CAM-WOOD BR-3532X CONSTRUCTION BORING MACHINE35-Spindle boring head on 32 mm centers with position indicator.Features & Specifications: -- Stops in 0° & 90° with pneumatically assisted positioning in vertical & horizontal. -- 0" - 3" Adjustable drilling depth with speed control. -- Head height fine adjustment with mechanical digital readout. -- (2) 2 HP - 3,400 RPM Motors. -- Cast iron 52" x 19-1/4" table with side fences for mirror-image. -- Line boring fence with repeat stops. -- Foot actuated pneumatic clamps & drill cycle.Complete with: -- Magnetic starter, overload protection. -- Optional quick-change chucks $28.00 ea.

CAM-WOOD DP-1710F Drill Press17" Floor model Drill Press with a durable cast iron head, table and base.Equipped with: -- 1 HP motor, 140 - 3050 RPM motor drives (12) different speeds making it suitable for heavy industrial use. -- The spindle is equipped with a heavy duty 1/8"?- 1/2" drill chuck on a #3 Morse taper. -- Large 12-3/8" x 12-3/8" table with clamping slots. -- Rack and pinion system makes it easy to adjust the table up and down.

CAM-WOOD TRS 150F Frame SawCAM-WOOD Frame Saws are engineered and designed to make extremely accurate cuts, cutting products with very tight tolerances up to 0.004" and often eliminating sanding before proceeding to the next step . The unique thin frame saw design accepts different saw frames, blade combinations, and allows multiple saw fence configurations to produce single, double or multiple cuts in a single pass.Specifications: -- 3/4" Min. to 6" max. working width; 1-1/4" min. to 7-3/4" max. working thickness (height); 7-1/2" minimum length; finished material > 0.1094". -- 0.043" to 0.055" Saw blade thickness; runs up to (22) blades at one time at (450) stroke/minute with a 8-1/4" stroke length; accommodates blades 1.575" wide x 19.685" long. -- Saw blade frame is powered by a 15 HP motor. Feed speeds of 1 to 5 FPM by 1 HP motor. -- Features automatic oil lubrication system requiring 90 PSI air pressure. Cooling system via water and air. -- Minimum kerf multi-blade frame saw designed to maximize production and minimize material losses to kerf. -- Machine supplied with PLC controller to allow operator fast, instant set-up changes. -- All controls are centrally located for the operator to easily adjust & control operation. -- Material waste reductions of up to 20% are achievable by use of the thin kerf blades (0.043" ~ 0.055"). -- A special air blast system cools the blade for longer service intervals and removes saw dust from the gullet of the blade to reduce temperature and increase blade life.Note: Frames are available in different configurations.

CAM-WOOD - XL 300, ...Dip Chain Gang Rip Saw: (...Typically in stock for immediate delivery!)12" Width cap.; 3/8" min. to 4-3/4"; max. cutting depth; 14"; min. stock length.Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0.25 mm (see drawing after the "literature link); with 12"; usable cutting width. -- Accepts saw blades from 12"; - 14"; dia.; arbor is powered by a 50 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 - 100 FPM; feed chain is 12"; wide. -- Table: 30"; Wide x 62"; with 12"; between the column and the 1st saw blade. - Integrated 6"; dia. dust extraction connection.General Description: -- Designed for high quality Production Line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence; equipped with: Measuring ruler gauge. -- Triple anti-kickback fingers mounted at the infeed side provide max. safety protection; (2) rows from the top and (1) row from the bottom. -- Heavy-Duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision built saw head ensures accuracy for straight line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- Power raise & lower to the arbor. -- (4) Pressure rollers & (2) holddown plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for max. motor power output and guarantees Heavy-Duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radial rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or longer length boards. Options when ordering with machine: -- (1) Set spare feed chain link, please add ...$ 86. -- (1) Set of arbor drive belts consisting of (6) matched belts, add ...$ 600. -- Additional saw sleeve with spacer set consisting of: (2) 50 mm, (3) 25 mm, (4) 10 mm, (18) 1 MM, (10) 0.5 mm, (8) 0.25 mm, Please add... $ 685.

