MIDWEST AUTOMATION GS 214 Top and Bottom Glue Spreader53" Cap., top & bottom opposed glue applicator rolls, max. 3" opening, 40" pass-line height, 7-3/4" dia. grooved rubber spreading rolls. -- Rolls fitted with Teflon end seals and water tight bearings, upper elevator opening by single hand wheel on left with dial indicator; dual hand wheel opening glue film thickness adjustment. -- Galvanized collection tank; 54 FPM feed speed, top & bottom direct drive, 1.5 HP direct drive motors. -- Complete with: (2) Protection safety guards at roller in- & outfeed with safety interlocks, complies with UL & CE safety standards.

Designed for curved casings, crowns, circles, ellipses and straight mouldings. -- Working dimensions: 6" wide x 7" thickness capacity. -- Spindle diameter 1-1/4" with cutterhead speed of 6,000 RPM. 6-1/2" max. cutting circle in horizontal position, 6" max. cutting circle tilted. -- Feed motor 7.5 HP variable speed 0 - 30 FPM. -- Tilting of spindle head 0° - 52°. -- Includes: Hand wheel for spindle height & tilt adjustment, mechanically adjustable fence for accurate and easy positioning. Axial adjustment. Floating work table 30" x 23". -- Linear tracking system guides the work piece smoothly and directly under the cutterhead, while keeping the workpiece flat. -- Includes (1) 4" dia. corrugated cutterhead. Operating video and manual, spare parts list and (1) year warranty. -- Additional options: Proscale digital readout for height and tilt setting .... add $900.00 for each.

Automatically feeds, shapes & ejects Rosette blocks in sizes from 2-1/2" - 5" max. square blocks; 1.5 HP motor belt drives 2-7/8" spindle cutterhead @ 7,500 RPM. -- Operation: Adjustable hopper feed to side of spindle automatically indexes Rosette blocks under cutterhead up against a corner-V holding fixture with overhead spring fingers, cutterhead advances and machines Rosette, then automatically ejects block to front (hydraulic position of block and air eject cylinder). -- Features: Cutterhead equipped for standard 16°/60° corrugated back 1/4" thick knives to be ground at 0° hook angle. -- Produces up to (500) Rosettes/Hr; Rosette profiles can be ground on any profile grinder for infinitely variable design possibilities; table top unit may include base.

Automatically feeds, shapes & ejects Rosette blocks in sizes from 5-1/2" - 8" max. square blocks; 3 HP motor belt drives 4-3/4" spindle cutterhead @ 7,500 RPM. -- Operation: Adjustable hopper feed to side of spindle automatically indexes Rosette blocks under cutterhead up against a corner-V holding fixture with overhead spring fingers, cutterhead advances and machines Rosette, then automatically ejects block to front (hydraulic position of block and air eject cylinder). -- Features: Cutterhead equipped for standard 16°/60° corrugated back 1/4" thick knives to be ground at 0° hook angle. -- Produces up to (500) Rosettes/Hr; Rosette profiles can be ground on any profile grinder for infinitely variable design possibilities; table top unit may include base.

Horizontal Tilting Multi-Moulder with Verical Router System designed for curved casings, crowns, circles, ellipses and straight mouldings. -- Equipped with: (1) 1-1/4" Diameter Spindle, 6" max. width x 7" max. thickness cap., 7.5 HP spindle motor, 6,000 RPM spindle with reverse rotation, 6-1/2" max. cutting circle horizontal, 6" max. cutting circle tilted, 0° - 52° horizontal tilting arbor, hand wheel spindle height & spindle tilt adjustment. -- Variable feed speed from 0 - 30 FPM, DC feed feed motor; hand wheel adjustable thickness opening, 34" x 30" table, independently adjustable feed rollers, and mechanically adjusted fence. -- 3.25 HP, 5-speed Porter Cable router with 1/2" shank included. This allows easy insert & Channels on both straight and curved mouldings. -- Designed to use standard 4" dia. 2-knife cutterhead for 16°/60° 1/4" corrugated back knives, (1) supplied; includes operating manual & video, parts list and covered by (1) year warranty. -- Optional: ProScale digital readouts for height and tilt settings, please add $900 for each, or for the Optional 8’’ spindle and aluminum Cutter-head, please add $3,550

Milwaukee 8" Panel Saw

MINNESOTA 24-8 Multi-Spindle Carving Machine.Specifications: -- Spindles/Capacity: (24) Spindles, 8" between centers & 72" length capacity. -- Motors: (12) 0.75 HP motors with (1) motor driving (2) spindles via flat belt. -- Features: Manual table elevation, motorized stock rotation, non-indexable head. -- Comes with: (2) Sets of carving tools (one medium and one fine). -- Includes: Tables for flat carving - to be confirmed (?).

