CALPE TH5-1600 Heavy-Duty High-Production, Fully Automatic CNC Lathe: General Description: -- Multi-Spindle cutting simultaneously, (5) spindles using V-type gouge knives. -- 63" (1,600 mm) Max. distance between centers; 5-1/2" (140 mm) max. swing diameter between spindles. -- CNC Controlled with 2.95" (75 mm) travel for depth of cut. Motors/Speeds: -- Servo controlled CNC drives: -- CNC controlled electronic variable speed head drives the movement of the (5) gouge tools. -- CNC controlled feed speed carriage, variable up to 50 FPM (15 MPM). -- (1) Head stock variable speed drive for the (5) spindles, up to 6,000 RPM, approx 10 HP. -- Fast return travel of up to 590 IPM (15,000 mm/Min). 2 HP approx hydraulic drive -- Loading device & tail stock powered by hydraulic pump with 2 HP - 1,750 RPM motor; No. 5 Morse taper on main spindle shaft. Features: -- Automatic loading & unloading device; carriage mounted with linear guides providing high precision movement. -- Full CNC controller with on-screen CAD programming for all products.Matching CALPE L6-1600, record number LC-010996 spindle sander is available at additional cost at same facility.

CALPE L6-1600 Spindle Sander with Hopper Feed. -- (6) Spindles, semi-automatic sanding machine; distance between centers 63", 6-3/16" max sanding diameter, capable of sanding 1800 spindles per hour. -- 4 HP - 1,800 RPM head motor, (5) sandpaper holders, each for different grits, 4000-3200-2200-850 RPM head spindle speeds. Copier unit that follows all contours. -- Oscillating sanding units & stationary pick up of part. -- NOTE: This sander was running with lathe on our record number LC-01811 and owner prefers to sell at the same time.

CAM-WOOD SM-156A Feed Through Moulder;6-Head (B-R-L-T-T-B), working cap. 6" x 4".Specifications: -- Head sequence: Bottom 7.5 HP, right 5.5 HP, left 5.5 HP, top 10 top, top 7.5 HP and bottom 7.5 HP motor. -- Spindle diameter 40 mm with cutterhead speed of 6,000 RPM; spindles equipped with mechanical readouts for axial and radial adjustments. -- 4 HP Feed Motor variable speed 16- 65 FPM; carden drive system. -- 1.2 M (4'0") Infeed table with lateral side pressure roller mounted at table infeed. Manual table lubrication pump. -- Includes: Short stock attachment, set up tools and manuals. -- Dust collection Min. 3,500 CFM -- Air requirement 90 psi. -- 150 AMPs. at 220 V. -- Machine dimensions , length & width 137"; long, x 54"; Width x 68"; High Note: Brand New with Warranty!

CAM-WOOD Model SM-236U Moulder Feed Through 6-Head (B-R-L-T-T-U), working cap. 9" x 4-3/4"Specifications: -- Head sequence: Bottom 10 HP, Right 10 HP, Left 10 HP, Top 15 HP, Top 15 HP and Universal 7.5 HP motor. -- Max. (Min.) Working Thickness 4-3/4" -- Min. Working Length 9½" -- Feed Motor 7½ HP and Elevation motor 1½ HP -- Spindle Dia.: 40 MM with cutterhead speed of 6,000. Mechanical digital readouts for all spindle adjustments, as well as chip breakers and pressure elements. Tool cutting circles: vertical spindles 5" to 6.25" and top spindles 5" to 7". -- Variable Feed: From16 ~ 110 FPM with LED speed readout. Over-sized top and bottom rollers run synchronized, ensuring smooth feeding. The three independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding. -- Universal spindle with 270° rotation from the left side. -- Includes: Infeed table 2M (6'6") with manual table lubrication ports. Side pressure roller at infeed; Hard chrome-plated table for maximum wear resistance. Full sound and safety enclosure and manuals.

