CAM-WOOD WP-610A Single-Sided Planer 10 HP - 24" Cap. Features: -- 24" Spiral cutter head provides precise, efficient planing with low noise levels. -- Automatic digital thickness controller for quick & accurate setting. -- Motorized worktable raises & lowers by separate motor for more efficient operation. -- Specially designed infinitely variable feed system is powered by a separate motor and allows adjustment to the optimal feed rate for planing to a precise smooth finish on both hard or softwoods. -- The sectional infeed roller & anti-kickback device & chip breaker gives the operator greater safety. -- Up to 8"; thickness large cutting capacity. -- Exhaust dust hood with 4"; dia. outlet for proper chip extraction. -- The motorized worktable includes twin quick adjustable bed rollers that can be adjusted for rough & finish planing on damp or dry lumber ensuring a consistently smooth planed finish. -- Precision sealed long-life ball bearing. -- Industrial motor for powerful cutting capacity. Heavy gauge sheet metal frame and base for maintenance-free service.Specifications: -- Table area 25" x 28". -- Max. planing width 24". -- Feed Speed (Var.) 15 ~ 60 FPM. -- Max thickness 8'' and min. Planing Thickness 1/8". -- Elevation Motor 0.5 HP. -- Cutterhead Speed 5,500 RPM. -- Cutter head diameter 4-3/4", Spiral. -- Knife insert dimensions 14 mm x 14 mm. -- Max. Cutting Depth 5/16";. -- Feed Motor 1 HP. -- Cutterhead Motor 10 HP. -- G.W. 1,850 LBS / 2,000 Lbs.

CAM-WOOD WP-760 15 HP Single Sided 30" Planer Features: -- Spiral cutterhead provides precise, efficient planing with low noise levels. -- Automatic digital thickness controller for quick & accurate setting. -- Motorized worktable raises & lowers by separate motor for more efficient operation. -- Specially designed infinitely variable feed system is powered by a separate motor and allows adjustment to the exact feed rate and allows precision smooth finish planing on both hard or softwoods. -- The sectional infeed roller & anti-kickback device & chip breaker provides greater safety for the operator -- Exhaust dust hood with 4"; dia. outlet for proper chip extraction. -- The motorized worktable includes twin quick adjustable bed rollers that can be adjusted for rough & finish planing on damp or dry lumber ensuring a consistently smooth planed finish. -- Precision sealed long-life ball bearing. -- Industrial motor for powerful cutting capacity. Heavy gauge sheet metal frame and base for maintenance-free serviceSpecifications: -- Table Area 38" x 31" -- Max. Planing Width 30" -- Max. Planing Thickness 8" -- Mini. Planing Thickness 3/16" -- Cutterhead Speed 5,500 RPM -- Cutterhead Diameter 4-3/4" Spiral -- Knife Dimensions 14 mm x 14 mm -- Feeding Speed (Var.) 15 ~ 75 FPM -- Max. Cutting Depth 5/16" -- Feed Motor 2 HP -- Cutterhead Motor 15 HP, 3 Ph, 230 V -- Table Elevation Motor 1 HP -- Digital Thickness Control Yes -- Dust Hood Outlet 5"G.W. 2450 Lbs

CAM-WOOD WP-2000S Single Sided Planer20" Planer with solid cast iron construction and Spiral Cutter Head.Features & Specifications: -- Precision ground cast iron table w/manual adjustment by hand wheel via (2) large lead screws. -- Scale & pointer readout for accurate thickness adjustments. -- Fixed feed (30 FPM) speed setting for consistent stock removal. -- Sectional steel infeed roller & segmented chip breaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- 3 HP Self-braking motor. -- Magnetic starter & thermal overload switch and Emergency stop. -- Operations manual, parts list & tool kit. Optional: CT-SCH-14T - 14 mm x 14 mm SPIRAL CUTTERHEAD BLADES ...$3.30 each

