WEEKE ABD 050 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; with servo control of the "X" Axis; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 20 mm - 800 mm (.75" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) pneumatic top clamps can process up to (2) parts independently on the left-hand, right-hand or center stops; work pieces can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging.17" TFT flat screen monitor, CD-RW drive, 1.44 MB floppy drive, standard keyboard & mouse; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:Bar code control reader. All manuals, documentation & program disk provided with machine. -- Actual Model is WEEKE ABD 050.

WEEKE ABD 050 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; with servo control of the "X" Axis; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 20 mm - 800 mm (.75" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) pneumatic top clamps can process up to (2) parts independently on the left-hand, right-hand or center stops; work pieces can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging.17" TFT flat screen monitor, CD-RW drive, 1.44 MB floppy drive, standard keyboard & mouse; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:Bar code reader. All manuals, documentation & program disk provided with machine. -- Actual Model is WEEKE ABD 050/12/NA.

WEEKE BHP 100/VANTAGE 480 FLAT TABLE MACHINE, with ATC, Boring, Infeed Roller & Outfeed & 4,771 Hrs. (As of 10/31/23) -- Specifications:4' x 8' Bridge style gantry machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Area:'X" axis 99.21" (2,520 mm), "Y" axis 49.21" (1,250 mm), Max. material thickness of 3.94" (100 mm). -- Travels:“X"; axis 146.06"; (3,710 mm), “Y"; axis 81.30"; (2,065 mm), “Z"; axis 13.70"; (348 mm) Routing, 8.46"; (215 mm) Boring. -- Positioning Speed:"X" & "Y" axis Vector speed is 314 FPM (96 MPM), "Z" axis 65 FPM (20 MPM);The head travels via AC brushless drives & THK linear motion guides on all axes. -- Worktable:User-Friendly "S/C Tech "MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(2) Fixed LH side & (2) Fixed RH side pneumatic pop-up positioning stops. -- Boring Unit:(1) 3 HP (2.3 kW) Motor, variable speed for 1,500 - 7,500 RPM;(21) Independent vertical spindles with (8) in "X" axis, (9) in "Y" axis (1st Row), & (4) in "Y" axis (2nd Row). -- Machining:(1) 12 HP (9 kW) Air Cooled High speed constant duty Router with HSK F63 adaptor,1,250 - 24,000 RPM, constant torque achieved at 9,000 RPM, RH or LH rotation(1) 14-Position tool changer Carousel located at the back side of the spindle carriage. -- Machine & Operator Control:PC Front-End with WEEKE "Power Control + Windows + WoodWOP operating system.17" TFT Color graphic monitor, Hand-held control pendant, Foot pedal control;"BECKHOFF" Programmable logic control for (3/4) axes, linear, circular & helical interpolation;The controller is contained in a separate free-standing, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: 488"; W x 96"; L Infeed electric/hydraulic Scissor Lift platform, with 3"; x 3"; Support beams on 7"; Centers; 4’ L Roller track intermediate table; vacuum arm with (2) 10"; dia. vacuum pads; rake off-feed System; 49"; W x 10’ L x 36"; H Outfeed motorized belt conveyor. BUSCH "MM 1322 A VM3" 10 HP (7.6 kW) 300 mbar Vacuum Pump; 6’ H Safety fencing. -- Actual model is WEEKE BHP 100/VANTAGE 480Machine Dimensions: 292"; x 202"; x 96"; H.Machine with Scissor Lift Dimensions: 389"; x 202"; x 96"; H.