CAM-WOOD MRS-340-1M Dip Chain Gang Ripsaw with one Shifting Blade:Specifications: -- Cutting width up to 13";; machine will pass thru 25-1/2"; -- 3"; Maximum depth of cut with 12"; diameter blades. - Will cut 4"; thick with 14"; blades (optional). -- With 70 mm saw spindle; accepts 90 mm bore sawblades -- With air-loaded pressure rolls, standard fence, and feed chain. -- Urethane Chain Pads and Pad Holders optional -- With (1) powered moveable blade and fixed blades. -- Moveable blade controlled with a joystick. -- With (10) push buttons for pre-programmed selective ripping -- The shifting blade moves at 20 to 80 mm/second (up to 3"; per second). -- Moveable saw blade traverses from 0.59" thru 13.38" -- 50 HP Saw arbor motor; -- 3 HP Feed motor with feed speeds from 15 to 130 FPM -- (2) 1/2 HP Lift motors for pressure rolls and saw arborOptional Equipment when ordered with the machine: -- TRS-FT AUTOMATIC INFEED CONVEYOR SYSTEM, with Movable Fence with Digital Display and Shifting Laser Light for Rip Width Setting: .. -- Hydraulic Quick Lock Spindle Assembly. The hydraulic locking spindle assembly is designed to provide for quick changeover between various ripping requirements. Simply turn the locking knob to pressurize the arbor and lock the blades in position. Turn it in the opposite direction to unlock the blades. The sawblades are mounted to solid steel blade collars: ... -- Additional Quick Set Mechanically-Locked Saw Collars for fast, accurate, sure holding of saw blades in any stationary position ... -- 60 HP Saw Arbor Motor: -- Additional 30 MW Laser Unit with Bracket & Wiring: ... -- Pneumatic Pressure to Hold Down Feed Rollers (In lieu of spring pressure). Provides better control of the product being fed. Each pressure roll is controlled by an individual pressure regulator: .. -- Short stock feeding device for 14"; blades (see specifications for cutting capacity information): -- Feed Chain with (69) Easily Replaceable Bolt in Cast Iron Pads. Allows for changing chain pads as they wear or get cut into rather than replacing the complete chain assembly. NOTE: Specially ground down to 0.06"; square tip for optimum hold with virtually no marking: ... -- Feed Chain with (69) Easily Replaceable Urethane Non-Marking Strip Inserts. Urethane is vulcanized to metal backing bars and bolted in place: ... -- 12" Dia. carbide tipped ripsaw blades, cuts up to 3" material: ... -- 14" Dia. carbide tipped ripsaw blades, cut's up to 4" material: ...NOTE: Foot Pedal seen in the photo is only used with a powered Infeed Table and is designed to release boards from the Feed Table.

CAM-WOOD XL300/5116 DIP CHAIN GANG RIPSAW12" Width cap.; 5-5/8"; max. cutting depth; 14"; min. stock length; Designed to meet the exacting standards required for high quality production line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances, and feature the newest designs for operator safety and volume productionSpecifications: -- Accepts saw blades from 12"; to 16"; diameter. -- Arbor is 70mm dia. with (2) keyways -- Saw arbor is powered by a 60 HP motor driving the spindle at 3,200 RPM; Soft start starters and low voltage controls are standard equipment. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 8 to 80 FPM; feed chain is 12"; wide -- Table is 28"; wide x 67"; and 12"; between the column and the 1st saw blade. -- (2) Integrated 6"; dia. dust extraction connections.Complete With: -- (1) 70 mm ID saw sleeve with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0,25 mm (see drawing after the "literature link). -- Two (2) rows of anti-kickback fingers mounted on the top and one (1) row from the bottom (total 3 rows) provides maximum safety protection. Equipped with: -- Precision fence ensures absolute accuracy between blade & fence, equipped with measuring ruler gauge. -- Power raise and lower to the arbor. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frame for durability usage. -- Variable feed speeds enables the machine to meet different work requirements. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain longevity smoothness -- Automatic chain lubrication device equipped with an alarm that sends signals upon a lack of lubrication oil. Features: -- Precision built saw head ensures accuracy for straight line rip saw operations. -- Four (4) bearing spindle ensures rigidity & long life. -- Saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue; spindle is heat treated, precision ground and balanced to provide the utmost in precision cutting performance -- Four (4) pressure rollers & two (2) hold-down plates for precise cutting of large and small workpieces. -- Ten (10) groove pulley and V-Belt arrangement ensures maximum motor output, excellent HP delivery to the saw spindle, and guarantees proper power transmission for heavy-duty multiple rip cutting. -- Adjustable guide rollers make cutting straight for slight radials material; they also secure glue joint at short pieces or long stacks.Options when ordered with machine: -- Additional saw sleeves (sleeve only), each, $315 -- Additional saw with spacer set consisting of: -- (2) 50 mm -- (3) 25 mm -- (4) 10 MM, -- (18) 1 MM -- (10) 0.5 MM -- (8) 0.25 MM -- Add per Sleeve with Spacer Set, $685 -- Laser Light with Mounting Bracket, each $980 -- Power raise & lower of the hold-down system when ordered with th

