QUICK MACHINERY N-P50 Air Pod style Cold Press. -- Heavy Duty I-beam construction with machined steel plates for flat smooth pressing surface.Specifications: -- Platen pressing area size: 62" x 146" with side loading on 146" side (also available as end loading). -- 50 PSI Platen pressure over the entire surface area with 90 PSI supply air pressure. Pressure is applied by 12.8" dia. air pods with 5.9" stroke; (36) air pods total for this size press. -- (2) Pressure air pressure zones: 5' x 12' and 4' x 8'. -- Air powered raise and lower idler rollers in the bed of the press for loading & unloading panels; raising & lowering of idle conveyor roller tracks by control button on panel. -- Motorized Adjustable Daylight Opening from 2" to 40"; push button controls operate an electrically powered chain driven worm gear drive system for precise positioning of upper platen setting/opening. -- Controls: 60-Min cycle timers provide visual and audible signals at the end of each cycle and automatically releases platen air pressure at the end of each cycle if desired.

QUICK MACHINERY N-P80 Air Pod style Cold Press -- Heavy Duty I-beam construction with machined steel plates for flat smooth pressing surface. -- Specifications: -- Platen pressing area size: 38" x 98"; with end loading on 37" side. -- 80 PSI Platen pressure over the entire surface area with 105 PSI supply air pressure. Pressure is applied by 12.8" dia. air pods with 5.9" stroke; -- Air powered raise and lower idler rollers in the bed of the press for loading & unloading panels; raising & lowering of conveyor by control button on panel. -- Motorized Adjustable Daylight Opening from 1" to 40"; push button controls operate an electrically powered chain driven worm gear drive system for precise positioning of upper platen setting/opening. -- Controls: 60-Min cycle timers provide visual and audible signals at the end of each cycle and automatically releases platen air pressure at the end of each cycle if desired. -- Single platen 38" X 98". -- Optional: powered roller tracksSpecifications:QUICK Laminating Pod PressN-P80-03-08-EL-1PL-M-40-R-1Z• Maximum platen pressure: 81 psi at 90 psi supply pressure• Lower platen dimensions: 3' x 8' (38" x 98")• End-loading or Side-loading: End-loading• Number of upper platens: 1• Upper platen(s) dimensions: 3' x 8' (38" x 98")• Vertical opening: Motorized adjustable from 2" to 40"• Lower platen roller tracks: Yes, Non-powered roller tracks• Number of 12.8" diameter, 5.9" stroke air pods: 24• Number of air pressure zones: 1 -- The press model shown in pictures is a dual platen powered feed through end-load press.

QUICK MACHINERY N-P80 Air Pod style Cold Press. -- Heavy Duty I-beam construction with machined steel plates for flat smooth pressing surface.Specifications: -- Platen pressing area size: 49" x 97" with end loading on 49" side. -- 80 PSI Platen pressure over the entire surface area with 102 PSI supply air pressure. Pressure is applied by 12.8" dia. air pods with 5.9" stroke; (28) air pods total for this size press. -- Air powered raise and lower idler rollers in the bed of the press for loading & unloading panels; raising & lowering of conveyor by control button on panel. -- Motorized Adjustable Daylight Opening from 2" to 40"; push button controls operate an electrically powered chain driven worm gear drive system for precise positioning of upper platen setting/opening. -- Controls: 60-Min cycle timers provide visual and audible signals at the end of each cycle and automatically releases platen air pressure at the end of each cycle if desired. -- Single platen 49" X 97" . -- The press model shown in pictures is a dual platen powered feed through end load press. -- Actual model is N-P80-04-08-EL-1PL-M-40-R-1Z

QUICK MACHINERY N-P80 Air Pod style Cold Press. -- Heavy Duty I-beam construction with machined steel plates for flat smooth pressing surface.Specifications: -- Platen pressing area size: 62" x 146" with end loading on 62" side. -- 80 PSI Platen pressure over the entire surface area with 105 PSI supply air pressure. Pressure is applied by (60) 12.8" dia. air pods with 5.9" stroke; -- Air powered raise and lower idler rollers in the bed of the press for loading & unloading panels; raising & lowering of conveyor by control button on panel. -- Motorized Adjustable Daylight Opening from 2" to 40"; push button controls operate an electrically powered chain driven worm gear drive system for precise positioning of upper platen setting/opening. -- Controls: 60-Min cycle timers provide visual and audible signals at the end of each cycle and automatically releases platen air pressure at the end of each cycle if desired. -- Single platen 62" X 146". (2) Air pressure zones for upper platen: (4' x 8' and 5' x 12') -- Optional powered roller tracks for an additional fee. -- The press model shown in pictures is a dual platen powered feed through end load press. -- Actual model is N-P80-05-12-EL-1PL-M-40-2Z

