Trim Saws For Sale

14ft Double edge trimmer, Hyd controls Great Condition With New Paint job.

Newman Whitney KNO 24 trimmer, S/N 24120897, will pass a 5 1/2" cant, (9) station w/ individual motors, built-in wood waste block conveyor, used on dry line, good condition (ref# 200). We have another one of these that was just taken out of a sawmill in Iowa if that is closer to you.

5-Head Newman KM-16 Multiple Trimmer built for high-speed, precision lumber trimming. This machine features multiple saw units and 2 belt conveyors. Floor Space: 22' x 6'9" (6.71 m x 2.03 m), working height 36" (0.91 m), overall height 5' (1.52 m). Key Features: •Heavy-duty welded steel construction for long-term durability. •Overhead adjustable saw units for accurate cutting. •Integrated conveyors for material handling and scrap removal. •Ideal for large-scale production environments. Condition: •Age: 10+ Years •Usage: Regular production use. •Maintenance: Well maintained. •Electrical needs to be connected for operation. Specifications: Frame: Welded heavy duty 6" (152 mm) channel and angle iron construction. Pieces are accurately fitted, making an exceptionally rigid frame. Saw Units: •Overhead saw units with v-belt drive. •7-1/2 HP (5.6 kw), 1800 RPM, 3/60/230-460 arbor motor. •Ball bearing mounted arbors rotate at 3000 RPM. •Cut increments set by hand cranks and secured by individual friction locks. •Self-adjusting hold downs and lock-up heads are provided for each saw unit. Feed System: •Motors •1-1/2 HP (1.1kw) gearmotor with variable frequency drive. •Feed Speed: Variable 20 TO 60 CPM. •Feed Chain: #60 roller chain complete with four drags per chain, 2-1/4” (57 mm) high, spaced at 27” (686 mm) intervals. Each furnished with two chains. Capacity: ? Maximum thickness: 4" (102 mm). ? Minimum length: 18" (457mm) standard. ? Maximum length: 16' (406 mm) standard. ? Accuracy of 1/32" (0.7 mm) or better can be maintained. Saw Blades: •18" (457 mm) diameter, 1-1/4" (32 mm) bore, 5° negative hook, .050" (1.3 mm) side clearance. Conveyors: •Scrap conveyor: 12" (305 mm) wide. •Lumber conveyor: 12" (305mm) wide. •Motors: 1-1/2 HP (1.1 kw) gearmotors with variable frequency drives. •Belt Direction: To customer's specifications. Weight: •Approximately 7,000 lbs. (3200 kg) Floor Space: •22' x 6'9" (6.71 m x 2.03 m), working height 36" (0.91 m), overall heigh

Left Hand Double End Trim Saw

This 4 saw 16' x 6" multi saw trimmer will easily cut boards and cants in a multi cut product or simply double end trim. Fixed saw precision end cuts the lumber and 3 movable saws are easily adjusted with a slide and lock motion. Independent saw motors with 5.5 KW or about 7.5 hp motors. Quality and Performance in every cut simple handling, operation and maintenance. Call Kittrell 931-797-6284

In Stock. Brand new AKKUSLAR Model CBK 600 multi cut & double end trimmer w/ controls mounted on machine. 5 Saw with 4 easy slide and lock movable saws 7.5 HP each motor. Electric Feed Through sharp chains.. Price and performance will amaze you with this 50 year manufactureer of sawmill machinery. Simple handling and operation easy access for maintenance This machine includes a set of 5 saws at no additional charge also a 45’ X 16" wide X 7" Deep 14" - 16" as it is a split level overall belt conveyor to adapt to the trimmer as you please (throwing it in for free) Call Kittrell Sawmill Brokers for more information (931) 797-6284

Blanchard Industries 16' Dbl End Trim Saw Controls on the Left

Brewer Golden Eagle Double End Trim Saw

COOPER Dropsaw Trimmer - 24' left hand trimmer. Cuts up to 8" thick and 24 feet long. 15 hp saw motors. Zero saw adjustable for desired overtrim. Saws every 2 feet from 6 to 24 feet. 11 lugged feed chains with even-ender. Hydraulic variable speed feed. Controls and console remain wired. Over dimensional for transporting 32' long x 11.5' wide x 10'3" tall.

Corley Double End Trim Saw S/N RB-09-MM w/Waste Belt & Controls

Corley double end trim saw, 8" thick capacity, electric drive, good working condition

Cornell Dbl End Trim S/N STBD-335-5-93

1995 Cornell 915 LH Drop Saw Trimmer S/N 008-8-95 Out and Ready to Ship

Cornell Double End Trim Saw

Cornell 16' 3HD Trim Saw

Crosby 16' 8 Saw Upcut Trim Saw, Line Shaft Driven w/24" Saw Blades, Pneumatic Operated Saw Ladders, Drive & Controls S/N 3044W

MLS Number 10689968 Globe 5 Head Panel Trim Saw Approximate panel capacity: 8 feet wide X 26ft long Saw was cutting large full size sheets (8ft+ x 26ft) at a particle board manufacturer Lugs on chains have micro adjustment bolt ( brass) Air cylinders raise and drop heads Brands of chain: Woodward & White Overall width: 14 ft. 6inches Overall height: 6 ft. Overall length: 33 ft. 4 inches+-

Globe 5 head panel trim saw 5 powered adjustable heads, Lug chain feed air cylinders to raise or drop saw heads Approximate panel capacity: 8 feet WIDE X 26ft LONG Prior used of saw was cutting large full size sheets (8ft+ x 26ft+?) at a particle board manufacturer- directly after sheets came out of the press. Saw has been removed in one piece to reduce reinstallation time & cost- contact us for a delivered price to your location. Stored inside our warehouse Lugs on chains have micro adjustment bolt ( brass) Brands of chain: Woodward & White Contact us for additional details, photos and measurements Approximate shipping information: Overall width: 14 ft. 6inches Overall height: 6 ft. Overall length: 33 ft. 4 inches+- Price includes loading. contact us for a delivered price to your location.

New April 2024 barely used Go Fast MET-20 multi-end trim saw 44 FLA, 10 HP blade motors, 1 1/2 HP feed through motor VFD, includes 12" waste conveyor & 1/2 HP material take away, belt conveyor 12", 20" carbide tip saws - 2060 chain, material spec 12' long x 12" wide x 4 1/2" thick, mounted motor controls, Ref #204, Contact Jackie Kittrell 931-698-3342 Seller will load on your truck

The Go Fast TS10 Trim Saw is a heavy duty and compact machine, perfect for trimming boards to size. The easy to use moveable length stops are quick to adjust and allow for multiple, simultaneous board sizes. SIMPLE, SAFE AND STURDY: The easy stop system makes it SIMPLE for the operator to cut boards to length. The operator can SAFELY cut boards without ever having to stand on the blade side of the machine or have their hands near rotating shafts and sprockets. STURDY is one thing Go Fast had in mind when making the TS10 Trimmers. Weighing approximately 1,600 LBS with 3X3 tubular framing, you can bet that these saws will be around for the long run!