CAM-WOOD WP-1400H 52"; Heavy Duty Planer with S.C.H.55" Cap. solid cast iron construction planer with powerful 25 HP motor.Features & Specifications: -- Precision ground cast iron table with motorized worktable raising & lowering, manual adjustment by hand wheel via (2) large lead screws. -- Digital thickness display with touchpad positioning control for accurate thickness adjustments. -- 5" Spiral cutterhead with 4-sided carbide inserts provide precise, efficient planning with low noise levels. -- With (4) each 4" diameter dust outlets. -- Sectional steel infeed roller & segmented chipbreaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- Self-braking motor. -- Magnetic starter & thermal overload switch. -- Emergency stop. -- Operations manual, parts list & tool kit. Machining Specifications: -- Max. Cut Width 52". -- Max. Cut Thickness 8". -- Max. Cut Depth ¼". -- Min. Cut Length 9". -- Cutting Speed 3,600 RPM. -- Table Size (W x L) 55" x 55". -- Main Motor 25 HP, 3 Ph. -- Feed Motor 5 HP. -- Table Raising Motor 1 HP. -- Feed Rate (Variable) 0 ~ 50 FPM. -- Shipping weight 7,400 Lbs.

CAM-WOOD SM-155AX Feed Through Moulder 5-Head Moulder with a 6" width and a 4.75" max. thickness capacity.Overall Description: -- Cast Iron mainframe to maximize stability & minimize vibration during operation for years of use. -- Fully enclosed sound hood with lift-up door for easy set-up access. -- Adjustable infeed table w/fence for straightening rough sawn material. -- 16 - 66 FPM Variable feed speed system with top-driven rollers. -- All spindle adjustments except 1st bottom spindle with mechanical digital readouts. -- Left and Top spindles with mechanical Digi-set readouts. Chipbreaker and pressure element with mechanical digital readouts for accurate adjustment and precise settings.Complete with: 5' Infeed table length, Chromed table plates, fences, and pressure shoes. Manual Waxilit pump, Central lubrication of the machine from the front side.Specifications: -- Max. (Min.) Working Width 6" (3/4") -- Max. (Min.) Working Thickness 4-3/4" (5/16") -- Min. Working Length 9½". -- 1st Spindle Horsepower 7½ HP. -- 2nd, 3rd Spindle Horsepower 5½ HP, 5½ HP; -- 4th, 5th Spindle Horsepower 10 HP, 7½ HP. -- Cutterhead Dia.: 1st Bottom Head 5" dia.; 2nd, 3rd Vertical Head 5" - 6-1/4" dia.: 4th, 5th Head 5" - 7" diameter. -- Feed Motor 4 HP. -- Elevation 1 HP motor. -- Spindle Diameter 40 mm. -- Cutter Head Speeds 6,500 RPM. -- Variable Feed Speeds 16 ~ 66 FPM. -- Pneumatic Air 90 PSI (5 CFM by bolume) -- Dust Outlet Diameter 5" x 5" -- Net Weight 5,900 Lbs; Gross Weight 6,700 LbsIncludes: -- Operator/spare parts manuals and setup tools.

