SCHELLING FM-430/410 CNC Front Load Panel SawSpecifications & Features: 169" (4292 mm) Cutting length & 165.3" (4,200 mm) pull back, 3.75" (95 mm) max. saw blade projection; 25 HP (19 kW) 4,100 RPM main & 3.4 HP (2.5 kW) 5,600 RPM scoring motor. -- Equipped with: Variable saw carriage travel speed from 0 - 278.8 FPM (85 MPM), constant return of 278 FPM (85 MPM). -- Electronically controlled overhead program fence with rack & pinion driven on both sides; forward speed from 0 - 278 FPM (85 MPM), return speed of 278.8 FPM (85 MPM); equipped with (8) gripper clamps (open up to 5" (130 mm). -- Features: SCHELLING "COMPOSER" IBM-AT Compatible Computer Control; aftermarket color monitor (displays cutting dimensions and patterns w/moving graphics) , self-diagnostic, data input by keyboard; onboard optimization program. -- Complete with: 2-3/4" to 87" (2,200 mm) Long side/cross-cut aligning zone, (1) aligner in front & (1) behind the cut line. -- (3) Front mounted air float tables for moving panel from rip section to the cross-cut section, (2) movable and (1) fixed; each with their own blower. -- Rear of machine fully enclosed for safety with man-height sheet metal panels & wire screen windows. T

SCHELLING - FXH 430, ...Automatic Front Load Panel SawSpecifications: -- 169" Cutting length, 3" cutting height; 3.7" (95 mm) max. saw blade projection, 20 HP (15 kW) main & 3.5 HP (2.6 kW) scoring motor. -- Variable saw carriage travel speed from 0 - 394 FPM (0 -120 MPM) via brushless AC Servo Drive; constant return of 394 FPM (120 MPM). -- Equipped with: -- Electronically controlled overhead program fence, rack & pinion driven on both sides; forward speed from 0 - 262 FPM (0 - 80 MPM) via brushless AC Servo Drive, return speed of 262 FPM (80 MPM); (8) material gripper clamps (open up to 3.5"/ 90 mm). -- Flat guideways on the feeder and saw carriage that has a "Lifetime Guarantee". Features: -- SIEMENS "Fijitsu" IBM-compatible PC with INTEL Celeron 1.2 GHz processor, 30 GB hard drive, 256 MB RAM, floppy drive, CD ROM drive, modem, network card, (2) USB ports, and open expansion slots (all components non-proprietary). -- SIEMENS "Fijitsu" 17-inch monitor; Windows NT based "MCS" saw control software; data input by keyboard or direct downloading from office PC is possible; optimization of programs at Saw. Complete with: -- 90-1/2" (2,300 mm) Long crosscut fence (front-to-back); (2) automatic side/crosscut aligners for up to 87" (2,209 mm) crosscuts; (1) aligner in front & (1) aligner behind pressure beam; (3) front mounted air floatation tables, 24" x 82" (609 x 2,083 mm); (2) tables in rip section are movable. -- Includes: -- Roller support rails rear of machine; rear of machine fully enclosed for safety with man height wire screen fencing.

SCHELLING FXH 430/410 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications:169" (4,300 mm) Cutting length & 167" (4,250 mm) pull back; 3.9" (99 mm) max. saw blade projection, 23 HP (17 kW) main & 3.5 HP ((2.6 kW) scoring motor. -- Saw Carriage: Electronically controlled saw carriage with rack & pinion drive; variable travel speed 1 - 394 FPM (1 - 120 MPM), constant return of 394 FPM (120 MPM). -- Pusher Fence: Electronically controlled overhead pusher fence, rack & pinion driven on both sides; (9) Gripper clamps that open up to 3.5" (90 mm). -- Forward speed 0 - 262 FPM (0 - 80 MPM), return speed 262 (80 MPM) FPM; travel via brushless AC Servo Drive -- Operator & Machine Control:PC Front-end with Schelling "MCS" + Windows "NT" operating system.17" Color display with SVGA resolution (displays cutting dimensions & patterns w/moving graphics); virtually unlimited storage capacity, standard keyboard & mouse.Ethernet card; 128 MB Ram, 56K modem. Integrated graphical self-diagnostic, remote diagnostics by the factory is possible via dedicated phone line; data input by keyboard or possible direct downloading from office PC.SCHELLING "MCS" software displays simulation of patterns before actual cutting; graphical representations of cut-to-size parts in production shows the operator what to do in "real time". -- Complete with:2,300 mm Long crosscut fence (front-to-back), (2) automatic side/crosscut aligners for up to 87" (2,210 mm) crosscuts, (1) in front & (1) behind pressure beam cut line.(3) Front mounted air floatation tables, each table 24" x 83" (609 x 2,108 mm), rear of machine fully enclosed for safety with man-height safety fencing. -- Actual Model is SCHELLING FXH 430/410

