Hogs and Wood Grinders For Sale

WEIMA - Woodchuck: Low Noise Slow Speed Vertical Wood Waste GrinderLow cost/investment solution for Woodwaste disposal - feasible for a small shop.Specifications -- 25 HP Main Drive motor; 24" x 41" hopper opening; 0.74 cu. yds cap; 10" dia. rotor, 100 RPM. -- Equipped with: -- (28) 40 mm x 40 mm Concave; indexable cutters; 6" discharge outlet. -- Features -- Patented V-ROTOR design utilizes tooling closely matched to grooves in the counter knife. -- V-ROTOR Produces: Uniform discharged material; free of splinters; dedicates more horsepower to grinding. -- Includes -- 5/8" or 3/4" Screen (TBD); integrated "plug-and-play" electrical control system with: UL Approved components. -- (5,454) Total operating hours.

WEIMA Horizontal Beaver 300 Slow Speed, High Torque Waste Grinder w/Vibratory Conveyor. 25 HP (18.5 kW), 10" rotor diameter, 11.8" (300 mm) rotor length, (14) 40 x 40 mm indexable, concave cutters; 11.8" x 4" infeed opening. Equipped with: -- WRRL 300 12' Vibratory Conveyor (550 Lbs). -- The "Horizontal Beaver" receives the material from a vibratory conveyor system; from the conveyor, a feed roller system pinches and feeds the material into the rotor. -- Features: Patented "V-Rotor" design utilizes a V-groove rotor closely matched to grooves in the counter-knife; the V-Rotor produces uniform discharged material that is free of splinters and dedicates more horsepower to grinding. -- Includes integrated "plug-and-play" electrical control system with UL approved components; -- Extraction requirements: 1,900 CFM (28 MPS), 8" (200 mm) diameter for dust collection. Total Approx. weight of 2,430 Lbs.

WEIMA WLK 8 Vertical Hopper-fed Low-noise GrinderSpecifications: -- 39" x 49" Hopper opening at the top, 1.75 cu. yds. cap.; (3) sides straight with curved back wall. -- 35 HP (27 kW) rotor motor, 10" dia. patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counterknife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- Equipped with: --39.4" Long rotor operating at 80 - 120 RPM; with (54) replaceable back bolt-on (4 x indexable) concave shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Features: -- WEIMA'S proprietary gearbox designed specifically for slow speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. -- Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Options: -- Flared hopper, material discharge auger; programmable logic controls and ram comb.

WEIMA Woodchuck Low Noise Slow Speed Vertical Wood Waste Grinder:A low cost/investment solution for Woodwaste disposal - feasible for a small shop.Specifications: -- 25 HP Main Drive motor; 24" x 41" hopper opening, 0.74 cu. yds cap; 10" dia. rotor, 100 RPM. -- Equipped with: -- (28) 40 mm x 40 mm Concave, indexable cutters; 6" discharge outlet. -- Features: -- Patented V-ROTOR design utilizes tooling closely matched to grooves in the counter-knife. -- V-ROTOR Produces uniform discharged material, free of splinters and dedicates more horsepower to grinding. -- Includes: -- 5/8" or 3/4" screen (TBD); Integrated "plug-and-play" electrical control system with UL approved components; 1-Year warranty, operations and parts manuals. .

WEIMA WLK-6 Vertical Hopper-Fed Low-Noise Waste GrinderEquipped with: -- 31-1/2" x 49" hopper opening at the top, 1.2 cu. yds. cap.; (3) sides straight with curved Front Wall. -- 30 HP rotor motor, 10" dia. Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counterknife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- 31-1/2" Long rotor operates at 80 - 120 RPM; equipped with (42) replaceable back bolt-on (4 x indexable) concave shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Features: -- WEIMA's proprietary gearbox designed specifically for slow speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. -- Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Material output from 1,000 - 1,250 Lbs/Hr (output is an average and can be influenced by density, material size, screen size, feeding form, and other); 1" standard screen hole size. -- Includes: -- A/B Programmable Logic Controller. -- Options: -- Flared hopper, material discharge auger.

