HOLZ-HER CUT 85 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications:4,250 mm (167") Max. rip cut cap., 3,800 mm (149") pull back pusher stroke; 97 mm (3.8") saw blade projection.15 HP (11 kW) Main saw motor, 3 HP (2.2 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 328 FPM (1 - 100 MPM ), return speed of 328 FPM (100 MPM).Automatic cutting length limiter adjusts the cutting length at the end of the workpiece, automatic saw carriage lubrication. -- Pusher Fence:(7) Material gripper clamps; 259 FPM (80 MPM) forward positioning speed, 259 FPM (80 MPM) return speed.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with CUTCONTROL "Direct Cut" + "OPTIPRO" + Windows 2000 operating system,15" TFT Display with unlimited program storage via floppy disk, keypad for data entry, USB & RS-232 serial port, CD ROM & 1.44 MB disk drive for additional storage of programs.CUTCONTROL offers Real-Time Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."Direct Cut" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials."OPTIPRO" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting. -- Complete with: Rear roller support rails; automatic crosscut side aligner; automatic saw blade height adjustment.(3) Air support tables, ea. 78" x 24" (1,981 x 509 mm). -- Actual Model is HOLZ-HER CUT 85 4300.

HOLZ-HER CUT 6120 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications: 3,900 mm (153.5") Max. rip cut cap., 3,900 mm (153.5") pull back pusher stroke; 82 mm (3.2") saw blade projection.15 HP (11 kW) Main saw motor, 1.5 HP (1.1 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 320 FPM (1 - 100 MPM ), return speed of 416 FPM (130 MPM).Motorized bi-directional grooving capabilities with electronic adjustment for 0 mm - 35 mm.Automatic cutting length limiter adjusts the cutting height & cutting length at the end of the workpiece. -- Pusher Fence:(7) Material gripper clamps, (1) Double Finger mounted at the cross-cut fence location for narrow strip cutting & (6) standard clamps. 82 FPM (25 MPM) forward positioning speed, 328 FPM (100 MPM) return speed.Variable pressure settings for delicate materials. Pressure beam has an integrated "Last Cut" operation to achieve a "0" mm panel dimension.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with "CUTCONTROL 2" + "EASY-PLAN" + Windows operating system,19" TFT Display with unlimited program storage; keypad for data entry, USB & RS-232 serial port, "CUTCONTROL 2" offers Real-Time 3D Moving Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."CUTCONTROL 2" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials."Opti-Cut" & "EASY-PLAN" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting -- Complete with: Non-Marking rear roller support rails: Solid Air Cushion Table before & after the cutting line, ensures easy panel handling. Pneumatic crosscut side aligner, adjustable from 0" - 82.6" (0 - 2,100 mm). Side aligner is "Fully Automatic" adjustment when panel is less than 1,300 mm (51")"Quick Change" Blade system with automatic saw blade height adjustment; Electronic positioning of the scoring blade through the NC control.(3) Adjustable via "pneumatic locking" air support tables, ea. 70.8" x 23.6" (1,800 x 600 mm); -- Actual Model is HOLZ-HER CUT 6120 Dynamic

HOLZ-HER - 1619, ...Boring Machine (Construction & Line Boring) -- Specifications:(19) Spindles on 32 mm centers; bores vertically from top and horizontally from the rear; repositions via manual air shock assisted tilting.2 HP Motor with: 2,800 RPM Gear driven boring head. -- Features:4-Position turret style depth stop for boring depth and a 4-3/4" max. stroke of boring head.24-3/4" Working width; 27-1/8" max. panel width; 19-1/2"; x 38"; x 32-1/2"; H table size. -- Equipped & Complete with:RH & LH Indexing fence with flip stops; (2) indexing pins (for continuous line boring); (3) 4" dia. pneumatic holddown clamps; foot pedal actuator; magnetic push button starter. -- Actual Model is: HOLZ-HER 1619Dimensions of this specific machine with pallet: 52" x 40" x 65" H.Dimensions of this specific machine when vertical: 52" x 37" x 60" H.Dimensions of this specific machine when horizontal: 52" x 51" x 46" H.

HOLZ-HER 1402 HF Compact EdgebanderFeatures: -- Cartridge glue system, 3 mm edge thickness cap., -- Semi-automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock is fed manually with pusher bar to advance the edging. Digital glue height indicator.Workstations: -- Double motor end trim (1 HP - 10,500 RPM motor ea.) -- Universal top & bottom fine trim (1942M) for bevels from 0° - 15³; allows simultaneous bevel & profile trimming (1 HP - 18,000 RPM motor ea.; trim motors are 0.6 kW HF - 300 Cy). -- Top & bottom PVC scraper unit (1929) for 0.8 - 3 mm radius. -- Top & bottom buffing (1940), 0.3 HP - 1,620 RPM motor ea. -- Single feed speed of 35 FPM. -- Complete with: Fixed outboard panel support, frequency converter, sound enclosure, and used tooling.

