CAM-WOOD WP-610A Single-Sided Planer 10 HP - 24" Cap. Features: -- 24" Spiral cutter head provides precise, efficient planing with low noise levels. -- Automatic digital thickness controller for quick & accurate setting. -- Motorized worktable raises & lowers by separate motor for more efficient operation. -- Specially designed infinitely variable feed system is powered by a separate motor and allows adjustment to the optimal feed rate for planing to a precise smooth finish on both hard or softwoods. -- The sectional infeed roller & anti-kickback device & chip breaker gives the operator greater safety. -- Up to 8"; thickness large cutting capacity. -- Exhaust dust hood with 4"; dia. outlet for proper chip extraction. -- The motorized worktable includes twin quick adjustable bed rollers that can be adjusted for rough & finish planing on damp or dry lumber ensuring a consistently smooth planed finish. -- Precision sealed long-life ball bearing. -- Industrial motor for powerful cutting capacity. Heavy gauge sheet metal frame and base for maintenance-free service.Specifications: -- Table area 25" x 28". -- Max. planing width 24". -- Feed Speed (Var.) 15 ~ 60 FPM. -- Max thickness 8'' and min. Planing Thickness 1/8". -- Elevation Motor 0.5 HP. -- Cutterhead Speed 5,500 RPM. -- Cutter head diameter 4-3/4", Spiral. -- Knife insert dimensions 14 mm x 14 mm. -- Max. Cutting Depth 5/16";. -- Feed Motor 1 HP. -- Cutterhead Motor 10 HP. -- G.W. 1,850 LBS / 2,000 Lbs.

CAM-WOOD WP-760 15 HP Single Sided 30" Planer Features: -- Spiral cutterhead provides precise, efficient planing with low noise levels. -- Automatic digital thickness controller for quick & accurate setting. -- Motorized worktable raises & lowers by separate motor for more efficient operation. -- Specially designed infinitely variable feed system is powered by a separate motor and allows adjustment to the exact feed rate and allows precision smooth finish planing on both hard or softwoods. -- The sectional infeed roller & anti-kickback device & chip breaker provides greater safety for the operator -- Exhaust dust hood with 4"; dia. outlet for proper chip extraction. -- The motorized worktable includes twin quick adjustable bed rollers that can be adjusted for rough & finish planing on damp or dry lumber ensuring a consistently smooth planed finish. -- Precision sealed long-life ball bearing. -- Industrial motor for powerful cutting capacity. Heavy gauge sheet metal frame and base for maintenance-free serviceSpecifications: -- Table Area 38" x 31" -- Max. Planing Width 30" -- Max. Planing Thickness 8" -- Mini. Planing Thickness 3/16" -- Cutterhead Speed 5,500 RPM -- Cutterhead Diameter 4-3/4" Spiral -- Knife Dimensions 14 mm x 14 mm -- Feeding Speed (Var.) 15 ~ 75 FPM -- Max. Cutting Depth 5/16" -- Feed Motor 2 HP -- Cutterhead Motor 15 HP, 3 Ph, 230 V -- Table Elevation Motor 1 HP -- Digital Thickness Control Yes -- Dust Hood Outlet 5"G.W. 2450 Lbs

CAM-WOOD WP-2000S Single Sided Planer20" Planer with solid cast iron construction and Spiral Cutter Head.Features & Specifications: -- Precision ground cast iron table w/manual adjustment by hand wheel via (2) large lead screws. -- Scale & pointer readout for accurate thickness adjustments. -- Fixed feed (30 FPM) speed setting for consistent stock removal. -- Sectional steel infeed roller & segmented chip breaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- 3 HP Self-braking motor. -- Magnetic starter & thermal overload switch and Emergency stop. -- Operations manual, parts list & tool kit. Optional: CT-SCH-14T - 14 mm x 14 mm SPIRAL CUTTERHEAD BLADES ...$3.30 each

