CAM-WOOD RD-5412-SC Tenoner with Dowel DrillTenoning/Coping machine for straight or miter material. Great machine for miter door production or stile and rail stock. Equipped with: -- 6" High stackable spindle by pneumatic up & down with (3) different stops; easily and accurately setup for each cutter position. -- Drill heads for dowel hole at each end. -- One shaper head at each side of the table. -- Table moves from right to left by variable speed Pneumatic-Hydraulic power to achieve the fully cutting power. -- Twin table moves in and out separated for tongue and groove, end match application. -- Twin heavy-duty pneumatic pistons hold down the workpieces tightly to the table during the cutting process.Features: -- Rigid construction on the heavy sheet metal frame, cast iron table & base for durability usage. -- Heavy-duty industrial motor is suitable for heavy duty cutting under full load. -- Linear guide rails and bearings let the operator moving the table smoothly. -- Cast iron fence locks in the table groove to finish 45° cut easily. -- Automatic cycle function, just place the material against the stops, the machine will automatically clamp, move in for shaping/tenoning, come out and release the hold down.

CAM-WOOD TRS-3016 Single Blade Bottom Cut Straight Line Rip Saw 15 HP - 3,600 RPM Direct drive BOTTOM mounted arbor,Specifications: -- 1" Dia. arbor, 10" to 16" max. blade cap., 3-1/4" max. depth of cut, 12" min. length; 19" throat cap., 69" long x 43" wide table. -- Precision-built saw head designed for straight-line rip saw operations.Feed System: -- 2 HP Variable feed motor, 30 - 85 FPM, 8-3/4" Twin chain drive, Automatic chain and lubrication to V-Way track; Top pressure system with roller holddowns. -- Double anti-kickback fingers mounted at the infeed; feed chain with V-way track and chain block surface, heat-treated for long wear resistanceFeatures: -- Hard chrome plated table for maximum wear resistance; precision fence with measuring ruler gauge. -- Saw arbor manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced for precise cutting performance; -- (4) Bearing spindle mount ensuring rigidity & long life; Anti-kick finger, two long rollers, in front of saw blade, 4 x 2 = 8 short rollers at the side of the saw blade, two long rollers at outfeed heavy-duty cast iron table. Complete with: -- Rip fence, push buttons, magnetic starter, and 4" dia. dust outlet. -- Optional Laser Beam Light, please add ...$980.

CAM-WOOD "EXCEL" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 408: $ 91,900SERIES 510: $ 96,900SERIES 512: $ 99,300Models Include (Table Sizes): 408 (4' x 8'), 510 (5' x 10'), 510 (5' x 12')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemAuto-Loading: Auto In-feed Loading Scissor Lift & Out-feed Conveyor TableSpindle: 9.0kW (12.8Hp) HSD Air-Cooled Spindle - 6,000-24,000 rpmBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Servo-Motor and DriverY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: Rotary (12) Tools ISO30, ER32Inverter: 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionalDrill Bank: Includes (9) Tools HSDCAD/CAM Software: OptionalWorking Size:SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)SERIES 512: 63’’ (X) x 150’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408: 98’’ (X) x 433’’ (Y) x 71’’ (Z)SERIES 510: 110’’ (X) x 531’’ (Y) x 71’’ (Z)SERIES 512: 112’’ (X) x 603’’ (Y) x 71’’ (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408: 8,810 lbs / SERIES 510: 9,970 lbs / SERIES 512: 10,750 lbsFeatures Include: --Nesting Work for Automatic In-feed Loading w/Scissor Lift and Out-feed Unloading w/Conveyor Process. --Automatic (12) Tool Rotary Type Auto-Tool Changer for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by Brush-less Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --DNC is no longer required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress Relieved Prior to Finished Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse a