MOAK - NO. 7, ...Spindle ShaperSpecifications: -- 1.5 HP motor, belt driven to spindle; 9,000 RPM spindle speed; 1" diameter spindle. -- Length of spindle above table is 5"; 3-1/4" vertical adjustment of spindle; 22" x 42" table; manual starter; 750 Lbs machine weight.

16” capacity 5 hp motor 220 volt 3-phase

Montgomery Blo-Hog, drop feed Steel Flywheel for surge loads Top infeed opening: 18 ¼ X 13 1/4” Bottom discharge Will be repainted Model: ER 18S315FHDL Serial # 1032 75 hp motor. 230/460V, frame: 405T, Support stand Extra parts Contact us for a delivered price

MORBIDELLI UNIFLEX HP 1.1 CNC MACHINING CENTER (2-HEAD): -- Specifications:Flexible "TOP & BOTTOM" Machining Center that uses an innovative panel handling system. -- Positioning SpeedsThe "UNIFLEX" can reach positioning speeds of: 130 MPM in "X" Axis; 80 MPM in "Y" axis; 50 MPM in "Z" axis with total safety, providing an unmatched working capacity. -- Working DimensionsMax. worktable part size for: "X" axis is 118" (3,000 mm); "Y" axis is 51" (1,300 mm) "Z" axis max. part thickness 3.1" (80 mm).Min. worktable part size for: "X" Axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness 0.157" (4 mm). -- Worktable:Automatic LH infeed air table with gripper clamps; automatic RH outfeed transfer conveyor with belts; both infeed & outfeed are considered Robot ready. -- Boring Units:(1) Top mounted boring block: 4.2 HP (3 kW); variable speed from 1,500 - 6,000 RPM; (48) vertical spindles: 24-Spindles in "X axis & 24-spindles in "Y" axis; (6) horizontal spindles with: (2+2) in "X" axis & (1+1) in "Y" axis; (1) 4.2 HP (3 kW) - 9,000 RPM, NC controlled 0°-90° "X/Y" Grooving Saw, max. 120 mm dia. blade.(1) Bottom mounted boring block: 4.2 HP (3 kW); variable speed from 1,500 - 6,000 RPM; (48) vertical spindles: 24-Spindles in "X axis & 24-spindles in "Y" axis; (6) horizontal spindles with: (2 + 2) in "X" axis & (1 + 1) in "Y" axis; (1) 4.2 HP (3 kW) - 9,000 RPM, NC controlled 0°-90° "X/Y" Grooving Saw, max. 120 mm dia. blade. -- Machining:(1) Top mounted 10 HP (7.5 kW) electro-spindle with: HSK D-50 Adaptor; "ERC 32" tool holders & RC-32 collets, 1,500 - 24,000 RPM.(1) Bottom mounted 10 HP (7.5 kW) electro-spindle HSK D-50 adaptors, "ERC 32" tool holders & RC-32 collets; 1,500 - 24,000 RPM. -- Operator Interface:PC Front-End with: "XYLOG PLUS" + Windows environment Operating system; 20 GB hard drive; 17" TFT monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 Serial ports, USB ports; (1) 1.44 MB floppy drive; (1) CD ROM drive; all mounted in separate control console. -- Operating System:"XYLOG PLUS" Offers Real time multitask processing; programs can be transferred via diskette or downloaded by wire. -- Complete with: Pneumatic part clamping devices; sound enclosure; safety mats. -- Operating features: Machine can work the panel from above & below at the same time and can produce (2) identical or mirrored panels per cycle with no difficulty.The "UNIFLEX" can machine porous materials since the pieces are held with grippers, directly managed by the numerical control; it can even process small pieces and carry out "through" machining.(4) Operating modes at each cycle, it can change automatically from: Top machining to bottom machining, to top & bottom machining together, either on (1 or 2) stacked panels. -- Actual model is MORBIDELLI UNIFLEX HP.

