BRANDT PROFILINE KDF 970 2C HD EDGEBANDER WITH PRE MILL & CORNER ROUNDINGSpecifications: -- Edgebanding thickness 0.4 - 20 mm (0.02" - 0.79"), Including 3 mm (0.12") PVC banding. -- Panel thickness 8 - 60 mm (0.31" - 2.38"), Min. panel width 65 mm (2.56"), Min. panel length 160 mm (6.30"). -- Variable feed speeds 36 - 65 FPM (11 - 20 MPM), Max. feed speed using corner rounding units or applying solid wood 52 FPM (16 MPM). -- Working height 900 mm (35.43").Equipped with: -- Pre-milling unit, with (2) 3 kW (4 HP) - 11,580 RPM Vertical milling/jointing heads with FS Whisper Heads, Electro-pneumatic jump control, Head counter-rotation, & SIKO digital units for vertical & horizontal adjustments. -- 32-1/2" Dia. Coil table. -- Motorized infeed fence. -- Extended magazine for strips & coiled material. -- Reinforced guillotine for coiled edgebanding material, 0.4 - 3.5 mm (0.2" - 0.14") Thickness & 8 - 55 mm (0.31" - 2.17") Height. -- "Quick-Melt" Hot melt glue unit, with Heat-up time: Approx. 12 min., Pre-melt hopper feed, Quick-change hopper & tank for color changes, Reversible glue applicator roller rotation, Retractable glue roller, Infrared heating unit positioned between glue roller & pressure section to improve edge quality, and Pneumatic positioning & Locking. -- Programmable pressure section, with (1) Large driven & (4) Small pneumatically-controlled idler rolls and SIKO Digital units for adjustments. "POWER CONTROL PC 20+" Control, with 600 MHz, 256 MB RAM, USB Port, 1 GB Flash card, Internal modem for remote diagnostic access link, & 12" TFT Flat screen monitor. -- Line control (no limit switches) for workstation functions. -- Heavy-duty feed chain, with 2.2 kW (3 HP) Motor, Rubber pads, & Automatic chain track lubrication. -- Motorized top pressure beam with 0.14 HP (0.10 kW) Motor. -- Outboard panel support, with Roller guide & 1,000 mm (39.37") Adjustment. -- Sound enclosure.Workstations: -- Front & rear end trim unit, with (2) 1 HP - 12,000 RPM High frequency motors, 0° - 15° Chamfer, & Programmable pneumatic control for straight or chamfer trimming. -- Top & bottom rough trim unit, with (1) 1.86 kW (2-1/2 HP) High frequency motor. -- Top & bottom fine trim unit, with (2) 0.55 kW (3/4 HP) - 11,300 RPM High frequency motors with Electronic brakes, Servo control bevel, 0° - 25° Tilt, Vertical & Horizontal tracing, Servo control (in/out), & DFC Radius cutters. -- Corner rounding unit, with (2) 0.35 kW (1/2 HP) - 10,940 RPM High frequency motors, & Automatic 2-position edge thickness. -- Quick-change top & bottom profile scraping unit for rigid PVC edges, with Digital quick-set system for 2 - 6 mm (0.08" to 0.24") Radius, Pneumatic indexing, Servo control (in/out), & Pneumatically-controlled blow-off nozzle. -- Top & bottom buffing unit, with (2) 0.3 HP - 2,800 RPM Motors and Vertical & Horizontal tilt.Full Servo Edgebander, with Pre-Mill, Corner Rounding, Pre-Melt, $5,000 Package of Almost New Diamond Pre-Mill Heads, New