CAM-WOOD "DYNAMIC" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 408: $ 60,090SERIES 510: $ 63,800SERIES 512: $ 65,080Models Include (Table Sizes): 408 (4' x 8'), 510 (5' x 10'), 510 (5' x 12')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemSpindle: 9.0kW (12.8Hp) HSD Air-Cooled Spindle - 6,000 - 24,000 rpmBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: YASKAWA Servo Drive and MotorY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: Rotary (12) Tools ISO30, ER32Inverter: 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionalDrill Bank: Includes (9) Tools HSDCAD/CAM Software: OptionalWorking Size:SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)SERIES 512: 63’’ (X) x 150’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408: 87’’ (X) x 122’’ (Y) x 71’’ (Z)SERIES 510: 99’’ (X) x 149’’ (Y) x 71’’ (Z)SERIES 512: 99’’ (X) x 173’’ (Y) x 71’’ (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408: 3,960 lbs / SERIES 510: 4,480 lbs / SERIES 512: 4,970 lbsFeatures Include: --Automatic (12) Tool Rotary Type Auto-Tool Changer for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by Brush-Less Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --Optional CAD/CAM System can Create and Edit Part Programs then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified and Edited from here to Create a G-Code. --DNC is no Longer Required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress-Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Trav

CAM-WOOD "PROFORMA LN" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 408 LN: $ 43,300SERIES 510 LN : $ 46,600Models Include (Table Sizes): 408 LN (4' x 8'), 510 LN (5' x 10')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemSpindle: 9.0kW (12 Hp) Air-Cooled Spindle 6,000 - 24,000 RPMBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Lead-Shine Servo Drive and MotorY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: SERIES Linear (12) Tools ISO30, ER32Inverter: SCHNEIDER 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionDrill Bank: Optional (9) Tool HSDCAD/CAM Software: OptionWorking Size:SERIES 408 LN: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510 LN: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408 LN: 122’’ (X) x 87’’ (Y) x 71’’ (Z)SERIES 510 LN: 99’’ (X) x 149’’ (Y) x 71 (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408 LN: 3,960 lbs / SERIES 510 LN: 4,480 lbsFeatures Include: --Automatic (12) Tools Linear Type Auto Tool Changer under the Bridge for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by a Brushless Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --Optional CAD/CAM System can Create and Edit Part Programs then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified and Edited from Here to Create a G-Code. --DNC is no longer Required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse and Precision. --The X & Y Axis are Equipped with a Precision Rack & Pinion Driving System. The Z Axis Utilizes a Ball Screw Assembly Complete with the Pre-Loaded and

CAM-WOOD - IN-408-R, ...4' x 8' CNC Router with Automatic Rotary Tool Changer:4' x 8' Flat Table CNC Router, Perfect for your 3-axis routing applications including "Nested Base Manufacturing".Machine Bed/Base: -- The Welded & Structurally Engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- The Moving Gantry Bridge travels in the X- & Y-axis via inclined toothed Helical rack & pinion on "HIWIN" 1" (25 mm) thick hardened & precision ground rectangle linear guide ways providing extra smooth movement, high-speed traverse and accurate cutting. -- The Tool Gantry Movement for the vertical Z-axis travels on a 1" (25.4 mm) dia. precision ball screw for smooth & consistent movement.CNC Control & Operator Interface: -- Industrial Grade "SYNTEC" controller with network-compatible WINDOWS PC-based front-end, color monitor, keyboard, mouse. Absolute & incremental programming, cutter & tool length compensation, feed rate & spindle speed override, inch/metric operation, and linear/circular & helical interpolation.. -- Compatible with virtually all CAD/CAM programming software on the market. - You choose the software that best suits your needs.Working Table/Envelope: -- 51" (1,295 mm), 98" (2,489 mm), 7.75" (197 mm). -- (6) Independent vacuum zones.Axes Travel Range & Feed Speed: -- Max Traverse Speeds: 2,350 IPM -- Max Working Speed: 1,100 IPM. -- Yaskawa "AC" Servo drives & SHIMPO Gear Boxes power all axes movements.Routing & Machining: -- (1) 12 HP HSD Air cooled Router Spindle with: ISO 30 Adaptor ER-32, variable programming speeds from 6,000 to 24,000 RPM, -- (1) 12-Position ATC (automatic rotary tool changer)Complete With: -- 10 HP Vacuum Pump. -- (3) ISO 30 tool holders -- two pop up pins at X, axis & three pop up pins at Y,. -- Automatic tool offset device. -- Automatic lubrication device with filter. -- Standard MPG hand wheel -- safety light curtain and Estop -- 1-Year manufacture warrantyUtilities and Dims: -- Machine power supply is wired for 220 Volts, 60 Cy, 3-Phase, 53 Amps. -- Machine weighs approx. 3 960 Lbs. -- Machine air consumption at 90 PSI is approx. 15 CFM;Extra options not included in machine price: HSD 9-spindle vertical Drill-bank ...$7,675

