Equipment For Sale

BIESSE ROVER K 1532 CNC MACHINING CENTER (W/ATC & "C" AXIS): -- Specifications:"BRIDGE GANTRY" machine with a working field in "X" axis 126" (3,200 mm), "Y" axis 61" (1,560 mm), max. material thickness 6" (165 mm). -- Positioning speed:"X" Axis 279 FPM (85 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 65 FPM (20 MPM). -- Work Table:(8) "ATS" Panels supports with lifting rails for heavy pieces; (4) "ATS" vacuum pods with universal clamping systems on each panel support.BIESSE "Set Up Assist" & digital readouts for pod & rail placement.(2) Independent working areas with (8) pneumatic back stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM;"BL 30" Boring head with (20) "Quick Change" independent vertical spindles, (9) spindles in "X" axis & (11) spindles in "Y" axis;(8) Horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) "X" axis grooving saw with 120 mm dia. blade. -- Machining:(1) 17 HP (12.6 kW) electro-spindle router with HSK F63 adaptor, variable speed from 3,000 - 24,000 RPM.Motorized dust deflector shield & 6-position adjustable dust suction hood,(1) NC controlled "C" axis for 360° horizontal processing.(1) 16-position ATC tool plate mounted on board the "X" axis at the rear of the machine. -- Operator & Machine Control:PC Front End with Biesse "BH 660" + Biesse "bSolid" + Windows "7 WRT" operating system,15" Flat screen monitor, full standard keyboard & mouse, 1.44MB & CD ROM disk drives for data entry,RS 232 & USB ports, Ethernet connection, specific function controls & internet trouble shooting capabilities.Electronics are mounted in an air conditioning & dust free environment control cabinet. -- Biesse "bSolid" is a 2D/3D Cad/Cam software program that supports the performance of any machining operation thanks to vertical modules designed for specific manufacturing processes.Planning with "bSolid" takes just a few clicks & has endless possibilities; "Real-Time" simulation allows the operator to visualize the piece prior to processing, it provides virtual prototyping of the piece to avoid collisions & ensures optimal machine performance. -- Complete with:(1) 250 m³/Hr Vacuum pump; Hand-held "Remote Control" pendant for immediate operator control; LED bar with (5) colors that show the machine's status in "Real-Time".Safety fences, safety bumpers, safety photocells & safety mats; scrap conveyor; original documentation + user & maintenance manuals, wiring diagrams and operation of Numerical Control. -- Actual Model is BIESSE ROVER K 1532 G VS2

BIESSE SKIPPER 100 L CNC MACHINING CENTER (2-HEAD): -- Specifications:Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system. -- Workable part size:"X" axis is 118" (3,000 mm), "Y" axis is 39.4" (1,000 mm), max. part thickness of 2.4" (60 mm).Min. workable part size in "X" axis is 3.5" (90 mm), "Y" axis is 2.7" (70 mm), "Z" axis is .3" (8 mm). -- Worktable:Automatic LH infeed transfer conveyor with belts & rollers, Automatic RH outfeed transfer conveyor with belts & rollers; infeed/outfeed table is "robot ready". -- Positioning Speed:"X" Axis is 394 FPM (120 MPM), "Y" axis 295 FPM (MPM), "Z" axis is 98 FPM (30 MPM). -- Boring units: (1) Top mounted boring block, 4.2 HP (3 kW), 4,000 RPM; (29) vertical spindles, (17) spindles in "X" axis & (12) spindles in "Y" axis; -- (10) Horizontal spindles, (4+4) spindles in "X" axis & (1+1) horizontal spindles in "Y" axis; -- (1) "X" axis grooving saw with 2.2 HP (1.7 kW) motor - 5,000 RPM, 150 mm dia blade. -- (1) Bottom mounted boring block, 4.2 HP (3 kW), 4,000 RPM, (29) vertical spindles, (17) spindles in "X" axis & (12) spindles in "Y" axis; -- (10) Horizontal spindles, (4+4) spindles in "X" axis & (1+1) horizontal spindles in "Y" axis; -- (1) "X" axis grooving saw with 2.2 HP (1.7 kW) motor - 5,000 RPM, 150 mm dia blade. -- Machining:(1) Top mounted 4.8 HP (3.5 kW) electro spindle, 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick-tool" change, ERC-32 tool holders & RC-32 collets. -- (1) Bottom mounted 4.8 HP (3.5 kW) electro spindle, 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick-tool" change, ERC-32 tool holders & RC-32 collets. -- Operator Interface: PC Front-End with BIESSE "NC 1000" + Windows "Biesse Work" Operating System; 15" color monitor; international keyboard with soft-touch keypad & industrial mouse.RS-232 serial ports for possible down-loading from an office PC, USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with a built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Universal transformer for voltages from 200 - 600 volts, 50/60 Hz, 3-Phase; automatic lubrication system for guides & ways; sound enclosure and complete set of safety fences/devices; machine docs & manuals. -- Options include:"BiesseWORKS Advanced" Office version with: (2) Hardware keys; pneumatic part clamping with motorized infeed & outfeed transfer conveyors; Software Disclaimer: EX-FACTORY INC. Offers NO warranty or support, written or implied concerning any/all "optional" or "additional" manufacturer or 3rd party software supplied with this machine. All software related issues including relicensing fees/requirements/functionality & training is ultimately the sole responsibility of the "Buyer".Note : Tear down and loading not included

