HOLZMA PROFIMAT HPL 500 38/16 REAR LOAD, AUTOMATIC PANEL SAW: -- Specifications: 149.6" (3,800 mm) Cutting length & pull-back; 6.7" (170 mm) max. main blade projection; 40 HP (29.8 kW) Main & 3 HP (2.2 kW) scoring motor. -- Saw carriage: Infinitely variable speed from 0 - 492 FPM (0 - 150 MPM), constant return of 492 FPM (150 MPM).Carriage is electronically & automatically controlled (cutting height & length) through the CADmatic according to the material/program being processed."Power-Loc" quick change system for fast and easy saw blade change.NC Controlled scoring saw adjustment from the control panel during operation -- Pusher Fence:Rack & pinion digital drives with AC Servos on both sides, forward speed 295 FPM (90 MPM), return speed 295 FPM (90 MPM).(7) Material clamps which open up to 6.7" (170 mm): (3) Standard clamps with two fingers & (4) clamps with one finger.(4) Trimming rakes for thin strips/scrap removal are attached at the clamps. -- Operator Interface:HOLZMA "Power Touch Control" IPC multi-tasking controller with Windows "7 PRO" + "CADmatic 4.0 PRACTIVE" operating system;Intel i5 Dual-core Processor, Intel HD graphics card, 4GB RAM, SATA 2-250GB hard drive, (6) USB ports, (1) serial port, ATI/DVI video port, Standard industrial keyboard connection,21.5" LCD "Touch-Screen" monitor with real-time moving 2D & 3D graphics (displays cutting dimensions & error diagnostic); virtually unlimited cutting dimension memory.(2) Ethernet 10/100 interface connections; downloading from office PC is possible. -- Rear of machine: Profile rails & "Combi-rollers" at 50 mm centers; (2) integrated front & cross-aligning units before cutting to prevent off-set panels within the same book. -- Front of machine: (3) Air flotation tables 85" x 31.5" (2,160 x 800 mm) with (1) central blower unit. -- Rear Lift Table:7-Ton (14,000 LBS), 4-Column electro-hydraulic powered rear lift table running lengthwise with fork cut-outs, 150" x 63" (3,800 x 1,600 mm) capacity. Powered rollers are 4.2" (107 mm) dia x 7.79" (198 mm) spacing, 39 FPM (12 MPM) infeed/outfeed speed; Feeding material from (3) sides is possible with additional roller conveyors.22" (560 mm) Max. bunk height from floor level; 30.7" (780 mm) max. bunk height with a pit or risers; -- Complete With: Holzma's Unique "EcoPlus" System offers energy savings up to 20%; Includes Standby button & IE3 energy efficiency Motors rating.Angular cross-cut fence; Automatic side pressure device integrated into the saw carriage for cross-cutting, the machine cuts left to right to the cross-cut fence.Front & rear forks electronically & automatically controlled through the CADmatic according to the material/program being processed.Min. side aligning dimension 0" (0 mm), max. side aligning dimension 149" (3,800 mm)."Power-Loc" quick blade change system for main/scoring blades. -- Options Include: (1) Non-Powered in/out-feed staging conveyor with fork cut-outs as pictured. Micro In-feed for thin an

120" Carriage travel, 13" wide anodized aluminum sliding table w/lateral handle, 45ø tilting arbor, 13-3/4" blade cap., 4-3/4" max. depth of cut, 49" rip cut cap. -- 9 HP Main motor, (3) cutting speeds 2,800 - 4,000 & 5,600 RPM, 1 HP - 8,500 RPM scoring unit with external fine adjustment, manual height & tilt adjustment, all point slide lock, on/off switches at end of sliding table. -- Complete with: Steel overarm protection guard, outfeed table extension, rip fence w/micro-adjust, crosscut fence with (2) large stops and "goniometer" miter system; mechanical holddown clamp for multiple panels. --From seller: "This Saw though several years old has been meticulously maintained with weekly cleaning and lubrication (which are the only maintenance needed besides regular belt checks and blade changes). It operates comparably to when it was purchased new. Scoring blade adjustments are easily performed at the front facing adjustment knobs."

