CAM-WOOD "PROFORMA" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.Models Include (Table Sizes): 404 (4' x 4'), 408 (4' x 8'), 510 (5' x 10')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: WEIHONG NK105 G3Spindle: 9.0kW (12 Hp) Air-Cooled Spindle 6,000 - 24,000 RPMBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Servo-Motor and DriverY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: SERIES 404: Rear Linear (6) Tools ISO30, ER32 - SERIES 408/510: Rear Linear (8) Tools ISO30, ER32Inverter: SCHNEIDER 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERWorking Size:SERIES 404: 51’’ (X) x 51’’ (Y) x 7-3/4’’ (Z)SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 404: 87’’ (X) x 74’’ (Y) x 71’’ (Z)SERIES 408: 87’’ (X) x 122’’ (Y) x 71’’ (Z)SERIES 510: 99’’ (X) x 149’’ (Y) x 71’’ (Z)Max Travel Speed: 2350 IPMMax Working Speed: 1100 IPMMachine Net Weight: SERIES 404: 3,520 lbs / SERIES 408: 3,960 lbs / SERIES 510: 4,480 lbsFeatures Include: -- Automatic (12) Tools Linear Type Auto Tool Changer Under the Bridge for Increased Productivity. -- All “Servo Motor"; Driving System: All Axes are Driven by Brush-less Type, High Torque AC Servo Motors. -- DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats Along with On-Board Conversational Applications. -- Optional CAD/CAM System can Create and Edit Part Programs Then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified, and Edited from Here to Create a G-Code. -- DNC is No Longer Required as the PC Directly Stores all Part Programs in a Text Editable File. -- Machine Designed Ready for 3-D Cutting Usage and Superior Performance. -- Moving Gantry Construction for Space Saving. -- The Rigid Steel Frame Construction has been Stress-Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. -- Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. -- Linear Guides and Sliding Blocks are Pre-loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse and Precision. --The X & Y Axis are Equipped with a Precision Rack & Pinion Dri

CAM-WOOD "DYNAMIC" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.Models Include (Table Sizes): 408 (4' x 8'), 510 (5' x 10'), 510 (5' x 12') - Please call for current pricing!General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemSpindle: 9.0kW (12.8Hp) HSD Air-Cooled Spindle - 6,000 - 24,000 rpmBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: YASKAWA Servo Drive and MotorY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: Rotary (12) Tools ISO30, ER32Inverter: 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionalDrill Bank: Includes (9) Tools HSDCAD/CAM Software: OptionalWorking Size:SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)SERIES 512: 63’’ (X) x 150’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408: 87’’ (X) x 122’’ (Y) x 71’’ (Z)SERIES 510: 99’’ (X) x 149’’ (Y) x 71’’ (Z)SERIES 512: 99’’ (X) x 173’’ (Y) x 71’’ (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408: 3,960 lbs / SERIES 510: 4,480 lbs / SERIES 512: 4,970 lbsFeatures Include: --Automatic (12) Tool Rotary Type Auto-Tool Changer for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by Brush-Less Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --Optional CAD/CAM System can Create and Edit Part Programs then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified and Edited from here to Create a G-Code. --DNC is no Longer Required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress-Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse and Precision. --Th

CAM-WOOD "EXCEL" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.Models Include (Table Sizes): 408 (4' x 8'), 510 (5' x 10'), 510 (5' x 12')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: SYNTEC Control SystemAuto-Loading: Auto In-feed Loading Scissor Lift & Out-feed Conveyor TableSpindle: 9.0kW (12.8Hp) HSD Air-Cooled Spindle - 6,000-24,000 rpmBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Servo-Motor and DriverY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: Rotary (12) Tools ISO30, ER32Inverter: 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERTool Length Device: AutomaticVacuum Pump: OptionalDrill Bank: Includes (9) Tools HSDCAD/CAM Software: OptionalWorking Size:SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)SERIES 512: 63’’ (X) x 150’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 408: 98’’ (X) x 433’’ (Y) x 71’’ (Z)SERIES 510: 110’’ (X) x 531’’ (Y) x 71’’ (Z)SERIES 512: 112’’ (X) x 603’’ (Y) x 71’’ (Z)Max Travel Speed: 2 350 IPMMax Working Speed: 1 100 IPMMachine Net Weight: SERIES 408: 8,810 lbs / SERIES 510: 9,970 lbs / SERIES 512: 10,750 lbsFeatures Include: --Nesting Work for Automatic In-feed Loading w/Scissor Lift and Out-feed Unloading w/Conveyor Process. --Automatic (12) Tool Rotary Type Auto-Tool Changer for Increased Productivity. --All “Servo Motor"; Driving System: All Axes are Driven by Brush-less Type, High Torque AC Servo Motors. --DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats along with On-Board Conversational Applications. --DNC is no longer required as the PC Directly Stores all Part Programs in a Text Editable File. --Machine Designed Ready for 3-D Cutting Usage and Superior Performance. --Moving Gantry Construction for Space Saving. --The Rigid Steel Frame Construction has been Stress Relieved Prior to Finished Machining to Provide Repeatability and Accuracy. --Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. --Linear Guides and Sliding Blocks are Pre-Loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse and Precision. --The X & Y Axis are Equipped with a Precisio

