QUCK R-RCGS-2-17 Top & Bottom Glue SpreaderQUICK 17" wide Top and Bottom Glue Spreader with 0.04" - 1.75" thickness capacity.Features: -- (2) Grooved SBR Rubber (60 Durometer) covered 8" glue rollers, (2) 5.8" chrome covered doctor rolls. -- Converts quickly to Top only glue application when needed. -- Comes standard with a fixed 64 FPM feed rate (Optional 40-118 FPM Variable Speed Drive). -- Durable chain drive gives years of trouble-free operation. -- Simple-to-access hand wheels allow the operator to make quick adjustments when panel thicknesses change.Complete with: -- Roll guard hoods -- Emergency stop bars at front and back of machine for Operator Safety. -- Stainless Steel drip pan catches clean-up water.

QUICK CRFR-12 Panel and Door ClampThe QUICK Clamp Rack’s moderate cost, ultra high-quality clamps, super-strong frame and efficient use of floor space makes it the ideal gluing station for the small to mid-sized cabinet shop, furniture manufacturer or millwork producer.Includes: -- 12' width capacity, 6-row (3 rows on each side) Clamp Rack with (24) heavy-duty, zinc-plated, hand-tightened clamps. -- Clamps are 40" opening (32" opening is available), with 3.5" high x 4.75" wide jaws, with 1° inward draft.Standard Features: -- Standard features include a super heavy-duty frame with 4" x 4" structural tubing cross beams, 4" x 6" structural tubing legs, and 4" x 4" structural tubing feet. -- Two-position feet can be configured for one-sided or two-sided Rack operation. -- All tubing ends are angled and/or closed for maximum strength and proper aesthetics. -- High-quality urethane finish. -- Clamps are exceptionally heavy-duty, with full box frame construction, and feature quick-release rear jaws and long, smooth handles for maximum ease of use.

QUICK CRFT-08 Clamp Rack The QUICK Clamp Rack’s moderate cost, ultra high-quality clamps, super-strong frame and efficient use of floor space makes it the ideal gluing station for the small to mid-sized cabinet shop, furniture manufacturer or millwork producer.Includes: -- 8' width capacity, 6-row (3 rows on each side) Clamp Rack with (16) heavy-duty, zinc-plated, hand-tightened clamps. Clamps are 40" opening (32" opening is available), with 3.5" high x 4.75" wide jaws, with 1° inward draft.Standard Features: -- Standard features include super heavy-duty frame with 4" x 4" structural tubing cross beams, 4" x 6" structural tubing legs, and 4" x 4" structural tubing feet. -- Two-position feet can be configured for one-sided or two-sided Rack operation. -- All tubing ends are angled and/or closed for maximum strength and proper aesthetics. -- High-quality urethane finish. -- Clamps are exceptionally heavy-duty, with full box frame construction, and feature quick-release rear jaws and long, smooth handles for maximum ease-of-use.

1' x 10' pressing capacity via (10) 1' x 1' platens. Pod Press produces 78,000 lbs. total platen force (7,800 lbs. per platen) at 120 PSI supply air pressure; suitable for lighter-duty (high-pressure laminates to composite substrates) and heavier-duty (wood veneering) applications. 40" fixed daylight; vertical structural frame members and hinged containment fences arrangement for end-loading and side loading the press. -- Horizontally-adjustable vertical containment fences keep laminated material from sliding while under pressure. (10) 10"" maximum diameter air pods with 5" stroke; each air pod with separate hand-operated air valve; each air pod / platen activates individually. Main air valve controls all "activated" air pods at once; various pods are controlled together, or each pod can be controlled separately. -- NOTE: Special Press configuration for use in stile and rail entry and passage door operations.