HOLZ-HER 1435-SE EDGEBANDERCartridge glue system, 5 mm edge thickness cap. (up to 8 mm w/optional tooling), automatic magazine coil & strips, 3 mm PVC cap. pneumatic guillotine for coil cutoff.Workstations: -- Double motor end trim (2) 0.3 HP - 9,000 RPM motor ea.), chamfers 0° - 10° -- Universal top & bottom fine trim (for bevels from 0° - 15°) allows simultaneous bevel & profile trimming, (2) 0.8 HP - 18,000 RPM motor each; all trim motors are 0.6 kW HF - 300 Cy. -- Top & bottom PVC scraper unit for 0.8 - 5 mm radius, with air jets for blowoff. -- Top & bottom "jump" buffing (0.3 HP - 1,620 RPM ea.). -- Single feed speed 35 FPM. --Complete with: --Built-in operator control panel, outboard panel support, frequency converter, used tooling, and sound enclosure.

HOLZ-HER - 1432, ...CP/B Edgebander (Compact) -- Cartridge glue system (single cartridge system); edge thickness cap.: 0.3 to 3 mm (1/8"); max. banding height: 2"; min. panel width: 60 mm; min. length: 180 mm.Equipped with: -- Semiautomatic feed magazine; coil stock feeds automatically with guillotine cutoff; all strip stock is fed manually with pusher bar to advance the edging.Workstations: -- Single motor end trim for leading & trailing edge (trim motor recently replaced). -- Top & bottom flush/bevel trim: 1 HP - 28,000 RPM Motor ea. (recently replaced with BOSCH Trimmer motors). -- Top & Bottom buffing unit: 0.3 HP - 1,620 RPM ea. motor; equipped with: Cotton flap wheels. -- Single feed speed: 16-1/2 FPM.Complete with: -- Sound/safety enclosure; outboard panel support. - Machine is on casters.

HOLZ-HER - 1435-SE EDGEBANDER"1906" Cartridge Glue System; 5 mm edge thickness cap. (up to 8 mm w/optional tooling); automatic magazine coil & strips; 3 mm PVC cap. pneumatic guillotine for coil cutoff. Workstations: -- Double-motor end trim, (2) 0.3 HP - 9,000 RPM motor ea.; chamfers 0° - 10°. -- Universal top & bottom fine trim (for bevels from 0° - 15°); allows simultaneous bevel & profile trimming; (2) 0.8 HP - 18,000 RPM motor ea.; all trim motors are 0.6 kW HF - 300 Cy. -- Top & Bottom PVC scraper unit for 0.8 - 5 mm radius; air jets for blowoff. -- Top & Bottom "jump" buffing (0.3 HP - 1,620 RPM ea.). -- Single feed speed: 35 FPM.Complete with: Built-in Operator Control Panel; outboard panel support; frequency converter; used tooling; and sound enclosure.

HOLZ-HER 1402 HF Compact EdgebanderFeatures: -- Cartridge glue system, 3 mm edge thickness cap., -- Semi-automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock is fed manually with pusher bar to advance the edging.Digital glue height indicator.Workstations: -- Double motor end trim (1 HP - 10,500 RPM motor ea.) -- Universal top & bottom fine trim (1942M) for bevels from 0° - 15³; allows simultaneous bevel & profile trimming (1 HP - 18,000 RPM motor ea.; trim motors are 0.6 kW HF - 300 Cy). -- Top & bottom PVC scraper unit (1929) for 0.8 - 3 mm radius. -- Top & bottom buffing (1940), 0.3 HP - 1,620 RPM motor ea. -- Single feed speed of 35 FPM.Complete with: -- Fixed outboard panel support, frequency converter, sound enclosure, and used tooling.

