LHI 6,000 # Scissor LiftSimple Design, Low Cost, High Performance w/ Off-The-Shelf Parts so you can keep it running years from now Specification: -- 6,000 Lbs weight capacity. -- 48" x 96" Smooth steel platform. -- Lowered height 9-1/2" raised height 49". -- Travel speed: 1/2" per second up -- Foot pedal control.Includes: Auto-indexing UPAvailable Options: -- Automatic Down Indexing -- Automatic Up Indexing -- Automatic Up/Down Indexing

LHI PIGTAIL Crosscut saw with conveyor and air stopSpecifications -- 62" Cut width --Saw motor 5 HP -- 14 FT gravity conveyor cutting surface -- Cam Lock adjustable stop -- Power feed wheel for rip saw infeed assist -- Blade dia. 12"Equipped with and Features -- 4,500 lb lift with loading ramps 1 HP, 30" X 72" platform -- 4,500 lb Outfeed lift with 3 ramps, 48" X 96" Platform, Auto down indexing -- 10" X 40T X 4-3/16" , 30 Blades -- 3-15/16" ID x 4.18" bore x 1.25" wide 30 collars -- 32 Throat Plates

LHI 96" x 60" ANGULAR TYPE RIP & CROSS-CUT SYSTEM: Specifications: -- Automatic Angular Rip & Crosscut 5-Position System; max. panel size of 8' (96") long x 5' (60") wide x 1" - 4" thick; 1.25" minimum spacing between the blades; variable feed speed from 0 - 150 FPM. This system will process a unit of material in approx. (7) Min. -- Pos. # 1: LHI Automatic Staging/Infeed/Transfer & Panel Rake Feeding System: 10' (120") Long, powered 3-chain staging conveyor; (2) units can be preloaded while (1) unit is in process. Automatic up-indexing 4,500 Lbs capacity Scissors Lift with auto. rake infeed system: infeed rake system designed with a thin material device that can automatically load material as thin a 1/8". -- Pos. # 2: LHI "72": 72" Arbor length designed for panels up to max. of 5' (60") wide, min. panel length 30"; 40 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation. 2-3/4" Dia. arbor with 1-15/16" "Fafnir" arbor bearings; positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia. vertical dust outlets with an easy access strip separator box. -- Pos. # 3: LHI Cross-Transfer System: Transfer conveyor with panel hold-down & chain drive system to change direction 90° & automatically feed LHI 102". -- Pos. # 4: LHI "102": 102" Arbor length designed for panels up to max. 8' (96") long; 30 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation; 2-3/4" dia. arbor with 1-15/16" "Fafnir" arbor bearings. Positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia vertical dust outlets with an easy access strip separator box. -- Pos. # 5: LHI Stacking & Outfeed Transfer System: Auto. down-indexing 4,500 Lbs cap. Scissor Lift; (4) adjustable alignment posts & (4) bin separators to keep processed stacks square. 98' (96") Long outfeed gravity conveyor.Operating System: -- (1) LHI ALLEN-BRADLEY "Inter-Link" PLC for simple single-operator management of the entire system from (1) central control.NOTE: ...Attached description & pictures are for INFO purposes only; ...a NEW System can be modified to your exact specifications!NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI 72" RFPR Wide Arbor Roll Feed Gang Panel Ripper with Custom 5' x 16' Automated Infeed -- Specifications: -- 30 HP Arbor Motor; 1/8" min. to 1-1/4" max. material thickness and 72" cutting width. -- 10" Dia. blade design cuts thru max. 2" thickness; -- 3-15/16" dia. arbor with 72" of usable width cutting capacity, min. panel length 30". -- 1-15/16" FAFNIR arbor bearings; with (8) steel feed rollers on 6" centers; fixed feed speed of 80 FPM -- 47-1/4" working height -- (1) Arbor Cart is included -- (2) 4" Dia. dust collection ports on top and (1) 8" dust collection port on bottom. Recommended 1,500 CFM Includes the Following Optional Items: -- 5-Strand powered Chain Deck; 12' long; arranged to feed 5' x 16' packages onto the Scissors Lift. Complete with controls for forward, reverse, and jog. -- 5-Sections of Gravity Rollers on Scissors Lift Deck -- 8,000 lbs. Infeed Tandem Scissors Lift with 5' x 17' Deck and 2-HP, 3-Phase Motor. Lift includes a backstop for initial alignment at the Rake Feeder -- (8) Polyurethane Rollers on 6" centers -- Variable Feed Speeds from 10 to 80 FPM. -- Rake Feeder for 16' long panels -- Auto-cycle for Rake Feeder. -- 6' Line Up Conveyor with Fence and Powered Pinch Roll Included Tooling: -- (36) Standard Saw Collars for Ripping -- (72) Standard 10" Sawblades for Ripping (Includes a spare set) -- (37) Standard Throat Plates for RippingQuick Setup Kit Included, Contains the Following -- Belt guide -- Belt Tensioner -- Hydraulic Arbor LockAdditional Arbor Setup Included. Contains the Following: -- Arbor Cart -- Cart -- Blade Box -- Arbor -- Bearings -- Sheave -- Throat Plate Rack -- (6) Throat Plates PRICE REFLECTS FACTORY'S 7% MATERIALS SURCHARGE ON $156,995, OR $10,990

