Gang Saws For Sale

Pendu 9100 SE Gang Saw with Sizer & 30HP , 75HP on Arbors

1979 well Maintained Pendu 4100 Log Machine - Can also do Pallet stock Saws 8 x 8 and also 4 x 4 into rounded log They were doing Tiny Homes & Sheds All electric Still Under Power

Complete Cut-Up Line –– Pendu Junior Gang Saw, Deutz diesel, blower, dust pipe, cant deck, Morgan Standard Chop Saw, 24" blade, single phase, dead rolls and stops. $32,500 276-692-6322 or 276-694-4276

SH-100 - SMW Double Arbor Gang Saw - Cuts 1 1/2"-4"T x 9 3/4"-12"W, 8 1/4" Outside Diameter Saw Blade, 3 1/2" Outside Diameter Gasket, 2"dia Spindle, Dual 30hp Motor, Weighs ~3130lbs. Also Available: SH-120 - SMW Double Arbor Gang Saw - Cuts 2"-4 3/4"T x 9 3/4"-12"W, 9" Outside Diameter Saw Blade, 3 1/2" Outside Diameter Gasket, 2"dia Spindle, 30hp Motor & 40hp Motor, Weighs ~3440lbs. SH-150 - SMW Double Arbor Gang Saw - Cuts 2 3/8"-6"T x 9 3/4"-12"W, 10" Outside Diameter Saw Blade, 3 1/2" Outside Diameter Gasket, 2"dia Spindle, 30hp Motor & 40hp Motor, Weighs ~3575lbs.

SCHURMAN SINGLE ARBOR GANG SAW 6" x 60"

STAR V MACHINERY - SCG-1600: Automatic Cross Groover -- Specifications(1) Spindle with: 12 HP - 3,600 RPM Motor; 60" max. crosscut cap.; material thickness: 0.25" - 1.125".(1) Internal 60" stroke Tape Applicator Station. -- 96" Stroke Servo motor driven Rear Pusher Fence (full 60" rear table width); 96" long x 20" front table with: (5) Digital manual stops. -- Rear Fence Movement, Cutter forward Speed Cut/Tape Stroke and All Controls for Start/Stop, On/Off, Axis position Displays on 10" Touch Screen Panel HMI. -- Grooving head up & down movement via pneumatic cylinder with: Linear rail & linear bearings; depth fine adjustment with special threaded adjustable unit. -- Carriage cross travel powered by: 3 HP Hydraulic motor (4 GPM); driven ball screw with: Linear rail & linear bearings; feed rate: 0 - 40 FPM; Heavy-Duty welded frame construction. -- Complete with:Safety guards & cutter guards; pneumatic support fence; (1) Heavy-Duty infeed/outfeed roller tables. Available options at additional cost below:Accessories, Tooling & Tape: Choose and add to machine base price. Cove Corner Plug Jig: ...$ 575 ea. Brazed carbide 90° cutter for up to 1/2" solid surface: ...$ 745. Please specify the material. Brazed carbide cove backsplash cutter for 1/2" solid surface: ...$1,265 ea. Please specify 3/8" or 1/2" radius. Brazed carbide 90° cutter for up to 3/4" wood materials: ...$ 940.00. 90° Insert cutter for up to 1/2" thick material (body only): ...$1,265.00. Requires below inserts.......90° V-Insert for up to 1/2" thick material: ...$32 ea. min. of (12) inserts required: ...$ 384.......Carbide insert cove backsplash cutter head for 1/2" material (body only): ...$1,590 ea. Please specify 3/8 or 1/2 Radius.Requires Below Inserts:......3/8" Cove radius insert for 1/2" thick material: $42 ea. Min. of (12) inserts required. ...$ 504. ......3/8" Double 45° insert for 1/2" thick material: $42 ea. Min. of (12) Inserts required. ...$ 504.......PCD Diamond 90° cutter for up to 1/2" thick material $3,485 ea.......PCD Diamond cove cutter with 1/2" radius for 1/2" thick material: $ 5,645.00 ea. Roll of VAC2MG: 2" (50 mm) wide; 1,025 y (937 m) long roll V-Groove tape: $ 245. ea.& Minimum of (3) rolls per order = $735. -- Actual Model: STAR V MACHINERY - SCG-1600: Automatic Cross Groover