CAM-WOOD - IN-510-R, ...5' x 10' CNC Router with Automatic Rotary Tool Changer:5' x 10' Flat Table CNC Router, Perfect for your 3-axis routing applications including "Nested Base Manufacturing".Machine Bed/Base: -- The Welded & Structurally Engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- The Moving Gantry Bridge travels in the X- & Y-axis via inclined toothed Helical rack & pinion on "HIWIN" 1" (25 mm) thick hardened & precision ground rectangle linear guide ways providing extra smooth movement, high-speed traverse and accurate cutting. -- The Tool Gantry Movement for the vertical Z-axis travels on a 1" (25.4 mm) dia. precision ball screw for smooth & consistent movement.CNC Control & Operator Interface: -- Industrial Grade "SYNTEC" controller with network-compatible WINDOWS PC-based front-end, color monitor, keyboard, mouse. Absolute & incremental programming, cutter & tool length compensation, feed rate & spindle speed override, inch/metric operation, and linear/circular & helical interpolation. -- Compatible with virtually all CAD/CAM programming software on the market. - You choose the software that best suits your needs.Working Table/Envelope: -- X 63" (1,600 mm), Y 126" (3,200 mm), X 7.75" (197 mm). -- (6) Independent vacuum zones.Axes Travel Range & Feed Speed: -- Max Traverse Speeds: 2,350 IPM -- Max Working Speed: 1,100 IPM. -- Yaskawa "AC" Servo drives & SHIMPO Gear Boxes power all axes movements.Routing & Machining: -- (1) 12 HP HSD Air cooled Router Spindle with: ISO 30 Adaptor ER-32, variable programming speeds from 6,000 to 24,000 RPM, -- (1) 12-Position ATC (automatic rotary tool changer)Complete With: -- 10 HP Vacuum Pump. -- (3) ISO 30 tool holders -- two pop up pins at X, axis & three pop up pins at Y. -- Automatic tool offset device. -- Automatic lubrication device with filter. -- Standard MPG hand wheel -- safety light curtain and Estop -- 1-Year manufacture warrantyUtilities and Dims: -- Machine power supply is wired for 220 Volts, 60 Cy, 3-Phase, 53 Amps. -- Machine weighs approx. 4,480 Lbs. -- Machine air consumption at 90 PSI is approx. 15 CFM;Extra options not included in machine price: HSD 9-spindle vertical Drill-bank ...$7,675 Add second 10 HP Vacuum Pump with stand ...$6,000

CAMASTER - PANTHER 408: Router w/Vacuum Pump -- SpecificationsMaterial processing dimensions: 48" Wide x 96" long x 8" thick; 11" "Z" axis stroke. -- Fixed 4-zone universal vacuum table for simple clamping of workpiece to machine; moving gantry bridge rides on high precision HIWIN linear rails for consistent movement & accurate cutting. -- Welded structural steel machine base: Provides solid foundation for superior cut quality; tool gantry & bridge travel by rack & pinion; vertical axis travels on ball screws for smooth consistent movement. -- Working UnitsIndustrial grade direct drive: 4 HP (3 kW) HSD router spindle; variable tool speed: Up to 18,000 RPM allows for the right cutting speed in any application. -- X- & Y-Axis; 1,500 IPM traverse speed for quick movement between cutting cycles to reduce total CNC machining time. -- Includes Windows-based CNC control preloaded on a PC (included); very intuitive interface; quick to learn and easy to use. -- Full-featured machine Operating System with: On-screen tool path graphics & CAM software; controller accepts direct import of: DXF, HPGL, BMP, or JPEG files & will create machine code simply & easily with a few "clicks" from the mouse. -- Compatible with virtually all CAD/CAM programming software on the market, which means you can choose the software that suits your business best. -- IncludesRemote Control Pendant; dust hood with: 4" Dia. inlet; BECKER "VTLF 2.250/10" HP Vacuum Pump & piping; JET Cyclone Dust Collector & ductwork; Toolholder & Collet. -- Actual Model - CAMASTER PANTHER 408 ROUTER.