SCHELLING FH4-330/310 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications: 130" (3,330 mm) Rip Cutting cap. & 130" (3,300 mm) pull back; 4.1" (105 mm) saw blade projection; 3.5" (90 mm) Max book height; 24 HP (18 kW) - 3.800 RPM main motor, 3 HP (2.2 kW) - 5,500 RPM scoring motor. -- Saw Carriage: Variable saw carriage travel speed from 16 - 525 FPM (5 - 160 MPM), constant return of 525 FPM (160 MPM). -- Pusher Fence: Programmable overhead program fence, rack & pinion driven on both sides; forward speed from 0 - 262 FPM (0 - 80 MPM), constant return speed of 262 FPM (80 MPM).Pusher fence with (8) material gripper clamps with double clamping fingers, clamps open to 3.5" (90 mm).Operator & Machine Control:PC Front-end controller with SCHELLING "MCS" Evolution + "HPO" Optimizing System + "Windows XP" operating system.17" Color screen displays cutting dimensions & patterns with "REAL TIME" moving graphics, self-diagnostic, data input by keyboard or direct downloading from office PC. -- Complete with:90.5" (2,300 mm) Long crosscut fence (front-to-back), (2) side/crosscut aligners, (1) in front & (1) back of the cut-line, up to 87" (2,210 mm) cross-cutting cap.Electronic scorer adjustment, from the machine control, (3) Front-mounted air float tables with (1) central fan, 24" x 83" (600 x 2,100 mm) each, of which (2) are movable.Fully enclosed for safety with a man-height wire screen fence with access doors. -- Includes:Original Docs, Manuals, tools & tooling as pictured. -- Actual Model is SCHELLING FH4 330/310

SCHELLING FM-H 330/330 Automatic Panel Saw 129.9" (3,200 mm) Cutting length, 3.3" (85 mm) max. saw blade projection.Specifications & Features: -- 11 kW (15 HP) main & 1.6 kW (2 HP) scoring motor. -- Variable saw carriage travel speed from 0 - 262 FPM (80 MPM), constant return of 262 FPM (80 MPM). -- Electronically controlled overhead program fence with grippers, rack & pinion driven on both sides, forward speed from 0 - 262 FPM (80 MPM), return speed of 262 FPM (80 MPM); (6) Clamps open up to 3.9" (100 mm). -- 1,500 mm Long crosscut fence (front-to-back), (2) side/crosscut aligners for up to 87" crosscuts, (1) in front & (1) behind pressure beam. -- SCHELLING "COMPOSER" operating system; on-board SCHELLING optimizer, color monitor (displays cutting dimensions & patterns w/moving graphics), self-diagnostic, data input by keyboard & mouse or direct downloading from office PC is possible. Complete with: -- (3) Front mounted air float tables for moving panel from rip position to crosscut position; fully enclosed for safety with man-height sheet metal panels & wire screen windows.Specifications subject to verification.