This machine was purchased new. The seller has changed contracts and no longer needs the system for their application. 2019 Morbidelli P200 5 X 12 Contour Edgebander Eye M Controller with 21.5? Touch Screen Hand Held Pendant w/ 7? Touch Screen Air Conditioned Cabinet 20.5 HP Liquid Cooled Router Tool Touch Probe 12 Position Ride Along Tool Changer 14 Position Side Tool Changer 17 Vertical Spindles 8 Horizontal Spindles / 3+3 in X and 2+2 in Y Hinge Unit Edgebanding Unit Standard two Coils Magazines on Safety Enclosure Additional Support for 6 Coils EVA or PUR Glue Aggregates for 3mm PVC Flexmatic Table with 8 Rails 8 Lifting Rails Variety of Vacuum Pods HE Pods Conveyor for Dust Busch Mink Vacuum Pump Pro Speed w/ Safety Enclosure

Morbidelli Planet P800 CNC Router

MORBIDELLI AUTHOR 504 R CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working Cap. "X" Axis 139-3/8" (3,540 mm); "Y" axis 48-3/8" (1,230 mm) for routing & 39.6" (1,008 mm) for boring; "Z" axis 3.1" (80 mm). -- Positioning Speed:"X" Axis 213 FPM; "Y" axis 131 FPM; "Z" axis is 65 FPM. -- Worktable:(8) Adjustable panel supports each with: (3) Vacuum pods; worktable setup for (2) independent working areas. -- Boring Unit:(29) Independent vertical boring spindles forming a T-configuration with: (15) Spindles on the "X" axis and (14) spindles on the "Y" axis.A total of (8) horizontal spindles with: (3 + 3) on "X" Axis; (1 + 1) on "Y" axis. -- Machining:(1) 9 HP (7 kW) Vertically mounted router; inverter driven (FUJI) at 12,000 - 18,000 RPM.(1) 8-Position ATC for Automatic Tool Changer. -- Operator & Machine Control:"NUM CN" Loaded onto a HP, PC Based Controller mounted in separate control cabinet.15" VGA Color monitor and ergonomic keypad. Remote Control Pendant: Allows the operator to move around and still control all the axis movements, speed, and emergency stop.Includes: USB Ports; (2) serial ports RS-232 & RS-242 (requires no 3rd party CAD system for downloading programs). XILOG-PLUS OPERATOR Interface: Offers incredible list of: Functions from (a) Auto. diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria; programs can be transferred via diskette or downloaded by wire. Equipped with: Onboard mini-CAD with built-in programming for writing circles, ellipses & angles with only a few keystrokes; on-board cycle optimization, on-board calculator, mirror imaging, and repeat imaging. -- Complete with:(1) 100 cbm/Hr Vacuum Pump. -- Actual model is: MORBIDELLI - Author 504 .

MORBIDELLI U 550 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Worktable area "X" axis 126" (3,200 mm); "Y" axis 51" (1,300 mm),;"Z" axis stroke 4.52" (115 mm); max. material thickness 3.1" (80 mm). -- Positioning Speed:"X" & "Y" Axes are192 FPM (58 MPM); "Z" axis 80 FPM (24 MPM). -- Worktable:(8) Adjustable panel supports with (3) vacuum pods per support.(8) Pneumatic backstops, (2) pneumatic side stops & (2) pneumatic center stops; (2) independent work zones. -- Boring Unit:(1) 4 HP (3 kW) - 4,000 RPM Motor; (29) independent vertical spindles at 32 mm centers with (14) vertical spindles in "X" axis & (15) vertical spindles in "Y" axis.(6) Horizontal spindles with (3 + 3) in the "X" axis. -- Machining:(2) 9 HP (6.7 kW) Routers with: ISO 30 Adaptors; variable speed from 12,000 - 18,000 RPM.(1) 5-Position tool racks mounted on the LH side of the machine base for ATC. -- Operator & Machine Control:Separate control cabinet with: "TRIA 7500" CNC 32-Bit multiprocessor (100% MS/DOS compatible), 512 KB user RAM.14" VGA Color monitor; ergonomic extended keypad with (18) function keys; 1.44 MB floppy disk drive & (2) RS 232 & (1) RS 242 serial ports. -- Complete with:(1) 100 cbm/Hr Vacuum Pump; working head safety enclosure; emergency stop rope. -- Actual Model is: MORBIDELLI - U 550.