CAM-WOOD WP-1400H 52"; Heavy Duty Planer with Spiral Cutter Head55" Cap. solid cast iron construction planer with powerful 25 HP motor.Features & Specifications: -- Precision ground cast iron table with motorized worktable raising & lowering, manual adjustment by hand wheel via (2) large lead screws. -- Digital thickness display with touchpad positioning control for accurate thickness adjustments. -- 5" Spiral cutterhead with 4-sided carbide inserts provide precise, efficient planning with low noise levels. -- With (4) each 4" diameter dust outlets. -- Sectional steel infeed roller & segmented chipbreaker. -- Independently adjustable feed rollers. -- (2) Externally adjustable bed rollers. -- Hinged top for easy access to cutterhead & gear assembly. -- Self-braking motor. -- Magnetic starter & thermal overload switch. -- Emergency stop. -- Operations manual, parts list & tool kit. Machining Specifications: -- Max. Cut Width 52". -- Max. Cut Thickness 8". -- Max. Cut Depth ¼". -- Min. Cut Length 9". -- Cutting Speed 3,600 RPM. -- Table Size (W x L) 55" x 55". -- Main Motor 25 HP, 3 Ph. -- Feed Motor 5 HP. -- Table Raising Motor 1 HP. -- Feed Rate (Variable) 0 ~ 50 FPM. -- Shipping weight 7,400 Lbs.

CAM-WOOD PL-24 TOP & BOTTOM STRAIGHTENING PLANER8" x 24" Capacity Planer for accurate and powerful two-sided planing in one pass.Includes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $2,000 Specifications: -- 25"; Max. Planning Width, 3/8" to 8"; Max. Planning Thickness. -- 1/4";Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 70 FPM Feed Speeds (Variable). -- 4,200 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges -- 25 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor and 1/2 HP Elevation Motor. -- Net weight 7,200 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-fre

CAM-WOOD PL-18 18" Wide Top & Bottom Straightening Planer. -- 18" Planer with straight knife heads with HSS knives for accurate and powerful two-sided planning in one pass.ADD for Spiral Heads with Carbide Insert Knives... $3,200.00Specifications: -- 17-3/4"; Max. Planning Width. -- 3/8 to 8" Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 10"; Min. Planning Length. -- 15 to 70 FPM Feeding Speed (Inverter Driven). -- 4,200 RPM Cutter Straight Knife Head Speed. (6,000 RPM for Spiral Cutter Head). -- (4) Knife Cutterheads. -- 15 HP Upper Motor. -- 10 HP Bottom Motor. -- 2 HP Feed Motor. -- 1/2 HP Elevation Motor. -- Table Size (L x W) 88" x 16". -- N.W. 6,500 Lbs.Features: -- Standard equipped with automatic thickness controller, easy, accurate and quick setting for the cutting thickness. -- Upper & lower straight knives or spiral cutterheads for accurate and powerful two-sided planing in one pass. -- The worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planning. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing of the surface can be performed to prevent jumping during processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with heavy-duty drive chains and gears to provide a smooth even feeding during rough or finish planning. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- The heavy-duty rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial motor for maximum cutting capacity. -- All precision sealed long-life bearing for durability -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Changing the knife on the upper cutterhead only requires removal of the upper dust chute. -- The optional spiral insert head design allows for fast, accurate insert changes and minimum down time. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth chatter-free planing regardless of the feed rate or hardness of material being planed. -- A powerful motor is utilized to make adjustments quickly

CAM-WOOD PL-38 TOP & BOTTOM STRAIGHTENING PLANERIncludes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Insert Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $10.00 EACHSpecifications: -- 3" to 38"; Max. Planning Width -- 3/8" to 8"; Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 52 FPM Feed Speeds (Variable). -- 4,000 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges 40 HP Top Head Motor. -- 25 HP Bottom Head Motor. -- 5 HP Feed Motor -- 2 HP Elevation Motor. -- Net weight 9,900 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-free planing regardless of the feed rate or hardness of planed material. -- 1/2 HP Motor provides quick and accurate top head thickness adjustments.