HOLZ-HER PRO-MASTER 7122 K 4X CNC MACHINING CENTER (W/ATC/BORING/"C" AXIS): -- Specifications: Working capacity: "X" Axis 142" (3,607 mm); "Y" axis is 59" (1,500 mm); "Z" axis stroke is 22.2" (565 mm); max. material thickness: 8.26" (210 mm) from the top of the vacuum pod. -- Positioning Speed: "X" Axis is 393 FPM (120 MPM); "Y" axis is 328 FPM (100 MPM), "Z" axis 82 FPM (25 MPM)."X" Axis travel on high precision prismatic STAR guides & ground helical rack; "Y" & "Z" axes travel via hardened ground ball screw. -- Worktable:(6) Support rails, (2) adjustable vacuum pods per rail.Laser positioning system for quick positioning of pods and with value input from Controller according to part size and machining required.(6) Pneumatic pin stops located in the rear of the machine; (6) pneumatic pin stops located in the front of the machine.(2) Side stops & (2) central stops for mirror imaging; (2) independent working areas.Stops can be fitted with "quick fit" mushroom clamps for clamping of small or awkward shaped parts. -- Boring Head:4 HP (3 kW) Motor; variable spindle speed from 1,000 - 6,800 RPM; (18) independent vertical boring spindles with: (12) Spindles in "X" axis & (6) spindles in "Y" axis.(6) Horizontal spindles with: (2+2) in "X" Axis & (1+1) in the "Y" axis.(1) "X" Axis grooving saw for max 120 mm dia. blade. The boring head is arranged to accommodate (2) operating units. -- Machining Units:(1) 13 HP (9.7 kW) Vertically mounted liquid cooled electro-spindle with: HSK 63F Adaptor; inverter driven 1,000 - 24,000 RPM with max. torque from 12,000 - 24,000 RPM.(1) NC Controlled "C" axis for 360° horizontal processing.(1) 18-Position ride-along rotary tool changer plate for "on the fly" ATC.Max. tool dia. 85 mm (if fully loaded) or 200 mm (with free spaces). -- Operator & Machine Control: SIEMENS PC Front-End + "CAMPUS" + Windows "7" operating system with 3D simulation.15" Color monitor; standard PC Keyboard & mouse; CD-ROM drive. - Card ports: (1) AGP, (1) PCI, and (1) ISA; (2) serial ports & (2) parallel ports; (2) PS/2 ports & (4) USB ports; (2) PCI Bus-Master IDE ports; (3) Com 905B-Combo fast Ethernet cards.Hand-held pendant for remote control start/stop of working cycle, speed control, reset function, etc."CAMPUS" is user-friendly CNC software with office and machine license; extensive 3D simulation module as standard feature; integrated CAD module and versatile macros for easy programming. -- Complete with:(1) 100 cbm/Hr Vacuum Pump; tool length "Touch-Off" Probe; emergency stop rope & pressure sensitive safety mats that will instantly place machine in "pause cycle" when stepped on.Sound absorbing protective head enclosure with debris curtain around bottom edge. -- Actual Model is: HOLZ-HER - PRO-MASTER 7122 K 4X.

HOLZ-HER 1329 SPRINT PREMIUM EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) & Features the HOLZ-HER Patented Dual "GLU-JET" EVA & PUR Zero Joint Technology System; Specifications: -- Edgebanding Capacity: edge thickness min./max. 0.4 - 15 mm (0.016 - 0.59"), coiled material 0.4 - 3 mm (0.016 - 0.157"); Panel thickness 8 - 60 mm (0.236 - 2.362"), workpiece width min. of 60 mm (2.36"); workpiece length min. 160 mm (6.29"); Feed speed 10 - 18 MPM (33 - 59 FPM). -- Programmable Logic Control (PLC) for Pre-Milling, edge feed, glue application, end trimming, flush trimming, radius trimming, scraping, corner rounding, and buffing. -- Holz-Her PPC 315 "EDGE CONTROL TOUCH" Electronically controlled set-up processes with 100% repetition accuracy. 18.5" Flat Touch Screen with Brilliant graphic display of machining process. Simple operation – rotating and swiveling control panel at eye height.,Programs can be easily created and recalled at will; Graphic interface makes programming easy,Icon of each unit may be brought up on the screen to show the operator the status of the unit and the parameters which can be programmed;Edgebander can be operated manually when required, without necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station : (2) 2.0 KW (2.68 HP) - 12,000 RPM motors; Equipped with "ProLock" quick-change flange including height adjustment for optimum utilization of cutters. -- Edge Feeder Magazine: "SYNCRO" drive. The new magazine with its synchronous adaptation to the feed rate guarantees short intervals between work pieces & simultaneously optimizes edging protrusions. Small 3° feed angle thanks to nozzle design with easy feeding of coils, strips &up to 3 mm & solid wood edging up to 15 mm (.059"). Exclusive "Tractor-Belt feed System", edge guide equipped with automatic guillotine lock-out for safety, -- Pressure Section: Servo controlled pressure section with (1) large driven roller and (2) cantered idle rollers. Straight and tapered pressure rollers for perfect glued joints -- GLUING SYSTEM: "GUL Jet" thin film technology processes "EVA" or "PUR" Glue in Cartridge of Granulate Form, motorized, programmable glue nozzle (upper glue line) height positioning.Workstations: -- End Trimming Unit (1918-P): Front & rear 2 x 0.35 KW (0.5 HP) - 9,000 RPM motor each, uni-point swivel-axis for no re-indexing when changing from flush to bevel end trim (0° - 10° bevel),"PCS" programmable pneumatic change-over from flush to bevel. -- Multi-function Trimming Unit (1826 ): Servo controlled, 2 @ servo motors (1) for horizontal copy wheel & (1) for tool spindle position) programmable top & bottom unit 2 x 0.65 KW (0.87 HP) - 12,000 RPM each motor. Uni-Point design with no second adjustment, pneumatic, programmable tilt action for changing the degree of bevel, digital counters for vertical copy wheel position and pneumatic air cylinder for in/out pre-positioning of trimming motor. -- Trimming & Corner Rounding Unit (1833 MOT4): For linea

