CAM-WOOD SFJ-300A End Matcher, 12" Performs tongue and groove, tenoning, mortising, and shaping at both ends of the boards; -- Includes 10'-6" Powered Infeed and 7' Non-Powered Outfeed Conveyors. -- Air-operated hold-downs keep material firmly in place during the machining process. -- Cutter heads move in and out while cutting a tongue on the trailing end of one part and a groove on the leading end of the following part.FEATURES: -- PLC controls combined with a touch-sensing screen for maximum convenience of operation. -- Each cutter head is driven by a separate motor driving the spindle at 7,500 RPM spindle speed. -- Accepts unlimited wood lengths via an automated conveyor for infeed and outfeed processing. -- Cutterheads feed thru the wood is controlled by a frequency inverter that permits speed changes to suit various cutting conditions. -- Pressure plates are actuated by air cylinders. -- Hard chrome-plated table features maximum wear resistance. -- Table rollers increase feed smoothness. -- Powered in feed roller conveyor is driven by a 1 HP motor. -- 3,400 mm in feed roller conveyor and 2,200 mm out feed conveyor table are standard equipment. -- Fully enclosed chip guards. -- Air-operated clamp holds stock firmly in place. After the workpiece is clamped, the cutter head moves in and performs the shaping operation. -- The spindle is precision constructed to cut accurately -- The spindle height adjustment is displayed on a dial gauge. -- CAM-WOOD’S 2-spindle design accommodates cutterhead dia. up to 6"; -- When end matching, one spindle cuts the tongue, and the second cutterhead machines the groove. SPECIFICATIONS: -- 1-1/2" To 12" width cap. -- 10-1/2"; min. length cap. -- Thickness 3/8" to 1 3/8" -- Unlimited length, no restriction. -- Material feed speeds up to 297 FPM; cutterhead travel speed of 79 FPM -- Cutting cycle time 1.5 second.and up to 20 cycle per minute -- (2) 5-1/2 HP Spindle motors and a 2 HP feed drive -- 1/2 HP motor for in/out cutterhead travel. -- 40 mm Dia. spindle -- Requires 1300 CFM dust collection.

CAM-WOOD 16' Pusher Type Cutoff Saw with Crayon Marking connected to a CAM-WOOD 12" wide End Matcher; System width capacity is 12" with a maximum inbound board length of 16' (as priced here). 8' and 12' Saws are also available. Call Jeff for price deduction.General Data: -- Cut-Off Saw is arranged to remove defects from Clear. Will chop for random length clear material OR optimize clear wood according to your cutlist, delivering either to the End Matcher. -- The line requires (1) man to mark and feed the Cutoff Saw and (1) man to offbear and stack finished work coming from the End Matcher. Price includes the following equipment and specifications: Defect Saw Features: -- 18" CAM-WOOD Model CS-18AAT-16' Automatic Cut Off Saw equipped with Automatic Pusher for increased automation and efficiency -- 16' Infeed table -- Works as an automatic pusher for defect removal and fixed length cutting when crayon marking -- PLC controlled automatic pusher device is driven by servo motor at feed speeds up to 200 FPMAutomatic Pusher Operation: -- Operator places crayon marks at the leading and trailing ends of a defect or waste zone (Optional) -- Pusher moves the board to the first crayon marked defect, automatically completes the cutting cycle, and continues to position and chop the board at each crayon mark, thereby removing all waste zones. When the board is finished, the pusher returns to its starting position at top speed and starts on the next board -- Super Pusher travels up to 200 FPM -- Sealed, long-life ball bearings -- Precision ground cast iron table with heavy metal stand -- Easy to operate in all operations -- Saw blade comes up from beneath the table and returns after cutting for safe operation -- Totally enclosed blade guard prevents danger during cutting cycle -- Includes magnetic starters with overload protectionCutting & Other Specifications: -- (45) Strokes/Min -- 18"; Saw Blade Diameter with 1"; Saw Arbor -- 10 HP Arbor Motor -- 3,200 RPM Blade Speed -- 90 PSI Compressed Air requirement with 1" Inlet -- (1) 4"; Dust Hood -- Machine Size (W x L), 30" X 28-1/2'Automatic Transfer between Defect Saw and End MatcherCAM-WOOD SFJ -300 End Matcher with the following Specifications: -- Machines tongue and groove at ends of random or fixed length boards as provided by the Defect Saw -- Includes powered conveyor for infeed and steel landing table at the outfeed -- Air operated hold downs keep material firmly in place during the machining process -- Cutter heads move in and out while cutting a tongue on the trailing end of one part and a groove on the leading end of the following pieceFeatures: -- PLC controls combined with touch-screen for maximum convenience of operation -- Each cutter head is powered by a separate motor driving the spindles at 7,500 RPM -- Accepts unlimited wood lengths via an automated conveyor for infeed and outfeed -- Cutterhead travel thru the wood is controlled by a VFD which permits automatic speed changes to suit various