CAM-WOOD MODEL WP-4S 650 2C 25"-20 4-SIDED PLANER WITH MOULDING CAPABILITIES: Designed for heavy furniture, cabinet, flooring, intermittent planing millwork, and other industrial uses. Perfect Planer for S2S and S4S planing up to 16" high x 25" wide timbers, tongue & groove flooring, wall paneling, etc. up to approximately 75 FPM depending on depth of cuts and dimensions of parts.SPECIFICATIONS: -- Width capacity from 2-3/4"; to 25";. -- Thickness capacity from 3/4"; to 20";. -- Feed speeds variable from 18 to 65 FPM -- 30 HP Bottom head motor -- 30 HP Top head motor -- 20 HP Left (outside) spindle motor -- 20 HP Right (inside) spindle motor -- 1/2 HP motors on right & left champhering (top eased edge) spindles -- (2) X 7.5 HP feed motor -- 5"; dia. top and bottom cutterheads -- 5"; or 6"; dia. right & left cutterheads -- 60 mm (2.362";) dia. spindles on top and bottom heads -- 40 mm (1.574";) dia. spindles on top and bottom heads -- 30 mm (1.181") champhering spindles -- 15 x 15 x 2.5 mm insert knives -- (4) Dust outlets, each 6"; diameter -- Planer measurements: 110"; long x 91"; wide x 94"; high -- Planer weighs 19,500 Lbs. FEATURES: -- Compact construction with planing and moulding capabilities; provides flexible performance at an affordable price -- Equipped with a digital controller to set thickness & width automatically -- Rigidly mounted alloy steel spindle with outboard bearing support for accurate, vibration-free planing surfaces on horizontal spindles -- Spindle height adjustment by precision rack & pinion gear sets. -- Bedplates are precision ground, chrome-plated and polished to a mirror finish; provide a smooth, wear-resistant surface -- Variable speed inverter control for smooth feed speed adjustment depending on lumber hardness, depth of cut & width. Speed adjusts to provide the best finish and highest speed for best overall performance. -- Feed rolls are driven by geared transmission boxes and drive shafts with heavy-duty universal joints and drive shafts; provide smooth, even feeding for rough or finish planing -- Heavy fabricated steel plate frame, heated and stress relieved for vibration-free finishes, supports the worktable and helps dampen vibration for a superior finish. Ensures years of dependable service -- Industrial-grade, standard off-the-shelf motors for maximum cutting capacity and ease of service -- Bearings are precision, sealed, long-life bearings for durability and service life -- Removable cutterheads on all spindles, designed for convenient knife changing or rotating, including the bottom head. -- Changing or rotating knives on the top head only requires removal of the dust hood -- 4-Row spiral insert knife head design allows fast, accurate insert knife changes and minimum down time. Uses standard 15 x 15 x 2.5 mm insert knives -- Minimized setup time on top head when using the auto material thickness device -- All cutter heads are precision balanced to provide consistently smoo

CAM-WOOD SM-124TAX 4-Sided Planer/Moulder; 11-3/4"; Wide x 4" to 9"; HighCompact construction with moulding & planing capabilities and flexible performance at an attractive price. Designed for furniture, cabinet, and yes, even industrial arts and large hobby shops. The perfect machine for tongue & groove flooring, wall paneling, S4S work, etc. Specifications: -- 2-Sided Planing Capacity: 7/16"; to 9"; thick x 11-5/8"; wide -- 4-Sided Planing Capacity: 7/16"; to 9"; thick x 10-1/4"; wide. -- All cutters run at 7,000 RPM -- Top and bottom heads are 2-27/32"; (72 mm) diameter. -- Right and left side heads are 3-1/2"; (90 mm) diameter -- All spindles powered by 4.1 HP (3 kW) motors -- Top Spindle will profile to a 3/8"; pattern depth and 5/16"; max. stock removal when planing. -- Bottom Spindle will profile to a 3/16"; pattern depth and 3/16"; max. stock removal when planing. -- Right & left side spindles are 4"; long and have a max. moulding depth of 13/16";. -- Machined and hard chromed table is 24"; wide x 40"; long and travels 9"; (230 mm) vertically -- Feed system runs at 11 to 52 FPM and is powered by a 1/2 HP variable speed drive. -- Overall dimensions are 54"; long x 42"; wide x 44"; high and weighs 1,370 Lbs.Features: -- Large 11-5/8"; wide x 9"; thick 2-sided planing capacity or 10-1/4"; wide x 4"; thick 4-sided planing and moulding work. -- Individual motors drive each spindle; 7,000 RPM spindle speeds on all heads. -- Mechanical meter for accurate thickness adjustments. -- Heavy-duty spindle assemblies for durability & run-out free finishes. -- Rigidly mounted alloy steel spindles in precision bearings provide accurate and vibration-free power transfer. -- Spindle height adjustment by precision rack & pinion gear system. -- Compact construction, Heavy-duty welded steel frame and See through top guard. -- Magnetic overload switch for protection. -- Industrial-rated TEFC motors with sealed-for-life ball bearings.

