HOLZ-HER 1315 EDGEBANDER WITH CORNER ROUNDINGMax. 5/16" (8 mm) solid wood banding & 3 mm PVC cap., 1-3/4" max. panel thickness and 5-1/2" min. panel length.Equipped with: -- Cartridge glue system w/cartridge hopper & "quick melt" feature, automatic magazine for coil, strip & solid edgebanding; HD guillotine for 3 mm PVC, glue applicator nozzle. -- Pressure section with (1) large dia. drive roller & (2) idle rollers, each w/individual pneumatic plunge & pressure control, powered 1st roller with electronic speed control synchronized with chain feed speed.Workstations: -- Double motor end trim "1918" (0.5 HP - 18,000 RPM motor ea. 300 Cy HF motors), adjustable 0° - 10° for chamfer cuts electro-pneumatically. -- Top & bottom flush fine & radius trim unit "1942M" (0.8 HP - 300 Cy HF motors 18,000 RPM Motor ea.), bevels 0° - 15°, SIKO digital readouts. -- "Single Station" corner rounding unit for leading & trailing edge. -- "1929" Top & bottom profile scraper for thick PVC. -- Top & bottom buffing unit "1940" (0.25 HP - 2,600 RPM ea.), tilts 0° - 5°. -- Two feed speed 8/16 MPM (26 & 52 FPM), panel overhang beyond chain 35 mm (1.38"). Complete with: -- Operator Touch Screen Monitor Microprocessor for line control & glue temperature, 10 KVA frequency changer, outboard panel support, and sound enclosure w/interior lights over enclosed workstations of the machine & used tooling on the stations.

HOLZ-HER 1411 K-3 SPRINT EDGEBANDER -- Specifications: Cartridge Glue System for EVA & PUR pucks, 5 mm edge thickness cap. (up to 13 mm w/optional tooling), 1.77" max. panel thickness, and 7" min. panel length.Equipped with:Automatic magazine coil & strips, 3 mm PVC cap. pneumatic guillotine for coil cutoff. -- Pressure section with (1) large dia. drive roller & (1) idle. Workstations:Double-motor end trim model "1918" (tilting 0° - 10°), 0.5 HP - 18,000 RPM motor each. -- Top & bottom radius trim model "1942", 0.8 HP - 18,000 RPM motor each (trim motors are 0.6 kW HF). -- Top & bottom glue scraper unit "1929". -- Top & bottom buffing unit "1940" (tilting cap. 0 - 5°), 0.2 HP - 1,400 RPM Motors each. -- Variable feed speed from 36 - 52 FPM. - Fixed outboard panel support. Complete with:PLC (Programmable Logic Control) for easy setup and program storage. -- Frequency converter, sound enclosure, and used tooling.

HOLZ-HER - Sector 1254: Panel Processing & Dust Collection System. Complete Panel Processing & Dust Collection System. Ideal for professional woodworking and cabinet shops. Less than 100) hours of use. -- 1. HOLZ-HER "1254" Vertical Panel Saw: Heavy-Duty steel/aluminum grid support system. Vertical & horizontal precision cuts. Integrated dust port for clean operation. Ideal for sheet goods: MDF, plywood, laminates. -- 2. HOLZ-HER "SuperCut Plus" Lift & Feed System. -- 3. ONEIDA AIR SYSTEMS Cyclone Dust Collector.