CAM-WOOD - IN-510-R, ...5' x 10' CNC Router with Automatic Rotary Tool Changer:5' x 10' Flat Table CNC Router, Perfect for your 3-axis routing applications including "Nested Base Manufacturing".Machine Bed/Base: -- The Welded & Structurally Engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- The Moving Gantry Bridge travels in the X- & Y-axis via inclined toothed Helical rack & pinion on "HIWIN" 1" (25 mm) thick hardened & precision ground rectangle linear guide ways providing extra smooth movement, high-speed traverse and accurate cutting. -- The Tool Gantry Movement for the vertical Z-axis travels on a 1" (25.4 mm) dia. precision ball screw for smooth & consistent movement.CNC Control & Operator Interface: -- Industrial Grade "SYNTEC" controller with network-compatible WINDOWS PC-based front-end, color monitor, keyboard, mouse. Absolute & incremental programming, cutter & tool length compensation, feed rate & spindle speed override, inch/metric operation, and linear/circular & helical interpolation. -- Compatible with virtually all CAD/CAM programming software on the market. - You choose the software that best suits your needs.Working Table/Envelope: -- X 63" (1,600 mm), Y 126" (3,200 mm), X 7.75" (197 mm). -- (6) Independent vacuum zones.Axes Travel Range & Feed Speed: -- Max Traverse Speeds: 2,350 IPM -- Max Working Speed: 1,100 IPM. -- Yaskawa "AC" Servo drives & SHIMPO Gear Boxes power all axes movements.Routing & Machining: -- (1) 12 HP HSD Air cooled Router Spindle with: ISO 30 Adaptor ER-32, variable programming speeds from 6,000 to 24,000 RPM, -- (1) 12-Position ATC (automatic rotary tool changer)Complete With: -- 10 HP Vacuum Pump. -- (3) ISO 30 tool holders -- two pop up pins at X, axis & three pop up pins at Y. -- Automatic tool offset device. -- Automatic lubrication device with filter. -- Standard MPG hand wheel -- safety light curtain and Estop -- 1-Year manufacture warrantyUtilities and Dims: -- Machine power supply is wired for 220 Volts, 60 Cy, 3-Phase, 53 Amps. -- Machine weighs approx. 4,480 Lbs. -- Machine air consumption at 90 PSI is approx. 15 CFM;Extra options not included in machine price: HSD 9-spindle vertical Drill-bank ...$7,675 Add second 10 HP Vacuum Pump with stand ...$6,000

CAM-WOOD SET-42TS-S 2 Heads 48" Double End Tenoner: Trimming only Capacity: -- Max. 48" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Motorized opening with LED indicator; -- Single-post machine, single "dual-track" base, right side fixed, left side movable.Each side equipped -- Top trim head, 5 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade; -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads and dogs at 6" center, --Spring loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $38,900) -- Hopper feed magazine (additional $3,990)Extended infeed 42" (additional $4,500) -- Pneumatic jump control on scoring or shaping unit -- Same machine with 8' opening

CAM-WOOD SET-108TS- SHJC Double End Tenoner, (8) HeadsCapacity & Style: -- Max. 120" working capacity, min. 12"; max. 2" opening(thickness), 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top scoring head, 2 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Top trim head , 10 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Cope shaping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5-7/8" long x 1" diameter arbor, 6" to 8" max. dia. cutter head -- Jump coping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5 7/8" long X 1" diameter arbor, 6" to 8" maximum dia. cutter head -- Variable feed speed from 12 - 52 FPM, 2 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams with endless belts. -- Separate electrical control cabinet with operator controls.Options Available: (Pricing to be confirmed at time of order) -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional ...$39800). -- Hopper feed magazine (additional ...$3,990). -- 42" Infeed extension (additional ...$4,500) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (...$6,900) -- Electric motor brake -- Central support Included for 10' opening machineNote: Pictures are showing the machine with several options included

