WYSONG & MILES - 315, ...Edge Sander6" x 32" Graphite mocovered wooden platen; double 8" x 34" tilting side tables; full 180° steel end table; tilts and raises & lowers. -- 2 HP Motor; direct drive motor.

WYSONG & MILES - 291, ...Stroke Sander (Manual)5 HP - 1,200 RPM Motor; roller table size: 32" x 84"; horizontal travel stroke: 38"; adjustable height of table base from 26" to 35" via large hand wheel. -- Rubber-faced aluminum pullies, 8-1/2" face x 16" dia.; accepts 6" wide abrasive sanding belts.Pulleys can be spaced to accommodate various belt & material sizes; belt loop travels over table with manual handwheel belt tension & tracking. -- Includes: Magnetic starter, dust hoods

This item is in an Auction on exfactoryauctions.com. Go here to view item: http://exf.ac/i6l WYSONG & MILES 284 M2 Automatic Vertical Hollow Chisel Mortiser Specifications: Max. chisel dia. 1-1/4", Max. bit dia. 5/8". Throat 6-1/4”. Max. distance from table to chisel 16". Table size 8” x 42”, with Tilt 45° Left & Right. Longitudinal table travel 13", Cross table travel 3-3/4", Vertical table travel 12". Max. chisel stroke 4-1/4". Speeds 15, 30, & 45 SPM. Equipped with: 5 HP - 3,600 RPM Spindle Motor. 1-1/2 HP Feed motor. (2) Stroke stops. Spacing gauge, with (6) Adjustable spring stops. Screw clamp. (2) Hold-downs. Foot pedal for Single stroke or continuous operation. Complete with: Fence.

This item is in an Auction on exfactoryauctions.com. Go here to view item: http://exf.ac/i6m WYSONG & MILES 284 Automatic Vertical Hollow Chisel Mortiser Specifications: Max. chisel dia. 1-1/4", Max. bit dia. 5/8". Throat 6-1/4”. Max. distance from table to chisel 16". Table size 8” x 42”, with Tilt 45° Left & Right. Longitudinal table travel 13", Cross table travel 3-3/4", Vertical table travel 12". Max. chisel stroke 4-1/4". Speeds 15, 30, & 45 SPM. Equipped with: 5 HP - 3,480 RPM Spindle Motor. 1-1/2 HP Feed motor. (2) Stroke stops. Spacing gauge, with (6) Adjustable spring stops. Screw clamp. (2) Hold-downs. Foot pedal for Single stroke or continuous operation. Complete with: Fence.

WYSONG & MILES - 284, ...Hollow Chisel MortiserThis Heavy-Duty American made Mortiser is a well functioning machine with a 5 HP motor. -- Works like a smooth running clock; a great machine for doing all types of mortises, and it is bulletproof.Note from the seller: Nice 284 complete with a selection of 1/4, 3/8, and 1/2" chisels, bits, collets, and bushings. Runs smoothly, ready to work. Those who have used them will agree that this is the best hollow chisel mortiser made, and easy on your legs if you have a lot of mortising to do.. 220/440/3/60, now 220.

Used YAMAMOTO 30-opening, premium quality, Plywood Hot Press. -- 500 Tons pressing capacity. -- Daylight is 4.7"(120mm). -- Press plates are 54" x 108" x 1.5" (1,370 x 2,700 x 40 mm). -- Auto loader feeds charger using pusher arm to load press. -- Pie rack with automatic unloader. -- Hydraulic system with accumulation tank. -- Heated by steam. -- Professional removal and loading available at Buyer's cost.

Used YAMAMOTO 45-opening, premium quality, Plywood Hot Press. -- 500 Tons Pressure Capacity. -- Daylight is 2.75" (70 mm). -- Press Platens are 106" x 53" x 1.57" (2,700 x 1,350 x 40 mm). -- Auto loader feeds charger using pusher arm to load press. -- Pie rack with automatic unloader. -- Hydraulic system with accumulation tank. -- Heated by steam. -- This particular press was only operated for about 1-1/2 years. -- Professional removal and loading available at Buyer's cost.