CMS VIVA PF 6-B2-TUCU+GF CNC Router (5-Axis) W/ATC: -- Specifications:High-Speed bridge type 5-axis CNC router with two moving worktables with an overall 228" x 148" Table size. The tables can be used single or synchronized together with head travel of: X-Axis 258", Y-axis 168", Z-axis 47.25". -- Positioning speed:On X- and Y- axis 2,340 IPM, movable tables with loading and unloading on front side end, gantry with head assembly travels in a "shuttle style" across entire table which is divided into left and right working area. -- Equipped with:Router head, air cooled 17.5 HP spindle motor with static inverter frequency changer, infinitely variable speed of 1,200 to 18,000 RPM, accepts "HSK 63F" spindle chuck with 1" collets, features C-axis with 360ø rotation, rotates at a max. speed of 90ø/Sec, B-axis + or - 110ø -- (1) 16-Position ATC tool changer, "HSK 63F" for tool holders with tooling and aggregates,(includes 2 90ø tools each with 2-spindle that are opposed) 300 mm tool dia. and 12 Lbs max. tool weight, mounted on a traveling gantry for an "on-the-fly" tool change. -- Drilling unit:with 17-spindles 9-vertical + 8-horizontal @ 32 mm center distance. Additionally includes (1) drill unit for the under-side of machine. RENISHAW probe for X - Y - Z of the tools in tool holder & parts location from zero. -- Work Area:Support table with phenolic & vacuum hold down; the table is equipped for part support fixtures or parts that can be secured directly to the table, lowerable side and back stops plus 2-extra center stops for each table for the placement of double parts on the table, the table is sectional allows parts to be removed from one end of table while remaining fixed on the other end. -- Operator Interface:"Fanuc 31i-Model B5: Popularly selected for high-precision tooling and heavy-duty milling applications requiring robust multi-axis simultaneous interpolation." Control, port for an RS-232 connection to a PC, floppy disk, CD ROM, direct link to PC, bar coding, etc., CRT display unit with color screen. -- Program memory of 200 KB editing capabilities of stored programs, diagnostic full time on-line with modem, closed loop system, 3-axis simultaneous positioning for linear movement, cutter radius compensation, tool length compensation, absolute & increment positioning ability, system for tool recognition. -- Complete with:Control in separate movable cabinet, central automatic lubrification for all feed guides & driving units, (1) 160 m³/Hr, Vacuum Pump. Safety devices & safety bumper provided at both sides of gantry.

CNC FACTORY - VIPER: Flat Table Machine (w/ATC) -- Specifications:4' x 8' Flat Table "Bridge Gantry" machine with: "Phenolic "MATRIX" grooved flat table for "NESTED BASE MANUFACTURING". -- Working Capacity"X" Axis: 97" (2,463 mm); "Y" axis: 49" (1,245 mm); "Z" axis stroke: 20.2" (515 mm); max. material thickness: 10" (250 mm). -- Positioning Speed"X" & "Y" Axis: 279 FPM (85 MPM); "Z" axis: 115 FPM (35 MPM).All axes movement is with 5 G driverless Servo System with: Direct helical rack & pinion & 5 G no homing calibration. -- Work AreaFlat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing".Machine has: (4) Independent working/vacuum zones with: Dual layer high flow vacuum; 1-left origins, 1-right origins, 1-front origin & 1-rear origin.Auto-material alignment pins; auto-unloading arm; material loading wheels; rear & side material alignment pushers. Automatic on/off vacuum flow; vacuum hold-down communication; automatic parts hold-down; automatic release.Robotic Material Sensing Dust Hood; Single & dual vacuum ports. -- Machining(1) 10 HP (7-1/2 kW) Air-cooled "HSD Electro Spindle" with: ISO 30 Adaptor; RH & LH rotation; variable speed from: 1,000 - 24,000 RPM.(1) 12-Position ATC tool rack mounted on the Bridge of the machine. -- Operator Interface"SYNTEC" PC Front-End Touchscreen control with: CNC Factory 5G; 5th generation CNC control + At machine cabinet and V-carve cutting software. Air-Conditioned control cabinet, 21" "TOUCHSCREEN" monitor with: Automatic vacuum control; all mounted on a mobile cart. -- Complete with:(1) V300 Vacuum Pumps; automatic pressurized Lubrication System for linear guides; pads & recirculating ball screw. Auto tool length measurement probe; Perimeter Safety System & fencing. -- Actual Model: CNC FACTORY VIPER

