CAM-WOOD - VPS Twin, ...Automatic Vertical Panel Saw, for Cutting & Grooving Aluminum Composites (78-3/4" x 157-1/2").The VPS TWIN is engineered with specific features for cutting or grooving Aluminum Composite or similar materials. Top to Bottom cutting height is 2,000 mm (78-3/4"). Saw head w/motor rotates 90° for rip or crosscutting grooving.Automatic Cutting Cycle: Cutting or grooving length "rip cut: Left/right" is 4,000 mm (157-1/2"); cuts or grooves panels up to 20 mm (3/4") in thickness; Digital LED readout scales for both X- & Y-axis measurement. Unique saw head design: (1) Standard Saw blade and (1) V-grooving blade all in (1) housing. An operator can select a standard or V-grooving cut automatically by a flip of a switch. Automatic “Flip of the Switch"; changeover from a cut-to-size blade cutting operation to channel grooving cutting; includes precision depth control required for ACM (Aluminum Composite Material) panel grooving and bending.4.0 HP Motor (5.5 HP Option): Spring-loaded floating shoe guide enhances dust collection and safety by enclosing the blades & cutterhead, automatically shifting material back support grid; shifts away from the saw blade cut line, preventing cuts into the grid support strips, while rip cutting horizontally; grid senses the blade/cutter position and automatically shifts away, built-in Dust Collection with collection bag mounted on the rear of the Saw frame. Alternatively, remove & bypass the bag for easy connection to your existing Dust Collection System.Equipped with: Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels.Vertical cutting stations are spaced at 40" increments to lock in the Saw beam for vertical crosscuts. Cross- or rip cutting: Material always rests firmly against the "slightly angled" back grid support; repeat rip gauge for duplicating multiple horizontal cuts; a foldout shelf that runs the entire length of the frame for small parts cutting and (2) standard flip-stops for dimension setting.Includes WARRANTY: 12-Month Factory Warranty covering defective parts and workmanship (not including wear parts); 6-Month Factory Warranty on electrical; manuals; (1) 62T x 230 mm dia. Main Saw Blade; (1) 10T x 200 dia. V-grooving blade (90°); 5,800 RPM.

CAM-WOOD - VPS IS Compact, ...Vertical Panel Saw (76" x 122" w/Scoring)Short 10' Frame Compact Model with Scoring offers many features in a compact space-saving design. -- Top to Bottom cutting height is 2,030 mm (78-3/4") without scoring and 1,930 mm (76") with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length "rip cut from left/right" is 3,100 mm (122"); cuts single or stacked panels up to 42 mm (1-5/8") in thickness.Features: -- Separate 5" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine & Hardwood, especially preventing surface chipping when cutting laminated materials. -- Includes: -- 4 HP Motor and true scoring with a 125 mm (5") dia. 24-teeth blade, 250 mm (10") dia. 80-tooth main blade; spring loaded floating saw blade enclosure - shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- Auto-shifting material back support grid shifting away from the saw blade cutline prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away.Equipped with: -- Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels; both standard inch & metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm (in inch or metric) increments to lock in the saw beam for vertical crosscuts. -- (2) Adjustable flip-stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down. -- Includes: -- Pneumatic lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade.Optional: -- Add ACCURATE TECHNOLOGY Proscale Digital Readouts on X & Y axis ($ 2,000 upgrade).

CAM-WOOD - VPS I, ...Vertical Panel Saw (82.677" x 161.417" w/Scoring)Top to Bottom cutting height is 2,100 mm with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 4,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness. Standard features: -- 4 HP Motor with a 250 mm (10") dia. 80-tooth main saw blade. -- Separate 3.15" Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cut line prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock-in the saw beam for vertical crosscuts. -- (2) Adjustable flip stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: -- (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade; Repeat Cutting Device.Optional Equipment available: Built-in Dust Collector, please add ...$ 1.250.

