HOLZMA HPL 380 43/16 REAR LOAD, AUTOMATIC PANEL SAW + VrSS PPOST FORMING: -- Specifications169.2" (4,300 mm) Cutting length; 3.7" (95 mm) max. main blade projection; 28 HP (20.8 kW) main & 3 HP (2.2 kW) VrSS Post Form (Jump) scoring motor. -- Saw Carriage: Variable speed from 16 - 426 FPM (5 - 130 MPM); constant return of 426 FPM (130 MPM); electronically & automatically controlled through the CADmatic according to the material/program being processed. -- Pusher FenceRack & pinion drive on both sides: Forward speed 82 - 262 FPM (25 - 80 MPM); forward speed is currently set at 0 - 82 FPM (0 - 25 MPM) per CE standards; return speed 262 FPM (80 MPM).(6) Material clamps that open up to 3.9" (100 mm); 1st (2) clamps with: (2) Fingers and the others with (1) finger. -- Operator & Machine ControlHOLZMA "Power Control 22" IPC multitasking controller with: "Windows XP" + "CADmatic 4.0" Operating System.17" TFT Flat Screen display/monitor with: real-time moving graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.Standard industrial keyboard: CD ROM & 1.44 MB floppy drives; possible direct downloading from office PC through RS 232 or USB connection. -- Rear of MachineProfile rails & "Combi Rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent offset panels within the same book. -- Front of Machine(4) Air flotation tables: 85" x 25-1/2" (2,160 x 650 mm); (1) central blower unit. -- Rear Lift TableAutomatic 4-column electrohydraulic rear load lift table; 169.2" x 62.9" (4,300 x 1,600 mm) capacity; 4.2" dia. powered rollers; 39 FPM (12 MPM) infeed/outfeed speed.22.8" (580 mm) Max. bunk height without pit or risers; 30.7" (780 mm) max. bunk height with a pit or risers; 8,800 Lbs (4,000 kG) lift capacity. -- Complete with:Angular crosscut fence; side pressure device for crosscutting with front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed; min. side aligning dimension 0" (0 mm), max. side aligning dimension 169.2" (4,300 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Actual model is: HOLZMA Optimat HPL 380-43/16

HOLZMA - HPP 380 32/32: Front Load Automatic Panel SawSpecifications -- 126" (3,200 mm) Rip cutting capacity & pull back; 3.74" (95 mm) saw blade projection.18 HP (13.5 kW) Main saw motor and 3 HP (2.2 kW) scoring motor; scoring saw adjustment via "CADMATIC" control. -- Saw CarriageVariable saw carriage travel speed from: 16 - 426 FPM (5 - 130 MPM); constant return: 426 FPM (130 MPM). -- Pusher FenceElectronically controlled overhead program fence; equipped with: (6) Clamps that open up to 100 mm (3.9").Rack & Pinion driven on both sides; forward speed: 262 FPM (80 MPM); return speed: 262 FPM (80 MPM). -- Operator InterfaceHOLZMA Power Control with "CADMATIC" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory.TFT 17" Flat Screen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard; 1.44 MB Floppy & DVD R/W drives; capable of online operation via RS 232 or USB port for possible link to an office PC. -- Complete with:Automatic "CENTRIC" side aligner with front & rear forks; holding ripped strips squarely against the right-angle fence.(3) Front air flotation tables; 67" x 25" (1.700 mm x 650 mm). Rear support rails with non-marking roller modules. -- Options include:Label Printer as pictured & label printing software -- Actual model is HOLZMA HPP 380 32/32.

