CAM-WOOD SM-732 HS 7-Heads High-Speed Trough Feed Moulder(7) Heads (B-R-L-T-T- T-B), working cap. 111 13/16" x 6-1/4"".Specifications: -- Max/Min working width 11 13/16" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 20 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP, top 15 HP and bottom 15 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,000 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- PNEUMATIC LOAD INFEED SIDE PRESSUREWhile high speed feeding, the side pressure on infeed table ensures every timber close to the fence even under different width. It's convenient to adjust quickly. --OVER HEiGHT PROTECTIONIn case workpiece exceeds the rated maximum height, it will be restricted by the over height protection device provided at the workpiece infeed end. -- HYDRAULIC OUT-BOARD BEARING SUPPORT TOP AND BOTTOM SPINDLESpecially designed hydraulic supports on the top and bottom spindles assure maximum stability while performing high speed and heavy duty machining. -- PNEUMATIC LOAD SIDE PRESSURE WHEELS The front side air pressure wheel on left vertical spindle fully eliminates problem when feeding short or narrow stock not smoothly. The pressure plate is easy and quickly to adjust. -- PNEUMATIC LOAD TOP PRESSURE PLATEThe front pressure plate for top spindle is available to apply an air loading device ensuring maximum stability while performing high speed cutting -- CENTERAL LUBRICATION POINTThe lubrication point are located at the centralized plate for convenience. -- POWERED INFEED TABLE ROLLER The roller in the infeed table is powered, providing a smooth feeding effect for feed stock. -- VERTICAL SPINDLE AXIAL ADJUSTMENT UP TO 60MMIt allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. The 60mm spindle adjustment provides full utilization for a single cutter. -- CENTRALIZED PRESSURE ADJUSTMENT• All pressure regulations for the entire pneumatic system are centralized at the front of the machine for added convenience in pressure adjustment, and sectional pressure adjustments for all pressure rollers ensure consistent pressure.• Clear numerical indicators are provided to correspond directly to the pneumatic mechanisms on the machine, allowing operators to make adjustments based on different processing requirementsAvailable options: -- Automatic Jointer for all (6) heads add: ...$45,600 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control sys

CAM-WOOD SM-545 HS 5-Heads High-Speed Trough Feed /Planer/Moulder(5) Heads (B-R-L-T-T), working cap. 450 mm X 160 mm (17-7" x 6-1/4").Specifications: -- Max/Min working width 17.7" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, and top or bottom 20 HP . -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications)

CAM-WOOD PL-24 TOP & BOTTOM STRAIGHTENING PLANER8" x 24" Capacity Planer for accurate and powerful two-sided planing in one pass.Includes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $3,000 Specifications: -- 25"; Max. Planning Width, 3/8" to 8"; Max. Planning Thickness. -- 1/4";Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 70 FPM Feed Speeds (Variable). -- 4,200 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges -- 25 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor and 1/2 HP Elevation Motor. -- Net weight 7,200 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-fre

CAM-WOOD PL-18 18" Wide Top & Bottom Straightening Planer. -- 18" Planer with straight knife heads with HSS knives for accurate and powerful two-sided planning in one pass.ADD for Spiral Heads with Carbide Insert Knives... $4,000.00Replacement Knives:CT-SCH-14T 14 mm wide x 2.0 mm thick Spiral Knives - $2.90 EACHCT-SCH-15T 15 mm wide x 2.5 mm thick Spiral Knives - $3.60 EACHSpecifications: -- 17-3/4"; Max. Planning Width. -- 3/8 to 8" Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 10"; Min. Planning Length. -- 15 to 70 FPM Feeding Speed (Inverter Driven). -- 4,200 RPM Cutter Straight Knife Head Speed. (6,000 RPM for Spiral Cutter Head). -- (4) Knife Cutterheads. -- 15 HP Upper Motor. -- 10 HP Bottom Motor. -- 2 HP Feed Motor. -- 1/2 HP Elevation Motor. -- Table Size (L x W) 88" x 16". -- N.W. 6,500 Lbs.Features: -- Standard equipped with automatic thickness controller, easy, accurate and quick setting for the cutting thickness. -- Upper & lower straight knives or spiral cutterheads for accurate and powerful two-sided planing in one pass. -- The worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planning. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing of the surface can be performed to prevent jumping during processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with heavy-duty drive chains and gears to provide a smooth even feeding during rough or finish planning. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- The heavy-duty rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial motor for maximum cutting capacity. -- All precision sealed long-life bearing for durability -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Changing the knife on the upper cutterhead only requires removal of the upper dust chute. -- The optional spiral insert head design allows for fast, accurate insert changes and minimum down time. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth cha

CAM-WOOD PL-38 TOP & BOTTOM STRAIGHTENING PLANERIncludes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Insert Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $8,000Specifications: -- 3" to 38"; Max. Planning Width -- 3/8" to 7"; Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 52 FPM Feed Speeds (Variable). -- 4,000 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges 40 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor -- 2 HP Elevation Motor. -- Net weight 9,800 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-free planing regardless of the feed rate or hardness of planed material.