MORBIDELLI U 550 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Worktable area: "X" Axis 126" (3,200 mm); "Y" axis 51" (1,300 mm); "Z" axis stroke 4.52" (115 mm); max. material thickness 3.1" (80 mm). -- Positioning Speed:"X" & "Y" Axis are 192 FPM (58 MPM); "Z" axis 80 FPM (24 MPM). -- Worktable:(8) Adjustable panel supports with (3) vacuum pods per support.(8) Pneumatic backstops; (2) pneumatic side stops & (2) pneumatic center stops; (2) independent work zones. -- Boring Unit:(1) 4 HP (3 kW) - 4,000 RPM Motor; (29) independent vertical spindles at 32 mm centers with: (14) Vertical spindles in "X" axis & (15) vertical spindles in "Y" axis.(6) Horizontal spindles with (3 + 3) in the "X" axis. -- Machining:(2) 9 HP (6.7 kW) Routers with: ISO 30 Adaptors; variable speed from 12,000 - 18,000 RPM.(1) 5-Position tool rack mounted on the LH side of the machine base for ATC. -- Operator & Machine Control:Separate control cabinet with: "TRIA 7500" CNC 32-Bit multiprocessor (100% MS/DOS compatible); 512 KB user RAM,14" VGA Color monitor; ergonomic extended keypad with (18) function keys; 1.44 MB floppy disk drive & (2) RS 232 & (1) RS 242 serial ports. -- Complete with:(1) 100 cbm/Hr Vacuum Pump; working head safety enclosure; emergency stop rope. -- Actual Model is: MORBIDELLI - U 550.

X5 Author cnc router 11KW/15HP 5 axis electrospindle router motor Spindle takes HSK63 tool holders 120” x 51.2” working area Max speed in X/Y/Z – 131/131-/74 FPM Remote pendant 18 spindle boring unit with 12 vertical (7+5) and six horizontal (2+2, 1+1) 12 position rear tool changer Centralized dust collection See less

MORBIDELLI N 100 15 FLAT TABLE MACHINE (W/ATC/BORING/RAKE): -- Specifications: 5' x 12' x 37" H High-efficiency laminate aluminum with Magnetic vacuum locking system.Grid pattern allows use of vacuum pods or closed cell rope gasket material & use of spoil boards for nested base machining, Part location pop-up pins mounted on table perimeter, Chips conveying device. -- Working Area: X-Axis 3,686 mm (145.12"), Y-Axis 1,555 mm (61.22"), Z- Axis 150 mm (5.91"). -- Travels:X-Axis 4,230 mm (166.54), Y-Axis 1,985 mm (78.15"), Z-Axis 250 mm (9.84"). -- Positioning Speeds: X- & Y- Axes 35 MPM (114 FPM), Moving Gantry, High precision rack & pinion system for X & Y Axes, Ground ball screws for Z-Axis, All axes ride on extra-large precision profile linear guide ways. -- Boring Unit: 2.2 kW (3 HP) Motor, (12) Independent vertical roto-axial spindles with (8) in X-Axis & (4) in Y-Axis, Maximum spindle speed 8,000 RPM. -- Machining: (1) 15 kW (21 HP) Air-cooled electro spindle with HSK F63 Adaptor, Variable spindle speeds to 24,000 RPM, (1) 14-Position TR side tool changer. -- Operator Interface:Mobile console with Integrated PC “EYE-M"; Industrial PC with 21-1/2" Full HD Multi-touch color touchscreen, WINDOWS Operating system, "MAESTRO SUITE" with Auto-diagnostic to Zooming, Controlled acceleration & deceleration, Encoder feedback, Dynamic tool correction via PLC due to active tool wear using space-and-time criteria, "TECPAD" Remote pendant with 7" Color touchscreen. -- Complete with: PRO-SPACE safety system which allows worktable access to all sides of the machine, (1) 300 m³/Hr. Vacuum pump, Automatic lube system, -- NOTE: Machine was de-installed by a technician and is currently in storage.

