SORBINI MR1TFF26420 Single Head Differential Roll Coater;SORBINI Single head differential Roll Coater, 51" width cap., all functions PLC controlled.Specifications: -- (1) 9.8" Dia. applicator roll. -- (1) 6.8" Dia. hard chromed doctor rolls. -- Chromed wiper blades with precision control on applicator & doctor rolls. -- 1 HP Motor with AC inverter control on applicator rolls, 0.5 HP motor with AC inverter, speed control on all rolls. -- 3-15/16" Part thickness opening with dial indicator readouts mounted in both hand wheels, "quick change" feature of applicator rolls. -- Variable conveyor feed speed from 20 - 80 FPM, 1 HP AC inverted control for speed control. -- Complete with: Fluid pump with automatic low level fill, return trough.

Combination Differential/Filling Machine SMARTCOATER with: 880 mm (34-1/2") Working/pass-through height; one of the best units ever produced. Dual purpose machine can be utilized as: -- 1) A standard differential Roll Coater for application of UV sealer or top coat material; as a differential Roll Coater the 1st application head is independently utilized to for precisely controlled application. -- 2) A Filling Machine for application of H2O or UV filling material to calibrate substrates with porous veneer; as a Filling Machine, both heads are utilized for application and reverse smoothing or pressing of UV filling material.Specifications: -- (2) Heads, 53" width cap. - 1st Head: 250 mm (9-3/4") Dia. rubber coated applicator roller with separate doctor roller; doctor blades are oscillating. -- 2nd Head: 245 mm (9-5/8") Dia. chromium coated smoothing/reverse roller w/separate chromium doctor roll; all heads are floating to compensate for calibration errors & minimize damages from oversize parts. -- Adjustable opening 0 - 100 mm (3-3/4"); thickness protection safety bar connected to pneumatic emergency lifting; EX-proof electrics on all motors. -- 2 HP Conveyor drive: Variable feed speed from 26 - 131 FPM; 1/2 HP variable RPM drive on doctor rolls and separate 3/4 HP drive on applicator & reverse rollers. -- Electrical power: 480 V, 3-Ph, 3.8 kW; 7 Amps.

2022 CNC controller! Under power & ready to demo! 3-Axis CNC Vertical Milling Machine - Seller has outgrown and upgraded to larger capacity CNC Machining Center. - Table size 10" x 50" x 38” H - Travels: X-Axis: 31", Y-Axis: 17", Z-Axis: 23-1/2" - Quill travel 5" - Quill diameter 100 mm (3.94") - No. 40 Spindle taper - Variable spindle speeds 80 - 4,000 RPM - Rapid traverse 150 IPM - Distance from spindle nose to table (Maximum part height) 23-1/2" - Distance from spindle center to column face 19" - Maximum weight of workpiece 1,320 Lbs. - Maximum work capacities: 1" Drilling & Tapping mild steel & Milling (Metal removal rate/mild steel) 5 cu. in./min. - 5 HP Spindle motor - 560 in-oz Continuous torque D.C. servo motors & Precision ground ball screws for X, Y, & Z-Axes - YEONG DIEN Automatic lubrication unit Includes: - 2022 "PROTOTRAK SMX3" 3-Axis CNC Control/3-Axis Digital Readout (Control defines tool path based upon user defined part geometry), with Pentium PC-processor with 512 MB RAM, 10.4? Color active-matrix screen, Touchpad, (4) USB connectors, MICROSOFT "WINDOWS" Operating system, Program feedrate override & Tool path graphics - ALL MACHINE PARTS "MAXI TORQUE-RITE" Pneumatic drawbar, with 40 - 50 ft. Lbs. of torque - EKSTROM CARLSON "MISTIC MIST 1ST-2LC" 1 Gallon Capacity Coolant Mist Generator, with Adjustable air & Liquid control valve - WALDMANN "ROCIA.FOCUS" 600 Lumen 5,000 K Sealed Housing LED Work Light