QUICK MODEL L-HLPP-1-36-43-6 SINGLE SIDED HYDRAULIC LAMINATING PRESS FOR POSTS AND BEAMS: -- Number of working sections: 1 -- Maximum working length: 36'. The 36' length achieved by manufacturing the machines in two 18' long pieces; the two 18' pieces are then joined together, resulting in 36' total working length. -- Maximum working width: 43" -- Maximum working thickness: 6"Main Laminating Cylinders: -- Number of cylinders: (30) -- Size of cylinders: 80mm dia. x 80mm strokeHolddown Cylinders: -- Number of cylinders: (30) -- Size of cylinders: 40mm dia. x 150mm strokeSide Lift Cylinders: -- Number of cylinders: (2) per section = (4) -- Size of cylinders: 63mm dia.Hydraulics: -- Hydraulic pump drive motor: 7-1/2 HP -- Maximum pressure: 140kg/cm2 -- Maximum Holddown Cylinder Pressure: 50kg/cm2 -- Maximum Side Lift Cylinder Pressure: 50kg/cm2 -- NOTE: Shipped without hydraulic oil

QUICK L-HLPP-2-20-43-8-12 ...2-Sided Hydraulic Laminating Press: -- Number of working sections: (2) -- Working width, section #1: 6" and 8" -- Working width, section #2: 8", 10"; and 12" -- Maximum working length: 6,200mm (20.3') -- Maximum working height: 1,100mm (43.3") -- Pressure at the glue line: Up to 175 PSIMain Laminating Cylinders: -- Number of cylinders, section #1: (14) -- Number of cylinders, section #2: (21) -- Size of cylinders: 100 mm dia. x 80 mm strokeHolddown Cylinders: -- Number of cylinders, section #1: (14) -- Number of cylinders, section #2: (21) -- Size of cylinders: 40 mm dia. x 150 mm strokeLift Cylinders: -- Number of cylinders: (2) on each side = (4) -- Size of cylinders: 63 mm dia.Hydraulic Pump: -- Drive motor: 10 HP -- Maximum pressure: 140 kG/cm² -- Maximum Holddown Cylinder Pressure: 50 kG/cm² -- Maximum Side Lift Cylinder Pressure: 50 kG/cm² -- Shipped without hydraulic oil in the oil tank

QUICKWOOD CD2-300 Moulding & Profile Sander or Denibber;4-Head Brush Loading Sander, 12" width and 4" height cap., for 3-sided sanding & denibbing. Head Configuration: -- (2) "BH300" Overhead rotating abrasive/brush heads, both arbors equipped with a combination of abrasive and brush loadings, 12" long arbors, 12" max. dia. sanding discs. -- 0.75 HP Motor drives each arbor with inverter for 200 - 1,200 RPM arbor rotation speed. -- Right & Left ("BH-140" & "BH-100" respectively) side mounted rotating abrasive/brush heads. -- Tilting heads and adjustable in-and-out, 6" long arbor, 8" dia. sanding discs, 0.5 HP motor each head. -- 0" - 4" Max. manual part height adjustment via hand wheel; 57-1/2" long roller conveyor with PVC covered rollers, variable feed speed 10 - 60 FPM. -- Infeed & outfeed overhead holddown rolls and (1) between the top heads. Includes centralized control panel, hubs, abrasive, & brush. -- Can also be ordered with just (2) top heads or (3) heads, ie. Left or Right. Call for separate prices.