WEEKE VANTECH 512 CON2/BHP 008 FLAT TABLE MACHINE (W/ATC/BORING): + AUTO IN-FEED/RAKE/OUT-FEED: -- Specifications:5' x 12' Flat Table "Bridge Gantry" machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Capacity: "X" Axis 156.7" (3,980 mm), "Y" axis 61" (1,550 mm), "Z" axis stroke is 9.6" (243.8 mm); max. material thickness is 3.9" (99 mm). -- Positioning Speed:"X" & "Y" Axes 315 FPM (96 MPM); "Z" axis is 82 FPM (25 MPM).The head travels via AC brushless drives & THK linear motion guides on all axes. -- WorktableUser-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(6) Pop-up pneumatic locator/positioning on the front side & (1) on the back side in "X" axis & (2) pop-up pneumatic locator/positioning pins on RHS facing side in "Y" axis.(4) Vacuum Table work zones can be used independently or together for full table area Foot pedal vacuum zone controls. -- Boring Unit1.5 kW (2 HP) Motor, with "Quick Change" drill bit holders; programmable variable speed from 1,500 - 7,500 RPM; -- Machining(1) 12 HP (9 kW) High speed constant duty, variable speed electro-spindle router with "HSK F 63" adaptor.Router is programmable from 1,250 - 24,000 RPM, RH or LH rotation.(1) 10-Position ATC rack located at the end of machine. -- Operator InterfacePC Front-End with: WEEKE "PC 85T" + "Windows XP" + WoodWOP Operating System.17" TFT Color graphic monitor; keyboard for data entry; PC 85T hand control pendant; central USB hub; Ethernet interface for LAN connection to office PC; RS-232 serial interface.BECKHOFF Programmable logic control for (3/4) axes, linear, circular & helical interpolation; the controller is contained in a separate freestanding, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: (4) 100 cbm/Hr Vacuum Pumps; safety light curtain (the machine will stop when the Operator enters the work area); safety fencing; separate control cabinet. - Manuals & Documents -- Options Include: NC Controlled Touch-Off Tool Probe, length measuring device. (1) NC controlled scissor lift/vacuum in-feed device. (1) NC controlled, powered flat belt outfeed table with Automatic Dust Control Vacuum Sweep Arm Rake system. Laser fence surround for safety -- Actual Model is: WEEKE VANTECH 512 CON2/BHP 008.

WEEKE BHC 350 4/10 CNC MACHINING CENTER: Specifications: -- Working cap.:"X" axis: 3,750 mm (147.6"), "Y" axis: 1,250 mm (49.2"), 80 mm (3.1") max. material thickness. -- Positioning Speed: "X" axis is 196 FPM (60 MPM), "Y" axis 164 FPM (50 MPM) & "Z" axis 66 FPM (20 MPM). The heads travels on THK linear motion guides on all axes. -- Worktable: (6) Moveable support rails, raise-and-lower panel feeding rails, (3) matrix style vacuum pods per rail.(6) Pneumatic backstops, (6) Pneumatic front stops, (2) movable pneumatic side stops, and the dual central zero-stop creates (2) working zones. -- Boring Unit:(1) 3.5 HP, 1,500 - 7,000 RPM Motor; equipped with (24) independent vertical spindles with (16) spindles in "X" axis & (8) spindles in "Y" axis.(4) Horizontal spindles with (1+1) in the "X" axis & (1+1) in "Y" axis;(1) "X" axis grooving saw for max. 100 mm dia. blade, 2,000 - 7,000 RPM. -- Machining:(1) 8 HP HSK F63 Liquid cooled electro-spindle powered by KEB frequency inverter, programmable from 1,200 - 18,000 RPM (constant torque from 9,000 - 18,000 RPM), RH or LH rotation. -- Operator & Machine Control:IPC control with "WEEKE MCC" + Windows "XP" + WoodWOP 5.0 operating system; 15" high resolution color graphic monitor, standard keyboard & mouse for data entry, 1.44MB floppy disk drive, CD ROM drive.EtherNET interface for possible LAN connection to office PC, RS-232 serial interface for simple PC connection; all mounted in separate free-standing control cabinet.WoodWOP allows for the machine to be programmed off-line with the same intuitive icon driven software that the operator has on the machine controller."BECKHOFF" programmable logic control (PLC) operating system for (3) axes; linear, circular & helical interpolation. -- Complete with:(1) 100 m³/Hr Vacuum pump, man-height safety enclosure around rear & sides of machine, 2-zone safety mats (will stop machine if operator enters work area). Actual Model is WEEKE BHC 350 4/10 .