SCHELLING FMH 430 Front Load Panel Saw169.2" (4,300 mm) Cutting length, 161" (4,100 mm) pull-back, 3.3" (85 mm) max. saw blade projection, 25 HP (19 kW) main saw motor & 2.5 HP (2 kW) scoring motor. -- Variable saw carriage travel speed from 0 - 262 FPM (80 MPM), return speed of 262 FPM (80 MPM), LED ammeter to show load of main saw motor during operation. -- Electronically controlled overhead program fence, rack & pinion driven on both sides, forward speed from 0 - 262 FPM (80 MPM), return speed of 262 FPM (80 MPM); (9) material gripper clamps open up to 3.1" (80 mm). -- SCHELLING "COMPOSER" Electronic control with color monitor (displays cutting dimensions and patterns w/moving graphics), self-diagnostic, data input by keyboard or possible direct downloading from office PC. -- 90-1/2" (2,300 mm) Long crosscut fence (front-to-back); (2) side/crosscut aligners for up to 87" (2,210 mm) crosscuts; split pressure beam, (1) in front & (1) behind. -- (3) Front mounted air float tables for moving panel from rip position to cross-cut position, 24" x 78" (610 x 1,981 mm) each, (2) in the crosscut section are movable. -- Rear of machine fully enclosed for safety with man-height sheet metal panels & wire screen windows. -- Main saw blade is 370mm, Scoring blades are 200mm. Actual model is FM 430 MCS-F.This machine came equipped with the following optional upgrades: -- Formatting stops (for cutting panels with plastic laminate hanging over the edge), Real time label printing (industrial printer included), Symmetrical Cutting, Window Cutting, Postform Scorer (edge scoring saw that aligns with the main saw blade to reduce chipping at the exit side of the main blade travel), Large miter gauge that mounts to the saw to facilitate making mitered cuts, & Laser light that shows the cutline for freehand manual cutting.

Schneeberger 9 Sculptor Profile GrinderSwiss Made, Schneeberger Automated High Precision Grinder for Finger Joint, router bits, saw blades, straight and milling Cutters. Specifications -- Grinding Motor: 1,500 - 3,000 RPM. -- Cooling Pump: 2,800 RPM. -- Grinding Wheel Speed: 3,000 - 6,000 RPM. -- Grinding Wheel Diameter: 50 - 200 mm. Grinding Wheel Bore: 30 mm. -- Cross Travel of Grinding Wheel: 200 mm. Vertical Travel of Grinding Wheel: 400 mm. -- Grinding Head: Swivel-able. -- Worktable Travel: 400 mm. -- Coolant Capacity: 25 liters. -- Dimensions: 1,226 mm Lenght x 1,160 mm width x 1,180 mm height; Weight - 320 kG.10" Width cap., 11.5" dia., max. profile depth 5.5", radial clearance angle up to 35ø, lateral clearance angle up to 15øEquipped with & Features; -- 2 HP - 1,500 RPM motor, variable grinding speed 2,000 - 4,000 RPM, three sided full jet cooling. -- All std. grinding equipment for HSS grinding, 1-1/2" spindle arbor, (2) wheel flanges, (1) knife holder, dresser.

--In Auction--Starting bid: $100-- Schuetz Tool Bladder Press Specifications: (2) Shuttle tables, approx. 55” x 106” press capacity. Hot air design with 3mm silicone membrane to press veneer into profile, typical cycle time 3 minutes using proper glue that sets at 200°F. Can use PVA which would extend cycle time to approx. 15 > 45 minutes depending on the actual glue mix used to achieve 80%+ cure strength. Includes Hydraulic Pump. SPECIAL NOTE: Fully operational, however, need 4 or 5 heating rods replaced, new rod parts are included for you to install ( don't have the capability to remove them). The current average operational temperature is 150° F. NOTE: Above specs are taken from literature and thought to be accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

Schuetz Tool Bladder Press Specifications: (2) Shuttle tables, approx. 55” x 106” press capacity. Hot air design with 3mm silicone membrane to press veneer into profile, typical cycle time 3 minutes using proper glue that sets at 200°F. Can use PVA which would extend cycle time to approx. 15 > 45 minutes depending on the actual glue mix used to achieve 80%+ cure strength. Includes Hydraulic Pump. SPECIAL NOTE: Fully operational, however, need 4 or 5 heating rods replaced, new rod parts are included for you to install ( don't have the capability to remove them). The current average operational temperature is 150° F. NOTE: Above specs are taken from literature and thought to be accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

SCHUTTE PULVERIZER COMPANY - Model 40 HZF, ...HammermillComplete with the following major components & features: -- Integrated 18", 4,000 CFM Blower. -- WEBSTER 16 Ft. Horizontal Vibrating Conveyor. -- Motor Controls. -- Main drive motor, 75 HP - 3,540 RPM. -- Hammer width is approximately 1-1/4 in. wide. -- 3-1/4" Shaft. -- 24" Dia. Rotor and a tip speed of 22,600. -- 17-1/2" Rotor width. -- 3/4" Main chamber steel. -- Factory Frame.MANUFACTURER'S STATED KEY FEATURES:&#9679 Heavy-Duty plate construction with replaceable liner plates. &#9679 Heavy-Duty grates available in a variety of sizes. &#9679 Heavy-Duty rotor assembly. &#9679 24" Dia. x 3" thick flywheel. &#9679 Built-in fan conveys material up to 50' vertically and 100' horizontally.&#9679 Reversible anvil. &#9679 2-Way reversible "raked" hammers pull wood in without feed rolls. NOTES: &#9679 The HZF Series Horizontal Trim Scrap Grinder is a high-speed, high production Grinder designed specifically for processing longer lengths of wood scrap such as rippings, edging, and trim blocks.&#9679 Available in (4) standard sizes from 10" to 36" wide.

