Sanders For Sale

GRIGGIO G 1100 Wide belt Sander2-Head, 1,100 mm (43") width cap. -- 1st Head: Rubber covered steel contact roll, duro 85, 220 mm diameter . -- 2nd Head: Rubber covered contact roll duro 50 -- 25 HP motor to drive both head. -- 43" x 85" abrasive belts, electropneumatic abrasive belt tracking, -- Conveyor belt feed, two speed from control panel at 15 and 30 FPM, 0.4/0.7 HP feed drive, automatic conveyor belt tracking, -- 1/8" - 6-1/2" motorized thickness adjustment with LED readout & 0.75Hp gearmotor drive. --Automatic positioning of the working table, rubber covered spring loaded pressure rollers, double infeed and outfeed rubber covered rolls, infeed panel "over-thickness" sensor. --Two suction dust hoods dia. 6" (150mm),

GRIZZLY H2934 2-HEAD WIDE BELT SANDER2-Head Wide Belt Sander, 36-1/2" width cap. -- Head configuration: - 1st Head: Rubber covered contact drum; 2nd Head: Combination head with rubber covered contact drum and adjustable platen; Abrasive belt size 37" x 60". -- 0" to 6" Thickness cap., LED digital depth encoder; 14" min. board length and 12" infeed conveyor. -- 1st Abrasive belt surface speed of 3,543 SFPM; 2nd abrasives belt surface speed of 2,554 SFPM. -- Conveyor speed from 14 - 60 FPM. -- 20 HP - 50/25 Amp Sanding motor; 1 HP - 3.4/1.7 Amp conveyor motor; 0.25 HP - 1.2/0.6 Amp table lift motor. -- Complete with: Rubber covered holddown rolls, adjustable felt platen, Amp/load meter, and disc brake for emergency stop.

GRIZZLY G5394 STROKE SANDERModel G5394 - Motor 3 Ho - Volt 220 - HZ 60 - Phase 1 - MFG No M05227 - Date 2008/09SPECIFICATIONS: -- Motor: 3 HP, 220V, single-phase, 17A -- Sanding belt speed: 3500 SFPM --Sanding belt size: 6" x 186" -- Table Size: 58" x 23-3/4" -- Table vertical travel: 24" -- Platen horizontal travel: 59" -- Table lateral travel: 18" -- Drive roller diameter: 8" -- Footprint: 70" L x 30-1/2" W -- Overall dimensions: 93-3/4" W x 38" D x 50" H -- Approximate shipping weight: 690 lbsORIGINAL MODEL NUMBER: CT-1500

24” width capacity 5HP motor 6” drums 11fpm

LSM 8 2 head wide belt sander · 1st Head: Segmented cross-belt, 5/8" wide segments (86 total) with "CSD" control, abrasive belt size 5.9" x 244", (5,400 mm X 150 mm ) inside chevron belt 5.9" x 191", sanding belt speed 5-12 m/s with 17 HP motor. (Inverter controlled) · 2nd Head: Combination head, with segmented polishing platen, 5/8" wide segments with CSD control, 17 HP motor, 106" x 53" ( 2,620 mm X 1,350 mm ) abrasive belt size. (Inverter controlled) Cleaning brush Vacuum bed

HEESEMANN - LSM 8-5 RRRL, ...53" Wide Belt Sander53" Width cap.: Drum, Drum, Drum, and CSD® Pad.Head Configuration:• Unit 1 - Longitudinal Sanding Unit: Steel contact roller, helically grooved. - Single-speed 48 HP motor, electronic braking.• Unit 2 - Longitudinal Sanding Unit: Rubber-covered contact roller, helically grooved. - Single-speed 35 HP motor, electronic braking.• Unit 3 - Longitudinal Sanding Unit:- Rubber-covered contact roller, helically grooved. - Single-speed 35 HP motor, electronic braking, bi-directional drive.• Unit 4 - Longitudinal Sanding Unit: CSD® Segmented pad system, 2-speed 20/26 HP motor, electronic braking.• Unit 5 - Panel Cleaning Brush: Fiber trimming, 2.3 HP Motor.Specifications: -- Working height: 880 mm (34.64"). -- Workpiece thickness: 3 mm to 150 mm (1/8" to 6"). -- Working width: 1,300 mm (51-1/8"). -- Longitudinal belt: 1,350 x 2,620 mm (53" x 103"). -- Machine voltage: U.S. Electrics 480 Volts, 3-Phase, 60 cycles.Constant Pass LineController: -- Industrial PC. -- TFT Color touchscreen. -- Windows® Operating System. -- (100) Memory addresses for: • CSD® sanding pressure. • Sanding start/stop. • Sanding belt speeds. • Grit sequence indication. • Sanding belt selection - "ON/OFF". • 1-Button sequenced starting for all motors.RS-232 Serial port.RJ-45 LAN Port.Modem with software licenses.For All additional, detailed specs, select the "View Literature" link .