CAM-WOOD - VPS I +, ...Vertical Panel Saw (82.67" x 161.41" w/Scoring), Vertical-Horizontal Digital Readouts & Auto Lock System. Top to Bottom cutting height is 2,100 mm with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 4,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness.Standard features: -- 4.0 HP Motor (5.5 HP Option) with a 250 mm (10") dia. 80-tooth main saw blade. -- Separate 80 mm (3.15") Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cut line, prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- (2) Adjustable flip-stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Repeat Rip Gauge for duplicating multiple horizontal cuts. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: Vertical-Horizontal Digital Readouts; Pneumatic lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-teeth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade.Optional Equipment available: Built-in Dust Collector, please add ... $ 1,250.

CAM-WOOD - VPS APL , ...Vertical Saw w/Scoring & Panel Lifting ClampsCapacity: -- Top to Bottom cutting height is 82-1/2" (2,100 mm) without scoring and 78-3/4 (2,000 mm) with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length "rip cut from left/right" is 161.417" (4,100 mm); cuts single or stacked panels up to 1-7/8 (50 mm) in thickness. Equipped with: -- 4 HP Motor; 250 mm (10") dia. x 80-tooth x 30 mm bore main blade; separate 3.15" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine to Hardwood. -- 2-Motorized panel lifting clamps "grab panel on top edge" for bottom cuts, clamps travel on (2) vertical screws for positioning of panels (660 Lbs. cap). -- (2) LED Readouts, (1) for crosscutting at the middle of the frame and (1) for horizontal rip cuts; (2) flip stops for crosscut measuring, one located on the bottom rail and the other on the mid-height measuring rail. Complete with: -- Foldout shelf at the middle of the frame for small part cutting; automatically shifting material back support grid shifting away from the saw blade cut-line prevents cutting into the grid support strips while rip cutting horizontally. -- Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels; standard inch preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- Rip gauge for repeat (same size) rip cuts and (3) adjustable preset stops; material always rests firmly against the "angled" back grid support. Includes: -- Spring-loaded floating saw blade enclosure shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- (1) Main blade; (1) scoring blade.

CAM-WOOD - VPS I +, ...Vertical Panel Saw (76" x 122" w/Scoring), Vertical/Horizontal Digital Readouts & Auto-Lock SystemTop to Bottom cutting height is 2,000 mm (76") with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 3,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness.Standard features: -- 4.0 HP Motor (5.5 HP Option) with a 250 mm (10") dia. 80-teeth main saw blade. -- Separate 80 mm (3.15") Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cutline, prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock-in the saw beam for vertical crosscuts. -- (2) Adjustable flip-stops on inch (metric available) measuring scales, one located on the lower rail and the other on the fold-out shelf at the middle of the frame. -- Repeat Rip Gauge for duplicating multiple horizontal cuts. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: Vertical/Horizontal Digital Readouts; Pneumatic lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade.Optional Equipment available: Built-in Dust Collector, please add ...$ 1,250.

CAM-WOOD SM-324D 4-Sided Planer for L-Shape MouldingSpecial Design for “L"; Shape Mouldings; One set of Cutter heads IncludedSpecifications: -- Maximum Working Width 12";, Max. Thickness 4"; -- Hard chrome-plated table for maximum wear resistance. -- Anti-impact plate for over-width and over-thickness protection. -- Oversized top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard provides maximum durability and impact resistance. -- The three independent sections; pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding and outstanding results. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Specifically designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate based on the table feeding roller design provides smooth and precise cutting of dry and wet wood, reducing the possibility of material jams.Features: -- The base is machined by CNC machine equipment to ensure the utmost working accuracy. -- The first bottom horizontal spindle can be fitted with a trimming cutter for trimming a groove on the workpiece side to achieve perfect straightness. -- The specially designed short stock feeding mechanism combined with auxiliary pressure wheels permits the machine to perform machining on extra short stocks. -- All spindles are precision constructed and specially heat treated to provide maximum cutting stability and permanent accuracy. -- Each spindle is equipped with a mechanical digital readout giving accurate adjustment. -- Every cutter spindle can be adjusted "up and down" and "in and out" for quick setup. -- Industrial full-power motors for maximum cutting capacity.Capacity and Heads: -- Max. Working Width 12"; -- Max. Working Thickness 4-3/4" -- Min. Working Length 9½" -- Vertical stroke of side head 30 mm (1.18") -- 1st Spindle Horsepower 10 HP -- 2nd, 3rd, 4th Spindle Horsepower 10, 10, 10 HP -- Feed Motor 7½ HP -- Elevation motor 1 HP -- Spindle arbor Diameter 40 mm -- Cutter Speeds (RPM) 6,500 -- Variable Feed Speeds (FPM) 16 ~ 82Cutterhead Diameter -- 1st Bottom Head 6"; Dia x 12"; L -- 2nd & 3rd Vertical Head 6"; Dia x 3"; L -- Top Head 6"; Dia x 12"; L -- Pneumatic Air 90 PSI (CFM) 5 -- Dust Outlets Diameter 5" x 4 outlets -- N.W. (Lbs) 9800Option: -- Sound enclosure Add ...$10,900