CAM-WOOD TRS-3200 SLAT RIPPER - (1) Horizontal Bottom Saw or Moulder Spindle Bottom;The machine can rip extremely narrow parts. Ideal for shutters, louver slats, yardsticks, etc.Features & Equipped with: -- Designed to meet the exacting standards required for high-quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- All of these features combine to show what true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy and is equipped with measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy-duty industrial TEFC motor ensures full-depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allow the machine to meet the cutting requirements of different materials. -- Saw head built to precise tolerances assures accuracy for all straight-line ripping operations and provides stellar cut quality. -- Top & bottom powered pneumatically tensioned feed rolls for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat-treated, precision ground, and balanced providing precise cutting performance.Specifications: -- 12"; Max. Cutting Width. -- 4-3/4"; Max. Cutting Depth. -- 10"; Min. Workpiece Length. -- 10"; to 16"; Dia. Sawblade Size. -- 4,000 RPM Spindle Speed. -- 12"; Spindle Length -- 70 mm Arbor Diameter (with 2-keyways). -- 30 HP Rip Saw Motor -- 3 HP Feed Motor. -- 12 to 60 FPM Feed Speed (Variable). -- 1 HP Feed Roll Elevating Motor. -- 1/2 HP Saw Arbor Elevating Motor.Footprint: 81" long x 40" wide x 60" high.

CAM-WOOD TRS-405-SS Short Stock Rip Saw ...with the following specifications and features:Specifications: -- Max cutting width: 12.6"; -- Min length part: 3.15"; -- Short stock ratio of thickness to length: 2:5 -- Distance from center of chain to throat, 30"; -- Saw arbor powered by 50 HP Std. - 30 HP, 60 HP and 75 HP optional -- Spindle speed, 3,200 RPM -- Sawblade diameter to thickness: 10"; dia = 2"; thick, 12"; dia = 3"; thick, 14"; dia = 4"; thick, 16"; dia = 5"; thick -- Sleeve diameter (sawblade bore), 70 mm -- Sawblade keyway, 2 each 20 mm wide -- Spacer size, 70 mm ID x 95 mm OD -- 2 HP feed motor, 3 HP optional -- Variable feed speeds from 20 to 80 FPM -- Head elevation powered by ¼ HP motor -- With (2) 6"; dia. dust outlets -- NET weight, 5,500 Lbs. Features and Benefits: -- Exclusive feed track - Design for short stock feed – see literature! -- Exclusive length capacity on a standard Gang Ripsaw, as short as 3";! -- Turn waste blocks into useable parts -- Pressure rolls supported from both sides hold stock securely for even, smooth ripping -- Pressure plate (hold-down shoe) supported from both sides; helps prevent split parts from damaging sawblades -- Power raise and lower for overhead pressure roll and hold-down assembly -- Variable feed speeds allow ripping a variety of material, hard or soft, thick or thin -- 2-Top and 1-bottom rows of kickback fingers plus side splitter guards provide operator safetyNOTE: ...Where have you seen a Gang Ripsaw capable of ripping as short as 3"!!! ...Also perfect for slats!