CAM-WOOD SM-623L Moulder, Feed Through 6-Head (B-R-L-T-T-B), working cap. 9-3/4" x 5-1/4". Head sequence: -- Bottom 10 HP, right 10 HP, left 10 HP, top 20 HP, top 15 HP, and bottom 20 HP motor. -- Spindle dia. 40 mm with a cutter-head speed of 7,200 RPM. All spindles with mechanical digital readouts. -- Feed: Variable speed of 26 - 119 FPM, with 7-1/2 HP feed drive motor. Powered feed rollers top and bottom. -- Infeed Straightening table 2M (6'6"), with side pressure roller and table lubrication pump. -- Dust outlet Diameters are 5" X 6" outlets. Includes: -- Hard chrome-plated fences and table, -- Operator/spare parts manuals, -- Centralized control panel, -- Sound and safety enclosure, -- Short stock feeding mechanism (9 1/2" min length), -- Power elevation (1-1/2 HP beam.)Options:Training and installation, tooling & rigging are optional. -- SM-KFST Knife Setting Stand ...$1,970.00The machine base is one piece coated from high-quality cast iron (FC-25) for maximum stability of the structure. Base is machined by CNC machine equipment to ensure the utmost working accuracy. Net weight 11,220 Lbs Shipping weight 12,300 Lbs.

CAM-WOOD SM-155AX Feed Through Moulder 5-Head Moulder with a 6" width and a 4.75" max. thickness capacity.Overall Description: -- Cast Iron mainframe to maximize stability & minimize vibration during operation for years of use. -- Fully enclosed sound hood with lift-up door for easy set-up access. -- Adjustable infeed table w/fence for straightening rough sawn material. -- 16 - 66 FPM Variable feed speed system with top-driven rollers. -- All spindle adjustments except 1st bottom spindle with mechanical digital readouts. -- Left and Top spindles with mechanical Digi-set readouts. Chipbreaker and pressure element with mechanical digital readouts for accurate adjustment and precise settings.Complete with: 5' Infeed table length, Chromed table plates, fences, and pressure shoes. Manual Waxilit pump, Central lubrication of the machine from the front side.Specifications: -- Max. (Min.) Working Width 6" (3/4") -- Max. (Min.) Working Thickness 4-3/4" (5/16") -- Min. Working Length 9½". -- 1st Spindle Horsepower 7½ HP. -- 2nd, 3rd Spindle Horsepower 5½ HP, 5½ HP; -- 4th, 5th Spindle Horsepower 10 HP, 7½ HP. -- Cutterhead Dia.: 1st Bottom Head 5" dia.; 2nd, 3rd Vertical Head 5" - 6-1/4" dia.: 4th, 5th Head 5" - 7" diameter. -- Feed Motor 4 HP. -- Elevation 1 HP motor. -- Spindle Diameter 40 mm. -- Cutter Head Speeds 6,500 RPM. -- Variable Feed Speeds 16 ~ 66 FPM. -- Pneumatic Air 90 PSI (5 CFM by bolume) -- Dust Outlet Diameter 5" x 5" -- Net Weight 5,900 Lbs; Gross Weight 6,700 LbsIncludes: -- Operator/spare parts manuals and setup tools.

CAM-WOOD - SM-236AX, ...Moulder Feed Through 6-Head (B-R-L-T-T-B), working cap. 9" x 5-1/4". Specifications: -- Head sequence: Bottom 10 HP, Right 10 HP, Left 10 HP, Top 15 HP, Top 10 HP and Bottom 10 HP motor -- Max. (Min.) Working Thickness 5-1/4" (5/16") -- Min. Working Length 9-1/2 in. -- Feed Motor 4 HP, variable feed speed from 16 - 82 FPM -- Elevation motor 1 HP -- Spindle Dia.: 40 mm with cutterhead speed of 6,500 RPM. -- Mechanical digital readouts for all spindle adjustments, as well as chip breakers and pressure elements. -- Tool cutting circles: First bottom head 5", 2nd & 3rd head 5" to 6-1/4", 4th to 6th head 5" to 7".Feed System: -- Variable Feed Speed from 16 - 82 FPM with LED speed readout. -- Oversized top & bottom rollers run synchronized, ensuring smooth feeding. -- The (3) independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding.Complete with: -- Infeed table: 2M (6'-6") with manual table lubrication ports. -- Side pressure roller at infeed. -- Hard chrome-plated table for maximum wear resistance. -- Full sound and safety enclosure and manuals.