CAM-WOOD WP-2400 Single Sided PlanerFeatures & Specifications: -- Solid cast iron construction. -- Precision ground cast iron table w/manual adjustment by hand wheel via (2) large lead screws. -- Scale & pointer readout for accurate thickness adjustments. -- solid steel 3 knife cutter head -- Fixed feed speed setting for consistent stock removal. -- Sectional steel infeed roller & segmented chip breaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- Self-braking motor 5 HP. -- Magnetic starter & thermal overload switch. -- Emergency stop. -- Operations manual, parts list & tool kit..

CAM-WOOD WP-610A Single-Sided Planer 10 HP - 24" Cap. Features: -- 24" Spiral cutter head provides precise, efficient planing with low noise levels. -- Automatic digital thickness controller for quick & accurate setting. -- Motorized worktable raises & lowers by separate motor for more efficient operation. -- Specially designed infinitely variable feed system is powered by a separate motor and allows adjustment to the optimal feed rate for planing to a precise smooth finish on both hard or softwoods. -- The sectional infeed roller & anti-kickback device & chip breaker gives the operator greater safety. -- Up to 8"; thickness large cutting capacity. -- Exhaust dust hood with 4"; dia. outlet for proper chip extraction. -- The motorized worktable includes twin quick adjustable bed rollers that can be adjusted for rough & finish planing on damp or dry lumber ensuring a consistently smooth planed finish. -- Precision sealed long-life ball bearing. -- Industrial motor for powerful cutting capacity. Heavy gauge sheet metal frame and base for maintenance-free service.Specifications: -- Table area 25" x 28". -- Max. planing width 24". -- Feed Speed (Var.) 15 ~ 60 FPM. -- Max thickness 8'' and min. Planing Thickness 1/8". -- Elevation Motor 0.5 HP. -- Cutterhead Speed 5,500 RPM. -- Cutter head diameter 4-3/4", Spiral. -- Knife insert dimensions 14 mm x 14 mm. -- Max. Cutting Depth 5/16";. -- Feed Motor 1 HP. -- Cutterhead Motor 10 HP. -- G.W. 1,850 LBS / 2,000 Lbs.

CAM-WOOD WP-760 15 HP Single Sided 30" Planer Features: -- Spiral cutterhead provides precise, efficient planing with low noise levels. -- Automatic digital thickness controller for quick & accurate setting. -- Motorized worktable raises & lowers by separate motor for more efficient operation. -- Specially designed infinitely variable feed system is powered by a separate motor and allows adjustment to the exact feed rate and allows precision smooth finish planing on both hard or softwoods. -- The sectional infeed roller & anti-kickback device & chip breaker provides greater safety for the operator -- Exhaust dust hood with 4"; dia. outlet for proper chip extraction. -- The motorized worktable includes twin quick adjustable bed rollers that can be adjusted for rough & finish planing on damp or dry lumber ensuring a consistently smooth planed finish. -- Precision sealed long-life ball bearing. -- Industrial motor for powerful cutting capacity. Heavy gauge sheet metal frame and base for maintenance-free serviceSpecifications: -- Table Area 38" x 31" -- Max. Planing Width 30" -- Max. Planing Thickness 8" -- Mini. Planing Thickness 3/16" -- Cutterhead Speed 5,500 RPM -- Cutterhead Diameter 4-3/4" Spiral -- Knife Dimensions 14 mm x 14 mm -- Feeding Speed (Var.) 15 ~ 75 FPM -- Max. Cutting Depth 5/16" -- Feed Motor 2 HP -- Cutterhead Motor 15 HP, 3 Ph, 230 V -- Table Elevation Motor 1 HP -- Digital Thickness Control Yes -- Dust Hood Outlet 5"G.W. 2450 Lbs