HOLZMA - HPP 350 38/38: Front Load Automatic Panel Saw -- Specifications149.6" (3,800 mm) Cut length; 145.7" (3,700 mm) pull back; 3" (80 mm) saw blade projection. 18 HP (13.5 kW) Main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment is from the "CADMATIC 4.0" control. -- Saw CarriageTravel speed: 16 - 492 FPM (5 - 150 MPM); constant return 492 FPM (150 MPM). -- Pusher FenceOverhead program fence with: (7) Gripper clamps; clamps open up to 90 mm (3-1/2"); rack & pinion drive on both sides.Forward speed: 82 to 295 FPM (24 - 90 MPM); return speed: 295 FPM (90 MPM). -- Operator InterfaceHOLZMA "Power Control 22" with: "CADMATIC 4.0 PROFESSIONAL" + "Windows XP" operating system. Virtually unlimited cutting dimensions memory.TFT 19" flat Touchscreen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard; 1.44 MB Floppy & CD ROM drives; capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with front & rear forks holding ripped strips squarely against the right angle fence.(3) Front air floatation tables: 85" x 31.-1/2 (2,160 mm x 800 mm). -- Options Include:Label Printer as pictured. -- Actual model - HOLZMA HPP 350 38/38.

HOLZMA - HPP 350 31/31: Front Load, Automatic Panel Saw -- Specifications122" (3,100 mm) Cut length; 122" (3,100 mm) pull back; 3" (80 mm) saw blade projection.18 HP (13.5 kW) Main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment from the "CADMATIC 4.0" control. -- Saw CarriageTravel speed: 16 - 426 FPM (5 - 130 MPM); Constant return: 426 FPM (130 MPM). -- Pusher FenceElectronically controlled overhead program fence with: (6) Gripper clamps; clamps open up to 90 mm (3-1/2").Rack & Pinion drive on both sides; forward speed: 82 to 262 FPM (24 - 80 MPM); Return speed: 262 FPM (80 MPM). -- Operator InterfaceHOLZMA Power Control with: "CADMATIC 4.0" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory.17" TFT Flat screen monitor; REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard, 1.44 MB Floppy & DVD R/W drives; capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with: Front & rear forks holding ripped strips squarely against the right angle fence.(1) Front air floatation tables: 86" x 25" (2,160 mm x 650 mm); (2) front air floatation tables: 69" x 25" (1.760 mm x 650 mm); rear support rails with non-marking rollers. -- Options include: ZEBRA "Z4M" Plus thermal label printer; (4) sets main/scoring blades; miscellaneous spare parts. -- Actual model: HOLZMA HPP 350 31/31

HOLZMA HPP-11-32 OPTIMAT FRONT LOAD PANEL SAW:Specifications & features: 3,200 mm (126") Cutting length & pull-back behind the cutting line; 125 mm (4.9") saw blade projection; 30 HP (22.3 kW) main & 3 HP (2.2 kW) scoring motor. -- Variable saw carriage travel speed from 0 - 410 FPM (0 - 125 MPM), constant return of 410 FPM (125 MPM). -- Equipped with: Main blade 18" (450 mm) dia. and scoring blade 8" (200 mm dia.). -- Electronically controlled overhead pusher fence, rack & pinion drive on both sides by AC Servo motor; forward speed from 0 - 262 FPM (0 - 80 MPM), return speed of 262 FPM (80 MPM); equipped with (8) gripper clamps (open up to 4.7"). -- HOLZMA CADmatic Operating system; 15" color monitor (displays cutting dimensions); data input by keyboard or 1.44 MB floppy disk drive & downloading from office PC is possible. -- Control panel mounted on double swiveling arm for ergonomic positioning by the operator. -- Includes: Combi-rollers rear machine table with profile rails, rollers spaced at 50 mm centers; front with (3) air floatation tables, 85" x 26" (2,159 x 660 mm) each. -- Complete with: Angular square fence, automatic side aligner for crosscutting, (2) aligning devices on program fence; "Quick Saw Changing System" for main & scoring blade.