YATES AMERICAN B-26 Top & Bottom Rough Lumber Planer24" x 4" Opening cap., 3/4" to 4" thickness capacity; 46" minimum unbutted length capacity;Specifications: -- (1) 75 HP DMD motor power hoisted top head, (1) 40 HP DMD motor bottom head, 8" dia. cutting circle at 3,450 RPM. -- 40 HP Hydraulic power unit for variable feed rate from 75 to 400 FPM, 12" dia. Urethane tire top feed rolls, 12" dia. non-powered lower rolls. Equipped with: -- Carbide spiral cutterheads, automatic pressure bar release (hydraulically operated), hydraulic top & bottom headlocks, anti-lap bar device, air tensioned & released chipbreaker. -- Complete with: Built-in top & bottom jointers, dust hoods, electrically interlocked safety guards, and small remote operator's console.

ZAFFARONI MSR 160 P BS/PD MULTI-BLADE PANEL SAW (W/TOP & BOTTOM ARBORS): -- SpecificationsZAFFARONI is the "Top of the Line" in Precision Multi-Rip Saws for Panels. Blade Depth is mechanically adjustable with a tolerance of +/- 0.01 mm (0.0004").The Saw is so precise it can also be used for V-Grooving.The Saw blades project through the table from above & below. A double-row of hold-down wheels are mounted above the saw, with (28) adjustable rollers to prevent contact with the blade.The Top & Bottom shafts & wheels are connected by a quick flange system that can be removed/replaced without dismounting the bearing collars.Motorized adjustment of the depth of the saw blade projection by the touch-screen operating control(4) motorized & self-adjusting (according to material thickness) upper rubber coated rollers with grooves,(4) Idle lower polyethylene coated rollers & (1) Pair of ejector rollers at the output of the machine.Automatic locking and unlocking arbor shaft with HSK collector on the LH side controlled with electro-pneumatic device for the automatic cleaning of the coupling Safety device that features a presence and positioning sensor of the shaft; closed circuit air cooling device for the shaft bearingsSaw Blade work table with interchangeable MDF inserts.Technical Characteristics: -- Working Width is 1,600 mm (63"). -- Max. panel pass through is 1,780 mm (70"), min. length is (450 mm) 17.7". -- Motorized thickness adjustment from 0 - 70 mm (2.7"). -- Adjustable projection of the saw blades from the working from 0 - 62 mm (0" - 2.4") with circular saw blades or hogger trimmer up to 280 mm dia. (11"). -- Working table height is variable, from 970 - 1270 mm (38" - 50"). -- Material Feed Speed from 3 - 45 MPM (9.8 - 147.6 FPM). -- Main Motor Power is 45 kW (60 HP) with toothed Belt Drive arbor. -- Saw Blade arbor 80 mm dia. x 1,310 mm (3-1/8" x 51-1/2"), with double-tangs and automatic anti-rotation locking clutch. -- Blade Arbor Speed of 4,000 RPM.Machine Features: -- Opening of the roller group through pneumatic cylinder with timer interlock for safety. -- Safety protection hood with sound absorbing materials to conform to ISO 7960/95 Norm. -- PLC Logic touch screen control with digital communications through profibus cable.Spacer Sets: Machine requires Spacer Sets and Saw Blades (not included); pricing is available on request.Examples:width from......1 - 10 mm ...$ 25.45width from.....11 - 25 mm ...$ 30.15width from.....26 - 50 mm ...$ 35.60width from.....51 - 75 mm ...$ 40.15width from.....76 - 100 mm ...$ 45.20width from...101 - 125 mm ...$ 49.75width from...126 - 150 mm ...$ 54.90Example of productivity:Approx. 240 panels/hour running the machine at 49 FPM (15MPM) – considering to load 4 panels/minute) & a change-over time of approx. 10 minutes.

