Description:

Vance PT600R8 Drum Chipper See this machine at IWF Atlanta 2024! This Wood Drum chipper PT600 is used in production of wood chips from logs and veneer waste. It has a toothed roller system that allows efficient material infeed, a rubberized conveyor belt and a Hydropneumatic unit to lift the rotor cover for maintenance. It comes with 01 chipper Knife set and 01 nose bar set. It does not come with the output conveyor. - Width of inlet: 600 mm; - Height: 300 mm; - Rotor diameter: 800 mm; - Toothed roller: 01 upper and 01 lower; - Grooved rollers: 01; - Rollers gear motor: GD (helical gears); - Metal detector: Flat model; - Rollers motor size: 5 hp (2x); - Number of rotor knives: 02; - Wood chip size: 25 - 40 mm; - Main motor 125 hp 4P: Included; - Drive panel: Included; - Lead Time: 240 Days; - Estimated production: 55 m3 / h (it may vary according to the type of material and time used with blade sharpening); - Infeed conveyor length: 3 500 mm (included); - Width: 1 850 mm; - Height: 1 .150 mm; - Overall length: 6 700 mm; - Approximate weight: 4,900 kg.