HOLZ-HER ARCUS 1335 EDGEBANDER (W/PRE-MILLING): -- Specifications: Edgebanding Cap. Edge thickness min./max. 0.4 - 15 mm (0.016 - 0.59"); coiled material 0.4 - 3 mm (0.016 - 0.157"); panel thickness 6 - 60 mm (0.236 - 2.362").Workpiece width min. of 60 mm (2.36"); workpiece length min. 160 mm (6.29"); variable feed speed from 10 - 18 MPM (33 - 59 FPM).Machine Infeed Configuration: -- Pre-milling Station: (2) 2.0 kW (2.68 HP) - 12,000 RPM motors; equipped with "ProLock" quick-change flange including height adjustment for optimum utilization of cutters. -- Edge Feeder Magazine: Small 3° feed angle thanks to nozzle design with easy feeding of coils; strips up to 3 mm & solid wood edging up to 15 mm (5/8"). Exclusive "Tractor-Belt Feed System": Edge guide equipped with automatic guillotine lockout for safety. -- 3 mm Guillotine: For up to 3 mm coiled & strip materials. -- Gluing Section: HOLZ-HER patented cartridge puck system with unrivaled properties with 95% less energy consumption & 70% shorter heat up time of 205° Celsius in just 3-1/2 minutes.Changing glue types takes just a minute and no special tools are required for glue and color. All that is changed is the cartridge. The time-consuming cleaning procedure of the glue pot, previously essential, is no longer necessary. The patented HOLZ-HER Cartridge System is a practical solution. -- Pressure Section (1) large & (3) cantered driven pressure rollers for perfect glued joints.Workstations: -- Front & Rear End Trimming: 2 x 0.35 kW (0.5 HP) - 9,000 RPM each motor for edge thicknesses up to 20 mm. -- Multifunction Top & Bottom Trimming Unit: Manual adjustment 2 x 0.65 kW (0.87 HP) - 12,000 each motor.Digital counters for vertical copy wheel position and pneumatic air cylinder for manual in/out pre-positioning of trimming motor. -- Top & Bottom Fine Trimming Unit: Manual Adjustment, 2 x 0.65 kW (0.87 HP) - 12,000 each motor.Digital counters for vertical copy wheel position and pneumatic air cylinder for manual positioning of fine trimming motors. -- Top & Bottom Profile Scraping Unit: For PVC edges.Reversible insert carbide knives. -- Top & Bottom Glue Scraping Unit: Flat, top/bottom, ball bearing guided. -- Top & Bottom Buffing Station: Top & bottom buffing motors with 150 mm ( 6.0") cloth buffing wheel diameter, 1,440 RPM wheel rotation.Operator Interface: -- HOLZ-HER "Edge Control" Electronically controlled set-up processes with ...100% repetition accuracy.Flat Screen 8.4" VGA Color Monitor: Dustproof soft key input panel surface; programs can be easily created and recalled at will; graphic interface makes programming easy.Icon of each unit may be brought up on the screen to show the Operator the status of the unit and the parameters that can be programmed; Edgebander can be operated manually when required, without the necessity to write a program. Programmable Logic Control (PLC) for Pre-milling: Edge feed, glue application, end trimming, flush trimming, radius trimming, scrapi

HOLZ-HER 1516 CASE CLAMP (SINGLE-BAY): -- Specifications:1-Bay Clamp, 100" x 50" x 24" clamping cap.; (1) movable, vertically positioned clamping beam with (3) horizontal clamps, (4) adjustable vertical clamps. -- Total of (14) pressure cylinders with 3-7/8" stroke & (4) adjustable counter-pressure bars; 700 Lbs/cylinder pressure at 100 PSI compressed air; built-in controls with pressure gauge.

