CAM-WOOD "DYNAMIC" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 408: $ 60,090SERIES 510: $ 63,800SERIES 512: $ 65,080Models Include (Table Sizes): 408 (4' x 8'), 510 (5' x 10'), 510 (5' x 12')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemSpindle: 9.0kW (12.8Hp) HSD Air-Cooled Spindle - 6,000 - 24,000 rpmBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: YASKAWA Servo Drive and MotorY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: Rotary (12) Tools ISO30, ER32Inverter: 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionalDrill Bank: Includes (9) Tools HSDCAD/CAM Software: OptionalWorking Size:SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)SERIES 512: 63’’ (X) x 150’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408: 87’’ (X) x 122’’ (Y) x 71’’ (Z)SERIES 510: 99’’ (X) x 149’’ (Y) x 71’’ (Z)SERIES 512: 99’’ (X) x 173’’ (Y) x 71’’ (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408: 3,960 lbs / SERIES 510: 4,480 lbs / SERIES 512: 4,970 lbsFeatures Include: --Automatic (12) Tool Rotary Type Auto-Tool Changer for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by Brush-Less Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --Optional CAD/CAM System can Create and Edit Part Programs then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified and Edited from here to Create a G-Code. --DNC is no Longer Required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress-Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Trav

CAM-WOOD "PROFORMA LN" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 408 LN: $ 43,300SERIES 510 LN : $ 46,600Models Include (Table Sizes): 408 LN (4' x 8'), 510 LN (5' x 10')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemSpindle: 9.0kW (12 Hp) Air-Cooled Spindle 6,000 - 24,000 RPMBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Lead-Shine Servo Drive and MotorY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: SERIES Linear (12) Tools ISO30, ER32Inverter: SCHNEIDER 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionDrill Bank: Optional (9) Tool HSDCAD/CAM Software: OptionWorking Size:SERIES 408 LN: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510 LN: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408 LN: 122’’ (X) x 87’’ (Y) x 71’’ (Z)SERIES 510 LN: 99’’ (X) x 149’’ (Y) x 71 (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408 LN: 3,960 lbs / SERIES 510 LN: 4,480 lbsFeatures Include: --Automatic (12) Tools Linear Type Auto Tool Changer under the Bridge for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by a Brushless Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --Optional CAD/CAM System can Create and Edit Part Programs then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified and Edited from Here to Create a G-Code. --DNC is no longer Required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse and Precision. --The X & Y Axis are Equipped with a Precision Rack & Pinion Driving System. The Z Axis Utilizes a Ball Screw Assembly Complete with the Pre-Loaded and

CAM-WOOD SM-3006 Push Feed Moulder4" x 6" 3-Side Planer, Moulder; Our most cost effective small to medium shop size Push-Feed Moulder.Equipped with & Features: -- If you try to run your short runs of special moulding at lower prices, this machine could be your answer. -- Solidly built with cast and steel plate construction, this is one moulder that will give you a foot up on the competition at an affordable price. -- Precision cast and steel plate construction to ensure a smooth finished product. Two vertical and one 1-1/4" horizontal spindle driven by individual industrial motor allowing smooth cutting on three surfaces simultaneously. -- Alloy steel spindle for durability usage. -- Two power infeed rollers feed the material to push previous pieces through moulding process then comes out from the end. -- (2) Belts driving at each spindle for maximum cutting power. -- Top and side pressure hold down to ensure smooth finish. -- Industrial full power motor for maximum cutting capacity. -- Precision sealed long-life bearings. -- Heavy cast iron frames and table for durability usage.Specifications: -- Table Size 47" L x 10" W. -- Moulding Capacity (Max.) 6" W x 5" H, Capacity (Min.) ¼" W x ½" H. -- Top Spindle Size 35 mm x 6" long. -- Side Spindle Size 1¼" x 3½" long. -- Spindle Travel 3", Spindle Speed 7000 RPM. -- Max. Cutter dia. 5". -- Spindle Motor (Top) 5 HP, (side) spindle motors 3 HP each. -- Feed Motor ½ HP and Feed Speed 10 ~ 56 FPM. -- Dust Hood 4" x 4". -- (2) Top Pressure Rollers and (3) Side Pressure Rollers.Overall Dimensions & Weight: -- 51" L x 43" W x 41" H. -- N.W. 1210 Lbs, G.W. 1550 Lbs.