HOLZMA PROFIMAT HPL 500 38/16 REAR LOAD, AUTOMATIC PANEL SAW: -- Specifications: 149.6" (3,800 mm) Cutting length & pull-back; 6.7" (170 mm) max. main blade projection; 40 HP (29.8 kW) Main & 3 HP (2.2 kW) scoring motor. -- Saw carriage: Infinitely variable speed from 0 - 492 FPM (0 - 150 MPM), constant return of 492 FPM (150 MPM).Carriage is electronically & automatically controlled (cutting height & length) through the CADmatic according to the material/program being processed."Power-Loc" quick change system for fast and easy saw blade change.NC Controlled scoring saw adjustment from the control panel during operation -- Pusher Fence:Rack & pinion digital drives with AC Servos on both sides, forward speed 295 FPM (90 MPM), return speed 295 FPM (90 MPM).(7) Material clamps which open up to 6.7" (170 mm): (3) Standard clamps with two fingers & (4) clamps with one finger.(4) Trimming rakes for thin strips/scrap removal are attached at the clamps. -- Operator Interface:HOLZMA "Power Touch Control" IPC multi-tasking controller with Windows "7 PRO" + "CADmatic 4.0 PRACTIVE" operating system;Intel i5 Dual-core Processor, Intel HD graphics card, 4GB RAM, SATA 2-250GB hard drive, (6) USB ports, (1) serial port, ATI/DVI video port, Standard industrial keyboard connection,21.5" LCD "Touch-Screen" monitor with real-time moving 2D & 3D graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.(2) Ethernet 10/100 interface connections; downloading from office PC is possible. -- Rear of machine: Profile rails & "Combi-rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent off-set panels within the same book. -- Front of machine: (3) Air flotation tables 85" x 31.5" (2,160 x 800 mm) with (1) central blower unit. -- Rear Lift Table:7-Ton (14,000 LBS), 4-Column electro-hydraulic powered rear lift table running lengthwise with fork cut-outs, 150" x 63" (3,800 x 1,600 mm) capacity. Powered rollers are 4.2" (107 mm) dia x 7.79" (198 mm) spacing, 39 FPM (12 MPM) infeed/outfeed speed; Feeding material from (3) sides is possible with additional roller conveyors.22" (560 mm) Max. bunk height from floor level; 30.7" (780 mm) max. bunk height with a pit or risers; -- Complete With: Holzma's Unique "EcoPlus" System offers energy savings up to 20%; Includes Standby button & IE3 energy efficiency Motors rating.Angular cross-cut fence; Automatic side pressure device integrated into the saw carriage for cross-cutting, the machine cuts left to right to the cross-cut fence.Front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed.Min. side aligning dimension 0" (0 mm), max. side aligning dimension 149" (3,800 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Options Include: (1) Non-Powered in/out-feed staging conveyor with fork cut-outs as pictured. Micro In-feed for thin an

KOCH SPRINT SELECT.LINE 3000 CNC RAIL BORE & ROUTING MACHINE: -- Specifications:NC-positioning for "X", "Y" axis, "Z" axis is manual adjustment. Horizontal drilling station, with 3 individually controlled drilling spindles with automatic step-by-step, boring into rail components, drawer parts, chair pieces, etc. at programmed random spacing. Horizontal Routing Unit for mortise, tenon, louver, strike plate, etc. type processing. -- Working Cap: Stock length (Y) from 4.25" - 31.5" (110 mm - 800 mm), stock width (X) from 0.75" - 120" (20 mm - 3,050 mm), stock thickness (Z) from 0.5" - 2.4" (4 mm - 60 mm), max. boring depth 1.1" (28 mm).120" (3,050 mm) "X" axis divided into (4) work zones of approx 29" (736mm) ea., one part can be processed, while the others are being unloaded or loaded. -- Equipped with: (10) Stock clamping cylinders; Stock clamping system for panels/rails, small parts & solid wood parts.(3) Independent Horizontal boring spindle, 7,200 RPM, 1.25 HP (.9 kW) motor. (1) Horizontal Routing Unit for Rails, mortise, tenon, louver type processing & Door strike plates, plungers, hinges, etc., 9,000 RPM, 3HP (2.2 kW) motor. -- Operator Interface:NC Front end with 15" color touch screen monitor pad & stored in built-in CNC control using Windows type operating system with graphics and online diagnostic. serial interface and USB connection. Touch screen pad at eye-level height, integrated into machine frame structure, menu driven operator interface for function control and graphic illustration of machine functions. -- Features: Positioning speed of working units at 197 FPM (60 MPM). -- Complete with:Central lubrication system; (2) Fixed fences (1-RH & 1-LH side), (2) pop up Center Fences & (4) working zones. -- Options Include:Some additional spare parts ordered with the machine & as pictured.