BIESSE ROVER C 6.65 CONF 3 CNC MACHINING CENTER (5-AXIS PROCESSING): -- Specifications: Working Capacity: "X" Axis 253" (6,450 mm); "Y" axis 60.4" (1,535 mm); "Z" axis stroke 25-1/2" (650 mm); max. material thickness 10.8" (275 mm). -- Positioning Speed:"X" & "Y" Axes 328 FPM (100 MPM) each; "Z" axis 98 FPM (30 MPM). -- Worktable:(10) EPS (Electronic Positioning System) Panel supports with: (8) Lifting bars; (4) ATS vacuum pods with universal clamping systems per panel support.(2) Independent working areas with: (10) Pneumatic back stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) Motor with variable speed from 1,500 - 7,500 RPM; (5) independent vertical spindles in "Y" axis.(4) Horizontal boring spindles with: (1 + 1) in "X" axis & (1 + 1) in "Y" axis. -- Machining:(1) 16 HP (12 kW) Liquid Cooled 5-AXIS electro spindle router with HSK F63 adaptor; variable speed from 3,000 - 24,000 RPM.(1) 33-Position ATC tool rack chain located at the back of the machine. -- Operator & Machine Control:PC Front-End with BIESSE "NC 1000" + "BiesseWORKS" + WINDOWS "XP" Operating System.15" Color CRT, full keyboard, mouse, 1.44 MB & CD ROM disk drives. RS 232 & USB ports.Ethernet connection, specific function controls, & and Internet trouble shooting capabilities.Air-conditioned control cabinet & dust free environment."BiesseWORKS" is a multitask Operating System with: Input/output modules, axes override, (4) axes interpolation, diagnostic graphics aid for programming, machine data & tool management. -- Complete with:(1) 250 m³/Hr Vacuum Pump; safety fences & mats; scrap conveyor; CE mark; original documentation; user & maintenance manuals, wiring diagrams & operation of Numerical Control. -- Actual Model is BIESSE - ROVER C 6.65 CONF 3.