HEESEMANN MFA-8 D Wide Belt Sander (4) Heads; 53" Width cap. Veneer/ Sealer Sanding Wide Belt.Great Lacquer/Sealer sander with: (2) Segmented polishing platen, (2) Orbital heads, (1) De-nibbing/Polishing brush.Head Configuration: Head 1: Segmented polishing platen, 5/8 wide segments CSD Control, Variable speed abrasive belt with inverter RPM control, 15HP motorHead 2: Segmented polishing platen, 5/8 wide segments CSD Control, Variable speed abrasive belt with inverter RPM control, 15HP motorHead 3: Orbital head with composite/dense fiber loading; 5HP motorHead 4: Orbital head with composite/dense fiber loading: 5HP motor(1) Brush Type head for de- nibbing and polishingSpecifications: -- LCD monitor with graphic display and key pad entry, 20 program capacity, -- Pressure for each segment can be pre-programmed to provide less pressure on the outer edges or more in the center if required.Equipped with & Features -- Air blast abrasive belt cleaner on heads 1 & 2. -- Variable feed speed from 10 to 49 FPM via 2 HP feed drive. -- Motorized thickness opening 1/4" to 3-5/32" max. -- Rubber covered Infeed and out feed holddown rolls.

HEESEMANN MFA-6 Wide Belt Sander with (3) Heads and a Cleaning Brush.Basic Working Capacity: Max. working width is 1,350 mm (53"), thickness opening min./max. is 3 mm - 150 mm (0.118" - 6.0"). - Conveyor belt speed variable from 5 - 15 MPM (16 - 49 FPM); constant pass height of 880 mm (34.65").Features: -- Head Configuration: (2) Steel contact drum heads, (2) "CSD" controlled contact platens, and (1) rotary cleaning brush. -- Belt Handling: Broken belt monitor and automatic infrared belt tracking; intermittent pneumatic belt cleaning device, belt access on the left-hand side. -- Conveyor Belt: High powered vacuum holddown by 8.6 kW (11.5 HP) fan drive motor, automatic vacuum monitoring system. Variable speed by inverter from 5 - 15 MPM (16 - 49 FPM). -- CSD-32 System: Heads #3 & #4 are equipped with HEESEMANN's Patented "Segmented Pad System", Computer Selective Pressure Control from 0 - 150%, precise surface & edge pressure control, edge pressure independent of surface; 2 mm thickness compensation - zero maintenance with sealed enclosure.Sanding Head Configuration: -- 1st Head: Steel Contact Roll, 8" dia., 25.3 kW (34 HP) motor; sanding belt size of 2,150 mm x 1,400 mm (85" x 55"); belt speed is 18 MPS (60 FPS); equipped with belt motor brake. -- 2nd Head: Steel Contact Roll, 8" dia., 17.5 kW (24 HP) motor; sanding belt size of 2,150 mm x 1,400 mm (85" x 55"); belt speed is 18 MPS (60 FPS); equipped with belt motor brake. -- 3rd Head: Sanding Platen, electronically controlled pressure segments to conform to panel size, 17.5 kW (24 HP) motor; sanding belt size is 2,150 mm x 1,400 mm (85" x 55"), belt speed of 18 MPS (60 FPS); equipped with belt motor brake.. -- Cleaning Brush: Outfeed Rotary Panel Cleaning bristle brush, 120 mm (4-3/4) dia., 0.9 kW (1.2 HP) motor, and holddown roller. -- Includes: Outfeed conveyor table, 48" width x 80" length. Large batch of sanding belts.Controls: -- LCD Operating Panel with: Touch-screen and graphical display, (20) memory addresses for sanding head selection, thickness opening, conveyor feed speed, 1-button sequenced starting of sanding motors, and tracking of sanding belt usage. -- Operating Requirements: Electrical is 151 Amps @ 460 Volt; Dust Extraction is 5,800 CFM @ 3" static pressure. Machine weight approx. 7,000 kG (15,500 Lbs). -- Complete With: Extended infeed table with (2) idle rollers, interior lights, emergency and oversize part thickness safety bar, and Manual.