CAM-WOOD PL-12SX 12" Wide Top & Bottom Straightening PlanerFeatures & Equipped with: -- Spiral Insert Cutterheads. -- Standard equipped with Automatic Thickness Controller, easy and quick setting for the cutting thickness. -- Top & bottom carbide cutter heads for accurate and powerful two-sided planing in one pass. -- Auto digital thickness control for quick and accurate setup. -- The worktable surface was precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planing. -- Variable speed control by inverter for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The in-feed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then an accurate planing surface can be performed to prevent jumping during the processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with a heavy-duty drive chain and gears to provide a smooth even feeding during rough or finish planing. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload Specifications: -- 7-1/2 HP Top Head Motor -- 5 HP Bottom Head Motor -- 12-1/2"; Max. Working Width -- 4-3/4"; Max. Working Thickness -- 19/32"; Min. Working Thickness -- 13"; Min. Working Length -- 1/4"; Max. Cutting Depth per Head -- 2 HP Feed Motor -- Feed Speed (Inverter drive) from 15 to 52 FPM -- 5,000 RPM Cutter Head Speed -- 1/2 HP Elevation Motor -- With (2) 6" diameter dust outlets -- Spiral Insert Cutterheads with (45) 12 x 30 x 1.5 mm carbide insert knives with (2) cutting edges. Allows for fast, accurate insert changes and minimum downtime -- If required, change of electrics, will be quoted separately

CAM-WOOD PL-43-SX 43" TOP AND BOTTOM SURFACER with Spiral CutterSPECIFICATIONS: -- 40"; Maximum Working Width. -- 3/8" to 8" Maximum Working Thickness. -- 1/4"; Max. Depth of cut (Per Side). -- 4,000 RPM Cutter Head Speed. -- 6-1/4"; Cutter Head Diameter. -- 15 x 15 x 2.5mm Spiral Cutter Head Carbide Insert Knives. -- 40 HP Top Cutter Head Motor -- 30 HP Bottom Cutter Head Motor -- 2 HP Elevation Motor -- (1) 7.5 HP Feed Motors -- Feed Speed (Variable by Inverter drive) from 15 to 52 FPM -- 5-3/4 Feed Roll Diameter. -- Universal Joint & Shaft Drive System. -- Machine Weight, 11,600 Lbs. -- Machine Size (L x W x H) 81" x 106" x 63". FEATURES: -- Roll feed eliminates slipping when running green and heavy wood. -- Universal Joint and Shaft Driven Feed Rolls ensure adequate feeding power for wet, rough lumber as well as warped, cupped and bowed material and provide needed power transmission against heavy cutting depths. -- Top and bottom feed rolls are directly driven by universal joints and drive shafts for full-power transmission. -- A movable control box provides additional convenience in operation and setup. -- Standard equipment includes automatic thickness control to aid in easy and quick setting for the thickness to be planed. -- Worktable surface is precision ground and electric chrome-plated and polished to a smooth mirror finish. The durable wear-resistance surface is easy to clean and maintain and promotes good feeding of all types of wood. -- Stepless variable speed control (VFD) for smooth adjustment of feed rate depending on the material hardness, depth of cut & width. Used to provide the best finish surface and fast feed performance. -- Twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- Heavy, rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial-duty motors for maximum power transmission. -- All precision sealed, long-life bearings for durability. -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth, chatter-free planing regardless of the feed rate or hardness of material being planed.

CAM-WOOD MODEL PL-52 SHX TOP AND BOTTOM SURFACERSpecifications: -- 52"; Maximum Working Width -- 12-1/4"; Maximum Working Thickness -- 1/2"; Minimum Working Thickness (3/8" on request) -- 1/2"; Max. Depth of cut (Per Side) -- 4,000 RPM Cutter Head Speed -- 6-1/4"; Cutter Head Diameter -- 15 x 15 x 2.5 mm Spiral Cutter Head Carbide Insert Knives -- 40 HP Top Cutter Head Motor -- 30 HP Bottom Cutter Head Motor -- 2 HP Elevation Motor -- Feed Speed (Variable by Invertor drive) from 12 to 55 FPM -- 5-3/4 Feed Roll Diameter -- (2) 5 HP Feed Motors -- Machine Weight, 15,700 Lbs -- Machine Size (L x W x H) 81" x 112" x 63" Features: -- Roll feed eliminates slipping when running green and heavy wood. -- Universal Jointed Shaft Feed Rolls to ensure adequate feeding power for wet, rough lumber as well as warped, cupped and bowed material for heavy cutting depths -- Top and bottom feed rolls are directly driven by universal joints and drive shafts for full-power transmission. -- Movable control box provides additional convenience in operation and setup. -- Standard equipment includes automatic thickness control to aid in easy and quick setting for the thickness to be planned. -- Worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear-resistant surface is easy to clean and maintain and promotes good feeding of all types of wood. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width. Used to provide the best finish surface and fast feed performance. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- Heavy, rigid cast iron frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial-duty motors for maximum power transmission. -- All precision sealed, long-life bearings for durability. -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth, chatter-free planing regardless of the feed rate or hardness of material being planed.OPTION: -- 600 volts 3 phases 60 HZ additional: $2,100