CAM-WOOD SM-124TAX Feed Through Moulder4-Head Moulder with a 11-3/4" width x 9" maximum thickness when used as a 2-sided planer, and 10-1/4" width x 4" maximum thickness when used in 4-sided operation ( please see literature ).Equipped with: -- Cast Iron mainframe to maximize stability & minimize vibration during operation for years of use. -- Fully enclosed sound hood with lift-up door for easy set-up access. -- Adjustable infeed table w/fence for straightening rough sawn material. -- 11 - 52 FPM Variable feed speed system with top-driven rollers. -- All spindle adjustments with mechanical digital readouts. -- Left and top spindles with mechanical digi-set readouts. Chipbreaker and pressure element with mechanical digital readouts for accurate adjustment and precise settings.Complete with: 40" Infeed table length, Chromed table plates, fences, and pressure shoes. Manual waxilit pump, Central lubrication of the machine from the front side.SPECIFICATIONS SM-124TA Max. (Min.) Working Width 10-1/4"Max. (Min.) Working Thickness 4"1st Spindle Horsepower 4.1 HP - 7,000 RPM2nd, 3rd Spindle Horsepower 4.1 HP - 7,000 RPM4th, Spindle Horsepower 4.1 HP - 7,000 RPMFeed Motor 1/2 HPSpindle Diameter 40 MMCutter Speeds 6,500 (RPM)Variable Feed Speeds (FPM) 17 ~ 66Cutter head Diameter 1-1/4" or 30 mmPneumatic Air 90 PSI (CFM) 5Dust Outlet Diameter 5" x 4"N.W. 1,157 LbsG.W. 1,366 LbsIncludes: -- Operator/spare parts manuals and set-up tools.

CAM-WOOD SM-632LX 6-Head Feed Through Moulder6-Head (B-R-L-T-T-B), working cap. 12-1/2" x 6".Specifications: -- Max/Min working width 12-1/2" - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 25 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with a cutterhead speed of 7,600 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on left and top spindles. Mechanical readouts for pressure elements and chip breakers; all chip breakers and pressure elements with pneumatics. -- Feed works: Inverter driven 10 HP feed system with feed speeds of 38 - 98 FPM. (up to 120 FPM available)Infeed table 2M (6'6"), chromed tables and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 98' per minute are a standard feature. -- The full safety enclosure covers as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows to fit several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- SM Automatic feed magazine -- DC Automatic digital control -- SM Knife setting stand

CAM-WOOD SM-532L 5-Head Through Feed Moulder5-Head (B-R-L-T-B), working cap. 12-1/2" x 6".Specifications: -- Max/Min working width 12-1/2" - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 25 HP and bottom 20 HP motor. -- All Horizontal spindle have outboard bearings -- Spindle dia. 50mm with cutterhead speed of 7,600 RPM. -- All spindles equipped with mechanical digital readouts, "Dual mechanical" readouts on left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 10 HP feed system with feed speeds of 28 - 98 FPM. (up to 120 FPM available)Infeed table 2M (6'6"), chromed tables and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 28' ~ 98' per minute are a standard feature. -- The full safety enclosure cover as chip guard and helps to reduce noises. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows to fit several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table, permits the table to be position extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high speed running. -- Centralized lubrication system Available options: -- SM Automatic feed magazine -- DC Automatic digital control -- SM Knife setting stand

CAM-WOOD SM-632 HS 6-Heads High-Speed Trough Feed Moulder(6) Heads (B-R-L-T-T-B), working cap. 12-1/2" x 6-1/4"".Specifications: -- Max/Min working width 12 " - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic Jointer for all (6) heads add: ...$45,600 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications) -- For 6 heads machine add $82,800 -- For 7 heads machine add $ 90,600

CAM-WOOD SM-167AX Lateral Chain FeederLateral Chain Feeder for up to 11.8"' X 16' long materialFeatures: -- The feed table is designed to be able to connect with any 4-sided Moulder, Multiple Blade Rip Saw, Straight Line Rip Saw and Planer -- Feed rollers are pneumatically actuated for quick clamping of wood. The feed speed of the front set of rollers is adjustable to match the moulder -- Hydraulic drive motors for each feed roller allow variable feed drive -- Centralized control panel, with push-button for start and stop, chain feed regulation and display, feed roller raising/lowering control -- Infeed fence, the infeed fence allows the material to be lined up properly with the feed roller -- Wood thickness limit. There are two adjustable thickness limits preventing over-thickness material to enter the moulderSpecifications: -- Working width 25 to 300 mm (1" to 11.8") -- Working thickness: 8 to 160 mm (0.315" to 6.3") -- Working lenght: 2,000 mm to 7,000 mm (78.7" to 275.6") -- Infeed table 5,425 mm L X 2,090 mm W X 1,920 mm H ( 213.5' L X 82.2" W X 75.5" H) -- Minimum working length: 1,000 mm (39") -- Feed speed: 10 - 120 MPM (32.5 FPM - 390 FPM) -- Feed motor drive for hydraulic motor: 5 HP -- Table feed motor: 2 HP with inverter control -- Feed roller diameter: 140 mm (5-1/2")