FELDER FORMAT4 - Profit H08: Flat Table Machine (w/Offloading) -- Specifications5' x 10' "MATRIX" Phenolic Flat Table design for: "Nested Base" Manufacturing. -- Working Capacity"X" Axis is 121.6" (3,090 mm); "Y" axis is 60.2" (1,530 mm);"Z" axis stroke is 11.8" (300 mm); max. material thickness is 4.3" (110 mm). -- Positioning Speed"X" & "Y" Axis at 197 FPM (60 MPM); "Z" axis is 49 FPM (15 MPM). -- WorktableWorking area is subdivided into (8) vacuum fields (H08 16.31) to: Ensure the best holding force for the most varied board sizes.The vacuum fields are controlled manually by means of: Hand levers on the front side of the machine. Prepared for (optional) elevated pods: Allows profile & horizontal machining. -- Boring Unit(1) DH 8-Spindle Vertical Drill block: On 32 mm centers. -- Machining(1) 13.4 HP (10 kW) Vertically mounted electro spindle Router with: HSK F63 Adaptor; inverter driven 1,000 - 24,000 RPM; max. torque from 12,000 RPM.(1) 15-Position ATC Tool Rack: Mounted at the end of the machine. -- Operator & Machine ControlPC Based user-friendly; icon driven control housed on the: Main machine base + "WOODFLASH" Operating System. -- Complete with:(2) 250 m³/Hr Vacuum pumps; handheld terminal with: Potentiometer & emergency stop; automatic measuring system of the tool length.Sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Options Include: Automatic unloading unit with: Electromotive offloading pusher. This addition allows finished workpieces to be automatically pushed off the table after processing: Reducing manual handling & speeding up production cycles. -- Actual model: FELDER FORMAT4 - PROFIT H08 16.31

GIBEN G2 GENESIS 48 CNC ROUTER (ATC & BORING): 4' x 8' Fixed table; moving gantry machine with: Single zone vacuum table. -- Equipped with:(1) 12 HP, ANDI HSK-63F ATC spindle; air-cooled; ceramic bearings; variable spindle speed from: 6,000 - 24,000 RPM. -- 6-Station Automatic Tool Changer & 2 HP 9-spindle vertical drill bank (5 in X- & 4 in Y-Axis). -- Axis Stroke1,300 mm (51") In Y-Axis; 2,500 mm (98.4") in X-Axis; 200 mm (7.8") in Z-axis. -- Max. Feed Rate60 MPM (2,362 IPM) In X- & Y-axis; 30 MPM (1,180 IPM) in Z-axis. -- FeaturesTool Length Measuring System (Tool Touch Off device). -- ControlANDI/SYNTECH Controller with: Network compatible WINDOWS PC based front-end; color monitor; keyboard; mouse.Full function handheld pendant absolute & incremental programming; cutter & tool length compensation; feed rate & spindle speed override; inch/metric operation; linear/circular & helical interpolation. -- Complete with:10 HP BECKER Vacuum Pump; Tool Holder’s collets; Light safety fences. -- Maintenance supplies: Grease, grease guns; full manuals; product literature.

GIBEN - G4 EVO 510: CNC Router ATC & Boring: + Infeed, Rake & Offloading -- Specifications 5' x 10' "Matrix" grid Phenolic surface for "Nested Base Manufacturing". -- Working CapacityX-Axis 126" (3,200 mm); Y-axis 62.9" (1,600 mm); Z-axis stroke is 9.8" (250 mm); max. material thickness 4.7" (119 mm). -- Positioning Speed• X- & Y-Axis 262 FPM (80 MPM); Z-axis 98 FPM (30 MPM).• X- & Y-Axis use: Precision Rack & Pinion system; Z-axis uses precision ball screws.• All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors.• All motion components are maintained by an automatic Lubrication System. -- Work Area• Flat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing".• (2) Side clamps + (4) external pneumatic pop-up stops for piece positioning at (4) corners of workstations; automatic NC controlled 8-zone vacuum table.• Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with: "Quick Connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit• (1) 2-1/2 HP (1.7 kW) Motor; variable speed: Up to 6,000 RPM; "HSD" Boring unit.• (16) Independent vertical spindles with: (9) In X-axis & (7) in Y-axis. -- Machining• (1) 15 HP Air-Cooled "ANDERSON" Electrospindle with: HSK F63 Adaptor; RH & LH rotation; variable speed from 1,000 - 24,000 RPM.• (1) 8-Position ride-along ATC tool changer for "on the fly" ATC. • NC Controlled "touch off probe" tool presetting for the measurement of the tool length. -- Operator & Machine Control• PC Front-End with: ANDI/GIBEN "SYNTEC" + "WINDOWS" Operating System.• 19" LCD Flat screen monitor; server; full keyboard; mouse: All mounted on a mobile cart.• Intel(R) Core i CPU; 8 GB RAM memory; 500 GB (SSHD) hard disk; dedicated graphic card; DVD reader; USB ports; Ethernet card for network connection capabilities. • Automatic program update according to the tool length (touch off probe). -- Equipped with: • (2) 250 m³/Hr (9 HP) "BECKER" vacuum pumps • Automatic Lubrication system for: Linear guides, pads, & recirculating ball screw • Teleservice capabilities • Perimeter safety light bars & perimeter fencing • Manuals & Documents on CD. -- Options Include:• (1) NC Controlled infeed Scissor Lift table • (1) Vacuum loading device • (1) Rake system • (1) NC controlled & powered belt outfeed table with vacuum sweeping system. -- Actual Model is: GIBEN - G4 EVO 510