QUICK '6-SECTION HEAVY DUTY-P CLAMP CARRIER (Pneumatic). -- Overall Data: Heavy Duty 16.5' wide (16.5' maximum stock length capacity), 6-section Thick Stock Pneumatic Clamp Carrier with (72) 3.5" high, 40" opening clamps; (12) clamps per section. -- Includes: Pneumatic Clamp Tightener, Pneumatic Panel Flattener, Electric Motor Drive with Automatic Rotation Cycle. -- Major Parts & Components list as follows:Qty Part# Description Each Total (1) A-CCFP-16.5-06 CC Frame Pneumatic, 16.5' wide, 6 Sect. $9,900.00 $9,900.00(72) B-CLMP-3.5-40 Clamp, 3.5" high jaw, 40" opening 82.00 5,904.00(1) C-PCT1-16.5-06 Pneumatic Clamp Tightener, 16.5' wide, for 6-sect. CC 4,450.00 4,450.00(1) D-PPF1-16.5 Pneumatic Panel Flattener, 16.5' wide 2,200.00 2,200.00 (1) E-EMDR-06-16.5 Electric Motor Drive for 6 Sect. CC, 16.5' wide, #135 2,450.00 2,450.00 TOTAL ..................................................................................................................................... $ 24,904.00.OPTIONAL(24) B-CLMP-3.5-40 Clamp, 3.5" high jaw, 40" opening 82.00 $1,968.00 -- Note: Lead time is about (8 - 10) weeks.

Quick Hydraulic Clamp Carrier with 20-sections and 12-1/2' width capacity.This special "thick stock" frame accepts (12) Heavy Duty zinc plated clamps per section. Includes: -- 240 clamps with 36" openings and 6" high x 4-3/4" wide jaws with 1° inward draft. -- Integral hydraulic overhead panel flattener. -- (2) Hydraulic clamp tightener with adjustable torque limiter. -- (2) Pneumatic panel flattener -- Single button automatic electric motor rotation cycle with indexing. -- Heavy Duty frame with 3" diameter shafts and 6" I-beam legs. -- Includes foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating and tool box with spare parts & tools.Note: Could be order with single tightener and panel flattener

QUICK 20-Section Heavy Duty Pneumatic Clamp Carrier with 10-1/2' width capacity -- With (8) Standard zinc plated clamps per section (160 clamps total), 38" opening on clamps.Standard Features include: -- Clamps jaws are 3-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- Panel Flattener with easy to use controls. -- Pneumatic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. -- Electric Motor Rotation 2 HP; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time!Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools.NOTE: A 20-Section Clamp typically produces 500 panels per shift.OAL Dimensions are 163" W x 182" D x 125" H

QUICK 20-Section Pneumatic Clamp Carrier with 10-1/2' width capacity -- With (8) Standard zinc plated clamps per section (160 clamps total), 38" opening on clamps. Standard Features include: -- Clamps jaws are 2-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- Panel Flattener with easy to use controls. -- Pneumatic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. -- Electric Motor Rotation; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time!Complete with: Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools.NOTE: A 20-Section Clamp typically produces 500 panels per shift.

²QUICK 14-Section Pneumatic Clamp Carrier with 10-1/2' width capacity With (8) Standard zinc plated clamps per section (112) clamps total), 38" opening on clamps Standard Features include: -- Clamps jaws are 2-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- Panel Flattener with easy-to-use controls. -- Pneumatic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; a two-handed, trigger-activated tightener is more confidence-inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate the need for manual adjustment of rear clamp jaws. -- Electric Motor Rotation; push button, automatic cycle with indexing. -- Automatic Rotation Cycle includes the entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time! Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high-quality urethane finish coating, and toolbox with spare parts & tools. -- A 14-Section Clamp will produce approx. 300 panels

QUICK 6-SECTION, 12-1/2' Wide Pneumatic "Standard" Clamp Carrier: 6-Section Clamp, typically produces (144) high-quality edge glued panels per day (3 panels per section x 6 sections x 8 hours). Equipped with: -- (6) Sections with (9) clamps per section and 12-1/2' width capacity. -- (54) Clamps with 38" opening and 2-1/2" high x 4-3/4" wide jaws with 1° inward draft. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. -- Rocker Plates are available as optional equipment for face gluing. Features: -- Semi-automatic electric motor drive. -- Pneumatic Panel Flattener for 10-1/2' wide Carrier with easy-to-use controls. -- Pneumatic Clamp Tightener with a 3,000 RPM air wrench is (5 -10) times faster than competitive tighteners; the 2-handed, trigger-activated tightener is more confidence-inspiring than the older, ergonomically awkward "swing-style" clamp tighteners. -- Fast tightening and full-length clamp screws eliminate the need for manual adjustment of rear clamp jaws. Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, and automatic air line oiler; -- High-quality Urethane finish coating, and tool box with spare parts & tools.Floor space requirement: 195"W X 125" H X 127"D