CAM-WOOD WP-2000S Single Sided Planer20" Planer with solid cast iron construction and Spiral Cutter Head.Features & Specifications: -- Precision ground cast iron table w/manual adjustment by hand wheel via (2) large lead screws. -- Scale & pointer readout for accurate thickness adjustments. -- Fixed feed (30 FPM) speed setting for consistent stock removal. -- Sectional steel infeed roller & segmented chip breaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- 3 HP Self-braking motor. -- Magnetic starter & thermal overload switch and Emergency stop. -- Operations manual, parts list & tool kit. Optional: CT-SCH-14T - 14 mm x 14 mm SPIRAL CUTTERHEAD BLADES ...$3.30 each

CAM-WOOD WP-1400H 52"; Heavy Duty Planer with S.C.H.55" Cap. solid cast iron construction planer with powerful 25 HP motor.Features & Specifications: -- Precision ground cast iron table with motorized worktable raising & lowering, manual adjustment by hand wheel via (2) large lead screws. -- Digital thickness display with touchpad positioning control for accurate thickness adjustments. -- 5" Spiral cutterhead with 4-sided carbide inserts provide precise, efficient planning with low noise levels. -- With (4) each 4" diameter dust outlets. -- Sectional steel infeed roller & segmented chipbreaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- Self-braking motor. -- Magnetic starter & thermal overload switch. -- Emergency stop. -- Operations manual, parts list & tool kit. Machining Specifications: -- Max. Cut Width 52". -- Max. Cut Thickness 8". -- Max. Cut Depth ¼". -- Min. Cut Length 9". -- Cutting Speed 3,600 RPM. -- Table Size (W x L) 55" x 55". -- Main Motor 25 HP, 3 Ph. -- Feed Motor 5 HP. -- Table Raising Motor 1 HP. -- Feed Rate (Variable) 0 ~ 50 FPM. -- Shipping weight 7,400 Lbs.

CAM-WOOD PL-24 TOP & BOTTOM STRAIGHTENING PLANER8" x 24" Capacity Planer for accurate and powerful two-sided planing in one pass.Includes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $3,000 Specifications: -- 25"; Max. Planning Width, 3/8" to 8"; Max. Planning Thickness. -- 1/4";Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 70 FPM Feed Speeds (Variable). -- 4,200 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges -- 25 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor and 1/2 HP Elevation Motor. -- Net weight 7,200 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-fre

CAM-WOOD PL-18 18" Wide Top & Bottom Straightening Planer. -- 18" Planer with straight knife heads with HSS knives for accurate and powerful two-sided planning in one pass.ADD for Spiral Heads with Carbide Insert Knives... $4,000.00Specifications: -- 17-3/4"; Max. Planning Width. -- 3/8 to 8" Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 10"; Min. Planning Length. -- 15 to 70 FPM Feeding Speed (Inverter Driven). -- 4,200 RPM Cutter Straight Knife Head Speed. (6,000 RPM for Spiral Cutter Head). -- (4) Knife Cutterheads. -- 15 HP Upper Motor. -- 10 HP Bottom Motor. -- 2 HP Feed Motor. -- 1/2 HP Elevation Motor. -- Table Size (L x W) 88" x 16". -- N.W. 6,500 Lbs.Features: -- Standard equipped with automatic thickness controller, easy, accurate and quick setting for the cutting thickness. -- Upper & lower straight knives or spiral cutterheads for accurate and powerful two-sided planing in one pass. -- The worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planning. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing of the surface can be performed to prevent jumping during processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with heavy-duty drive chains and gears to provide a smooth even feeding during rough or finish planning. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- The heavy-duty rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial motor for maximum cutting capacity. -- All precision sealed long-life bearing for durability -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Changing the knife on the upper cutterhead only requires removal of the upper dust chute. -- The optional spiral insert head design allows for fast, accurate insert changes and minimum down time. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth chatter-free planing regardless of the feed rate or hardness of material being planed. -- A powerful motor is utilized to make adjustments quickly

CAM-WOOD PL-38 TOP & BOTTOM STRAIGHTENING PLANERIncludes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Insert Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $8,000Specifications: -- 3" to 38"; Max. Planning Width -- 3/8" to 7"; Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 52 FPM Feed Speeds (Variable). -- 4,000 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges 40 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor -- 2 HP Elevation Motor. -- Net weight 9,800 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-free planing regardless of the feed rate or hardness of planed material.