BRANDT OPTIMAT KDN 650 C Edgebander, with Corner Rounding, Pre-Melt, & 8,654 Hrs. (As of 6/2/22) Specifications: -- Edgebanding thickness 0.4 - 8 mm (0.02" - 0.31"). -- Panel thickness 8 - 55 mm (0.31" - 2.17"), Min. panel width 65 mm (2.56"), Min. panel length 160 mm (6.30"). -- Feed speeds 11/14 FPM (36/46 FPM). -- Working height 950 mm (37.40").Equipped with: -- 32-1/2" Dia. Coil table. -- Automatic magazine. -- 3 mm (0.12") Guillotine. -- "Quick-Melt" Hot melt glue unit, with Heat-up time: Approx. 12 min., Pre-melt hopper feed, Quick-change hopper & tank for color changes, Reversible glue applicator roller rotation, & Retractable glue roller. -- Pressure section, with (1) Large driven & (3) Small pneumatically-controlled idler rolls. -- "POWER CONTROL PC 20+" Control, with 600 MHz, 256 MB RAM, USB Port, 1 GB Flash card, Internal modem for remote diagnostic access link, & 12" TFT Flat screen monitor. -- Line control (no limit switches) for workstation functions. -- Feed chain, with 2.2 kW (3 HP) Feed motor & Automatic chain track lubrication. -- Digital height indicator. -- Sound enclosure.Workstations: -- Front & rear end trimming unit, with (2) 0.35 kW (1/2 HP) - 12,000 RPM High frequency motors, 0° - 15° Chamfer, & Programmable pneumatic control for straight or chamfer trimming. -- Top & bottom flush trimming unit, with (2) 0.55 kW (3/4 HP) - 11,300 RPM High frequency motors, 0° - 25° Swivel, & Combination straight/radius cutters. -- Corner rounding unit, with (2) 0.35 kW (1/2 HP) - 10,940 RPM High frequency motors & 3 mm (0.12") Radius insert cutters. -- Top & Bottom Profile scraping unit, with Vertical & Horizontal tracing. -- Top & bottom buffing unit, with (2) 1/4 HP - 1,400 RPM Motors and Vertical & Horizontal tilt.

BRANDT AMBITION 1110 (KDN 110) EDGEBANDER: -- Specifications:0.4 - 3 mm (1/8") Edge thickness cap.; 8 - 40 mm (0.3" - 1.57") panel thickness; 60 mm (2.3") min. panel width; 140 mm (5-1/2") min. length.Equipped with: -- Infeed fence: Adjustable; manual with digital indicator. -- Gluing System: Hot-melt; quick heat-up time; easy maintenance. -- Edge Magazine: Automatic for strip & coil stock; 3 mm PVC guillotine. -- Side Pressure Section: (1) Driven plus (2) idle rollers w/digital readout setting.Workstations: -- End Trimming Unit: Double-motor end trim; (2) x 1/2 HP - 12,000 RPM motors; chamfers 0° - 15°. -- Multi-Trimming Unit: Top/Bottom for flush/bevel/radius trimming; (3) quick setting positions; motors: (2) 1/2 HP - 12,000 RPM; with insert knives. -- Buffing Unit: Top/Bottom; (2) 1/2 HP motors. -- Scrapping Unit: Top/Bottom Scrapping UnitControls:LCD Display: Approx. 2 x 6" with soft keys for fast navigation and operator comfort. Complete with: -- Feed Speed: Fixed; 8MPM (26 FPM); 3 HP feed drive. - Sound enclosure and Scraper collection box. -- Actual Model is BRANDT AMBITION 1110 (KDN 110).

BRANDT OPTIMAT KTD 820 Contour EdgebanderSpecifications: -- Designed for straight, curved (contour), or beveled edgebanding. -- Edgebanding thickness 0.4 - 3 mm (0.02"; - 0.12";). -- Coil cutoff 0.4 - 3 mm (0.02"; - 0.12";) (Max. edge height 45 mm/1.77";). -- Panel thickness 16 - 40 mm (0.63"; - 1.57";). -- Min. radius 25 mm (0.98";). -- Min. panel length 180 mm (7.09";), Min. panel width 100 mm (3.94";). -- Feed speeds 0.7 - 4.2 MPM (2.30 - 13.80 FPM).Equipped with: -- 33"; Dia. Vertical coil table. -- Small glue pot for quick heat-up. -- Magazine for coil or solid strips. -- Guillotine. -- Handheld gluing unit, with Tool balancer & Rotating jib with 8’ Travel. -- (2) 23-1/2"; x 27-1/2"; x 35 H Work tables. -- Large panels can be glued by guiding handheld gluing unit around panel mounted to vacuum suction table. -- Small panels can be glued by guiding panel along gluing unit mounted to table.