CAM-WOOD WP-4S-500-2C 4-SIDED, 19-5/8" WIDE X UP TO 20" HIGH PLANER SPECIFICATIONS FOR 6"; X 19-5/8"; HEAVY-DUTY PLANER: -- Width Capacity from 2-3/4" to 19-5/8" -- Thickness Capacity from 3/4" to 6"; (see options for taller side spindles) -- Variable Feed Speeds from 18 to 75 FPM (higher on request) -- 25 HP Top and Bottom Spindle Motors -- 20 HP Left and Right Vertical Spindle Motors -- (2) 1/2 HP Left & Right Chamfer Motor -- (2) 7-1/2 HP Feed Motors -- Belt-driven, high speed, 7,000 RPM spindle speeds. -- TEFC motors with sealed-for-life ball bearings provide accurate, vibration-free spindle vibration. -- Top & Bottom Cutterhead Dia. 5" -- Right & Left Cutterhead Dia. 5" or 6" -- Top & Bottom Spindle Dia. 60 mm -- Right & Left Spindle Dia. 40 mm (1-13/16" available) -- Chamfer Spindle Dia. 30 mm -- Insert Cutter Size 15 x 15 x 2.5 mm -- (4) 6" Diameter Dust Hood -- Machine Size 110" x 86" x 94" x net 15,200 Lbs. Additional Equipment and Options: -- Right side fixed fence (no charge) -- Change side head spindle rotation to rotate with the direction of feed (no charge) -- 1-13/16" side spindle dia. (no charge) -- Top & bottom spindle rotation against the direction of feed (standard) -- Wired for 480-Volt operation (no charge). -- Pair Auto-Set and Power Raise/Lower of right and left side spindles (included). -- Pair Spindle Brake on right and left side spindles (included). -- 12"; High side spindle with outboard bearing, add $19,000 -- 16"; high side spindle with outboard bearing, add $25,500 -- 20"; high side spindle with outboard bearing, add 30,700. FEATURES: -- Compact construction, huge moulding or planing capacity, extremely flexible and high-performance design. -- Digital controller automatically sets thickness & width adjustment -- Rigidly mounted alloy steel spindles with outboard bearing support provide accurate vibration-free power transfer. -- Spindle height adjustment by precision rack & gear sets -- Beds and fences are precision ground then chrome-plated and polished to a smooth mirror finish. The wear resistant surfaces are easy to clean and maintain -- Variable speed invertor controls for smooth adjustment of feed rate depending on the material hardness, depth of cut & width will provide the best finish surface and fast cutting performance -- The floating powered feed rollers are driven by geared transmission boxes linked to the feed rolls by heavy-duty universal joint axels while firmly holding stock securely to the bed; feeds positively to provide a smooth, even feed rate during rough or finish planning -- The heavy-duty welded and heat treated steel frame supports the beds and helps dampen vibration while safeguarding future years of dependable service -- Industrial rated motors for maximum stock removal and feed rates -- Precision sealed, long-life bearings throughout -- Removable cutter heads are designed for convenient knife changing even on the on the bottom cutterhead -- Changing

CAM-WOOD MODEL WP-4S 650 2C 25" 4-SIDED PLANER WITH MOULDING CAPABILITIES: -- WP-4S2C-650-6 25"; wide x 6"; high 4-Side Planer $189,900 -- WP-4S2C-650-12 25"; wide x 12"; high 4-Side Planer $208,900 -- WP-4S2C-650-16 25"; wide x 16"; high 4-Side Planer $226,900 -- WP-4S2C-650-20 25"; wide x 20"; high 4-Side Planer $238,900Designed for heavy furniture, cabinet, flooring, intermittent planing millwork, and other industrial uses. Perfect Planer for S2S and S4S planing up to 16" high x 25" wide timbers, tongue & groove flooring, wall paneling, etc. up to approximately 75 FPM depending on depth of cuts and dimensions of parts.SPECIFICATIONS: -- Width capacity from 2-3/4"; to 25";. -- Thickness capacity from 3/4"; to 6";. (up to 16"; with O/B Bearings is optional) -- Feed speeds variable from 18 to 65 FPM -- 15 HP Bottom head motor (20 HP optional) -- 20 HP Top head motor (25 HP optional) -- 20 HP Left (outside) spindle motor -- 15 HP Right (inside) spindle motor -- 1/2 HP motors on right & left champhering (top eased edge) spindles -- 10 HP feed motor -- 5"; dia. top and bottom cutterheads -- 5"; or 6"; dia. right & left cutterheads -- 60 mm (2.362";) dia. spindles on top and bottom heads -- 40 mm (1.574";) dia. spindles on top and bottom heads -- 30 mm (1.181") champhering spindles -- 15 x 15 x 2.5 mm insert knives -- (4) Dust outlets, each 6"; diameter -- Planer measurements: 110"; long x 91"; wide x 94"; high -- Planer weighs 19,500 Lbs. FEATURES: -- Compact construction with planing and moulding capabilities; provides flexible performance at an affordable price -- Equipped with a digital controller to set thickness & width automatically -- Rigidly mounted alloy steel spindle with outboard bearing support for accurate, vibration-free planing surfaces on horizontal spindles -- Spindle height adjustment by precision rack & pinion gear sets. -- Bedplates are precision ground, chrome-plated and polished to a mirror finish; provide a smooth, wear-resistant surface -- Variable speed inverter control for smooth feed speed adjustment depending on lumber hardness, depth of cut & width. Speed adjusts to provide the best finish and highest speed for best overall performance. -- Feed rolls are driven by geared transmission boxes and drive shafts with heavy-duty universal joints and drive shafts; provide smooth, even feeding for rough or finish planing -- Heavy fabricated steel plate frame, heated and stress relieved for vibration-free finishes, supports the worktable and helps dampen vibration for a superior finish. Ensures years of dependable service -- Industrial-grade, standard off-the-shelf motors for maximum cutting capacity and ease of service -- Bearings are precision, sealed, long-life bearings for durability and service life -- Removable cutterheads on all spindles, designed for convenient knife changing or rotating, including the bottom head. -- Changing or rotating knives on the top head only requires r