LHI MODEL RFPR AUTOMATED PANEL RIP SYSTEM --Arranged for up to 5/8"; Thick x 52"; Wide x 18’ Long Panels as follows: AUTOIMATIC INFEED SYSTEM, INCLUDES: --Rake Feeder for up to 18’ Long Sheets --Automated Feed Cycle Controls --Turnkey Controls, Plug it in and Run --1 HP, 3-Phase, 460-Volt Operation 6’ ALIGNMENT CONVEYOR, INCLUDES: --Gravity Roller Frame with 60"; Wide Rollers --Alignment Fence --Spring Loaded “Feather"; to Keep Sheets Tight to the Alignment Fence --Powered Feed Wheel to Push Sheets into the Ripsaw --2 HP, 3-Phase, 460-Volt Operation TANDEM INFEED SCISSORS LIFT --8,000 LBS. Capacity --30"; x 204"; Platform With 62"; Rails Mounted Across the Lift for Fork Lift Entry. Rails are Evenly Spaced Down the Length of the Lift --62"; x 204"; Useable Deck Size. --Automatically Raised and Lowered by Signals from the Sheet Feeder --2 HP, 3-Phase, 460-Volt Operation TANDEM OUTFEED SCISSORS LIFT --8,000 LBS. Capacity --30"; x 204"; Platform With 62"; Long Rails Mounted Across the Lift for Fork Lift Entry. Rails are Evenly Spaced Down the Length of the Lift --62"; x 204"; Useable Deck Size. --Automatically Lowers by Signals from Auto-Down Index Control Unit --2 HP, 3-Phase, 460-Volt Operation --OPTIONAL: 4-Sided “Accordion Skirts"; for each Tandem Lift Table, add $2.650 per lift RFPR" ROLL FEED PANEL GANG RIP SAW --50 HP Main Arbor Motor --1/8" Min. To 1-1/4" Max. Material Thickness x 72" Cutting Width --10" Dia Blade Design; 3-15/16" Dia. Arbor with 72" of Usable Width Cutting Capacity --Min. Panel Length 30". --1-15/16" FAFNIR Arbor Bearings --(8) Polyurethane Feed Rollers on 6" Centers --Variable Feed Speeds Via VFD --(1) Quick Blade Change-Out Kit --(1) Additional Arbor Cart --(2) 4" Dia. Dust Collection Ports on Top and (1) 8" Dust Collection Port on Bottom. Total Recommended 1,500 CFM. TOOLING: --(20) Saw Collars, Mount Directly to the Arbor with a Set Screw --(20) Saw Blades Configured for Clean Cuts on Your Panels

LHI AUTOMATIC RAKE FEEDER with the following equipment: -- Panel Feeder with up to 18' Long x 5' Wide x 1" Thick Sheet Capacity (with 4' min. sheet length) -- Feeder loads from right side when viewed from the End of the Scissors Lift -- Auto-cycle for Rake Feeder -- 6' Line-Up conveyor with Fence & Powered Pinch Wheel -- 8000 Lbs. Tandem Scissors Lift with 5' x 17' top, 600-Volt, 3-phase, 2 HP motor -- 5-Section Gravity Rollers on Scissors Lifts -- 12' Powered 5 Strand Chain Conveyor Feeds Tilt Lift w/forward/ reverse, jog controls -- Wired for 600-Volt/3-Phase/60-Cycle Operation (other voltages available) -- Arranged for Customer Provided MultiScore Panel Ripper with right side arbor loading

