sawmill Equipment For Sale

STAR V MACHINERY SLG-2000 48" LINEAR V-GROOVER: -- SpecificationsWorking table dimensions: 120" Long x 48" wide; working width: 6" - infinite" (152 mm - infinite); working length: 20" - infinite (508 mm - infinite); working thickness: 0.25" - 1.15" (6 - 29 mm).Max. throat clearance for linear & crosscuts: 14-1/2"/24-1/2" (355/622 mm). -- Equipped with: (2) Independent 10 HP - 3,600 RPM saw motors with: "Servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple fold profiles, or using it for hogging and finish cut; 9-1/4" (235 mm) max. cutterhead dia.(1) Saw motor mounted on the front & (1) Saw motor mounted on the back of the 8" x 12" x 1/2" heat treated steel Heavy-Duty overhead support beam.Side-to-side head travels via linear rails & bearings; manual head height adjustment via linear rails & bearings. -- Feeding System(1) 3 HP Variable speed drive belt system with: "Servo" height adjustment; feed rate: 0 - 45 FPM (12 MPM); belt feeder moves workpiece on a precision "aluminum" roller table. -- Tape Applicator (2) Automatic Tape Applicators with: "Servo" adjustment according to the Saw motor position in "Y" axis. -- Operator Interface10" HDMI Touchscreen display for: Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:Safety guards and cutter guards; Anti-Kickback Device; Emergency Shutoff line.Dust Collection requirements: 4,200 CFM; Collector outlets on cutter guards: 5" in dia. -- Actual model #: STAR V MACHINERY SLG-2000

STAR V MACHINERY SLW-4818 SLAT WALL GROOVING MACHINE: -- Specifications48" wide panel capacity, feed through style overhead milling Slatwall machine. The machine will produce 4' x 8' panels in portrait orientation or any orientation as long as the panel size does not exceed 4' x 4'.The panels are placed with side to be grooved, facing up, then pushed in between the fixed fence and a movable fence, until the panel is grabbed by the first rubberized feed roller, the panel is then transported between a number of pinch rollers and processed through 3 rows of high-speed spindle motors.As the T Slot cutting is processed each bank (6 in total) of 3 high speed spindle motors cut a T shaped groove appropriate to the size of tool installed in each spindle, blow the groove clean by use of high-speed air knives, and remove dust through a number of dust ports. Then pinch rollers push the sheet out of the machine roller bed.Panels as narrow as 6" wide can be fed through the machine although workpieces less than 3/8" thick must be 48" wide. Workpieces as short as 24" can also be fed through the machine safely.Minimum recommended workpiece width, 6": Maximum workpiece width, 48": Minimum recommended workpiece length, 24": Maximum workpiece length, UNLIMITED: Maximum workpiece height, 1.5". -- Features:5HP 1750RPM, 460V Feeder Drive Motor through 50:1 Gear Box. 5HP VFD Inverter to drive and control feed speed through machine, 0-50 linear feet per minute. Heavy Duty Welded Tubular Steel Frame Construction. Stainless Steel Roller Bed with Rollers 6" on Center. 10x Linatex Rubber coated Feed Pinch Rollers Driven by 5Hp Feed Motor and Drive. Fixed Guide Fence& Movable fence to aid feeding of sheets into machine. Safety Fence around both sides along the length of the machine, with 1 gate in each side, each with safety interlock. Safety photo eye in infeed and outfeed side of the machine. Gauge block for setting height of router arbors. -- Spindle Motors:18 x 3 kW (4 HP), 18,000 RPM, 230V, High Speed Spindle Motors. 100 HP VFD Inverter to drive and control rotational speed of all 18 spindle motors.Variable RPM of Spindle Motors through Potentiometer and RPM displayed on Control Panel. Individual Ammeter for each Spindle on Control Panel. 6 x banks with 3 x High Speed Spindle Motors per bank (18 Total Spindle Motors). All 6 Spindle Banks are adjustable on the Overhead Beams by Hand, and lock into Position via locking handles. Digital Read Out for horizontal position of each spindle bank. Spindle 1 on each bank is fixed horizontally, Spindles 2, and 3 adjust on each bank horizontally. All 3 spindles adjust individually vertically on each spindle bank via Hand wheel. Position of depth on Digital Read Out.All Spindle raised individually through pneumatic cylinder for changing tooling, or when not in use. Each Bank has a phenolic Hold Down Shoe.Spindle Centers adjust from 3" to 4" Centers; Rapid Center Adjust Switch, from 3" to 4" through Air Cylinders against positive s