CAM-WOOD SM-124TAX 4-Sided Planer/Moulder; 11-3/4"; Wide x 4" to 9"; HighCompact construction with moulding & planing capabilities and flexible performance at an attractive price. Designed for furniture, cabinet, and yes, even industrial arts and large hobby shops. The perfect machine for tongue & groove flooring, wall paneling, S4S work, etc. Specifications: -- 2-Sided Planing Capacity: 7/16"; to 9"; thick x 11-5/8"; wide -- 4-Sided Planing Capacity: 7/16"; to 9"; thick x 10-1/4"; wide. -- All cutters run at 7,000 RPM -- Top and bottom heads are 2-27/32"; (72 mm) diameter. -- Right and left side heads are 3-1/2"; (90 mm) diameter -- All spindles powered by 4.1 HP (3 kW) motors -- Top Spindle will profile to a 3/8"; pattern depth and 5/16"; max. stock removal when planing. -- Bottom Spindle will profile to a 3/16"; pattern depth and 3/16"; max. stock removal when planing. -- Right & left side spindles are 4"; long and have a max. moulding depth of 13/16";. -- Machined and hard chromed table is 24"; wide x 40"; long and travels 9"; (230 mm) vertically -- Feed system runs at 11 to 52 FPM and is powered by a 1/2 HP variable speed drive. -- Overall dimensions are 54"; long x 42"; wide x 44"; high and weighs 1,370 Lbs.Features: -- Large 11-5/8"; wide x 9"; thick 2-sided planing capacity or 10-1/4"; wide x 4"; thick 4-sided planing and moulding work. -- Individual motors drive each spindle; 7,000 RPM spindle speeds on all heads. -- Mechanical meter for accurate thickness adjustments. -- Heavy-duty spindle assemblies for durability & run-out free finishes. -- Rigidly mounted alloy steel spindles in precision bearings provide accurate and vibration-free power transfer. -- Spindle height adjustment by precision rack & pinion gear system. -- Compact construction, Heavy-duty welded steel frame and See through top guard. -- Magnetic overload switch for protection. -- Industrial-rated TEFC motors with sealed-for-life ball bearings.

CAM-WOOD TYPE F1, MODEL FAH 8" X 20’ AUTOMATIC HORIZONTAL FINGER JOINT SYSTEM - SINGLE CHAIN TYPE (including Feeding System from Optimizing saw)Technical Specifications: -- Working thickness: 17 mm to 60 mm (0.66" to 2-3/8") -- Working width: 25 mm to 205 mm ( 1" to 8") -- Maximum finish length: 6.2 Meters ( 20') -- Glue type: PVAC -- Timber moisture: 8% to 12% -- Infeed quality must be S4S with tolerance +/- 02 mm, wood need 90° right angle and straight MECHANICAL SPECIFICATIONS FOR THE FEED SYSTEM: -- Operating speed: 120 to 180 lugs/Min -- Intermittent feed motor: 2 HP + 1:25 -- Feed chain motor: 30 HP (20 kW) Servo Drive (C2) MECHANICAL SPECIFICATIONS: RIGHT-SIDE SHAPER: -- Cutterhead Motor: 25 HP -- Spindle size: 2-3/4"; (70 mm) -- Maximum cutter head body diameter: 10"; -- Cutterhead speed: 5,500 RPM at 60 Hz -- Trim Saw Motor: 15 HP -- Trim Saw blade size: 12"; (305 mm) x 80 Tooth x 5 mm kerf -- Cut-off saw Speed: 4,300 RPM -- Scoring saw motor: 3 HP -- Scoring saw blade: 7"; (180 mm) x 50 Tooth x 5 mm -- Scoring saw spindle speed: 4,200 RPM -- Holddown rise and lower motor: 1/2 HP (C3) MECHANICAL SPECIFICATIONS: LEFT-SIDE SHAPER: -- Cutterhead Motor: 25 HP -- Spindle size: 2-3/4"; (70 mm) -- Maximum cutter head body diameter: 10"; -- Cutterhead speed: 5,500 RPM at 60 Hz -- Trim Saw Motor: 15 HP -- Trim Saw blade size: 12"; (305 mm) x 80 Tooth x 5 mm kerf -- Cut-off saw Speed: 4,300 RPM -- Scoring saw motor: 3 HP -- Scoring saw blade: 7"; (180 mm) x 50 Tooth x 5 mm -- Scoring saw spindle speed: 4,200 RPM -- Holddown rise and lower motor: 1/2 HP -- Glue Application by GLUE COMB -- Standard glue height: 6"; High, 3.8 mm pitch 3.8 mm. Finger lengths from 10 to 12 mm (Other lengths available) (K) MECHANICAL SPECIFICATIONS: SHAPER OUT-FEED: -- Working size: Length 150 mm to 900 mm ( 6" to 35-7/16"); Width 25 to 205 mm (1" to 8") -- Speed: 70 m/Min ( 230 FPM) -- Infeed inverter : (1) 3 HP -- Vacuum device blower with 3"; Vacuum port: 5 HP (G) MECHANICAL SPECIFICATIONS: PRE-JOINT ASSEMBLY: -- Working size: Thickness 17 mm to 60 mm (5/8" to 2,3/8"); Width 25 mm to 205 mm (1" to 8") --Feed chain drive: (2) 3 HP motors --In-feed Inverter: (1) 7-1/2 HP --Chain type: Flat top double chain --Feeding speeds from 10 to 90 m/Min (32 to 292 FPM) (H) MECHANICAL SPECIFICATIONS: 20’ (6.2 M) ASSEMBLY PRESS: --Working dimension: 3/4"; to 8"; wide x 0.60"; to 2-3/8"; high x up to 20’ long --Upper & lower roll power: (2) 2 HP motors --In-feed Inverter: 7-1/2 HP --In-feed speed: 10 m to 70 m/Min (32 to 227 FPM) --PROGRAMMABLE Cut-off saw power: 5 HP --Cut-off Blade dimensions: 14"; Dia. x 120 Tooth x 1"; bore --Cut-off saw speed: 2,850 RPM --Hydraulic power: 5 HP (With high-speed oil tank) --Cycle Speed: 1 to 6 Cy/MinPRODUCTION CAPACITY - PARAMETERS: -- Based on a 480-minute shift -- Finger length to customer’s specifications -- Average infeed length at the shaper section is 500 mm (20";) --Average block cros