CAM-WOOD TRS-190-2VS 7.5"; x 6"; VERTICAL SPINDLE MOULDER FOR SMOOTH SLAT RIPPINGIncludes one setup including Splitter Set, Holddown Plate, Fence, Sawblades, and Spacers WORKING CAPACITY -- Working width: 3"; to 7-1/2"; -- Working height: 3/4"; to 6"; RIGHT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. LEFT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. SPINDLE COMPONENTS AND ASSEMBLY -- Precision spindles are manufactured from SCM-4 tool steel imported from MITSUBISHI Japan, heat treated to HR 46° (ROCKWELL C Scale) fitted with class 6 -- SKF-matched ball bearings then mated to precision machined spindle housings. -- The spindle body and bearing housing are burnished. -- Spindle hardness and accuracy, high precision SKF bearings, and precise spindle housing and bearing installation by SHEN KO provides a spindle assembly -- Capable of speeds to 9,000 RPM and will meet every user’s requirement. -- Spindles are powered by V-shaped belts (MITSUBISHI) without slippage. FEED SYSTEM -- Powered with a 5 HP motor -- Feed speed is infinitely variable by inverter drive from 20 to 120 FPM -- Infeed rolls consist of (3) top and (2) bottom-powered feed rolls. -- Outfeed with (1) set of top and bottom-powered feed rolls -- Pneumatic pressure to all (4) top feed rolls -- Top rolls with independent pressure adjustment -- All top and bottom feed are driven by a universal joint drive -- Feed rolls are 5-1/2"; diameter TABLE AND FENCE -- 4’ infeed table with (1) driven roller above the tablet -- Table is harden and chromed. -- Fence is harden PRESSURE ELEMENTS -- A pneumatic pressure plate assures stability during slicing -- Precision splitting wedge guide for saw kerf SETUP FEATURES -- Mechanical digital read-outs -- Mobile jog box for ease of setting up -- Central lubrication system for spindles -- Oil pump to remove the resin from table -- Each table has (2) holes for lubrication ELECTRICAL -- Operating voltage 230.460/575/600-volt, 60-cycle, 3-phase -- All “name brand"; electric components. -- Operating panel separate from motor control cabinet for ease of operation MISCELLANEOUS -- Machine cover/hood with a lamp for ease of set up -- Includes a toolbox and operator’s manual

CAM-WOOD TRS-340 M2 Gang Rip Saw With (2) Moveable Blades:Capacity: -- Depth of cut with 14"; dia. blades: 4"; at movable blades, 4.3"; at fixed blades -- Depth of cut with 12"; dia. blades: 2.95"; at movable blades, 3.34"; at fixed blades -- Depth of cut with short stock holddown and 14"; dia. blades: 3.14"; -- Depth of cut with short stock holddown and 12"; dia. blades: 2.36"; -- Max. rip width cap. 13.4"; -- Max material width, 25.6"; -- Min. rip length, 22"; -- Min rip length with short stock holddown, 15.8";Other Specifications: -- Max. sawblade dia., 14"; -- Min. sawblade dia., 12"; -- Sawblade bore, 90 mm (3.54";) -- Saw arbor dia., 70 mm (2.75";) -- Arbor motor, 50 HP -- Arbor speed, 3,800 RPM with 50 or 60 HP motors -- Feed speed from 20 to 135 FPM -- Feed motor by 3 HP VFD -- Overhead pressure roll raise & lower motor, 1/2 HP -- Dust collection; (2) 8"; diameter -- Overall dims., 62"; wide x 88"; long x 72"; high x 5,000 Lbs Features: -- Machine combines edging, selective, and gang rip functions -- Control Panel can be located for easy access -- Edges of random width boards can be trimmed in a single pass -- The positions of the movable saw blades are accurately controlled from the control panel for fast and convenient sets. -- Saw blade movement is driven through precision ball screws along a linear slideway for accurate, effortless traverse -- Exclusive laser projection system ensures accuracy -- Digital display for saw blade traverse; readouts in inch and metric displays are switchable -- Pressure rolls are supported on both sides and hold stock firmly and evenly -- Overhead pressure roll mechanism includes powered raise and lower -- Variable feed speed permits effortless ripping of a variety of stock; hard or soft, thick, or thin -- Double top and single bottom anti-kickback fingers, plus a side guard, provide excellent safety for the operator. -- Stepping motors drive precision ball screws for fast and accurate width settings. -- Same as above. f equipped with optional shifting fence and includes a digital display to accurately indicate fence travel -- Suspension of pressure plate from two sides helps prevent split or broken parts from damaging the saw arbor or saw blades -- Saw blade's movements are concentric for perfect rip accuracy and parallelism of ripped boards. Comes standard with: -- (3) 15 Mw Laser -- (2) Fixed saw seats -- (3) 12" Carbide Tipped SawbladesOptional: --TRS-FTAO-3: Automated In-Feed Table, 3 Meter Powered Conveyor System with Movable Fence, Shifting Laser Lights for 2-Moveable Blades for Rip Width Settings, and Digital Display, -- TRS-FTMU-3: 3 Meter Powered In-feed Table, Manual,