LAZZARI JUNO 3200 Sliding Table Saw with 126" Carriage TravelSpecifications: -- 13" Wide anodized aluminum sliding table w/lateral handle; 45° tilting arbor, 13-3/4" blade cap., 4-3/4" max. depth of cut, 49" rip cut cap. -- 9 HP Main motor, (3) cutting speeds 2,800 - 4,000 & 5,600 RPM, 1 HP - 8,500 RPM scoring unit with external fine adjustment, manual height & tilt adjustment, all point slide lock, on/off switches at end of sliding table. -- Complete with: -- Steel overarm protection guard, outfeed table extension, rip fence w/micro-adjust, crosscut fence with (3) flip stops. -- Includes: -- Three-phase transformer.

MAYER - PS 80P: Front Load, Automatic Panel Saw -- Specifications125.9" (3,200 mm) Cutting length & 122" (3,100 mm) pull back; 3.14" (80 mm) max. saw blade projection.12 HP (9 kW) Main saw motor; 320 mm main saw blade (3,800 RPM); 30 mm bore dia.; 1.5 HP (1.1 kW) score blade; 150 mm (8,680 RPM); 30 mm bore.Electronically controlled saw blade height adjustment; electronically controlled scoring blade horizontal (side-to-side) adjustment; "QUICK CHANGE" main & scoring blade system. -- Saw CarriageInfinitely variable forward cutting speed from: 5 - 262 FPM (1.5 - 80 MPM); constant return speed of: 262 FPM (80 MPM).Automatic cutting length adjustment; rack & pinion drive (not chain); AC Servo motor drives on the saw carriage with rack & pinion on hardened & ground guideways. -- Pusher FenceElectronically controlled overhead program fence; forward speed: 0 - 82 FPM (0 - 25 MPM); return speed:196 FPM (60 MPM); fence retracts: 122" (3,100 mm) Behind cutting line; AC Servo motor drives on the pusher fence with: Rack & Pinion on hardened & ground guideways.(6) Material gripper clamps open up to: 80 mm (3.1"); (3) Are closely spaced in crosscut area; the other (3) are at equal distance in rip cut area. -- Operator InterfaceMAYER "PC 5400" + Windows Operating System with: "REAL TIME" graphic display; 14" Color monitor mounted in a pivoting console.3-COM Network interface: 10/100 MBs with RF45 (TP) connection; (2) serial, (1) parallel interfaces, and SVGA graphics adapter; data input by keyboard or downloading from office PC is possible.PC 5400 Control System features: Automatic cutting length (material is scanned by sensor underneath the packet on the saw bed); electronically controlled automatic cutting height adjustment (also can be used for grooving by entering depth and width of groove at control).Automatic trim calculation: Constant display of remaining material in both axis during programming (eliminates need for operator calculations during programming). -- Complete with:Left angle crosscut fence: 78.7" (1,999 mm) long;, automatic crosscut aligner from: 3/4" - 47.2" (19 - 1,199 mm) with automatic presetting.Rear slotted pressure beam to minimize offcut; (3) front mounted air flotation tables: 79" x 24" (2,000 x 600 mm); segmented transparent plastic safety guards on front of pressure beam; wire mesh screen enclosure around rear machine table. -- Actual model - MAYER PS/80P/3200

ORIGINAL 3691-03 Overhead Rail Panel SawSpecifications: -- Sturdy welded steel frame for saw head and beam arm; 7.5 HP motor; 1" dia. arbor; 1-3/8" long arbor; saw head with automatic electro-mechanical motor brake. -- 20" Max. blade dia.; 7" max. cutting depth @ 90°; 3-1/2" @ 45°; 62" long x 1", 4" & 6" thick max. crosscut cap. -- Complete with: -- 36" x 60" MDF table; heavy gauge steel base & legs for solid support. -- Includes: -- Upper & lower blade guards; magnetic starter and overload protection. -- Single-phase option available for;...$ 250.

ORIGINAL 3691-01-7 Overhead Rail Panel SawSpecifications: -- Sturdy welded steel frame for saw head and beam arm; 7.5 HP motor; 1" dia. arbor; 1-3/8" long arbor; saw head with automatic electro-mechanical motor brake. -- 20-1/2" Max. blade dia.; 8" max. cutting depth @ 90°; 4" @ 45°; 60" long x 1" max. crosscut cap. -- Complete with: -- 36" x 60" MDF table; heavy gauge steel base & legs for solid support. -- Includes: -- Upper & lower blade guards; magnetic starter and overload protection.