CAM-WOOD SET-86TS SJC Double End Tenoner, 6 HeadsCapacity & Style: -- Max. 98" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top trim head, 10 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Jump cope shaping head, 7.5 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Cope shaping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5 7/8" long X 1" diameter arbor, 6" to 8" max. dia. cutter head -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross-transfer system with transfer line 4' X 8' transfer table with rollers (additional $38,900). -- Hopper feed magazine (additional $3,990). -- 42" Infeed extension (additional $4,500) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (additional $ 6,900) -- Electric motor brake -- Central supportNote: Pictures are showing the machine with several options included

CAM-WOOD SET-46TS 6 Heads 48" Double End Tenoner: Soring, trimming and shapingCapacity: -- Max. 48" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Motorized opening with LED indicator; -- Single-post machine, single "dual-track" base, right side fixed, left side movable.Each side equipped -- Front of post: Bottom scoring unit, 2 HP - 3,600 RPM motor, 1" dia. arbor & up to 10" blade; -- Top trim head, 3 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade; -- Back of post: Vertical shaping head, 5 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads and dogs at 6" center, --Spring loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $41,400) -- Hopper feed magazine (additional $4,250)Extended infeed 42" (additional $4800) -- Sound enclosure $ 7,350 -- Pneumatic jump control on scoring or shaping unit -- Same machine with 8' opening

CAM-WOOD SET-52SAT 6-Head Double End Tenoner (Not Feed Through)Capacity: -- Length of cut: 12" to 60" (opening). -- Max. width of cut: 24" (cross cut). -- Max. clamping thickness: 4-1/2". -- Saw blade dia. 8" to 12"; saw arbor dia. 1"; saw blade speed 3,400 RPM; saw head swivels 180 degrees. -- Moulder (Shaper) spindle: 1" Dia. x 5" long; spindle speed 6,000 RPM; spindle swivels 180 degrees. -- Vertical travel: 17" vertical. -- Carriage (table) travel (front/back): 24".Equipped with: -- Saw motors: (4), each 2 HP motors (1 top & bottom each side). -- Shaper spindles: (2), each 2 HP motors (1 each side). -- Out Feed Conveyor drive: 1 HP motor (not this model!). -- Powered length setting: 1/2 HP motor (machine opening).Features: -- With the double end miter saw set-up, you can cut-off stock faster or consider a double end miter saw combined with moulding (shaper) head. It lets you cut and machine stock and moulding pattern in a single feed, saves time, space and cost. -- Air-operated vertical clamps hold sticks firmly in place. After the work piece is clamped, table start to feed, performs trimming and shaping operations. -- Trim saw allows to cut stock accurately with a clean cut. -- Moulding (Shaper) spindle mounted at the rear of saw head enables the machine to perform edge moulding after stock is cut off. -- The entire cutting cycle, cut-off, shaping/tenon or mortise is automatically operated in a single pass of stock feeding. -- The material Clamping table travels on a precision linear motion guide for stability. -- The table traverse is motorized, ensuring very stable, smooth workpiece feeding. -- Material transport thru machine powered by variable speed inverter drive for 10 to 20 Sec per cycle -- Variable feed speed permits proper feed selection for hard or soft wood materials. -- Large hand-wheel to adjust depth of cut. -- All controls are grouped in a control panel. -- Industrial motors for optimal cutting results.Machine Stations: -- 1: Top & Bottom Trim Saws powered by (4) 2 HP saw arbor motors for trimming to length. -- 2: Shaper spindles powered by (2) 2 HP spindle motors for applying tenons and grooves. -- Floor space requirement: 94" X 40" X 54" high. -- Cycle time: 10 to 20 Sec per cycle.Available option at additional cost: -- Auto Outfeed device -- Return conveyor