MFA 6 3 heads Pad (inverter controlled) Pad (inverter controlled) brush CSD System 480 V 100 A

Heesemann MFA6 (3) Head Wide Belt Sander, 53" width cap. Drum Drum, Segmented platenHead configuration1st Head: Steel contact roll, 30 HP motor2nd Head: Rubber covered contact roll, 20 HP motor3rd Head: Segmented polishing platen, electronically controlled segments to conform to panel size, 20 HP motor4th Station: Outfeed rotary panel cleaning brush, 2 HP motor.Specifications -- Platen head equipped with: HESSEMANN's Patented "CSD-32" selective pressure adjustment system; sensors placed every (32 mm) sense part configuration, pressure for each segment can be pre-programmed to provide less pressure on the outer edges or more in the center if desired. -- Both contact rolls with NC positioning and auto grit compensation, automatic line control for platen independent of feed speed determines automatically the correct part in time for the pressure segmentEquipped with & Features -- Outfeed rotary panel cleaning brush, 2 HP motor. -- 55" x 103" Abrasive belts on all heads with abrasive belt air cleaners, "ICP" control for all sander functions, (20) programs storrage. -- Variable feed speed from 10 - 49 FPM, 3 HP feed drive with inverter control. -- Vacuum conveyor bed assembly with suction fan and )motor mounted in machine base, motorized thickness opening 0" - 5-7/8" w/digital readout, constant passline of conveyor bed assembly 35" height.NOTE Some Spec's need to Varified

Heesemann MFA Impression 4-Head Wide Belt SanderSpecifications -- Working Width: 53" (1350mm) -- Workpiece Thickness: 0.118" to 6" (3mm to 160mm) -- Working Height: 36.2" (880 mm) -- Wide Belt Size: 103" x 55" (2620mm x 1400mm) -- Cross Belt Size: 189"x6" (4800 x 150mm) -- Variable Feed Speed: 10-50 FPM (3-15 mpm) -- Vacuum Bed for Safe Movement -- os Workpieces Shorter than 19.7" (500mm)Head Configuration1st Head: Cross Sanding Unit Heesemann's Cross Sanding Head Unit Removes Fiber from Solid Wood or can be used to Remove Tape from VeneerSanding Belt Speed:6.5 - 65 FPS (2-20 m/s)Drive Motor: 23HP (17kW)2nd Head: Longitudinal Sanding Unit Sanding Belt Speed: 6-60 FPS (1.8-18 m/s) Drive Motor: 23HP (17kW)3rd Head Longitudinal Sanding Unit Sanding Belt Speed: 6-60 FPS (1.8-18 m/s) Drive Motor: 23HP (17kW)4th Head: Lef Head w/ Internal Pressure Belt Enhanced Finish Let Head Features an Inner Chevron Belt to Allow for Fine Sanding of Workpiece Sanding Belt Speed w/o Pressure Belt: 6-60 FPS (1.8-18 m/s) Sanding Belt Speed w/ Pressure Belt: 6-30 FPS (1.8-9 m/s) Drive Motor: 23HP (17kW)Equipped with & Features --All Heads Variable Speed Belt equipped with Inverter Motor -- CSD® segmented pad system on all Heads -- A pinch roll system, rubber covered and adjustable -- An automatic infra-red belt control -- Servo cross belt tracking adjustments, for quick and easy belt centering when loading -- Workpiece Blasting Device -- Rotating Compressed Air Nozzles for Blasting Workpiece Surface -- LED Lights on Belt Change Side -- Ionization Bar from Above that Helps Reduce Static Charge -- Pneumatic Conveyor Belt Cleaning -- Dust Extraction: Approx 6000 CFM -- Compressed Air: 100 cfm @ 100 psi -- Power: 480 Volt, 3 Phase, 60HZ