ORIGINAL - 3691-03: Overhead Rail Panel Saw w/Infeed & Outfeed TablesSpecifications -- Sturdy welded steel frame for saw head and beam arm; 7-1/2 HP motor; 1" dia. arbor; 1-3/8" long arbor; saw head with: Automatic electromechanical motor brake. -- 20" Max. blade dia.; 7" max. cutting depth @ 90°; 3-1/2" @ 45°; 62" long x 1", 4" & 6" thick max. crosscut cap. Complete with: -- Heavy gauge steel base & legs for solid support; upper & lower blade guards; magnetic starter; overload protection. Includes -- Infeed & outfeed tables.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5x Entry-level Vertical panel saw for cutting various materials, straight & square to 1/32". Specifications: 3.25 HP Industrial Duty saw motor; 8" saw blade cap. with 1-3/4" max. material thickness; 64" crosscut (vertical position) with spring-loaded counterbalance system; unlimited rip-cut length cap. Features: Saw head rotates 90° to switch between rip and crosscut modes; adjustable scales on a 10' welded steel frame. Complete with: Zinc plated 1-3/4" guide tubes with "Nylatron" 4-roller bearing system; +/- 1/32" squaring or straight cutting tolerance. NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

SAFETY SPEED MFG 7400 Vertical Panel Saw: Mid-level Vertical for a variety of materials that do not require a 100% chip-free finish. -- 2 HP single-phase Induction Saw Motor. -- 8" Blade cap. with 2-1/8" max. material thickness. -- 64" Crosscut (vertical position) with spring loaded counterbalance system. -- 120" Frame length with unlimited rip cap. -- 90° Saw head rotation to switch between cross- and rip cut modes. -- Triangulated welded steel frame with base mounted aluminum rollers. -- Midway fence for small part cutting. -- Adjustable scales on a 10' welded steel frame. -- Heavy extruded beams utilizing dual-V bearings. -- 0.005" Squaring or straight cutting tolerance. -- Optional material scoring attachment. 120" L x 46" W x 96" H (Crated Dimensions - 125" L x 51" W x 101" H). Machine pictured with Optional Wheels and Frame.Also available with 3 HP single-phase motor.

Mid-level Vertical for a variety of materials that do not require a 100% chip-free finish. -- 3 HP Industrial-duty saw motor. -- 8" Blade cap. with 1-3/4" max. material thickness. -- 64" Crosscut (vertical position) with spring loaded counterbalance system. -- Unlimited rip capacity. -- 90° Saw head rotation to switch between cross- and rip cut modes. -- Triangulated welded steel frame with base mounted aluminum rollers. -- Option: Midway fence for small part cutting. -- Option: Adjustable scales on a 10' welded steel frame. -- Zinc plated 1-3/4" guide tubes with "Nylatron" 8-roller bearing system. -- ± 1/64" Squaring or straight cutting tolerance. -- 120" L x 36" W x 90" H (Crated Dimensions - 125" L x 41" W x 95" H). -- Machine pictured with Optional Wheels and Stand.

Mid-level Vertical for a variety of materials that do not require a 100% chip-free finish. -- 3 HP Worm drive industrial duty saw motor. -- 8" Blade cap. with 1-3/4" max. material thickness. -- 74" Crosscut (vertical position) with spring loaded counterbalance system. -- Unlimited rip capacity. -- 90° Saw head rotation to switch between cross- and rip cut modes. -- Triangulated welded steel frame with base mounted aluminum rollers. -- Midway fence for small part cutting. -- Adjustable scales on a 10' welded steel frame. -- Zinc plated 1-3/4" guide tubes with "Nylatron" 8-roller bearing system. -- ± 1/64" Squaring or straight cutting tolerance. -- 120" L x 36" W x 98-1/2" H (Crated Dimensions - 125" L x 41" W x 103-1/2" H). -- Machine pictured with Optional Wheels and Stand.