GRIZZLY G9981 Heavy-Duty Overarm Pin Router Specifications: Throat 25-19/32". Table size 29-3/4” LR x 21-1/2” FB with Table tilt 0° - 45° Forward, Table height 36-1/2" - 42-3/4".Vertical table travel 8". Spindle speeds 10,000 & 20,000 RPM. Spindle travel 3-15/16". Equipped with: 5 HP - 3,450 RPM Motor. Foot pedal control.

HOLZ-HER DYNESTIC 7505, 5x12 CNC FLAT TABLE MACHINE (W/ATC/BORING): 5' x 12' Phenolic MATRIX Table for "Nested Base" Manufacturing. -- Working Area: "X" Axis 145" (3,683 mm), "Y" axis 61.45" (1,561 mm), "Z" axis stroke is 12.4" (317 mm). -- Positioning speed: "X" & "Y" Axis 230 FPM (70 MPM), "Z" axis is 65 FPM (20 MPM). -- Worktable: Flat table designed for "Nested Base Manufacturing"; (4) Pneumatically controlled reference stop pins with (3) in "Y" axis & (1) in "X" axis. -- Boring Unit:2 HP (1.7 kW) motor for spindle speed from 1,000 to 6,000 RPM; (10) independent vertical boring spindles with (6) spindles in the "X" axis & (4) spindles in the "Y" axis;(4) Horizontal spindles with (1+1) in "X" axis & (1+1) in "Y" axis.(1) "X" axis Saw for max 120 mm dia. blade. -- Machining unit: (1) 15 HP (11 kW) Electro-spindle Router with HSK F63 adaptor, 1,000 - 24,000 RPM;(1) 12-position Linear ATC tool rack mounted to the machine base. -- Operator & Machine Control: PC Front-End with Holz-Her "CAMPUS V7" + Windows "7" operating system; 17" Color monitor; standard keyboard, mouse & CD ROM for data entry; (3) axes simultaneous control; feed rate and spindle speed override & axis movement.CAMPUS/NC Hops offers "Real Time" 2D or 3D graphics; Campus aCADemy is a full-fledged, high-performance CAD/CAM software package with versatile import features. -- Complete with:(3) 250 m³/Hr BECKER Vacuum Pumps with ECO Vac Intelligent Vacuum that automatically turns on/off vacuum units in reference to required static negative pressure; "forced" lubrication system for guides & ball screw; sound absorbing protective head enclosure. -- Actual Model is HOLZ-HER DYNESTIC 7505 5x12

HOLZ-HER DYNESTIC 7516 FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 5' x 10' MATRIX Table for "Nested Base" Manufacturing. -- Working Field: "X" Axis 122.2" (3,105 mm), "Y" axis 61.45" (1,561 mm), "Z" axis stroke is 16.5" (418 mm). -- Positioning speed: "X" & "Y" Axis 230 FPM (70 MPM), "Z" axis is 65 FPM (20 MPM). -- Worktable: Flat table designed for "Nested Base Manufacturing" with (4) pneumatically controlled reference stop pins. -- Boring Unit:2 HP (1.7 kW) motor for spindle speed from 1,000 to 4,400 RPM;(10) Independent vertical boring spindles with (6) spindles in the "X" axis & (4) spindles in the "Y" axis; -- Machining: (1) 15 HP (11 kW) Electro-spindle Router, HSK F63 adaptor, 1,000 - 24,000 RPM;(1) 8-Position ATC. (dynamic carrousel type) -- Operator & Machine Control: PC Front-End with: CAMPUS Version 6.3.0.3 (BECKHOFF CNC Version 2.3.7) machine control,17" Color Flat Panel Monitor; continuous graphical and barcode interface, (3) axes simultaneous control; feed rate and spindle speed override & axis movement. -- CAMPUS/NC Hops Software: This package provides the prerequisites for effective machining and convenient operation. Our ECO Mode automatic standby control is a standard feature on all HOLZ-HER CNC machining centers for software-controlled minimization of the power consumption.Campus aCADemy is a full-fledged, high-performance CAD/CAM software package with versatile import features. -- Complete With:(1) BECKER 250 m³/Hr vacuum pump; manual central lubrication pump for guides & ball screw; left & right-side safety enclosure; Hand Control, pendant for set-up and program try-outs -- Actual Model is HOLZ-HER DYNESTIC 7516 10.5.