CAM-WOOD Continuous in-line Long Board Vertical Finger Joint System, Model "UCT-305"Up to 12"; Wide x 4-1/4" Thick x Unlimited Assembled Length System Specifications: -- Incoming board lengths from 39"; to 236" (1,000 mm - 6,0000 mm). -- Board widths from 2"; to 12"; (50 mm - 305 mm). -- Board thickness from 1" to 4.3"; (25 mm - 110 MM). -- Board out-feed length 40’. (could be increase with outfeed conveyor) -- Glue type to be used: PVAC. (Glue pump and applicator not included) -- Board species: SOFTWOOD and HARDWOOD. -- Board moisture content: 8% to 12%. -- Infeed board qualities: Lumber runs best on Finger Jointers when surfaced on (4) sides (S4S) (Tolerance +/- .2 mm (.008"). System prefers straight boards with 90-degree corners. UCT-305 Mechanical Specifications: -- Top infeed feed rolls powered with (2) 2HP motors. -- Bottom infeed feed rolls powered with (2) 2 HP motors. -- In-feed Inverter with (2) 7.5 HP motors. -- Auxiliary conveyor wheel with 2.6 HP servo motor. -- Top Shaper Spindle powered with a 30 HP motor. -- Bottom Shaper Spindle powered with a 30 HP motor. -- Maximum Cutterhead length, 12“(305 mm). -- Maximum Cutterhead diameter, 6.3“(160 mm). -- Typical cutter pitch, 4.0 mm. Length, 10 mm - 12 mm (Other sizes available). -- Shaper spindle moving power by 2.6 HP Servo Motor. -- In-feed speed from 32 to 295 FPM (10 ~90 m/Min). -- Outfeed cut-off saw motor, 10 HP. -- Cut-off sawblade, 24“ dia x 120 teeth (included). -- Cut-off sawblade speed, 2,850 RPM. -- Hydraulic pump power, 30 HP. -- Outfeed conveyor, (2) 2 HP drives. -- Top outfeed feed rolls powered with (2) 2 HP motors. -- Lower outfeed feed rolls powered with (2) 2HP motors. -- Out-feed Inverter with (2) 7.5 HP motors. -- Glue injection Glue Applicator for Standard PVAC glue. (glue pump not included) -- Hydraulic oil tank with 150-gal capacity (oil not included)Outfeed options: -- Outfeed roller conveyor 20'' X 8' long Additional: $ 4,890 per sectionNot included with the machine: -- Cutter heads for finger jointer (we can provide quote) -- Gluing system with pump and nozzle Optional Cross Infeed Conveyor System: -- 8’ X 19’ Lateral Long Infeed Conveyor System To Meet Production Requirement. -- Working size accepts inbound boards from 39"40"; to 236" long x 2"; to 12"; wide x 1"; to 4-1/4"; thick. -- Cross feed system 3 HP drive motor. -- Feed speed 48.75 FPM. (15M/Min) -- 8’ (2,500 mm) Buffer Chains.Additional: $28,990NOTE: Training, installation & tooling not included TO BE PROVIDED LOCALLY -- Electric power supply to Motor Control Center -- Constant voltage (voltage deviations max.: 5%) -- Temperature range for computer control should not exceed 95°F. -- 65% Maximum relative air humidity for computer control system --Dust exhaust system: (V=30M/S at a low pressure of 12M BAR) --Compressed air connection to machinery: 7~8 KG/cm² – 8 BAR --Electrical cabling, dust collecting ductwork. --Hydraulic oil --Skilled operating an