CAM-WOOD - VPS I, ...Vertical Panel Saw (82.677" x 161.417" w/Scoring)Top to Bottom cutting height is 2,100 mm with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 4,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness. Standard features: -- 4 HP Motor with a 250 mm (10") dia. 80-tooth main saw blade. -- Separate 3.15" Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cut line prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock-in the saw beam for vertical crosscuts. -- (2) Adjustable flip stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: -- (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade; Repeat Cutting Device.Optional Equipment available: Built-in Dust Collector, please add ...$ 1.250.

CAM-WOOD - VPS I +, ...Vertical Panel Saw (82.67" x 161.41" w/Scoring), Vertical-Horizontal Digital Readouts & Auto Lock System. Top to Bottom cutting height is 2,100 mm with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 4,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness.Standard features: -- 4.0 HP Motor (5.5 HP Option) with a 250 mm (10") dia. 80-tooth main saw blade. -- Separate 80 mm (3.15") Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cut line, prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- (2) Adjustable flip-stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Repeat Rip Gauge for duplicating multiple horizontal cuts. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: Vertical-Horizontal Digital Readouts; Pneumatic lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-teeth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade.Optional Equipment available: Built-in Dust Collector, please add ... $ 1,250.

CAM-WOOD - VPS APL , ...Vertical Saw w/Scoring & Panel Lifting ClampsCapacity: -- Top to Bottom cutting height is 82-1/2" (2,100 mm) without scoring and 78-3/4 (2,000 mm) with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length "rip cut from left/right" is 161.417" (4,100 mm); cuts single or stacked panels up to 1-7/8 (50 mm) in thickness. Equipped with: -- 4 HP Motor; 250 mm (10") dia. x 80-tooth x 30 mm bore main blade; separate 3.15" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine to Hardwood. -- 2-Motorized panel lifting clamps "grab panel on top edge" for bottom cuts, clamps travel on (2) vertical screws for positioning of panels (660 Lbs. cap). -- (2) LED Readouts, (1) for crosscutting at the middle of the frame and (1) for horizontal rip cuts; (2) flip stops for crosscut measuring, one located on the bottom rail and the other on the mid-height measuring rail. Complete with: -- Foldout shelf at the middle of the frame for small part cutting; automatically shifting material back support grid shifting away from the saw blade cut-line prevents cutting into the grid support strips while rip cutting horizontally. -- Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels; standard inch preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- Rip gauge for repeat (same size) rip cuts and (3) adjustable preset stops; material always rests firmly against the "angled" back grid support. Includes: -- Spring-loaded floating saw blade enclosure shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- (1) Main blade; (1) scoring blade.

CAM-WOOD - VPS I +: Vertical Panel Saw (76" x 122" w/Scoring); Vertical/Horizontal Digital Readouts & Auto-Lock SystemTop to Bottom cutting height : 2,000 mm (76") with or without: Scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 3,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness.Standard Features -- 4.0 HP Motor (5-1/2 HP Option) with: 250 mm (10") dia. 80-teeth main saw blade. -- Separate 80 mm (3.15") dia. scoring blade; belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto shifting material back support grid; shifting away from the saw blade cutline prevents cutting into the grid support strips while rip cutting horizontally; senses the blade/cutter position & automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading & positioning of the larger or heavy panels; both standard inch & metric preset "beam lock" stations. -- Vertical Cutting Stations: Spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- (2) Adjustable flip stops on inch (metric available) measuring scales: (1) Located on the lower rail & the other on the foldout shelf at the middle of the frame. -- Repeat Rip Gauge for duplicating multiple horizontal cuts. -- Retractable Material Support Shelves throughout the entire length of the machine frame allow ergonomic cutting of smaller parts, at any cutting station without the need for the Operator to bend down.Includes: Vertical/Horizontal Digital Readouts; Pneumatic Lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth; 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth; 20 mm bore scoring blade.Optional Equipment available. Built-in Dust Collector: Please add ...$ 1,250.