CAM-WOOD HSTC-62 HIGH SPEED LONG BOARD VERTICAL FINGER JOINTER with the following Specifications: Technical Specifications: -- Infeed lenght 1000 mm to 5,000 mm (39" to 16') -- Working width 50mm - 300 mm (1.9" to 11.9") -- Working thickness 25 mm tp 100 mm (1" to 3.9")HSTC-62A Infeed Belt Conveyor: -- Working dimension: 24"; wide x 16’ long -- Speed at 110 FPM -- One 3 HP Inverter Drive Motor SHAPER #1: DFSR-62I - Left Side Heavy Duty Finger Joint Shaper -- Working dimension: 24"; wide x 2"; to 12"; high x 39"; to 16' long -- Scoring Saw: 2 HP motor -- Scoring Saw Blade: 7"; diameter x 50 tooth -- Scoring Saw speed: 2,850 RPM -- Trim Saw Spindle: 15 HP motor -- Trim Saw Blade: 12"; diameter x 80 tooth -- Trim Saw Speed: 2,800 RPM -- (2) Finger Joint Spindles, (1) for rough cut and (1) for finish cut, each with a 30 HP motor -- Spindle diameter: 50 mm -- Diameter of cutterhead possible without knives: 8-1/4"; -- Shaper Spindle speed: 3,800 RPM -- Conveyor belt with 3 HP Inverter Drive -- Table cycle by 3 HP Drive Motor -- Table cycle speed from (1) to (4) cycles per minute (depends on work)HSTC-62A HEAVY SINGLE TABLE OUTFEED TRANSFER CONVEYOR -- Working dimension: 24"; wide X 16’ long -- Speed at 110 FPM -- One 3 HP Inverter DriveHSTC-62A SINGLE TABLE INFEED TRANSFER CONVEYOR -- Working dimension: 24"; wide X 16' long -- Speed at 110 FPM -- One 3 HP Inverter DriveSHAPER #2: DFSR-62I - RIGHT SIDE HEAVY DUTY FINGER JOINT SHAPER WITH GLUE APPLICATOR -- Working dimension: 24"; wide x 1"; to 10"; high x 8"; to 16' long -- Scoring Saw: 2 HP motor -- Scoring Saw Blade: 7"; diameter x 50 tooth -- Scoring Saw speed: 2,850 RPM -- Trim Saw Spindle: 15 HP motor -- Trim Saw Blade: 12"; diameter x 80 tooth -- Trim Saw Speed: 2,800 RPM -- (2) Finger Joint Spindles, (1) for rough cut and (1) for finish cut, each with a 30 HP motor -- Spindle diameter: 50 mm -- Diameter of cutterhead possible without knives: 8-1/4"; -- Shaper Spindle speed: 3,800 RPM -- Conveyor belt with 3 HP Inverter Drive -- Table cycle by 3 HP Drive Motor -- Injection type adhesive spreader with standard glue height of 10"; -- Glue system included is for PVAC. (glue pump not included) -- Optional APQUIP Glue System available at extra cost -- Optional Glue Equipment available for Loctite HB X Glue at extra priceHSTC-62B OUTFEED CONVEYOR WITH BELT CLEANER -- Working dimension 24"; long X 16’ wide -- Speed at 115 FPM -- (1) 3 HP Inverter Drive -- (1) 1/2 HP motor for conveyor cleaning device HSCB-62 TIPPING CONVEYOR W/NARROW CONVEYOR -- Flips boards from vertical to horizontal for automatic feed to the Press -- Working dimensions: -- (1) Conveyor at 24"; wide x 16’ long -- (1) Conveyor at 12"; wide x 16’ long -- Speed 110 FPM -- 3 HP Inverter Drive UFJ-600 FINGER JOINT CONTINOUS ASSEMBLY MACHINE FOR INFINITE LENGTHS -- Working dimension 1-3/8"; to 12" wide X 1"; to 4"; thick by unlimited lengths -- In-feed speed from 100 to 165 FPM -- Cut-Off Saw: 7-1/2