HOLZ-HER - DYNESTIC 7505 10.5 Push: CNC Flat Table Machine (w/Rake/Offloading) -- Specifications5' x 10-1/2' Phenolic MATRIX Table for: "Nested Base" Manufacturing. -- Working Area:"X" Axis 122" (3,100 mm); "Y" axis 62.2" (1,580 mm); "Z" axis stroke 12.4" (317 mm). -- Positioning Speed"X" & "Y" Axis 230 FPM (70 MPM); "Z" axis is 65 FPM (20 MPM). -- WorktableFlat table designed for "Nested Base Manufacturing".(4) Pneumatically controlled reference stop pins with: (3) In "Y" axis; (1) in "X" axis. -- Boring Unit2 HP (1.7 kW) motor for spindle speed from 1,000 to 6,000 RPM.(10) Independent vertical boring spindles with: (6) spindles in the "X" axis & (4) spindles in the "Y" axis;(2) Horizontal spindles with: (1 + 1) In "X" axis; (1) "X" axis Saw for max. 120 mm dia. blade. -- Machining Unit(1) 10.7 HP (8 kW) Electrospindle Router with: HSK F63 adaptor; 1,000 - 24,000 RPM.(1) 6-Position Linear ATC tool rack mounted to the machine base. -- Operator InterfacePC Front-End with: HOLZ-HER "CAMPUS V7" Operating system; 17" color monitor; standard keyboard; mouse; USB slots for data entry; (3) axes simultaneous control; feed rate & spindle speed override & axis movement.CAMPUS/NC Hops offers: "Real Time" 2D or 3D graphics; Campus aCADemy is a full-fledged, high-performance CAD/CAM software package with versatile import features. -- Complete with:(2) 140 m³/Hr BECKER Vacuum Pumps with ECOVac Intelligent Vacuum that: Automatically turns on/off vacuum units in reference to required static negative pressure; "forced" lubrication system for guides & ball screw; sound absorbing protective head enclosure. - Perimeter safety devices & fencing. -- Options Include: Pusher/rake offload system with: 5' x 12' Gravity roller conveyor with casters. Vacuum evacuation port for dust extraction & Spoil board from below. -- Actual Model: HOLZ-HER DYNESTIC 7505 10.5 PUSH

HOLZ-HER CUT 85 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications:4,250 mm (167") Max. rip cut cap., 3,800 mm (149") pull back pusher stroke; 97 mm (3.8") saw blade projection.15 HP (11 kW) Main saw motor, 3 HP (2.2 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 328 FPM (1 - 100 MPM ), return speed of 328 FPM (100 MPM).Automatic cutting length limiter adjusts the cutting length at the end of the workpiece, automatic saw carriage lubrication. -- Pusher Fence:(7) Material gripper clamps; 259 FPM (80 MPM) forward positioning speed, 259 FPM (80 MPM) return speed.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with CUTCONTROL "Direct Cut" + "OPTIPRO" + Windows 2000 operating system,15" TFT Display with unlimited program storage via floppy disk, keypad for data entry, USB & RS-232 serial port, CD ROM & 1.44 MB disk drive for additional storage of programs.CUTCONTROL offers Real-Time Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."Direct Cut" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials."OPTIPRO" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting. -- Complete with: Rear roller support rails; automatic crosscut side aligner; automatic saw blade height adjustment.(3) Air support tables, ea. 78" x 24" (1,981 x 509 mm). -- Actual Model is HOLZ-HER CUT 85 4300.

HOLZ-HER CUT 6120 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications: 3,900 mm (153.5") Max. rip cut cap., 3,900 mm (153.5") pull back pusher stroke; 82 mm (3.2") saw blade projection.15 HP (11 kW) Main saw motor, 1.5 HP (1.1 kW) scoring motor. -- Saw Carriage:Variable feed speed from 3 - 320 FPM (1 - 100 MPM ), return speed of 416 FPM (130 MPM).Motorized bi-directional grooving capabilities with electronic adjustment for 0 mm - 35 mm.Automatic cutting length limiter adjusts the cutting height & cutting length at the end of the workpiece. -- Pusher Fence:(7) Material gripper clamps, (1) Double Finger mounted at the cross-cut fence location for narrow strip cutting & (6) standard clamps. 82 FPM (25 MPM) forward positioning speed, 328 FPM (100 MPM) return speed.Variable pressure settings for delicate materials. Pressure beam has an integrated "Last Cut" operation to achieve a "0" mm panel dimension.Rack & pinion movement on both sides to assure the pusher remains parallel. -- Operator & Machine Control:PC Front-End with "CUTCONTROL 2" + "EASY-PLAN" + Windows operating system,19" TFT Display with unlimited program storage; keypad for data entry, USB & RS-232 serial port, "CUTCONTROL 2" offers Real-Time 3D Moving Graphics, diagnostic for errors or machine malfunction by means of an error signal code, incremental or absolute programming in mm or inches."CUTCONTROL 2" allows the operator to easily input information for absolute, serial, format, grooves, perforations, & position cutting which allows the machine to easily adapt to various situations & materials."Opti-Cut" & "EASY-PLAN" is a very user friendly on-board Optimizing System for all types of various cutting patterns, including angled cutting -- Complete with: Non-Marking rear roller support rails: Solid Air Cushion Table before & after the cutting line, ensures easy panel handling. Pneumatic crosscut side aligner, adjustable from 0" - 82.6" (0 - 2,100 mm). Side aligner is "Fully Automatic" adjustment when panel is less than 1,300 mm (51")"Quick Change" Blade system with automatic saw blade height adjustment; Electronic positioning of the scoring blade through the NC control.(3) Adjustable via "pneumatic locking" air support tables, ea. 70.8" x 23.6" (1,800 x 600 mm); -- Actual Model is HOLZ-HER CUT 6120 Dynamic