CAM-WOOD SM-623-HS 6-Head High-Speed Trough Feed Moulder(6)-Heads (B-R-L-T-T-B), working cap. 9" x 6-1/4".Specifications: -- Max/Min working width 9-3/4" -- Max/Min thickness 6-1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 10 HP, right 10 HP, left 10 HP, top 15 HP, top 15 HP and bottom 15 HP motor. -- Spindle dia. 40 mm (or by request) with cutterhead speed of 6,200 RPM. -- Feed works: Inverter driven, 10 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2 M (6'6"), chromed tables, and fences. Side pressure roller mounted at the infeed. Features and complete with: -- SM-237-DG where the last bottom spindle can be used for cutter head or saws with inverter RPM control -- HMI Touch Screen Control for all the head positions -- Automatic setting from 2nd to 6th heads, (2) axis positions and thickness control by servo control movement -- 200 sets of memory (Extendable) -- Feed speeds ranging from 20' ~ 260' per minute are standard specifications. -- Hard chrome-plated table for maximum wear resistance. -- Full enclosure safety hood reduces noise and completely prevents chips from splashing. -- Anti-impact plate for over-width and over-thickness protection. -- Oversize top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard features maximum durability and is impact resistance. -- The three independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers canbe set with individual pressure allowing for consistent feeding results and outstanding effect. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Exclusively designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate with table feeding roller design, provides smooth and precise cutting of dry and wetwood, reducing the possibility of material jams. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic jointer head for all (6) heads add ...$ 58,500 -- Siko encoder with digital display for all axis add ...$ 4,200 per head -- Automatic lateral chain feeder P.O.R.

CAM-WOOD SM-732 HS 7-Heads High-Speed Trough Feed Moulder(7) Heads (B-R-L-T-T- T-B), working cap. 111 13/16" x 6-1/4"".Specifications: -- Max/Min working width 11 13/16" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 20 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP, top 15 HP and bottom 15 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,000 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- PNEUMATIC LOAD INFEED SIDE PRESSUREWhile high speed feeding, the side pressure on infeed table ensures every timber close to the fence even under different width. It's convenient to adjust quickly. --OVER HEiGHT PROTECTIONIn case workpiece exceeds the rated maximum height, it will be restricted by the over height protection device provided at the workpiece infeed end. -- HYDRAULIC OUT-BOARD BEARING SUPPORT TOP AND BOTTOM SPINDLESpecially designed hydraulic supports on the top and bottom spindles assure maximum stability while performing high speed and heavy duty machining. -- PNEUMATIC LOAD SIDE PRESSURE WHEELS The front side air pressure wheel on left vertical spindle fully eliminates problem when feeding short or narrow stock not smoothly. The pressure plate is easy and quickly to adjust. -- PNEUMATIC LOAD TOP PRESSURE PLATEThe front pressure plate for top spindle is available to apply an air loading device ensuring maximum stability while performing high speed cutting -- CENTERAL LUBRICATION POINTThe lubrication point are located at the centralized plate for convenience. -- POWERED INFEED TABLE ROLLER The roller in the infeed table is powered, providing a smooth feeding effect for feed stock. -- VERTICAL SPINDLE AXIAL ADJUSTMENT UP TO 60MMIt allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. The 60mm spindle adjustment provides full utilization for a single cutter. -- CENTRALIZED PRESSURE ADJUSTMENT• All pressure regulations for the entire pneumatic system are centralized at the front of the machine for added convenience in pressure adjustment, and sectional pressure adjustments for all pressure rollers ensure consistent pressure.• Clear numerical indicators are provided to correspond directly to the pneumatic mechanisms on the machine, allowing operators to make adjustments based on different processing requirementsAvailable options: -- Automatic Jointer for all (6) heads add: ...$45,600 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control sys

CAM-WOOD SM-545 HS 5-Heads High-Speed Trough Feed /Planer/Moulder(5) Heads (B-R-L-T-T), working cap. 450 mm X 160 mm (17-7" x 6-1/4").Specifications: -- Max/Min working width 17.7" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, and top or bottom 20 HP . -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications)