ZAFFARONI MLS 130 P PD MULTI-BLADE PANEL SAW: -- SpecificationsZaffaroni is the Top of the Line in Precision Multi Rip saws for Panels. Blade Depth is mechanically adjustable with a tolerance of =- 0.01 mm (0.0004"). The saw is so precise it can also be used for "V" grooving.The Saw blades project through the table from below. A double row of hold down wheels are mounted above the saw, with 24 adjustable rollers to prevent contact with the blade.Technical Characteristics: -- Working Width 1300 mm (51-1/8") -- Min. Panel Length 300 mm (11-7/8"). -- Motorized thickness adjustment from 0 - 70 mm (2-3/4"). -- Adjustable projection of the saw blades from the working from 42 - 62 mm (1- 5/8" - 2-7/16") with circular saw blades or hogger trimmer up to 280 mm diam. (11"). -- Working Table Height 1120 mm (44"). -- Transport Speed from 3 - 45 MPM (9.8 - 147.6 FPM). -- Main Motor Power 37 KW (50 HP) with Belt Drive. -- Saw Blade Spindle 80 mm x 1310 mm (3-1/8: x 51-1/2"), with double tangs and automatic anti-rotation locking clutch. -- Spindle Speed 4,000 RPM.Machine Features: -- Opening of the roller group through pneumatic cylinder with timer interlock for safety. -- Safety protection hood with sound absorbing materials to conform to ISO 7960/95 Norm. -- PLC logic control with digtital communications through bus cable.Spacer Sets: Machines require Spacer Sets and Saw Blades (not included) and pricing is available on request.

ZAFFARONI MLS 160 P MULTI-BLADE PANEL SAW: -- SpecificationsZAFFARONI is the "Top of the Line" in Precision Multi-Rip Saws for Panels. Blade Depth is mechanically adjustable with a tolerance of +/- 0.01 mm (0.0004"). The Saw is so precise it can also be used for V-Grooving.The Saw blades project through the table from below. A double-row of hold-down wheels are mounted above the Saw, with (24) adjustable rollers to prevent contact with the blade.Technical Characteristics: -- Working Width is 1,600 mm (63"). -- Max. panel pass through is 1,780 mm (70"), min. length is (320 mm) 12-5/8". -- Motorized thickness adjustment from 0 - 70 mm (2-3/4"). -- Adjustable projection of the saw blades from the working from 42 - 62 mm (1-5/8" - 2-7/16") with circular saw blades or hogger trimmer up to 280 mm dia. (11"). -- Working table height is 1,120 mm (44"). -- Material Feed Speed from 3 - 45 MPM (9.8 - 147.6 FPM). -- Main Motor Power is 55 kW (74 HP) with Belt Drive arbor. -- Saw Blade arbor 80 mm dia. x 1,310 mm (3-1/8" x 51-1/2"), with double-tangs and automatic anti-rotation locking clutch. -- Blade Arbor Speed of 4,000 RPM.Machine Features: -- Opening of the roller group through pneumatic cylinder with timer interlock for safety. -- Safety protection hood with sound absorbing materials to conform to ISO 7960/95 Norm. -- PLC Logic control with digital communications through bus cable.Spacer Sets: Machine requires Spacer Sets and Saw Blades (not included); pricing is available on request. Examples:width from......1 - 10 mm ...$ 25.45width from.....11 - 25 mm ...$ 30.15width from.....26 - 50 mm ...$ 35.60width from.....51 - 75 mm ...$ 40.15width from.....76 - 100 mm ...$ 45.20width from...101 - 125 mm ...$ 49.75width from...126 - 150 mm ...$ 54.90

ZEETECH - 200, ...Universal Hopper Feeder that can be mounted to all Moulders. - Capacity: 3/4" - 9-1/2" width, 0.38" - 5" max. material height, 10" min. length. -- Oil-free air operated drive unit mounted on THOMPSON hardened ways, damped drive travel, positive sensing sequencing actuator. -- Variable speed range from 0 - 120 FPM @ 80 - 120 PSI. -- Includes: All air logic controls (no power required) and air filters; easy to install.