WEIMA WLK 10 Vertical Hopper-Fed Low-Noise Grinder Equipped with: -- 39.4" x 47.2" Hopper opening at the top, 1.7 cu. yds. cap.; (3) sides straight with curved Front Wall. -- 60 HP rotor motor, 14-1/2" dia. The patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- 39.4" Long rotor operates at 60 - 120 RPM; equipped with (52) replaceable back bolt-on (4 x indexable) concave-shaped cutter knives. -- Welded knife holders standard; recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. Features: -- WEIMA'S proprietary gearbox is designed specifically for slow-speed grinders. -- 8" Dia. outlet for material discharge via auger, conveyor, or pneumatic (1,900 CFM required for pneumatic conveying); choice of 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content). -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system. Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL-approved components (system UL certification available upon request for an additional charge). -- Ground material output depends on screen hole size and material from 1,200-2,500 Lbs/Hr.; 3/4" holes are supplied standard screen hole size. Options: -- Flared hopper, material discharge auger; programmable logic controls, and ram comb.

WEIMA TIGER 400 Horizontal Slow Speed Single Shaft Wood Grinder w/Vibratory ConveyorSpecifications: -- 6" High (160 mm) x 15-11/16" (400 mm) wide max. infeed opening, 50 HP rotor motor, 14" dia. rotor grinds at 620 RPM (fixed rotor speed depending on application). -- Equipped with: -- Patented "V-ROTOR" design utilizes a v-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- Features: -- (22) Replaceable back bolt-on cutter knives (welded knife holders standard, bolt-ons per customer request), recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Infeed roller with replaceable wear strips for ease of maintenance, feed speed is controlled by monitoring the amp draw of the rotor, preventing "braking" or excessive pressure on the rotor, the vibratory infeed conveyor (12'), is also tied into the feed roll to eliminate binding. -- 9.85" (250 mm) Dia. dust collection outlet (3,000 CFM required). -- Includes: -- Heavy Duty low-profile frame (15-3/4" passline height); integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge); up to 16' vibratory infeed conveyor available.

WEIMA TIGER 600 Horizontal Slow Speed Grinder w/Vibratory ConveyorSpecifications: -- 6" High x 23.6" wide max. infeed opening, 50-60 HP rotor motor, 14" dia. rotor grinds at 620 RPM (fixed rotor speed depending on application). -- Equipped with: -- Patented "V-ROTOR" design utilizes a v-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. -- Features: -- (32) Replaceable back bolt-on cutter knives (welded knife holders standard, bolt-ons per customer request), recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear. -- Infeed roller with replaceable wear strips for ease of maintenance, feed speed is controlled by monitoring the amp draw of the rotor, preventing "braking" or excessive pressure on the rotor, the vibratory infeed conveyor (12') is tied into the feed roll to eliminate binding. -- 9.85" (250 mm) Dia. dust collection outlet (3,000 CFM required). -- Includes: -- Heavy Duty low-profile frame (15-3/4" passline height); integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge); up to 16' vibratory infeed conveyor available.

WEIMA WLK 15 Vertical Hopper-fed Low Noise Grinder Specifications: -- Single shaft Shredder/Grinder, 59" x 59" rear-flared hopper opening; 3 cu. yds. cap.; 368 mm (14.5") rotor dia.; 120 HP motor; hydraulic ram with 4-sided serrated ram. -- Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (82) Welded knives, (4) broaching cutters & (4) counter-knives, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear. -- Features: -- Drop out discharge, hydraulically actuated lift up door for easy purge cleaning; extended screen basket; cut-out for conveyor (not included); false wall; 3/8" - 4" screen available. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full. -- Complete with: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Recommended for plastic, paper or wood applications.

WEIMA WL-10 Vertical Hopper Low Noise Grinder:39" x 47" Hopper opening (straight sided with flared top section), 1.3 cu. yds. capacity.Equipped with: -- 368 mm (14-3/4") rotor dia.; 60 - 120 RPM rotor speed; 40 HP motor. -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counterknife (40 x 40 mm), (2) Rows of knives to ensure uniform discharge free of splinters; adjustable counter knife for maximum reduction of cutting gap; reduce friction, and dedicate more horsepower to grinding. -- (52) Replaceable back bolt-on cutter knives, recessed concave cutters with low clearance over the rotor extend cutter life, protect the bolts, and reduce machine wear..Complete with: -- HMI Operator Interface mounted in a stand alone NEMA 12 electrical enclosure. -- 8" Dia. dust collection outlet (1,900 CFM required); 1/2" interchangeable screen. -- Output depends on screen size, material density, and moisture content; hydraulic ram optimizes feed pressure by monitoring rotor motor amperage. -- Extented upper 5' X 7'Note: Approximately (1,200) Lbs/Hr output with 1/2" screen.