BIESSE - ROVER K 1532: CNC Machining Center (ATC & Boring) -- Specifications:"BRIDGE GANTRY" Machine with: Working field in "X" axis 126" (3,200 mm); "Y" axis 61" (1,560 mm); max. material thickness 6" (165 mm). -- Positioning Speed:"X" Axis 279 FPM (85 MPM); "Y" Axis 196 FPM (60 MPM);"Z" axis 65 FPM (20 MPM). -- Worktable(6) "ATS" Panels supports with: (4) Lifting rails for heavy pieces; (4) "ATS" vacuum pods with universal clamping systems on each panel support.BIESSE "Set Up Assist" & digital readouts for pod & rail placement.(2) Independent working areas with: (6) Pneumatic back & center stops; (4) pneumatic side stops; (2) LH & (2) R. with (12) removable nylon clamping units for narrow pieces. -- Boring Unit:4 HP (3 kW) Motor with: Variable speed from: 2,800 - 6,000 RPM."BL 30" Boring head with: (20) "Quick Change" independent vertical spindles; (9) spindles in "X" axis; (11) spindles in "Y" axis.(8) Horizontal boring spindles with: (2 + 2) in "X"'; (2 + 2) in "Y" axis.(2) Grooving Saws: (1) In "X" axis; (1) in "Y" axis for max. 120 mm dia. blade. -- Machining(1) 17.7 HP (13.2 kW) Electrospindle router with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM.Motorized dust deflector shield with: 6-Position adjustable dust suction hood; blowing unit.NOTE: NC Controlled C-Axis for 360° horizontal processing is not installed but CAN BE ADDED. - Per spec sheet on Dropbox folder: "“Prearrangement for the assembly of a 360° operating unit (C axis). It includes all the harness for the electric cabinet. The slot is to be specified. It allows reducing machine downtime for the installation of this unit on an already delivered machine";. (1) 16-Position ATC tool plate mounted on board the "X" axis at the "X" axis carriage (rear of the machine base). -- Operator Interface:PC Front-End with: BIESSE "BH 660" + BIESSE "bSolid" + Windows "7 WRT" Operating System.21-1/2" Flat screen monitor; full standard keyboard & mouse; 8 GB RAM memory;128 SSD GB hard disk or superior; USB Ports for data entry. Dedicated graphics card; Ethernet connection to an office PC with specific function controls & internet trouble shooting capabilities.Electronics are mounted in an air conditioned & dust free environment control cabinet. -- BIESSE "bSolid" is a 2D/3D CAD/CAM software program that supports the performance of any machining operation thanks to vertical modules designed for specific manufacturing processes.Planning with "bSolid" takes just a few clicks & has endless possibilities; "Real-Time" simulation allows the Operator to visualize the piece prior to processing; it provides virtual prototyping of the piece to avoid collisions & ensures optimal machine performance. -- Complete with:(1) 100 cbm/Hr Vacuum Pump; handheld "Remote Control" pendant for immediate Operator control; LED bar with (5) colors that show the machine's status in "Real-Time".Centralized Automatic Lubrication System; Scrap Belt conveyor; Tool Per-setting device; Safety fences; s

BIESSE - ROVER 20: CNC Machining Center (w/ATC/Boring)Specifications: -- Working capacity: X-Axis: 2,885 mm (113.58"); Y-Axis: 898 mm (35.35") for boring; 950 mm (37.40") for routing; max. panel thickness: 65 mm (2.56"). -- Positioning speed: X-Axis: 75 MPM (246 FPM); Y-Axis: 45 MPM (147 FPM); Z-Axis: 15 MPM (49 FPM).Equipped with: -- Work area with (2) Working zones: (6) Manually positioned & pneumatically locked panel supports; each with: (2) 6"; x 6-1/4"; Vacuum pods; (6) backstops/clamps; left & right side stops; all pneumatic raised & lowered automatically by start/stop of machining cycle. -- High precision prismatic guides & ground helical rack on X-axis; hardened ground ball screws on Y- & Z-axes. -- Boring Unit: 1.7 kW (2.3 HP) - 5,135 RPM Motor; spindle speed: 4,000 RPM; (10) vertical independently operated spindles with: (6) In X-Axis & (4) in Y-axis; (6) horizontal spindles with: (2 + 2) In X-Axis & (1 + 1) in Y-axis; (1) grooving saw in X-axis with 120 mm (4.72") dia. blade & blade speed 5,200 RPM. -- Machining: HSD "ES 919A" 6.6 kW (8.9 HP) Air-cooled electrospindle with: ISO 30 Adapter; RH & LH rotation; spindle speeds: 1,000 - 24,000 RPM; 4-position side-mounted automatic tool changer magazine; 3-position rear-mounted on-the-fly automatic tool changer (ATC). -- Control: PC Front-End with: 15" Color display; pendant control; (2) foot pedal controls.Complete with: -- BECKER "PICCHIO 2200" Vacuum Pump: 3 kW - 4 HP - 130 mbar.Control Dimensions: 60" x 36" x 77" H.Vacuum Pump Dimensions: 28 x 14 x 24 H.