BIESSE - ARTECH LEVIA 330, ...3-Head Wide Belt Sander43" Width cap. Drum, Drum, and Combination Head.Head Configuration: -- 1st Head: Rubber covered Contact Roll, 6" dia., 25 HP motor. -- 2nd Head: Steel Contact Roll, 6" dia., 25 HP motor. -- 3rd Head: Combination head with a rubber-covered Contact Roll and Finishing Platen.NOTE: There are (2) 25 HP motors; one drives the 1st head and the 2nd drives the other (2) heads.Specifications: -- 44" x 85" Abrasive belts, electronic abrasive belt tracking; all contact rolls with pneumatic seclusion; Head #3 with air belt cleaner. -- EASY PRO "2000 C" Processor with (200) programs, touchscreen for control of Sander functions, thickness opening, feed speed, sequential startup, contact roll seclusion, and abrasive belt cleaner. -- Conveyor belt feed, 11 - 66 FPM variable feed speed, 2 HP feed drive with inverter control. -- 1/8" - 7-7/8" Motorized thickness adjustment with LED readout; automatic part thickness setup.Equipped with & Features; -- Automatic conveyor belt tracking. -- Infeed & outfeed shoes or rubber-covered holddown rolls, infeed panel "over thickness" sensor. -- Electronic brakes on both sanding head motors. -- Infeed emergency stop, 3-roll infeed extension, and motor load meter.

BIESSE AKRON 855 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING):Specifications: -- Material infeed for strips & coiled edge material like PVC, ABS, veneer, and solid wood.0.4 - 3 mm (0.118"), Panel thickness 10-60 MM ( 0.39" - 2.36"), min. panel length 140 mm (5.5") and 85 mm (3.34") min. widthInfeed System Equipped with: -- Independent copying guide pads on each unit with manual adjustment & mechanical digital indicator.Pre-Milling Unit (FI-701) (2) 1.8 kW motors (2.5 HP), 12,000 RPM with Auto-Set device to ensure optimum positioning of the cutters according to the thickness of the panel being machine; -- "VC-710" edge feeding, gluing & pressing unit with automatic edge magazine for strip & coil stock; 3 mm PVC guillotine. -- "TEKNO-GLUE" System, Pre-Melt "QM-701" for quick heating & tank changing with floating & bi-directional glue roller applicator.Pressure Section: (1) Large motorized pressure wheel with clutch, plus (5) idle rollers, independent pneumatic pressure control & digital counters for quick edge thickness changeover.Edgebanding Workstations: -- Double Motor End Trim, tiltable from 0° - 15°, each motor 0.5 kW (0.6 HP) - 12,000 RPM; sliding in a slicing motion on a 45° precision guide bar with oversized bearing blocks. -- Top & Bottom Rough Trim: Top/bottom (2) motors, each 1.8 kW (2.5 HP) 12,000 RPM with superimposed motor position, 0° - 45° tilt capability, straight cutterheads (80 x 25 x 16 mm) w/insert knives; includes pneumatic exclusion from control panel. -- Top & Bottom Fine Trim: Top/bottom (2) motors, each 1.8 kW (2.5 HP) 12,000 RPM with superimposed motor position, 0° - 45° tilt capability, straight cutterheads (80 x 25 x 16 mm) w/insert knives; includes pneumatic exclusion from control panel. -- Multifunction 4-Motor Corner Rounding Unit "CR-202": (4) Motors, each 0.65 kW (0.87 HP) - 12,000 RPM; motors carry out Corner Rounding and Top & Bottom Trimming on panel edge with PVC, ABS, etc. material and wood edgebanding up to 5 mm max. edge thickness. -- Top & Bottom Radius Scraping (PVC): Knives R = 2 mm, with mechanical digital indicators for precision setup, pneumatic exclusion of the unit from the machining line, PVC scrape collection box. -- Top & Bottom Flat Scraper (Glue): self-adjusting with copy wheels & flat insert knives, removing potential excess glue before buffing unit. -- Top & Bottom Oscillating Buffing Station: (2) motors, each 0.37 kW (0.5 HP) - 2,800 RPM. -- Top & Bottom Hot Air Blowers is made by two 2000 W hotair blowers to reactivate the color of PVC/ABS edges after the machining.The air temperature is adjustableFeatures & Feed: -- All cutting & trimming workstations have HF motors and enclosed by padded sound enclosure, top pressure is provided by staggered double-row holddown wheels mounted on ball bearings. -- Feed chain track speed : 10 - 14 - 20 MPM (33 - 46 - 65 FPM). -- Complete with:CNi PC w/Flat, Color "REAL TIME" graphic interface design on 17"; flat screen (TFT) with high resolution. --