SPEC AIR Model R120-26RD-OC Baghouse Filter Auto Shaker Type Dust Collector Loaded with features. -- Capacity of approx.15,500 CFM and the following features and components: -- EB-26, 60 HP SPEC AIR, Air Handling Fan , 15.500 CFM @ 16" SP mounted in a negative pressure configuration (clean air side) with return air and with automatic 26" dia. Abort Gate Damper according to NFPA-68-69 CODE. 110 volt actuated by the Spark Detection System. -- HANSENTEK AN104 Spark Detection/Suppressions system Per NFPA 64-68 and c/w BPS-9X4 Booster Pump & FLEXCON P2P20 Tank. -- 1,961 sq. ft. of filter area using (97) high efficiency Polyester bags. Operating at 7.9 to 1 ACR (Air to cloth ratio). -- 26"; Diameter Inlet & outlet duct. -- Tangential inlet with Backflow Damper, according to NFPA-68 CODE. -- Top mounted motorized bag shaker. mechanism powered by 1.5 HP. -- Rotary Air Lock with 96" clearance. (4) leg support steel frame & Safety access ladder. -- Explosion Venting Doors, according to NFPA-68 CODE. -- Filter Bag size approx. 9" dia. x 9' long, -- Inline 26" dia. Silencer muffler on return air duct. -- Ground mounted Belt Driven Fan complete with TEFC motor and inspection door. -- Features: 60 HP Soft Start Controller. -- ENGINEERED ELECTRIC Control Panel with starters and controls. -- Manometer gauge to monitor differential pressure (life) of filter media. -- Housing/Support Steel dimensions: 120" long x 120" wide x 32' high. Approx. 13, 500 Lbs. -- Some pictured pipe is included.

WEEKE BHX 050 CNC MACHINING CENTER (VERTICAL): -- Specifications: Flexible "Vertical" Machining Center uses less than 5 sq/m of valuable floor space, in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for "X" axis is 98.4" (2,500 mm); "Y" axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning SpeedThe "BHX 050" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axes & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring Unit(1) 3 HP (2.3 kW); Variable speed from 1,500 - 7,500 RPM motor; (8) independent vertical spindles with: (4) Spindles in "X" axis & (4) spindles in "Y" axis.(3) Horizontal Spindles with: (1+1) In "X axis & (1) spindle in "Y" axis.Boring block has QUICK-CHANGE spindle system. -- Operator Interface:WEEKE "POWER CONTROL" + Windows + WoodWOP "Mosiac" Operating System."IntelCore 2 DUO" Processor. 17" TFT Monitor: International keyboard, soft touch keypad & industrial mouse; RS-232 serial ports;, USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive; modem; Ethernet connection.Real time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:&#9679 Extension of Work Piece Length up to 3,050 mm (120") &#9679 (1) "X" Axis grooving saw; 9,000 RPM, saw blade dia. 100 mm.&#9679 (1) 7 HP (5 kW) Electro-spindle router with: Manual, Hydraulic "QUICK-CHANGE" tool system; "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is: WEEKE BHX 050.

WEEKE - VENTURE 106M (BMG 111): CNC Machining Center (w/ATC/Boring) -- Specifications: Working Capacity: "X" Axis is 123.2" (3,130 mm); "Y" axis is 61.02" (1,554 mm); "Z" axis stroke is 7.2" (185 mm); max. material thickness 5.9" (150 mm). -- Positioning Speed: "X" & "Y" Axis travel speed of 262 FPM (80 MPM); "Z" axis travel speed of 66 FPM (20 MPM).The machine head travels on THK linear motion guides on all axes. -- Worktable:(6) Movable K-Table support rails with: Side mounted raise-and-lower panel feeding rails; (2) vacuum pods per rail.(6) Pneumatic backstops; (2) pneumatic side stops create (2) working zones.Laser Positing System setup assistance for precise rail & vacuum pod positioning. -- Boring Unit:3 HP (2.3 kW) Motor; variable speed from 1,500 - 7,500 RPM; (12) vertical "QUICK-CHANGE" drill spindles: (7) Spindles in "X" axis & (5) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis & (1 + 1) in "Y" axis. -- Machining: (1) 12 HP (9 kW) Air-Cooled electrospindle router with: HSK F63 Adaptor with: Programmable 1,250 - 24,000 RPM; constant torque from 9,000 - 24,000 RPM; RH or LH rotation; powered by a frequency inverter.(1) 8-Position ATC magazine located at the RH side of the machine. -- Operator & Machine Control: WEEKE IPC "PC 85 Power Control" + Windows "XP" + WoodWOP 6.1 Operating System; INTEL Core2 Duo Processor; "BECKOFF" PLC for (3) axes with: Linear, circular, & helical interpolation.17" TFT Monitor with: 2D / 3D "REAL-TIME" graphics; industrial keyboard; mouse for data entry.(1) SATA Hard drive; 160 GB; central USB front side bus connection; Ethernet connection 10/100 Mbit; all mounted in separate free-standing Control Panel. -- Complete with:(1) 84 cbm/Hr Vacuum Pump: 3-Zone safety mats (will stop machine if operator enters the active work area); safety fences; scrap conveyor; handheld pendant controller. -- Actual Model is: WEEKE VENTURE 106M / BMG 111.