CAM-WOOD PL-24 TOP & BOTTOM STRAIGHTENING PLANER8" x 24" Capacity Planer for accurate and powerful two-sided planing in one pass.Includes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $3,000 Specifications: -- 25"; Max. Planning Width, 3/8" to 8"; Max. Planning Thickness. -- 1/4";Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 70 FPM Feed Speeds (Variable). -- 4,200 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges -- 25 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor and 1/2 HP Elevation Motor. -- Net weight 7,200 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-fre

CAM-WOOD PL-18 18" Wide Top & Bottom Straightening Planer. -- 18" Planer with straight knife heads with HSS knives for accurate and powerful two-sided planning in one pass.ADD for Spiral Heads with Carbide Insert Knives... $4,000.00Replacement Knives:CT-SCH-14T 14 mm wide x 2.0 mm thick Spiral Knives - $2.90 EACHCT-SCH-15T 15 mm wide x 2.5 mm thick Spiral Knives - $3.60 EACHSpecifications: -- 17-3/4"; Max. Planning Width. -- 3/8 to 8" Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 10"; Min. Planning Length. -- 15 to 70 FPM Feeding Speed (Inverter Driven). -- 4,200 RPM Cutter Straight Knife Head Speed. (6,000 RPM for Spiral Cutter Head). -- (4) Knife Cutterheads. -- 15 HP Upper Motor. -- 10 HP Bottom Motor. -- 2 HP Feed Motor. -- 1/2 HP Elevation Motor. -- Table Size (L x W) 88" x 16". -- N.W. 6,500 Lbs.Features: -- Standard equipped with automatic thickness controller, easy, accurate and quick setting for the cutting thickness. -- Upper & lower straight knives or spiral cutterheads for accurate and powerful two-sided planing in one pass. -- The worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planning. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing of the surface can be performed to prevent jumping during processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with heavy-duty drive chains and gears to provide a smooth even feeding during rough or finish planning. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- The heavy-duty rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial motor for maximum cutting capacity. -- All precision sealed long-life bearing for durability -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Changing the knife on the upper cutterhead only requires removal of the upper dust chute. -- The optional spiral insert head design allows for fast, accurate insert changes and minimum down time. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth cha

CAM-WOOD PL-38 TOP & BOTTOM STRAIGHTENING PLANERIncludes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Insert Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $8,000Specifications: -- 3" to 38"; Max. Planning Width -- 3/8" to 7"; Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 52 FPM Feed Speeds (Variable). -- 4,000 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges 40 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor -- 2 HP Elevation Motor. -- Net weight 9,800 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-free planing regardless of the feed rate or hardness of planed material.

CAM-WOOD WP-4S-500-2C 4-SIDED, 19-5/8" WIDE X UP TO 20" HIGH PLANER SPECIFICATIONS FOR 6"; X 19-5/8"; HEAVY-DUTY PLANER: -- Width Capacity from 2-3/4" to 19-5/8" -- Thickness Capacity from 3/4" to 6"; (see options for taller side spindles) -- Variable Feed Speeds from 18 to 75 FPM (higher on request) -- 25 HP Top and Bottom Spindle Motors -- 20 HP Left and Right Vertical Spindle Motors -- (2) 1/2 HP Left & Right Chamfer Motor -- (2) 7-1/2 HP Feed Motors -- Belt-driven, high speed, 7,000 RPM spindle speeds. -- TEFC motors with sealed-for-life ball bearings provide accurate, vibration-free spindle vibration. -- Top & Bottom Cutterhead Dia. 5" -- Right & Left Cutterhead Dia. 5" or 6" -- Top & Bottom Spindle Dia. 60 mm -- Right & Left Spindle Dia. 40 mm (1-13/16" available) -- Chamfer Spindle Dia. 30 mm -- Insert Cutter Size 15 x 15 x 2.5 mm -- (4) 6" Diameter Dust Hood -- Machine Size 110" x 86" x 94" x net 15,200 Lbs. Additional Equipment and Options: -- Right side fixed fence (no charge) -- Change side head spindle rotation to rotate with the direction of feed (no charge) -- 1-13/16" side spindle dia. (no charge) -- Top & bottom spindle rotation against the direction of feed (standard) -- Wired for 480-Volt operation (no charge). -- Pair Auto-Set and Power Raise/Lower of right and left side spindles (included). -- Pair Spindle Brake on right and left side spindles (included). -- 12"; High side spindle with outboard bearing, add $19,000 -- 16"; high side spindle with outboard bearing, add $25,500 -- 20"; high side spindle with outboard bearing, add 30,700. FEATURES: -- Compact construction, huge moulding or planing capacity, extremely flexible and high-performance design. -- Digital controller automatically sets thickness & width adjustment -- Rigidly mounted alloy steel spindles with outboard bearing support provide accurate vibration-free power transfer. -- Spindle height adjustment by precision rack & gear sets -- Beds and fences are precision ground then chrome-plated and polished to a smooth mirror finish. The wear resistant surfaces are easy to clean and maintain -- Variable speed invertor controls for smooth adjustment of feed rate depending on the material hardness, depth of cut & width will provide the best finish surface and fast cutting performance -- The floating powered feed rollers are driven by geared transmission boxes linked to the feed rolls by heavy-duty universal joint axels while firmly holding stock securely to the bed; feeds positively to provide a smooth, even feed rate during rough or finish planning -- The heavy-duty welded and heat treated steel frame supports the beds and helps dampen vibration while safeguarding future years of dependable service -- Industrial rated motors for maximum stock removal and feed rates -- Precision sealed, long-life bearings throughout -- Removable cutter heads are designed for convenient knife changing even on the on the bottom cutterhead -- Changing