CAM-WOOD SET-88DET-SHJCJC 8-Head, 96" Double End Tenoner -- Suitable for mass production of woodworking task for double-end cutting, tenoning, grooving, profiling and sanding -- Scoring, Hogger/Saw, Jump Shaper, Jump Shaper: Total (4) stations on both sides. -- A solid, powerful machine great for Heavy-Duty production.Capacity: -- The specially designed numeric controller allows quick setting of sizes, for the tolerance within 0.004";. -- Variable speed, through feed, wide rubber pad chain, spring-loaded dogs at 8" center conveyor for the best finish selections. -- Heavy-duty pressure rolls at top of wide width conveyor to hold the material tight to prevent sliding during the cutting process. -- Shaper heads can be moved up & down, forward & backward. -- Max. 96" working capacity, min. 12"; max. 3-1/8" opening, 24" load area in front of hold-downs. -- The automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 66 FPM. -- Motorized opening with LED indicator.Each side equipped -- Top Scoring saw unit , 2 HP - 3,600 RPM motor, 1" dia. arbor & up to 8" blade -- Hogging/ Trim saw tiltable unit, 5 HP - 3,600 RPM motor, 1" arbor and up to 10" blade. -- Jump Shape/coping head unit, 7.5. HP - 4,500-7,000 RPM motor, 40mm dia. arbor for 6" to 8" cutter head. -- Jump Shape/coping head unit, 7.5 HP - 4,500-7,000 RPM motor, 40 mm dia. arbor for 6" to 8" cutter head -- Variable feed speed from 20 - 66 FPM, 2 HP motor, steel feed chains with plastic anti-slip pads and dogs at 16" center. -- Spring-loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Not Included -- Hopper feed magazine $3,960) -- Extended infeed 42" in front of hold-down belt $4,900) -- Sound enclosure $ 8,900Floor space : 8.5' X 9' X 6', weight 10,500 Lbs

CAM-WOOD SET-812 SCCWW, Double End Tenoner with Sanding12-Head Double End Tenoner, suitable for mass production in a woodworking factory, processing double end cutting, tenoning, grooving, moulding, and sanding.Features: -- Automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 75 FPM. -- In addition to the double-end cutting, all the settings and other processing can also be executed with high accuracy. -- Since the machine is so versatile, we believe it will be one of the most satisfactory machines for bulk production lumber-processing factories. -- The specially designed numeric controller allows quick setting of length sizes for tolerance within 0.004". -- The numeric control system provides highly accurate settings, and a special memory retains all settings, even if there is a power failure. -- Variable speed, through feed, wide rubber pads with spring-loaded dogs located at 16" center distance with conveyor speed for the best finish selections. -- Heavy-duty powered pressure rolls at top of the wide width conveyor holds the material tight to prevent sliding during the cutting and sanding process. -- Shaper head can be moved up & down, forward & backward. -- Workstations are powered by industrial motors for full power cutting and utilizing the entire sanding capacity range. -- Two sanding heads can use brush, flap wheel or profile disc for fine finish with one pass. -- Trim saws and sanding heads can be tilted for different angular setup. -- Heavy cast iron base for durability and heavy duty usage.Specifications: -- Thickness: ½" to 4" -- Length: 10" to 96" -- Miter Saw Blade: 10" x 30 mm Dia. -- Grooving Saw Blade: 8" x 1" Dia. -- Shaper Cutter: 6" - 10" x 30 mm Dia. -- Feed Speed: Variable, 20 ~ 75 FPM -- Trim Saw 3 HP x 2, 3,450 RPM -- Hogging Saw 10 HP x 2, 3,450 RPM -- Jump Shaper 10 HP x 2, 4,500 to 7,000 RPM -- Shaper 10 HP x 2 4,500 to 7,000 RPM -- Belt Sanding 3 HP x 2, 0-1500 RPM -- Brush Sanding 3 HP x 2 with 30 mm arbor 0-1500 RPM -- Feeding 3 HP x 1 -- Width (Opening) Setting 1 HP x 1 Option: -- Sound enclosure ...$ 7800