--This machine is in an Auction on exfactoryauctions.com--NO RESERVE-- (2 Available) BIESSE SKIPPER 100 2-Head CNC Machining Center, with Infeed & Outfeed Tables – Seller states that machine was run (2) shifts from 2005 - 2021, then only a few hours per day since! Specifications: Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system. Working Capacity: "X" Axis 3,000 mm (118.11"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31"). Work Table: Left-hand infeed & Right-hand outfeed, Each with 20-1/2” x 66” x 35-1/2” H infeed & outfeed areas with Fixed caster-type conveyor rails. Positioning Speed: "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM). Boring Units: (1) Top & (1) Bottom boring blocks, Each with: 3 kW (4 HP) Motor, Boring spindle speed 4,000 RPM, (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 3 kW (4 HP) Motor, Blade speed 5,000 RPM, & Blade diameter 150 mm (5.91"). Machining: (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets. Operator & Machine Control: Mobile Control Console, with PC-Based Control, 18" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. Pedestal & Pendant controls. Equipped with: Universal transformer, 200 - 600 V, 50/60 Cy, 3-Ph., Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & TAPESWITCH "CONTROLMAT CKP" 24" x 72" Heavy-duty ribbed pressure-sensitive safety mat. Complete with: 7’ x 9’ x 35-1/2” H Infeed Table, with Rails & Pusher. 6-1/2’ x 8’ x 35-1/2” H Outfeed Table, with Transfer Belts. Handheld Bar Code Reader. Dust Manifold. Dimensions including Safety Fence: 307" x 184" x 98" H.

Biesse Rover B Edge semi automatic pod setting 4 coil magazine vertical and horizontal drill bank main spindle with U axis Milling X1: 5055 mm Y1: 1600 mm Edgebanding X2: 4100 mm Y2: 1600 mm Milling Module H74 - Z1: 245 mm Module H29 - Z2: 290 mm

Biesse Elix B Boring Machine

2007 Biesse Rover B 7.40 R FTK - 61.22" (routing) - 75" (drilling) - Working field of machine in Z-axis - 5.9" X-axis stroke - 157.87" Y- axis stroke - 77.16" Z-axis stroke - 6.23" 61.22" x 145"

Big Jack Scragg Mill

The listing is for all equipment at a closed sawmill. Everything is ready to be moved ASAP. - Timberline big Jake scragg - 48” front saws - 36” back saws all inserted tooth blades. - 10’ capacity - 60ft infeed with step loader for mill - Crosby edger 6x36 - Dead indeed live outfeed - Numerous belts conveyors. - Home made 3 blade flat edger power infeed and outfeed. - 50 ft barn sweep. - The different log decks one with stop and load. - Several descramblers. - Bandit whole tree chipper needs motor. Has 800 hours on it was wrecked and only damaged motor and cab a little. - 410 printice loader with self propelled carrier. New motor. A lot of misc electric motors, belts and other parts.

Big on Dry Thermal Modification Kiln Optional Single or Double Units available! The photos on this listing show the latest kiln installed in the US. The wood treated was 12" wide pine at 190 degrees C. Contact CMS for more details! - Gas boiler system (optional oil or electric) - Quick, efficient installation provided by technicians! - Complete package includes shipping, installation and all drawings fro site preparation. - Approx 10,000-12,000 board foot capacity (depending on lumber size and bundle stacking) on the Double Kiln. - Customer support via internet connection.