KOCH BD-A BORING MACH. (FEED THRU CNC): -- Specifications: Model BD-A Boring Machine for straight rail-stock work pieces for Horizontal & Vertical Drilling; Infeed and outfeed pass height is 36.2" (920 mm) . The work pieces are transported through the working stations by means of a cam transport system.Stock is worked in clamped position. -- Stock dimensions: Stock length 9.8" - 59" (250 - 1500 mm), Stock width 1.50" - 9.8" (38 - 250 mm), Stock thickness 0.63" - 1.18" (16 - 30 mm) Note: The specified dimensions do not allow all possible combinations. -- Horizontal drilling station:Each side with (1) drilling unit with 2.7 HP (2 kW) - 3,400 RPM, Each horizontal boring heads with (3) Spindle Type D-1277 boring chucks on 16 mm centers;10 mm dia shank & 70 mm max bit lengthEach head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holesLinear path control for stock transport with low profile machine bed and linear guides, fixed stock stops,Adjustable working stations with motorized width adjustment. -- Vertical Drilling head with rotating device:(2) LH & (2) RH Type D -1277, 2.7 HP (2 kW) Adjustable vertical boring heads with dust extraction hoods & variable speed from 3,000 - 6,000 RPM; Each Drilling chuck with (1) Drilling Spindle per chuck. Drilling Chucks with KOCH "QC" (quick change) system & rotating device each head; 10 mm dia drill bit shank & 70 mm max bit lengthEach head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holesLinear path control for stock transport with low profile machine bed and linear guides, fixed stock stops,Mechanical digital read out for manual finite adjustment, (2) air hold down clamps, foot pedal control to start activation. -- Features:The stationary machine side is on the LH side (seen in transport direction) and not adjustable. The RH is adjustable via NC controlled "X" axis.The machine is equipped with Hopper Feed & has a part stack capacity of approx 9.8" (250 mm) & working capacity of approx 48 Pieces/Min.Stock infeed belts move the workpiece through an intermediate hopper to the stock support. Then the workpiece is transported through the working stations by means of transfer belts with lateral stock alignment; working pass height (36.2" (920 mm).Stock is worked in clamped position; There are stock outfeed belts at the machine outfeed. The workpiece is transferred to the out-feed hopper & removed manually. -- Operator & Machine Control:Beckoff SPS PLC for running the machine. -- Complete With: Open Station to add Dowel Inserting units at a later time ( Dowel units are not included) Manual Hand Pump Central Lubrication system for working units (1) NC controlled positioning of machine RH side (X), LH side is a fixed "0' point. Hopper Rail Feeding devices with capacity of approx 48 Work Pieces/Min. Separate drive for outfeed belt. Center Stock support. -- O