CAM-WOOD SET-410-SHJJA 50" Double End Tenoner with Sanding(10) Heads Double End TenonerFeatures: -- The automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 66 FPM. -- Suitable for mass production in woodworking factory for processing of double end cutting, tenoning, grooving, moulding, and sanding. -- In addition to the double end cutting, all the settings and other processing can also be executed with high accuracy. -- Since the machine is so versatile, we believe it will be one of the most universally satisfying machines for bulk production in lumber-processing factories. -- The specially designed numeric controller allows quick setting of length sizes for tolerance within 0.004". -- Variable speed, through feed, wide rubber pad, spring-loaded dogs at 16" center conveyor for the best finish selections. -- Heavy-duty powered pressure rolls at top of wide width conveyor to hold the material tight to prevent sliding during the cutting and sanding process. -- Shaper head can be moved up & down, forward & backward. -- Equipped with industrial motor for full power cutting and sanding capacity. -- Two sanding heads can use brush, flap wheel or profile disc for fine finish with one pass. -- Trim saws and sanding heads can be tilted for different angular setup. -- Heavy cast iron base for durability usage.SPECIFICATIONS: -- Material Thickness: ½" to 4". -- Material Length: 10" to 50". -- Scoring Saw Blade: 12" x 1" Dia. -- Hogging Saw Blade: 8" x 40 mm dia. arbor. -- Shaper Cutter: 6" - 10" x 40 mm dia. arbor. -- Feed Speed: 20' - 66' Variable, Motor 3 PH, 220/440 V. -- Trim Saw 5 HP x 2. -- Hogging saw blade 10 HP x 2. -- Jump Shaper 15 HP x 2. -- Jump Shaper 15 HP x 2. -- Brush/Disc Sanding 2 HP x 2 with inverter for variable RPM. -- Feed Drive 3 HP x 1. -- Width Setting 1HP x 1. Option: -- Sound enclosure $ 8,900 -- Hopper feed magazine $ 3,900 -- 42" extend infeed conveyor before top hold down $ 4,900

CAM-WOOD SET-106TS- SJC Double End Tenoner, (6) HeadsCapacity & Style: -- Max. 120" working capacity, min. 12"; max. 4" opening(thickness), 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top scoring head, 2 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Top trim head , 7.5 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Cope shaping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5-7/8" long x 1" diameter arbor, 6" to 8" max. dia. cutter head -- Variable feed speed from 12 - 52 FPM, 2 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams with endless belts. -- Separate electrical control cabinet with operator controls.Options Available: (Pricing to be confirmed at time of order) -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional ...$41,400). -- Hopper feed magazine (additional ...$4,250). -- 42" Infeed extension (additional ...$4,800) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (...$7,350) -- Electric motor brake -- Central support Included for 10' opening machineNote: Pictures are showing the machine with several options included

CAM-WOOD SET-84 -TS - SH Double End Tenoner, (4) Heads4-Head machine (two on each side) with Scoring/Cutting and HoggingCapacity & Style: -- Max. 98" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Scoring head, 3 HP - 3,600 RPM motor, and 1" dia. arbor for up to 10" blade. -- Hogging/cutting unit 5 HP - 3,600 RPM motor, 1" dia. arbor, 10" max. dia. cutter-head. -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring loaded overhead hold-down beams with endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $38,900). -- Hopper feed magazine (additional $3,990). -- 42" Infeed extension (additional $4,500) -- Sound enclosure ...$6,900 -- Electric motor brake -- Central supportNote: Pictures are showing the machine with several options included

CAM-WOOD SET-14TS Double End Tenoner, (4) Heads, with Single feed chain for Narrow PartsFeatures: --The automatic high-speed through feed tenoner allows for perfect finishing at speeds ranging from 1 ~ 43 FPM. -- Suitable for mass production for processing of double-end cutting, tenoning, grooving, and moulding. -- SET-14TS Shaper, Sander: Total (2) stations on both sides. -- Variable speed, through feed, wide rubber pad, and spring-loaded dogs feed chain for the best finish selections. -- Heavy-duty pressure rolls at top of the wide-width conveyor to hold the material tight to prevent sliding during the cutting process.Specifications: --Max. Working Thickness 2" --Working Width 2-3/4"; ~ 10"; -- Working length 4" to 14" -- First head Tilting cutting saw -- Second head Tilting cutting Saw --Optional: Shaper Cutter Heads, Sander Heads 6" ~ 8" x 1" Dia. --Feed Speed 1' ~ 43' FPM, Variable --Feed Drive 3 HP, 220 or 440 V -- Saw Heads 5 HP x 2 -- Saw heads 5 HP x 2 -- Feed drive motor 1 HP Option: -- Tiltable saw blade 0° to 90° Additional $2,800