BIESSE ROXYL 6.0 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR FORCE" PUR/EVA GLUING TECHNOLOGY: Features: -- Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers.This technology allows changes based on banding colors without any setup. Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. -- In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Specifications: -- Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). -- Machine Controls: "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy; icons of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without the necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material + a (2) position vertical Coil Magazine Cart. -- Pressure Section: Servo controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System: -- EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special precoated edge material (commonly referred to as laser edge).Workstations: -- End Trimming Unit "IT90-S": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-100": Top/Bottom pre- or flush trimming motors -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (4) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece's surfaces. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner a

BIESSE AKRON 855 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING):Specifications: -- Material infeed for strips & coiled edge material like PVC, ABS, veneer, and solid wood.0.4 - 3 mm (0.118"), Panel thickness 10-60 MM ( 0.39" - 2.36"), min. panel length 140 mm (5.5") and 85 mm (3.34") min. widthInfeed System Equipped with: -- Independent copying guide pads on each unit with manual adjustment & mechanical digital indicator.Pre-Milling Unit (FI-701) (2) 1.8 kW motors (2.5 HP), 12,000 RPM with Auto-Set device to ensure optimum positioning of the cutters according to the thickness of the panel being machine; -- "VC-710" edge feeding, gluing & pressing unit with automatic edge magazine for strip & coil stock; 3 mm PVC guillotine. -- "TEKNO-GLUE" System, Pre-Melt "QM-701" for quick heating & tank changing with floating & bi-directional glue roller applicator.Pressure Section: (1) Large motorized pressure wheel with clutch, plus (5) idle rollers, independent pneumatic pressure control & digital counters for quick edge thickness changeover.Edgebanding Workstations: -- Double Motor End Trim, tiltable from 0ø - 15ø, each motor 0.5 kW (0.6 HP) - 12,000 RPM; sliding in a slicing motion on a 45ø precision guide bar with oversized bearing blocks. -- Top & Bottom Rough Trim: Top/bottom (2) motors, each 1.8 kW (2.5 HP) 12,000 RPM with superimposed motor position, 0ø - 45ø tilt capability, straight cutterheads (80 x 25 x 16 mm) w/insert knives; includes pneumatic exclusion from control panel. -- Top & Bottom Fine Trim: Top/bottom (2) motors, each 1.8 kW (2.5 HP) 12,000 RPM with superimposed motor position, 0ø - 45ø tilt capability, straight cutterheads (80 x 25 x 16 mm) w/insert knives; includes pneumatic exclusion from control panel. -- Multifunction 4-Motor Corner Rounding Unit "CR-202": (4) Motors, each 0.65 kW (0.87 HP) - 12,000 RPM; motors carry out Corner Rounding and Top & Bottom Trimming on panel edge with PVC, ABS, etc. material and wood edgebanding up to 5 mm max. edge thickness. --Top & Bottom Radius Scraping (PVC): Knives R = 2 mm, with mechanical digital indicators for precision setup, pneumatic exclusion of the unit from the machining line, PVC scrape collection box. -- Top & Bottom Flat Scraper (Glue): self-adjusting with copy wheels & flat insert knives, removing potential excess glue before buffing unit. -- Top & Bottom Oscillating Buffing Station: (2) motors, each 0.37 kW (0.5 HP) - 2,800 RPM. -- Top & Bottom Hot Air Blowers is made by two 2000 W hotair blowers to reactivate the color of PVC/ABS edges after the machining.The air temperature is adjustableFeatures & Feed: -- All cutting & trimming workstations have HF motors and enclosed by padded sound enclosure, top pressure is provided by staggered double-row holddown wheels mounted on ball bearings. -- Feed chain track speed : 10 - 14 - 20 MPM (33 - 46 - 65 FPM). -- Complete with:CNi PC w/Flat, Color "REAL TIME" graphic interface design on 17"; flat screen (TFT) with high resolution. --