QUICK 6-SECTION, 10'-1/2' Wide Pneumatic "Standard" Clamp Carrier: 6-Section Clamp typically produces (48) high quality edge glued panels per day (3 panels per section x 6 sections x 8 hours). Equipped with: -- (6) Sections with (8) clamps per section and 10-1/2' width capacity. -- (48) Clamps with 50" opening and 2-1/2" high x 4-3/4" wide jaws with 1° inward draft. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. Features: -- Electric motor drive. -- Pneumatic Panel Flattener for 10-1/2' wide Carrier with easy to use controls. -- Pneumatic Clamp Tightener with 3,000 RPM air wrench is (5 -10) times faster than competitive tighteners; 2-handed, trigger activated tightener is more confidence inspiring than the older, ergonomically awkward "swing-style" clamp tighteners. -- Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality Urethane finish coating, and tool box with spare parts & tools. --

Quick Heavy Duty Pneumatic Clamp Carrier with 20-sections and 12-1/2' width capacity. -- (8) Heavy Duty zinc plated clamps per section for 10 section, clamp opening 44" -- (10) Heavy Duty zinc plated clamps per section for 10 section, clamp opening 44" -- Includes 180 clamps with 44" openings and 3.5" high x 4-3/4" wide jaws with 1° inward draft. -- Pneumatic overhead panel flattener along with tightener -- Pneumatic panel flattener for second operator -- Semi-Automatic Pneumatic clamp tightener . -- Semi-Automatic panel tightener for second operator -- Single button automatic electric motor rotation cycle with indexing. -- Heavy Duty frame with 3" diameter shafts and 6" I-beam legs. -- Includes foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating and tool box with spare parts & tools.

QUICK 14-Section Heavy Duty Hydraulic Clamp Carrier with 20-1/2' width capacity With (16) Standard zinc plated clamps per section (224) clamps total), 38" opening on clamps Standard Features include: -- Clamps jaws are 3-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- Pneumatic Panel Flattener with easy to use controls. -- Pneumatic panel flattener for second operator -- Hydraulic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. -- Hydraulic clamp tightener for second operator -- Electric Motor Rotation; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time! Complete with:Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools. 14-Section Clamp will produce 300 panels

Quick Heavy Duty 14-Section Hydraulic Clamp Carrier, 16-1/2' Wide -- 14-Section Clamp Carrier 16-1/2' width cap.. -- (12) Heavy Duty zinc plated clamps per section for (168) total clamps. -- 38" opening on clamps; jaw sizes on clamps are 3-1/2" high x 4-3/4" wide with 1° inward draft. Equipped with: -- Dual Overhead Pneumatic Panel Flatteners for (2) operators -- Dual Hydraulic Clamp Tighteners for (2) operators -- Automatic Electric Motor Rotation with Indexing. -- Standard features include: Foot levelers, coiled air lines where used and flexible conduit for wires.

²QUICK 14-Section Pneumatic Clamp Carrier with 12-1/2' width capacity With (8) Standard zinc plated clamps per section (112) clamps total), 38" opening on clamps Standard Features include: Clamps jaws are 3-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment Panel Flattener with easy to use controls.Pneumatic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. Electric Motor Rotation; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time! Complete with:Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools. 14-Section Clamp will produce 300 panels

QUICK 40-Section Heavy Duty Clamp Carrier 12.5' with Auto Clamp Loosener -- With (9) Standard zinc plated clamps per section (320 clamps total), 32" opening on clamps.Standard Features include: -- Clamps jaws are 3-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- (2) Hydraulic Semi Automatic Clamp Tightener/Panel Flattener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; two-handed, trigger activated tightener is more confidence inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. -- Hydraulic Upper Auto Clamp loosener for 12.5' wide -- Electric Motor Rotation; push button, automatic cycle with indexing. Automatic Rotation Cycle includes entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time!Complete with: -- Conveyorized glue spreader 20" wide with 10' infeed and 13' outfeed -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools.

Quick Pneumatic Clamp Carrier with 20-sections and 12-1/2' width capacity. -- (8) Heavy Duty zinc plated clamps per section with 52" opening. -- Includes 160 clamps with 52" openings and 3.5" high x 4-3/4" wide jaws with 1° inward draft. -- Pneumatic overhead panel flattener riding along with tightener -- Semi-Automatic Pneumatic clamp tightener . -- Single button automatic electric motor rotation cycle with indexing. -- Heavy Duty frame with 3" diameter shafts and 6" I-beam legs. -- Includes foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating and tool box with spare parts & tools.