CAM-WOOD SFJ-3800-205-FM-FAH HIGH SPEED, LONG BOARD, HORIZONTAL JOINT, FINGER JOINTER: Specifications: -- Double Chain & Slat Type Shaper Section designed for long incoming boards -- Manual infeed; Slat Bed Feed Chain runs at up to 75 FPM; lugs on 30" centers. Slat Bed powered with a 15 HP gear motor with 1:40 gear ratio. -- Table Transfer Conveyor (Powered), even ends boards to the Right and Left Shaper Fences: powered by (2) 7-1/2 HP motors -- Power raising and lowering of the holddown assemblies on both Shaper Sections; Powered with (2) 2 HP motors -- (1) Pair Scoring Saws with 2 HP motors, 50mm arbor, 2,850 RPM, scoring blade size of 7"; x 50 tooth, (4) Blades included -- (1) Pair Trim Saws with 10 HP motors, 50mm arbor, 4,275 RPM, trim saw blade size of 10"; x 100 tooth. (2) Blades included -- (1) Pair Vertical Hogging Shaper Spindles with 10 HP motors, 50mm arbor, 4,375 RPM, hogging blade size of 9.4"; x 50-tooth. (2) Blades included -- (1) Pair Vertical Finish Shaper Spindles with 20 HP motors, 50mm diameter spindles, 5,300 RPM. For -- 50mm bore x 160mm dia. cutterheads; finger length of 1.122";; cutterheads and knife profile to buyer’s specification -- Extrusion Type Glue Application System for PVAC Glues; mounted on Right Side Shaper Section. Includes glue pump, valves, and glue injection thru the applicator comb machined to buyer's specifications. -- Optional APQUIP Glue System available at extra cost -- Optional Glue Equipment available for Loctite HB X Glue at extra price -- Deduct $5,200 if provided without a Glue SystemSCC-20 TRANSFER CONVEYOR -- Conveyor between Shaper Section to the Press Section -- Working dimension: from 1"; to 8"; wide x 12"; to 12’-6"; long -- Speed 230 FPM -- Powered by (1) 3 HP HSC-65 HIGH-SPEED PRE-PRESS ASSEMBLY SECTION -- Working dimensions: 1"; to 8"; wide x 3/4"; to 2-1/4"; high x up to 21’ long -- (2) 5 HP motors drive the double flat-top chains -- Feed speeds from 32 to 295 FPM -- Includes (1) 15 HP Frequency Converter to power the feed chain motors at speeds determined by incoming boards lengths NFJ-1500 50’ HEAVY-DUTY AUTOMATIC ASSEMBLY PRESS -- Working dimension: 1"; to 8"; wide x 3/4"; to 2-1/4"; high x up to 50’ long -- Power of upper rollers: (2) 3 HP motors with a 1:10 gear ratio -- Power of lower roller: (1) 5 HP motor with a 1:10 gear ratio -- In-feed Inverter: (1) 15 HP motor -- In-feed speed: From 32 to 295 FPM -- Cut-off saw: With 7.5 HP motor driving the arbor at 2,850 RPM -- Sawblade: 14"; Diameter x 120 tooth -- Hydraulic power to the Pressing Cylinders: (2) 20HP with high-speed oil tank -- Hydraulic pressure output: 1,700 PSI at the joint -- Capacity (1) to (4) 50’ assembled boards per minute -- Machine comes arranged with equipment to assemble (3) sizes of material cross sections according to buyer’s specifications for width within +/-3/16"; width toleranceSYSTEM REQUIREMENTS FOR INCOMING BOARDS -- Incoming lumber length: 1’ to 12