STAR V MACHINERY SLW-6018 SLAT WALL GROOVING MACHINE: -- Specifications60" (5') Wide panel capacity, feed through style overhead milling Slatwall machine. The machine will produce 5' x 8' panels in portrait orientation or any orientation as long as the panel size does not exceed 5' x 5'.The panels are placed with side to be grooved, facing up, then pushed in between the fixed fence and a movable fence, until the panel is grabbed by the first rubberized feed roller, the panel is then transported between a number of pinch rollers and processed through 3 rows of high-speed spindle motors.As the T Slot cutting is processed each bank (6 in total) of 3 high speed spindle motors cut a T shaped groove appropriate to the size of tool installed in each spindle, blow the groove clean by use of high-speed air knives, and remove dust through a number of dust ports. Then pinch rollers push the sheet out of the machine roller bed.Panels as narrow as 6" wide can be fed through the machine although workpieces less than 3/8" thick must be 48" wide. Workpieces as short as 24" can also be fed through the machine safely.Minimum recommended workpiece width, 6": Maximum workpiece width, 48": Minimum recommended workpiece length, 24": Maximum workpiece length, UNLIMITED: Maximum workpiece height, 1.5". -- Features:5HP 1750RPM, 460V Feeder Drive Motor through 50:1 Gear Box. 5HP VFD Inverter to drive and control feed speed through machine, 0-50 linear feet per minute. Heavy Duty Welded Tubular Steel Frame Construction. Stainless Steel Roller Bed with Rollers 6" on Center. 10x Linatex Rubber coated Feed Pinch Rollers Driven by 5Hp Feed Motor and Drive. Fixed Guide Fence & Movable fence to aid feeding of sheets into machine. Safety Fence around both sides along the length of the machine, with 1 gate in each side, each with safety interlock. Safety photo eye in infeed and outfeed side of the machine. Gauge block for setting height of router arbors. -- Spindle Motors:18 x 3 kW (4 HP), 18,000 RPM, 230V, High Speed Spindle Motors. 100 HP VFD Inverter to drive and control rotational speed of all 18 spindle motors.Variable RPM of Spindle Motors through Potentiometer and RPM displayed on Control Panel. Individual Ammeter for each Spindle on Control Panel. 6x banks with 3x High Speed Spindle Motors per bank (18 Total Spindle Motors). All 6 Spindle Banks are adjustable on the Overhead Beams by Hand, and lock into Position via locking handles. Digital Read Out for horizontal position of each spindle bank. Spindle 1 on each bank is fixed horizontally, Spindles 2, and 3 adjust on each bank horizontally. All 3 spindles adjust individually vertically on each spindle bank via Hand wheel. Position of depth on Digital Read Out.All Spindle raised individually through pneumatic cylinder for changing tooling, or when not in use. Each Bank has a phenolic Hold Down Shoe.Spindle Centers adjust from 3" to 4" Centers; Rapid Center Adjust Switch, from 3" to 4" through Air Cylinders against positi

STEEL FAB 400 Gallon Vertical Air Receiving TankSpecifications: -- Tank size 36" Dia. x 6' H.