WEEKE - BHX 050: CNC Machining Center (Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 meter² of valuable floor space in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for: "X" Axis: 98.4" (2,500 mm); "Y" axis: 33.4" (850 mm); max. part thickness: 2.4" (60 mm). -- Min. worktable part size for: "X" Axis: 7.8" (200 mm); "Y" axis: 2.7" (70 mm); min. part thickness of: 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The BHX 050 reaches movement speeds of: 164 FPM (50 MPM) in "X" & "Y" axis; 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit(1) 2.4 HP (1.8 kW); Variable speed from: 1,500 - 7,500 RPM motor; (8) independent spindles with: (4) Spindles in "X" axis & (4) spindles in "Y" axis. -- (6) Horizontal spindles with: (2 + 2) In "X" axis; (1 + 1) in "Y" axis. -- Boring block has "QUICK CHANGE" Spindle System. -- Operator InterfaceWEEKE "POWER CONTROL" + Windows + WoodWOP 5.0 + Operating System; "IntelCore 2 DUO" Processor. -- 17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 Serial ports; USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive; modem; Ethernet connection. -- Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:&#9679 (1) "X" Axis grooving saw with: 9,000 RPM Motor; max. saw blade dia. 100 mm. &#9679 (1) 7 HP (5 kW) Electrospindle router with: Hydraulic "QUICK CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE BHX 050

WEEKE - BHX 055: CNC Boring Machine (P to P Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space in addition to an innovative panel handling system. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm); "Y" axis 33.4" (850 mm), max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning SpeedThe "BHX 055" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axis & 50 FPM (15 MPM) in "Z" axis with total safety - providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW) Variable speed from 1,500 - 7,500 RPM motor; (13) independent spindles with: (8) Spindles in "X" axis & (5) spindles in "Y" axis.(4) Horizontal spindles with: (1 + 1) in "X" Axis & (1 + 1) in "Y" axis.Boring block with "Quick Change" vertical spindle system. -- Operator & Machine Control:WEEKE "Power Control PC 85" + Windows + WoodWOP 6.0 Operating System; Intel Core "2 DUO" Processor.17" TFT Monitor: International keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive: modem, Ethernet connection.Real time multitask processing: Programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:(1) "X" Axis grooving saw, 9,000 RPM, max. saw blade dia. 100 mm.

WEEKE - BHX 500 OPTIMAT: CNC Machining Center (2-Head)Specifications -- Flexible "TOP & BOTTOM" Machining Center that uses an innovative panel handling system. -- Working CapacityMax. workable part size: "X" Axis is 98.4" (2,500 mm); "Y" axis 39.3" (1,000 mm); max. material thickness 3.1" (80 mm).Min. workable part size: "X" Axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness 0.157" (4 mm). -- "BHX 500 OPTIMAT" Positioning Speed can reach movement speeds of: 452 FPM (138 MPM) in "X" axis; 262 FPM (80 MPM) in "Y" axis;164 FPM (50 MPM) in "Z" axis; with total safety, providing an unmatched working capacity. -- Worktables:Automatic LH air floatation infeed table; automatic RH outfeed transfer conveyor with belts; both infeed & outfeed are "Robot Ready". -- Boring Units:(1) Top mounted boring block; 3-1/2 HP (2.7 kW); variable speed from 1,500 - 7,500 RPM; (32) vertical spindles with "QUICK CHANGE" drill bit adaptors.(1) Bottom mounted boring block: 3-1/2 HP (2.7 kW); variable speed from 1,500 - 7,500 RPM; (32) vertical spindles with "QUICK CHANGE" drill bit adaptors. -- Machining Units(1) Top mounted 8 HP (6 kW) Router spindle with: "ETP" 25 "QUICK CHANGE" Hydro-Chuck adaptor; 1,200 - 24,000 RPM with RH rotation. (1) Bottom mounted 8 HP (6 kW) Router spindle with: "ETP" 25 "QUICK CHANGE" Hydro-Chuck adaptor; 1,200 - 24,000 RPM with RH rotation. -- Sawing Units: (1) Top mounted NC Controlled 0° - 90° "X /Y" grooving saw; 3-1/2 HP (2.7 kW); 7,500 RPM; max. saw blade dia. 125 mm.(1) Bottom mounted NC Controlled 0° - 90° "X /Y" grooving saw; 3-1/2 HP (2.7 kW); 7,500 RPM; max. saw blade dia. 125 mm. -- Operator & Machine Control:WEEKE "PC85T Power Control" + Windows "XP"+ WoodWOP operating system; 17" TFT monitor; international keyboard, soft touch keypad & industrial mouse.RS-232 Serial ports; USB ports; (1) 1.44 MB floppy disk drive; (1) CD -ROM, modem; all mounted in a separate control console. Real time multitask processing; programs can be transferred via diskette or downloaded by wire. Built-in 1,500-Watt air conditioner for constant temperature & dust-free environment. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety fences/devices. -- Machine Features: The machine can work the panel from above & below at the same time and can produce (2) identical or mirrored panels per cycle with no difficulty.The "BHX 500 OPTIMAT" can also machine porous materials since the pieces are held with grippers directly managed by the numerical control; it can even process small pieces and carry out "through" machining.(4) Operating modes at each cycle, it can change automatically from top machining to bottom machining, to top & bottom machining together, either on (1 or 2) stacked panels. -- Actual Model is WEEKE BHX 500 Optimat