HEESEMANN - LSM 8, ...3-Head Wide Belt Sander53" Width cap. Crossbelt, Combination , and DrumHead Configuration:1st Head: Cross Belt Sanding Unit, 2-speed motor - 19/24 kW (26/33 HP). - Abrasive belt speed: 12/24 MPS (39/78 FPS); Cross Belt (Cloth), 4,800 x 150 mm (189" x 6").2nd Head: Combination Longitudinal Sanding Unit Front retractable roller for light calibrating and segmented pad system for fine sanding; bi-directional sanding; Door-in-Door viewing; 2 speed motor - 31/37 Hp, abrasive belt speed 10/20 mps (33/65 fps3rd Head: Longitudinal Sanding Unit Internal pressure segment belt for finer sanding Inner chevron belt; Inverter driven motor: 26 kW (34 HP); abrasive belt speed: 0.5-16 MPS (1.6-52 FPS); Longitudinal Belt: 2,620 x 1,350 mm (103" x 53").Unit 4: Panel Cleaning Brush, Fiber trimming.Specifications: -- HEESEMANN's LSM-8 Sanders are designed for heavy (2 - 3) shift operations; this Sander is ideal for: Whitewood sanding of veneered panels and panels coated with various sealers. -- The crossbelt removes tape, cuts short fibers that contribute to grain rising, and sands panels with "book-matched" veneer. -- The last sanding unit is equipped with an internal pressure segment belt for an extra smooth finish.Enhanced 16 mm control roller spacing with (3) rollers per segmented pad. -- CSD® Segmented pad system is equipped on all (3) sanding units. -- Pneumatic conveyor belt cleaning. -- Infeed extension with non-driven rollers. --Electronic variable feed speed from 5 - 25 MPM (16-82 FPM). --Workpiece thickness 3 mm - 140 mm (1/8" to 5-1/2").Equipped with & Features: -- Vacuum Table: Only HEESEMANN builds it into the frame for superior holddown! -- Industrial PC controller, Windows® Operating System.Width Capacity: 53"

HEESEMANN LSM-8/3-OSR Wide Belt Finishing Sander, 52" and (3) Heads; Equipped with: (1) longitudinal segmented platen head. and (2) Orbital Platens -- 1st Head: Longitudinal segmented platen head. Segmented Polishing Platen, 20 & 27 HP dual speed motor. electronically controlled segments to conform to panel size,.2620 x 1350 mm (91.4 x 53.2") Sanding belt. - Equipped with HEESEMANN's patented "CSD" selective pressure adjustment system, sensors placed every 16 mm (5/8") sense part configuration; pressure for each segment, to eliminate sand through, can be pre-programmed to provide less pressure on the outer edges or more in the center if desired. The "CSD" computer control will hold a maximum of (20) programs. -- 2nd & 3rd Heads: OSR Dual orbital action head with (1) high-speed orbit on sanding pad, powered by 3 kW (4.5 HP) motor.Secondary oscillation movement of platens powered by 1.5 HP motor. Upstream and downstream vacuum chutes on each head for dust localized dust pickup.- Platens feature "quick change" abrasive material; Both orbital heads with variable speed inverter drives. -- Outfeed Rotary Brush with cleaning brush loading with single end adjustment , 6" max. dia., 3.4 HP motor. -- Variable feed speed from 13 to 82 FPM, 6.5 HP feed drive. -- Infeed and outfeed Ssissor Lift and Control box shown are not included. -- Motorized thickness opening 1/4" to 3-5/32" max. - -- Power Consumption: 63 KW, 75 Amps. -- Separate display console for CSD control.