EFLA - BT20 SP - 1/R: Combination Differential/Filling MachineOne of the best units ever produced! -- Dual purpose machine can be utilized as:Standard differential Roll Coater for application of U.V. sealer or topcoat material. As a differential Roll Coater, the 1st application head is independently utilized for precisely controlled application.Filling Machine. For application of U.V. filling material to calibrated substrates with porous veneer. As a filling machine, both heads are utilized for application & reverse smoothing or pressing of U.V. filling material. -- Features: 2-Head, 53" width cap.1st Head: 250 mm (9-3/4") Dia. rubber coated applicator roller; (40 shore) w/separate doctor roller.2nd Head: 245 mm (9-5/8") Dia. chromium coated smoothing/reverse roller; separate chromium doctor roll: 0 - 100 mm (3-3/4") Adjustable opening (manual).HP Conveyor Drive. Variable feed speed from: 26 - 131 FPM; 1/2 HP variable RPM drive on doctor rolls; separate 3/4 HP drive on applicator & reverse rollers; 880 mm (34-1/2") working/pass through height. -- Electrical Power: 480 V - 3 Ph (3.8 kW - 7 amps). -- Includes: Wheels & rails for removal of the Line; has its own operator Control Panel. -- Plus: Pneumatic emergency lifting in case a part is misfed or too thick for the setup.NOTE: Equipment is a Brazil version of the model. all specifications should be the same, but there may be a small variation in details.

CEFLA 5 Ft. Wide Single Lamp UV OvenGreat for handing those "extra wide" Panels!Features: -- UV-R Super Focus: This configuration is suitable for reducing the heating effect of the lamps on artifacts sensitive to high temperatures (e.g. resinous wood). -- The particular shape of the lamp parabolas focuses the UV ray beam at the same point of the panel, allowing to reduce significantly reducing the number of lamps needed to dry the paint and avoiding the dispersion of rays, also guaranteeing significant savings in terms of space and energy consumption. -- This configuration can be integrated with the "SMART-THICK" system for adjusting the thickness of the pieces in line, usually on roller application lines.UV-R SP: Allows the cross-linking of the paint applied even on the edges of the pieces, thanks to the use of inclined lamps and a greater energy impact of the lamps themselves on the edges.UV-R: Equipped with an electronic system for regulating the power of each lamp; it also allows you to automatically activate the energy-saving function by checking the presence of material under each lamp.The Electrical Panel is integrated into the machine body and does not require additional spaces in the line layout.

2019 CEFLA, model ROC 3 D. Reciprocating Spray Machine:This sprayer can easily run at 30 feet per minute Machine consists of --a tilt-able up infeed belt conveyor with the Electronic Reading bar located over the entire width, this bar reads the parts as they enter the machine which controls the Gun spray pattern. --Parts are fed through the spray cabin by means of a Patented continuous CFB belt conveying system. --Sprayer is equipped with (2) two roll Overspray recovery systems. Belt cleaning is done by means of a counter-rotating roller's with scraper and belt cleaning unit. The rollers are fitted on the "cleaning" trolley which is pulled out from under the machine longitudinally by manual control. Motorized outfeed belt conveyor, tilt-able up to make access to the cleaning trolley easy. -- (2) Oscillating arms equipped to accept a maximum of (8) guns, driven by a Brushless motor's, the PLC in the control panel automatically triggers the guns based on thier size and location on the belt. -- This sprayer has (2) two separate lacquer feeding circuits and a pressurized cabin with both incoming air filtration and exhaust filtration. -- Air is pulled in from (2) air intake ducts (positioned between guns) above the slanted perforated top panels, perforations help to reduce turbulence -- Large front viewing window/access panel.