CAM-WOOD SFJ-460L FINGER JOINT ASSEMBLY PRESS SYSTEM With Optional GluingDescription: -- The SFJ-460L is an automatic Assembly System, Cutoff Saw, and Press. The system performs three functions; pre-assembles finger jointed blocks with glue previously applied in the FSG 150 manual Glue Applicator (not included), cuts the assembled boards to length, and performs the final assembly when pressed by a powerful hydraulic system. When pressing is complete, boards are fed out of the Press. -- Power feed for feeding boards, stops automatically at the desired board length using the included cut-off saw as standard equipment for cutting boards to length. -- The maximum assembled board length is 15'. Specifications: -- Max. length capacity, 188"; max. width, 6"; max. thickness, 3". -- Feed speeds from 0 - 26 FPM; -- Cutoff Saw runs at 3,500 RPM and is powered by a 5 HP motor; Blade diameter is 355 mm (14") with a 1" arbor; -- With 1/2 HP feed motor and 5 HP hydraulic pump motor. Option: -- Manual Gluing unit FSG 150 Additional $ 8,990Note: Same press with 6,000 mm (19.7') capacity additional price is $6,900

CAM-WOOD TYPE F1, MODEL FAH, 6"; X 20’ Horizontal Fully Automatic Finger Joint System Single Chain TypeMECHANICAL SPECIFICATIONS FOR THE FEED SYSTEM: -- Operating speed: 120 to 150 lugs/Min -- Intermittent feed motor: 2 HP + 1:25 -- Feed chain motor: 30 HP (20 kW) Servo Drive (C2) MECHANICAL SPECIFICATIONS: RIGHT-SIDE SHAPER: -- Cutterhead Motor: 25 HP -- Spindle size: 2-3/4"; (70 mm) -- Maximum cutter head body diameter: 10"; -- Cutterhead speed: 5,500 RPM at 60 Hz -- Trim Saw Motor: 15 HP -- Trim Saw blade size: 12"; (305mm) x 80 Tooth x 5mm kerf -- Cut-off saw Speed: 4,300 RPM -- Scoring saw motor: 3 HP -- Scoring saw blade: 7"; (180 mm) x 50 Tooth x 5 mm -- Scoring saw spindle speed: 4,200 RPM -- Holddown rise and lower motor: 1/2 HP (C3) MECHANICAL SPECIFICATIONS: LEFT-SIDE SHAPER: -- Cutterhead Motor: 25 HP -- Spindle size: 2-3/4"; (70 mm) -- Maximum cutter head body diameter: 10"; -- Cutterhead speed: 5,500 RPM at 60Hz -- Trim Saw Motor: 15 HP -- Trim Saw blade size: 12"; (305 mm) x 80 Tooth x 5 mm kerf -- Cut-off saw Speed: 4,300 RPM -- Scoring saw motor: 3HP -- Scoring saw blade: 7"; (180 mm) x 50 Tooth x 5 mm -- Scoring saw spindle speed: 4,200 RPM -- Holddown rise and lower motor: 1/2 HP -- Glue Application by GLUE COMB -- Standard glue height: 6"; High, 3.8 mm pitch 3.8 mm. Finger lengths from 10 to 12 mm (Other lengths available) (K) MECHANICAL SPECIFICATIONS: SHAPER OUT-FEED: -- Speed: 230 FPM -- Feed Motor: (1) 3 HP -- Vacuum device blower with 3"; Vacuum port: 5 HP (G) MECHANICAL SPECIFICATIONS: PRE-JOINT ASSEMBLY: --Feed chain drive: (2) 3 HP motors --In-feed Inverter: (1) 7-1/2 HP --Chain type: Flat top double chain --Feeding speeds from 30 to 300 FPM (H) MECHANICAL SPECIFICATIONS: 20’ (6.2M) ASSEMBLY PRESS: --Working dimension: 3/4"; to 6"; wide x 0.60"; to 3"; high x up to 20’ long --Upper & lower roll power: (2) 2 HP motors --In-feed Inverter: 7-1/2 HP --In-feed speed: 30 to 300 FPM --PROGRAMMABLE Cut-off saw power: 5 HP --Cut-off Blade dimensions: 14"; Dia. x 120 Tooth x 1"; bore --Cut-off saw speed: 2,850 RPM --Hydraulic power: 5 HP (With high speed oil tank) --Cycle Speed: 1 to 8 Cy/MinPRODUCTION CAPACITY - PARAMETERS: -- Based on a 480-minute shift -- Finger length to customer’s specifications -- Average infeed length at the shaper section is 20"; --A verage block cross section is 2"; x 4"; -- Chain speed at the Shaper sections is 150 lugs/Min -- Press capacity is (8) 20’ loads per minute (maximum) CAPACITY OF THE SHAPERS WHEN FINGER JOINTING 2"; X 4"; x 20" BLOCKS -- (120) Blocks per minute -- x 20"; Average infeed length -- x 480 Minutes per shift -- x 0.8 Rate of utilization = 76,800 lineal feet per shift CAPACITY OF THE PRESS ASSEMBLING 20’ LENGTHS: -- (8) Assembled lengths per minute -- x 20’ Per minute -- x 480 Minutes per shift -- x 0.8 Rate of utilization = 66,440 lineal feet per shift -- NOTE: If using the cutoff saw for multi-section pressin