BRANDT AMBITION 1440 FC (KDF 440 C) EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) & 3,359 Hrs.Specifications: -- Edge & Workpiece Capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") Panel thickness, 160 mm (6.30") Min. panel length, 70 mm (2.76") Min. panel width.Equipped with: -- Adjustable Infeed Fence: Motorized adjustment with 0.049 kW (0.07 HP) Motor. -- Joint Trimming/Pre-Milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, Left-Hand & Right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting, 0.4 - 8 mm (0.016" - 0.31") Strip thickness, 3 mm (0.12") PVC Max. coil thickness. -- Hot Melt Glue Application Unit: 6 - 10 kg/Hr. (13 - 22 Lbs./Hr.) Melting capacity (Depending on glue type). -- Workpiece Preheating Unit -- Pressure Zone: (1) Driven & (2) Idle Rollers, Timed pneumatic pressure controlled, Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds: 8 - 14 MPM (27 - 45 FPM), 11 MPM (36 FPM) with Contour trimming. -- BRANDT "POWERTOUCH" Control: With 21" HD LCD Touchscreen monitor.Workstations: -- Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors, with 0° - 15° Automatic chamfer, Pneumatic adjustment & Activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt, with Horizontal & Vertical Tracing wheels, Brushless multi-axis servo motors for positioning of work-unit & horizontal copy wheels for quick changeover, with (3) Positioning options: Profile 1, Profile 2 & Flush trimming. -- Multi-Functional Trimming Unit: (2) 0.4 kW (1/2 HP) 12,000 RPM Motors for leading & trailing edges vertical corner rounding of panels, Either radius or chamfer cutters can be mounted, 3 mm (0.12") Max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"), Servo control positioning of vertical & horizontal copy wheels, PVC Scrape collection box, Pneumatic adjustment using "POWERTOUCH" control, Pneumatic disengagement. -- Top & Bottom Glue Scraping Unit: Flush on panel surface, with Floating insert knives. -- Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) 2,750 RPM Motors.Complete with: -- Motorized, programmable hold-down pressure beam with 0.12 kW (0.16 HP) Motor, 1.5 kW (2 HP) Feed motor, 32" Diameter Coil table, Padded sound enclosure.NOTE: CPU needs to be replaced.

BRANDT KDF 650 (1650 HIGHFLEX) EDGEBANDER (W/PRE-MILLING & CORNER ROUNDING), with 3,339 Hrs. (As of 10/31/23):Specifications: -- 0.4 - 12 mm (1/2") Edge cap., panel thickness 5/16" - 2-3/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. -- Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator. -- "PC-16" Program Control with: 21-1/2"; Display, signal infeed light to ensure proper spacing between panels.Equipped with: -- Pre-milling station for cleaning edges of the panel; "Quick change" glue tank for maintenance & glue color change. -- 32"; Dia. Coil table. -- Automatic magazine for strip & coil stock, 3 mm PVC guillotine, (1) drive plus (3) idle roll "pneumatically controlled" pressure sections with digital indicator for quick edge thickness changeover.Workstations: -- End trim (0.33 HP - 12,000 RPM motors), chamfers 0° - 15°; -- Top & bottom flush/bevel/radius trim, bevels 0° - 15° (0.5 HP - 12,000 RPM motors) with insert knives for 2 mm PVC radius. Vertical copy wheels are servo-controlled for quick changeover, programmable from the control panel. -- 2-Motor (4 corners) contour trim for profile corner rounding (two 0.5 HP - 12,000 RPM motors), with insert knives for 2 mm PVC radius. -- Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blow off nozzles; -- Top & bottom buffing (0.25 HP - 1,400 RPM motors). -- End trim, flush/bevel/radius trim & corner rounding stations have HF motors with electronic brakes; feed chain track speed 42 FPM, 2 HP feed drive.Complete with: -- Operator control panel, PLC (Programmable Logic Control) keypad, and LED readouts; used tooling.NOTE: Actual Model "KDF 650".NOTE: Specifications must be confirmed.Machine Dimensions: 254"; x 50"; x 68"; H.Machine Dimensions with Outboard Panel Support Extended: 254"; x 66"; x 68"; H.