WEEKE VENTURE 230 L CNC MACHINING CENTER (W/ATC/BORING/ "C" AXIS): -- Specifications: Working Capacity "X" Axis is 180" (4,500 mm), "Y" axis is 60" (1,500 mm) for boring & 64" (1,600 mm) for routing, "Z" axis stroke is 7.2" (185 mm), max. material thickness 4.9" (125 mm). -- Positioning Speed: "X & "Y" Axis travel speed of 361 FPM (110 MPM), "Z" axis travel speed of 66 FPM (20 MPM);The machine head travels on THK linear motion guides on all axes. -- Worktable:(8) Movable K-Table support rails w/6 side mounted raise-and-lower panel feeding rails, (2) vacuum pods per rail; (8) pneumatic backstops, (2) pneumatic side stops create (2) working zones.Setup assistance through LED displays on the support rails for precise rail & vacuum pod positioning. -- Boring Unit:3 HP (2.2 kW) Motor, variable speed from 1,500 - 7,500 RPM; (21) vertical drill spindles, (11) spindles in "X" axis & (10) in "Y" axis. (10) Horizontal spindles with (3+3) in "X" axis & (2+2) in "Y" axis;(1) NC controlled 0° - 90° "X" / "Y" grooving saw, 125 mm dia. saw blade. -- Machining: (1) 16 HP (12 kW) Air cooled electro-spindle router with HSK F63 adaptor, w/programmable 1,250 - 24,000 RPM, constant torque from 9,000 - 24,000 RPM, RH or LH rotation; powered by a frequency inverter.(1) NC Controlled "C" axis for 360° horizontal processing;(28) Total ATC positions with (1) 14-Position ATC tool changer magazine at the back of the machine head, for "on the fly" ATC.(1) 14-Position ATC Rack mounted on the RH side of the machine -- Operator Interface: WEEKE IPC "PC 85 Power Control" + Windows "XP" + WoodWOP 6.0 operating system; "Beckoff" PLC for (3/4) axes linear, circular & helical interpolation.15" TFT Monitor, industrial keyboard for data entry, CD R/W & 1.44 MB floppy drives, modem, USB slot, RS-232 serial interface for possible simple PC connection; all mounted in separate free-standing control panel. -- Complete with:(2) 100 m³/Hr Vacuum Pump(s), 2-zone safety mats (will stop machine if operator enters work area), safety fences, scrap conveyor, hand held pendant controller. -- Actual Model is WEEKE VENTURE 230 L

AYEN SKB-50 Construction Hole Boring Machine for 32 MM System Boring; -- 50-Spindles total in (2) swivel heads with (25) spindles each, drills vertically from top & horizontally from rear, drills at any angle between 0° - 90° with a positive stop at 45°. -- Equipped with: 50-Spindle swivel head assembly converts quickly into (2) 25-spindle heads for double line boring, 5 1/8" min. distance between heads when line boring. -- Features: 3 HP - 3,450 RPM gear box motor, 39" panel width cap. with a 30-1/4" drilling width. -- Complete with: (2) 39" Fences with flip stops, (3) pneumatic quick-set hold-down clamps, quick fence setting gage, foot pedal control for drilling cycle / head positioning.