STAR V MACHINERY - SLG-2000 36: Linear V-Groover -- SpecificationsWorking table dimensions: 120" Long x 36" wide; working width: 6" - infinite" (152 mm - infinite); working length: 20" - infinite (508 mm - infinite); working thickness: 0.25" - 1.15" (6 - 29 mm).Max. throat clearance for linear & crosscuts: 14-1/2"/24-1/2" (355/622 mm). -- Equipped with: (2) Independent 10 HP - 3,600 RPM saw motors with: "Servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple fold profiles, or using it for hogging and finish cut; 9-1/4" (235 mm) max. cutterhead dia.(1) Saw motor mounted on the front & (1) Saw motor mounted on the back of the 8" x 12" x 1/2" heat treated steel Heavy-Duty overhead support beam.Side-to-side head travels via linear rails & bearings; manual head height adjustment via linear rails & bearings. -- Feeding System(1) 3 HP Variable speed drive belt system with: "Servo" height adjustment; feed rate: 0 - 45 FPM (12 MPM); belt feeder moves workpiece on a precision "aluminum" roller table. -- Tape Applicator (2) Automatic Tape Applicators with: "Servo" adjustment according to the Saw motor position in "Y" axis. -- Operator Interface10" HDMI Touchscreen display for: Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:Safety guards and cutter guards; Anti-Kickback Device; Emergency Shutoff line.Dust Collection requirements: 4,200 CFM; Collector outlets on cutter guards: 5" in dia. -- Actual model #: STAR V MACHINERY SLG-2000

STAR V MACHINERY SLG-2000 48" LINEAR V-GROOVER: -- SpecificationsWorking table dimensions: 120" Long x 48" wide; working width: 6" - infinite" (152 mm - infinite); working length: 20" - infinite (508 mm - infinite); working thickness: 0.25" - 1.15" (6 - 29 mm).Max. throat clearance for linear & crosscuts: 14-1/2"/24-1/2" (355/622 mm). -- Equipped with: (2) Independent 10 HP - 3,600 RPM saw motors with: "Servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple fold profiles, or using it for hogging and finish cut; 9-1/4" (235 mm) max. cutterhead dia.(1) Saw motor mounted on the front & (1) Saw motor mounted on the back of the 8" x 12" x 1/2" heat treated steel Heavy-Duty overhead support beam.Side-to-side head travels via linear rails & bearings; manual head height adjustment via linear rails & bearings. -- Feeding System(1) 3 HP Variable speed drive belt system with: "Servo" height adjustment; feed rate: 0 - 45 FPM (12 MPM); belt feeder moves workpiece on a precision "aluminum" roller table. -- Tape Applicator (2) Automatic Tape Applicators with: "Servo" adjustment according to the Saw motor position in "Y" axis. -- Operator Interface10" HDMI Touchscreen display for: Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:Safety guards and cutter guards; Anti-Kickback Device; Emergency Shutoff line.Dust Collection requirements: 4,200 CFM; Collector outlets on cutter guards: 5" in dia. -- Actual model #: STAR V MACHINERY SLG-2000