HOLZMA HPP-11-32 OPTIMAT FRONT LOAD PANEL SAW:Specifications & features: 3,200 mm (126") Cutting length & pull-back behind the cutting line; 125 mm (4.9") saw blade projection; 30 HP (22.3 kW) main & 3 HP (2.2 kW) scoring motor. -- Variable saw carriage travel speed from 0 - 410 FPM (0 - 125 MPM), constant return of 410 FPM (125 MPM). -- Equipped with: Main blade 18" (450 mm) dia. and scoring blade 8" (200 mm dia.). -- Electronically controlled overhead pusher fence, rack & pinion drive on both sides by AC Servo motor; forward speed from 0 - 262 FPM (0 - 80 MPM), return speed of 262 FPM (80 MPM); equipped with (8) gripper clamps (open up to 4.7"). -- HOLZMA CADmatic Operating system; 15" color monitor (displays cutting dimensions); data input by keyboard or 1.44 MB floppy disk drive & downloading from office PC is possible. -- Control panel mounted on double swiveling arm for ergonomic positioning by the operator. -- Includes: Combi-rollers rear machine table with profile rails, rollers spaced at 50 mm centers; front with (3) air floatation tables, 85" x 26" (2,159 x 660 mm) each. -- Complete with: Angular square fence, automatic side aligner for crosscutting, (2) aligning devices on program fence; "Quick Saw Changing System" for main & scoring blade.

HOLZMA PROFIMAT HPL 500 38/16 REAR LOAD, AUTOMATIC PANEL SAW: -- Specifications: 149.6" (3,800 mm) Cutting length & pull-back; 6.7" (170 mm) max. main blade projection; 40 HP (29.8 kW) Main & 3 HP (2.2 kW) scoring motor. -- Saw carriage: Infinitely variable speed from 0 - 492 FPM (0 - 150 MPM), constant return of 492 FPM (150 MPM).Carriage is electronically & automatically controlled (cutting height & length) through the CADmatic according to the material/program being processed."Power-Loc" quick change system for fast and easy saw blade change.NC Controlled scoring saw adjustment from the control panel during operation -- Pusher Fence:Rack & pinion digital drives with AC Servos on both sides, forward speed 295 FPM (90 MPM), return speed 295 FPM (90 MPM).(7) Material clamps which open up to 6.7" (170 mm): (3) Standard clamps with two fingers & (4) clamps with one finger.(4) Trimming rakes for thin strips/scrap removal are attached at the clamps. -- Operator Interface:HOLZMA "Power Touch Control" IPC multi-tasking controller with Windows "7 PRO" + "CADmatic 4.0 PRACTIVE" operating system;Intel i5 Dual-core Processor, Intel HD graphics card, 4GB RAM, SATA 2-250GB hard drive, (6) USB ports, (1) serial port, ATI/DVI video port, Standard industrial keyboard connection,21.5" LCD "Touch-Screen" monitor with real-time moving 2D & 3D graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.(2) Ethernet 10/100 interface connections; downloading from office PC is possible. -- Rear of machine: Profile rails & "Combi-rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent off-set panels within the same book. -- Front of machine: (3) Air flotation tables 85" x 31.5" (2,160 x 800 mm) with (1) central blower unit. -- Rear Lift Table:7-Ton (14,000 LBS), 4-Column electro-hydraulic powered rear lift table running lengthwise with fork cut-outs, 150" x 63" (3,800 x 1,600 mm) capacity. Powered rollers are 4.2" (107 mm) dia x 7.79" (198 mm) spacing, 39 FPM (12 MPM) infeed/outfeed speed; Feeding material from (3) sides is possible with additional roller conveyors.22" (560 mm) Max. bunk height from floor level; 30.7" (780 mm) max. bunk height with a pit or risers; -- Complete With: Holzma's Unique "EcoPlus" System offers energy savings up to 20%; Includes Standby button & IE3 energy efficiency Motors rating.Angular cross-cut fence; Automatic side pressure device integrated into the saw carriage for cross-cutting, the machine cuts left to right to the cross-cut fence.Front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed.Min. side aligning dimension 0" (0 mm), max. side aligning dimension 149" (3,800 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Options Include: (1) Non-Powered in/out-feed staging conveyor with fork cut-outs as pictured. Micro In-feed for thin an