CAM-WOOD SM-324D 4-Sided Planer for L-Shape MouldingSpecial Design for “L"; Shape Mouldings; One set of Cutter heads IncludedSpecifications: -- Maximum Working Width 12";, Max. Thickness 4"; -- Hard chrome-plated table for maximum wear resistance. -- Anti-impact plate for over-width and over-thickness protection. -- Oversized top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard provides maximum durability and impact resistance. -- The three independent sections; pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding and outstanding results. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Specifically designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate based on the table feeding roller design provides smooth and precise cutting of dry and wet wood, reducing the possibility of material jams.Features: -- The base is machined by CNC machine equipment to ensure the utmost working accuracy. -- The first bottom horizontal spindle can be fitted with a trimming cutter for trimming a groove on the workpiece side to achieve perfect straightness. -- The specially designed short stock feeding mechanism combined with auxiliary pressure wheels permits the machine to perform machining on extra short stocks. -- All spindles are precision constructed and specially heat treated to provide maximum cutting stability and permanent accuracy. -- Each spindle is equipped with a mechanical digital readout giving accurate adjustment. -- Every cutter spindle can be adjusted "up and down" and "in and out" for quick setup. -- Industrial full-power motors for maximum cutting capacity.Capacity and Heads: -- Max. Working Width 12"; -- Max. Working Thickness 4-3/4" -- Min. Working Length 9½" -- Vertical stroke of side head 30 mm (1.18") -- 1st Spindle Horsepower 10 HP -- 2nd, 3rd, 4th Spindle Horsepower 10, 10, 10 HP -- Feed Motor 7½ HP -- Elevation motor 1 HP -- Spindle arbor Diameter 40 mm -- Cutter Speeds (RPM) 6,500 -- Variable Feed Speeds (FPM) 16 ~ 82Cutterhead Diameter -- 1st Bottom Head 6"; Dia x 12"; L -- 2nd & 3rd Vertical Head 6"; Dia x 3"; L -- Top Head 6"; Dia x 12"; L -- Pneumatic Air 90 PSI (CFM) 5 -- Dust Outlets Diameter 5" x 4 outlets -- N.W. (Lbs) 9800Option: -- Sound enclosure Add ...$10,900

CAM-WOOD TX-P10AAT FRONT LOAD AUTOMATIC PANEL SAW: Shop Saw -- Specifications: 128" (3,250 mm) Max. rip cut cap. & 128" (3,250 mm) max. pull-back front/back; 15 HP (11.45 kW) saw blades motor, 1" dia. arbors,4" (101 mm) max. depth of cut with 355 mm (13.9") dia. blade at 4,500 RPM,160 mm (6.3") scoring blade at 6,000 RPM blade speed. -- Positioning Speed:2 HP Saw carriage drive motor, variable cutting speed from 16 - 98 FPM (5 - 30 MPM), return speed of 98 FPM (30 MPM). -- Pusher Fence: Programmable rear material push fence with servo drive, made of square tubular steel bar;0.5 HP pusher motor, rack & pinion drive, 16 - 49 FPM (5 - 15 MPM) speed. -- Operator & Machine Control:PC Controller with touch-screen to program cutting patterns or individual line cutting operation, graphic displays, self-diagnostics, machine parameter list; touch-screen keypad for data entry. -- Complete with: (3) Bakelite covered front support tables and fully covered rear table; (optional air flotation tables available at additional cost)(4) Dust collector outlets, (1) on each end of the saw base, (1) on the right side at cut-line height, and (1) on the right-hand side on top of the pressure beam. -- Available Options: (1) TX-ATSA AUTO SIDE ALIGNMENT DEVICE = $2,300.00 additional cost; (3) TX-PFT AIR FLOATING TABLES = $3,690.00 additional cost. -- Actual Model is CAM-WOOD TX-P10AAT

CAM-WOOD TX-P12AAT FRONT LOAD AUTOMATIC PANEL SAW: -- Specifications: 149.6" (3,800 mm) Max. rip cut cap. & 149.6" (3,800 mm) max. pull-back front/back; 10 HP (7.45 kW) saw blades motor, 1" dia. arbors,4" (101 mm) max. depth of cut with 355 mm (13.9") dia. blade at 4,500 RPM,160 mm (6.3") scoring blade at 6,000 RPM blade speed. -- Positioning Speed:2 HP Saw carriage drive motor, variable cutting speed from 16 - 98 FPM (5 - 30 MPM), return speed of 98 FPM (30 MPM). -- Pusher Fence: Programmable rear material push fence with servo drive, made of square tubular steel bar.0.5 HP pusher motor, rack & pinion drive, 16 - 49 FPM (5 - 15 MPM) speed. -- Operator & Machine Control:PC Controller with touch-pad to program cutting patterns or individual line cutting operation, graphic displays, self-diagnostics, machine parameter list; touch-screen keypad for data entry. -- Complete with: (3) Bakelite covered front support tables and fully covered rear table; (optional air flotation tables available at additional cost)(4) Dust collector outlets, (1) on each end of the saw base, (1) on the right side at cut-line height, and (1) on the right-hand side on top of the pressure beam. -- Available Options: &#9679 (1) TX-ATSA AUTO SIDE ALIGNMENT DEVICE = $2,300.00 additional cost. &#9679 (3) TX-PFT AIR FLOATING TABLES = $3,690.00 additional cost. -- Actual Model is CAM-WOOD TX-P12AAT