CAM-WOOD - VPS AV, ...CNC Fully Automatic Vertical Saw w/Scoring & Panel Lifting ClampsPC Control Panel with Software Optimizing Panel Cuts, Automatic Positioning System; the machine automatically switches to the vertical and horizontal position by Automatic Positions System.Capacity: -- Top to Bottom cutting height is 82-1/2" (2,100 mm) without scoring and 78-3/4 (2,000 mm) with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length 161.4" (4,100 mm); cuts single or stacked panels up to 1.57" (40 mm) in thickness. Equipped with: -- 4 HP Motor; 250 mm (10") dia. x 80-tooth x 30 mm bore main blade rotate at 5,800 RPM; separate 3.15" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine to Hardwood. -- 2-Motorized panel lifting clamps "grab panel on top edge" for bottom cuts, clamps travel on (2) vertical screws for positioning of panels (660 Lbs cap.). -- (2) LED Readouts, (1) for crosscutting at the middle of the frame and (1) for horizontal rip cuts; (2) flip stops for crosscut measuring, one located on the bottom rail and the other on the mid-height measuring rail. -- Programmable Panel Drive System with +/- 0.1 mm accurate positioning to preprogrammed lengths. Complete with: -- Foldout shelf at the middle of the frame for small part cutting; automatically shifting material back support grid shifting away from the saw blade cutline prevents cutting into the grid support strips while rip cutting horizontally. -- Precision ground bottom edge support rollers with double bearings to facilitate easy loading & positioning of the larger or heavy panels; standard inch preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- Rip gauge for repeat (same size) rip cuts and (3) adjustable preset stops; material always rests firmly against the "angled" back grid support. -- Spring-loaded floating saw blade enclosure shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- Includes: -- Automatic Lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 125 mm (4.92") dia. 24-tooth, 20 mm bore scoring blade.Optional label printer available for additional cost.

CAM-WOOD TX-E8V Automatic Vertical Panel SawSpecifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- Manually positioned pusher fence with grippers; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (3) Cutting modes: Standard, trim & cutoff to permit clean burrs, repeat cutting mode; heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut, this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD TX-C8VX Automatic Vertical Panel Saw (Servo Gripper)Specifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- PLC Controlled automatic pusher fence with grippers with Auto Stops or Auto Program Sizing mode; 40 FPM pusher speed, +/- 0.004" accuracy; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (2) Cutting modes: Standard cutting & scoring pass and cutting; the heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut; this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD PT-48VAX Door Clamp (Single Sided). -- Work Space: 48" Max. width x 97" max. length, hydraulically operated.Specifications: -- Applies max. 11,000 PSI pressure from (2) sides; 90 PSI from holddown. -- Includes 5 HP hydraulic pressure system. -- Hydraulically operated assembly table; twin hydraulic cylinders for moveable rams at two sides pressing for max. assembly capacity. -- Easy adjustments of rams, makes changing sizes simple; separate controls for adjusting the each side of press rams. -- Fixed reference points for lower & left edges ensure 90° assembly of face frames; heavy gauge steel metal table & frame.NOTE: Also available as a 2-sided Clamp for ...$26,500.

CAM-WOOD PTX-2513 Entry Door/Window Hydraulic Assembly Press, 4' x 8'. Hydraulically operated. Solidly constructed and welded with great precision.Specifications: -- Working area:1300 mm (51") Max. width; 2500 mm (98") max. length. -- (2) Vertical cylinders, each of stroke 80 x 600st; (2) side cylinders, each of stroke 50 x 800st. -- Comes with: 2 HP hydraulic pump motor. -- Outer structure is made of two vertical beams which are individually located at the upper and the bottom side of the machine. The horizontal beams have vertical hydraulic cylinders thereby moving beams up and down to distribute the pressure evenly on the workpiece. The overhead push button operates the hydraulic motor. -- Stops (square blocks) are moved manually to set to the desired position. The mobile pressing platen of the square block and the horizontal upper beam can be moved by the vertical hydraulic cylinder. -- Equipped with: A pressure gauge and pressure control valve to regulate the vertical and horizontal hydraulic cylinders for precise, desired working pressure. -- Overall Dimensions/eight: 3000 x 1200 x 2200 mm (120 x 48 x 87"). Weight: 1200 Kg (2650 Lbs).NOTE: Also available in 5' x 10' Press for ...$26,500.

CANTEK HB-800 32" Vertical Band Resaw32" Wheel diameter, 20 HP motor Vertical Band Saw;Specifications: -- 3.543" (90 mm) wheel width, 30-5/8" throat capacity, 15-3/8" under guide capacity. -- 4" Blade width X 216- 217-1/8" blade length. -- 20 HP main motor, generates a blade speed of 5,024 SFPM.Features: -- Heavy fabricated steel machine frame. -- Specially designed Bakelite guide blocks provide rigid side blade support for straight cutting. -- Large cast iron work table is precision ground & can tilt to a maximum of 45°. -- Convenient blade tension adjustment by means of a handwheel and gauge. -- Cast iron upper and lower saw wheels are precision machined and dynamically balanced. -- Rack & pinion blade guide adjustment. -- Wheel is crowned for proper blade tracking & added stability of the blade.Complete with: -- Foot brake for braking wheels & blade. -- Blade lubrication system and reservoir for lubricant keeps blades cool.Including Electrics to UL/CSA - all starters -- Auto Start-Delta control for main motor with Emergency Stop Switch -- Telemecanique brand magnetic switchHF-150A Feeder: -- 1 HP motor with variable feed speed from 16 - 66 FPM; 6" feed opening. -- Pneumatic tensioned feed roller. -- Feed pressure is adjustable. -- Feed roller opening & closing is controlled by a foot switch for operator convenience. -- Knurled steel roller.