QUINCY - QMT15 ACA, ...Air Compressor (Rotary Screw) w/DryerSpecifications: -- 15 HP - 54.9 CFM @ 125 PSIG; 120-Gallon tank mounted with Refrigerated Dryer & Filters. Equipped with: -- 15 HP TEFC Motor; air-cooled aftercooler; high efficiency inlet filter; upward package air discharge; vibration isolation; Wye-Delta start. -- 54.9 CFM @ 125 PSIG; 69 dBA; 120-gal horizontal tank; refrigerated air dryer.Total operating hours: (29,407).Specifications subject to verification

QUINCY "QSV-40" 40 HP vacuum pump:550 ACFM, 29.9"HgV, Direct drive rotary screw vacuum, positive lubrication fluid pump. -- Equipped with:Modulating inlet valve, temperature regulating valve, and high discharge temperature shutdown system with manual reset. -- Complete with:Complete unit enclosure, gauges, exhaust separation system, spin-on fluid filter, and magnetic motor starter -- Additional:All service records from date of purchase. -- Quincy the OEM did 1 partial and 1 full tune up every year since purchase.

QUINCY QSVB-25ANN2C Vacuum Pump:25 HP "QSVB Series", 371 CFM, 29.9"HgV rotary screw vacuum, positive lubrication fluid pump; 3″ inlet and 2″ exhaust port.. -- Equipped with:Modulating inlet valve, temperature regulating valve, and high discharge temperature shutdown system with manual reset. -- Complete with:Control panel, electrical enclosure, gauges, exhaust separation system, spin-on fluid filter, and magnetic motor starter. NOTE: The pump only has 969.2 total hours on the meter

RADER - Trailer Dumper with 30 ft. Tipping DeckComes with the following components and features: -- This unit was installed at the current location in approx. 1971 and is reportedly in great working order and condition. -- Previously used for Dumping Wood Chip Trailers. -- Professional rigging and loading is available. Decks are often extended for longer (53 ft.) trailers.

RAIMANN Model ASA 1650, Veneer Patcher.Specifications: -- 61" Throat cap., 3 HP gear motor with new/rebuilt drive unit, strip type mechanical plug-feeder mechanism - cap. of up to (40) plugs/Min.; -- Thickness of veneer patchable 1/32" - 1/5" (0.08 mm - 0.2 mm) (softwoods), 1/20" - 3/16" (hardwoods). P-34 dies. -- Tool sequence: Veneer patch is cut by the table die and scrap is ejected into discharge chutes, veneer patch blank is then positioned against the underside of the table die, plug punch cuts replacement veneer patch from underside and patch is inserted into the proper position. -- Reconditioned by experts. -- Overall size: 10' 8" (3,250 mm) Length x 67" (1,700 mm) height; approx. weight 12,000 Lbs (5,450 kG). -- Optional Glue applicator add ...$9,975. -- Optional strip feeder add ...$6,750.Actual model is RAIMANN Model ASA 1650

RAIMANN (WEINIG) Variorip 310 M with Infeed and (2) Moving Blades SystemClean, very hard-to-find 2015 Weinig Raimann Variorip 310 M Optimizing Rip Saw with (2) moving blades and Infeed SystemSpecifications -- Working dims: Length 24″ to 184″; width to 12.2″ (310 mm) and thickness .59″ to 3.94″ (184″ is fence length) -- Cutting dims: Width min. 5/8″ (1st movable blade); min. 1-5/8″ to 10-1/4″ (2nd movable blade) and fixed pocket 1″ -- Production in auto mode 7 x 10′ boards per minute. -- Saw: 50 HP motor with arbor dimension of 2.6″; RPM of 4200. -- Quick fix arbor (hand turn nut) for position blades. -- Saw blade dia. 12″ to 14″ (300 - 350 mm). -- Blade positions by ball screw adjustment. -- Chain: Width 12-3/4″ steel chain with every 3rd link with spikes --. Automatic oiler for chain lubrication. -- The chain has auto shut-off when the oil level is low. Roto chain brush for continuous chain cleaning of debris. (4) set of antikickback fingers. -- Feed: Variable 26-157 FPM (8-48 m/min) with 3 HP motor.Equipped with and Features: -- Controller: Raimann TimberMAX, with 15″ color screen with storage for 100 cut lists, -- Production recording and yield. -- Also includes: (4) Lasers with mounts, spare parts, & manuals.Note: This was not a daily driver or a shift machine.Foot Print & Weight: Infeed is 3,306 Lbs and roughly 8' x 16'Saw is 4,603 Lbs and roughly 6' X 6'The saw slightly offsets the infeed. So the footprint together is a little larger.....probably closer to 9' x 23'