SCHUTTE 280.100 HAMMERMILL -- Type 13100P -- Rotor 24" dia. x 48" wide -- Housing 3/4" thick -- Shaft speed 3,600 rpm -- Heavy duty, statically and dynamically balanced rotor -- (96) Standard notched heat treated hammers 3/8" thick -- Also included; two screens -- Motor 125 HP -- Applications; Planer shavings, dry wood chips, etc. etc.

SCHUTTE PULVERIZER COMPANY - Model 40 HZF, ...HammermillComplete with the following major components & features: -- Integrated 18", 4,000 CFM Blower. -- Mellott Vibrating Conveyor -- Main drive motor: 75 HP -- Hammer width approx. 1-1/4" wide. -- 3-1/4" Shaft. -- 24" Dia. Rotor and a tip speed of 22,600. -- 17-1/2" Rotor width. -- 3/4" Main chamber steel.MANUFACTURER'S STATED KEY FEATURES:&#9679 Heavy-Duty plate construction with replaceable liner plates. &#9679 Heavy-Duty grates available in a variety of sizes. &#9679 Heavy-Duty rotor assembly. &#9679 24" dia. x 3" thick flywheel. &#9679 Built-in fan conveys material up to 50' vertically and 100' horizontally.&#9679 Reversible anvil. &#9679 2-Way reversible "raked" hammers pull wood in without feed rolls. NOTES: &#9679 The" HZF Series" Horizontal Trim Scrap Grinder is a high-speed, high production Grinder designed specifically for processing longer lengths of wood scrap such as: Rippings, edging, and trim blocks. Available in (4) standard sizes from 10" to 36" wide.&#9679 Each model features a built-in fan driven off of the main mill shaft, saving energy and valuable floor space while also significantly increasing production.

SCHUTTE-BUFFALO 15 Series, Model 15300 Wood Grinder;Complete with the following components and features: --Carbon Steel Construction. --Rotor approximate 44" diameter x 72" wide. --Approximately 3" wide Swinging Hammers, tip speed 20,700. --Top feed, bottom discharge. --Bottom screen approximate 5040 square inch area. --Clam shell housing. --500 HP, TEFC, 3/60/460 volt, 1785 RPM drive Motor with coupling and shaft guard. --Mounted on a heavy-duty steel Factory Frame. --NOTES: Largest model of the 15 Series. &#9679 Machine weight 16,000 Lbs.

SCHUTTE BUFFALO - Model WA16L, ... HammermillModel# WA16L, 3500 RPM, with filtration system and multiple grates for destruction sizes. -- Also, includes Electrical panel. --This system is apart and palletized. All you have to do is pick it up and transport it to you. -- System was in perfect working order when it was taken apart and palletized for transport. --System is perfect for destruction of computer hard drives and different types of media.

SCM P-170 Feed Through Moulder5-Head, 6-5/8" x 4-3/4" capacity. Specifications: -- Head sequence: Bottom 6.5 HP, right 6.5, left 6.5 HP, top 9 HP, Universal 9 HP motor; -- 1-13/16" Dia. spindles at 6,000 RPM, spindles equipped with high cap. precision bearings, all set-up adjustments on front side of machine. -- 15 - 85 FPM Feed speed, 3.6 HP Cardan (chainless) feed drive, motorized feed beam with air-loaded feed wheels.Complete with: -- 84" Long infeed table with quick lever thickness adjustment for stock removal, manual Waxilit bed lubrication. -- Note: No cutterheads or tooling included.

