BRANDT - F-13, ...Top & Bottom TrimmerFor simultaneous top & bottom flush/radius trimming of the oversized edgeband on straight & shaped workpieces with inside-and-outside radii.Specifications: -- Top & Bottom edge trim PVC, HPL, and veneer edgings; up to 3 mm max. thickness. -- Manually operated; 1/2" - 2-1/4" panel thickness; 1-3/8" min. inside radius. -- Features: Independent top & bottom trim heads (0.5 HP - 11,800 RPM motor each). -- Built-in air jet blowoff device; 31" x 48" table size; dual foot pedal control.NOTE: Intermittent fault in the Control Panel, which will require replacement.

BRANDT - KDN 330, ...Compact EdgebanderSpecifications: -- Edgebanding thickness: 0.4 - 3 mm (0.02" - 0.12"); max. edge banding height: 45 mm (1.77"). -- Panel thickness: 8 - 50 mm (0.31" - 1.97"); min. panel width: 60 mm (2.36"); min. panel length: 140 mm (5.51"). -- Feed chain height: 35"; feed speed: 11 MPM (36 FPM); outboard support adjustment: 13".Equipped with: -- 800 mm (31-1/2") Dia. Coil table. -- Hot-melt granulate glue system with (10 - 12) Min heat-up time; reversible rotation glue applicator roller; automatic reduction glue temperature adjustment (when idle drops to 150°, 2-1/2 Min. to reactivate). -- 3 mm (0.12") PVC Pneumatic guillotine with double-acting pneumatic cylinder; automatic feed magazine; roll & fixed length. -- Pressure section with: (1) Large electronically controlled & feed speed synchronized driven and (1) small idler roll. -- 0.55 kW (3/4 HP) Feed belt motor; touchpad control with LCD Display; sound enclosure.Workstations: -- Front & Rear End Trim Unit with: (2) 0.18 kW (1/4 HP) - 12,000 RPM - 200 Hz Motors with electric brake; 0° - 15° Chamfer. -- Top & Bottom Flush/Bevel Trim Unit with: (2) 0.27 kW (1/3 HP) - 12,000 RPM - 200 Hz Motors with electric brake; combination insert knifes for flush & bevel trimming; vertical & horizontal tracing; 0° - 15° chamfer. -- Top & Bottom Buffing Unit with: (2) 0.09 kW (0.12 HP) - 2,710 RPM Motors. -- Manual height adjustment of top pressure beam for all workstations with Digital height gauge.Complete with: -- Documentation.

BRANDT - "KD-68", ...Edgebander1/4" (6 mm) Edge thickness cap. (will even do 8 mm max.); max. edgebanding height: 60 mm (2-3/8"); min. workpiece length: 160 mm; width: 70 mm (2-3/4").Equipped with: -- Quick Melt Glue System with: (10) Min heat up time and reversible glue roller. -- Automatic magazine for strip & coil stock; 3 mm PVC guillotine; 3-roller Pressure Section.Workstations: -- Double motor end trim on uni-slide: 0.33 HP - 14,400 RPM; chamfers 0° - 15°. -- Top & Bottom flush/bevel & radius trim; bevels 0° - 15°; 1/2 HP - 14,400 RPM motor ea.; w/SIKO digital readouts. -- Top & Bottom scraping for standard or 3 mm PVC edging; air jet blowoff; SIKO digital readouts. -- Top & Bottom buffing: 1/2 HP - 1,650 RPM; adjusts 0° - 40°. -- Feed chain feed speed: 36 FPM.Complete with: Electronic motor brakes on both trimmers; padded sound enclosure; eye level height swivel control panel w/fault sensor control; adjustable outboard panel support track; frequency converter; used tooling.