MORBIDELLI AUTHOR 503 FT CUSTOM CNC MACHINING CENTER (W/ATC): -- Specifications:4' x 8' Custom Stationary Extruded Aluminum Table for "Nested Base" manufacturing;Working cap. "X" axis is 125.2" (3,180 mm), "Y" axis is 41.3" (1,050 mm) for routing "Z" axis stroke is 5.7" (144 mm); max. material thickness is 3.1" (80 mm) -- Positioning speed:"X " & "Y" axis is 213 FPM. (65 MPM), "Z" axis is 82 FPM (25 MPM). -- Work Table: 4' x 8' Custom Stationary Extruded Aluminum Table for "Nested Base" manufacturing;(2) pneumatic side stops, (2) working areas -- Machining Units:(1) 10 HP (7.5 kW) Vertically mounted electro-spindle router with ISO-30 adapter, LH & RH rotation, inverter driven from 12,000 - 18,000 RPM,(1) 5-position ATC tool rack mounted on the LH side for automatic tool change, -- Operator & Machine Control:Separate control cabinet with Morbidelli "TRIA 7500" CNC Multi-processor, VGA monitor, ergonomic keypad, 3-1/2" disk drive, and (2) serial ports RS-232 & RS-242.Offers incredible list of functions from (a) auto-diagnostic to (z) zooming; -- Complete with: Voltage stabilizer 208. 230, 460 V, 60 Hz, 3 Phase Auto Transformer (1) 100 m³/Hr vacuum pump. -- Actual model is MORBIDELLI AUTHOR 503 FT CUSTOM

MORBIDELLI AUTHOR 636 FLAT TABLE MACHINE (W/ATC/RAKE): -- Specifications:5' x 12' Stationary extruded aluminum "MATRIX" table for "Nested Base" manufacturing. -- Work Area:"X" Axis 144" (3,660 mm); "Y" axis 57.8" (1,470 mm) for routing & 48" (1,230 mm) for boring; "Z" axis stroke 11" (280 mm); max. material thickness is 7" (180 mm). -- Positioning Speeds:"X" & "Y" Axes 262 FPM (80 MPM); "Z" axis 74 FPM (22.5 MPM).Closed loop AC Servo drive system with: Recirculating ground ball screw in the "X", "Y" & "Z" axis; all axes ride on precision prism linear guideways. -- Worktable:Aluminum grid "MATRIX" vacuum table machined with: Square grid pattern for fixturing parts;, grid pattern allows use of vacuum pods or closed cell rope gasket material and use of spoil boards.(2) Independent working areas; external pop-up reference ins located on the sides & back of the table for positioning parts. -- Boring Unit:3 HP (2.2 kW) - dual speed 4,500 & 6,000 RPM motor; (12) vertical spindles with: (7) spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with (2 + 2) in "X" axis & (1 + 1) in "Y" axis. -- Machining:(1) 15 HP (11 kW) "Power 2000" Electro-spindle w/lifetime lubrication and HSK F63 adaptor; spindle speeds from 900 - 18,000 RPM.(1) 12-position "Rapid-12" traveling ATC tool plate for "on the fly" ATC. -- Operator & Machine Control:PC Front End with: NUM 1040 + Xilog III + Windows Operating System.Includes: 12" High resolution CRT, ergonomic keypad, 1.44 MB & CD ROM disk drives, (2) serial ports RS-232 & RS-242. All housed in air-conditioned cabinet with a KELVIN air conditioner. -- Complete with:(2) 250 cbm BECKER "VTLF 250" Vacuum pump with: Emergency stop rope, handheld pendant control. -- Options Include:Nesting Rake: Off feed table to increase machine/operator output; (1) 208/230/460 Volt transformer. -- Actual model - MORBIDELLI AUTHOR 636 S.