KOCH SBD-8 BORING MACH. (FEED THRU DBL END TRIM, BORE & DOWEL): -- Specifications:0.6" - 1.18" (15 - 30 mm) Material thickness; 0.9" - 9.8" (23 - 250 mm) width; & 10" - 98.4" (254 - 2,500 mm) length cap.; -- Working pass height 36.2" (920 mm); Capacity of approx 25 Work Cycles/Min. -- Features:Motorized opening with digital setting. Automatic hopper feed with hydraulic stock feed beam and automatic return conveyor to operator. -- Each side equipped with: Trim saw units, Boring units with horizontal and vertical drilling, & Dowel insertion. -- Linear path control for stock transport with low profile machine bed and linear guides. Fixed stock stops. -- Adjustable working stations with Manual & motorized adjustments. -- Horizontal Drilling:Each side with (1) 2.7 HP (2 kW) - 3,400 RPM Boring unit. -- Each horizontal boring unit has a (3) Spindle Type D-1277 drilling chucks on 32 mm centers. -- Drilling Chucks hold 10 mm dia shank & 70 mm max bit length. -- Each head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holes. -- Top Vertical Drilling:(2) Top Vertical Boring Units with rotating device. Each unit 2.7 HP (2 kW) - variable speed from 3,000 - 6,000 RPM. -- Each Drilling chuck with mechanical digital read out for manual finite adjustment. -- Drilling Chucks hold 10 mm dia drill bit shank & 70 mm max bit length. -- Each head moves on guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holes. -- Each vertical unit can be equipped with Boring blocks (swivel 0° - 90°) with pneumatic locking. -- All Vertical units are equipped with pneumatic locking & individual adjustment of the boring block. -- Distance position readouts on all heads for finite "X"/"Y" adjustments; and "Z" axis boring depth control. -- Doweling:With (2) total dowel Inserters, (2) inserter on each side, with vibrating dowel bowl feeders. -- Includes automatic dowel measurement, pressurized glue tank, & back-wash rinsing tank. -- NOTE:This machine is currently setup for 0.437" dia. x 1.75" long dowels (11 mm dia. x 44.45 mm long dowels). Other sizes & additional dowel injectors can be purchased from Koch, at additional cost. -- Operating Features:Mechanical digital readout setting for all drill stations for "X"/"Y"/"Z" axis positioning. -- The stationary machine side is on the LH side (seen in transport direction) and not adjustable. -- The RH is adjustable via motorized movement along the "X" axis. -- The machine is equipped with Hopper Feed & has a part stack capacity of approx 9.8" (250 mm) & working capacity of approx 48 Pieces/Min. -- Stock infeed belts move the workpiece through an intermediate hopper to the stock support. Then the workpiece is transported through the working stations by means of transfer belts with lateral stock alignment. -- Work pieces are automatically feed and positioned to pneumatic stops then clamped prior to trim, drilling or insertion. -- Compl

KOCH SPRINT-PTP-2-L CNC BORE, GLUE & DOWEL INSERTER: -- Specifications: Automatic step-by-step, boring, glue injection & dowel insertion at random spacing. -- Working Capacity:Stock length (Y) from 4.25" - 31.4" (110 mm - 800 mm), Stock width (X) from 0.75" - 98.4" (20 mm - 2,500 mm),Stock thickness (Z) from 0.51" - 1.57" (13 mm - 40 mm), max. boring depth 1.1" (28 mm). 98.4" (2,500 mm) X-Axis divided into (2) work zones of 47.2" (1,200 mm) ea zone.One part can be processed, while the other is being unloaded or loaded. -- Positioning Speed: 344.5 FPM (105 MPM), boring & insertion capacity up to (60) dowels/Min -- Machining:(1) Horizontal boring spindle, 7,200 RPM, powered by 1.2 HP (0.9 kW) motor; (1) Glue injection & dowel inserting system, Dowel inserter is set up for 8 mm dia. x 30 - 35 mm long dowels (other dimensions available). -- Operator & Machine Control:12." Color touch screen monitor using Windows XP operating system with graphics & diagnostic. serial interface & USB connection.Menu driven operator interface for function control and graphic illustration of machine functions -- Complete with:Central lubrication system; (1) Vibrating hopper for dowel delivery; (8) Stock clamping cylinders; (1) Removable center stop for up to (2) working zones; "Air tight" pressurized 1:1 glue tank.(was only used with water) (2) Fixed fences (RH & LH side), double sided center fence. -- Actual Model is KOCH SPRINT-PTP-2-L