CAM-WOOD TRS-350X Heavy-Duty Dip Chain Gang Ripsaw75 HP! ... plenty of power for those with a lot of ripping work!Specifications: -- Maximum cutting width, 13-3/4"; -- Maximum depth of cut, 5-1/4"; -- Distance from column to first blade, 15"; -- Minimum working length, 25"; -- Maximum blade diameter, 16"; -- Minimum blade diameter, 10"; -- Sawblade bore, 2.756"; -- Saw arbor diameter, 2.165"; -- Saw arbor speed, 3,000 RPM -- Saw arbor motor, 75 HPFeatures: -- Variable feed speeds, 25 to 100 FPM -- Feed motor, 2 HP -- Roller holddown elevation motor, 1/2 HP -- Table working area 72"; x 31";Shipping dimensions, 84"; x 71"; x 68"; x 6,000 Lbs

TRS-350-3MX Multiple Blade RIPSAW w/OPTIMIZING and (3) SHIFTING BLADES &#9679 WITH 13-3/4" OF USEABLE ARBOR SPACE!Specifications: -- Moveable sawblades when using the Optimization program.1-1/2"; minimum distance between movable sawblades -- Sawblade configuration with (3) movable saws and (1) fixed sawblade -- Sawblades are optional -- Infeed & outfeed roller tables are optional -- With 50 HP saw arbor drive motor and 3 HP feed motor -- Pressure rollers elevation motor: 1/2HP -- (3) 1 HP servo motors for shifting sawblades -- Fence adjustment is manual. -- (3) 0.13 HP servo motors for shifting Laser Lights -- With UL electric components. -- 10 to 130 FPM variable feed speed -- 13-3/4"; Max. distance between the fixed saw and the last movable saw -- 26-1/2"; Max. material feeding width -- 27"; Min. cutting length -- (2) 6"; Dust hoods -- Cutting depths: 10" blade, 1.65"; thick; 12"; blade, 2.65"; thick; 14", 3.66"; thick; 16" blade, 4.64"; thick -- Sawblade size vs. RPM. (Make Blade size clear when order) -- Spindle speed @: 3,800 RPM (10" & 12" sawblade) / 3,000 RPM (14" & 16" sawblade)Computerized Rip Optimizing Program, Included: -- The operator only sets a line for total width, then the computer performs optimized ripping according to sizes set on the job sheet and the priority mode set from these options: -- 1. Priority according to the widest -- 2. Priority according to the same size -- 3. Fixed-width ripping -- 4. Yield priority -- 5. Value priorityOPTIONAL "TRS-350M3-INCOV" 3500 mm AUTOMATIC INFEED CONVEYOR SYSTEM WITH SCANNER AND OPTIMIZING SYSTEM, add ...$192,000 -- Automated infeed system controlled by electrical clutch connected with the Ripsaw's feed chain -- 13' Max. infeed length with (16) width detectors (scans every 8") -- Special pressure roller set, motion with liner rail and air cylinder -- Width scanning by sensors, with optimizing program for auto calculating -- Moving fence by servo motor, according to the wood width