Panel Saw and Router Combination on (1) vertical 10' steel welded frame. -- Can be changed from saw to router in less than a minute and has accuracy of 1/64" straight and square. -- 3 HP, 15 amp Industrial duty saw motor. -- 3-1/4 HP, 11 amp Industrial duty router motor. -- 8" Blade cap. with 1-3/4" max. material thickness. -- 62" Crosscut (vertical position) with spring-loaded counterbalance system. -- Equipped with a MID-WAY FENCE system with stop as standard equipment which makes processing small panels more efficient. -- The patented self-adjusting router carriage provides for a consistent depth of cut when routing. -- Unlimited rip capacity. -- 90° Saw head rotation to switch between rip and crosscut modes. -- Adjustable vertical and horizontal rulers. -- Chrome plated 1-3/4" guide tubes with 8 "Nylatron" roller bearing system. -- Adjustable floating router head. -- 4 Material clamps. -- 2 Blind dado stops. -- Optional equipment available: "Gold", "Silver" and "Bronze" Packages are customized to maximize the benefits for building component shops and save when purchased together. -- "Bronze Package" includes: 5' QUICK STOP Gauge, saw blade 840ATB1 for general purpose wood, fixed stand, wheels. --"Silver Package" includes: 8' QUICK STOP Gauge, Dust Collection Kit (Vacuum additional) saw blade 860ATB for fine wood, fixed stand, wheels. -- "Gold Package" includes: MID-WAY FENCE, 8' QUICK STOP Gauge, saw blade 860NRATB for melamine, veneer and laminates, fixed stand, wheels. Other Options available: extensions, Stop bar gauge, MID-WAY FENCE flip stop, dust hood and hose kit, dust vacuum system (1 HP or 2-1/4 HP), hold down bar, specialty saw blades and router bits. -- Contact Product Manager for prices on optional equipment. -- 120" L x 36" W x 90" H (Crated Dimensions - 125" L x 41" W x 95" H).

The 7000 vertical panel saw is a high capacity production machine. This heavy-duty saw offers incredible durability and accuracy at a very affordable price. -- Sporting a 3 HP, 3-Ph motor - (Model 7000M - 2 HP 1-Phase deduct $ 205) this machine will rise to the occasion during the toughest of applications. -- The saw carriage rides on two aluminum anodized extruded beams with integrated linear v-guides allowing the machine to deliver an accuracy of .015". -- The rugged steel frame will handle years of abuse in the most challenging working environments. -- Shipping anywhere in continental U.S.;...$ 649.

SCHELLING FM-430/410 CNC Front Load Panel SawSpecifications & Features: 169" (4292 mm) Cutting length & 165.3" (4,200 mm) pull back, 3.75" (95 mm) max. saw blade projection; 25 HP (19 kW) 4,100 RPM main & 3.4 HP (2.5 kW) 5,600 RPM scoring motor. -- Equipped with: Variable saw carriage travel speed from 0 - 278.8 FPM (85 MPM), constant return of 278 FPM (85 MPM). -- Electronically controlled overhead program fence with rack & pinion driven on both sides; forward speed from 0 - 278 FPM (85 MPM), return speed of 278.8 FPM (85 MPM); equipped with (8) gripper clamps (open up to 5" (130 mm). -- Features: SCHELLING "COMPOSER" IBM-AT Compatible Computer Control; aftermarket color monitor (displays cutting dimensions and patterns w/moving graphics) , self-diagnostic, data input by keyboard; onboard optimization program. -- Complete with: 2-3/4" to 87" (2,200 mm) Long side/cross-cut aligning zone, (1) aligner in front & (1) behind the cut line. -- (3) Front mounted air float tables for moving panel from rip section to the cross-cut section, (2) movable and (1) fixed; each with their own blower. -- Rear of machine fully enclosed for safety with man-height sheet metal panels & wire screen windows. T

SCM TECNOMAX SC/4 WS 8-1/2' Sliding Table SawSpecifications: -- Max. depth of cut with 315 mm (12.40") Dia. blade: 100 mm (3.94") at 90°, 70 mm (2.76") at 45°. -- Main saw: 3.6 kW (4.82 HP) Motor, Blade dia. 315 mm (12.40"), Arbor tilt 0° - 45°, Blade speed 4,000 RPM. -- Scoring saw: Blade dia. 100 mm (3.94").Equipped with: -- 11-1/2"; x 102"; x 35-1/2"; H Aluminum sliding table, 840 mm (33.07") LR Fixed table. -- Manual raise, lower & tilt. -- Mechanical digital tilt indicator.Complete with: -- 39-1/4"; L x 3-1/2"; H Rip fence, with 51" Cutting width cap. & Cam-locking. -- 650 x 1,100 mm (29.59" x 43.32") Squaring frame, with Crosscut fence with 1,800 mm (70.87") Cutting cap., (2) Flip stops & Sliding outrigger support.Actual model is SC/4 WS-N.