LHI RFPR 72/12 "HEAVY DUTY" MULTI-BLADE PANEL SAWSpecifications -- (1) 50 HP main arbor motor for 1/8" min. - 2" max. material thickness; 12" Dia max. blade capacity with 1.25" minimum spacing between the blades; Minimum panel length 30" & 72" of usable width cutting capacity. -- 3-15/16" Dia. arbor with 1-15/16" precision arbor bearings; positive powered steel contact feed rollers with (8) Polyurethane drive rollers; variable feed speed to max 80 FPM. -- (1) "Quick Change" arbor cart trolley and blade box for 9 1/2" cutsOn average this machine will cut a bundle (42 sheets) of 3/4" Plywood. LVL, PB, MDF or OSB into narrow strips in 4 minutes or less.Available Options: -- Blade Box Arbor Cart and Trolley $ 12,590.00 each -- Arbor Carts modifications to accept 12" dia. blades $ 700.00 each -- Single Point Height Adjustment $ 6,000.00 each -- "Quick Change" set up kit (includes belt guide, belt tensioner, and hydraulic arbor lock) $ 3,695.00 each -- Tandem 8000# capacity infeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt, 31" x 192" platform and cross bars for fork truck entry $ 14,495.00 each -- Tandem 8000# capacity outfeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt with 48" x 192" platform and beveled crossbars for fork truck entry and auto down indexing $ 16,390.00 eachTooling Cost: -- Carbide Tip Blades 12" x 40T x 4 3/16 bore with TCG and 3 pin holes $ 125.00 each -- Saw Blade Tooling Collars $ 125.00 each -- Actual Model is LAUDERDALE-HAMILTON RFPR "HEAVY DUTY" 12 Panel Rip SawNOTE: PRICING DOES NOT REFLECT FACTORY'S 7% MATERIALS SURCHARGE

LHI RFPR 102/10 MULTI-BLADE PANEL SAW: with 102" of usable width cutting capacity. Specifications: -- (1) 40 HP main arbor motor for 1/8" min. - 4-1/4" max. material thickness; min. panel length 30"; 102" of usable width cutting capacity. -- 12" Dia max. blade capacity; 1.25" minimum spacing between the blades; -- 3-15/16" Dia. arbor with 1-15/16" precision arbor bearings; -- Positive powered steel contact feed rollers with (8) Polyurethane drive rollers; fixed feed speed of 80 FPM. -- Includes (6) arbor collars - blades not included. -- Complete with:(2) 4" dia dust collection ports on top and (1) 8" dust collection port on bottom. Total recommended 2,200 CFM.Available Options: -- Blade Box & "Quick Change" Arbor Cart and Trolley $12,590.00 each -- Arbor Carts modifications to accept 12" dia. blades $700.00 each -- Single Point Height Adjustment $ 6,000.00 each -- "Quick Change" set up kit (includes belt guide, belt tensioner, and hydraulic arbor lock) $3,695.00 each -- Tandem 8000# capacity infeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt, 31" x 192" platform and cross bars for fork truck entry $14,495.00 each -- Tandem 8000# capacity outfeed Scissors Lift, 2 HP, 3 Phase, 230/460 Volt with 48" x 192" platform and beveled crossbars for fork truck entry and auto down indexing $16,390.00 each -- Drag Chain Feeder Conveyor - Roller conveyor transfers sheets to in-feed of saw and dog chains align and start the sheets into the saw feed rolls. Recommended with 102" wide machines, $18,800 Tooling Cost: -- Carbide Tip Blades 10" dia. x 40-tooth thin kerf blades $125.00 each -- Saw Blade Tooling Collars $125.00 eachOn average this machine will cut a bundle (42 sheets) of 3/4" Plywood. LVL, PB, MDF or OSB into narrow strips in 4 minutes or less.NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI MODEL RFPR ROLL FEED PANEL RIP SAW WITH THE FOLLOWING STANDARD AND SPECIAL EQUIPMENT: Specifications: -- 72" Useable Arbor and 50 HP Arbor Motor -- 14 - 80 FPM Variable Speed Feed Rate (4-speed programmable or potentiometer) -- (8) Polyurethane feed rollers -- Arranged for 14" dia. blades and 4"; max cutting thickness -- Single Point Thickness Adjustment from 1/2" to 4" -- Arbor Quick-Change KitComplete with: -- Additional Arbor Setup, Includes: Cart, Blade Box, Arbor, Bearings, Sheave, Throat Plate Rack, and (6) Throat Plates -- (15) Blade Collars: 3-15/16" ID x 4.18" bore x 1.25" wide -- (15) 14" Carbide Tipped Blades: 40 Tooth with 4.188 bore -- Delivery ESTIMATED at (14) weeks; assumes order and down payment are received within (30) days of the date of this quotation. -- Technical Installation assistance - $125/Hr plus travel time and expenses -- Buyer is responsible for rigging -- Quote assumes customer will deliver material for testing (if required) -- Warranty: 1 Year mechanical parts (electrical controls excluded) -- This quotation is valid for 30 days.