TRS-460M4 Multiple Blade Rip Saw w/Optimizing, (4) SHIFTING BLADES &#9679 WITH 18" OF USEABLE ARBOR SPACE!Specifications: -- Moveable sawblades when using the Optimization program.1-1/2"; minimum distance between movable saw blades -- Sawblade configuration with (4) movable saws and (1) fixed sawblade -- Sawblades are optional -- Infeed & outfeed roller tables are optional -- With 50 HP saw arbor drive motor and 3 HP feed motor -- Pressure rollers elevation motor: 1/2 HP -- (4) 1 HP servo motors for shifting sawblades -- Fence adjustment is manual. -- (4) 0.13 HP servo motors for shifting Laser Lights -- With (5) Laser Lights -- UL electrical components. -- 10 to 130 FPM variable feed speed -- 18"; Max. distance between fixed saw and the last (outside) movable saw -- 31"; Max. material feeding width -- 27"; Min. cutting length -- (2) 6"; Dust hoods -- Cutting depths: 10" blade, 1.65"; thick ; 12"; blade, 2.65"; thick; 14", 3.66"; thick; 16" blade, 4.64"; thick -- Sawblade size vs. RPM. Make Blade size clear when order) -- Spindle speed @: 3,800 RPM (10" & 12"sawblade) / 3,000 RPM (14" & 16"sawblade)Computerized Rip Optimizing Program, Included: -- The operator only sets a line for total width, then the computer performs optimized ripping according to sizes set on the job sheet and the priority mode set from these options: -- 1. Priority according to the widest -- 2. Priority according to the same size -- 3. Fixed-width ripping -- 4. Yield priority -- 5. Value priorityOPTIONAL MODEL TRS-460M4-INCOV 3500mm AUTOMATIC INFEED CONVEYOR SYSTEM WITH SCANNER AND OPTIMIZING SYSTEM, add $198,000 -- Automated infeed system, speed rate controlled by electrical clutch connected with the Ripsaw's feed chain -- 13' max. infeed length with (16) width detectors (scans every 8") -- Special pressure roller set, motion with liner rail and air cylinder -- Width scanning by sensors, with optimizing program for auto calculating -- Moving fence by servo motor, according to the wood width

CAM-WOOD MODEL TRS-3000TB.12" SLAT RIPPER - (1) top & (1) bottom rip spindle.CAM-WOOD MODEL TRS-2050TB.8" SLAT RIPPER - (1) top & (1) bottom rip spindle - DEDUCT $8,000FEATURES: -- The machine can plane or shape the wood at two surfaces then rip it. Ideal for shutters, louver slats, yard stick blanks, etc.. -- Special profile hold down & groove table for slat ripping, optional -- Designed to meet the exacting standards required for high quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances, and feature the newest designs for operator safety and volume production. -- All of these features combine to show what a true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy between cutterheads & fence and is equipped with measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy duty industrial TEFC motor ensures full depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allows the machine to meet the cutting requirements of different materials. -- Saw heads built to precise tolerances assures accuracy for all ripping and profiling operations provide a stellar quality of cut. -- Top & bottom powered pneumatically tensioned pressure rollers for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance.SPECIFICATIONS: -- 12"; Max. Cutting Width (TRS2050 WITH 8" MAX. WIDTH) -- 4-3/4"; Max. Cutting Depth -- Min. Cutting Depth Limited by Thin Material Breakup -- 10"; Min. Workpiece Length -- 14"; Dia. Max. Sawblade Size on Top Spindle -- 10" to 16"; Dia. Sawblade Size on Bottom Spindle (TRS2050 WITH 16" DIAMETER) -- 4,000 RPM Top & Bottom Spindle Speed -- 12"; Spindle Length (TRS2050 WITH 8" SPINDLE LENGTH) -- 40mm Arbor Diameters with 2-Keyways (TRS 2050TB WITH 70MM ARBORS) -- 15 HP Top Rip Saw Motor (TRS 2050 WITH 10 HP MOTOR) -- 30 HP Bottom Rip Saw Motor -- (6) Upper and (2) lower Feed Rolls -- 12 to 60 FPM Feeding Speed (Variable) -- 1 HP Feed Roll & Top Head Elevating Motor -- 1/2 HP Lower Saw Arbor Elevating Motor -- 7-1/2 HP Feed Motor (TRS2050 WITH 3 HP MOTOR) -- Dimensions (L x W x H) 96" x 64" x 55"

CAM-WOOD MODEL TRS-1200TB SLAT RIPPER - (1) Top & (1) Bottom Rip Spindle.The machine can plane or shape the wood on two surfaces and then rip it. Ideal for shutters, louver slats, yardstick blanks, etc.Features: -- Special profile hold down & groove table for slat ripping, optional -- Designed to meet the exacting standards required for high-quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- All of these features combine to show what a true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy between cutterheads & fence and is equipped with a measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy-duty industrial TEFC motor ensures full-depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allow the machine to meet the cutting requirements of different materials. -- Saw head built to precise tolerances assures accuracy for all straight-line ripping operations and provides a stellar quality of cut. -- Top & bottom powered pneumatically tensioned feed rolls for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat treated, precision ground, and balanced providing precise cutting performance.SPECIFICATIONS: -- 8"; Max. Cutting Width -- 5"; Max. Cutting Depth -- 10"; Min. Workpiece Length -- 4"; to 6"; Dia. Top Spindle Sawblade Size -- 8"; to 12"; Dia. Bottom Spindle Sawblade Size -- 6,000 RPM Top & Bottom Moulder Spindle Speed -- 8"; Spindle Length -- 40 mm Rip Saw Arbor Diameter (with key) -- 10 HP Top Rip Saw Motor -- 15 HP Bottom Rip Saw Motor -- 12 to 60 FPM Feeding Speed (Variable) -- 1/2 HP Feed Roll & Top Head Elevating Motor -- 1/2 HP Rip Saw Arbor Elevating Motor -- 3 HP Feed Motor