--In Auction: https://exfactoryauctions.com/Detail/LC-230120/event/A122024$1--NO RESERVE!-- --SUPER RARE MACHINE-- BACCI T4M-O 4-Spindle Asymmetric Copy Lathe, with Sanding & Enclosure Specifications: Distance between spindle centers 170 mm (6.69"). Max. working height 165 mm (6.50"), Max. copying length 1000 mm (39.37"). Standard cutter dia. 35 mm (1.38"). Cutter holder dia. 145 mm (5.71"). Cutter holder speed 5,300 RPM. Spindle speeds 25 & 42 RPM. Carriage speeds 75 - 200 mm/Min. (2.95 to 7.87 IPM). Equipped with: (4) Duplicating/carving/copy spindles. Complete with: (4) 130 mm (5.12") W Copy Belt Sanders for asymmetrical parts, with 130 x 990 mm (5.12" x 38.98") Belts. 114" x 92" x 88" H Enclosure. NOTE: Larger diameters possible by using every second carriage position, ie. (2) heads instead of (4) heads. Machine weight: 3,330 Lbs. Enclosure weight: 775 Lbs.

This item is in an Auction on exfactoryauctions.com. Go here to view item: http://exf.ac/i6o BACCI MOD Double-Sided Oscillating Slot Mortiser Specifications: Max. slot depth 80 mm (3.15"), Max. slot length 4-3/8". Chuck size 16 mm (0.63"). Max tool dia. 50 mm (1.97"). Vertical table adjustment 100 mm (3.94"). Oscillation range 120 mm (4.72"). Oscillation speed 224 OPM. Equipped with: (2) 8” x 19-1/2” Tables, Each with Tilt 20° Left & Right. 3 HP - 9,500 RPM Spindle motor, 3 HP Oscillation motor. Hydraulic table feed. (2) Pneumatic hold-downs.

BACCI - MOD: Slot MortiserAutomatic double table round end Mortiser; Mortises or bores holes on chair, furniture or case goods.Technical Specifications -- (2) Tables & spindles; (1) table on each side to eliminate dead cycle time. -- 3 HP - 9,400 RPM Motor; spindles belt driven; 3 HP oscillation motor with: (224) Oscillations/Min; spindle movement with: Ball bushings sliding on hardened ground guides. -- Table assemblies hydraulically feed into spindles; in-and-out table adjustment between table & spindle to reduce spindle engagement time; tilting tables: +/- 20° (Side-to-side); overhead pneumatic clamp cylinders. -- 3" Max. slot depth; 4-3/8" max. slot length with: Mechanical digital readout; adjustable without wrenches; 1-15/16" max. dia. tooling, Heavy-Duty spindles with: 16 mm Chucks.

BAKER C 4-HEAD Horizontal Resaw w/Powered Return6" Wide x 12" high cap. Resaw; standard spring blade tensioning system;Specifications: -- 13'-2" x 1-1/4" x 0.035 blade provides thin kerf savings; quick & easy blade height adjustments. -- Wheels: 28" Dia. CNC machined, dynamically balanced, all-steel band wheels, (4) bolt flange; rough top feed belt combines with opposing side feed rolls and air pressure hold over rolls; idler hold downs . -- (4) 20 HP Total Enclosed Fan Cooled Motors; Thin-kerf technology and the Baker Low Profile Flat Guide System generates up to 60-70% less sawdust and up to 25% more boards, easily out-producing a gang rip. Complete with: -- Hydraulic variable feed speed from 20 to 120 FPM (6 to 36 MPM) with a tank, flow control and remote feed shutoff; powered side feed rolls. Includes: -- Powered conveyor, powered return conveyor, NEMA electrical panel with the starters, motor overload protection, remote start/stop stations.6" x 6" Square dust collection with a 90° adapter chute to a 4" dia. outlet (can be rotated in (4) directions); 600 CFM required for each drop.