CAM-WOOD TX-P330X FRONT LOAD AUTOMATIC PANEL SAW: "High Production Saw" -- Specifications: 126" (3,200 mm) Max. rip cut cap. & 126" (3,200 mm) max. pull-back front/back; 15 HP (11.2 kW) saw blades motor, 1" dia. arbors,3-1/8" (82.5 mm) max. depth of cut with 355 mm (13.9") dia. blade at 4,500 RPM,180 mm (7") scoring blade at 6,000 RPM blade speed. -- Positioning Speed:2 HP Saw carriage drive motor, variable cutting speed from 16 - 150 FPM (5 - 46 MPM), return speed of 100 FPM (30 MPM). -- Pusher/Gripper Fence: Programmable rear material push/gripper fence with AC servo drive, 1 HP pusher motor, rack & pinion drive, 16 - 80 FPM (5 - 24 MPM) speed. -- Operator & Machine Control:PC Controller with touch-screen to program cutting patterns or individual line cutting operation, graphic displays, self-diagnostics, machine parameter list; touch-screen keypad for data entry. -- Complete with: TX-ATASA automatic side alignment device, (3) Bakelite covered front support tables and fully covered rear table; (optional air flotation tables available at additional cost)(4) Dust collector outlets, (1) on each end of the saw base, (1) on the right side at cut-line height, and (1) on the right-hand side on top of the pressure beam. -- Available Options: &#9679 (3) TX-PFT AIR FLOATING TABLES = $3,690.00 additional cost. &#9679 (1) TX-P3SB THIRD JUMP SCORING UNIT = $4,290.00 additional cost. &#9679 (1) PC BASE CONTROL (Optional with OPTIMIZE SOFTWARE) = $4,890.00

CAM-WOOD TRS-3016 Single Blade Bottom Cut Straight Line Rip Saw 15 HP - 3,600 RPM Direct drive BOTTOM mounted arbor,Specifications: -- 1" Dia. arbor, 10" to 16" max. blade cap., 3-1/4" max. depth of cut, 12" min. length; 19" throat cap., 69" long x 43" wide table. -- Precision-built saw head designed for straight-line rip saw operations.Feed System: -- 2 HP Variable feed motor, 30 - 85 FPM, 8-3/4" Twin chain drive, Automatic chain and lubrication to V-Way track; Top pressure system with roller holddowns. -- Double anti-kickback fingers mounted at the infeed; feed chain with V-way track and chain block surface, heat-treated for long wear resistanceFeatures: -- Hard chrome plated table for maximum wear resistance; precision fence with measuring ruler gauge. -- Saw arbor manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced for precise cutting performance; -- (4) Bearing spindle mount ensuring rigidity & long life; Anti-kick finger, two long rollers, in front of saw blade, 4 x 2 = 8 short rollers at the side of the saw blade, two long rollers at outfeed heavy-duty cast iron table. Complete with: -- Rip fence, push buttons, magnetic starter, and 4" dia. dust outlet. -- Optional Laser Beam Light, please add ...$980.