CAM-WOOD IAT 620-100HX INVERTER DRIVEN FINGER JOINT SYSTEM 3" X 6" X 16.5 feet long medium capacity Finger Jointing SystemIncoming Block Specifications: -- Incoming block lengths from 6"; to 31.5"; -- Blocks must be at least 50% longer than their width. -- Block thickness from 1/2"; to 3" -- Block width from 1"; to 6" -- Assembled lengths from 10’ to 16’ (Options 20’ or 24’) -- For use with PVAC adhesives (glue pump and nozzle not included) -- Works equally well with soft and hardwoods. -- Moisture content from 8 to 12% -- Blocks to be surfaced on (4) sides through a Moulder or 4-sided Planer to ± 0.2 mm with 90° right angle corners.Lay-Up and Block-Staging Infeed Conveyor: -- 24" Wide x 31.5" long belt conveyor powered with 1/2 HP motors. The conveyor is controlled by the operating system. Feeds at a constant rate of 180 FPM. Block delivery is controlled by the operator and machine system criteria to feed the Shaper. The conveyor facilitates keeping the system full and productive. FSR-62I Right Hand Inverter Type Finger Joint Shaper: -- Feed table is 24" wide and accepts blocks from 6" to 31.5" long -- 5/8" to 6" width -- 1/2" to 3" thickness -- Shaper spindle is driven by a 20 HP motor and is equipped with provisions for vertical adjustment of 20 mm up and 20 mm down. Spindle diameter is 50 mm and runs at 6,600 RPM. 6.3"; (160 mm) maximum shaper cutterhead diameter (cutter head not included) -- 5 HP - 4,800 RPM Cutoff and trim saw; accepts 10" dia. x 100 tooth x 5 mm blades. -- 2 HP - 2,850 RPM Scoring saw, accepts 7" dia. x 50 tooth x 5 mm blades. -- Conveyor powered by 1/2 HP motor. -- Table movement is inverter driven; powered by a 3 HP inverter motor with cycle speeds from 1 to 4 cycles per minute. Motor senses load and varies travel as needed. TC-62 Single Table Transfer Conveyor to the 2nd (Left Hand) Shaper: -- 24" Wide x 31.5" long belt conveyor. Powered with (1) 1/2 HP motor. Controlled by system criteria. Feeds at a constant rate of 180 FPM. FSL-62I Left Hand Inverter Type Finger Joint Shaper with Glue Extruder: -- Feed table is 24" wide and accepts blocks from 6" to 31.5" long -- 5/8" to 6" width. -- 1/2" to 4" thickness -- A 20 HP motor drives shaper spindle. Spindle diameter is 50 mm and runs at 6,600 RPM. 6.3" (160 mm) Maximum shaper cutterhead diameter (cutter head not included). -- 10 HP - 4,800 RPM Cutoff and trim saw; accepts 10" dia. x 100 tooth x 5 mm blades. -- 2 HP motor scoring saw, running at 2,850 RPM; accepts 7" dia. x 50 tooth x 5 mm blades. -- Conveyer powered by 1/2 HP motor. -- Table movement is Inverter driven; powered by a 3 HP inverter motor with cycle speeds from 1 to 4 cycles/Min. Motor senses the load and varies travel as needed. Speed is controlled by system criteria. Included Injection Type Glue Applicator: -- Extrudes adhesive into the fingers without a messy runoff. 4" Comb height is standard. -- Finger pitch 4 mm, 10 - 12 mm finger length is standard equipm

CAM-WOOD FJ-17 (FM) 6" X 16' Long Semi-Automatic Finger Jointer System(4) Version possible on this model. Choose the one that suits your needsTechnical Specifications:Incoming Block Requirements: -- Incoming block lengths No Limit (Manual Loaded). Blocks must be at least 50% longer than their width. -- Block thickness from 1/2"; to 3" -- Block width from 1"; to 6" -- Assembled lengths from 8’ to maximum 16’ or (20’ Options Add Extra ...$4,900.00) or 24’ (Options Add Extra ...$9,900.00) -- For use with PVAC adhesives Glue pump is not included -- Works equally well with soft and hardwood Blocks. Moisture content from 8 to 12% -- Blocks to be surfaced (4) sides through a Moulder or 4-sided Planer to ±0.2mm with 90° right angle cornersThis semi-automatic system is offered in (4) different versionsVersion 1: -- Finger Shaper (FSM-460A) + Conveyor (RO-62) x 2 + Assembly Press (FJ-500A) The price: $82,900.001. Semi-Auto Finger Shaper Process the finger at one side 2. Manually flip/turn to the other side and make fingers again at the same shaper,3. Manual blush applied the glue,4. Semi-Automatic finger jointer press The price: $82,900.00Version2: -- Finger Shaper (FSM-460A) + Conveyor (RO-62) x 2 + Manual Gluer (FSH-150) + Assembly Press (FJ-500A) 1. Semi-Auto Finger Shaper Process the finger at one side.2. Manually flip/turn to the other side and make fingers again at the same shaper,3. Manual Glue Spreader applied the glue,4. Semi-Automatic finger jointer pressThe price: $92,990Version 3: -- Finger Shaper with Gluer (FSM-621) + Conveyor (RO-62) x 2 + Assembly Press (FJ-500A) 1. Semi-Auto Finger Shaper Process the finger at one side.2. Manually flip/turn to the other side and make fingers again at the same shaper,3. Automatic Glue Spreader applied the glue at the second finger process,4. Semi-Automatic finger jointer press The price: ...$104,900Version 4:Finger Shaper (FSM-460A) + RO-62 x 3 + Finger Shaper with Gluer (FSM-621) + Assembly Press (FJ-500A)1. Semi-Auto Finger Shaper Process the finger at one side.2. Push to the next (2nd) Semi-automatic finger shaper with Auto Glue Spreader and applied the glue at the other side,3. Semi-Automatic finger jointer pressThe price: ...$ 143.900Description of Each Unit:FSM-460A Semi-auto finger shaper (Air-hydraulic type) -- Working timber width (Horizontal Direction); 1"; to 6"; -- Maximum timber total width fit on working table 18"; -- Maximum working height (Vertical direction); 4"; -- Maximum timber thickness (Height feed into assembly press); 3"; -- Working timber length; No Limit (Timber length must be at least 50% longer than the timber width to be processed.) -- Trim saw/Hogging blade 180 mm x 50T x 5 mm x 1 pcs. Trim/Hogging saw speed; 2,850 RPM -- Trim/Hogging saw motor 5 HP x 1 -- Finger shaper motor; 10 HP x 1 . Finger spindle Speed; 5,500 RPM. Spindle size; 50 mm, OD of finger cutter; OD160 mm -- Table movement by pneumatic–hydraulic cylinder -- Cycle time 2 to