CAM-WOOD MODEL WP-4S 650 2C 25" 4-SIDED PLANER WITH MOULDING CAPABILITIES: -- WP-4S2C-650-6 25"; wide x 6"; high 4-Side Planer $189,900 -- WP-4S2C-650-12 25"; wide x 12"; high 4-Side Planer $208,900 -- WP-4S2C-650-16 25"; wide x 16"; high 4-Side Planer $226,900 -- WP-4S2C-650-20 25"; wide x 20"; high 4-Side Planer $238,900Designed for heavy furniture, cabinet, flooring, intermittent planing millwork, and other industrial uses. Perfect Planer for S2S and S4S planing up to 16" high x 25" wide timbers, tongue & groove flooring, wall paneling, etc. up to approximately 75 FPM depending on depth of cuts and dimensions of parts.SPECIFICATIONS: -- Width capacity from 2-3/4"; to 25";. -- Thickness capacity from 3/4"; to 6";. (up to 16"; with O/B Bearings is optional) -- Feed speeds variable from 18 to 65 FPM -- 15 HP Bottom head motor (20 HP optional) -- 20 HP Top head motor (25 HP optional) -- 20 HP Left (outside) spindle motor -- 15 HP Right (inside) spindle motor -- 1/2 HP motors on right & left champhering (top eased edge) spindles -- 10 HP feed motor -- 5"; dia. top and bottom cutterheads -- 5"; or 6"; dia. right & left cutterheads -- 60 mm (2.362";) dia. spindles on top and bottom heads -- 40 mm (1.574";) dia. spindles on top and bottom heads -- 30 mm (1.181") champhering spindles -- 15 x 15 x 2.5 mm insert knives -- (4) Dust outlets, each 6"; diameter -- Planer measurements: 110"; long x 91"; wide x 94"; high -- Planer weighs 19,500 Lbs. FEATURES: -- Compact construction with planing and moulding capabilities; provides flexible performance at an affordable price -- Equipped with a digital controller to set thickness & width automatically -- Rigidly mounted alloy steel spindle with outboard bearing support for accurate, vibration-free planing surfaces on horizontal spindles -- Spindle height adjustment by precision rack & pinion gear sets. -- Bedplates are precision ground, chrome-plated and polished to a mirror finish; provide a smooth, wear-resistant surface -- Variable speed inverter control for smooth feed speed adjustment depending on lumber hardness, depth of cut & width. Speed adjusts to provide the best finish and highest speed for best overall performance. -- Feed rolls are driven by geared transmission boxes and drive shafts with heavy-duty universal joints and drive shafts; provide smooth, even feeding for rough or finish planing -- Heavy fabricated steel plate frame, heated and stress relieved for vibration-free finishes, supports the worktable and helps dampen vibration for a superior finish. Ensures years of dependable service -- Industrial-grade, standard off-the-shelf motors for maximum cutting capacity and ease of service -- Bearings are precision, sealed, long-life bearings for durability and service life -- Removable cutterheads on all spindles, designed for convenient knife changing or rotating, including the bottom head. -- Changing or rotating knives on the top head only requires r
