HOLYTEK - KL-36PC, ...2-Head Sander 2-Head Planer Sander 36" with planer head & combination head.Description: -- Planing Head (P): 6'' Dia. made of steel with spiral design for heavy stock removal. 228 TCT Tips: 15 x 15 x 2.5 mm; each disposed on (6) rows. Each knife has: (4) Usable cutting edges; easy access to planing head for tips rotation or replacement. -- Precise dial indicator showing the exact positioning of the sanding pad; quiet & smooth oscillation! Pneumatic oscillation system controlled electronically by an infrared system, which is not affected by dust. -- Combination Head: (1) Drum & (1) sanding pad (C) for superior quality of finishing. Sanding belt with: 120 or 150 Grit; allows finishing sanding in a single pass. -- Elevation Table: (4) Screws. -- Infeed roller table extension: 15-3/4". -- Outfeed roller table: 15-3/4" with (2) Rollers. -- Centralized Control Panel with: Electronic digital readout (Metric or Imperial) for elevation; precise positioning at the elevation requested. -- Ammeter indicating: Electrical intensity on the spiral cutterhead and the combination head motors. -- Electrical box with: CSA Approved electrical components ensuring maximum dependability and an outstanding long-lasting performance.Specifications -- Spiral cutterhead motor: 20 HP - 600 V; 60 Hz - 3 Ph. -- Combination head motor: 15 HP - 600 V; 60 Hz - 3 Ph. -- Table elevation motor: 1/4 HP - 600 V; 60 Hz - 3 Ph. -- Feed motor: 2 HP - 600 V; 60 Hz - 3 Ph. -- Spiral cutterhead dia.: 6''. -- TCT Tips dim.: 15 x 15 x 2 mm (228); (6) rows. -- Max. working width: 36". -- Min. working length: 12". -- Max. working thickness: 5". -- Sanding belt dim.: 37" x 75". -- Dust hoods dia.: 4'' x 2 & 5" x 2. -- Machine dim.: 71" L x 76" W x 77'' H. -- Net weight: 1,450 kG or 3,190 Lbs.

HOLYTEK SS-512 TS Shaper with Tilting Spindle, and Power FeederSpecifications: -- 1-1/4" Interchangeable spindle, 7.5 HP motor with (5) spindle speed settings of 3,000 - 4,000 - 6,000 - 8,000, & 10,000 RPM. -- Approx. 6" max. cap. under nut, 31" x 39" cast iron table. -- Insert ring diameters 2.8", 4/3", 6" and 8". -- Tilting spindle +10° and -45° -- Vertical movement of the spindle 7" -- sliding tableComplete with: -- Reverse rotation switch, adjustable fence assembly, and dust hood. -- 3-Roll Power Feeder

Holytek heavy duty band vertical resaw

Holytek heavy duty band vertical resaw Model# HB-900H

HOLYTEK MHB 242 Top/Bottom Wide Belt SanderHeavy-duty and powerful double surface sander providing significant time saving and improved productivity.Smooth and quiet oscillation. Belts oscillation controlled electronically by an infrared system which resists dust.Pneumatic sanding belts tensioning ensuring fast and easy belt replacement.Independent motor for each sanding belt.Pneumatic disc brake system automatically activated if power supply is interrupted, thus preserving the sanding belts from being damaged. Top and bottom 24" wide belt sanderFeatures: -- Spiral grooved 8" (D) rollers (R) and 3-1/2" (D) rollers (K) keep the sanding belts cool. -- Sanding belts: 75" Long. -- Elevation of table with digital readout and activated by independent motor. -- Control panel with: Ammeters indicating main motors current. Specifications: -- Upper Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Upper Combination head motor: 10 HP; 600 V; 60 Hz - 3-Ph. -- Lower Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Lower Combination head motor: 10 HP, 600 V, 60 Hz - 3-Ph. -- Feeding motors: 2 HP (x2). -- Table elevation motor: 0.5 HP. -- Electrical intensity: 53 A. -- Drums: 8" (D) - 75 DUROS. -- Max. working width: 24". -- Min. working length: 13-3/4". -- Working thickness: 3/16" ~ 5" -- Sanding belts dimensions: 25" x 75". -- Variable feeding speed: 8 - 16 MPM. -- Dust hoods Top: 4 x 4"(D); Bottom: 3 x 4"(D). -- OAL 127" x 70" x 75" high. -- Weight: 9,460 Lbs.