CAM-WOOD IAT 620-150HX INVERTER DRIVEN FINGER JOINT SYSTEM Lay-Up and Block-Staging Infeed Conveyor: -- 24" Wide x 31.5" long belt conveyor powered with 1/2 HP motors. The conveyor is controlled by the operating and system. Feeds at a constant rate of 180 FPM. Block delivery is controlled by the operator and machine system criteria to feed the Shaper. The conveyor facilitates keeping the system full and productive. FSR-62I Right Hand Inverter Type Finger Joint Shaper: -- Feed table is 24" wide and accepts blocks from 6" to 31.5" long x 5/8" to 6" wide. Shaper spindle is driven by a 20 HP motor and is equipped with provisions for vertical adjustment of 20 mm up and 20 mm down. Spindle diameter is 50 mm and runs at 6,600 RPM. 8-1/4"; maximum shaper cutterhead diameter - without knives. -- 5 HP - 4,800 RPM Cutoff and trim saw; accepts 10" dia. x 100 tooth x 5 mm blades. 2 HP - 2,850 RPM Scoring saw, accepts 7" dia. x 50 tooth x 5 mm blades. -- Conveyor powered by 1/2 HP motor. -- Table movement is inverter driven; powered by a 3 HP inverter motor with cycle speeds from 1 to 4 cycles per minute. Motor senses load and varies travel as needed. TC-62 Single Table Transfer Conveyor to the 2nd (Left Hand) Shaper: -- 24" Wide x 31.5" long belt conveyor. Powered with (1) 1/2 HP motor. Controlled by system criteria. Feeds at a constant rate of 180 FPM. FSL-62I Left Hand Inverter Type Finger Joint Shaper with Glue Extruder: -- Feed table is 24" wide and accepts blocks from 6" to 31.5" long x 5/8" to 6" wide. Shaper spindle is driven by a 20 HP motor. Spindle diameter is 50 mm and runs at 6,600 RPM. 8-1/4" Maximum shaper cutterhead diameter - without knives. -- 10 HP - 4,800 RPM Cutoff and trim saw; accepts 10" dia. x 100 tooth x 5 mm blades. 2 HP motor powers a top and a 2nd 2 HP motor powers a bottom scoring saw, both running at 2,850 RPM; accepts 7" dia. x 50 tooth x 5 mm blades. -- Conveyer powered by 1/2 HP motor. Table movement is Inverter driven; powered by a 3 HP + 3 HP inverter motor with cycle speeds from 1 to 4 cycles/Min. Motor senses load and vary travel as needed. Speed is controlled by system criteria. Injection Type Glue Applicator: -- Extrudes adhesive into the fingers without a messy runoff. 6" Comb height is standard. Finger pitch 4 mm, 10 - 12 mm finger length is standard equipment (special sizes available as optional equipment) STC-62A Single Table Conveyor Belt to the Assembly Section: -- 24" Wide x 31.5" long belt conveyor. Powered with (1) 1/2 HP motor. Controlled by system criteria. Feeding at a constant rate of 180 FPM. FJ-500A (240") Assembly Press with Cut-Off Saw: -- Capacity from 1" to 6"; wide x 1/2" to 3" high x and from 6' to 16-1/2' long. motor powers the upper and lower pre-assembly driven by (2) 2 HP motor . -- 5 HP infeed inverter drive. In-feed speed from 30 to 230 FPM. Speed is controlled by system criteria. -- 5 HP - 2,850 RPM Cutoff saw accepts 14" dia. x 120 tooth x 4 mm kerf blade. Cutoff Saw c