HOLZ-HER LYNX 7511 FT FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 10' Phenolic "MATRIX" table for "Nested Base" Manufacturing. -- Working Field: "X" Axis 120" (3,050 mm), "Y" axis 62" (1,575 mm), "Z" axis stroke is 16-1/2" (419 mm), max material thickness 7" (180 mm). -- Positioning Speed: "X" & "Y" Axis 230 FPM (70 MPM), "Z" axis is 65 FPM (20 MPM). -- Worktable:Flat table designed for "Nested Base Manufacturing" with (3) "Y" axis pneumatically controlled reference stop pins. -- Boring Unit:2.3 HP (1.1 kW) motor for spindle speed from 1,000 to 6,000 RPM; (10) independent vertical boring spindles with (6) spindles in the "X" axis & (4) spindles in the "Y" axis; -- Machining: (1) 15 HP (11 kW) Electro-spindle Router, HSK F63 adaptor, 1,000 - 20,000 RPM; (1) 12-position tool rack for ATC. -- Operator & Machine Control: PC Front-End with Holz-Her "CAMPUS" + Windows operating system, 17" Color monitor; continuous graphical and barcode interface,BAUMULLER - PLC for (3/4) axes simultaneous control, feed rate and spindle speed override & axis movement. -- Complete with:(1) 250 m³/Hr BECKER Vacuum Pump; automatic "forced" lubrication system for guides & ball screw; sound absorbing protective head enclosure. -- Actual Model is HOLZ-HER LYNX 7511 FT.

HOMAG - OPTIMAT BOF 211/30/R: Flat Table Machine (W/ATC/Boring/"C"Axis) -- Specifications4' x 10' Flat Matrix grid Phenolic working table. -- Working Field"X" Axis 120" (3.050 mm); "Y" axis 51" (1,300 mm); "Z" axis stroke 21" (535 mm); max material thickness 8.2" (210 mm). -- Positioning Speed"X" & "Y" Axis is 260 FPM (80 MPM); "Z" axis is 98 FPM (30 MPM). -- Boring Unit4.2 HP (3 kW) Variable speed from 1,500 - 7,500 RPM; (12) independent vertical spindles: (6) in "X" axis & (6) in "Y" axis. -- Machining(1) 19.4 HP (14.5 kW) Liquid-Cooled electrospindle router with: HSK 63F Adaptor; variable speed from 1,000 - 24,000 RPM. -- (1) NC Controlled C-axis for 360° horizontal processing. -- (1) 12-Positon automatic tool changer mounted at the back of the head for "on the fly" ATC. -- Operator Interface PC Front-End with: "HOMATIC" PC 85 Power Control + Windows "NT" + WoodWOP Operating System. -- 14" Color graphic monitor; industrial keyboard for data entry; 1.44 MB & CD RW disk drives; EtherNET interface for possible LAN connection to office PC. -- USB & RS-232 Serial interface for simple PC connection. -- NUM (PLC) With 3D Linear interpolation; 4-axis control for "X", "Y", "Z", & "C" axes. -- All mounted in separate free-standing control cabinet. -- Complete with:(1) 40 HP DEKKER "VMX055" Vacuum Pump; safety fencing; safety mats (will stop machine if operator enters work area); handheld pendent control. -- Actual Model: HOMAG OPTIMAT BOF 211/30/R