SCM - OLIMPIC K 201 HFA, ...Automatic Compact Edgebander with: 3 mm Max. coiled edgebanding thickness & High Frequency motorsSpecifications: -- Edgebanding thickness cap. (for both coil & strip): 0.4 - 3 mm (0.02" - 0.19"). -- Min. panel length for coiled edges (min. width 200 mm) 140 mm (5.51"). -- Min. panel width for coiled edges: 65 mm (2.56"). -- Panel thickness: 8 - 40 mm (0.31" - 1.57"). -- Feed speed:9 MPM (29 FPM).Equipped with: -- Automatic adjustment of all units when panel thickness is changed. -- 20" Dia. coil table. -- Automatic coil feed magazine; manual strip feed. -- Teflon-coated glue pot. -- 1.2 mm (0.05") Cap. guillotine. -- Eye-level control with: GEFRAN "1000" LED Temperature controller. -- Adjustable feet.Workstations: -- Single-motor end trimming unit with: (1) 0.19 kW (1/4 HP) - 12,000 RPM High-frequency motor & copying device. -- Top & bottom flush trimming unit with: (2) 0.35 kW (1/2 HP) - 12,000 RPM high-frequency motors, and front & vertical copying devices.

SCM OLIMPIC K208ER EDGEBANDER WITH CORNER ROUNDING15/32" (12 mm) Max. edge cap., 2" max. (w/corner rounding only 1-3/4") banding height, 2-3/8" min. panel width and 6-5/16" min. length.Equipped with: -- Automatic strip & coil feed magazine w/Heavy Duty 3 mm PVC cap. guillotine. -- Teflon coated glue pot with glue roller application system complete w/automatic recycling device for unused glue. -- Digital thermostat adjustment for temperature control. -- 3-roll pressure unit w/pneumatic controls for all pressure rollers.Workstations: -- Double motor front & rear end trim (0.4 HP - 12,000 RPM motor ea.), tilts 0° - 15°, end trimmers mounted on 45° THK guide. -- Top & bottom fine/radius trimmer w/pneumatic positioning from control panel. -- Corner rounding units for leading & trailing edges. (2) 0.5 HP - 200 Cy Motors ea. -- Top & bottom PVC scraper for up to 5 mm radius. -- Top & bottom buffing unit (0.33 HP - 2,800 RPM motors). -- Hot air heating unit for PVC/ABS. -- Single 42 FPM fixed feed speed, 1 HP drive; heavy 3/4" drive chain with chain pads traveling on round & flat tracks.Complete with: -- Microprocessor for line control & glue temperature (can store up to 50 preset programs), swiveling control panel, pneumatic positioning of super finish, full cover sound enclosure, 200 Cy - 5 kW frequency inverter w/automatic motor brakes for all HF motors; includes used tooling. NOTE: Video of equipment was made in February 2021, prior to being decommissioned and placed in storage fully wrapped and ready for transport.

SCM - S 52, ...Straight Knife Planer20" Width cap.; knife cutterhead; 9 HP main motor (approx.); 1/8" to 9-1/4" motorized opening with mechanical digital readout; max. depth of cut 5/16"; 10" min. length of workpiece; (4) feed speeds at: 21 - 32 - 42 & 55 FPM; table size: 20-1/2" x 33-1/4". -- Equipped with: Chip breaker; sectional grooved infeed & solid outfeed roller.

20" (520 mm) Width cap.7,5 HP (5,5 kW) main motor ÷4-knife cutterhead÷1/8" to 9-1/2" (3 - 240 mm) ÷motorized opening mechanical scale for bed position max. depth of cut 5/16"÷10" min. length of workpiece ÷(4) feed speeds at 18/30/39/51 FPM (6/10/13/17 m/min.)÷table size 20-3/4" x 33-1/4". ÷Includes: Knife sharpening attachment ÷ Equipped with: Chip-breaker, sectional grooved infeed & solid outfeed roller.

SCM - S520 E, ...Planer Specifications: -- 20" Width cap.; 9 HP main motor; 4-3/4" dia. 4-knife TERSA cutterhead at 4,500 RPM. -- 1/8" - 9-1/4" Powered opening with digital readout for fine adjustment; max. depth of cut 5/16"; 10" min. length of workpiece. -- (4) Feed speeds: 20 - 33 - 43 & 56 FPM; table size 20-3/4" x 39".Equipped with: -- Chip breaker; sectional grooved infeed & solid outfeed rollers; (2) adjustable bed rollers. -- Complete with: Magnetic starter & shaving hood.