CAM-WOOD SET 83-3M Single End TenonerIt performs tenon, moulding functions. -- Three tenon cutters, cope spindles accepts general shaper cutter. -- Suited for cutting tenons, finger joints for windows or door frames and general joint-tenon. -- Hand, manually operated clamping and feeding of stock. -- Then two horizontal moulding, tenon spindles and one vertical coping spindle enables machine to perform edge tenon, moulding. -- Since each head is adjusted independently, a wide variety of tenons can be cut. -- At the end, the cope spindle provides 6000 RPM cutting, allowing to feature a spindle sharperSpecifications: -- Table Size 31"; W x 12"; L -- Max. Length of Cut ~ -- Min. Length of Cut 5"; -- Max. Width of Cut Pass Once 5", Pass Twice 8"; -- Max. Tennor Height 5"; -- Max. Tenoner Depth 6"; -- HORIZONTAL COPING HEADS X 2 UNITS (M1 & M2) -- Cutter Head Dia. 6-3/4";, Cutter Arbor Dia. 30 mm, Cutter Head Length 2-3/8";, Cutter Speed 4,000 RPM -- VERTICAL COPING HEAD (M3), Cutter Head Dia. 5";, Cutter Arbor Dia. 30 mm, Cutter Head Length 2-3/8";, Cutter Speed 4,000 RPMTRAVERSE -- Saw Longitudinal Travel 3" -- Saw Vertical Travel 3" -- Carriage Cross Travel 20" -- MOTOR Saw & Tenoner Head 3 HP x 2 -- Cope Head 5 HP x 1 -- DUST HOOD Out Diameter 6"; x 2

CAM-WOOD - SET-48TS-CHX, ... Double End Tenoner for Chevron & Herringbone FlooringSpecial design Servo Control for Chevron & Herringbone Double End TenonerFeatures: -- Servo Control for +45° or –45° and 90° cutting. -- The automatic high-speed through feed device allows for perfect finishing at speeds ranging from 12 - 52 FPM. -- Feed chain with dogs at 10" center distance. -- Suitable for mass production of woodworking factory for processing of double end cutting, tenoning, grooving, moulding, and sanding. -- Possibility for: Scoring Saw, Trim Saw, Jump Coping, Shaper, Coping. -- Total (4) stations at each side. -- Reversed direction cutting jump shaper head with sensor for automatic move in and out for perfect cutting to prevent tearing at end edge. -- HMI Plus PLC controller for user-friendly easy setting and operation. -- Powerful machine is great for heavy-duty production. In addition to the double end cutting, all the settings and other processing can also be executed with high accuracy. -- Since the machine is so versatile, we believe it will be one of the most satisfactory machines for bulk production lumber-processing factories. -- The specially designed numeric controller allows quick setting of sizes for tolerance within 0.004";. -- Variable speed, through feed, wide rubber pad, and spring-loaded dogs conveyor for the best finish selections. -- Heavy-duty pressure rolls at top of wide width Conveyor to hold the material tight to prevent sliding during the cutting process. -- The Shaper head can be moved up & down, forward & backward. -- Equipped with: Industrial motors for full power cutting capacity. Specifications: -- Max. working thickness: 2";. -- Max. working length: 45° is 49";. -- Max. working length: 90° is 48". -- Min. working length: 45° is 18". -- Min. working length: 90° is 13-3/4". -- Scoring/Main saw blade (dia.): 10" x 1". -- Shaper cutter (dia.): 6" - 8" x 1" -- Feed speed 12' - 52', variable power 3 PH - 220/440 Volt. -- V-Scoring saw: 3 HP x 2. -- Trim saw: 3 HP x 2. -- Jump Shaper: 5 HP x 2 Stationary. -- Shaper: 5 HP x 2. -- Feed motor by Servo: 1 kW x 1; Width setting by Servo 0.75 kW x 1.Available Options: -- Total sound enclosure cover: Add ...$7,900. -- Infeed Hopper Magazine: Add ...$4,990.