STAR V MACHINERY SLW-4818 SLAT WALL GROOVING MACHINE: -- Specifications48" wide panel capacity, feed through style overhead milling Slatwall machine. The machine will produce 4' x 8' panels in portrait orientation or any orientation as long as the panel size does not exceed 4' x 4'.The panels are placed with side to be grooved, facing up, then pushed in between the fixed fence and a movable fence, until the panel is grabbed by the first rubberized feed roller, the panel is then transported between a number of pinch rollers and processed through 3 rows of high-speed spindle motors.As the T Slot cutting is processed each bank (6 in total) of 3 high speed spindle motors cut a T shaped groove appropriate to the size of tool installed in each spindle, blow the groove clean by use of high-speed air knives, and remove dust through a number of dust ports. Then pinch rollers push the sheet out of the machine roller bed.Panels as narrow as 6" wide can be fed through the machine although workpieces less than 3/8" thick must be 48" wide. Workpieces as short as 24" can also be fed through the machine safely.Minimum recommended workpiece width, 6": Maximum workpiece width, 48": Minimum recommended workpiece length, 24": Maximum workpiece length, UNLIMITED: Maximum workpiece height, 1.5". -- Features:5HP 1750RPM, 460V Feeder Drive Motor through 50:1 Gear Box. 5HP VFD Inverter to drive and control feed speed through machine, 0-50 linear feet per minute. Heavy Duty Welded Tubular Steel Frame Construction. Stainless Steel Roller Bed with Rollers 6" on Center. 10x Linatex Rubber coated Feed Pinch Rollers Driven by 5Hp Feed Motor and Drive. Fixed Guide Fence& Movable fence to aid feeding of sheets into machine. Safety Fence around both sides along the length of the machine, with 1 gate in each side, each with safety interlock. Safety photo eye in infeed and outfeed side of the machine. Gauge block for setting height of router arbors. -- Spindle Motors:18 x 3 kW (4 HP), 18,000 RPM, 230V, High Speed Spindle Motors. 100 HP VFD Inverter to drive and control rotational speed of all 18 spindle motors.Variable RPM of Spindle Motors through Potentiometer and RPM displayed on Control Panel. Individual Ammeter for each Spindle on Control Panel. 6 x banks with 3 x High Speed Spindle Motors per bank (18 Total Spindle Motors). All 6 Spindle Banks are adjustable on the Overhead Beams by Hand, and lock into Position via locking handles. Digital Read Out for horizontal position of each spindle bank. Spindle 1 on each bank is fixed horizontally, Spindles 2, and 3 adjust on each bank horizontally. All 3 spindles adjust individually vertically on each spindle bank via Hand wheel. Position of depth on Digital Read Out.All Spindle raised individually through pneumatic cylinder for changing tooling, or when not in use. Each Bank has a phenolic Hold Down Shoe.Spindle Centers adjust from 3" to 4" Centers; Rapid Center Adjust Switch, from 3" to 4" through Air Cylinders against positive s

STAR V MACHINERY SLW-6018 SLAT WALL GROOVING MACHINE: -- Specifications60" (5') Wide panel capacity, feed through style overhead milling Slatwall machine. The machine will produce 5' x 8' panels in portrait orientation or any orientation as long as the panel size does not exceed 5' x 5'.The panels are placed with side to be grooved, facing up, then pushed in between the fixed fence and a movable fence, until the panel is grabbed by the first rubberized feed roller, the panel is then transported between a number of pinch rollers and processed through 3 rows of high-speed spindle motors.As the T Slot cutting is processed each bank (6 in total) of 3 high speed spindle motors cut a T shaped groove appropriate to the size of tool installed in each spindle, blow the groove clean by use of high-speed air knives, and remove dust through a number of dust ports. Then pinch rollers push the sheet out of the machine roller bed.Panels as narrow as 6" wide can be fed through the machine although workpieces less than 3/8" thick must be 48" wide. Workpieces as short as 24" can also be fed through the machine safely.Minimum recommended workpiece width, 6": Maximum workpiece width, 48": Minimum recommended workpiece length, 24": Maximum workpiece length, UNLIMITED: Maximum workpiece height, 1.5". -- Features:5HP 1750RPM, 460V Feeder Drive Motor through 50:1 Gear Box. 5HP VFD Inverter to drive and control feed speed through machine, 0-50 linear feet per minute. Heavy Duty Welded Tubular Steel Frame Construction. Stainless Steel Roller Bed with Rollers 6" on Center. 10x Linatex Rubber coated Feed Pinch Rollers Driven by 5Hp Feed Motor and Drive. Fixed Guide Fence & Movable fence to aid feeding of sheets into machine. Safety Fence around both sides along the length of the machine, with 1 gate in each side, each with safety interlock. Safety photo eye in infeed and outfeed side of the machine. Gauge block for setting height of router arbors. -- Spindle Motors:18 x 3 kW (4 HP), 18,000 RPM, 230V, High Speed Spindle Motors. 100 HP VFD Inverter to drive and control rotational speed of all 18 spindle motors.Variable RPM of Spindle Motors through Potentiometer and RPM displayed on Control Panel. Individual Ammeter for each Spindle on Control Panel. 6x banks with 3x High Speed Spindle Motors per bank (18 Total Spindle Motors). All 6 Spindle Banks are adjustable on the Overhead Beams by Hand, and lock into Position via locking handles. Digital Read Out for horizontal position of each spindle bank. Spindle 1 on each bank is fixed horizontally, Spindles 2, and 3 adjust on each bank horizontally. All 3 spindles adjust individually vertically on each spindle bank via Hand wheel. Position of depth on Digital Read Out.All Spindle raised individually through pneumatic cylinder for changing tooling, or when not in use. Each Bank has a phenolic Hold Down Shoe.Spindle Centers adjust from 3" to 4" Centers; Rapid Center Adjust Switch, from 3" to 4" through Air Cylinders against positi