CAM-WOOD TRS 0012, Straight Line Rip-SawSpecifications: -- Max. cutting depth 3-3/4". -- Arbor Diameter 1". -- Saw Blade Size 8½" - 12". -- Throat to Blade Depth 15". -- Table Dimensions 33" x 59". -- 10 HP Main Motor. -- Spindle Speed 4,500 RPM. -- Feed Motor 1 HP. -- Feed Chain Width 6". -- Feeding Speed 30 - 85 RPM. -- Automatic Lubrication. -- Chip & Dust Collection Hood Diameter 4".Features: -- Cast iron and hard chrome plated table for durability & extended wear. -- Precision machined saw trunnion & fence assure optimal accuracy. -- Measuring ruler gauge for easy & accurate fence adjustments. -- Double anti-kickback fingers mounted at the infeed provide safety protection for the operator. -- Heavy-duty industrial motor for powerful cutting capacity. -- Rugged fabricated durable steel construction for years of use.Feed System: -- Variable speed settings enable the machine to meet different application needs. -- V-way track and chain block surfaces are heat-treated for longer, lasting usage. -- Automatic lubrication to V-Way track allows the chain to operate smoothly. -- (4) Pressure Rollers for accurate cutting of both large and small workpieces.Special Features: -- Saw arbor is manufactured from NI-Cr-MO alloy steel to provide the best durable and anti-fatigue, heat treated, and balanced for a more accurate cut. -- (4) Bearing spindle mount for prolonged life usage.

CAM-WOOD PTX-2513 Entry Door/Window Hydraulic Assembly Press, 4' x 8'. Hydraulically operated. Solidly constructed and welded with great precision.Specifications: -- Working area:1300 mm (51") Max. width; 2500 mm (98") max. length. -- (2) Vertical cylinders, each of stroke 80 x 600st; (2) side cylinders, each of stroke 50 x 800st. -- Comes with: 2 HP hydraulic pump motor. -- Outer structure is made of two vertical beams which are individually located at the upper and the bottom side of the machine. The horizontal beams have vertical hydraulic cylinders thereby moving beams up and down to distribute the pressure evenly on the workpiece. The overhead push button operates the hydraulic motor. -- Stops (square blocks) are moved manually to set to the desired position. The mobile pressing platen of the square block and the horizontal upper beam can be moved by the vertical hydraulic cylinder. -- Equipped with: A pressure gauge and pressure control valve to regulate the vertical and horizontal hydraulic cylinders for precise, desired working pressure. -- Overall Dimensions/eight: 3000 x 1200 x 2200 mm (120 x 48 x 87"). Weight: 1200 Kg (2650 Lbs).NOTE: Also available in 5' x 10' Press for ...$26,500.