CANTEK MODEL CFS100 / EM-12 DEFECT SAW AND END-MATCHING SYSTEM:Consisting of a CANTEK model "CFS-100" Optimizing Cut-Off Saw followed by a CANTEK Model "EM 12" Through-Feed End Matcher and with the following specifications and features: CANTEK "CFS-100" OPTIMIZING CUT-OFF SAW -- Up to 20 mm X 200 mm or 100 mm X 100 mm( 3/4" X 7.87" or 3.9" X 3.9" cutting capacity with 18" x 30 mm bore sawblade is driven by a 10 HP motor driving the saw spindle at 3,200 RPM; 2.7 HP servo drive feed system drives the stock up to 260 FPM; 0.787" min. distance between crayon marks; requires 75 to 80 PSI at the saw and 100 to 120 PSI at defect blow-off station. Machine comes completely wired and programmed. -- Machine is ideal for separating crayon marked waste zones from useable material before entering into a feed-thru End Matcher; provides (3) times greater production than manual cut-off saws.5% + Material recovery (yield increase) over manual cutting; compact and user-friendly design; controller adopts an industrial grade computer that employs a 32-bit floating-point DSP system and features flash and battery backup SRAM for double security; superior to conventional PC-based controls, it can fully eliminate the machine going down or being damaged due to a poor environment, such as, unstable voltage, high temperature, sawdust, etc. -- With defect blow-off system combined with computerized logic control permits the blow-off time and the length of defect to be set as desired; provides efficient defect removal and eliminates defects from bumping against the sawblade, resulting in the machine going down or sawblade damage. -- Computer control provides easy and fast maintenance; feed system driven by a servo motor for fast and accurate motion and position control; max. feed speed up to 260 FPM; cutting rate up to 80 cuts per minute with cutting accuracy within approx. ±1mm / 0.40"; control employs a touch screen for easy learning and operation.Features: -- New machine design features maximum maintenance convenience; high quality electric components provide maximum dependability; safety guards for maximum operator protection; 48" long infeed table standard - longer available option; 18" carbide blade included.(5) Cutting modes include: -- Adjustable end cuts to a max. of 10mm (0.4") -- Fixed length of cutting mode. -- Sequential cutting mode with (10) sets of cutting sizes held in memory (for sequential cutting mode only). -- Cutting on fluorescent marks with double-end trimming (perfect solution for end matching). -- Reading fluorescent marks with double end trim, fixed-length, random length end match, and finger joint block cutting. CANTEK "EM-12" END MATCHER -- Continuous through-feed system; handles random length min. 10.6" to any length x 0.4" to 1.38" thickness x 12" width capacity; -- 295 FPM max. feed speed; average speed of 75 FPM based on 6'-6" board lengths; with 118" infeed and 98" outfeed tables; -- 5.5 HP Shaper motors, 1 HP feed motor an

CANTEK EM-12 End Matcher;1.6" to 12" Width x 0.4" to 1.38" thickness (to 2-1/4" optional) x 10.6" min. length capacity. Unlimited lengths possible.Specifications: -- Feed speeds to 295 FPM with approximate production speeds of 77 FPM (based on 6-1/2' incoming boards). -- Standard 173" long infeed table and standard 86" (2,200 mm) long outfeed table; -- (2) 10 HP cutterhead motors with 40 mm spindle diameters; 1 HP feed motor; 1/2 HP motor drive to cutterhead carriage; clamping pressure from top and side; 24 volt DC controls.Standard equipment and Features: -- Designed for machining tongue & groove with or without V's on flooring and panel products; designed to be used for finger joint cutting. -- Heavy-duty self supporting main frame; compact design requires minimum floor space.Feedworks: -- Capable of processing material as short as 11" to an unlimited length; variable speed through-feed systems is controlled by frequency inverter; through-feed system allows the tongue to be cut simultaneously on the tail of one board and the leading edge of the next board. -- Powered top Urethane rolls and spring loaded bed rollers feed the material into position for processing. -- Pneumatic side pressure ensures the material is held square against the fence.Complete with: -- Safety and noise reduction enclosure; convenient touch screen control is used to quickly activate and adjust the machine functions. -- Powered 176" long infeed conveyor is included (additional length optional); with a 86.6" long outfeed table (additional length optional). -- Includes: (2) Individual Precision Insert Tooling Heads as Supplied with Machine & stacked to make (1) pair of heads; set of heads provided for groove on left and tongue on right.