KOCH SBD-B BORING MACH. (FEED THRU DBL END TRIM, BORE & DOWEL): -- Specifications:0.6" - 1.18" (15 - 30 mm) Material thickness; 0.9" - 9.8" (23 - 250 mm) width; & 4.7" - 98.4" (120 - 2,500 mm) length cap.; -- Working pass height 36.2" (920 mm); Capacity of approx 25 Work Cycles/Min. -- Features:Motorized opening with digital setting. Automatic hopper feed with hydraulic stock feed beam and automatic return conveyor to operator. -- Each side equipped with: Trim saw units, Boring units with horizontal and vertical drilling, & Dowel insertion. -- Linear path control for stock transport with low profile machine bed and linear guides. Fixed stock stops. -- Adjustable working stations with Manual & motorized adjustments. -- Horizontal Drilling:Each side with (1) 2.7 HP (2 kW) - 3,400 RPM Boring unit. -- Each horizontal boring unit has a (6) Spindle Type D-1277 drilling chucks on 32 mm centers. -- Drilling Chucks hold 10 mm dia shank & 70 mm max bit length. -- Each head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holes. -- Top Vertical Drilling:(4) Top Vertical Boring Units with rotating device. Each unit 2.7 HP (2 kW) - variable speed from 3,000 - 6,000 RPM. -- Each Drilling chuck with mechanical digital read out for manual finite adjustment with, KOCH's "QC" (quick change) system & rotating device. -- Drilling Chucks hold 10 mm dia drill bit shank & 70 mm max bit length. -- Each head moves on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holes. -- Each vertical unit can be equipped with "QC" Boring blocks (swivel 360°) with pneumatic locking. -- All Vertical units are equipped with pneumatic locking & individual adjustment of the boring block. -- Distance position readouts on all heads for finite "X"/"Y" adjustments; and "Z" axis boring depth control. -- Doweling:With (4) total dowel Inserters, (2) inserter on each side, with vibrating dowel bowl feeders. -- Includes automatic dowel measurement, pressurized glue tank, & back-wash rinsing tank. -- NOTE:This machine is currently setup for 0.437" dia. x 1.75" long dowels (11 mm dia. x 44.45 mm long dowels). Other sizes & additional dowel injectors can be purchased from Koch, at additional cost. -- Operator & Machine Control:Beckoff SPS PLC for machine function & error diagnosis. -- Operating Features:Electrical digital setting with all drill stations arranged with readouts for "X"/"Y"/"Z" axis positioning. -- The stationary machine side is on the LH side (seen in transport direction) and not adjustable. -- The RH is adjustable via motorized movement along the "X" axis. -- The machine is equipped with Hopper Feed & has a part stack capacity of approx 9.8" (250 mm) & working capacity of approx 48 Pieces/Min. -- Stock infeed belts move the workpiece through an intermediate hopper to the stock support. Then the workpiece is transported through the working stations by means of transfer

KOHLER - 20REOZJB, ...Diesel GeneratorSpecifications: Rated at 23 - 30 KVA when used as primary; 25-34 KVA as standby.90 - 600 V, 3-Phase, 60 Hz. -- Brushless; rotating field Generator has broad range capability(176) Total operating hours running time.

KOHLER - KG 100, ...Natural Gas GeneratorNatural gas-powered Generator. -- Rated at 125 KVA. -- Primary Voltage: 247/600 V - 3-phase, 60 Hz, 121 Amps. -- 100 kW, 150.5 Amps. -- 1,800 RPM - 12 Volt battery.

