Biomass Equipment For Sale

VERVILLE - 95-VP-438SE-CCW-35/125I: 4-Station Bagger complete Automatic Bag Placement and Bag SealerComplete Line was used for wood shavings only. The Line is in operation at the time of this write-up.The VERVILLE - VP438-CCW: 4-Station compression Bagging System designed for high-efficiency bagging operations.It features: High tubes of 125". Automatic plastic bag sealing Ability to handle bag sizes ranging from: 11" x 17" to 30" High.This System is often used in industries like: Biomass and Packaging. It also includes features: Oil tank heater and a Modem for remote monitoring.Bagging Capacity -- Handles bag sizes ranging from: 11" x 17" to 30" high. -- Automatic feature: Automatic plastic bag sealer for seamless operations. -- Height: System features: High tubes of 125 in., making it suitable for large-scale bagging needs. Additional Features -- Equipped with: Oil tank heater; modem for remote monitoring ensuring smooth and efficient performance.The control box is mounted on the side of the automatic Bagger with: ALLEN-BRADLEY Panel View 550 unit. -- Main 4-section Bagger: 125 " Tall. -- Main master control cabinet. -- Long 45° screw auger to feed from: Bottom of the Sifter to the top of the Bagger -- Master hydraulic tank & pump arrangement with all hoses. -- Full sealed bag auto. discharge conveyor belt & turning roller Conveyor. -- Sifter with: Canvas wrap cover. -- Screw Conveyor: Runs from under the outside dust Collection System rotary airlock: Drops the “good"; wood chips down to the 45° screw with “light dust" going out thru the Screw Conveyor into an open Dump Trunk outside.IMPORTANT ISSUESThe machinery requires a new Electronic Board & Computer with Software. Computer & Software is available, but it has to be programmed for this machine.Total HP: 75Price Includes: Loading on a Truck

VERVILLE 6-SCREW HOLDING BINSpecifications: -- (6) Motorized 14-1/2" Diameter Bottom Screw -- (1) Motorized 14-1/2" Diameter Exit Screw -- 11 Feet Long -- 16 Feet Wide -- 18 Feet High -- 12 Feet High Support LegsDismantled and Loaded on Truck

Verville VP300 Bagger

10x40 Triple Pass Drum Dryer Webb Dust Burner All piping and controls Cyclone Additional blower Airlock

Webb Waste Burner With (3) Draft Blowers And Heat Duct To Drum Dryer Transition, AAP 125hp Induction Blower Mdl S105-32 With Pipe To Cyclone Transition

Webb Dryer System

WEIMA ZM-40 Quad Shaft 4-Shaft ShredderEquipped with: -- Dual drive motors - (2) 30 HP Drive motors. -- Hopper opening measures 51" x 55.1" (1,300 x 1,400 mm); cutting chamber opening of 30" x 27.6" (762 x 700 mm). -- Rotor length of 30" (762 mm); Rotor speed 25 RPM; cutting disc 11" (280 mm) diameter. -- Complete with: -- Control Panel with soft start and 16' cable bundle. -- Note: "Quad Shaft" Shredders, unlike Dual Shaft Shredders, allow shredded material to be circulated through the cutting chamber until it is small enough to pass through the sizing screen. -- Machine weight: 5,500 Lbs.

WEIMA ZM-30 Quad Shaft 4-Shaft ShredderEquipped with: Model- ZM 30 S -- Unit was used to shred wire (6,000 – 8,000 lbs per hour) --20mm screen included 25 HP x 2 --480V- 3 phase --Cutting chamber is 19"; x 27"; Hopper is 33"; x 48"; --The ZM30S is a beefed up version of the ZM 30. Unit has the same size motors, shafts and cutters as the ZM 50 but with a shorter shaft length

WEIMA C 150 Briquette PressSpecifications & Features: -- Produces 2" (50 mm) dia. Briquettes; -- Hopper opening of 41" x 41" (1,040 x 1,040 mm); hopper volume 1.43 cu/yd (1.1 cbm). Equipped with: -- 9 HP Hydraulic motor; 0.75 HP auger motor; hydraulic oil volume of 26.4 gallons (100 liters). -- Vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material; extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio at 2,600 PSI; hourly output up to 80 - 120 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors").Features: -- Briquette length control, chrome plated clamp, oil level switch, control panel side-mounted to hopper, and overheating protection for hydraulic oil. Solid German engineering. - Freight, start-up, discharge pipes, etc. not included.