CAM-WOOD - SM-236AX, ...Moulder Feed Through 6-Head (B-R-L-T-T-B), working cap. 9" x 5-1/4". Specifications: -- Head sequence: Bottom 10 HP, Right 10 HP, Left 10 HP, Top 15 HP, Top 10 HP and Bottom 10 HP motor -- Max. (Min.) Working Thickness 5-1/4" (5/16") -- Min. Working Length 9-1/2 in. -- Feed Motor 4 HP, variable feed speed from 16 - 82 FPM -- Elevation motor 1 HP -- Spindle Dia.: 40 mm with cutterhead speed of 6,500 RPM. -- Mechanical digital readouts for all spindle adjustments, as well as chip breakers and pressure elements. -- Tool cutting circles: First bottom head 5", 2nd & 3rd head 5" to 6-1/4", 4th to 6th head 5" to 7".Feed System: -- Variable Feed Speed from 16 - 82 FPM with LED speed readout. -- Oversized top & bottom rollers run synchronized, ensuring smooth feeding. -- The (3) independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding.Complete with: -- Infeed table: 2M (6'-6") with manual table lubrication ports. -- Side pressure roller at infeed. -- Hard chrome-plated table for maximum wear resistance. -- Full sound and safety enclosure and manuals.

CAM-WOOD SM-124TAX Feed Through Moulder4-Head Moulder with a 11-3/4" width x 9" maximum thickness when used as a 2-sided planer, and 10-1/4" width x 4" maximum thickness when used in 4-sided operation ( please see literature ).Equipped with: -- Cast Iron mainframe to maximize stability & minimize vibration during operation for years of use. -- Fully enclosed sound hood with lift-up door for easy set-up access. -- Adjustable infeed table w/fence for straightening rough sawn material. -- 11 - 52 FPM Variable feed speed system with top-driven rollers. -- All spindle adjustments with mechanical digital readouts. -- Left and top spindles with mechanical digi-set readouts. Chipbreaker and pressure element with mechanical digital readouts for accurate adjustment and precise settings.Complete with: 40" Infeed table length, Chromed table plates, fences, and pressure shoes. Manual waxilit pump, Central lubrication of the machine from the front side.SPECIFICATIONS SM-124TA Max. (Min.) Working Width 10-1/4"Max. (Min.) Working Thickness 4"1st Spindle Horsepower 4.1 HP - 7,000 RPM2nd, 3rd Spindle Horsepower 4.1 HP - 7,000 RPM4th, Spindle Horsepower 4.1 HP - 7,000 RPMFeed Motor 1/2 HPSpindle Diameter 40 MMCutter Speeds 6,500 (RPM)Variable Feed Speeds (FPM) 17 ~ 66Cutter head Diameter 1-1/4" or 30 mmPneumatic Air 90 PSI (CFM) 5Dust Outlet Diameter 5" x 4"N.W. 1,157 LbsG.W. 1,366 LbsIncludes: -- Operator/spare parts manuals and set-up tools.

CAM-WOOD SM-632LX 6-Head Feed Through Moulder[6-Head (B-R-L-T-T-B), working cap. 12-1/2" x 6"]Specifications: -- Max/Min working width 12-1/2" - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 25 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with a cutterhead speed of 7,600 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on left and top spindles. Mechanical readouts for pressure elements and chip breakers; all chip breakers and pressure elements with pneumatics. -- Feed works: Inverter driven 10 HP feed system with feed speeds of 38 - 98 FPM. (up to 120 FPM available)Infeed table 2M (6'6"), chromed tables and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 98' per minute are a standard feature. -- The full safety enclosure covers as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows to fit several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- SM Automatic feed magazine -- DC Automatic digital control -- SM Knife setting stand

CAM-WOOD SM-532L 5-Head Through Feed Moulder5-Head (B-R-L-T-B), working cap. 12-1/2" x 6".Specifications: -- Max/Min working width 12-1/2" - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 25 HP and bottom 20 HP motor. -- All Horizontal spindle have outboard bearings -- Spindle dia. 50mm with cutterhead speed of 7,600 RPM. -- All spindles equipped with mechanical digital readouts, "Dual mechanical" readouts on left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 10 HP feed system with feed speeds of 28 - 98 FPM. (up to 120 FPM available)Infeed table 2M (6'6"), chromed tables and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 28' ~ 98' per minute are a standard feature. -- The full safety enclosure cover as chip guard and helps to reduce noises. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows to fit several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table, permits the table to be position extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high speed running. -- Centralized lubrication system Available options: -- SM Automatic feed magazine -- DC Automatic digital control -- SM Knife setting stand