HOLZMA HPL 380 43/16 REAR LOAD, AUTOMATIC PANEL SAW: -- Specifications: 169.2" (4,300 mm) Cutting length, 3.7" (95 mm) max. main blade projection, 28 HP (20.8 kW) main & 3 HP (2.2 kW) scoring motor. -- Saw carriage: Variable speed from 16 - 426 FPM (5 - 130 MPM), constant return of 426 FPM (130 MPM); electronically & automatically controlled through the CADmatic according to the material/program being processed. -- Pusher fence;Rack & pinion drive on both sides, forward speed 82 - 262 FPM (25 - 80 MPM), forward speed is currently set at 0 - 82 FPM (0 - 25 MPM) per CE standards, return speed 262 FPM (80 MPM).(6) Material clamps which open up to 3.9" (100 mm); first (2) clamps with two fingers and the others with one finger. -- Operator & Machine Control:HOLZMA "Power Control 22" IPC multi-tasking controller with "Windows XP" + "CADmatic 4.0" operating system;17" TFT Flat-Screen display/monitor with real-time moving graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.Standard industrial keyboard; CD ROM & 1.44MB floppy drives; possible direct downloading from office PC through RS 232 or USB connection. -- Rear of machine: Profile rails & "Combi-rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent off-set panels within the same book. -- Front of machine: (4) Air flotation tables 85" x 25.5" (2,160 x 650 mm), (1) central blower unit. -- Rear Lift Table:Automatic 4-column electro-hydraulic rear load lift table; 169.2" x 62.9" (4,300 x 1,600 mm) capacity; 4.2" dia powered rollers, 39 FPM (12 MPM) infeed/outfeed speed;22.8" (580 mm) max. bunk height without pit or risers, 30.7" (780 mm) max. bunk height with a pit or risers; 8,800 Lbs (4,000 kG) lift capacity. -- Complete With:Angular cross-cut fence; side pressure device for cross-cutting with front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed; min. side aligning dimension 0" (0 mm), max. side aligning dimension 169.2" (4,300 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Actual model is HOLZMA Optimat HPL 380-43/16.

HOLZMA HPP 250 Front Load Automatic Panel Saw: Specifications: -- 149.6" (3,800 mm) Cutting length & pull-back; 2.8" (72 mm) saw blade projection -- 10 HP (7.5 kW) - 4,700 RPM Main saw motor, 350 mm main saw dia; -- 1.5 HP (1.1 kW) - 5,100 RPM scoring motors, 200 mm scoring saw dia.; NC controlled scoring saw adjustment from "CADMATIC" controlSaw carriage: Variable travel speed from 16 - 262 FPM (5 - 80 MPM), constant return of 262 FPM (80 MPM).Pusher Fence: -- Electronically controlled overhead program fence, rack & pinion driven on both sides; forward speed capacity from 0 - 197 FPM (0 - 60 MPM).Operator & Machine Control: -- PC Front-End with: HOLZMA "CADMATIC 3" Power

HOMAG SAWTEQ B-400 PROFILINE 32/32 FRONT LOAD AUTOMATIC PANEL SAW: -- Specifications:Working Capacity: 122'' (3,100 mm) Rip cutting capacity; 122'' (3,100 mm) Pull back capacity. Main saw blade projection 4.3'' (110 mm) 25 HP (18.6 kW) Main saw blade & 3 HP (2.2 kW) "Post Forming" (Jump) scoring blade; Scoring saw adjustment via "CADmatic" control. -- Saw CarriageForward speed 0 - 492 FPM (0 - 150 MPM) Saw carriage reverse speed 0 - 492 FPM (0 - 150 MPM). -- Pusher Fence:Electronically controlled overhead program fence with (9) 2-finger gripper clamps; clamps open up to 110 mm (4.3").Rack & Pinion drive on both sides, forward speed up to 296 FPM (90 MPM), return speed of 296 FPM (90 MPM). -- Operator & Machine Control:HOMAG "powerTouch2" PC Front-End with "CADmatic 5.0" Operating System "designed for industrial environments"; virtually unlimited cutting dimensions memory.21" Full HD widescreen "Touch-Screen" monitor with multi-touch display, online operation from an office PC is possible. All mounted into dust sealed, air-conditioned control cabinet."Real-Time" Cutting sequences with a new 3D assistance graphic supports the operator and is intuitive to operate, which shortens the training period and reduces errors to a minimum. This results in efficient processes and steady output.Simple handling via tapping and swiping (touch functions) with Quick change between the individual sectionsCADmatic 5.0 is Tapio compatible & open for communication with other machines and software solutions.The SAWTEQ B-400 "IntelliDivide" optimizing software is Tapio-ready from installed software or directly from the tapio cloud, allowing "IntelliDivide" to recognize the machine configuration of your saw and consider it for every optimization run in the cloud, completely automatically & you have the choice -- Complete with:On-Board Optimizer; Automatic "CENTRIC" side aligner with front & rear forks holding ripped strips squarely against the right-angle fence.Max. Side aligner stroke 122'' (3,100mm): Rear support rails with non-marking roller modules.(3) Front air flotation tables 74" x 26 (1,879 mm x 660 mm). -- Options Include:(1) American M-1202-30, 6,000 Lbs. scissor-lift, as pictured. -- Actual model is HOMAG SAWTEQ B-400 PROFILINE 32/32 US Addition.

