for continuous operation. Reduces loading/unloading times.Controller/COMEVA Software:: -- OSAI (open series) CNC controls its (7) Interpolated axes. Intuitive graphical interface with 19" display. Built-in barcode scanner/reader. -- Specially developed CAD COMEVA DOOR 4.0 software allows the machining of the main designs of hinges and slots you may find all over the market. Software carries a series of predesigned macros that help the operator when performing different operations, thus speeding up various job designs. The software carries out a special program of parametric macros for frames. -- Includes: Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Engineered & Manufactured by COMEVA S.L, in Spain.
Call for Price
COMEVA - G-300, ...4-Axes CNC Controlled Door Frame/Jamb Milling Machine: Designed for cutting and milling the stiles and rails (headers) of door frames/jambs using a saw blade which rotates from +/- 45° & 90° straight cuts (rabbet-step cuts) and a router head for the milling pockets of all types of hinges and locks. --Specifications: Max. frame length of 118.1" (3,000 mm); max. frame thickness of 1.18" (30 mm); max. frame width of 9.84" (250 mm). Saw cut positions at +45°, 90°, -45°. Saw blade diameter of 11.81" - 12.28" (300 - 314 mm).Milling Group: Cutting and milling with (4) axes, X, Y, Z, & A , each with Servo motors controlled by CNC. Components from reputable manufacturers for guaranteed reliability, performance and quality. 1.5 kW - 18,000 RPM Router motor and 4kW - 5,640 RPM saw motor. X-Axis reaches a speed up to 290 FPM (90 MPM)COMEVA Software: -- Specially developed COMEVA DOORS software allows the machining of the main designs of hinges and slots you may find all over the market, including the machining on the upper side/edge of the door. Software carries a series of predesigned macros that help the operator when performing the different operations, thus speeding up various job design. Software carries out a special program of parametric macros for doors/door frames. This software is normally installed in user's own PC.NC Control: NC Controls for X, Y, Z & A-axis for tool positioning & processing. Axis movement via hardened round ways & ground ball screws. Advanced NC control powered by OSAI which is set up to control the (4) Interpolated axes. Comes with a PC with 19" display.Rails//Workholding: (4) Sliding rail units with (4) pneumatic fixturing clamps (aluminum and plastic) that can be moved for all frame sizes. (2) Side pistons put both frame stiles and the head rail in the correct position before starting the cycle. -- Includes: Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Overall machine dimensions: 134" x 99" x 63" high (3,400 x 25 mm x 1,600 mm) -- Engineered & Manufactured by COMEVA S.L, in Spain.