CAM-WOOD SM-632 HS 6-Heads High-Speed Through Feed Moulder(6) Heads (B-R-L-T-T-B), working cap. 12-1/2" x 6-1/4"".Specifications: -- Max/Min working width 12 " - 3/4" -- Max/Min thickness 6" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 15 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP and bottom 20 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,200 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- Feed speeds ranging from 20' ~ 260' per minute are a standard feature. -- The full safety enclosure also works as a chip guard and helps to reduce noise. -- Table surface is hard chrome-plated for maximum wear resistance. -- All manually adjusted turning parts are housed in dry bearings for oil-free lubrication. -- One piece cast iron machine frame and table is especially normalization heat treated for maximum stability and rigidity. -- Fence adjustment is quickly accomplished by a quick-setting lever. -- The three independent section pneumatic pressure for the infeed rollers, in-process rollers and outfeed rollers can be set with individual pressure allowing for consistent feeding results and outstanding effect. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Each spindle is provided with a mechanical digital readout, giving accurate adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of vertical spindle and insert table permits the table to be positioned extremely close to the cutterheads for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic Jointer for all (6) heads add: ...$46,900 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control system. This option consists of motorized adjustment of the head control from the main screen of the machine.This option include: -- 15" HMI (1000 memory setting), -- Servo motor positioning, Simple and easy to operate. -- Width and thickness quickly & auto set-up -- Tools management system -- Lateral chain feeder (quoted with customer material specifications) -- For 6 heads machine add $82,800 -- For 7 heads machine add $ 90,600

CAM-WOOD SM-167AX Lateral Chain FeederLateral Chain Feeder for up to 11.8"' X 16' long materialFeatures: -- The feed table is designed to be able to connect with any 4-sided Moulder, Multiple Blade Rip Saw, Straight Line Rip Saw and Planer -- Feed rollers are pneumatically actuated for quick clamping of wood. The feed speed of the front set of rollers is adjustable to match the moulder -- Hydraulic drive motors for each feed roller allow variable feed drive -- Centralized control panel, with push-button for start and stop, chain feed regulation and display, feed roller raising/lowering control -- Infeed fence, the infeed fence allows the material to be lined up properly with the feed roller -- Wood thickness limit. There are two adjustable thickness limits preventing over-thickness material to enter the moulderSpecifications: -- Working width 25 to 300 mm (1" to 11.8") -- Working thickness: 8 to 160 mm (0.315" to 6.3") -- Working lenght: 2,000 mm to 7,000 mm (78.7" to 275.6") -- Infeed table 5,425 mm L X 2,090 mm W X 1,920 mm H ( 213.5' L X 82.2" W X 75.5" H) -- Minimum working length: 1,000 mm (39") -- Feed speed: 10 - 120 MPM (32.5 FPM - 390 FPM) -- Feed motor drive for hydraulic motor: 5 HP -- Table feed motor: 2 HP with inverter control -- Feed roller diameter: 140 mm (5-1/2")

CAM-WOOD SM-623-HS 6-Head High-Speed Trough Feed Moulder(6)-Heads (B-R-L-T-T-B), working cap. 9" x 6-1/4".Specifications: -- Max/Min working width 9-3/4" -- Max/Min thickness 6-1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 10 HP, right 10 HP, left 10 HP, top 15 HP, top 15 HP and bottom 15 HP motor. -- Spindle dia. 40 mm (or by request) with cutterhead speed of 6,200 RPM. -- Feed works: Inverter driven, 10 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2 M (6'6"), chromed tables, and fences. Side pressure roller mounted at the infeed. Features and complete with: -- SM-237-DG where the last bottom spindle can be used for cutter head or saws with inverter RPM control -- HMI Touch Screen Control for all the head positions -- Automatic setting from 2nd to 6th heads, (2) axis positions and thickness control by servo control movement -- 200 sets of memory (Extendable) -- Feed speeds ranging from 20' ~ 260' per minute are standard specifications. -- Hard chrome-plated table for maximum wear resistance. -- Full enclosure safety hood reduces noise and completely prevents chips from splashing. -- Anti-impact plate for over-width and over-thickness protection. -- Oversize top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard features maximum durability and is impact resistance. -- The three independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers canbe set with individual pressure allowing for consistent feeding results and outstanding effect. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Exclusively designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate with table feeding roller design, provides smooth and precise cutting of dry and wetwood, reducing the possibility of material jams. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic jointer head for all (6) heads add ...$ 58,500 -- Siko encoder with digital display for all axis add ...$ 4,200 per head -- Automatic lateral chain feeder P.O.R.