RAIMANN KR 310 2M Multiple Rip Saw System ( 2 Moving Blades )12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Equipped with:& Features -- Quick Fix arbor with: (2) Movable blade and (3) fixed blades; (5) Laser Lights. -- Enlarged movable saw housing with 25" pass through. Ball threaded adjustment of spindle. Saw blades mounted to individual collars. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler fo guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods. Raimtech E5 with TimberMax Software optimizing software; makes it possible to get the most out of incoming lumber. -- The software optimizes rips for width or grade. -- TimberMax calculates the most profitable ripping solution for each board at which time shifting saw blades are positioned automatically. -- Infeed includes a infeed belt conveyor with pressure roller. -- Infeed is mounted on slide that automatically adjusts the board in the best position before entering the saw. -- Conveyor is 24" wide X 120" long. ( This option has to be verified )Cutting Specifications -- Cutting depth with 12" Dia. saw blades, 2-1/2" with pressure shoe; 4" without pressure shoe. -- Variable feed speed, 16 - 158 FPM, feed drive 2 HP motor.Additional Features -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over thickness shutoff on infeed. -- Automatic starting and swing arbor mount for control panel.

RAIMANN KR 310 2M Multiple Rip Saw System With Valu-Rip Inffed12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Equipped with: -- Quick Fix arbor with: (2) Movable blade and (3) fixed blades; (5) Laser Lights. -- Enlarged movable saw housing with 25" pass through. Ball threaded adjustment of spindle. Saw blades mounted to individual collars. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler fo guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods. -- Raimtech E5 with TimberMax Software optimizing software; makes it possible to get the most out of incoming lumber. The software optimizes rips for width or grade. TimberMax calculates the most profitable ripping solution for each board at which time shifting saw blades are positioned automatically. Infeed includes a infeed belt conveyor with pressure roller. Infeed is mounted on slide that automatically adjusts the board in the best position before entering the saw. Conveyor is 24" wide X 120" long.Cutting Specifications: -- Cutting depth with 12" Dia. saw blades, 2-1/2" with pressure shoe; 4" without pressure shoe. -- Variable feed speed, 16 - 158 FPM, feed drive 2 HP motor.Features: -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over thickness shutoff on infeed. -- Automatic starting and swing arbor mount for control panel.Also included: -- Valu-Rip infeed system 16' long -- (4) movable Lazer light Note: This machine has recently been refurbished on the chain feed and the arbor

RAIMANN KR 310 2M Multiple Rip Saw System ( 2 Moving Blades )12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Equipped with:& Features -- Quick Fix arbor with: (2) Movable blade and (3) fixed blades; (4) Laser Lights. -- Enlarged movable saw housing with 25" pass through. Ball threaded adjustment of spindle. Saw blades mounted to individual collars. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler fo guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods. Cutting Specifications -- Cutting depth with 12" Dia. saw blades, 2-1/2" with pressure shoe; 4" without pressure shoe. -- Variable feed speed, 16 - 158 FPM, feed drive 2 HP motor.Additional Features -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over thickness shutoff on infeed. -- Automatic starting and swing arbor mount for control panel.Note: Transformer for 600 volts included if necessary

RAIMANN - KM-310, ...Gang (Multi-Blade) Rip Saw12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Features: -- "Quickfix Hydro-Quick" Arbor: Multiple Saw blades are mounted on the arbor, they slide up-and-down the arbor into position and lock into place by tightening the end of the arbor; no tools & no spacers required. -- Frequency controlled feed speed of 13 - 110 FPM, 2.2 HP feed drive, chain spikes every 3rd chain link, automatic chain lubrication.Specifications: -- 300 mm (11.8") Max. saw blade dia. with 80 mm (3.15") bore, 65 mm (2.55") dia. arbor. -- Provides 3" max. depth of cut with pressure shoe, 3-1/2" depth of cut without. -- Manual thickness adjustment of upper holddown rolls with indicator scale. -- 6" Throat depth to the right of blade; 7/8" min. strip width, 17-3/4" min. stock length.Equipped with: -- (4) Sets of top & bottom antikickback fingers. -- Extended infeed with additional bed roll, and adjustable infeed fence. -- Motor load meters and automatic STAR DELTA starting. -- Automatic over thickness shutoff on infeed and 7-1/4" dia. dust hood. -- (4) Laser lights.Also included: -- (6) Used blades.