BIESSE STREAM B1 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING), Production Edgebander: -- Specifications: Working cap., 0.4 - 15 mm edge thickness cap., min. panel width 100 mm, panel thickness 10 - 60 mm, min. panel length 150 mm. -- Pre-Milling Unit: With jump control & side copying unit for managing warped panels, 2-position infeed fence, digitals readouts. -- NC 410 Controller with:Graphic interface on MS-Windows 2000 Professional, 32-bit operating system; high resolution LCD color screen, unlimited" number of working programs, each with functions for remote control of processing units; fault diagnostic, bar code reader adaptable; etc. -- Automatic (2) coil vertical feed magazineFor coil material up to 3 mm thickness with automatic changeover. -- Patented Glue Systemw/pre-melt, large separated granular hopper for easy filling & high gluing capacity, with roller applicator (reversible); -- Pressure Section,(1) large driven pressure roller & (6) pneumatic secondary pressure rollers. Workstations: -- End Trimming:Double motor front & rear linear end trimming unit "IT 46" (0.4 HP/0.3 kW - 12,000 RPM motors ea.); pneumatic chamfer setting, 0° - 15° adjustable. -- Pre/Rough Trimming:Top & bottom "RS 10" (1.75 HP/1.3 kW - 12,000 RPM motor ea.), pneumatic exclusion & positioning from control panel. -- Radius/Bevel Trimming:Top & bottom (0.87 HP/0.65 kW - 12,000 RPM motor ea.), tiltable 0° - 30°, pneumatic exclusion from operator panel. -- Corner Rounding:4-Motor for leading & trailing edges. -- Profile Scraping Unit:Top & bottom with collection box. -- Flat Glue Scrapers:Top/bottom to remove potential glue squeeze-out. -- Buffing Unit:Top/bottom, oscillating/tilting "SZ 30" w/pneumatic exclusion control from control panel & 0.67 HP/0.5 KW- 1,400 RPM motors; -- Hot Air Unit:Top/Bottom hot air blowers to reactivate/smooth heavy pvc radius edges. Complete With:&#9679 Motorized top pressure beam with powered V-belt hold-down, electronic positioning by NC controller. &#9679 80 mm wide Heavy Duty feed chain w/rubber pads, &#9679 4 HP feed drive for feed variable speeds of 26 - 78 FPM. &#9679 Pneumatic Pre-set Stop System for most adjustments via the control panel on top & bottom trim, fine trim, and scraper station, &#9679 Electronic frequency inverter, electronic DC brakes on all trim motors. &#9679 Sound cabins for all trim work stations, outboard panel support. -- Actual Model is BIESSE STREAM B1 9.0

