Description:

Description ( to be confirmed) PLANING WIDTH: 10 – 230 mm PLANING THICKNESS: 7 – 125 mm MIN. WORKING LENGTH: 230MM FEED MOTOR: 5HP WITH INVERTER FEED SYSTEM ELEVATION: 1/3HP SPINDLE DIAMETER: 40MM OR1 13/16 INCH SPINDLE RPM: 6000RPM FEED SPEED: 10-120 FPM SPINDLE DIA 40MM FRONT BTM SPINDLE: 100 – 150MM CUTTER DIAMETER RIGHT/LEFT VERTICAL SPINDLE: 100 – 195MM CUTTER DIAMETER TOP HORIZONTAL SPINDLES: 100 – 200MM CUTTER DIAMETER BOTTOM HORIZONTAL SPINDLES: 100 – 200MM CUTTER DIAMETER MOTOR HORSEPOWER: BTM HORIZONTAL SPINDLE: 10HP RIGHT/LEFT VERTICAL SPINDLE: 15HP TOP HORIZONTAL SPINDLE: 10HP TOP HORIZONTAL SPINDLE: 10HP BTM HORIZONTAL SPINDLE: 10HP FEED ROLL DIAMETER: 140MM FEED ROLL WIDTH: 2 X 50MM ADJUSTMENT OF VERTICAL SPINDLE: 30MM ADJUSTMENT OF HORIZONTAL SPINDLE: 40MM TABLE ADJUSTMENT: 12MM TABLE LENGTH: 1800MM MIN LENGTH OF CUT: 230MM