LHI 4,500 # Scissor LiftSimple Design, Low Cost, High Performance w/ Off-The-Shelf Parts so you can keep it running years from now Specification: -- 4,500 Lbs weight capacity. -- 48" x 96" Smooth steel platform. -- Lowered height 9-1/2" raised height 49". -- Travel speed: 1/2" per second up -- Foot pedal control.Available Options: -- Automatic Down Indexing -- Automatic Up Indexing -- Automatic Up/Down Indexing

NEDERMAN S-1000 BAG FILTER Dust Collector. The NEDERMAN S-Series Baghouse Dust Collector is quick to install and easy to operate. It's the ideal solution for a smaller shop or single work-cell operation.Specifications: -- With a 10 HP motor and a 5,000 CFM @ 7" WG and 360 Sq/ft of filter media. -- 10 HP - 1,750 RPM TEFC Motor, (24) Beane material filter bags and magnetic starter. -- Features: Easy installation, typically (1) hour; quiet operation, (3) waste discharge points. Inlet opening 16". Available in 208/230/460 V, 60 Cy, 3 Ph. Must specify Voltage at time of orderAvailable option:- Aluminum Impeller: - 45 Gallon Drum Discharge - Single Drum (3 REQUIRED)- 230 Gallon Dump Bin: Available spare parts:- Filter Bag (24 Filters)- Plastic Bags (Roll of 90 - 8 mil thickness) - 500mm Clamp (bags, barrels, and bin)

NEDERMAN S-1000 BAG FILTER Dust Collector w/ Auto Bag ShakerThe NEDERMAN S-Series Baghouse Dust Collector is quick to install and easy to operate. It's the ideal solution for a smaller shop or single work-cell operation.Specifications: -- With a 10 HP motor and a 5,000 CFM @ 7" WG and 360 Sq/ft of filter media. -- 10 HP - 1,750 RPM TEFC Motor, (24) Beane material filter bags and magnetic starter. -- Features: Easy installation, typically (1) hour; quiet operation, (3) waste discharge points. Inlet opening 16". Includes: -- Auto Bag ShakerAvailable in 208/230/460 V, 60 Cy, 3 Ph. Must specify Voltage at time of orderAvailable option:- Aluminum Impeller: - 45 Gallon Drum Discharge - Single Drum (3 REQUIRED)- 230 Gallon Dump Bin: Available spare parts:- Filter Bag (24 Filters)- Plastic Bags (Roll of 90 - 8 mil thickness) - 500mm Clamp (bags, barrels, and bin)

NEWCNC - SMART ER SERIES I 510: CNC Router w/ATC & Lathe5' x 10' FLAT TABLE CNC ROUTER W/ATC & LATHE: Great for "Nested Base Manufacturing" or just about any type of 3-Axis work. -- Working Table: 63" (1,600 mm) x 122" (3,100 mm). There are: (4) Pop-Up stops to aid in panel positioning; an "M-code" controlled 4-zone electrovalve; special high flow Vacuum Table System. -- X- & Y-Axis Speed: 3,181 IPM (265 FPM / 83 MPM) & Z-axis: 350 IPM (29 FPM / 12 MPM) for quick traverse positioning that reduces total CNC machining time between cutting cycles. "YASKAWA" Servo drives power the axes movement. -- Industrial machine tool welded structurally engineered: Machine base provides a solid foundation for superior cut quality; entire frame is stress relieved and heat treated. -- Moving gantry bridge: Travels on: "THK" Large thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high-speed traverse & accurate cutting. -- Tool Gantry & Bridge Movement: Large thick inclined teeth rack & pinion; vertical axis travels on a large diameter precision ball screw for smooth consistent movement. -- Machining: (1) 12.6 HP (9.4 kW) Air-cooled SCM Router spindle with: "HSK 63F" Adaptor; variable programming speeds: From 1,000 to 22,000 RPM. -- Tools are loaded into the "SCM" spindle by: (1) 8-position plate "on the fly" ride along carousel ATC (automatic tool changer). -- Tool heights can be set using the Tool Length setting gauge (included); machine requires ER-32 tool collets. -- CNC Control: Industrial Grade "OSAI 10/510" OPEN CNC control with: 19" Color monitor; includes self-diagnosis & alarm history display & background editing; up to (4) simultaneously controlled axes with 3D simulation; helical interpolation; tool offset; length compensation & backlash compensation. -- Compatible with virtually all CAD/CAM programming software on the market; you choose the software that best suits your needs. -- Includes: (1) 7.5 HP (5 kW) "Rotary Vane" type Vacuum Pump. -- Complete with: Dust hood with 6" manifold connection; Tool Length setting gauge; "MPG" handheld wheel remote; safety bumper system on both sides of the moving bridge & a safety bar around the back of the machine. -- Options Include: (1) 12' Lathe attachment with: Chuck and tailstock (...$ 8,450 value); (1) additional 7.5 HP (5 kW) Rotary Vane Vacuum Pump (...$5,150 value).