NOTE: Wide Belt Sander was completely rebuilt for $68,000 in 2019. 53" 4-Head Wide Belt Sander Head Configuration: 1st Head: Spiral rubber contact roll, 45 kW, 460 V; 2nd Head: Spiral rubber contact roll, 44 kW, 420/480 V; 3rd Head: Spiral rubber contact roll, 37 kW, 460 V; 4th Head: Platen design with (2) Smooth steel rollers; Final Station: Rotating air-jet blow-off; 12" Load space, Sensing, Abrasive belt size 1,400 x 3,250 mm (55.12" x 127.95"), T.B. WOODS "E-TRAC WF-2" Sensor-less vector drive for variable sanding head speed Vacuum feed mat, Adjustable fence, VACON Variable speed drive for feed speed, 8.6 kW, 254-277/440-480 V, Electronic belt tracking & Pneumatic motorized thickness control, Approximately 2 HP, 230/460 V HEESEMANN Swivel-mounted touchscreen control Overall dimensions: 164" x 92" x 112" H, Weight: 11,000 kg (24,250 Lbs.) NOTE: Machine is currently in storage.

54" 3-Head Orbital Sander, For abrasive belt cross-grain scratch removal with (3) Orbital Platen Heads & (1) Rotary Brush Head Configuration: 1st, 2nd, & 3rd Heads: Each with 5" W Platen, Dual orbital action, High-speed orbit on sanding pad with 3 kW (4 HP) Motor, Secondary oscillation with 1-1/2 HP Motor, "Quick-change" abrasive material, Inverter drive; Rotary Brush: 6" Maximum diameter, 3-1/2 HP Motor, Brush loading, Ionization bar for final fine dust collection Vacuum conveyor bed with 10 HP Blower motor, Inverter-controlled variable speed drive with 4 HP Motor & Variable feed speeds 15 - 66 FPM, Automatic conveyor belt tracking, Automatic parts thickness, with 1/8" - 4-5/8" Thickness range & Programmable height adjustment, (4) Screw jacks PC-based control, Windows XP, Touchscreen monitor, Infeed & outfeed spring-loaded hold-down rolls, Infeed hand safety stop, outfeed emergency stop, Digital motor load meters, High-efficiency dust extraction NOTE: Machine is currently in storage.

Heeseman LSM8 Wide Belt Sander

HEESEMANN LSM-8 C/L Wide Belt Sander, (2) Heads 53" (1,300 mm) Width cap., (1) Segmented cross-belt & (1) longitudinal combination head with segmented platen. Head Configuration: · 1st Head: Segmented cross-belt, 5/8" wide segments (86 total) with "CSD" control, abrasive belt size 5.9" x 244", (5,400 mm X 150 mm ) inside chevron belt 5.9" x 191", sanding belt speed 5-12 m/s with 17 HP motor. (Inverter controlled) · 2nd Head: Combination head, with segmented polishing platen, 5/8" wide segments with CSD control, 17 HP motor, 106" x 53" ( 2,620 mm X 1,350 mm ) abrasive belt size. (Inverter controlled) Equipped with & Features: · HESSEMANN's patented "CSD" magnetic pressure adjustment system, sensors spaced every 5/8" (16 mm) sense part configuration; (2) mm part thickness variation can be sanded without sand through’s, pressure for each segment can be pre-programmed to provide less pressure on the outer edges or more in the center if required. · The "CSD" computer control will hold approx. (20) programs or part configurations. · Additional features: Outfeed rotary panel cleaning brush with single end adjustment, 2 HP motor, air blast abrasive belt cleaners on all heads. · Variable feed speed from 13 to 82 FPM via Stober drive, 6.5 HP feed drive, motorized thickness opening 1/4" to 3-5/32" maximum. · Belt condition at 80% good.