WEEKE - BHX 050: CNC Machining Center (Vertical) -- Specifications Flexible "Vertical" Machining Center: Uses less than 5 sq/m of valuable floor space; includes an innovative Panel Handling System. -- Working CapacityMax. workable part size for: "X" Axis: 98.4" (2,500 mm); "Y" axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for: "X" Axis: 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed"BHX 050" Reaches movement speeds of: 164 FPM (50 MPM) in "X" & "Y" axes; 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit(1) 3 HP (2.3 kW) Variable speed from: 1,500 - 7,500 RPM Motor; (8) independent vertical spindles with: (4) Spindles in "X" axis; (4) spindles in "Y" axis.(3) Horizontal Spindles with: (1 + 1) in "X axis; (1) spindle in "Y" axis.Boring block has: QUICK-CHANGE Spindle system. -- Operator & Machine ControlWEEKE "POWER CONTROL" + Windows + WoodWOP 6.0 + Operating System; "IntelCore 2 DUO" Processor.17" TFT Monitor; international keyboard; soft touch keypad; industrial mouse; RS-232 serial ports; USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive; modem; Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices.Options include:&#9679 (1) "X" Axis grooving saw: 9,000 RPM; saw blade dia. 100 mm.&#9679 (1) 5 HP (3.6 kW) Electrospindle router with: Hydraulic "QUICK-CHANGE" tool system; "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. &#9679 Voltage transformer: 600 Volts operation. -- Actual Model: WEEKE BHX 050.

WEIMA C 150 Briquette PressSpecifications & Features: -- Produces 2" (50 mm) dia. Briquettes; -- Hopper opening of 41" x 41" (1,040 x 1,040 mm); hopper volume 1.43 cu/yd (1.1 cbm). Equipped with: -- 9 HP Hydraulic motor; 0.75 HP auger motor; hydraulic oil volume of 26.4 gallons (100 liters). -- Vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material; extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio at 2,600 PSI; hourly output up to 80 - 120 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors").Features: -- Briquette length control, chrome plated clamp, oil level switch, control panel side-mounted to hopper, and overheating protection for hydraulic oil. Solid German engineering. - Freight, start-up, discharge pipes, etc. not included.

WEIMA TH 1500 M Briquette Press (Square Brick) -- Specifications: Produces 5.9" x 2.3" (150 x 60 mm) rectangular briquette; hopper opening of 55" x 55" (1,400 x 1,400 mm); hopper volume of 2.46 cu/yd (1.88 cbm). -- Equipped with: 40 HP Hydraulic motor; 2.6 HP auger motor; 3.0 HP agitator motor; hydraulic oil volume of 264 gallons (1,000 liters). -- Volume reduction from chip/dust to block up at a 10:1 ratio; hourly output up to 800 - 900 Lbs. -- Features: Conical shaped agitator with curved hopper corners, "Bridge Breaker" mounted on agitator; automatic "On/Off" integrated in feeding hopper; hydraulic oil cooling, overheating protection for hydraulic oil. -- Complete with: Touch-Screen control panel on swivel mount; discharge ramp for briquette extraction, chrome plated clamp, and an oil level switch. -- Solid German engineering.

WEIMA TH 814 Briquetter A volume reduction of 90% is possible through the briquetting of wood, paper, aluminum and biomass or synthetics, providing significant savings in labor, disposal and storage costs.Material is hand fed or by dust system into the hopper, where an agitator pulls it into the auger and pressing chamber. Specifications: -- Produces 80 mm (approx. 3.1") dia. compacted logs; approx. 2.4 cu. yd. (55.1 x 55.1 x 37") square vertical hopper, 18 HP motor. -- Hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio; approx. hourly output between 300 - 400 Lbs/Hr.Features: -- Auto on/off integrated into feeding hopper; automatic briquette length adjustment; conical-shaped agitator; dust connection at pressing unit.Options: -- Hydraulic cooling for 24-hour operation, heating for cold weather start-ups; plastic tubing discharge into Gaylord or carousel bagging system. .