HOLYTEK HK 610 Double Sided Planer with THOMAS MANUFACTURING Return ConveyorHOLYTEK HK 610 Double Sided Planer specifications - -- 24" x 8" Cap. Double Surface Planer, spiral carbide cutterheads belt driven by 20 HP top and 15 HP bottom motors at 4,000 RPM. -- Spriral cutter head 125 mm diam. with 96 inserts 30mm X 12 mm X 1.5 mm -- Variable feed motor delivers a range of 7 M./min to 20 M./min. (19.5 FPM to 82 FPM) -- Feed motor 3 HP, corrugated sectional infeed rollers and (4) table rollers provide superior feeding regardless of the type of wood being processed; hard-chromed table surface precision ground to provide smooth performance and maximum wear resistance at high speeds. -- Machines are currently wired for 220 Voltage.Technical Specifications:• Maximum width 610 mm (24")• Minimum length: 300 mm (11.9")• Maximum thickness 170 mm (6.69")• Minimum thickness 8 mm (.31")• Table size: 686 mm X 2616 mm (27" X 103")• Dovetailed slideways on the table elevation ensures stability and rigidity; a mechanical readout provides accurate details of table positioning adjustment; thickness limit guard is provided at the infeed end as a safety feature. • Machine Dimensions - 109" Long x 46" Wide x 68" High, Machine weight 7,280 lbsTHOMAS MANUFACTURING Return Conveyor specifications -37" Wide x 144" Long Receiving Table that transfers to a 20" Wide x 240" Long Return Conveyor1 HP - 3 Phase Variable-Speed DrivePhotoelectric SensorRemote ControlSolid State TimerSwing-Out Section that is 20" Wide x 90" Long

HOLYTEK - HRS-12TK, ...Straight Line Rip SawSpecifications: -- Overhead saw arbor, 15 HP motor belt driven, 4,500 RPM arbor. -- 12" Dia. max. saw blade. -- 3-3/8" Max. depth of cut. -- 18" Max. throat depth. -- 2 HP Stepped feed speeds of 50 - 65 - 83 - 100. -- Automatic lubrication of chain. -- Magnetic controls. -- Saw is glue line rated.Equipped with & Features: -- Overhead holddown rolls. -- Double-row of antikickback fingers. -- (6) Pressure rollers. -- Infeed adjustable fence line. -- Cast Iron table with rip fence.

HOLYTEK - HRS-12TK, ...Straight Line Rip Saw with Glue Joint CutSpecifications: -- Overhead saw arbor, 15 HP motor belt driven, 4,500 RPM arbor. -- 12" Dia. max. saw blade. -- 3-3/8" Max. depth of cut. -- 18" Max. throat depth. -- 2 HP Stepped feed speeds of 50 - 65 - 83 - 100. -- Automatic lubrication of chain. -- Magnetic controls. -- Saw is glue line rated.Equipped with & Features: -- Overhead holddown rolls. -- Double-row of antikickback fingers. -- (6) Pressure rollers. -- Infeed adjustable fence line. -- Cast Iron table with rip fence.Also Included: -- Laser light -- Glue joint cutting capacity

HOLYTEK - HK 400, ...Top & Bottom PlanerSpecifications: -- 16" x 8" Cap., top & bottom helical insert knife heads, 4,000 RPM cutterhead rotation. -- 15 HP Top & 10 HP bottom; 10" min. stock length. -- 2 HP Variable feed speed from 23 - 65 FPM; sectional feed rolls & chipbreaker. -- 0.5 HP Motorized opening w/micro-adjustable table. Complete with: -- Heavy swing-out carriage with a built-in micro-dial; supports bottom cutterhead, pulled out for "quick & easy" replacement of knives.

HOLYTEK HK 610 Double-Sided Strato Planer -- 24" x 8" Cap. Double Surface Planer, spiral carbide cutterheads belt driven by 20 HP top and 15 HP bottom motors at 5,000 RPM. -- Spriral cutter head 125 mm diam. with 96 inserts 30 mm X 12 mm X 1.5 mm -- Variable feed motor delivers a range of 6 M./min to 25 M./min. (9.5 FPM to 82 FPM), -- Feed motor 3 HP, corrugated sectional infeed rollers and (4) table rollers provide superior feeding regardless of the type of wood being processed; -- Hard-chromed table surface precision ground to provide smooth performance and maximum wear resistance at high speeds.Technical Specifications:• Maximum width 635 mm (25")• Minimum length: 300 mm (11.9")• Maximum thickness 200 mm (7.87")• Minimum thickness 10 mm (.39")• Table size: 686 mm x 2616 mm (27" x 103")Features: &#9679 Dovetailed slideways on the table elevation ensure stability and rigidity; Mechanical readout provides accurate details of table positioning adjustment; &#9679 Thickness limit guard is provided at the infeed end as a safety feature. &#9679 Machine weight 6,600 Lbs

Holytek 37DA Wide Belt Sander (2) Heads37" Width cap Drum, Combination Head1st Head: 7" Dia. spiral grooved rubber covered contact roller, 20 HP motor;2nd Head: Combination sanding head with 5" dia. spiral grooved rubber covered contact roll & 2" wide polishing platen, 15 HP motor.Specifications -- Abrasive belt size of 37" x 60" -- Pneumatic belt tensioning and electronic abrasive belt tracking -- 12" min. working length. -- 2 HP Conveyor belt motor, -- Variable feed speed from 13 - 52 FPM,Equipped with & Features -- Infeed & outfeed rubber covered holddown rolls; -- 0" - 4" motorized thickness adjustment by 0.5 HP motor. -- Safety stop bar, emergency rail stop across the front of conveyor -- Motor load meters.