CANTEK JF-330A Profile Knife Grinder Clamping length of 12" (300 mm) for both straight and profile grind; dia. of knife swing 12" (300 mm). -- Grinding Arbor: 3 HP grinding motor with VFD (LED Readout) drive from 1.500 to 4.200 RPM. Quick change removable (140 mm) wheel adapter. Machine set for axial constant grinding and template set up on right-hand side.Over the wheel precision diamond dresser assembly for dressing and dimensioning of wheel. Manual positioning: of grinding wheel to tool; positioning of back clearance angle and side clearance angle 5°/10° and 15°. Quick change stylus turret for applications; (6) included with machine. -- Carriage: SCHNEEBERGER linear bearing table movement. Table movement 12" x 6". -- Coolant system: 1/8 HP motor from coolant pump located in the tank below; (3) coolant nozzles for smooth flow of coolant to knife rest during grinding. Additional hose with nozzle for cleanup. Stainless steel splash guards throughout! -- Includes: Set up tools, coolant, HD worklight, grinding wheels and (1) arbor of choice - (1.25", 1.5", 40mm, 1-13/16", 2.125" or 50 mm).

CANTEK MX340M EDGEBANDERThe MX340 from CANTEK is designed to be a compact, and durable edgebander.Specifications: -- This machine is equipped with end trimming, flush trimming, PVC scraping, and buffing. -- The CANTEK MX340 Edgebander is operated through a PLC control system with an LED display and keypad. -- The MX340 handles panel thickness of 0.315" up to 1.77" (8 mm to 45 mm), -- The coil feed accepts edgebanding from 0.4 mm to 3 mm thick, and strip material can be hand-fed. -- Conveyor feed speed is 29.5 FPM (fixed). --Work stations: -- Heated infeed fence for optimum glue penetration. Large capacity Teflon-coated glue pot (2.64 Lbs). -- Pneumatically operated guillotine for up to 3 mm thick banding, followed by spring-loaded double-pressure rollers. -- Single front/rear trimming unit 0.3 HP motor. -- Double top and bottom trimming units (2) 1/2 HP motors. -- Top and bottom scraper/radius scraper. -- Top and bottom buffing station (2) 0.16 HP motors.

CANTEK MX340 Edgebander (Single Phase or 3-Phase)The MX340 from CANTEK is designed to be a compact, and durable edgebander. -- This machine is equipped with end trimming, flush trimming, PVC scraping, and buffing. -- The CANTEK MX340 Edgebander is operated through a PLC control system with an LED display and keypad.Specifications: -- The MX340 handles panel thicknesses of 0.315" up to 1.77" (8 mm to 45 mm). -- The coil feed accepts edgebanding from 0.4 mm to 3 mm thick, and strip material can be hand-fed. -- Conveyor feed speed is 29.5 FPM (fixed).Work stations: -- Heated infeed fence for optimum glue penetration. Large capacity Teflon coated glue pot (2.64 Lbs). -- Pneumatically operated guillotine for up to 3 mm thick banding, followed by spring loaded double pressure rollers. -- Single front/rear trimming unit 0.3 HP motor. -- Double top and bottom trimming units (2) 1/2 HP motors. -- Top and bottom scraper/radius scraper. -- Top and bottom buffing station (2) 0.16 HP motors.

CANTEK - EM-12: Finger Jointer / End MatcherMachine arranged to Finger Joint but can be easily converted to End Match.Specifications -- 1.6" to 12" Width x 3/8" to 1-3/8" thickness x 10.6" min. length capacity.Unlimited lengths possible.Feed speeds to: 295 FPM with approx. production speeds of 77 FPM (based on 6-1/2" incoming boards). -- Standard 118" long infeed table; standard 98" long outfeed table. -- (2) 5-1/2 HP Cutterhead motors; 40 mm spindle diameters; 1 HP feed motor; 1/2 HP motor drive to cutterhead carriage; clamping pressure from top and side.Standard Equipment & Features -- Heavy-Duty self-supporting main frame; compact design requires: Min. floor space; capable of processing material: As short as 11" to an unlimited length. -- Variable speed through-feed systems is: Controlled by frequency inverter; through-feed system: Allows the fingers to be cut simultaneously on the tail of one board & the leading edge of the next board. -- Powered top urethane rolls & spring-loaded bed rollers: Feed the material into position for processing. -- Pneumatic side pressure: Ensures the material is held square against the fence. -- Complete safety & noise reduction enclosure; convenient touchscreen control: Used to quickly activate & adjust the machine functions. -- Infeed & Outfeed Roller Conveyor.