CAM-WOOD - EX-ARES ...CNC Door Processing Machine Center for Pre-Hung Doors with Automatic Tool Changer. Distinctive design for Door Pre-Hang Processing. -- All the 5-side Project Processing -- Automatic Feed Through (Options with Auto Loading and Out-Feeding) -- Hinge Face Milling, Screw Hole Drilling -- Lock Bore Drilling -- Latch Face Milling, Latch Bore Drilling. FEATURES: -- DSP CNC controller is setup to accept standard G-code programming formats along with on board conversational applications. -- Optional CAD/CAM system can create and edit part programs then send to machine for easy cutting. DXF files can imported, modified, and edited from here to create a G-code. -- Horizontal and vertical spindle for top and side stock processing -- Machine designed ready for 3-D cutting usage and superior performance. -- Moving gantry construction for space saving. -- The rigid steel frame construction has been stressed relieved prior to finish machining to provide repeatability and accuracy. --Automatic frequency brake for the spindle allows rapid deceleration resulting in faster tool changes. -- Linear guides and sliding blocks are prismatic pre-loaded with recirculation bearings to ensure maximum rapid traverse and precision. -- The X & Y axis equipped with a precision rack & pinion driving system. The Z axis utilizes a ball screw assembly complete with the pre-loaded and ground screw for long life and optimum accuracy.SPECIFICATIONS: -- Working size 51"; Width x 98"; Length x 7-7/8"; Height (Door Lock Maximum Depth 4-3/4";) -- Custom made door vacuum table (Optional Vacuum Pump) -- SYNTEC 60WA control with All in one PC Controller -- 9.0KW air cooling Spindle with 4 pcs ISO30 tools linear ATC for Top Side Milling, Drilling, Lock, Bore.. Processing -- 6.0KW double Side milling Spindle at X direction for X Axis Two Side, Milling, Drilling, Ball Catch, Split Line. Processing -- 6.0KW double milling spindle at Y direction, Two Side, Milling, Drilling, Hinge, Latch Hole, Face, Dead Ball, Processing -- 2.2KW 4 Side Milling Spindle for All the 4 Side, Small Holes, or Screw Hole Drilling process -- 1500W servo drive. -- Max travel speed 200 FPM (60m/min), Max working speed 50 fpm (15m/min) (According different processing material) -- Professional PTP table with German SCHMALZ Vacuum pads 6pcs -- 2M helical rack, 30 square rails & Ball screw -- Automatic control with Aluminum oil pipe Oil lubrication.OPTIONS: -- 10' table capacity ...............$US3,100. -- ARES Options for 3 Degrees Bevel.A.) Pre-set the Angle heads point to left or right side at tool rack. HSD Angle Head $US8,990.00 each (most time, it will need at least two units, preset to 3 degrees, one bigger cutter for routing, one small cutter to do re-fine the latch corner or drill the screw holes).B.) Upgrade to Italy HSD C Axis System add $US23,990.00. (Horizontal 360 Degrees turning, it can work on all the 4 door edges). Plus, HSD Angle Head $8,990.00 each (most time, it will need at least

CAM-WOOD CM3636NA-BX Box / Drawer PinnerBox Nailing Assembler is designed to automatically nail / fasten 4 or 5 pcs with bottom, PB, MDF, solid wood boxes or draw togetherFeatures: Complete cycle to square, clamp and nail / fastens different size and style boxes or drawing, maximum 36"; x 36";. -- Fast and easy operation, 600 to 1,100 units per shift.. -- High Quality and safe processing, automatically senses the materiel and automatic nailing at settled pitch. -- Automatic shutting staples from top to bottom by detecting sensor. -- Clamps from both width & length direction with adjustable clamp pressure for differentthickness or material. Specifications: -- Maximum working capacity 36"; L x 36" W. -- Minimum working capacity 7" L x 7"; W. -- Maximum working height 10", minimum working height 3";. -- Panel thickness 5/8"; tor 3/4". -- Building frame 0 to5 degrees tilted to back side. -- Standard staple gun Senco SNTSLS20 x 4 units (other guns will be optional). -- Staple size 1-1/4"; length, ¼"; crown. -- Automatic shutting staples space distance 1"; (adjustable pitch by 1";). -- Minimum pneumatic required 90 psiOther sizes available with special order.

CAM-WOOD AC-7580 Piston Air CompressorCompact unit with a 7.5 HP induction motor.Features & Specifications: -- 22 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 80-Gal. vertical tank that meets ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD AC-5080 Piston Air CompressorCompact unit with a 5 HP induction motor.Features & Specifications: -- 18 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 80-Gal. vertical tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD AC-100120 Piston Air CompressorHeavy Duty unit with a 10 HP induction motor.Features & Specifications: -- 34.2 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 120-Gal. horizontal tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD SET-402TS-N Double End NotcherDouble end notchine machine for pallet componentsSpecifications: -- Working Length: 24" to 49" -- Working Thickness: 3/4" to 4" -- Pneumatic Hold Down x 4 units (2 sets at Top & 2 set at Bottom) -- Notch Cutter Speed 6,000 rpm -- Notch Cutter Stroke 4" -- Notch Cutter Diameter 1-1/4" -- Notch Cutter Motor 5 HP x 2 -- Feeding Hydraulic Motor 1 HP -- Linear servo drive feeding rails system -- Cycle time 4 to 7 second per piece -- Dust Hood 4" x 2