STEFF 2068/3 Power Feeder(6) 4-3/4" Dia. and 2-1/4" wide rubber feed rollers with 60-shore hardness. -- 2-Speed - 1 HP motor with foward-and-reverse. -- (8) Feed speeds of 6 - 13 - 26 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2034/1 Power Feeder (3) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- (2) Speeds are obtained by changing the position of the gears inside the housing while the other (2) aspeeds result from switching of the bipolar motor. -- 0.75 HP Motor with forward-and-reverse. -- (4) Feed speeds of 13 - 26 - 36 & 72 FPM. -- Feeder head movement in any position up throughout full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast iron parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2034/3 (3) 4-3/4" Dia. and 2-1/8"wide rubber feed rollers with 60-shore hardness. -- 2-Speeds are obtained by changing the position of the gears inside the housing while the other 2-speeds result from switching of the bipolar motor. -- 1 HP motor with forward-and-reverse. -- (4) Feed speeds of 13 - 26 - 36 & 72 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices. -- With (35) years of producing Power Feeders, STEFF has a huge market in the USA.Add $ 100 for 230 V, single phase option

STEFF 2038/1 Power Feeder (3) 4-3/4" Dia. and 2-3/8" rubber feed rollers with 60-shore hardness. -- 2-Speed - 0.75 HP motor with forward-and -reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2038/3 Power Feeder. -- (3) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to make it a "belt" feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2038CI/1 Power Feeder(3) Rollers with continuous belt. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 & 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

(3) Rollers with continuous belt. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6-13, 16-21, 36-42, 54-102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2044/1 Power Feeder(4) 4-3/4" Dia. and 2-1/4" wide rubber feed rollers with 60-shore hardness. -- 2-Speed - 0.75 HP motor with forward-and-reverse. -- (4) Feed speeds of 13 - 26 - 36 & 72 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2044-3 Power Feeder. -- (4) 4-3/4" Dia. and 2-1/4" wide rubber feed rollers with 60-shore hardness. -- 1 HP - 2-Speed motor with forward-and-reverse. -- (4) Speeds (motor & gear) of 13 - 26 - 36 & 72 FPM. -- Feeder head rotates to any position up to a full 180°range. -- 28" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column with locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; please ask for prices.

STEFF 2048/1 Power Feeder(4) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- 2-Speed - 0.75 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 and 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; ...please ask for prices.

STEFF 2048/3 Power Feeder (4) 4-3/4" Dia. and 2-1/4" rubber feed rollers with 60-shore hardness. -- 2-Speed - 1 HP motor with forward-and-reverse. -- (8) Feed speeds of 6 - 13 - 16 - 21 - 36 - 42 - 54 and 102 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit to belt feeder, different roller shore hardness and steel toothed rollers; ...please ask for prices.Add $ 100 for 230 V single phase option

STEFF VARIO4 Power Feeder(4) 4-23/32" Dia. and 2-3/8" wide rubber feed rollers with 60-shore hardness. -- 1 HP motor with foward-and-reverse. -- (Variable Speed) Feed speeds of 9 - 60 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit for high speed, different roller shore hardness and steel toothed rollers; please ask for prices. -- With (35) years of producing Power Feeders, STEFF has a huge market in the USA.

STEFF VARIO3 Power Feeder(3) 4-23/32" Dia. and 2-3/8" wide rubber feed rollers with 60-shore hardness. -- 1 HP motor with foward-and-reverse. -- (Variable Speed) Feed speeds of 9 - 60 FPM. -- Feeder head movement in any position up to a full 180° range. -- 20" Standard reach of head from base. -- Hardened steel drive gears. -- Electrostatic powder coated finish on all cast parts. -- Easy access external lubrication points for each roller shaft. -- Fully adjustable mounting column w/ locking joints. -- Options: Longer reach (34" & 38") from base to head; 2.5" or 3" wide feed rollers, conversion kit for high speed, different roller shore hardness and steel toothed rollers; please ask for prices. -- With (35) years of producing Power Feeders, STEFF has a huge market in the USA.

Stehle 5802 Profile Grinder

Stenner VHC Resaw Accepting offers

Stenner 36" Bandsaw, older unit but was running when pulled out of production.