HOLZ-HER 1435-SE EDGEBANDERCartridge glue system, 5 mm edge thickness cap. (up to 8 mm w/optional tooling), automatic magazine coil & strips, 3 mm PVC cap. pneumatic guillotine for coil cutoff.Workstations: -- Double motor end trim (2) 0.3 HP - 9,000 RPM motor ea.), chamfers 0° - 10° -- Universal top & bottom fine trim (for bevels from 0° - 15°) allows simultaneous bevel & profile trimming, (2) 0.8 HP - 18,000 RPM motor each; all trim motors are 0.6 kW HF - 300 Cy. -- Top & bottom PVC scraper unit for 0.8 - 5 mm radius, with air jets for blowoff. -- Top & bottom "jump" buffing (0.3 HP - 1,620 RPM ea.). -- Single feed speed 35 FPM. --Complete with: --Built-in operator control panel, outboard panel support, frequency converter, used tooling, and sound enclosure.

HOLZ-HER - 1432, ...CP/B Edgebander (Compact) -- Cartridge glue system (single cartridge system); edge thickness cap.: 0.3 to 3 mm (1/8"); max. banding height: 2"; min. panel width: 60 mm; min. length: 180 mm.Equipped with: -- Semiautomatic feed magazine; coil stock feeds automatically with guillotine cutoff; all strip stock is fed manually with pusher bar to advance the edging.Workstations: -- Single motor end trim for leading & trailing edge (trim motor recently replaced). -- Top & bottom flush/bevel trim: 1 HP - 28,000 RPM Motor ea. (recently replaced with BOSCH Trimmer motors). -- Top & Bottom buffing unit: 0.3 HP - 1,620 RPM ea. motor; equipped with: Cotton flap wheels. -- Single feed speed: 16-1/2 FPM.Complete with: -- Sound/safety enclosure; outboard panel support. - Machine is on casters.

HOLZ-HER - 1619, ...Boring Machine (Construction & Line Boring) -- Specifications:(19) Spindles on 32 mm centers; bores vertically from top and horizontally from the rear; repositions via manual air shock assisted tilting.2 HP Motor with: 2,800 RPM Gear driven boring head. -- Features:4-Position turret style depth stop for boring depth and a 4-3/4" max. stroke of boring head.24-3/4" Working width; 27-1/8" max. panel width; 19-1/2"; x 38"; x 32-1/2"; H table size. -- Equipped & Complete with:RH & LH Indexing fence with flip stops; (2) indexing pins (for continuous line boring); (3) 4" dia. pneumatic holddown clamps; foot pedal actuator; magnetic push button starter. -- Actual Model is: HOLZ-HER 1619Dimensions of this specific machine with pallet: 52" x 40" x 65" H.Dimensions of this specific machine when vertical: 52" x 37" x 60" H.Dimensions of this specific machine when horizontal: 52" x 51" x 46" H.

HOLZ-HER 1402 HF Compact EdgebanderFeatures: -- Cartridge glue system, 3 mm edge thickness cap., -- Semi-automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock is fed manually with pusher bar to advance the edging. Digital glue height indicator.Workstations: -- Double motor end trim (1 HP - 10,500 RPM motor ea.) -- Universal top & bottom fine trim (1942M) for bevels from 0° - 15³; allows simultaneous bevel & profile trimming (1 HP - 18,000 RPM motor ea.; trim motors are 0.6 kW HF - 300 Cy). -- Top & bottom PVC scraper unit (1929) for 0.8 - 3 mm radius. -- Top & bottom buffing (1940), 0.3 HP - 1,620 RPM motor ea. -- Single feed speed of 35 FPM. -- Complete with: Fixed outboard panel support, frequency converter, sound enclosure, and used tooling.