BRANDT - KD77/2 C, ...Edgebander with Corner Rounding0.4 - 12 mm (1/2") Edge cap; 8 - 55 mm panel thickness; 160 mm (6-3/8") min. panel length; 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function; 14 MPM feed speed (11 MPM automatically when corner rounding).Equipped with: Quick heat up Glue System w/overhead hopper feed; "quick change" glue tank for maintenance & glue color change. -- Automatic magazine for strip & coil stock; 3 mm PVC guillotine; (1) drive plus (3) idle roll "pneumatically controlled" pressure sections.Workstations. Double-motor end trim; 1/2 HP - 12,000 RPM motors; automatic chamfer from control panel 0° - 15°. -- Top & Bottom flush/Fine trim; 3/4 HP - 12,000 RPM motor; bevels 0° - 25°; with insert knives for 3 mm PVC radius; 4-position turret stop for electro-pneumatic axial movement of flush trimmer. -- 2-Motor Corner Rounding unit for leading & trailing edges of panels; either radius or chamfer cutters can be mounted; 1/2 HP - 12,000 RPM motors; 3 mm max. edge thickness. -- Top & Bottom scraping for (2 - 3) mm radius, -- Top & Bottom Buffing: 0.125 HP - 1,400 RPM motors. -- End trim & flush trim stations have HF motors w/electronic brakes.Complete with: Operator Control Panel with: PLC (Programmable Logic Control) keypad; LED readouts; padded sound enclosure, extended; used tooling.0.4 - 12 mm (1/2") Edge cap; 8 - 55 mm panel thickness; 160 mm (6-3/8") min. panel length; 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function; 14 MPM Feed Speed (11 MPM automatically when corner rounding).

BRANDT - KDF-550 C, ...Edgebander with Premill & Corner RoundingEdge & workpiece capacity. Edge: 0.4 - 8 mm (0.016 - 0.31"); panel thickness: 8 -60 mm (0.31" - 2-3/8"); min. panel length: 60 mm (6.29"); min. panel width: 70 mm (2-3/4").Equipped with: -- Premilling Station with: Diamond cutterheads; (2) motors @ 2.25 kW (3.0 HP) - 12.000 RPM; LH & RH rotation w/pneumatic jump control for chip free & clean panel edges. -- Infeed fence with: Servo motor positioning. -- Automatic Edge Magazine. For strip & coil stock; strips: 0.4 mm - 8 mm (0.016" - 0.31"); coils up to 3 mm PVC and "HD" guillotine. -- Pressure Section. 1st Roller driven; plus (3) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speed: Variable; 8 - 14 MPM (26 - 46 FPM); 11 MPM (36 FPM) when using contour trimming. -- BRANDT "PowerControl PC 16"; memory: 256 MB RAM; 1 GB Flash Card Drive; Operator control panel with: 22" Color HD wide screen; soft keypad; internal modem for remote diagnostic link.Workstations -- End Trimming; (2) Motors @ 0.35 kW (1/2 HP) 12,000 RPM; automatic chamfer from the control panel: 0°- 15°. -- Flush/Bevel-Fine/Radius Trimming Unit: Top/bottom (2) motors; 0.55 kW (3/4 HP) 12,000 RPM; auto tilt positioning 0° - 25°; combination flush/radius/chamfer cutterheads; horizontal and vertical tracing wheels. -- Includes: (3) Positioning options: Profile 1, profile 2, and flush trimming. -- Corner Rounding Unit: (1) Motor; 0.35 kW (1/2 HP) - 12,000 RPM for leading & trailing edges; vertical corner rounding of panels; either radius or chamfer cutters can be mounted; 3 mm max. edge thickness. -- Scraping, Multi-Profile (PVC) Top/Bottom with (2) profiles: 1 mm & 2 mm or 3 mm Instead of 2 mm; Servo control positioning of vertical & horizontal copy wheels; PVC scrape collection box. -- Scraping Glue Unit: Flush top/bottom on the panel surface with floating insert knives. -- Buffing Unit: Top/bottom (2) motors; 0.10 kW (0.125 HP) - 2,800 RPM.Complete with: Motorized, programmable holddown pressure beam; padded sound enclosure. -- Actual Model: BRANDT, OPTIMATKDF 550 C