CEFLA - MITO, ...Complete Spraying System with SORBINI Cleaning Brush.Reciprocating Feed Through System for Waterborne & Solvent-Borne Coatings: The max. flexibility and technology for the continuous spraying of any kind of raised panels.Features: -- Machine designed with a solid structure: LASER 3D; full accessibility, thanks to the wide use of glass superficies, access doors, and extractable parts. -- Conveying System with: CFB Belt with sealed edge, driven by inverter. -- Axis driven by the powerful brushless motor and by a sophisticated toothed belt handling system, with recycling sphere bearings. The best performances in speed, acceleration, and the softness in guns motion allows to achieve the max. application quality. -- The central axis holds: (1) Gun supporting arm (removable), equipped with quick-release (predisposed for max. 4 guns); complete with: Manual height adjustment, (3) high pressure lacquer feeding circuits with recycle; lacquer filters with stainless steel fittings. -- Exclusive pressurization flows analysis and sophisticated air diffusion plenum with double fan for air intake and filtration results in: Higher lacquer saving, better machine cleaning. Circulation provided by floor mounted MZ RLQ 560, Direct-drive 4 KW , 1755 RPM motor. -- Tanks with supporting areas for filters by COLUMBUS or ANDREAS-type filters.Electronic Scanner for: Shape reading and workpieces positioning; max. efficiency in managing the guns' spraying.TECHNICAL FEATURES:Total length of the machine: 4,650 mmTotal width of the machine: 3,850 mm (4,210 mm with fan)Machine structure height: 2,500 mmElectronic control unit with: PLC and software for machine managing.Main control cabinet: Pressurized, placed at the machine infeed, along the service side complete of cable and wiring system for connection to all the users.Spraying parameters management is operated by PLC:Working programs setup, measurements of the lacquered surface & lacquer consumption, 5" color touchscreen display for diagnostic and control; possibility to exchange data from and to PLC managing complete Lines.Possibility to manage pumps for color change/washing (up to 4 pumps). -- Comes with: 2006 SORBINI/CEFLA VS/33-ACT-F, 460/3/60 Panel Cleaning Brush with brush for the top roll followed by a nozzle blow off station. (1) Head, 53" width cap. Top brush head; features timed rotating air blowers, air liner blower with nozzles. Upper mounted Anti-static ionization bar; 400 RPM brush speed.With CEFLA TM 3000, 600/3/60 V, infeed belt conveyor. -- Line is disconnected/dismantled per last (8) photos.

CEFLA "ROTOSTAIN RT 2000 10 + 10 Rotary Stain Machine with: -- 20 Guns; utilized for automatic application of stain material on workpieces; the "Roto-Stain ROT 10 + 10" represents a new generation Spray Machine from CEFLA, the leader in CEFLA "ROTOSTAIN RT 2000 10 + 10 Rotary Stain Machine with: -- 20 Guns; utilized for automatic application of stain material on workpieces; the "Roto-Stain 2000 10 + 10" represents a new generation Spray Machine from CEFLA, the leader in technology development for spraying applications. -- The "Roto-Stain 2000 10 + 10" incorporates CEFLA's previous innovative developments into a machine with maximum capabilities (line speed and production output) for stain application. -- Continuous 65" width carbon fiber belt enables the recovery of over sprayed coating material for reuse. -- Cefla's patented conveyor belt system for coating recovery and belt cleaning is controlled by the PLC and recovers approximately 98% of the coating material deposited on the belt, which is then automatically cleaned with "Coating Appropriate Solvents" -- The automatic air flow system monitors and maintains consistent air flow/pressurization through spray booth. When filters become too plugged to maintain sufficient air flow, system operation is ceased --electronic control unit utilizes a 60 cell photodiode bar to monitor and regulate spray application, further maximizing application transfer efficiency -- Spraying is performed through a rotary system designed for the installation of ten plus ten (10 + 10) guns in (2) coating supply circuits with recycle.TECHNICAL SPECIFICATIONS: Working width from 0 - 1300mm ( 0 - 51") Minimum workpiece length 305mm (12") Speed range from 2 - 11 m/min (6.6 - 36 ft/min) Power consumption 10.7 kW Compressed air required 50 NI/min (1.8 cfm) Exhausted solvent /air mix 10000 mc/h (5886 cfm)