HOLYTEK HP-11P Horizontal Resaw -- Hydraulic Feeding conveyor, hydraulic pump with 3 HP motor -- Main saw motor 20 hp. Specifications: -- Working width capacity 12“ (300 mm) -- Variable Feed Speed 0- 17 m/min (0 to 55 FPM) -- Thickness capacity 4mm to 125 mm (.11/8" to 4.92") -- Conveyor tilting 0 ° to 7° -- Electroni display of cutting height -- Blade Capacity 4270 X 25 X 0.89 mm. -- Wheels Diameter 725 mm -- Return conveyor on machine top

Year: 2008 Excellent Condition HolzHer Triathlon 1488 Edge Bander Ligmatec Return Conveyor Manual Included Description: PreMill Front & Rear Trim Saws Top & Bottom Rough Cutter Top & Bottom Combination Finish Cutter 3mm Corner Rounding Edge Scraping Edge Buffing Variable Speed 8-18 mpm 8-60mm panel thickness Electrical: 230V 3Phase

Holz-her 1315 Edgebender

Holz-her 1255 Panel Saw Digital Readout capacity 169” x 74” 2.36 depth of cut 3 KW motor rotates 90^

Manufacturer Specs - Cartridge glue system, automatic magazine coil & strips (1903), 3 mm PVC capacity. - Pneumatic guillotine for coil cutoff. - Double-motor end trim (1918), chamfers 0° - 10°, includes pcs changeover system. - Universal top & bottom fine trim (1942m) for bevels from 0° - 15°; allows simultaneous bevel & profile trimming top & bottom. - PVC scraper unit (1929) with 3mm inserts. - Top & bottom buffing (1940). - Complete with PLC for easy setup & program storage. - Fixed outboard panel support. - Solid state frequency converter and sound enclosure.

Holz-her 1243 Slider Tigerstop Includes: (2) Cutting blades and scoring blades, some misc tooling

HOLZ-HER CUT 6220 Dynamic FRONT LOAD, AUTOMATIC PANEL SAW with 20'+ RIP cutting capacity!: -- Specifications: 4,300 mm (169.2") Max. rip cut cap., 6,250 mm (246") pull back pusher stroke; 105 mm (4.1") saw blade projection;28 HP (21 kW) Main saw motor, 3 HP (2.2 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 426 FPM (1 - 130 MPM ), return speed of 492 FPM (150 MPM).Automatic cutting length limiter adjusts the cutting length at the end of the workpiece, automatic saw carriage lubrication. -- Pusher Fence:(10) Material gripper clamps; 82 FPM (25 MPM) forward positioning speed, 328 FPM (100 MPM) return speed.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with "CUTCONTROL 2" + "EasyPlan" + Windows operating system,19" TFT Display with unlimited program storage; keypad for data entry, USB & RS-232 serial port, "CUTCONTROL 2" offers Real-Time 3D Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."CUTCONTROL 2" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials"Opti-Cut" & "EasyPlan" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting -- Complete with: Non Marking rear roller support rails; Solid Air Cushion Table before & after the cutting line, ensures easy panel handling. Pneumatic crosscut side aligner, adjustable from 0" - 82.6" (0 - 2,100 mm);Automatic saw blade height adjustment; Electronic positioning of the scoring blade through the NC control.(4) Adjustable via "pneumatic locking" air support tables, ea. 70.8" x 24" (1,800 x 509 mm); -- Actual Model is HOLZ-HER CUT 6220 Dynamic

Holz-her Streamer 1054 Edgebander Top/Bottom Trimmers End Trimmers Scraping Buffing Station No longer under power - Ready to ship! Serviced by Holly-her tech.

HOLZ-HER 1315 EDGEBANDER WITH CORNER ROUNDINGMax. 5/16" (8 mm) solid wood banding & 3 mm PVC cap., 1-3/4" max. panel thickness and 5-1/2" min. panel length.Equipped with: -- Cartridge glue system w/cartridge hopper & "quick melt" feature, automatic magazine for coil, strip & solid edgebanding; HD guillotine for 3 mm PVC, glue applicator nozzle. -- Pressure section with (1) large dia. drive roller & (2) idle rollers, each w/individual pneumatic plunge & pressure control, powered 1st roller with electronic speed control synchronized with chain feed speed.Workstations: -- Double motor end trim "1918" (0.5 HP - 18,000 RPM motor ea. 300 Cy HF motors), adjustable 0° - 10° for chamfer cuts electro-pneumatically. -- Top & bottom flush fine & radius trim unit "1942M" (0.8 HP - 300 Cy HF motors 18,000 RPM Motor ea.), bevels 0° - 15°, SIKO digital readouts. -- "Single Station" corner rounding unit for leading & trailing edge. -- "1929" Top & bottom profile scraper for thick PVC. -- Top & bottom buffing unit "1940" (0.25 HP - 2,600 RPM ea.), tilts 0° - 5°. -- Two feed speed 8/16 MPM (26 & 52 FPM), panel overhang beyond chain 35 mm (1.38").Equipped with: Opdraded Touch Screen Monitor Microprocessor for line control & glue temperature, 10 KVA frequency changer, outboard panel support, and sound enclosure w/interior lights over enclosed workstations of the machine, & used tooling on the stations.