SCM MINIMAX - FORMULA S1, ...Sliding Table SawSpecifications: -- 120" Cap. with: Scoring; 9 HP main motor & belt driven scoring blade; -- Manual tilting of the arbor 0° - 45°; Manual raise-and-lower of the main blade; -- 50" crosscut capacity with a movable fence.Features: -- "Easy-Set" scoring adjustment; heavy cast iron trunnion; 12" main saw blade dia. with 1" Arbor, 110 mm scoring blade dia.; -- Max. cutting height 3-1/2" at 90° & 2-3/4" at 45°; 1-speed arbor; 8,000 RPM on scoring blade. -- Complete with: 4" Main dust extraction outlet, miter fence & crosscut fence assembly with (2) flip stops.

SCM - SI 400 NOVA: Sliding Table Panel SawSpecifications & Features -- 126" Stroke with scoring; telescoping crosscut fence with panel support; back squaring fence: (2) Flip-stops; 3/4" dado capacity. -- Max. cutting height: 3-3/4" at 90°; 2-3/4" at 45°; 51" rip cut cap. with movable fence; "EZ Dial" adjustable split scoring blade assembly. -- 35" x 21" Main fixed table.Equipped with: -- 9 HP Main blade motor; 1 HP scoring blade motor; tilting arbor 0° - 45°; 300 mm (11.8") main saw blade dia.; 1" main blade arbor; 4,000 RPM. -- 100 mm (3.9") scoring blade dia.; 3/4" scoring blade arbor; 8,000 RPM; 2-position table lock mechanism. Complete with: -- "EZ Dial" adjustable split scoring blade assembly: Simply turn the dial to adjust the width of the score. This system eliminates the need for shims and is fully adjustable in 0.1 mm increments. -- Handwheels in front for lifting & tilting of saw blades; blade guard on riving knife with dust outlet. Includes: 120 mm Main dust collection outlet.

SCM - FORMULA S35: Sliding Table SawSpecifications -- 10' Cap. with: Scoring; 9 HP motor for main & scoring blade; tilting arbor: 0° - 45°. -- 126" Table stroke; 51" rip cut capacity with movable fence. -- 350 mm (13-3/4") Main saw blade dia.; 120 mm (4-3/4") scoring blade dia.; max. cutting height: Approx. 120 mm at 90°; 4,000 RPM. Complete with: -- Overhead guard with: 4" Dust extraction outlet. -- Crosscut fence assembly with: (2) Flip stops.

SCMI MINI MAX - Formula S 2: Sliding Table SawSpecifications & Features -- 128" Cutting cap. w/standard scoring saw and carriage; 5 HP motor; stop on fence for cuts extendable to 128"; 50" cutting width w/ rip fence.Equipped with: -- 14" Main blade; 4-1/2" scoring blade; 4-1/2" max. blade cutting height at 90°; 3-1/2" max. blade cutting height at 45°. -- 4,000 RPM Main blade speed; 8,500 RPM scoring blade; 90° - 45° blade tilting.

SCM TECNOMAX - SC/4 WS, ...8-1/2' Sliding Table SawSpecifications: -- Max. depth of cut with 315 mm (12.40"); dia. blade: 100 mm (3.94") at 90°; 70 mm (2.76") at 45°. -- Main saw: 3.6 kW (4.82 HP) Motor; blade dia. 315 mm (12.40"); arbor tilt 0° - 45°; blade speed 4,000 RPM. -- Scoring saw: Blade dia. 100 mm (3.94").Equipped with: -- 11-1/2"; x 102"; x 35-1/2"; H Aluminum sliding table; 840 mm (33.07") LR fixed table. -- Manual raise, lower & tilt. -- Mechanical digital tilt indicator.Complete with: -- 39-1/4"; L x 3-1/2"; H Rip fence with: 51" Cutting width cap. & cam locking. -- 650 x 1,100 mm (29.59" x 43.32") Squaring frame with: Crosscut fence; 1,800 mm (70.87") cutting cap.; (2) flip stops & siding outrigger support.NOTE: Saw is deinstalled as pictured in Photo #2. - Photo #1 shows Seller's other Saw, which is also available to purchase (EXF # PS-011935). Both Saws are one serial number apart. Seller confirms that all machine components are present.