Holytek 37DA Wide Belt Sander (2) Heads37" Width cap Drum, Combination Head1st Head: 7" Dia. spiral grooved rubber covered contact roller, 20 HP motor;2nd Head: Combination sanding head with 5" dia. spiral grooved rubber covered contact roll & 2" wide polishing platen, 15 HP motor.Specifications -- Abrasive belt size of 37" x 60" -- Pneumatic belt tensioning and electronic abrasive belt tracking -- 12" min. working length. -- 2 HP Conveyor belt motor, -- Variable feed speed from 13 - 52 FPM,Equipped with & Features -- Infeed & outfeed rubber covered holddown rolls; -- 0" - 4" motorized thickness adjustment by 0.5 HP motor. -- Safety stop bar, emergency rail stop across the front of conveyor -- Motor load meters.

HOLYTEK MHB 242 Top/Bottom Wide Belt SanderHeavy-duty and powerful double surface sander providing significant time saving and improved productivity.Smooth and quiet oscillation. Belts oscillation controlled electronically by an infrared system which resists dust.Pneumatic sanding belts tensioning ensuring fast and easy belt replacement.Independent motor for each sanding belt.Pneumatic disc brake system automatically activated if power supply is interrupted, thus preserving the sanding belts from being damaged. Top and bottom 24" wide belt sanderFeatures: -- Spiral grooved 8" (D) rollers (R) and 3-1/2" (D) rollers (K) keep the sanding belts cool. -- Sanding belts: 75" Long. -- Elevation of table with digital readout and activated by independent motor. -- Control panel with: Ammeters indicating main motors current. Specifications: -- Upper Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Upper Combination head motor: 10 HP; 600 V; 60 Hz - 3-Ph. -- Lower Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Lower Combination head motor: 10 HP, 600 V, 60 Hz - 3-Ph. -- Feeding motors: 2 HP (x2). -- Table elevation motor: 0.5 HP. -- Electrical intensity: 53 A. -- Drums: 8" (D) - 75 DUROS. -- Max. working width: 24". -- Min. working length: 13-3/4". -- Working thickness: 3/16" ~ 5" -- Sanding belts dimensions: 25" x 75". -- Variable feeding speed: 8 - 16 MPM. -- Dust hoods Top: 4 x 4"(D); Bottom: 3 x 4"(D). -- OAL 127" x 70" x 75" high. -- Weight: 9,460 Lbs.

HOLYTEK - KL-36PC, ...2-Head Sander 2-Head Planer Sander 36" with planer head & combination head.Description: -- Planing Head (P): 6'' Dia. made of steel with spiral design for heavy stock removal. 228 TCT Tips: 15 x 15 x 2.5 mm; each disposed on (6) rows. Each knife has: (4) Usable cutting edges; easy access to planing head for tips rotation or replacement. -- Precise dial indicator showing the exact positioning of the sanding pad; quiet & smooth oscillation! Pneumatic oscillation system controlled electronically by an infrared system, which is not affected by dust. -- Combination Head: (1) Drum & (1) sanding pad (C) for superior quality of finishing. Sanding belt with: 120 or 150 Grit; allows finishing sanding in a single pass. -- Elevation Table: (4) Screws. -- Infeed roller table extension: 15-3/4". -- Outfeed roller table: 15-3/4" with (2) Rollers. -- Centralized Control Panel with: Electronic digital readout (Metric or Imperial) for elevation; precise positioning at the elevation requested. -- Ammeter indicating: Electrical intensity on the spiral cutterhead and the combination head motors. -- Electrical box with: CSA Approved electrical components ensuring maximum dependability and an outstanding long-lasting performance.Specifications -- Spiral cutterhead motor: 20 HP - 600 V; 60 Hz - 3 Ph. -- Combination head motor: 15 HP - 600 V; 60 Hz - 3 Ph. -- Table elevation motor: 1/4 HP - 600 V; 60 Hz - 3 Ph. -- Feed motor: 2 HP - 600 V; 60 Hz - 3 Ph. -- Spiral cutterhead dia.: 6''. -- TCT Tips dim.: 15 x 15 x 2 mm (228); (6) rows. -- Max. working width: 36". -- Min. working length: 12". -- Max. working thickness: 5". -- Sanding belt dim.: 37" x 75". -- Dust hoods dia.: 4'' x 2 & 5" x 2. -- Machine dim.: 71" L x 76" W x 77'' H. -- Net weight: 1,450 kG or 3,190 Lbs.