KOMATSU D61PXi-24 Crawler DozerSpecifications: -- Engine: 126 kW / 169 HP @ 2.200 rpm (Turbocharged) -- Max. travel speed: 5.59 MPH -- Blade type: Straight -- Hours: 6,525Equipped with: -- Joystick operator controls -- IMC / GPS Machine -- A/C and Heated Enclosed Cab -- 6-Way Blade -- U-C is 65% Remaining -- Grade control -- Oscillation -- Drawbar -- Air Ride Seat

KOMO MHS AUTOMATIC VACUUM PANEL FEEDER: -- Specifications: Single vacuum Infeed & Rake-Off system for Nested Based CNC Router operation.Designed for loading of a 5' x 10' (61" x 128") panel cap. CNC Router and can handle material up to that size; Load/Rake cycle time is approx. (25) Seconds. -- Operating Process:A fully Automatic sheet Feeder and Unloader. Designed for a single bunk application and the ability to load from 3 sides.As it moves the sheet over the router table the previously nested parts are pushed onto a conveyor or sorting table, the dust is cleaned from the router table by the dust collection on the front of the gantry and the new sheet is Squared up on the router table.Full Bunk of material is loaded into staging area constructed of tubular steel with cross-support and safety guides to properly position bunk, preventing damage by Forklift operator to loader base.Loading is performed via a vacuum cup system with (4) rows of adjustable vacuum cups, (2) cups per row; front-to-back spacing is fixed and cups are adjustable left-to-right.Material is picked up from the top of the stack and loaded onto the router table, pusher arms at front & right side square the material onto the table.After machining, the vacuum lift picks up another sheet for processing; as it brings it over the side, squaring arm rakes the processed panel and skeleton onto a side table. PLEASE NOTE: This unit will need to be integrated with the controller of your current CNC Router. Actual Model is KOMO MHS.

KOMO - VR 510 TG SOLUTION: CNC Router (ATC & Boring) -- Specifications5' x 10' Moving gantry; stationary table design in a front-to-back configuration with: 1-Zone phenolic vacuum plenum; (4) pop-up pins for sheet placement around perimeter. -- Equipped with:(1) 12 HP - HSK-63F Type ATC spindle; variable speed from: 1,000 - 24,000 RPM; 10-station ATC tool carousel; (1) 9-spindle boring unit. -- All AxesUtilize FANUC brushless AC Servo motors; driving precision ball screws on the Y- & Z-axis; helical Rack & Pinion on X-axis. -- Ride-on Profile way-bearing Systems for:Rapid feed rates up to 2,300 IPM on the X- & Y-axis; 1,200 IPM on Z-axis; motion components are serviced by an automatic lubrication system. -- GE-FANUC CNC Control with:WINDOWS Based control with: Color CRT screen; large hard disk for program storage; USB and RS-232 interface. -- LinearCircular & helical interpolation; automatic acceleration & deceleration; fast corner function; handheld teach pendant; absolute & incremental programming; feed rate & spindle speed manual override. -- Complete with:An assortment of HSK-63F tool holders; assorted collets; 25 HP TRAVAINI Vacuum Pump and documentation.

KOMO VR 510 MACH II S 5' x 10' CNC Router, with ATC, Boring, & Vacuum Pump – 7,640 Hrs. only (As of 10/12/23)!Specifications: -- Table size 60" x 120" x 32" H, with Table thickness 2". -- Travels: X-Axis 135", Y-Axis 84", Z-Axis 11". -- Positioning speed: X & Y-Axis 3,150 IPM & Z-Axis 600 IPM. Equipped with: -- Moving solid cast-aluminum single-zone vacuum "Matrix" table, with Front-to-back configuration & (4) Pop-up location pins. -- OMLAT "103909" 12 kW (16 HP) - 24,000 RPM HSK-63F Air-cooled electrospindle; Variable spindle speeds to 24,000 RPM. -- 12-Position Carousel-type automatic tool changer.Features: -- Boring unit, with (13) Pneumatically-actuated vertical spindles, (8) in X-Axis & (5) in Y-Axis, & (6) Horizontal spindles, (2) (1 + 1) in X-Axis & (1) (1 + 1) in Y-Axis. -- All Axes with THK Precision contour linear guideways, Closed loop AC Servo drives, & Precision ground ball screws. -- Automatic lubrication system. -- Heavy-duty bridge. -- Automated tool length measurement. -- Closed loop counterbalance system.Operator Control: -- GE/FANUC "210-I" CNC Control, with 10.4" Display, RS-232 Port, Remote pendant control, (3) Axes simultaneous control, Linear & Circular interpolation, Network compatible, Background editing, Self-diagnostics, High speed, High precision machining function, Canned cycles, Absolute & Incremental programming, Inch/metric capability, Cutter & tool length compensation, and Feed rate & Spindle speed override.Complete with: -- (5) Toolholders. -- QUINCY "QSV-40 ACN3A" 40 HP Rotary Screw Vacuum Pump, S/N UNO49552, with 22,334 Hrs. (As of 10/12/23).