WEIMA - Woodchuck: Low Noise Slow Speed Vertical Wood Waste GrinderLow cost/investment solution for Woodwaste disposal - feasible for a small shop.Specifications -- 25 HP Main Drive motor; 24" x 41" hopper opening; 0.74 cu. yds cap; 10" dia. rotor, 100 RPM. -- Equipped with: -- (28) 40 mm x 40 mm Concave; indexable cutters; 6" discharge outlet. -- Features -- Patented V-ROTOR design utilizes tooling closely matched to grooves in the counter knife. -- V-ROTOR Produces: Uniform discharged material; free of splinters; dedicates more horsepower to grinding. -- Includes -- 5/8" or 3/4" Screen (TBD); integrated "plug-and-play" electrical control system with: UL Approved components. -- Options Include -- Powered Screw Chip extraction system as pictured.

WEIMA WLH-400 Horizontal Low-Speed Grinder with 16' Vibratory Infeed ConveyorEquipped with: -- 30 HP Rotor motor; 14.5" Dia. rotor with (22) 4-way indexable, replaceable cutter knives 40 mm X 40 mm, 1-piece counter bed knife, rotor/cutterhead grinding speed 500 - 600 RPM. -- Features: -- Top infeed roller, Heavy Duty Industrial Grade construction with stress-relieved shell and frame; Heavy Duty outboard roller bearings; separate electrical control panel with "soft start" starter. -- Complete with: -- 10" dia. collection outlet 3,000 CFM required. -- Includes: -- 14" Wide x 12' long vibrating infeed conveyor. -- Grinding capacity of 900 to 1,500 lbs/hour.

Manufacturers Specifications tool diameter: 100 - 300 mm tool width: max. approx. 230 mm motor / grinding disc drive: approx. 1,1 kW free angle, adjustable 15 - 35° drive for coolant pump: approx. 0,065 kW tank capacity: approx. 90 l

West Salem model 2420GR1-H wood grinder/hog 480 v Bottom discharge No screen - machine has breaking bars Disconnected and ready to ship

MLS Number 12321010 WEST SALEM WSM5472 Horizontal Grinder -60” Millpower Shaker conveyor/finger screen – deck removed, used to meter flow of material fed by operator and reduce bed depth to make cross belt and head pulley magnets most efficient. -60” Eriez cross belt electro magnet. -Eriez 10K42 kW Silicon Rectifier incorporating: To convert 480 volt, 60 Hz, 3 phase AC to230 volt DC 10,000 watts output Normal convection cooled, full wave bridge circuit Fused AC switch Nema 3r Enclosure -Eries beefy magnet stand to support magnet and chain fall. -60” x 28’6” Slider Bed (Heavy Duty Feeder Type Conveyor) with 8’ section of stainless steel non-magnetic for Eriez cross belt magnet to perform at peak -20”x60” Dodge magnetic head pulley – installed to double up on magnets on conveyor, prior to material entering WSM grinder drag chain feed. Downstream from this is the WSM 5472bh Titan horizontal grinder. Schematics and wiring diagram can be supplied as well. WSM also supplied the chip discharge conveyor and magnetic head pulley and electrical panel with touch screen (by Emerson). Price includes dismantling and loading on buyer's truck. Manuals available for components.

WSM Power Hog Industrial Hammermill - 500 HP NO MOTORSelling a heavy-duty West Salem Machinery (WSM) Power Hog Hammermill designed for industrial wood grinding, recycling, and construction debris processing. This unit features a massive 4-foot feed opening and can be powered a 300-500 horsepower electric motor, capable of shredding railroad ties, pallets, green waste, C&D materials, and more.Key Features: 4' wide feed opening for high-volume throughput Power Hog rotor - ideal for tough wood waste 300-500 HP electric motor - NOT INCLUDEDIdeal for: Sawmills & mulch processors Railroad tie reclaimers Demolition & recycling operations Biomass and wood waste facilities

WSM (WEST SALEM) nice large horizontal grinder/hog. 300HP direct drive motor. Power assisted, spiked top feed roll and knurled & chromed bottom feed roll. Includes 30' infeed slider-belt conveyor. In very good condition. REDUCED $49,000.

West Salem 2422 H2 Hog