DOUCET EM-2 End Matcher, Double End:Specifications: -- 12" Min. to 96" max. length x 1-3/4" to 5" width x 3/4" thick cap.; bar spacing is available at 12" center to center. -- Feed chains are is powered by a 3 HP fixed speed drive at 28 lugs per minute (simple to add a variable speed drive). Equipped with independent tongue & groove machining centers laid out on opposite sides of the transport table. -- Capacity is approx. 8,000 - 10,000 board feet per shift based on feed stock 2-1/4" wide x 36" long. Tongue & Groove Machining Centers with: -- 12" Dia. squaring saw; tongue station features a bottom & a 10" dia. top groover; Groove Station with 10" dia. groover; (5) squaring saws & groovers are powered by 3 HP arbor motors. -- When the machining centers, material is pushed up against the holddown press foot for justification with respect to the top of the board; material is placed between the traverse bars at the infeed end of the machine. -- While random length pieces are brought forward, material is positioned by perpendicular roller conveyors ahead of both machining centers; 3rd roller conveyor takes care of lateral outfeed. -- Roller conveyors are 24" wide and are embedded into the transport table; system equipped with motorized pinch roller to re-align pieces longer than 60" prior to the 2nd machining center. -- End-Matcher Model "EM" is designed for end-matching of strip flooring in a mid-sized volume production environment; End-Matcher "EM" is 21' long; overall width including the machining centers is 8 feet.

FRUILMAC RANDOMAT-E End Matcher;For end-matching flooring or cabinet & entry door rails; the feed-thru system allows continuous feeding of random-length parts with any kind of profile.Specifications: -- Width cap. of 1-3/16" to 9-7/8"; length cap. of 6-5/16" x 137" length (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness capacity. -- Approx. (10) cycles/Min depending on part length & width; -- Feed system with (2) 120" long x 10" wide powered infeed & outfeed belt conveyors, parts are automatically fed & positioned with sensors, and a positive stop to the 1st vertical shaper head (a 2nd shaper head is next to the 1st one); cope cycle is automatic. -- Parts are conveyed past the 1st & 2nd shaper head, automatically reversed, and positioned to a positive stop for the 2nd cut on the other end of the part. At the same time, the 1st shaper head would be coping the 1st end of another part.Equipped with: -- Twin 7.5 HP - 7,500 RPM high-speed shaper motors, which pneumatically traverse in tandem for each cutting cycle. -- Touch-screen SIEMENS Controller, PLC controlled conveyor & shaper cut cycle for automatic operation. -- Variable feed speed conveyor line; shaper head advance with led readout on the controls. -- Cutting station with overhead holddown wheels and 4-point pneumatic clamping with (2) overhead & (2) horizontal clamps.Includes:(4) set of used tooling

FRUILMAC RANDOMAT E - End Matcher; --For End Matching flooring or cabinet & entry door rails; the feed-thru system allows continuous feeding of random length parts with any kind of profile.Capacity & Description: -- Width cap. 1-3/16" x 9-7/8'; length cap. 6-5/16" x 137" length (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness cap. --÷ Approx. (10) cycles/Min depending on part length & width; -- Feed system with (2) 120" long x 10" wide powered infeed & outfeed belt conveyors, parts are automatically fed & positioned with sensors. -- Positive stop to the 1st vertical shaper head (a 2nd shaper head is next to the 1st one); cope cycle is automatic. -- Parts are conveyed past the 1st & 2nd shaper head, automatically reversed and positioned to a positive stop for the 2nd cut on the other end of the part. At the same time the 1st shaper head would be coping the 1st end of another part.Equipped with: --÷ Twin 7.5 HP - 7,500 RPM high-speed shaper motors which pneumatically traverse in tandem for each cutting cycle. --÷ Cutting station with overhead hold-down wheels and 4-point pneumatic clamping with (2) overhead & (2) horizontal clamps. --Controller & Operator Interface: Key Pad SIEMENS Controller, PLC controlled conveyor & shaper cut cycle for automatic operation, variable feed speed conveyor line, and shaper head advance with LED readout on the controls. --Includes Infeed and Outfeed Conveyors

HASKO HSEM & HSFM End Matcher High-Speed Feed Through; Complete with Infeed conveyor, Transfer conveyor, End matcher, Outfeed conveyor and All ToolingSpecifications: -- The feed-thru system allows for continuous feeding of random length parts with any kind of profile. -- Width cap. 1" x 7"; length cap. 8-1/2" x 12'-0" lengths; 5/16"- 2" max. thickness cap.; -- Endmatcher with feed speed from 12 - 154 lugs per minute. -- Infeed powered roller conveyor 12" x 16', feeding singulator wheels for introducing lumber onto 9-strand infeed chain deck for the Endmatcher. -- Chain deck allows for spacing of boards for singulation between the spacing bars on the infeed deck system feeding the right-hand & left-hand stations. -- Infeed to tongue cut 19'-4" x 10', Crossover chain 14' x 10' to groove cut, outfeed chain 24'-0". Transport sprockets 50 pitch.Equipped with: -- Tongue first position and groove second; (3) heads per station all with VFD 5 HP motors at 6,000 RPM. -- Both the right and left-hand processing stations have a scoring, trim and profiling head. Includes: -- (One) Auxiliary infeed 8' x 7" ABC for infeed to Tongue unit with 3/4 HP variable speed drive -- (One) Auxiliary outfeed conveyor 13'-6" long x 7" wide slider belt with 3/4 HP variable speed drive to be installed behind the groove unit and extends out for grading station.Tooling: 12" in diameterNote: Specifications must be verified Still under power.