Tierney 24" Gang With In & Out feed 300HP

Gang Saw with 30HP Electric Motor

ZAFFARONI MSR 160 P BS/PD MULTI-BLADE PANEL SAW (W/TOP & BOTTOM ARBORS): -- SpecificationsZAFFARONI is the "Top of the Line" in Precision Multi-Rip Saws for Panels. Blade Depth is mechanically adjustable with a tolerance of +/- 0.01 mm (0.0004").The Saw is so precise it can also be used for V-Grooving.The Saw blades project through the table from above & below. A double-row of hold-down wheels are mounted above the saw, with (28) adjustable rollers to prevent contact with the blade.The Top & Bottom shafts & wheels are connected by a quick flange system that can be removed/replaced without dismounting the bearing collars.Motorized adjustment of the depth of the saw blade projection by the touch-screen operating control(4) motorized & self-adjusting (according to material thickness) upper rubber coated rollers with grooves,(4) Idle lower polyethylene coated rollers & (1) Pair of ejector rollers at the output of the machine.Automatic locking and unlocking arbor shaft with HSK collector on the LH side controlled with electro-pneumatic device for the automatic cleaning of the coupling Safety device that features a presence and positioning sensor of the shaft; closed circuit air cooling device for the shaft bearingsSaw Blade work table with interchangeable MDF inserts.Technical Characteristics: -- Working Width is 1,600 mm (63"). -- Max. panel pass through is 1,780 mm (70"), min. length is (450 mm) 17.7". -- Motorized thickness adjustment from 0 - 70 mm (2.7"). -- Adjustable projection of the saw blades from the working from 0 - 62 mm (0" - 2.4") with circular saw blades or hogger trimmer up to 280 mm dia. (11"). -- Working table height is variable, from 970 - 1270 mm (38" - 50"). -- Material Feed Speed from 3 - 45 MPM (9.8 - 147.6 FPM). -- Main Motor Power is 45 kW (60 HP) with toothed Belt Drive arbor. -- Saw Blade arbor 80 mm dia. x 1,310 mm (3-1/8" x 51-1/2"), with double-tangs and automatic anti-rotation locking clutch. -- Blade Arbor Speed of 4,000 RPM.Machine Features: -- Opening of the roller group through pneumatic cylinder with timer interlock for safety. -- Safety protection hood with sound absorbing materials to conform to ISO 7960/95 Norm. -- PLC Logic touch screen control with digital communications through profibus cable.Spacer Sets: Machine requires Spacer Sets and Saw Blades (not included); pricing is available on request.Examples:width from......1 - 10 mm ...$ 25.45width from.....11 - 25 mm ...$ 30.15width from.....26 - 50 mm ...$ 35.60width from.....51 - 75 mm ...$ 40.15width from.....76 - 100 mm ...$ 45.20width from...101 - 125 mm ...$ 49.75width from...126 - 150 mm ...$ 54.90Example of productivity:Approx. 240 panels/hour running the machine at 49 FPM (15MPM) – considering to load 4 panels/minute) & a change-over time of approx. 10 minutes.