BAKER BBR-O 2-Head Horizontal Band ReSaw Specifications: -- 12" Wide x 12" high cap.; dual 30 HP (22 kW), 3-Ph. TEFC electric motors. -- 28" CNC machined dynamically balanced all-steel band wheels. -- Fully variable speed feed rate from 20-120 FPM controlled by a hydraulic flow valve to dial in your cut quality. -- Adjustable blade guides and spring blade tensioning system. -- Proven workhorse, ideal for sawmills, pallet manufacturers, and lumber processing operations looking to increase efficiency and reduce material waste.Note: Machine in excellent condition, used moderately in an inside operation.AKA Model CX 2-Head

BALEMASTER E-1290 Auto-Tie Horizontal Baler with AMERISHRED AMS-7500 Shredder/Conveyor/TipperBaler Specifications: -- Cylinder: 10" -- Bale size: 36" x 40" x variable -- Motor: 75 HPShredder Specifications: -- Cut: 5/8" -- Motor: 75 HPSystem equipped with: -- Enduraveyor Baler Feed Conveyor -- Discharge Conveyor -- Metering Feed Conveyor -- Cart Tipper

BALEMASTER - 48 X 72, ...Horizontal Closed Door Baler -- Designed for baling of whole or flattened corrugated boxes. -- Large feed opening to accommodate feed of larger material. -- Large 48" x 36" x 72" bale; weighs up to 1,700 pounds. -- Perfect for a Qarehouse application. -- 25 HP Moroe

BALEMASTER - EO-650: Horizontal Auto-Tie Baler Specifications: • 25 HP Motor.• 8"; Main Cylinder.• Hopper Opening: 46";x 50";.• Bale Size: 48"; x 30"; x (variable).• Main Ram Face Pressure: 75 PSI.• System Pressure: 2,000 PSI.• Total Compression Force: 100,500 Lbs.

BALEMASTER - 4550G-10: Auto-Tie Horizontal BalerSpecifications: --27"; x 40"; Opening. -- 50 HP. -- 10"; Cylinder. -- 30"; x 40"; x Variable Bale.

BALESTRINI MINI C 2500 DOUBLE SIDED TEMPLATE PROFILE SHAPERSpecifications: -- (2) Offset shaping heads with 10 HP (7.5 kW), 230/460 volt three phase drives. (1 each side) -- Maximum reciprocating length 98" (2500 mm). -- Maximum height 7" (180 mm). -- Maximum width between spindles 8", and shaping heads are staggered for full end rounding. -- 1¼"; Diameter work arbors with 7″ under the nut capacity, and Spindle speed of 8400 RPM -- Hydraulic stroke of 9-3/4″ wide x 110″ long tee slotted work table, with feed speeds of 3 - 49 feet per minute (1-15 m/Min.) powered by 3 HP, 230/460 volt three phase hydraulic pump -- Overhead beam clamp bar with (4) adjustable clamps. -- Push button operator control station.

Balestrini "MICRON" Slot Mortiser:Sprcifications -- Dual spindle system, (1) each side with tables and overhead holddown, 3 HP - 9,000 RPM spindles, (60 - 350) oscillations/Min, 18 mm collet dia. -- Capacity: 4-23/32" (120 mm) Max. length of slot, 3-1/8" (80 mm) max. slot depth, 1-3/16" (30 mm) max. slot thickness. - Hourly production rate of (500 - 800) slots.

BALESTRINI 2 CAP Mortiser --Automatically mortises or bores round holes in chairs or case good --Specifications -- Twin tables with pneumatic holddown clamps, (1) on each side eliminating dead cycle time, 19" long tables tilt left or right 0ø to 20ø. --Equipped with & Features -- 3 HP - 9,000 RPM Spindle motor and 1 HP oscillation motor. -- Spindles are mounted on prismatic guides with adjustable bronze gibs and move by rack & pinion, -- (120) to (240) oscillations/Min; 4-23/32" max. oscillation length, -- 3-1/8" max. depth, 7/8" max. bit dia., 13 mm spindle collet dia.

BALESTRINI - "MICRON": Slot MortiserSpecifications -- Dual Spindle System (1) Each side with: Tables and overhead holddown; 3 HP - 9,000 RPM spindles; (60 - 350) oscillations/Min; 18 mm collet dia. -- Capacity: 4-23/32" (120 mm) Max. length of slot; 3-1/8" (80 mm) max. slot depth; 1-3/16" (30 mm) max. slot thickness.Hourly production rate: (500 - 800) Slots.