QUICK 14-Section Pneumatic Clamp Carrier with 8-1/2' width capacity With (6) Standard zinc plated clamps per section (84 clamps total), 32" opening on clamps Standard Features include: -- Clamps jaws are 2-1/2" high x 4-3/4" wide with 1° inward draft to keep stock securely held down. Clamps use 3/4" dia. full-length screws; corrosion resistant, zinc plated, full box frame. For face gluing, Rocking Plates available as optional equipment -- Panel Flattener with easy-to-use controls. -- Pneumatic Clamp Tightener; 3,000 RPM air wrench is 5 to 10 times faster than competitive tighteners; a two-handed, trigger-activated tightener is more confidence-inspiring than the old ergonomically awkward "swing-style" clamp tighteners. Fast tightening and full-length clamp screws eliminate need for manual adjustment of rear clamp jaws. -- Electric Motor Rotation; push button, automatic cycle with indexing. The automatic Rotation Cycle includes the entire sequence; reverse rotation, front-rest out, forward rotation, front-rest in, and lay clamps on front rest. Perfectly! Every time!Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high-quality urethane finish coating, and toolbox with spare parts & tools. -- 14-Section Clamp will produce 300 panels per shift; 20-Section machine, 500 panels per shift.

QUICK 6-SECTION Clamp Carrier; (6) Sections, (6) clamps per section, and 8-1/2' width capacity. -- (36) Clamps total with 50" opening and 2-1/2" high x 4-3/4" wide jaws with 1° inward draft. -- 8 1/2 feet wide with easy to use controls.Equipped with: -- Pneumatic Clamp Tightener; 3,000 RPM air wrench is (5 -10) times faster than competitive tighteners; 2-handed, trigger activated tightener is more confidence inspiring than the older, ergonomically awkward "swing-style" clamp tighteners. -- Pneumatic Panel Flattener -- Electric motor drive for Carrier rotation.Complete with: -- Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler. -- Hhigh quality Urethane finish coating, and tool box with spare parts & tools. NOTE: -- 6-Section Clamp typically produces (144) high quality edge glued panels per day (3 panels per section x 6 sections x 8 hours). -- Clamp can be expanded to (14 or 20) sections at a later time. 14-Section Clamp will produce (300) panels per shift; 20-Section machine, (500) panels per shift.Floor space requirement: 134"w x 142"d x 143"h

QUICK 40-Section HEAVY DUTY HYDRAULIC CLAMP CAFRRIER with 8-1/2' Width cap. -- Clamp Carrier with: (6) Clamps per section, (240) total Heavy Duty zinc plated "Quick-Adj" fast adjusting clamps; 32" opening on clamps; jaw sizes of clamps are 3-1/2" high x 4-3/4" wide, with 1° inward draft. -- Equipped with: Integral pneumatic panel flattener and fully automatic hydraulic clamp tightener with adjustable torque limiter. -- Single-button automatic Heavy Duty electric motor rotation with cycle indexing. -- Automatic Carriage traverse is powered by a hydraulic motor coupled to a rack & pinion drive system, which provides smooth, accurate and very quiet operation. -- Automatic Carriage includes its own control panel for easy operator control at the Carriage; this is particularly helpful during "semi-automatic" operation. -- Operation: The machine automatically flattens panels, tightens clamps, rotates, and loosens clamps. After loading wood into a section of clamps, the operator presses the "Cycle Start" button. -- The hydraulic Automatic Carriage traverses from right-to-left, flattening panels and tightening clamps along the way. -- When the carriage reaches the end of its traverse, the machine performs an automatic rotation cycle, bringing the next section of clamps down to the operator's position. -- The carriage then traverses from left-to-right, loosening clamps on the way back to its starting point. -- Standard features: All structural & mechanical components are manufactured with very Heavy Duty materials, providing many years of reliable service. -- Heavy Duty frame with 3" dia. shafts and 6" I-beam legs. -- Supplied with: Foot levelers, coiled air lines, flexible conduit for electric wires, automatic air line oiler, high quality urethane finish coating, and tool box with spare parts & tools (QUICK Model "A-CCFH-08.5-40").