CAM-WOOD SM-732 HS 7-Heads High-Speed Trough Feed Moulder(7) Heads (B-R-L-T-T- T-B), working cap. 111 13/16" x 6-1/4"".Specifications: -- Max/Min working width 11 13/16" - 3/4" -- Max/Min thickness 6 1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 20 HP, right 15 HP, left 15 HP, top 20 HP, top 20 HP, top 15 HP and bottom 15 HP motor. -- All Horizontal spindles have outboard bearings -- Spindle dia. 50 mm with cutterhead speed of 6,000 RPM. -- All spindles are equipped with mechanical digital readouts, "Dual mechanical" readouts on the left and top spindles. Mechanical readouts for pressure elements and chipbreakers; all chipbreakers and pressure elements with pneumatics. -- Feed works: Inverter driven 15 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2M (6'6"), chromed tables, and fences. Side pressure roller mounted at infeed. Features and complete with: -- PNEUMATIC LOAD INFEED SIDE PRESSUREWhile high speed feeding, the side pressure on infeed table ensures every timber close to the fence even under different width. It's convenient to adjust quickly. --OVER HEiGHT PROTECTIONIn case workpiece exceeds the rated maximum height, it will be restricted by the over height protection device provided at the workpiece infeed end. -- HYDRAULIC OUT-BOARD BEARING SUPPORT TOP AND BOTTOM SPINDLESpecially designed hydraulic supports on the top and bottom spindles assure maximum stability while performing high speed and heavy duty machining. -- PNEUMATIC LOAD SIDE PRESSURE WHEELS The front side air pressure wheel on left vertical spindle fully eliminates problem when feeding short or narrow stock not smoothly. The pressure plate is easy and quickly to adjust. -- PNEUMATIC LOAD TOP PRESSURE PLATEThe front pressure plate for top spindle is available to apply an air loading device ensuring maximum stability while performing high speed cutting -- CENTERAL LUBRICATION POINTThe lubrication point are located at the centralized plate for convenience. -- POWERED INFEED TABLE ROLLER The roller in the infeed table is powered, providing a smooth feeding effect for feed stock. -- VERTICAL SPINDLE AXIAL ADJUSTMENT UP TO 60MMIt allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. The 60mm spindle adjustment provides full utilization for a single cutter. -- CENTRALIZED PRESSURE ADJUSTMENT• All pressure regulations for the entire pneumatic system are centralized at the front of the machine for added convenience in pressure adjustment, and sectional pressure adjustments for all pressure rollers ensure consistent pressure.• Clear numerical indicators are provided to correspond directly to the pneumatic mechanisms on the machine, allowing operators to make adjustments based on different processing requirementsAvailable options: -- Automatic Jointer for all (6) heads add: ...$45,600 -- Digital (electronic) display for X and Y axis for each head add $ 3,200 /per head -- NC Automatic positioning control sys

CAM-WOOD PL-24 TOP & BOTTOM STRAIGHTENING PLANER8" x 24" Capacity Planer for accurate and powerful two-sided planing in one pass.Includes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $3,000 Specifications: -- 25"; Max. Planning Width, 3/8" to 8"; Max. Planning Thickness. -- 1/4";Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 70 FPM Feed Speeds (Variable). -- 4,200 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges -- 25 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor and 1/2 HP Elevation Motor. -- Net weight 7,200 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-fre

