sawmill Equipment For Sale

Altistart 46 soft start w/no disconnect

Square D Mod 6 Motor Control Center Bus Rating 600AMP Horz & 600AMP Vertical

SQUARE D - 75T3H, ...75 KVA, 480 - 208 V, 3-Phase Autotransformer Specifications: -- Intended for power, heating, and lighting applications. -- Enclosure Rating: NEMA 2. -- Multi-Tap (432 - 504 V) Primary 480 V (Delta); Secondary 208Y / 120 V @ 60 Hz ventilated. -- Aluminum windings. -- cULus Listed. (2) Available; price per unit. - Make offer for both!

2000 Staiger V29 Slow Speed Grinder Hog, 30HP Electric Motor S/N 200420

STAR V MACHINERY SCG-1600 AUTOMATIC CROSS GROOVER:: -- Specifications:(1) Spindle with 12 HP - 3,600 RPM motor, 60" max. crosscut cap., material thickness 0.25" - 1.125". (1) Internal 60" Stroke Tape Applicator Station. -- 96" Stroke Servo Motor Driven Rear Pusher Fence (Full 60" Rear Table Width), 96" Long x 20" Front Table with 5 Digital Manual Stops. -- Rear Fence Movement, Cutter forward Speed Cut/Tape Stroke and All Controls for Start/Stop, On/Off, Axis position Displays on 10" Touch Screen Panel HMI. -- Grooving Head up & down movement via pneumatic cylinder with linear rail & linear bearings, depth fine adjustment with special threaded adjustable unit. -- Carriage cross-travel powered by a 3 HP hydraulic motor (4GPM), driven ball screw with linear rail & linear bearings; feed rate from 0 - 40 FPM; Heavy Duty welded frame construction. -- Complete with:Safety guards and cutter guards; pneumatic support fence; (1) heavy-duty in-feed/out-feed roller tables. Available Options at additional cost:ACCESSORIES, TOOLING AND TAPE "CHOOSE AND ADD TO MACHINE BASE PRICE" Cove Corner Plug Jig $575.00 ea. Brazed Carbide 90 Degree Cutter for up to 1/2" Solid Surface $745.00 ea. Please specify the Material Brazed Carbide Cove Backsplash Cutter for 1/2" Solid Surface $1,265.00 ea. Please specify 3/8" or 1/2" Radius Brazed Carbide 90 Degree Cutter for up to 3/4" Wood Materials $940.00 ea. 90 Deg. Insert Cutter for up to 1/2" Thick Material (Body Only) $1,265.00 ea. Requires Below Inserts90 Degree V Insert for up to 1/2" Thick Material, $32.00 ea. Minimum of 12 Inserts Required $384.00 Carbide Insert Cove Backsplash Cutter Head for 1/2" Material (Body Only) $1,590.00 ea. Please specify 3/8 or 1/2 RadiusRequires Below Inserts 3/8" Cove Radius Insert for 1/2" Thick Material $42.00 ea. Minimum of 12 Inserts Required $504.00 3/8" Double 45 Degree Insert for 1/2"Thick Material $42.00 ea. Minimum of 12 Inserts Required $504.00PCD Diamond 90 Degree Cutter for up to 1/2" Thick Material $3,485.00 ea. PCD Diamond Cove Cutter with 1/2" Radius for 1/2" Thick Material $5,645.00 ea. Roll of VAC2MG, 2" (50mm) wide 1025y (937m) long Roll V Groove Tape $245.00 ea. Minimum of 3 Rolls per order = $735.00 -- Actual Model is STAR V MACHINERY SCG-1600 AUTOMATIC CROSS GROOVER:

STAR V MACHINERY SLG-2000 36 LINEAR V-GROOVER: -- Specifications:Working table dimensions are 120" long x 36" wide; Working width from 6" - infinite" (152 - infinite mm); Working length from 20" - infinite (508 - infinite mm); Working thickness from 0.25" - 1.15" (6 - 29 mm).Maximum throat clearance for linear & cross-cuts is 14.5"/24.5" (355/622 mm). -- Equipped with: (2) Independent, 10 HP - 3,600 RPM Saw Motors with "servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. Arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple-fold profiles, or using it for hogging and finish cut; 9.25" (235 mm) max. Cutter-head dia.1-Saw motor is mounted on the front & 1-Saw motor is mounted on the back of the 8" x 12" x 1/2" heat-treated steel heavy-duty overhead support beam.Side-to-side head travels via linear rails & bearings, manual head height adjustment via linear rails & bearings. -- Feeding System:(1) 3 HP Variable speed drive belt system with "servo" height adjustment; Feed rate from 0 - 45 FPM (12 MPM), belt feeder moves workpiece on a precision "aluminum" roller table; -- Tape Applicator: (2) Automatic Tape Applicators with "servo" adjustment, according to the Saw motor position in "Y" axis. -- Operator Interface:10" HDMI Touch Screen Display for Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:; Safety guards and Cutter guards. Anti-Kick-back Device. Emergency Shutoff line. Dust collection requirements 4,200 CFM, collector outlets on cutter guards 5" in dia.. -- Actual model# is STAR V MACHINERY SLG-2000.

STEEL FAB 400 Gallon Vertical Air Receiving TankSpecifications: -- Tank size 36" Dia. x 6' H.

STEFF VARIO4 Power Feeder(4) 4-23/32" Dia. and 2-3/8" wide rubber feed rollers with 60-shore hardness. -- 1 HP motor with foward-and-reverse. -- (Variable Speed) Feed speeds of 9 - 60 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit for high speed, different roller shore hardness and steel toothed rollers; please ask for prices. -- With (35) years of producing Power Feeders, STEFF has a huge market in the USA.

STEFF VARIO3 Power Feeder(3) 4-23/32" Dia. and 2-3/8" wide rubber feed rollers with 60-shore hardness. -- 1 HP motor with foward-and-reverse. -- (Variable Speed) Feed speeds of 9 - 60 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit for high speed, different roller shore hardness and steel toothed rollers; please ask for prices. -- With (35) years of producing Power Feeders, STEFF has a huge market in the USA.

STEFF 2068/3 Power Feeder(6) 4-3/4" Dia. and 2-1/4" wide rubber feed rollers with 60-shore hardness. -- 2-Speed - 1 HP motor with foward-and-reverse. -- (8) Feed speeds of 6 - 13 - 26 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2034/1 Power Feeder (3) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- (2) Speeds are obtained by changing the position of the gears inside the housing while the other (2) aspeeds result from switching of the bipolar motor. -- 0.75 HP Motor with forward-and-reverse. -- (4) Feed speeds of 13 - 26 - 36 & 72 FPM. -- Feeder head movement in any position up throughout full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast iron parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2034/3 (3) 4-3/4" Dia. and 2-1/8"wide rubber feed rollers with 60-shore hardness. -- 2-Speeds are obtained by changing the position of the gears inside the housing while the other 2-speeds result from switching of the bipolar motor. -- 1 HP motor with forward-and-reverse. -- (4) Feed speeds of 13 - 26 - 36 & 72 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices. -- With (35) years of producing Power Feeders, STEFF has a huge market in the USA.Add $ 100 for 230 V, single phase option

STEFF 2038/1 Power Feeder (3) 4-3/4" Dia. and 2-3/8" rubber feed rollers with 60-shore hardness. -- 2-Speed - 0.75 HP motor with forward-and -reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2038/3 Power Feeder. -- (3) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to make it a "belt" feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2038CI/1 Power Feeder(3) Rollers with continuous belt. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

(3) Rollers with continuous belt. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6-13, 16-21, 36-42, 54-102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2044/1 Power Feeder(4) 4-3/4" Dia. and 2-1/4" wide rubber feed rollers with 60-shore hardness. -- 2-Speed - 0.75 HP motor with forward-and-reverse. -- (4) Feed speeds of 13 - 26 - 36 & 72 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2044-3 Power Feeder. -- (4) 4-3/4" Dia. and 2-1/4" wide rubber feed rollers with 60-shore hardness. -- 1 HP - 2-Speed motor with forward-and-reverse. -- (4) Speeds (motor & gear) of 13 - 26 - 36 & 72 FPM. -- Feeder head rotates to any position up to a full 180°range. -- 28" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column with locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2048/1 Power Feeder(4) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- 2-Speed - 0.75 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 and 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; ...please ask for prices.

STEFF 2048/3 Power Feeder (4) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 and 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; ...please ask for prices.Add $ 100 for 230 V single phase option