CANTEK - MX-370P: Edgebander (w/Premill & Corner Rounding) -- Specifications0.4 - 3 mm Edge thickness; panel thickness: 0.315" - 1.77"; min. panel length: 6.7"; min. panel width: 3-3/4". Heated infeed fence for better glue adhesion; fixed feed speed: 29 FPM. -- Equipped with: Premill: (2) 1.5 kW each (12,000 RPM) counterrotating cutterheads for removing up to 3 mm of the panel edge. -- Quick Change: 1.2 kG Teflon coated glue pot: Designed for EVA hot-melt glue; glue pot is a Quick-Change type & can be removed and replaced in less than (1) minute. -- Guillotine Shear: Guillotine shear can rough trim coiled material up to 3 mm in thickness. Pressure rollers section consists of: (1) Large driven roller followed by a smaller one. -- Workstations End Trim: System is a single motor with: (2) Saw blades. Unit is mounted on high precision linear guide rails. -- Top & Bottom Trimmers with: (2) High frequency motors for top & bottom trimming of the panel. Each motor equipped with: Inset knife cutterhead, which can be adjusted from flush to beveled finish for thin edges & radius trimming (2 mm radius). Single motor Corner Rounding Unit can process between: 0.4 - 3 mm & Up to a board thickness of 1.77" (45 mm).Multifunctional Cutter can: Round straight or radius edges with a 2 mm radius cutter. -- Radius Scraping Unit: Fine-tunes the edge radius, while removing knife marks during the milling process on radius edging; insert knives: 2 mm Radius. -- Buffing Unit: Leaves a super finish on ABS & PVC edging and removes any discoloration on the edges.

CANTEK - MRS-340-M2, ...Rip Saw Multiblade with OSI OptimisationAutomatid rip line with width optimizationSpecifications -- Part width 3" to 15" -- Part lenght 4' to 14' -- Part thickness up to 4.33" -- Feed speed 15 FPM to 135 FPMLine Composition: -- Inffed roller conveyor 16" X 15' long -- Cognex Width Scanner made by OSI/Logiflex -- Lateral cross feed conveyor OSI 15' X 16' -- Roller conveyor with Automatic fence positionning with control of the 2 moving blade on the Cantek rip sawCantek MRS 340-2 Specifications -- 4.3" Max. thickness with 14" dia. fixed blade(s); 3.3" with 12" fixed blade(s); 4" with 14" movable blades and 2.95" with 12" movable blades; 13.4" max. working width between outside saws 25.6: max. -- 0verall width; 5-1/2" max. distance to fence from inside fixed blade; 0.59" to 13.38" max. saw travel; 23-1/2" min. stock length; 19.7" possible with optional short stock holddown (reduces thickness capacity). -- With 70 mm dia. x 13-3/4" long saw arbor powered by a 50 HP motor driving the blades at 3,800 RPM; 3 HP feed motor; provides feed speeds from 15 to 135 FPM; -- 0.5 HP Lift motor for holddown roll. -- Infinitely variable saw shifting speeds from 0.78" to 3.15" per second. -- 72" x 31" table size; sits 30" from the floor. -- Outfeed lateral belt conveyor 86" X 150" with feed speed of 65FPM OAL: 30' X 30'

CANTEK MX350 EDGEBANDER (W/ PRE-MILLING): -- Specifications:0.4-3 mm Edge thickness, panel thickness 8~45 mm, min. panel width 100 mm (4″), min. panel length 170 mm (6.7″). Equipped with: -- Quick melt Teflon coated glue pot 2.5 Lb capacity. Two spring loaded pressure rollers (One driven, one idling). Automatic coil feed PVC/ABS up to 3mm thick, pneumatically operated guillotine. Laminate strip material can be hand-fed. PLC control system with LED display and keypadWorkstations: -- Pre-Mill station with (2) 1.1 Kw 12,000 RPM trim motors 32 mm (1.25") max. material thickness. -- Single motor front and rear edge trim station. -- Top & bottom trim station with insert knife cutters for radius trimming & bevel trimming. -- Top & bottom scrape station 2 mm radius. -- Top & bottom buffing. -- Feed speed 29 FPM