ZAFFARONI MLS 130 P PD MULTI-BLADE PANEL SAW: -- SpecificationsZaffaroni is the Top of the Line in Precision Multi Rip saws for Panels. Blade Depth is mechanically adjustable with a tolerance of =- 0.01 mm (0.0004"). The saw is so precise it can also be used for "V" grooving.The Saw blades project through the table from below. A double row of hold down wheels are mounted above the saw, with 24 adjustable rollers to prevent contact with the blade.Technical Characteristics: -- Working Width 1300 mm (51-1/8") -- Min. Panel Length 300 mm (11-7/8"). -- Motorized thickness adjustment from 0 - 70 mm (2-3/4"). -- Adjustable projection of the saw blades from the working from 42 - 62 mm (1- 5/8" - 2-7/16") with circular saw blades or hogger trimmer up to 280 mm diam. (11"). -- Working Table Height 1120 mm (44"). -- Transport Speed from 3 - 45 MPM (9.8 - 147.6 FPM). -- Main Motor Power 37 KW (50 HP) with Belt Drive. -- Saw Blade Spindle 80 mm x 1310 mm (3-1/8: x 51-1/2"), with double tangs and automatic anti-rotation locking clutch. -- Spindle Speed 4,000 RPM.Machine Features: -- Opening of the roller group through pneumatic cylinder with timer interlock for safety. -- Safety protection hood with sound absorbing materials to conform to ISO 7960/95 Norm. -- PLC logic control with digtital communications through bus cable.Spacer Sets: Machines require Spacer Sets and Saw Blades (not included) and pricing is available on request.

ZAFFARONI MLS 160 P MULTI-BLADE PANEL SAW: -- SpecificationsZAFFARONI is the "Top of the Line" in Precision Multi-Rip Saws for Panels. Blade Depth is mechanically adjustable with a tolerance of +/- 0.01 mm (0.0004"). The Saw is so precise it can also be used for V-Grooving.The Saw blades project through the table from below. A double-row of hold-down wheels are mounted above the Saw, with (24) adjustable rollers to prevent contact with the blade.Technical Characteristics: -- Working Width is 1,600 mm (63"). -- Max. panel pass through is 1,780 mm (70"), min. length is (320 mm) 12-5/8". -- Motorized thickness adjustment from 0 - 70 mm (2-3/4"). -- Adjustable projection of the saw blades from the working from 42 - 62 mm (1-5/8" - 2-7/16") with circular saw blades or hogger trimmer up to 280 mm dia. (11"). -- Working table height is 1,120 mm (44"). -- Material Feed Speed from 3 - 45 MPM (9.8 - 147.6 FPM). -- Main Motor Power is 55 kW (74 HP) with Belt Drive arbor. -- Saw Blade arbor 80 mm dia. x 1,310 mm (3-1/8" x 51-1/2"), with double-tangs and automatic anti-rotation locking clutch. -- Blade Arbor Speed of 4,000 RPM.Machine Features: -- Opening of the roller group through pneumatic cylinder with timer interlock for safety. -- Safety protection hood with sound absorbing materials to conform to ISO 7960/95 Norm. -- PLC Logic control with digital communications through bus cable.Spacer Sets: Machine requires Spacer Sets and Saw Blades (not included); pricing is available on request. Examples:width from......1 - 10 mm ...$ 25.45width from.....11 - 25 mm ...$ 30.15width from.....26 - 50 mm ...$ 35.60width from.....51 - 75 mm ...$ 40.15width from.....76 - 100 mm ...$ 45.20width from...101 - 125 mm ...$ 49.75width from...126 - 150 mm ...$ 54.90