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i63 The Flex Series of CNC routers from Komo Machine has been developed specifically for the customer who expects the utmost in technical quality and reliability at an economical price. These machines feature a moving gantry configuration and a side-mounted tool changer. Features: Four-pole, 16HP (12kw), 24,000 RPM, HSK 63F, fan-cooled spindle, 12 position automatic tool changer with aggregate capability, Air blast for optimal dust/chip evacuation and cooling of the cutting tool, Advanced Fanuc HVI servo system tuned for optimum acceleration and deceleration, Fanuc Panel i control with integrated PC 19" color display Construction, FEA "Finite Element Analysis" engineered structure, Heavy-duty steel fabrication Specifications Spindle: 1 Spindle RPM 16HP (12kw), four-pole, fan cooled Up to 24,000, fully programmable with HSK 63F taper. Table: 60" x 144" (1524mm x 3658mm), Four (4) 1" (25mm) part location pins Aggregate-Capable Tool Changer: Max 12 tools, Max Dia. 3.25" (82mm) positions full; 6.5" (165mm) adjacent positions empty, Max weight 12 lbs each / 80 lbs total (5.4kg / 36.4kg) Max Length 5" (127mm) Feed Rate/Traverse: X-Axis 2500ipm (63.5mpm), Y-Axis 2500ipm (63.5mpm) Z-Axis 1200ipm (30.5mpm), Acc/Dec83.3 in/sec² Axis Travel: 149" (3784mm) x 82" (2082mm) x 8.5" (215mm) Positioning: ±0.0008" (0.02mm) linear axis repeatability accuracy Control System: Fanuc Panel i With integrated PC and 19" color display Dust Collection Interface: 6" (152mm) diameter (recommended volume 900 cfm) Includes: Dekker Vacuum Pump NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

KRAEMER B21/40 Shaker Style Rectangular Baghouse. -- General Data: 10,889 CFM Square Baghouse with (6) 55-gal. barrel waste collection underneath (barrels not incl.), 1,406 sq. ft. of filter media from 5" dia. polyester filters (washable) for mixed dust, 1.0 TEFC HP motor for mechanical shaker bag cleaning. -- Equipped with: KRAEMER 23" Material Handling Blower ground-mounted blower belt driven by a 40 HP TEFC. -- Includes: Support legs (not shown), panels forFilter Access/Explosion doors, Electrical Control Panel with motor starters. Msc. piping if you want it.. -- Overall dimensions of housing 112" by 112" by 148" Ht. Weight of housing about 3,500 Lbs.

KRAMER K2024-1U -- K20 Series system is a heavy-duty barrel tumbler with standard capacity of 4.80 cubic feet. -- K20 system is a deburring machine solution that features a timer, variable speed, a heavy chain drive, and removable, interchangeable barrels. -- This deburring turn-key machine can configured to handle (1) to multiple barrels at a time. The barrels are mounted in a cradle and can be interchanged to divide up the load. -- Includes (1) Unlined barrel -- Variable speed control 25 - 50 RPM; 24-Hour timer; Start-stop switch. -- Complete unit dimensions are 58" W x 32" D x 50" H.