CAM-WOOD Continuous in-line Long Board Vertical Finger Joint System, Model "UCT-200"Up to 200 mm (7.87") Wide x 75 mm (2.95")4-1/4" Thick x Unlimited Assembled Length System Specifications: -- Incoming board lengths from 39"; to 236" (1,000 mm - 6,0000 mm). -- Board widths from 2"; to 7.87"; (50 mm - 200 mm). -- Board thickness from 1" to 2.95"; (25 mm - 75 MM). -- Board out-feed length unlimited (Conveyor to be quoted separately) -- Glue type to be used: PVAC. with Standard pneumatic pump and spreader included ( For different glue then PVAC Glue pump and applicator not included) -- Board species: SOFTWOOD and HARDWOOD. -- Board moisture content: 8% to 12%. -- Infeed board qualities: Lumber runs best on Finger Jointers when surfaced on (4) sides (S4S) (Tolerance +/- .2 mm (.008"). System prefers straight boards with 90-degree corners. UCT-200 Mechanical Specifications: -- Top infeed feed rolls powered with (2) 2HP motors. -- Bottom infeed feed rolls powered with (2) 2 HP motors. -- In-feed Inverter with (2) 7.5 HP motors. -- Auxiliary conveyor wheel with 2.6 HP servo motor. -- Top Shaper Spindle powered with a 30 HP motor. -- Bottom Shaper Spindle powered with a 30 HP motor. -- Maximum Cutterhead length, 12“(305 mm). -- Maximum Cutterhead diameter, 6.3“(160 mm). -- Typical cutter pitch, 4.0 mm. Length, 10 mm - 12 mm (Other sizes available). -- Shaper spindle moving power by 2.6 HP Servo Motor. -- In-feed speed from 32 to 295 FPM (10 ~90 m/Min). -- Outfeed cut-off saw motor, 10 HP. -- Cut-off sawblade, 24“ dia x 120 teeth (included). -- Cut-off sawblade speed, 2,850 RPM. -- Hydraulic pump power, 30 HP. -- Top outfeed feed rolls powered with (2) 2 HP motors. -- Lower outfeed feed rolls powered with (2) 2HP motors. -- Out-feed Inverter with (2) 7.5 HP motors. -- Glue injection Glue Applicator for Standard PVAC glue. -- Hydraulic oil tank with 150-gal capacity (oil not included)Outfeed options: -- Outfeed roller conveyor 20'' X 8' long Additional: $ 4,890 per sectionNot included with the machine: -- Cutter heads for finger jointer (we can provide quote) -- Gluing system with pump and nozzle if different then PVAC glue Optional Cross Infeed Conveyor System: -- 8’ X 19’ Lateral Long Infeed Conveyor System To Meet Production Requirement. -- Working size accepts inbound boards from 39" to 236" long x 2"; to 12"; wide x 1"; to 4-1/4"; thick. -- Cross feed system 3 HP drive motor. -- Feed speed 48.75 FPM. (15M/Min) -- 8’ (2,500 mm) Buffer Chains.Additional: $28,990NOTE: Training, installation & tooling not included TO BE PROVIDED LOCALLY -- Electric power supply to Motor Control Center -- Constant voltage (voltage deviations max.: 5%) -- Temperature range for computer control should not exceed 95°F. -- 65% Maximum relative air humidity for computer control system --Dust exhaust system: (V=30M/S at a low pressure of 12M BAR) --Compressed air connection to machinery: 7~8 KG/cm² – 8 BAR --Electrical cabling, du

CAM-WOOD TRS 150F Frame SawCAM-WOOD Frame Saws are engineered and designed to make extremely accurate cuts, cutting products with very tight tolerances up to 0.004" and often eliminating sanding before proceeding to the next step . The unique thin frame saw design accepts different saw frames, blade combinations, and allows multiple saw fence configurations to produce single, double or multiple cuts in a single pass.Specifications: -- 3/4" Min. to 6" max. working width; 1-1/4" min. to 7-3/4" max. working thickness (height); 7-1/2" minimum length; finished material > 0.1094". -- 0.043" to 0.055" Saw blade thickness; runs up to (22) blades at one time at (450) stroke/minute with a 8-1/4" stroke length; accommodates blades 1.575" wide x 19.685" long. -- Saw blade frame is powered by a 15 HP motor. Feed speeds of 1 to 5 FPM by 1 HP motor. -- Features automatic oil lubrication system requiring 90 PSI air pressure. Cooling system via water and air. -- Minimum kerf multi-blade frame saw designed to maximize production and minimize material losses to kerf. -- Machine supplied with PLC controller to allow operator fast, instant set-up changes. -- All controls are centrally located for the operator to easily adjust & control operation. -- Material waste reductions of up to 20% are achievable by use of the thin kerf blades (0.043" ~ 0.055"). -- A special air blast system cools the blade for longer service intervals and removes saw dust from the gullet of the blade to reduce temperature and increase blade life.Note: Frames are available in different configurations.

CAM-WOOD - XL 300, ...Dip Chain Gang Rip Saw: (...Typically in stock for immediate delivery!)12" Width cap.; 3/8" min. to 4-3/4"; max. cutting depth; 14"; min. stock length.Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0.25 mm (see drawing after the "literature link); with 12"; usable cutting width. -- Accepts saw blades from 12"; - 14"; dia.; arbor is powered by a 50 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 - 100 FPM; feed chain is 12"; wide. -- Table: 30"; Wide x 62"; with 12"; between the column and the 1st saw blade. - Integrated 6"; dia. dust extraction connection.General Description: -- Designed for high quality Production Line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence; equipped with: Measuring ruler gauge. -- Triple anti-kickback fingers mounted at the infeed side provide max. safety protection; (2) rows from the top and (1) row from the bottom. -- Heavy-Duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision built saw head ensures accuracy for straight line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- Power raise & lower to the arbor. -- (4) Pressure rollers & (2) holddown plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for max. motor power output and guarantees Heavy-Duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radial rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or longer length boards. Options when ordering with machine: -- (1) Set spare feed chain link, please add ...$ 86. -- (1) Set of arbor drive belts consisting of (6) matched belts, add ...$ 600. -- Additional saw sleeve with spacer set consisting of: (2) 50 mm, (3) 25 mm, (4) 10 mm, (18) 1 MM, (10) 0.5 mm, (8) 0.25 mm, Please add... $ 685.