NEWCNC SMART ER SERIES II 510 CNC ROUTER W/ATC & BORING:5' x 10' FLAT TABLE CNC ROUTER W/ATC & BORING is great for "Nested Base Manufacturing" or just about any type of 3-Axis work. -- Working Table: 63" (1,600 mm) x 122" (3,100 mm). There are (4) pop-up stops to aid in panel positioning & a "M-code" controlled 4-zone electro valve, special high flow vacuum table system. -- X- & Y-Axis speed are 3,181 IPM (265 FPM / 83 MPM) and Z-axis is 350 IPM (29 FPM / 12 MPM) for quick traverse positioning that reduces total CNC machining time between cutting cycles. "YASKAWA" servo drives power the axes movement. -- Industrial machine tool welded structurally engineered machine base provides a solid foundation for superior cut quality, the entire frame is stress relieved and heat treated. -- The moving gantry bridge travels on "THK" large thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high speed traverse and accurate cutting. -- Tool gantry & bridge movement by large thick inclined teeth rack & pinion; the vertical axis travels on a large dia precision ball screw for smooth consistent movement. -- Machining: (1) 12.6 HP (9.4 kW) Air cooled SCM Router spindle with HSK 63F adaptor, variable programming speeds from 1,000 to 22,000 RPM. -- Tools are loaded into the "SCM" spindle by (1) 8-position plate "on the fly" ride along carousel ATC (automatic tool changer). -- Tool heights can be set using the Tool Length setting gauge (included); machine requires ER-32 tool collets. -- CNC Control: Industrial grade "OSAI 10/510" OPEN CNC control with 19" color monitor; includes self-diagnosis & alarm history display & background editing; up to (4) simultaneously controlled axes with 3D simulation, helical interpolation, tool offset, length compensation & backlash compensation. -- Compatible with virtually all CAD/CAM programming software on the market; You choose the software that best suits your needs. -- Includes: (1) 7.5 HP (5 kW) "Rotary Vane" type vacuum pump. -- Complete with: Dust hood with 6" manifold connection; Tool Length setting gauge; "MPG" hand held wheel remote; Safety bumper system on both sides of the moving bridge & a safety bar around the back of the machine. -- Options Include: (1) 10-Spindle Vertical Boring Block with 5 independent spindles in "X" axis & 5 independent spindles in "Y" axis ($8,450.00 value). (1) Additional 7.5 (5 kW) rotary vane vacuum pump ($5,150.00. value).

Newman HP-688 Twin Bay Hydraulic Cold Press6-Sections (top platens) each 24" x 30" each, Center posts between third and fourth platens, creating two overall areas of 30" x 74". Specifications: -- Max. fixed opening 48" with 11" cylinder stroke, each platen section has (1) 10" bore with 5" dia. ram cylinder; -- Each platen is 15/16″ thick and it’s back structure is webbed every 5-1/2″ X 7-1/2″. -- Side-mounted self-contained hydraulic system w/tank, 10 HP continuous operating pressure compensating pump. -- Hand-Valves to Cycle Individual Platens with pressure gauges for each platen. -- Idle Pop-Up Bed Rollers in the bottom platen for easy loading and unloading.Over all the press is in excellent condition, is extremely heavily built, and is also a beautiful impressive press in person.