WEIMA TH 714 Briquette Press (Cylindrical). -- Produces 2-3/4" (70 mm) dia. x 4" (100 mm) long compacted logs. -- Specifications: Approx. 1.4 m³ vertical hopper, 18 HP (13.5 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 240 - 280 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). -- Equipped with: Centralized control panel for easy operation, MITSUBISHI Logic control & solid German engineering. -- Complete with: Auto on/off switch, auto length adjustment, & oil level sensor. -- Optional:: Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.

WEIMA TH 514 Briquette Press (Cylindrical). Produces 2" (50 mm) dia. x 4" (100 mm) long compacted logs. -- Specifications: -- Approx. 1.4 m³ vertical hopper, 12 HP (9 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 80 - 120 Lbs/Hr. ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). -- Equipped with: -- Centralized control panel for easy operation, PLC Logic control & solid German engineering. -- Complete with: -- Auto on/off switch, auto length adjustment, & oil level sensor. -- Optional: -- Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.

WEIMA WLK-13 Shredder with Econogrind ES 560/1000 Granulator Production LineFeatures & Specs: -- Single shaft Shredder/Grinder, 51" x 47" hopper opening (straight-sided); -- 2 cu. yds. cap.; 368 mm (14.5") rotor dia. x 51.2" rotor length.Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (68) welded knife holders, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear; drop out discharge, lift up door for easy purge cleaning when used in plastics application. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full.Features: -- Heavy-duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL-approved components. -- Recommended for plastic, paper or wood applications. Econogrind ES 560/1000 Granulator. -- Includes conveyor, conveyor magnet to pull any metal out, finish grind granulator, and Mettler Toledo weigh hopper, and dust collector. -- Wash system that can be included in the sale -- Line is still hooked to power, Lots of extra parts are included.

WEIMA ZM-40 Quad Shaft 4-Shaft ShredderEquipped with: -- Dual drive motors - (2) 30 HP Drive motors. -- Hopper opening measures 51" x 55.1" (1,300 x 1,400 mm); cutting chamber opening of 30" x 27.6" (762 x 700 mm). -- Rotor length of 30" (762 mm); Rotor speed 25 RPM; cutting disc 11" (280 mm) diameter. -- Complete with: -- Control Panel with soft start and 16' cable bundle. -- Note: "Quad Shaft" Shredders, unlike Dual Shaft Shredders, allow shredded material to be circulated through the cutting chamber until it is small enough to pass through the sizing screen. -- Machine weight: 5,500 Lbs.

WEIMA WLK 13 Vertical Hopper-fed Low Noise Grinder Specifications: -- Single shaft Shredder/Grinder, 51" x 47" hopper opening (straight sided), 2 cu. yds. cap.; 368 mm (14.5") rotor dia. x 51.2" rotor length; 60 HP motor and hydraulic ram. -- Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (68) welded knife holders, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear; drop out discharge, lift up door for easy purge cleaning when used in plastics application. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full. -- Features: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Recommended for plastic, paper or wood applications.

WEIMA WLK 4 Vertical Hopper-Fed, Low-Noise GrinderSpecifications: -- 31-1/2" x 39" Hopper opening at the top, 1.1 cu. yds. cap. Features: -- 30 HP rotor motor, Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. Equipped with: -- (14) Replaceable back bolt-on cutter knives, welded knife holders standard, recessed concave cutters with low clearance over the 10" dia. rotor extends cutter life, protects the bolts, and reduces machine wear. -- 6" Dia. dust collection outlet (1,200 CFM required); 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content); -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, the lateral force on the ram is minimized by a unique "U-Joint" mounting system. Includes: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for an additional charge). Options: -- Flared hopper, log Spacer, 2nd row of knives, material discharge auger; programmable logic controls;

WEIMA - WLB 400, ...Horizontal Low Speed Grinder Equipped with: -- 25 HP Rotor motor; rotor with (18) 4-way indexable, replaceable cutter knives. Features: -- Top infeed roller; 15-1/2" x 2-1/2" feed opening; Heavy-Duty Industrial Grade construction with stress relieved shell and frame; Heavy-Duty outboard roller bearings; separate electrical control panel. Complete with: -- 8" Dia. collection outlet; 3/4" screen.