CAM-WOOD WP-4 S2C-500-12 4-SIDED PLANEROutstanding Performance - Quality Components 4 sided with 6 heads as: top and bottom, left and right, (2) chamfer units -- Floating bottom infeed rolls for smooth, positive feeding -- PLC controls with touch-screen interface for ease of operation -- Variable feed speeds by VFD. Controlled from touch screen -- Drive shaft and universal joint feed roll transmission for each feed roll -- Power elevation of overhead mechanism via touch screen control -- Thickness settings from touch screen control -- With cutterheads and carbide knives for straight knife work -- With spindles for easing top edges -- Tables, fences, etc. are precision ground and hard chromed to provide long life and smooth feeding -- Overhead mechanism travels up/down and is support by (6) hard chromed posts -- Motor Control Center with under voltage and overload protection; includes UL and CSA approved electrical componentsWorking Capacities: -- 19 3/4" wide x 12"; high (500 mm X 305 mm) -- Min. thickness: 3/4"; -- Min. width 2-3/4"; -- Max. depth of cut: 1/4"; all heads -- Max. length: Unlimited -- Min. length: 70"; for feed-thru; butt-feed down to 40". (40"; to 70"; may have minor inaccuracies at edge due the hold-down restrictions) -- Feed speeds from 20 to 66 FPMCutterhead Motors: -- 25 HP Top and Bottom (see optional equipment for larger motors) -- 20 HP Right & Left Side Heads (see optional equipment for larger motors) -- Includes Right & Left Spindles for eased edge at top of board; consists of (2) 1 HP floating spindles to accurately ease top edges. Profile knives in primary side heads ease bottom edges. -- Chamfer motor 1/2 HP Feed Works: -- (2) 5 HP VFD’s -- (1) motor drives top set and (1) motor drives the bottom set of feed rolls -- Boards synchronize top and bottom feed roll speed and torque --Cutterheads and Spindles: -- Top and bottom spindles with 60mm (2.362";) spindle dia. Other diameters on request. -- Includes a set of (2) 4-knife x 20"; long x 5-1/2"; dia. spiral carbide cutterheads. -- Side heads with 40mm spindle dia. Other diameters on request -- Includes a set of (2) 4-knife x 12"; long spiral carbide heads -- Includes (1) set per head: 15 x 15 x 3mm carbide knives with (4) cutting edges -- All spindles with hydro-lock outboard bearings -- Left & Right Side Heads can be used for profile work with owner provided tooling -- Eased Edge Spindles: 30mm"; dia. -- Eased Edge Cutting Circle: 4.9"; -- Powered side pressure device at infeed Dust hoods: -- 6"; dia top and bottom head hoods; 6"; dia. side head hoodsOptional Equipment: -- Optional HP on Top & Bottom Heads, up to 40 HP, -- Optional HP on Right & Left, up to 30 HP, -- Electric Brakes for side spindles, -- Power raise/lower and auto-setting for side spindles, Machine Dimensions and Weight: -- 110" long x 86" wide x 94" high x 15200 Lbs.

CAM-WOOD SM-156A Feed Through Moulder;6-Head (B-R-L-T-T-B), working cap. 6" x 4".Specifications: -- Head sequence: Bottom 5 HP, right 4 HP, left 4 HP, top 10 top, top 5 HP and bottom 5 HP motor. -- Spindle diameter 40 mm with cutterhead speed of 6,000 RPM; spindles equipped with mechanical readouts for axial and radial adjustments. -- 4 HP Feed Motor variable speed 16- 65 FPM; carden drive system. -- 1.2 M (4'0") Infeed table with lateral side pressure roller mounted at table infeed. Manual table lubrication pump. -- Dust collection Min. 3,500 CFM -- Air requirement 90 psi. -- 150 AMPs. at 220 V. -- Machine dimensions , length & width 137"; long, x 54"; Width x 68"; High