CAM-WOOD MRS-340-1M Dip Chain Gang Ripsaw with one Shifting Blade:Specifications: -- Cutting width up to 13";; machine will pass thru 25-1/2"; -- 3"; Maximum depth of cut with 12"; diameter blades. - Will cut 4"; thick with 14"; blades (optional). -- With 70 mm saw spindle; accepts 90 mm bore sawblades -- With air-loaded pressure rolls, standard fence, and feed chain. -- Urethane Chain Pads and Pad Holders optional -- With (1) powered moveable blade and fixed blades. -- Moveable blade controlled with a joystick. -- With (10) push buttons for pre-programmed selective ripping -- The shifting blade moves at 20 to 80 mm/second (up to 3"; per second). -- Moveable saw blade traverses from 0.59" thru 13.38" -- 50 HP Saw arbor motor; -- 3 HP Feed motor with feed speeds from 15 to 130 FPM -- (2) 1/2 HP Lift motors for pressure rolls and saw arborOptional Equipment when ordered with the machine: -- TRS-FT AUTOMATIC INFEED CONVEYOR SYSTEM, with Movable Fence with Digital Display and Shifting Laser Light for Rip Width Setting: .. -- Hydraulic Quick Lock Spindle Assembly. The hydraulic locking spindle assembly is designed to provide for quick changeover between various ripping requirements. Simply turn the locking knob to pressurize the arbor and lock the blades in position. Turn it in the opposite direction to unlock the blades. The sawblades are mounted to solid steel blade collars: ... -- Additional Quick Set Mechanically-Locked Saw Collars for fast, accurate, sure holding of saw blades in any stationary position ... -- 60 HP Saw Arbor Motor: -- Additional 30 MW Laser Unit with Bracket & Wiring: ... -- Pneumatic Pressure to Hold Down Feed Rollers (In lieu of spring pressure). Provides better control of the product being fed. Each pressure roll is controlled by an individual pressure regulator: .. -- Short stock feeding device for 14"; blades (see specifications for cutting capacity information): -- Feed Chain with (69) Easily Replaceable Bolt in Cast Iron Pads. Allows for changing chain pads as they wear or get cut into rather than replacing the complete chain assembly. NOTE: Specially ground down to 0.06"; square tip for optimum hold with virtually no marking: ... -- Feed Chain with (69) Easily Replaceable Urethane Non-Marking Strip Inserts. Urethane is vulcanized to metal backing bars and bolted in place: ... -- 12" Dia. carbide tipped ripsaw blades, cuts up to 3" material: ... -- 14" Dia. carbide tipped ripsaw blades, cut's up to 4" material: ...NOTE: Foot Pedal seen in the photo is only used with a powered Infeed Table and is designed to release boards from the Feed Table.

CAM-WOOD XL300/5116 DIP CHAIN GANG RIPSAW12" Width cap.; 5-5/8"; max. cutting depth; 14"; min. stock length; Designed to meet the exacting standards required for high quality production line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances, and feature the newest designs for operator safety and volume productionSpecifications: -- Accepts saw blades from 12"; to 16"; diameter. -- Arbor is 70mm dia. with (2) keyways -- Saw arbor is powered by a 60 HP motor driving the spindle at 3,200 RPM; Soft start starters and low voltage controls are standard equipment. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 8 to 80 FPM; feed chain is 12"; wide -- Table is 28"; wide x 67"; and 12"; between the column and the 1st saw blade. -- (2) Integrated 6"; dia. dust extraction connections.Complete With: -- (1) 70 mm ID saw sleeve with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0,25 mm (see drawing after the "literature link). -- Two (2) rows of anti-kickback fingers mounted on the top and one (1) row from the bottom (total 3 rows) provides maximum safety protection. Equipped with: -- Precision fence ensures absolute accuracy between blade & fence, equipped with measuring ruler gauge. -- Power raise and lower to the arbor. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frame for durability usage. -- Variable feed speeds enables the machine to meet different work requirements. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain longevity smoothness -- Automatic chain lubrication device equipped with an alarm that sends signals upon a lack of lubrication oil. Features: -- Precision built saw head ensures accuracy for straight line rip saw operations. -- Four (4) bearing spindle ensures rigidity & long life. -- Saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue; spindle is heat treated, precision ground and balanced to provide the utmost in precision cutting performance -- Four (4) pressure rollers & two (2) hold-down plates for precise cutting of large and small workpieces. -- Ten (10) groove pulley and V-Belt arrangement ensures maximum motor output, excellent HP delivery to the saw spindle, and guarantees proper power transmission for heavy-duty multiple rip cutting. -- Adjustable guide rollers make cutting straight for slight radials material; they also secure glue joint at short pieces or long stacks.Options when ordered with machine: -- Additional saw sleeves (sleeve only), each, $315 -- Additional saw with spacer set consisting of: -- (2) 50 mm -- (3) 25 mm -- (4) 10 MM, -- (18) 1 MM -- (10) 0.5 MM -- (8) 0.25 MM -- Add per Sleeve with Spacer Set, $685 -- Laser Light with Mounting Bracket, each $980 -- Power raise & lower of the hold-down system when ordered with th