CEFLA ROCTRE D Automatic Spray Finishing Machine: for HIGH VOLUME PRODUCTIONThickness: Max. 50 mm (2"); Min. 5 mm (0.2").Maximum Line speed: 20 MPM (65 FMP).Equipment Specifications:CEFLA, model ROC 3 D. Is a Two Arm reciprocating Spray Machine: -- Parts are fed under the Part Reading Bar to measure size and spray parameters on a continuous CFB belt conveying system. -- Lacquer recovery and belt cleaning are accomplished by means of a "cleaning trolley" located under the exist end feed belt. Made up of counter-rotating rollers with scraper and belt cleaning unit, with 3 rollers and stainless-steel troughs: all the rollers are fitted on the motorized trolley longitudinally removable by hand pulling of trolley out. -- Powered outfeed tilt able belt lifts to approach the cleaning trolley. -- (2) Oscillating arms equipped to accept a maximum of (8) guns, four per arm and driven by a Brushless servo motor.There are (2) Separate lacquer feeding circuits with recycling system. -- This is a fully pressurized spray cabin with an exhaust air filtering system for overspray using double dry filters set, primary filter and secondary . -- Electronic control cabinet to monitor spraying functions.Booth consists of sandwich paneling and air is pushed in through (2) air intake ducts (positioned between guns) above the slanted perforated top panels made up of fine filter material help to reduce turbulence. parts running through the sprayer can be viewed by means of a large front viewing window/access panel which can be lifted to access the guns and interior of the sprayer. Note: EX-FACTORY’s Logistic Department is experienced and set up to provide “Full Service Logistic"; from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.

CEFLA ROCTRE D Automatic Spray Finishing Machine for HIGH VOLUME PRODUCTION and includes (2) two integrated cleaning trolleysThickness: Max. 50 mm (2"); Min. 5 mm (0.2").Maximum Line speed: 20 MPM (65 FMP).Equipment Specifications:CEFLA, model ROC 3 D. Is a Two-arm reciprocating Spray Machine: -- Parts are fed under the Part Reading Bar to measure size and spray parameters on a continuous CFB belt conveying system. -- Lacquer recovery and belt cleaning are accomplished by means of a "cleaning trolley" located under the existing end feed belt. Made up of counter-rotating rollers with scraper and belt cleaning unit, with (3) rollers and stainless-steel troughs: all the rollers are fitted on the motorized trolley longitudinally removable by hand pulling of trolley out. -- Powered outfeed tilt-able belt lifts to approach the cleaning trolley. -- (2) Oscillating arms equipped to accept a maximum of (8) guns, four per arm, and driven by a Brushless servo motor.There are (2) Separate lacquer feeding circuits with recycling system. -- This is a fully pressurized spray cabin with an exhaust air filtering system for overspray using a double dry filter set, primary filter, and secondary. -- Electronic control cabinet to monitor spraying functions.The booth consists of sandwich paneling, and air is pushed in through (2) air intake ducts (positioned between guns) above the slanted perforated top panels made of fine filter material, which help to reduce turbulence. Parts running through the sprayer can be viewed by means of a large front viewing window/access panel, which can be lifted to access the guns and interior of the sprayer. Photos show equipment while it was still in service - currently being reconditioned.Note: EX-FACTORY’s Logistics Department is experienced and set up to provide “Full Service Logistics"; from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door).

CEFLA - EASY 2000 D: Finish SystemCEFLA - Easy 2000: Reciprocating Spray Machine. 2-Arm dry filter Reciprocating Spray Machine with: (3) Independent paint circuits; allows several different coatings to all applied using the same machine with reasonably quick-change over. Parts are electronically scanned as they enter the spray cabin: To lower waste & increase spraying efficiency.Spray guns are: All electronically controlled at the "Easy lCD" interface panel.Spray Cabin. Setup with the CEFLA Recovery System. Means: No paper belt to change maintaining a "Clean" feed belt. The positively pressurized cabin helps both: Control dust & direct overspray down into the dry paper filters. Machine: Completely reconditioned with many new parts including: All belts. Air & Fluid lines. Pumps for the cleaning trolley. Filters. Wear parts.