BRANDT AMBITION 1440 FC (KDF-440 FC) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Edge & workpiece capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") panel thickness, 160 mm (6.30") min. panel length, 70 mm (2.76") min. panel width.Equipped with: -- Heated Adjustable Infeed Fence: Radiant Heated with Manual adjustment. -- Joint Trimming/Pre-milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, left-hand & right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting; 0.4 - 8 mm (0.016" - 0.31") strip thickness; 3 mm (0.12") PVC max. coil thickness. -- Hot Melt Glue Application Unit: 6 - 10 kG/Hr (13 - 22 Lbs/Hr) Melting capacity (depending on glue type). -- Pressure Zone: (1) Driven & (2) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds: 8 - 14 MPM (27 - 45 FPM); 11 MPM (36 FPM) when contour trimming. -- BRANDT "POWERTOUCH" Control with: 21" HD LCD Touch Screen Monitor.Workstations: -- Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors with 0° - 15° automatic chamfer, pneumatic adjustment & activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt with Horizontal & Vertical Tracing wheels, Brushless multi-axis Servo motors for positioning of work unit & horizontal copy wheels for quick changeover with (3) Positioning options: Profile 1, Profile 2 & Flush Trimming. -- Multifunctional Trimming Unit: (2) 0.4 kW (1/2 HP) - 12,000 RPM Motors for Top & Bottom, Leading & Trailing edges & Corner Rounding of panels, Servo motors for positioning of work unit & horizontal copy wheels. Either radius or chamfer cutters can be mounted, 3 mm (0.12") max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"); Servo control positioning of vertical & horizontal copy wheels; PVC scrape collection box, pneumatic adjustment using "POWERTOUCH" control, pneumatic disengagement. -- Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) - 2,750 RPM Motors.Complete with: -- Rubber padded feed chain w/top idle hold-down rollers; 1.5 kW (2 HP) feed motor; 32" diameter coil table; padded sound enclosure. -- Actual Model is BRANDT AMBITION 1440 FC (KDF 440 FC).

BRANDT KDN 650 C Edgebander; 6-Station Edgebander with 0.4 - 8 mm (5/16") Edge capacity. Specifications: -- Panel thickness 5/16" - 1-9/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; -- Line control (NO limit switches) for workstation function. -- Automatic height adjustment with top pressure beam for all work station, equipped with digital height indicator. -- PC-16 Program Control with 7-1/2" VGA screen 8 MB IDE flash disk, 8 MB RAM, Internal Modem for remote diagnostic link; -- Signal infeed light to insure proper spacing between panels. Equipped with: -- Quick heat-up glue system (10 to 12 minutes). -- Automatic magazine for strip & coil stock (large coil table 800 mm diam. to accommodate large coils of 3 mm PVC), 3 mm PVC guillotine; -- (1) Drive plus (3) idle roll "pneumatically controlled" pressure sections. Workstations: -- End trim (1/3 HP - 12,000 RPM motors) chamfers 0° - 15°; -- Top & bottom flush trim, bevels 0° - 15°, (2) 1/2 HP - 12,000 RPM motors) with insert knives. -- 2-Motor (4-corners) contour trim for profile corner rounding (2) 1/2 HP - 12,000 RPM motors), with insert knives for 3 mm PVC radius. -- Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blowoff nozzles. -- Last Station: Top & bottom buffing (0.25 HP - 1,400 RPM motors). Feed chain track speed 42 FPM, 2 HP feed drive. Complete with: Operator control panel w/PLC (Programmable Logic Control) keypad & LED readouts, and used tooling.

CAM-WOOD TX-E8V Automatic Vertical Panel SawSpecifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- Manually positioned pusher fence with grippers; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (3) Cutting modes: Standard, trim & cutoff to permit clean burrs, repeat cutting mode; heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut, this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD TX-C8VX Automatic Vertical Panel Saw (Servo Gripper)Specifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- PLC Controlled automatic pusher fence with grippers with Auto Stops or Auto Program Sizing mode; 40 FPM pusher speed, +/- 0.004" accuracy; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (2) Cutting modes: Standard cutting & scoring pass and cutting; the heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut; this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD SET-86TS SJC Double End Tenoner, 6 HeadsCapacity & Style: -- Max. 98" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top trim head, 10 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Jump cope shaping head, 7.5 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Cope shaping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5 7/8" long X 1" diameter arbor, 6" to 8" max. dia. cutter head -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross-transfer system with transfer line 4' X 8' transfer table with rollers (additional $38,900). -- Hopper feed magazine (additional $3,990). -- 42" Infeed extension (additional $4,500) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (additional $ 6,900) -- Electric motor brake -- Central supportNote: Pictures are showing the machine with several options included