WEIMA WLK 13 Vertical Hopper-fed Low Noise Grinder Specifications: -- Single shaft Shredder/Grinder, 51" x 47" hopper opening (straight sided), 2 cu. yds. cap.; 368 mm (14.5") rotor dia. x 51.2" rotor length; 60 HP motor and hydraulic ram. -- Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (68) welded knife holders, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear; drop out discharge, lift up door for easy purge cleaning when used in plastics application. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full. -- Features: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Recommended for plastic, paper or wood applications.

WEIMA TH 514 Briquette Press (Cylindrical). Produces 2" (50 mm) dia. x 4" (100 mm) long compacted logs. Specifications: -- Approx. 1.4 m³ vertical hopper, 12 HP (9 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 80 - 120 Lbs/Hr. ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). Equipped with: -- Centralized control panel for easy operation, PLC Logic control & solid German engineering. Complete with: -- Auto on/off switch, auto length adjustment, & oil level sensor. Optional: -- Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.

WEIMA WL-6 Low Noise Vertical Hopper Waste Grinder Specifications: -- Low noise hopper-fed grinder with a 10" dia X 31.5" long rotor and a 24HP drive package that includes a 2-sided flared hopper. -- Vertical 1.3 cubic yard hopper with 31.5" x 39.2" (800 mm x 900 mm) opening. Equipped with: -- (21) Recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear. -- Rotor operates at 80 - 100 RPM with outputs ranging from 1,000 - 34,000 Lb/Hr depending on screen size and material.Includes: -- Control panel.(4,926) Total operating hours.

WEIMA - WLB 400, ...Horizontal Low Speed Grinder Equipped with: -- 25 HP Rotor motor; rotor with (18) 4-way indexable, replaceable cutter knives. Features: -- Top infeed roller; 15-1/2" x 2-1/2" feed opening; Heavy-Duty Industrial Grade construction with stress relieved shell and frame; Heavy-Duty outboard roller bearings; separate electrical control panel. Complete with: -- 8" Dia. collection outlet;

WEIMA WLH-400 Horizontal Low-Speed Grinder with 16' Vibratory Infeed ConveyorEquipped with: -- 30 HP Rotor motor; 14.5" Dia. rotor with (22) 4-way indexable, replaceable cutter knives 40 mm X 40 mm, 1-piece counter bed knife, rotor/cutterhead grinding speed 500 - 600 RPM. -- Features: -- Top infeed roller, Heavy Duty Industrial Grade construction with stress-relieved shell and frame; Heavy Duty outboard roller bearings; separate electrical control panel with "soft start" starter. -- Complete with: -- 10" dia. collection outlet 3,000 CFM required. -- Includes: -- 14" Wide x 12' long vibrating infeed conveyor. -- Grinding capacity of 900 to 1,500 lbs/hour.

WEIMA - WLB 400, ...Horizontal Low Speed Grinder Equipped with: -- 25 HP Rotor motor; rotor with (18) 4-way indexable, replaceable cutter knives. Features: -- Top infeed roller; 15-1/2" x 2-1/2" feed opening; Heavy-Duty Industrial Grade construction with stress relieved shell and frame; Heavy-Duty outboard roller bearings; separate electrical control panel. Complete with: -- 8" Dia. collection outlet; 3/4" screen.