HOMAG - CENTATEQ N 300/510 OPTIMAT NBP084/VANTECH510: Flat Table Machine (W/Loading/Unloading/ATC/Boring) -- Specifications 5' x 10' Flat Table "Bridge Gantry" machine with: User-Friendly "MATRIX" grooved phenolic vacuum table. -- Working Area"X" Axis: 122" (3,100 mm); "Y" axis: 61" (1,550 mm); "Z" axis stroke Routing: 12.8" (325 mm); "Z" axis stroke boring: 7.3" (185 mm); max. material thickness: 3.9" (100 mm). -- Positioning Speed "X" Axis: 236 FPM (72 MPM); "Y" axis: 203 FPM (62 MPM); "Z" axis: 82 FPM (25 MPM). - Machine head travels on: THK Linear motion guides on all axes. -- Worktable(1) Pneumatic locator/positioning rail: "X" Axis; (1) pneumatic locator/positioning rail: "Y" Axis. - (10) NC Controlled Vacuum Table work zone. -- Boring Unit3.6 HP (2.7 kW) Motor; (12) independent vertical spindles with: "Quick-Change" drill bit holders; programmable variable speed: 1,500 - 7,500 RPM. -- Machining(1) 16 HP (12 kW) High-speed electrospindle router with: "HSK F63" Adaptor; constant duty; variable speed: 1,250 - 24,000 RPM; RH or LH rotation. - (1) 14-Position Rotary Tool Changer. -- Operator InterfacePC Front-End with: WEEKE "PC 85T" + Windows "10 PRO" + WoodWOP Operating System. 17" TFT Color graphic monitor; keyboard for data entry; PC 85T hand control pendant; CD R/W & floppy drives; EtherNET interface for LAN connection to office PC; RS-232 serial interface; USB ports. • BECKHOFF Programmable logic control for (3/4) axes: Linear, circular & helical interpolation. • Controller: Contained in a separate freestanding, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: • (2) 9 HP BUSCH "Mink MV 0312 B" Vacuum Pumps. • Light curtain (machine will stop if the Operator enters the work area). • Perimeter safety devices. • Separate control cabinet. • Touch-off tool length measuring device. • Handheld pendant control. -- Options Include• (1) NC Controlled infeed Scissor Lift table with vacuum loading; • (1) Rake system; • (1) NC Controlled & powered belt outfeed table with: Vacuum sweeping system. -- Actual Model: HOMAG - CENTATEQ N 300/510 OPTIMAT NBP084/VANTECH510.

--MAKE AN OFFER---EXCELLENT CONDITION HOMAG - Centateq N-300 NBP084/VANTECH 512, ...5' x 12' CNC Flat Table Machining Center with ATC, Boring, Nesting, Infeed Roller & Outfeed Specifications: 5' x 12' x 37” H Flat table "Bridge Gantry" machine. Working Area: X-Axis 3,683 mm (145"); Y-Axis 1,550 mm (61.02"); Z-Axis 100 mm (3.9"). Travels: X-Axis 193" (4,900 mm); Y-Axis 1,965 mm (77.36"); Z-Axis 245 mm (9.65"). Positioning Speed: X-Axis 72 MPM (236 FPM); Y-Axis 62 MPM (203 FPM); Z-Axis 25 MPM (82 FPM). (2) Synchronized X-Axis drives, AC brushless drives on head, THK linear motion guides on all axes. Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement. (1) Pneumatic locator/positioning rail in X-Axis & (1) pneumatic locator/positioning rail in Y-Axis; (10) CNC-Controlled vacuum table work zones. Boring Unit: 2 HP (1.5 kW) Motor; (7) independent vertical spindles with: (4) In X-Axis & (3) in Y-Axis; variable spindle speeds 1,500 - 7,500 RPM. Machining: (1) 13 HP (10 kW) High-speed electro-spindle router with: HSK F 63 Adapter, constant duty, variable spindle speeds 1,250 - 24,000 RPM, left-hand or right-hand rotation. (1) 14-Position carousel-type automatic tool changer on left-hand side of machine. Operator & Machine Control: "powerControl" Control, with MICROSOFT "Windows" + "WoodWOP 5.0" Operating System. "powerTouch" 21.5“, 16:9 full-HD multitouch display, Ethernet, RS-232, USB ports, and remote pendant control. BECKHOFF Programmable logic control for (3/4) axes; linear, circular, & helical interpolation, Tapio-ready. Complete with: Infeed electric/hydraulic Scissor Lift platform with roller top; 4’ x 4’ transfer Roller Section with: 2-1/8” Dia. x 3/4” W wheels on 12” & 9-1/2” centers; vacuum arm with (2) 10” dia. vacuum pads; rake off-feed System; 61” W x 13’ L outfeed motorized Belt Conveyor; (2) 2018 BECKER "VTLF2.250/0 - 79" 10 HP 200 mbar Vacuum Pumps; light curtain; 6' H safety Fencing, Touch-off tool length Measuring Device. Control Cabinet Dimensions: 44" x 39" x 96" H. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i63 The Flex Series of CNC routers from Komo Machine has been developed specifically for the customer who expects the utmost in technical quality and reliability at an economical price. These machines feature a moving gantry configuration and a side-mounted tool changer. Features: Four-pole, 16HP (12kw), 24,000 RPM, HSK 63F, fan-cooled spindle, 12 position automatic tool changer with aggregate capability, Air blast for optimal dust/chip evacuation and cooling of the cutting tool, Advanced Fanuc HVI servo system tuned for optimum acceleration and deceleration, Fanuc Panel i control with integrated PC 19" color display Construction, FEA "Finite Element Analysis" engineered structure, Heavy-duty steel fabrication Specifications Spindle: 1 Spindle RPM 16HP (12kw), four-pole, fan cooled Up to 24,000, fully programmable with HSK 63F taper. Table: 60" x 144" (1524mm x 3658mm), Four (4) 1" (25mm) part location pins Aggregate-Capable Tool Changer: Max 12 tools, Max Dia. 3.25" (82mm) positions full; 6.5" (165mm) adjacent positions empty, Max weight 12 lbs each / 80 lbs total (5.4kg / 36.4kg) Max Length 5" (127mm) Feed Rate/Traverse: X-Axis 2500ipm (63.5mpm), Y-Axis 2500ipm (63.5mpm) Z-Axis 1200ipm (30.5mpm), Acc/Dec83.3 in/sec² Axis Travel: 149" (3784mm) x 82" (2082mm) x 8.5" (215mm) Positioning: ±0.0008" (0.02mm) linear axis repeatability accuracy Control System: Fanuc Panel i With integrated PC and 19" color display Dust Collection Interface: 6" (152mm) diameter (recommended volume 900 cfm) Includes: Dekker Vacuum Pump NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