CAM-WOOD SET-46TS 6 Heads 48" Double End Tenoner: Soring, trimming and shapingCapacity: -- Max. 48" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Motorized opening with LED indicator; -- Single-post machine, single "dual-track" base, right side fixed, left side movable.Each side equipped -- Front of post: Bottom scoring unit, 2 HP - 3,600 RPM motor, 1" dia. arbor & up to 10" blade; -- Top trim head, 3 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade; -- Back of post: Vertical shaping head, 5 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads and dogs at 6" center, --Spring loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $38,900) -- Hopper feed magazine (additional $3,990)Extended infeed 42" (additional $4,500) -- Pneumatic jump control on scoring or shaping unit -- Same machine with 8' opening

CAM-WOOD SET-52SAT 6-Head Double End Tenoner (Not Feed Through)Capacity: -- Length of cut: 12" to 60" (opening). -- Max. width of cut: 24" (cross cut). -- Max. clamping thickness: 4-1/2". -- Saw blade dia. 8" to 12"; saw arbor dia. 1"; saw blade speed 3,400 RPM; saw head swivels 180 degrees. -- Moulder (Shaper) spindle: 1" Dia. x 5" long; spindle speed 6,000 RPM; spindle swivels 180 degrees. -- Vertical travel: 17" vertical. -- Carriage (table) travel (front/back): 24".Equipped with: -- Saw motors: (4), each 2 HP motors (1 top & bottom each side). -- Shaper spindles: (2), each 2 HP motors (1 each side). -- Out Feed Conveyor drive: 1 HP motor (not this model!). -- Powered length setting: 1/2 HP motor (machine opening).Features: -- With the double end miter saw set-up, you can cut-off stock faster or consider a double end miter saw combined with moulding (shaper) head. It lets you cut and machine stock and moulding pattern in a single feed, saves time, space and cost. -- Air-operated vertical clamps hold sticks firmly in place. After the work piece is clamped, table start to feed, performs trimming and shaping operations. -- Trim saw allows to cut stock accurately with a clean cut. -- Moulding (Shaper) spindle mounted at the rear of saw head enables the machine to perform edge moulding after stock is cut off. -- The entire cutting cycle, cut-off, shaping/tenon or mortise is automatically operated in a single pass of stock feeding. -- The material Clamping table travels on a precision linear motion guide for stability. -- The table traverse is motorized, ensuring very stable, smooth workpiece feeding. -- Material transport thru machine powered by variable speed inverter drive for 10 to 20 Sec per cycle -- Variable feed speed permits proper feed selection for hard or soft wood materials. -- Large hand-wheel to adjust depth of cut. -- All controls are grouped in a control panel. -- Industrial motors for optimal cutting results.Machine Stations: -- 1: Top & Bottom Trim Saws powered by (4) 2 HP saw arbor motors for trimming to length. -- 2: Shaper spindles powered by (2) 2 HP spindle motors for applying tenons and grooves. -- Floor space requirement: 94" X 40" X 54" high. -- Cycle time: 10 to 20 Sec per cycle.Available option at additional cost: -- Auto Outfeed device -- Return conveyor