MARINUS Powermax 300 HD End Matcher With Defecting, Cut to Length & Optimizing Cut-Off CapabilitiesFeatures & Specifications: -- Heavy and stable construction -- Cutterhead Carriage and Clamp System utilizes HD Lineal Bearings – grease lubricated. -- Heavy Duty – low maintenance Feed Chains Into machine and takeaway of material after cutting/ end matching. -- Continuous high-speed feeding system with accurate positioning utilizing HD Servo Drives. -- 2 Servomotors for maximum feed control and acceleration and deceleration control -- Servo-driven feed motor & gearbox for highest efficiency speed feeding and control of the cutterhead carriage includes independent step-less speed control forward & reverse. -- Pneumatic side pushers (holding material firmly against the fence) for guaranteed square angle cut. -- 2 Cut-off sawing servo motors: 5 HP each (3,0 kW) – 450 mm (17.7";) dia. blades with inverters (VDFs) for varying blade speed -- 2 High-speed milling head servo motors with inverter (VFD) (12HP - 7,5 kW each) with speeds to 12,000 RPM - 5"; (125 mm) dia. -- Adjustable cutterhead stroke based on material width to increase throughput speed based on the width of material input. -- 1 Luminescence-Sensor camera for defect crayon mark -- Inductive-Sensors – for detecting the position of the carriage and the others for detecting the positions of the saw blades. -- Cutoff waste powered belt conveyor in machine (below feed system- 12"; from floor) with drive motor for waste cutoff pieces taken to the outfeed end of the machine. Other Technical Specification: -- Machine is completely enclosed by safety doors. -- Machine is produced to CE Safety and Electrical Standards to UL/CSA Standards -- Lenze PLC Control -- Operation from operator’s control with touch screen control – mounted on the front right cover of the machine. -- Air pressure required – 85 PSI (6 Bare) -- 1x 8"; (200 mm) & 2 x 4.75"; (120 mm) dia dust outlets with approx. 5,000 to 5,500 mm and from 3050 to 3350 CFM -- Router Remote Access – with an internet connection, factory can monitor the performance of your machine. Also allows for easy access to service and softwareupdates and downloadsInput & Output Material Specifications -- Board Widths: 2";(50mm) Min. to 12.28";(312mm) Max. Min width 1.75"; (44.5 mm) min. -- Board Input Lengths: 17.9"; (450 mm) Min. to 20 ft.(6000mm) Max. -- Board Output Lengths: 15.9"; (400 mm) Min. -- An available short-piece option can be added to reduce output. length to 10"; (250mm) Min -- Board Widths: 2";(50 mm) min. to 12.28";(312 mm) max. -- Board Input Lengths: 17.9"; (450 mm) Min. to 20 ft. (6000 mm) Max. -- Board Thickness:4"; (10 mm) Min. - (to 0.315"; (8 mm) on request) (to 2"; (50 mm)Standard Programs / Programming -- The machine is equipped with 2 Primary Programs: -- 1. Endmatching – includes trimming ends and endmatching -- 2. Cutting only (no endmatching) -- 3 Sub-Programs -- 1. Defecting

OSI SM-450 Side Matcher LineSide Matcher:FEATURES -- Directly opposing heads (Side-Matcher): Enhances width tolerance and eliminates pistol grip -- Guarantee machining accuracy of +/- 0.002"; (0.05 mm) on width and on tongue/groove position -- Through feed system in both machines: work boards as short as 9"; (229 mm) out of the defecting station; can be processed directly into the Side-Matcher -- Process twisted, crooked and bowed boards -- Hydro-lock collars on all axis -- Feed wheels on independent suspension -- Very low friction -- High precision spindle -- Very short setup time Easy and quick width adjustment -- Easy opening for tool replacement -- Hydraulic unjammingSpecifications: -- Pre-Milling top and bottom with (2) 15 HP motor -- Feed speed 200 to 450 FPM -- Board width 1 1/2" to 8" -- Board thickness: 1/2" to 1 1/2" -- Board length: minimum of 9" trough feed -- Tooling: (2) X 8", RPM 6,000 -- Spindle drive: (2) X 30 HP -- Feed wheels: (2) rows of (4) wheels on top driven by (2) 3 HP motors -- Feed rolls: (3) chromed rolls on bottom driven by (3) 2 HP motor -- Axis movement: on linear bearings