RAIMANN - KM-310, ...Gang (Multi-Blade) Rip Saw12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Features: -- "Quickfix Hydro-Quick" Arbor: Multiple Saw blades are mounted on the arbor, they slide up-and-down the arbor into position and lock into place by tightening the end of the arbor; no tools & no spacers required. -- Frequency controlled feed speed of 13 - 110 FPM, 2.2 HP feed drive, chain spikes every 3rd chain link, automatic chain lubrication.Specifications: -- 300 mm (11.8") Max. saw blade dia. with 80 mm (3.15") bore, 65 mm (2.55") dia. arbor. -- Provides 3" max. depth of cut with pressure shoe, 3-1/2" depth of cut without. -- Manual thickness adjustment of upper holddown rolls with indicator scale. -- 6" Throat depth to the right of blade; 7/8" min. strip width, 17-3/4" min. stock length.Equipped with: -- (4) Sets of top & bottom antikickback fingers. -- Extended infeed with additional bed roll, and adjustable infeed fence. -- Motor load meters and automatic STAR DELTA starting. -- Automatic over thickness shutoff on infeed and 7-1/4" dia. dust hood.

RAIMANN KM 310 M PROFIRIP Multi-Blade Rip Saw System ( 1 Moving Blade )PROFIRIP Gang Rip Saw with (1) MOVEABLE BLADE -- 12-1/4" Max. width cap. with 25" total feed width, 13-1/2" chain width. 3/4" min. strip width, 19-1/2" min. stock length -- Arbor motor with 50 HP - 4,200 RPM V-belt drive arbor with (1) movable and fixed blades. -- Operation: (2) Laser lights with the outside light moving with the shifting blade; up to (10) shifting blade positions are pre-set; rip width is selected by the operator from operator's control console.When the rip width is selected at the operator's panel, the computer shifts the blade and the outside laser light follows the blade; fixed saw blades are mounted on collars that slide up-and-down the arbor into position, then lock into place using hydraulic pressure. Equipped with & Features: --12" Dia. saw blade capacity, 65 mm (2-1/2" dia.) arbor, 3" max. depth of cut, 17-3/4" centers between last infeed and first outfeed upper holddown rolls (phenolic holddown shoe included). -- Feed works with: Variable feed speed from 13 - 115 FPM, feed drive 2.2 HP motor, feed chain with chain spikes every 3rd chain link, automatic chain lubrication. -- Includes (2) Sets of top & bottom anti-kickback fingers, 7-1/4" dust outlet and adjustable infeed fence.

RAIMANN KM 310 1M - Movable Blade Gang Rip Saw; 12-1/4" Max. width cap.; 13-1/2" chain width; with 25" width clearance,Specifications: -- 50 HP - 4,200 RPM V-belt drive arbor with (1) movable and (2) fixed blade; shifting blades positioned from operator controls. -- As the computer or operator moves blade, laser light follows; fixed saw blade with "Quick Fix" hydro-arbor is mounted on an individual collar that slides up-and-down the arbor into position, then locks into place by tightening end of arbor; no tools & no spacers required.Equipped with: -- Blade capacity 11" to 14.1" (280 -380 mm) Dia. saw blades, 65 mm (2-1/2" dia.) arbor, 4-1/4" max. depth of cut, 17-3/4" centers between upper holddown rollers (phenolic pressure holddown shoe plate included); 3/4" min. strip width, 19-1/2" min. stock length. -- Variable feed speed from 13 - 115 FPM, feed drive 2.2 HP motor, provision for chain spikes every 3rd chain link, automatic chain lubrication. -- (2) Sets of top & bottom anti-kickback fingers, extended infeed with additional bed roll, and adjustable infeed fence.Complete with: -- Automatic over-thickness shutoff on infeed. -- (4) Laser Lights. -- Automatic STAR-DELTA starting. -- "ProfiCut 1" PLC Controls. -- 8" Dia. dust hood. -- Includes with approx. (9) blades.Dimensions: 85" x 56" x 73" H. Weight: 3,750 Lbs.Note: Stated condition reflects that the chain is worn and per owner "?Chain should be replaced."