CAM-WOOD SET-88DET-SHJCJC 8-Head, 96" Double End Tenoner -- Suitable for mass production of woodworking task for double-end cutting, tenoning, grooving, profiling and sanding -- Scoring, Hogger/Saw, Jump Shaper, Jump Shaper: Total (4) stations on both sides. -- A solid, powerful machine great for Heavy-Duty production.Capacity: -- The specially designed numeric controller allows quick setting of sizes, for the tolerance within 0.004";. -- Variable speed, through feed, wide rubber pad chain, spring-loaded dogs at 8" center conveyor for the best finish selections. -- Heavy-duty pressure rolls at top of wide width conveyor to hold the material tight to prevent sliding during the cutting process. -- Shaper heads can be moved up & down, forward & backward. -- Max. 96" working capacity, min. 12"; max. 3-1/8" opening, 24" load area in front of hold-downs. -- The automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 66 FPM. -- Motorized opening with LED indicator.Each side equipped -- Top Scoring saw unit , 2 HP - 3,600 RPM motor, 1" dia. arbor & up to 8" blade -- Hogging/ Trim saw tiltable unit, 5 HP - 3,600 RPM motor, 1" arbor and up to 10" blade. -- Jump Shape/coping head unit, 7.5. HP - 4,500-7,000 RPM motor, 40mm dia. arbor for 6" to 8" cutter head. -- Jump Shape/coping head unit, 7.5 HP - 4,500-7,000 RPM motor, 40 mm dia. arbor for 6" to 8" cutter head -- Variable feed speed from 20 - 66 FPM, 2 HP motor, steel feed chains with plastic anti-slip pads and dogs at 16" center. -- Spring-loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Not Included -- Hopper feed magazine $3,960) -- Extended infeed 42" in front of hold-down belt $4,900) -- Sound enclosure $ 8,900Floor space : 8.5' X 9' X 6', weight 10,500 Lbs

CAM-WOOD SET-812 SCCWW, Double End Tenoner with Sanding12-Head Double End Tenoner, suitable for mass production in a woodworking factory, processing double end cutting, tenoning, grooving, moulding, and sanding.Features: -- Automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 75 FPM. -- In addition to the double-end cutting, all the settings and other processing can also be executed with high accuracy. -- Since the machine is so versatile, we believe it will be one of the most satisfactory machines for bulk production lumber-processing factories. -- The specially designed numeric controller allows quick setting of length sizes for tolerance within 0.004". -- The numeric control system provides highly accurate settings, and a special memory retains all settings, even if there is a power failure. -- Variable speed, through feed, wide rubber pads with spring-loaded dogs located at 16" center distance with conveyor speed for the best finish selections. -- Heavy-duty powered pressure rolls at top of the wide width conveyor holds the material tight to prevent sliding during the cutting and sanding process. -- Shaper head can be moved up & down, forward & backward. -- Workstations are powered by industrial motors for full power cutting and utilizing the entire sanding capacity range. -- Two sanding heads can use brush, flap wheel or profile disc for fine finish with one pass. -- Trim saws and sanding heads can be tilted for different angular setup. -- Heavy cast iron base for durability and heavy duty usage.Specifications: -- Thickness: ½" to 4" -- Length: 10" to 96" -- Miter Saw Blade: 10" x 30 mm Dia. -- Grooving Saw Blade: 8" x 1" Dia. -- Shaper Cutter: 6" - 10" x 30 mm Dia. -- Feed Speed: Variable, 20 ~ 75 FPM -- Trim Saw 3 HP x 2, 3,450 RPM -- Hogging Saw 10 HP x 2, 3,450 RPM -- Jump Shaper 10 HP x 2, 4,500 to 7,000 RPM -- Shaper 10 HP x 2 4,500 to 7,000 RPM -- Belt Sanding 3 HP x 2, 0-1500 RPM -- Brush Sanding 3 HP x 2 with 30 mm arbor 0-1500 RPM -- Feeding 3 HP x 1 -- Width (Opening) Setting 1 HP x 1 Option: -- Sound enclosure ...$ 7800