CAM-WOOD TRS-3200 SLAT RIPPER - (1) Horizontal Bottom Saw or Moulder Spindle Bottom;The machine can rip extremely narrow parts. Ideal for shutters, louver slats, yardsticks, etc.Features & Equipped with: -- Designed to meet the exacting standards required for high-quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- All of these features combine to show what true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy and is equipped with measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy-duty industrial TEFC motor ensures full-depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allow the machine to meet the cutting requirements of different materials. -- Saw head built to precise tolerances assures accuracy for all straight-line ripping operations and provides stellar cut quality. -- Top & bottom powered pneumatically tensioned feed rolls for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat-treated, precision ground, and balanced providing precise cutting performance.Specifications: -- 12"; Max. Cutting Width. -- 4-3/4"; Max. Cutting Depth. -- 10"; Min. Workpiece Length. -- 10"; to 16"; Dia. Sawblade Size. -- 4,000 RPM Spindle Speed. -- 12"; Spindle Length -- 70 mm Arbor Diameter (with 2-keyways). -- 30 HP Rip Saw Motor -- 3 HP Feed Motor. -- 12 to 60 FPM Feed Speed (Variable). -- 1 HP Feed Roll Elevating Motor. -- 1/2 HP Saw Arbor Elevating Motor.Footprint: 81" long x 40" wide x 60" high.

CAM-WOOD TRS-405-SS Short Stock Rip Saw ...with the following specifications and features:Specifications: -- Max cutting width: 12.6"; -- Min length part: 3.15"; -- Short stock ratio of thickness to length: 2:5 -- Distance from center of chain to throat, 30"; -- Saw arbor powered by 50 HP Std. - 30 HP, 60 HP and 75 HP optional -- Spindle speed, 3,200 RPM -- Sawblade diameter to thickness: 10"; dia = 2"; thick, 12"; dia = 3"; thick, 14"; dia = 4"; thick, 16"; dia = 5"; thick -- Sleeve diameter (sawblade bore), 70 mm -- Sawblade keyway, 2 each 20 mm wide -- Spacer size, 70 mm ID x 95 mm OD -- 2 HP feed motor, 3 HP optional -- Variable feed speeds from 20 to 80 FPM -- Head elevation powered by ¼ HP motor -- With (2) 6"; dia. dust outlets -- NET weight, 5,500 Lbs. Features and Benefits: -- Exclusive feed track - Design for short stock feed – see literature! -- Exclusive length capacity on a standard Gang Ripsaw, as short as 3";! -- Turn waste blocks into useable parts -- Pressure rolls supported from both sides hold stock securely for even, smooth ripping -- Pressure plate (hold-down shoe) supported from both sides; helps prevent split parts from damaging sawblades -- Power raise and lower for overhead pressure roll and hold-down assembly -- Variable feed speeds allow ripping a variety of material, hard or soft, thick or thin -- 2-Top and 1-bottom rows of kickback fingers plus side splitter guards provide operator safetyNOTE: ...Where have you seen a Gang Ripsaw capable of ripping as short as 3"!!! ...Also perfect for slats!

CAM-WOOD TRS-190-2VS 7.5"; x 6"; VERTICAL SPINDLE MOULDER FOR SMOOTH SLAT RIPPINGIncludes one setup including Splitter Set, Holddown Plate, Fence, Sawblades, and Spacers WORKING CAPACITY -- Working width: 3"; to 7-1/2"; -- Working height: 3/4"; to 6"; RIGHT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. LEFT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. SPINDLE COMPONENTS AND ASSEMBLY -- Precision spindles are manufactured from SCM-4 tool steel imported from MITSUBISHI Japan, heat treated to HR 46° (ROCKWELL C Scale) fitted with class 6 -- SKF-matched ball bearings then mated to precision machined spindle housings. -- The spindle body and bearing housing are burnished. -- Spindle hardness and accuracy, high precision SKF bearings, and precise spindle housing and bearing installation by SHEN KO provides a spindle assembly -- Capable of speeds to 9,000 RPM and will meet every user’s requirement. -- Spindles are powered by V-shaped belts (MITSUBISHI) without slippage. FEED SYSTEM -- Powered with a 5 HP motor -- Feed speed is infinitely variable by inverter drive from 20 to 120 FPM -- Infeed rolls consist of (3) top and (2) bottom-powered feed rolls. -- Outfeed with (1) set of top and bottom-powered feed rolls -- Pneumatic pressure to all (4) top feed rolls -- Top rolls with independent pressure adjustment -- All top and bottom feed are driven by a universal joint drive -- Feed rolls are 5-1/2"; diameter TABLE AND FENCE -- 4’ infeed table with (1) driven roller above the tablet -- Table is harden and chromed. -- Fence is harden PRESSURE ELEMENTS -- A pneumatic pressure plate assures stability during slicing -- Precision splitting wedge guide for saw kerf SETUP FEATURES -- Mechanical digital read-outs -- Mobile jog box for ease of setting up -- Central lubrication system for spindles -- Oil pump to remove the resin from table -- Each table has (2) holes for lubrication ELECTRICAL -- Operating voltage 230.460/575/600-volt, 60-cycle, 3-phase -- All “name brand"; electric components. -- Operating panel separate from motor control cabinet for ease of operation MISCELLANEOUS -- Machine cover/hood with a lamp for ease of set up -- Includes a toolbox and operator’s manual