CAM-WOOD PL-18 18" Wide Top & Bottom Straightening Planer. -- 18" Planer with straight knife heads with HSS knives for accurate and powerful two-sided planning in one pass.ADD for Spiral Heads with Carbide Insert Knives... $4,000.00Specifications: -- 17-3/4"; Max. Planning Width. -- 3/8 to 8" Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 10"; Min. Planning Length. -- 15 to 70 FPM Feeding Speed (Inverter Driven). -- 4,200 RPM Cutter Straight Knife Head Speed. (6,000 RPM for Spiral Cutter Head). -- (4) Knife Cutterheads. -- 15 HP Upper Motor. -- 10 HP Bottom Motor. -- 2 HP Feed Motor. -- 1/2 HP Elevation Motor. -- Table Size (L x W) 88" x 16". -- N.W. 6,500 Lbs.Features: -- Standard equipped with automatic thickness controller, easy, accurate and quick setting for the cutting thickness. -- Upper & lower straight knives or spiral cutterheads for accurate and powerful two-sided planing in one pass. -- The worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planning. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing of the surface can be performed to prevent jumping during processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with heavy-duty drive chains and gears to provide a smooth even feeding during rough or finish planning. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- The heavy-duty rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial motor for maximum cutting capacity. -- All precision sealed long-life bearing for durability -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Changing the knife on the upper cutterhead only requires removal of the upper dust chute. -- The optional spiral insert head design allows for fast, accurate insert changes and minimum down time. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth chatter-free planing regardless of the feed rate or hardness of material being planed. -- A powerful motor is utilized to make adjustments quickly

CAM-WOOD PL-38 TOP & BOTTOM STRAIGHTENING PLANERIncludes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Insert Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $8,000Specifications: -- 3" to 38"; Max. Planning Width -- 3/8" to 7"; Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 52 FPM Feed Speeds (Variable). -- 4,000 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges 40 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor -- 2 HP Elevation Motor. -- Net weight 9,800 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-free planing regardless of the feed rate or hardness of planed material.

CAM-WOOD MODEL WP-4S 650 2C 25" 4-SIDED PLANER WITH MOULDING CAPABILITIES: -- WP-4S2C-650-6 25"; wide x 6"; high 4-Side Planer $189,900 -- WP-4S2C-650-12 25"; wide x 12"; high 4-Side Planer $208,900 -- WP-4S2C-650-16 25"; wide x 16"; high 4-Side Planer $226,900 -- WP-4S2C-650-20 25"; wide x 20"; high 4-Side Planer $238,900Designed for heavy furniture, cabinet, flooring, intermittent planing millwork, and other industrial uses. Perfect Planer for S2S and S4S planing up to 16" high x 25" wide timbers, tongue & groove flooring, wall paneling, etc. up to approximately 75 FPM depending on depth of cuts and dimensions of parts.SPECIFICATIONS: -- Width capacity from 2-3/4"; to 25";. -- Thickness capacity from 3/4"; to 6";. (up to 16"; with O/B Bearings is optional) -- Feed speeds variable from 18 to 65 FPM -- 15 HP Bottom head motor (20 HP optional) -- 20 HP Top head motor (25 HP optional) -- 20 HP Left (outside) spindle motor -- 15 HP Right (inside) spindle motor -- 1/2 HP motors on right & left champhering (top eased edge) spindles -- 10 HP feed motor -- 5"; dia. top and bottom cutterheads -- 5"; or 6"; dia. right & left cutterheads -- 60 mm (2.362";) dia. spindles on top and bottom heads -- 40 mm (1.574";) dia. spindles on top and bottom heads -- 30 mm (1.181") champhering spindles -- 15 x 15 x 2.5 mm insert knives -- (4) Dust outlets, each 6"; diameter -- Planer measurements: 110"; long x 91"; wide x 94"; high -- Planer weighs 19,500 Lbs. FEATURES: -- Compact construction with planing and moulding capabilities; provides flexible performance at an affordable price -- Equipped with a digital controller to set thickness & width automatically -- Rigidly mounted alloy steel spindle with outboard bearing support for accurate, vibration-free planing surfaces on horizontal spindles -- Spindle height adjustment by precision rack & pinion gear sets. -- Bedplates are precision ground, chrome-plated and polished to a mirror finish; provide a smooth, wear-resistant surface -- Variable speed inverter control for smooth feed speed adjustment depending on lumber hardness, depth of cut & width. Speed adjusts to provide the best finish and highest speed for best overall performance. -- Feed rolls are driven by geared transmission boxes and drive shafts with heavy-duty universal joints and drive shafts; provide smooth, even feeding for rough or finish planing -- Heavy fabricated steel plate frame, heated and stress relieved for vibration-free finishes, supports the worktable and helps dampen vibration for a superior finish. Ensures years of dependable service -- Industrial-grade, standard off-the-shelf motors for maximum cutting capacity and ease of service -- Bearings are precision, sealed, long-life bearings for durability and service life -- Removable cutterheads on all spindles, designed for convenient knife changing or rotating, including the bottom head. -- Changing or rotating knives on the top head only requires r