HOMAG OPTIMAT BAK 41/45/G FLAT TABLE MACHINE (W/EDGEBANDING): -- Specifications:Working capacity "X" Axis 177" (4,500 mm), "Y" axis 48" (1,220 mm), "Z" axis stroke is 7.8" (200 mm), max material thickness 2.3" (60 mm). -- Positioning Speed"X" & "Y" Axis 197 FPM (60 MPM), "Z" axis 98 FPM (30 MPM)AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Work Table:Phenolic Flat-Table design with (14) double side "pick-n-place" vacuum pods;Laser aided positioning of the vacuum pods according to the selected program -- Edge Banding unit:Floating "hot melt" glue pot & application roller with separate thermostats apply glue on the panel edge. Pneumatically controlled pressure roller with manually adjustable guides for coil & strip feeding; numerically controlled with encoder that measures strip feeding process; preheated tape magazine with warning sensor when the end of the spool is near. Pneumatically activated saw blade performs the end trimming for precise fitting of overlapping joints on adjoining edges. Precisely applies 0.4 - 3 mm ABS, 1 - 3 mm PVC & 0.4 - 2 veneer with 45 mm max. edge height (65 mm without edging). Minimum internal radius 300 mm (11.8"), Minimum external radius 8 mm (0.3"), both depending on the banding material & thickness when edge banding.The edgebanding is automatically applied to square or irregularly shaped parts as the CNC manufacturing head rotates along the "X", "Y" & "Z" axis & simultaneously rotates the tooling on a high precision "C" axis. -- Machining:(1) 6 HP (4.5 kW) liquid cooled electro-spindle router with HSK F63 adaptor, variable speed fr 1,500 - 18,000 RPM,NC Controlled "C" axis for 360° horizontal processing & contour edge banding.(1) 4-position "on the fly" plate-type rotary tool changer, max. tool dia 7.08" (180 mm) -- Operator & Machine Control:"HOMAG" NC 83 + "WoodWOP" 4.0 + "WINDOWS NT 4.0 operating system; Icon driven with a graphical interface to allow the operator to quickly and efficiently create programs; Pentium processor, 8 MB RAM, 8 MB hard disk; VGA video card.17" color LCD monitor, 1.44MB & CD ROMx32 drives, connection to an office PC is possible (up to 300 meters). Multitasking operating system, input/output modules, axes override, 4-axis interpolation, diagnostic graphics aid for programming, machine data & tool management. WoodWOP Editor Module for PC with same look and functionality of software on the machine, allows transmission of programs and work lists from an office PC (PC not included): -- Complete with: (1) 100 m³/Hr vacuum pump; (1) 1-coil tape magazine; perimeter protection cage, safety mats, user & maintenance manuals, wiring diagrams and operation of Numerical Control. -- Options Include:(1) Combination Snipping and Corner Rounding Unit; (1) Corner Rounding Radius Cutter Head; (1) Combi-Flush Trimming Scraping Unit; (1) Flush Trimming Unit; (1) extra glue pot; An assortment of spare parts as pictu