CAM-WOOD - XL 300, ...Dip Chain Gang Rip Saw: Short Stock version12" Width cap.; 3/8" min. to 3-3/4"; max. cutting depth; 7" min. stock length.Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0.25 mm (see drawing after the "literature link); with 12"; usable cutting width. -- Accepts saw blades from 10"; - 12"; dia.; arbor is powered by a 40 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 - 100 FPM; feed chain is 12"; wide. -- Table: 28"; Wide x 67"; with 12"; between the column and the 1st saw blade. - Integrated 6"; dia. dust extraction connection.General Description: -- Designed for high-quality Production Line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence; equipped with: Measuring ruler gauge. -- Triple anti-kickback fingers mounted at the infeed side provide max. safety protection; (2) rows from the top and (1) row from the bottom. -- Heavy-Duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision-built saw head ensures accuracy for straight-line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- Power raise & lower to the arbor. -- (4) Pressure rollers & (2) holddown plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for max. motor power output and guarantees Heavy-Duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radial rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or longer length boards.

Cam-Wood TRS-MR-1300 X 75mm Roll Feed Gang Rip SawSpecifications -- Working thickness: 10 - 100mm • -- Working width: 530 - 1300 mm • -- Working thickness : 10 – 75 mm / 100 mm • -- Saw Blade 14", • Washer Diameter 110mm • -- Minimum length of work piece when feeding consecutively: 600mm • -- Number of spindle : 1 • Equipped with & Features -- Up & down motor : 1 HP x 1 • -- Feed speed : 6 - 15 M/ min. • -- Feed motor: 7.5 HP x 1 with Inverter • -- Multiple rip saw spindle motor:150 HP / 200 HP • -- Spindle diameter : 80 mm with two key-ways 10 mm5 mm • -- Spindle R.P.M.: 4,000 R.P.M. • -- Movable 1300 mm Saw Shaft Support for easy saw blade replacement.

Cam-Wood TRS-MR-1300 X 100mm Roll Feed Gang Rip SawSpecifications -- Working thickness: 10 - 100mm • -- Working width: 530 - 1300 mm • -- Working thickness : 10 – 75 mm / 100 mm • -- Saw Blade 14", • Washer Diameter 110mm • -- Minimum length of work piece when feeding consecutively: 600mm • -- Number of spindle : 1 • Equipped with & Features -- Up & down motor : 1 HP x 1 • -- Feed speed : 6 - 15 M/ min. • -- Feed motor: 7.5 HP x 1 with Inverter • -- Multiple rip saw spindle motor:150 HP / 200 HP • -- Spindle diameter : 80 mm with two key-ways 10 mm5 mm • -- Spindle R.P.M.: 4,000 R.P.M. • -- Movable 1300 mm Saw Shaft Support for easy saw blade replacement.

CANTEK TA-14 Tilting Arbor Table Saw. -- Heavy-duty cast iron table precision ground for accuracy. -- Rugged machine frame construction provides maximum stability and reduced vibration. -- 14" Blade capacity. and 0° - 45° tilting arbor. -- 7.5 HP Motor with double V-belt drive. -- Rip fence for a 50" max. cut with a precision Rip fence. -- 48" x 38" Cast iron table. -- Blade guard, miter gauge, push button controls. -- Parts list & operation manual.

CANTEK 1214 TABLE SAWHeavy-duty cast iron table precision ground for accuracy. -- Rugged machine frame construction provides maximum stability and reduced vibration. -- 14" Blade capacity. and 0° - 45° tilting arbor. -- 10 HP Motor with double V-belt drive. -- Rip fence for a 50" max. cut with a precision Rip fence. -- 48" x 38" Cast iron table. -- Blade guard, miter gauge, push button controls. -- Parts list & operation manual.