BIESSE AKRON 855 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING):Specifications: -- Edge & Workpiece Capacity: 0.4 -15 mm (0.016" - 0.59"), Edge thickness, 14 - 65 mm (0.55" - 2.56"), Edge height, 10 - 60 mm (0.39" - 2.36"), Panel thickness:140 mm (5-1/2") Min. panel length, 85 mm (3.3") Min. panel width.Infeed Section: -- Pre-Milling Unit, "FI-701 Rectifies face to be edged before applying glue, Horizontal & vertical movement of (2) motors on linear guides, Independent automatic temporized intervention of (2) 1.8 kW (2-1/2 HP) 12,000 RPM Motors, Independent copying pads on each unit, Auto-set device to ensure optimum positioning of cutters according to the thickness of panel being machined. -- Edge Feeding, Gluing & Pressing Unit, "VC-710": with Automatic edge magazine for strip & coil stock, 3 mm (0.04") PVC Guillotine, "TEKNO-GLUE" System Includes: Pre-Melt, "QM-701", For quick heating & tank changing with floating & bidirectional glue roller applicator, and NC axis idle presser roller movement device. -- Pressure Section: (1) Large driven & (5) Idle rollers, Independent pneumatic pressure control, Programmable servo motor for quick edge thickness changeover, Feed speeds 10, 14 & 20 MPM (33, 46 & 65 FPM).Workstations: -- End (Edge) Trimming Unit, "IN-701-V": (2) 0.35 kW (1/2 HP) 12,000 RPM Motors, Automatic 4-position programmable chamfer from control panel (0°, 3.6°, 11°, 15°), Sliding in slicing motion on 45° precision guide bar with oversized bearing blocks. -- Superimposed Flush (Double Edge) Trimming Unit: "RS-701": Top & bottom, (2) 0.8 kW (1 HP) 12,000 RPM Motors with Superimposed motor position, 1° Tilt capability. Includes: Pneumatic exclusion device & Pneumatic top/bottom motor positioner. -- Tilting Top & Bottom Trimming Unit, "RI-701": (2) 0.65 kW (0.87 HP) 12,000 RPM Motors, For radius top & bottom fine trimming, Unit can be tilted 0° - 45°. Includes: NC axis multiple machining device. -- Corner Rounding Unit, "CR-200V": For corner rounding, top & bottom trimming on panel edge with synthetic material & wood edgebanding up to 5 mm (0.20") Maximum edge thickness. -- Edge Scraping Unit, "RB-701": For finishing rounded-off edges in PVC or ABS up to 5 mm (.20")thickness; Includes: Pneumatic unit lifter. -- Flat (Glue) Scraper, "RCC-700":Top & Bottom, removes potential excess glue before buffing unit. -- Buffing Unit, "SPL-700": Top & bottom. -- Hot Air Blower Unit, "PH-700", (2) STEINEL "2346" 2,000 W, Reactivates color of thick plastic.Complete with: -- PC-based control panel with 15" Color LCD monitor, HF (High-frequency motors on all cutting & trimming workstations. --Top pressure beam programmable via positioning motor, Top pressure provided by belt hold-down. -- 36" Diameter Coil table, Padded sound enclosure. -- Manuals (as pictured). -- Dimensions: 280" x 42" x 72" H. Weight: 3500 kG (7,750 Lbs).