KOMO VR 510 FUSION CNC Router (ATC/Boring): -- Specifications:Heavy Duty "VR 510 FUSION" with 60" x 120" table, (4) parts location pins & vacuum table zones; precision machined 2" solid aluminum table, spoil board ready. -- Table travels on precision THK contour linear guideways, extra Heavy Duty fixed center supported gantry for full 10' of X-axis travel table coverage. -- Machining:(1) 16 HP High Frequency router with "HSK 63F" air cooled electro-spindle, variable speed 6,000 - 24,000 RPM; router has a 15-position dynamic ride along Tool Changer, ATC is front mounted, travels with router spindle and allows loading-and-changing of aggregates. -- Router spindle has air cooling through independent electric fans, ceramic bearings and internal blowing device for cleaning of the "HSK 63F" tool holder cones. - Router is mounted on slides for individual positioning by Servo motors. -- Boring:(1) 9-Spindle (5x4) Boring unit -- Travel:Closed loop Servo drive system with precision ground pre-loaded precision ball screws driven by FANUC brushless AC Servo motors at (65,536) pulses/revolution for positioning +/- 0.0004 on all axis at 0.001 - 3,150 IPM max. machining feed rate with 3,150 IPM rapid traverse on X- & Y-axis, 600 IPM on Z-axis. -- X-Axis travels 140", Y-axis 84", and Z-axis 15" with 19" clearance under the gantry, extended gantry bridge for full 60" x 120" table coverage by all work heads. -- All axes ride on extra-large THK precision contour linear guideways, all positioning bearings serviced by an automatic lubrication system. -- Operator Interface:FANUC Series computer control with: 10.4" High resolution CRT, 3-1/2" floppy and 1.6 GB hard drive; RS-232 ports, (MPG) handheld controller, full Qwerty keyboard & air conditioning system for temperature control. -- Remote pedestal at opposite side of machine for Cycle/Start/Stop. As well as Vacuum control, locating pins, and Pop-up roller balls on the table. -- Features:(3) Axes simultaneous control, background editing, self-diagnostic, canned cycles, absolute & incremental programming, cutter & tool length compensation, feed rate & spindle speed override, inch/metric operation, and linear/circular & helical interpolation. -- Includes Quincy vacuum pump.

KOMO VR 510 MACH ONE CNC Router with ATC and Boring 60" x 120" Moving table, Heavy Duty fixed bridge machine, front-to-back configuration.2" Thick solid cast aluminum table machined with a single vacuum zone, (3) pop-up pins for material location. -- Machining:(1) 12 HP "BT-30" Type ATC spindle, variable spindle speed from 6,000 - 18,000 RPM, (1) 8-station ATC tool carousel. -- Boring:(1) Boring Block with (6) Independent vertical spindles & (1+1) horizontal spindle in X-axis & (1+1) horizontal spindle in Y-axis -- All axes:Ride on THK linear guide ways, closed-loop AC Servo motors drive precision preloaded ball screws for positioning tolerances of 0.001" & 1,200 IPM rapid traverse rates. - Automatic lubrication system to service all ball screw & way bearings. -- GE/FANUC "210 I" Control:WINDOWS PC Front end, 10.4" high resolution color CRT, (3) axes simultaneous control, linear & circular interpolation, network compatible, RS-232 port, and handheld controller. -- Complete with:Background editing, self-diagnostics, high speed, high precision machining function, canned cycles, absolute & incremental programming, inch/metric capability, cutter & tool length compensation, and feed rate & spindle speed override.Note: There is "NO" Vacuum Pump Included.