HOMAG - Centateq N-300 NBP084/VANTECH 512, ...5' x 12' CNC Flat Table Machining Center with ATC, Boring, Nesting, Infeed Roller & Outfeed -- Specifications:5' x 12' x 37"; H Flat table "Bridge Gantry" machine. -- Working Area:X-Axis 3,683 mm (145"); Y-Axis 1,550 mm (61.02"); Z-Axis 100 mm (3.9"). -- Travels: X-Axis 193" (4,900 mm); Y-Axis 1,965 mm (77.36"); Z-Axis 245 mm (9.65"). -- Positioning Speed:X-Axis 72 MPM (236 FPM); Y-Axis 62 MPM (203 FPM); Z-Axis 25 MPM (82 FPM).(2) Synchronized X-Axis drives, AC brushless drives on head, THK linear motion guides on all axes. -- Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(1) Pneumatic locator/positioning rail in X-Axis & (1) pneumatic locator/positioning rail in Y-Axis; (10) CNC-Controlled vacuum table work zones. -- Boring Unit:2 HP (1.5 kW) Motor; (7) independent vertical spindles with: (4) In X-Axis & (3) in Y-Axis; variable spindle speeds 1,500 - 7,500 RPM. -- Machining:(1) 13 HP (10 kW) High-speed electro-spindle router with: HSK F 63 Adapter, constant duty, variable spindle speeds 1,250 - 24,000 RPM, left-hand or right-hand rotation.(1) 14-Position carousel-type automatic tool changer on left-hand side of machine. -- Operator & Machine Control:"powerControl" Control, with MICROSOFT "Windows" + "WoodWOP 5.0" Operating System."powerTouch" 21.5“, 16:9 full-HD multitouch display, Ethernet, RS-232, USB ports, and remote pendant control. BECKHOFF Programmable logic control for (3/4) axes; linear, circular, & helical interpolation, Tapio-ready. -- Complete with:Infeed electric/hydraulic Scissor Lift platform with roller top; 4’ x 4’ transfer Roller Section with: 2-1/8"; Dia. x 3/4"; W wheels on 12"; & 9-1/2"; centers; vacuum arm with (2) 10"; dia. vacuum pads; rake off-feed System; 61"; W x 13’ L outfeed motorized Belt Conveyor; (2) 2018 BECKER "VTLF2.250/0 - 79" 10 HP 200 mbar Vacuum Pumps; light curtain; 6' H safety Fencing, Touch-off tool length Measuring Device.Control Cabinet Dimensions: 44" x 39" x 96" H.

HOMAG PROFILINE BOF 211/37/15/R FLAT TABLE MACHINE (ATC, BORING, C-AXIS) + LOADING/UNLOADING:" -- Specifications:"LOADED" 5' x 12' Flat table machine. -- Working AreaX-Axis 3,700 mm (145.67"); Y-Axis 1,550 mm (61.02"); Z-Axis stroke 535 mm (21.06"); max. material thickness 210 mm (8.27"). -- Positioning Speed X & Y-Axis 80 MPM (262 FPM); Z-Axis 30 MPM (98 FPM). -- WorktableTable size 3,700 mm x 1,610 mm x 870 mm H (145.67" x 63.39" x 34-1/4").(4) Front rails; (1) right-hand & (1) left-hand corner pneumatic location pins.User-Friendly "MATRIX" grooved aluminum grid vacuum table with: (2) Vacuum work zones with foot pedal controls; table zones can be used independently or together for full table area. Table accepts: Spoil board, gasket material, or vacuum pods. -- Boring Unit(1) 1.5 kW (2 HP) Motor; (9) independent vertical spindles with: (5) In X-Axis & (4) in Y-Axis; variable spindle speeds from 4,500 - 7,500 RPM; (4) horizontal spindles with (1 + 1) in X-Axis & (1 + 1) in Y-Axis. -- Machining(1) 12 kW (16 HP) Liquid cooled electro-spindle router with: "HSK 63F" Adapter; variable spindle speeds from 1,000 - 24,000 RPM.(1) CNC Controlled C-Axis for 360° horizontal processing.(1) 12-Position ride along automatic tool changer on back of head for "on-the-fly" tool changing. -- Operator & Machine Control"powerControl" CNC Control with: MICROSOFT "Windows" + "WoodWOP 5.0" Operating System.Includes: 17" LCD Display, Ethernet, RS-232, & USB ports, remote pendant control, (3) foot pedal controls. -- Complete with: SOUTHWORTH "LST8-36W" 8,000 Lbs Cap. extra wide Infeed Electric/Hydraulic Tandem Scissor Lift Platform; S/N I061700-100; platform size 60" x 144", lowered height 6-3/4", raised height 42-3/4". Vacuum Arm with: (4) 6-1/2"; Dia. Vacuum pads; 61"; W x 13’ L outfeed motorized belt conveyor; 2011 DEKKER "VMAX VMX0553KA1-00 40 HP oil sealed liquid ring Vacuum Pump, S/N M21128; with nominal cap. 550 CFM; max. vacuum pressure 29" Hg.; approx. oil capacity (17) gallons; minimum continuous operation 10,000 Hrs; max. noise level (at 3 ft.) 78 dBA; 40 HP - 1,775 RPM TEFC direct drive motor; "ONDEK" Touchpad Controller with LCD display; (10,918) run Hrs & dimensions: 90" x 27" x 108"; light curtain; 5’ x 17’ pressure sensitive Safety Mat.Machine Dimensions with Infeed & Outfeed: 478" x 142" x 117" H.Control Cabinet Dimensions: 50 x 32 x 96 H.