WEIMA WL-10 Vertical Hopper Low Noise Grinder:39" x 47" Hopper opening (straight sided with flared top section), 1.3 cu. yds. capacity.Equipped with: -- 368 mm (14-3/4") rotor dia.; 60 - 120 RPM rotor speed; 40 HP motor. -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counterknife (40 x 40 mm), (2) Rows of knives to ensure uniform discharge free of splinters; adjustable counter knife for maximum reduction of cutting gap; reduce friction, and dedicate more horsepower to grinding. -- (52) Replaceable back bolt-on cutter knives, recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear..Complete with: -- HMI Operator Interface mounted in a stand alone NEMA 12 electrical enclosure. -- 8" Dia. dust collection outlet (1,900 CFM required); 1/2" interchangeable screen. -- Output depends on screen size, material density, and moisture content; hydraulic ram optimizes feed pressure by monitoring rotor motor amperage. -- Extented upper 5' X 7'Note: Approximately (1,200) Lbs/Hr output with 1/2" screen.

WEIMA - Woodchuck: Low Noise Slow Speed Vertical Wood Waste GrinderLow cost/investment solution for Woodwaste disposal - feasible for a small shop.Specifications -- 25 HP Main Drive motor; 24" x 41" hopper opening; 0.74 cu. yds cap; 10" dia. rotor, 100 RPM. -- Equipped with: -- (28) 40 mm x 40 mm Concave; indexable cutters; 6" discharge outlet. -- Features -- Patented V-ROTOR design utilizes tooling closely matched to grooves in the counter knife. -- V-ROTOR Produces: Uniform discharged material; free of splinters; dedicates more horsepower to grinding. -- Includes -- 5/8" or 3/4" Screen (TBD); integrated "plug-and-play" electrical control system with: UL Approved components. -- Options Include -- Powered Screw Chip extraction system as pictured.

WEIMA ZM-40 Quad Shaft 4-Shaft ShredderEquipped with: -- Dual drive motors - (2) 20 HP Drive motors. -- Hopper opening measures 51" x 55.1" (1,300 x 1,400 mm); cutting chamber opening of 30" x 27.6" (762 x 700 mm). -- Rotor length of 30" (762 mm); Rotor speed 25 RPM; cutting disc 11" (280 mm) diameter. -- Complete with: -- Control Panel with soft start and 16' cable bundle. -- Note: "Quad Shaft" Shredders, unlike Dual Shaft Shredders, allow shredded material to be circulated through the cutting chamber until it is small enough to pass through the sizing screen. -- Machine weight: 5,500 Lbs.

WEIMA WLK-6 Vertical Hopper-Fed Low-Noise Waste GrinderEquipped with: -- 31-1/2" x 49" hopper opening at the top, 1.2 cu. yds. cap.; (3) sides straight with curved Front Wall. -- 30 HP rotor motor, 10" dia. Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counterknife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- 31-1/2" Long rotor operates at 80 - 120 RPM; equipped with (42) replaceable back bolt-on (4 x indexable) concave shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Features: -- WEIMA's proprietary gearbox designed specifically for slow speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. -- Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Material output from 1,000 - 1,250 Lbs/Hr (output is an average and can be influenced by density, material size, screen size, feeding form, and other); 1" standard screen hole size. -- Includes: -- A/B Programmable Logic Controller. -- Options: -- Flared hopper, material discharge auger.

WEIMA WLK 10 Vertical Hopper-Fed Low-Noise Grinder Equipped with: -- 39.4" x 47.2" Hopper opening at the top, 1.7 cu. yds. cap.; (3) sides straight with curved Front Wall. -- 60 HP rotor motor, 14-1/2" dia. The patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- 39.4" Long rotor operates at 60 - 120 RPM; equipped with (52) replaceable back bolt-on (4 x indexable) concave-shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. Features: -- WEIMA'S proprietary gearbox is designed specifically for slow-speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL-approved components (system UL certification available upon request for an additional charge). -- Ground material output depends on screen hole size and material from 1,200-2,500 Lbs/Hr.; 3/4" holes are supplied standard screen hole size. Options: -- Flared hopper, material discharge auger; programmable logic controls, and ram comb.