Carolina Machinery Sales (CMS) is proud to offer Thermo-Modification Technology from the Italian manufacturer Big on Dry. ????Big on Dry has improved the Thermo-Modification process with their THERMOWOOD (THW) line and provides complete "turn key" systems. The PLC control systems allow programming for a wide variety off wood applications. This allows the same systems to work with very delicate wood that is hard to treat to thicker wood that will be used for outdoor products. The THW system can also be used as a conventional kiln with steam. Basic systems include: - Kiln completely built with stainless steel and aluminum - Initial humidy of 10-15% is reduced to 5-6% - Loading options: Side or Trolley - Heating options: Gas or Wood Burner - Humidification: Combined Spraying System - Controls: Fully Automatic Controls with PLC - Interface & Software: Allows communication with Big on Dry technicians to provide online support - Complete installation and training in the USA Contact CMS to get a quote for your Thermal Modification system

Big on Dry (BOD) manufactures conventional dry kilns in Italy. They customer manufacture every unit and provide, installation, training and customer support. Conventional drying kilns installations are for sawn wood, hardwood and softwood, with capacities ranging from 15 m3 to over 250 m3, fully aluminium or customized to existing structures, made of standard modules or provided as per specific customer requirements. BIGonDRY srl kilns may be powered by any source of energy: hot water, steam or diathermic oil supplied by conventional or solid fuel boilers as well as hot air generated by gas, diesel or electric heating systems. Contact CMS for more information on BOD kilns!

BINKS - COMET 3, ...Paint PumpMounted on a roll-around cart.

BOILER UNICONFORT MODEL CMT-50 | Wood Chip/Saw Dust | Never Used

BISHAMON EZ LOADER Rotating Scissor LiftSelf-Leveling capacity range of 250 - 3,500 Lbs. Max. load capacity is 4,000 Lbs. Collapsed capacity range. -- 10-1/2" Lowered height, 21-1/4" travel, 30" raised height. -- 43" Dia. rotating circular platform. -- Secured ball bearing center pivot on rotator ring along; entrapped rollers in base for smooth even rotation. -- FIRESTONE Air stroke actuator to automatically decrease platform height according to the weight on it. -- No mechanical springs; captivated air to pressurize the air stroke actuator; bleed valve for capacity adjustments. -- Easy to move by forklift without the need for forklift pockets, weight 500 Lbs.

BISHAMON LX-100W Scissor Lift 2,200 Lbs load capacity. -- 34-1/2" x 51" Platform. -- 3.3" Lowered height. -- 35.3" travel to raised height of 38.6". -- Electro-hydraulic. -- 1 HP TENV Motor. -- 16-Second upward travel time when loaded. -- 12-Second downward travel time. -- Hand control with 8' long cord. -- Options: Foot switch. long loading ramp. Please ask for pricing.

BISHAMON LX-200WM Scissor Lift 4,400 Lbs. load capacity. -- 45-1/2" x 61-1/2" Platform. -- 4.3" Lowered height. -- 35.1" travel to raised height of 39.4". -- 34-Second upward travel time when loaded. -- 26-Second downward travel time. -- Electro-hydraulic. -- 1 HP TENV Motor. -- Hand control with 8' long cord. -- Options: Foot switch and long loading ramp. Please ask for pricing.

BISHAMON L2K-2848 Scissor Lift Unparalleled price for a 2,000 Lbs. cap. lift w/ a 24" x 48" smooth top. -- Complies with ANSI standards for lift tables. -- Heavy duty NEMA 12 hand control is rated for 120 volt, 25 amp operation. -- New heavy duty unitized power unit operates on a standard household 115 volt outlet. -- New power unit eliminates previous duty cycle restrictions and operates at low hydraulic pressure (1,500 PSI). -- New 3" bore cylinder provides smooth gravity down operation. -- Cylinder flow limiting valves protects the operator in the event of a hydraulic line failure. -- See through reservoir for easy fluid level identification. -- Hinged maintenance catches painted safety yellow. -- Entrapped scissor rollers for increased stability. -- Dual powder coated finish.