BIESSE ROVER 20 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working field: "X" Axis 113.9" (2,893 mm); "Y" axis 37.4" (950 mm); "Z" axis stroke is 3.9" (100 mm); max. panel thickness 2-1/2" (65 mm). -- Positioning Speed:"X" Axis at 246 FPM (75 MPM); "Y" axis 147 FPM (45 MPM); "Z" axis 49 FPM (15 MPM)."X" Axis moves on high precision prismatic guides and ground helical rack; "Y" & "Z" axes via hardened ground ball screw. -- Worktable:(6) Pneumatically locked & manually positioned panel supports with (2) vacuum cups each.(2) Working zones with: (6) pneumatic backstops, (2) pneumatic side & (2) center stops; stops raised & lowered automatically by start/stop of machining cycle. -- Boring Unit:(1) 2.3 HP - 5,135 RPM Motor; (10) vertical spindles independently operated with (6) in "X" axis & (4) in "Y" axis.(6) Horizontal spindles, (2 + 2) in "X" axis & (1 + 1) in "Y" axis; 2-1/2" (65 mm) max. boring depth.(1) "X" Axis grooving saw with 120 mm dia. blade - 5,200 RPM. -- Machining: Equipped with: (1) 9 HP (6.6 kW) Air-cooled "Quick Change" Electrospindle with ISO 30 adaptor.Router is driven by: 10.2 HP (7.5 kW) Inverter for variable speed from 1,000 - 24,000 RPM, RH & LH rotation.(1) 3-Position automatic rack tool changer mounted at the side of the machine. -- Operator & Machine Control: PC Front-end with: BIESSE "NC 500" + Windows Operating System; 4 GB hard drive.15" Color monitor, international keyboard & mouse; soft touch keypad; RS-232 serial port; 1.44 MB floppy & CD/ROM disk drives; programs can be transferred via diskette or downloading by wire is possible.All mounted in a separate Control Cabinet with built-in 1,500 W air-conditioner for constant temperature & dust-free environment. -- Complete with:Stabilized autotransformer for voltages between 200 - 600 Volt 50/60 Hz; (1) 100 cbm/Hr Vacuum Pump; triple photocell barrier; users operator/maintenance manuals & backup disks. -- Actual Model is: BIESSE ROVER 20

BIESSE ROVER B 4.35 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working capacity: "X" Axis is 125.9" (3,200 mm) any unit; "Y" axis is 51.7" (1,315 mm); "Z" axis stroke 6.3" (160 mm) max. material thickness is 5.9" (150 mm). -- Positioning Speed:"X" & "Y" Axis is 262 FPM (80 MPM) & "Z" axis is 66 FPM (20 MPM). -- Worktable:(6) Panel support rails with: (3) Vacuum pods per panel support; (4) pneumatic lifting bars for heavy panels.(2) Independent working areas with: (6) Front & (1 + 1) side pneumatic pop-up locating pins for positioning of parts on the worktable.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick Connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.3 HP (1.7 kW) - 4,000 RPM Motor: (12) Independent vertical boring spindles with (6) spindles in "X" axis & (6) spindles in "Y" axis.(6) Horizontal spindles with: (2 + 2) in "X" Axis & (1 + 1) in "Y" axis; (1) "X" axis grooving saw for max. 120 mm dia. blade. -- Machining Unit:(1) 10.2 HP (7.5 kW) Vertically mounted HSD "Electrospindle" Router with ISO 30adapter, inverter driven 1,000 - 20,000 RPM with max. torque from 12,000 - 20,000 RPM.(1) 10-Position ride-along ATC for "on the fly" tool change. -- Operator & Machine Control:PC Front-End with: BIESSE "XP 600" + "BiesseWORKS Advanced" + Windows "WRT" (Windows Real Time) operating system; INTEL "Celeron" 2.0 GHz processor; 4 GB Hard drive.15" Color monitor, international keyboard, soft touch keypad & industrial mouse, RS-232 serial port, USB ports, CD ROM & 1.44 MB disk drives.Separate Control Panel with: Built-in 1,500 W air conditioner for constant temperature & dust-free environment; 11 KVA Stabilized autotransformer for voltages between 200 - 600 Volts. -- Complete with:(1) 100 cbm/Hr Vacuum Pump; centralized manual lubrication system for guides & ball screw; emergency stop rope; safety light barrier & sound absorbing protective head enclosure with debris curtain around bottom edge; scrap belt conveyor. -- Actual model is: BIESSE - ROVER B 4.35.