CAM-WOOD SM-124TAX 4-Sided Planer/Moulder; 11-3/4"; Wide x 4" to 9"; HighCompact construction with moulding & planing capabilities and flexible performance at an attractive price. Designed for furniture, cabinet, and yes, even industrial arts and large hobby shops. The perfect machine for tongue & groove flooring, wall paneling, S4S work, etc. Specifications: -- 2-Sided Planing Capacity: 7/16"; to 9"; thick x 11-5/8"; wide -- 4-Sided Planing Capacity: 7/16"; to 9"; thick x 10-1/4"; wide. -- All cutters run at 7,000 RPM -- Top and bottom heads are 2-27/32"; (72 mm) diameter. -- Right and left side heads are 3-1/2"; (90 mm) diameter -- All spindles powered by 4.1 HP (3 kW) motors -- Top Spindle will profile to a 3/8"; pattern depth and 5/16"; max. stock removal when planing. -- Bottom Spindle will profile to a 3/16"; pattern depth and 3/16"; max. stock removal when planing. -- Right & left side spindles are 4"; long and have a max. moulding depth of 13/16";. -- Machined and hard chromed table is 24"; wide x 40"; long and travels 9"; (230 mm) vertically -- Feed system runs at 11 to 52 FPM and is powered by a 1/2 HP variable speed drive. -- Overall dimensions are 54"; long x 42"; wide x 44"; high and weighs 1,370 Lbs.Features: -- Large 11-5/8"; wide x 9"; thick 2-sided planing capacity or 10-1/4"; wide x 4"; thick 4-sided planing and moulding work. -- Individual motors drive each spindle; 7,000 RPM spindle speeds on all heads. -- Mechanical meter for accurate thickness adjustments. -- Heavy-duty spindle assemblies for durability & run-out free finishes. -- Rigidly mounted alloy steel spindles in precision bearings provide accurate and vibration-free power transfer. -- Spindle height adjustment by precision rack & pinion gear system. -- Compact construction, Heavy-duty welded steel frame and See through top guard. -- Magnetic overload switch for protection. -- Industrial-rated TEFC motors with sealed-for-life ball bearings.

CAM-WOOD PL-12SX 12" Wide Top & Bottom Straightening PlanerFeatures & Equipped with: -- Spiral Insert Cutterheads. -- Standard equipped with Automatic Thickness Controller, easy and quick setting for the cutting thickness. -- Top & bottom carbide cutter heads for accurate and powerful two-sided planing in one pass. -- Auto digital thickness control for quick and accurate setup. -- The worktable surface was precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planing. -- Variable speed control by inverter for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The in-feed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then an accurate planing surface can be performed to prevent jumping during the processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with a heavy-duty drive chain and gears to provide a smooth even feeding during rough or finish planing. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload Specifications: -- 7-1/2 HP Top Head Motor -- 5 HP Bottom Head Motor -- 12-1/2"; Max. Working Width -- 4-3/4"; Max. Working Thickness -- 19/32"; Min. Working Thickness -- 13"; Min. Working Length -- 1/4"; Max. Cutting Depth per Head -- 2 HP Feed Motor -- Feed Speed (Inverter drive) from 15 to 52 FPM -- 5,000 RPM Cutter Head Speed -- 1/2 HP Elevation Motor -- With (2) 6" diameter dust outlets -- Spiral Insert Cutterheads with (45) 12 x 30 x 1.5 mm carbide insert knives with (2) cutting edges. Allows for fast, accurate insert changes and minimum downtime -- If required, change of electrics, will be quoted separately