CAM-WOOD SET-410-SHJJA 50" Double End Tenoner with Sanding(10) Heads Double End TenonerFeatures: -- The automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 66 FPM. -- Suitable for mass production in woodworking factory for processing of double end cutting, tenoning, grooving, moulding, and sanding. -- In addition to the double end cutting, all the settings and other processing can also be executed with high accuracy. -- Since the machine is so versatile, we believe it will be one of the most universally satisfying machines for bulk production in lumber-processing factories. -- The specially designed numeric controller allows quick setting of length sizes for tolerance within 0.004". -- Variable speed, through feed, wide rubber pad, spring-loaded dogs at 16" center conveyor for the best finish selections. -- Heavy-duty powered pressure rolls at top of wide width conveyor to hold the material tight to prevent sliding during the cutting and sanding process. -- Shaper head can be moved up & down, forward & backward. -- Equipped with industrial motor for full power cutting and sanding capacity. -- Two sanding heads can use brush, flap wheel or profile disc for fine finish with one pass. -- Trim saws and sanding heads can be tilted for different angular setup. -- Heavy cast iron base for durability usage.SPECIFICATIONS: -- Material Thickness: ½" to 4". -- Material Length: 10" to 50". -- Scoring Saw Blade: 12" x 1" Dia. -- Hogging Saw Blade: 8" x 40 mm dia. arbor. -- Shaper Cutter: 6" - 10" x 40 mm dia. arbor. -- Feed Speed: 20' - 66' Variable, Motor 3 PH, 220/440 V. -- Trim Saw 5 HP x 2. -- Hogging saw blade 10 HP x 2. -- Jump Shaper 15 HP x 2. -- Jump Shaper 15 HP x 2. -- Brush/Disc Sanding 2 HP x 2 with inverter for variable RPM. -- Feed Drive 3 HP x 1. -- Width Setting 1HP x 1. Option: -- Sound enclosure $ 8,900 -- Hopper feed magazine $ 3,900 -- 42" extend infeed conveyor before top hold down $ 4,900

CAM-WOOD SET-106TS- SJC Double End Tenoner, (6) HeadsCapacity & Style: -- Max. 120" working capacity, min. 12"; max. 4" opening(thickness), 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top scoring head, 2 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Top trim head , 7.5 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Cope shaping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5-7/8" long x 1" diameter arbor, 6" to 8" max. dia. cutter head -- Variable feed speed from 12 - 52 FPM, 2 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams with endless belts. -- Separate electrical control cabinet with operator controls.Options Available: (Pricing to be confirmed at time of order) -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional ...$39800). -- Hopper feed magazine (additional ...$3,990). -- 42" Infeed extension (additional ...$4,500) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (...$6,900) -- Electric motor brake -- Central support Included for 10' opening machine -- Same machine with 8' opening $66,500Note: Pictures are showing the machine with several options included

CAM-WOOD SET-84 -TS - SH Double End Tenoner, (4) Heads4-Head machine (two on each side) with Scoring/Cutting and HoggingCapacity & Style: -- Max. 98" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Scoring head, 3 HP - 3,600 RPM motor, and 1" dia. arbor for up to 10" blade. -- Hogging/cutting unit 5 HP - 3,600 RPM motor, 1" dia. arbor, 10" max. dia. cutter-head. -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring loaded overhead hold-down beams with endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $38,900). -- Hopper feed magazine (additional $3,990). -- 42" Infeed extension (additional $4,500) -- Sound enclosure ...$6,900 -- Electric motor brake -- Central supportNote: Pictures are showing the machine with several options included

CAM-WOOD SET-14TS Double End Tenoner, (4) Heads, with Single feed chain for Narrow PartsFeatures: --The automatic high-speed through feed tenoner allows for perfect finishing at speeds ranging from 1 ~ 43 FPM. -- Suitable for mass production for processing of double-end cutting, tenoning, grooving, and moulding. -- SET-14TS Shaper, Sander: Total (2) stations on both sides. -- Variable speed, through feed, wide rubber pad, and spring-loaded dogs feed chain for the best finish selections. -- Heavy-duty pressure rolls at top of the wide-width conveyor to hold the material tight to prevent sliding during the cutting process.Specifications: --Max. Working Thickness 2" --Working Width 2-3/4"; ~ 10"; -- Working length 4" to 14" -- First head Tilting cutting saw -- Second head Tilting cutting Saw --Optional: Shaper Cutter Heads, Sander Heads 6" ~ 8" x 1" Dia. --Feed Speed 1' ~ 43' FPM, Variable --Feed Drive 3 HP, 220 or 440 V -- Saw Heads 5 HP x 2 -- Saw heads 5 HP x 2 -- Feed drive motor 1 HP Option: -- Tiltable saw blade 0° to 90° Additional $2,800