This item is in an Auction on exfactoryauctions.com. Go here to view item: http://exf.ac/i6r NEWMAN S-248 24" x 8" Single-Sided Planer Specifications: Planing thickness 1/16” - 8”. Min. stock length 13”, 4” Butted. Infeed & Outfeed table sizes 24" W x 16-3/4” L. Feed speeds 20 - 100 FPM. Equipped with: 4” Dia. 4-straight knife cutterhead. Segmented serrated upper with 2” W Spring-loaded segments & (3) Solid steel lower feed rollers. Chip breaker, with 2” W Reversible spring-loaded segments.

NEWMAN/Cameron - KF-24: Dip Chain Gang Rip Saw with CAMERON "34H-M1" Infeed SystemSpecifications -- Saw Arbor: 24" Arbor cap.; 14" max. dia. tooling; 4" max. motorized thickness adjustment;22" min. length for glue joint accuracy; 6" throat. -- 2-13/16" Dia. arbor; 24-1/2" capacity saw sleeve arranged for 3-1/8" dia. bore saw blades; saw blade options: 10" - 14" Dia.; spacers: 4-5/8" dia. includes: (1) Saw sleeve and spacers. -- 75 HP - 3,600 RPM TEFC Direct drive motor; arbor with: Disc brake & load meter; arbor lockout on the access door. Feed & Chain: -- 5 HP Variable feed speed: 20 to 100 FPM with: Jam arbor protection. Dip bed carried on: 5" Pitch hardened Double-V chain; hardened dip cams; extruded structural aluminum feed bed slats with: Replaceable steel-backed rubber insert strips; automatic chain oiler with low level shutoff. -- (2) 4" Dia. air loaded overhead pressure rolls; spring-loaded overhead bed plate; pressure rolls & bed plate unit with motorized adjustment; slide type infeed guide with: Handle block; either side of the guide can be used for a stock engraver. -- Anti-kickback finger system with: (1) Lower & (2) upper on infeed; (1) upper kickback on outfeed. Equipped with & Features: Upper outfeed main dust hood: 7-7/8" Dia. 2,150 CFM Infeed dust hood 4-7/8 dia. (855 CFM). (1) Spare sleeve; (2) setup fixtures; generous array of spacers (see photos).

Specially designed haunching machine for beaded face frames, picture frames and decorative cabinetry. This machine uses a specially designed 2-piece carbide insert adjustable cutter. -- The work piece is placed on the table and against the fence and the cutter travels in a vertical motion to achieve the precision cut. -- Any size cut width is attainable by adjusting the width of the cutter and indexing from the fence stops. -- TECHNICAL SPECIFICATIONS -- Motors: 1 @ 1.1 KW (1.5 HP), Voltage: 220/440V/3/60hz, RPM: 6,000 RPM @ 60 hz, Air: 6 Bar, -- TOOLING: Insert Carbide: Milling head 140 mm (5.5"), Height min: no min., width 1/6" (4.2 mm). Max Profile: Height 3.5" (88.9 mm), width no max. -- Machine Dimensions: L x W x H - 40" x 30" x 35". Machine Weight: 675 lbs. -- AVAILABLE OPTIONS (Call for Pricing): Tooling carbide insert head, additional set of inserts, additional flip stops, foot pedal control, left & right digital fence.

NORDFAB NFK Series Modular Dust Collector with (8) Modules, reverse air cleaning and drag chain unloading into a Rotary Air Lock (RAL) --23,000 CFM approx. capacity based on filter area and desired Air to Clothe Ratio. With 50 HP. Consisting of (248) filter bags of 8.7" dia. x 77.2 " long(220 mm x 1,960 mm long) also (8) filter bags of 8.7" dia. x 54.1" long.(220 mm x 1,375 mm long) - located at cleaning fans - for a total of 3,680 sq. ft. of filter area. -- Consists (8) modules and (1) inlet blank module. Fan inlet approx 26" dia. -- Bottom conveyor chain with scrapers carrying the dust to one end and fed into the RAL -- Includes NRS-10 Rotary Air Lock and Transfer Blower to convey the dust to an enclosed waste container (not included). -- Electrical control panel with starters included. -- Overall dimensions 32' long x 7.5' depth x 13.5' high (without support steel)., Approx weight 10,000 lbs. --Actual model is NFK 8AJ/1BL

NORFIELD - 250-M: Strike Router -- Strike Router capacity: 9' Length x 1-5/8" thickness cap.; infinite width; mortising plate & bolt relief in (1) continuous operation. -- 1-1/2 HP Router: Processes any strike up to 4-7/8" long, including T-strike. -- Rectangular relief leaves more wood in jamb for greater strength and more professional appearance.