CAM-WOOD SET 83-3M Single End TenonerIt performs tenon, moulding functions. -- Three tenon cutters, cope spindles accepts general shaper cutter. -- Suited for cutting tenons, finger joints for windows or door frames and general joint-tenon. -- Hand, manually operated clamping and feeding of stock. -- Then two horizontal moulding, tenon spindles and one vertical coping spindle enables machine to perform edge tenon, moulding. -- Since each head is adjusted independently, a wide variety of tenons can be cut. -- At the end, the cope spindle provides 6000 RPM cutting, allowing to feature a spindle sharperSpecifications: -- Table Size 31"; W x 12"; L -- Max. Length of Cut ~ -- Min. Length of Cut 5"; -- Max. Width of Cut Pass Once 5", Pass Twice 8"; -- Max. Tennor Height 5"; -- Max. Tenoner Depth 6"; -- HORIZONTAL COPING HEADS X 2 UNITS (M1 & M2) -- Cutter Head Dia. 6-3/4";, Cutter Arbor Dia. 30 mm, Cutter Head Length 2-3/8";, Cutter Speed 4,000 RPM -- VERTICAL COPING HEAD (M3), Cutter Head Dia. 5";, Cutter Arbor Dia. 30 mm, Cutter Head Length 2-3/8";, Cutter Speed 4,000 RPMTRAVERSE -- Saw Longitudinal Travel 3" -- Saw Vertical Travel 3" -- Carriage Cross Travel 20" -- MOTOR Saw & Tenoner Head 3 HP x 2 -- Cope Head 5 HP x 1 -- DUST HOOD Out Diameter 6"; x 2

CAM-WOOD - SET-48TS-CHX, ... Double End Tenoner for Chevron & Herringbone FlooringSpecial design Servo Control for Chevron & Herringbone Double End TenonerFeatures: -- Servo Control for +45° or –45° and 90° cutting. -- The automatic high-speed through feed device allows for perfect finishing at speeds ranging from 12 - 52 FPM. -- Feed chain with dogs at 10" center distance. -- Suitable for mass production of woodworking factory for processing of double end cutting, tenoning, grooving, moulding, and sanding. -- Possibility for: Scoring Saw, Trim Saw, Jump Coping, Shaper, Coping. -- Total (4) stations at each side. -- Reversed direction cutting jump shaper head with sensor for automatic move in and out for perfect cutting to prevent tearing at end edge. -- HMI Plus PLC controller for user-friendly easy setting and operation. -- Powerful machine is great for heavy-duty production. In addition to the double end cutting, all the settings and other processing can also be executed with high accuracy. -- Since the machine is so versatile, we believe it will be one of the most satisfactory machines for bulk production lumber-processing factories. -- The specially designed numeric controller allows quick setting of sizes for tolerance within 0.004";. -- Variable speed, through feed, wide rubber pad, and spring-loaded dogs conveyor for the best finish selections. -- Heavy-duty pressure rolls at top of wide width Conveyor to hold the material tight to prevent sliding during the cutting process. -- The Shaper head can be moved up & down, forward & backward. -- Equipped with: Industrial motors for full power cutting capacity. Specifications: -- Max. working thickness: 2";. -- Max. working length: 45° is 49";. -- Max. working length: 90° is 48". -- Min. working length: 45° is 18". -- Min. working length: 90° is 13-3/4". -- Scoring/Main saw blade (dia.): 10" x 1". -- Shaper cutter (dia.): 6" - 8" x 1" -- Feed speed 12' - 52', variable power 3 PH - 220/440 Volt. -- V-Scoring saw: 3 HP x 2. -- Trim saw: 3 HP x 2. -- Jump Shaper: 5 HP x 2 Stationary. -- Shaper: 5 HP x 2. -- Feed motor by Servo: 1 kW x 1; Width setting by Servo 0.75 kW x 1.Available Options: -- Total sound enclosure cover: Add ...$7,900. -- Infeed Hopper Magazine: Add ...$4,990.