HOLZ-HER 1327 SPRINT CLASSIC SPECIAL EDGEBANDER + GLU-JET EVA & PUR GLUING TECHNOLOGY: -- NOTE: This is a "Special Machine for THIN TAPE Only". -- Specifications:Features the: HOLZ-HER Patented dual "GLU-JET" EVA & PUR Zero Joint Technology System.Edgebanding capacity: Edge thickness min./max. 0.4 - 8 mm (0.02 - 0.31"); coiled material 0.4 - 3 mm (0.016 - 0.157").Workpiece thickness: 6 - 60 mm (0.23" - 2.36"); Workpiece width min. of 65 mm (2.56").Workpiece length: Min. 160 mm (6.29"); variable feed speed 10 - 18 MPM (33 - 59 FPM). Machine Infeed -- "Open Space" for Premilling Station "1802": (2) 2.0 kW (2.68 HP) - 12,000 RPM motors.NOTE: This machine is not equipped with the Premilling Station, but it can be added. -- Edge Magazine "1903":For coil & strip processing; utilizes motion detector to ensure accurate, trouble-free positioning of edge material.Exclusive "Tractor Belt Feed System": Edge guide equipped with automatic guillotine lockout for safety.3° Approach angle allows easy feeding of solid wood edges. -- Pressure Section "1913 Mot":1-Axis Servo controlled adjustment of the edge thickness.Pneumatic Plunge controlled pressure section with: (1) Large driven roller and (2) cantered idle rollers. -- Gluing System "GJ301Auto":Glue Jet Hybrid Technology; processes "EVA" or "PUR" glue in cartridge or granulate form.Motorized programmable glue nozzle (upper glue line); height positioning; approx. 3-minute heat up time. Workstations -- End Trimming Unit "1918P": Front & Rear; (2) x 0.45 kW (0.6 HP) - 9,000 RPM each motor.For Straight or Chamfer trimming with: "UNI-POINT Axis for "PCS" pneumatic changeover/swiveling up to 10° bevel. -- Combination Trimming Unit "1827": Top & Bottom; (2) x 0.65 kW (0.87 HP) - 12,000 RPM each motor; for T & B Flush/Bevel/Radius trimming. - "ProLock" Clamping System for rapid tool change.Manual edge radius adjustment up to 3 mm; chamfer adjustment up to 15° with a max. edge thickness of 6 mm. -- "Open Space" for: 2nd T & B Trimming Unit.NOTE-1: This machine is not equipped with the 2nd T & B Trimming Unit, but it can be added. -- "Open Space"for Profile Scraping Unit "1929P". NOTE-2: This machine is not equipped with the Profile Scraping Unit "1929P", but it can be added. -- "Open Space" for Finish Scraping "1964". NOTE-3: This machine is not equipped with the Finish Scraping "1964", but it can be added. -- "Open Space"for Buffing Unit "1940". NOTE-4: This machine is no not equipped with the Buffing Unit "1940", but it can be added. Operator Interface: -- HOLZ-HER "PPC 231" Power-PC + "Windows-like" Operating System. - 15" SVGA Flat "Touchscreen" control.USB Connection & Ethernet network connection ready; programs can be easily created and recalled at will. Graphic interface makes programming easy; icon of each unit may be brought up on the screen to show the Operator the status of the unit and the parameters that can be programmed.Edgebander can be operated manually when required, without necessity to

HOLZ-HER 1488 TRIATHLON EDGEBANDER W/PRE-MILLING & CORNER ROUNDING + LIGMATECH -ZR01 RETURN CONVEYOR: -- SpecificationsWorking Capacity: Max. 1" (25 mm) solid wood banding; thin PVC, Veneer, HPL & 3 mm PVC cap.; 60 mm (2.37") max. panel thickness; 140 mm (5-1/2") min. panel length.Frontend equipped with: -- Premilling Unit: (2) 2.2 kW (3.0 HP) - 12,000 RPM; (1) jump spindle with digital indicators for positioning. -- "ULTRA-GRANUPRESS" Gluing System with: Flat glue nozzle only 3° angle of approach ideal for solid wood edgebanding & "quick melt" feature. -- Automatic Edge Magazine: Coil, strip & solid wood edgebanding with TRACTOR-BELT feed system; Heavy-Duty guillotine for 4 mm PVC. -- Pressure Section: (3) Large dia. rollers, each w/individual pneumatic plunge and pressure control; programmable with Servo motor positioning; powered 1st roller with electronic speed control synchronized with chain feed speed.Edgebanding Workstations -- End Trimming Unit: (2) 0.75 HP - 6,800 RPM ea. "HF" Motors with: "Uni-Point Swivel", quick change from flush 0° - 15° bevel programmable from operator panel; Servo controls. -- Flush Trimming Unit: (2) 2.6 HP - 12,000 RPM - 200 Cy HF motors; Servo controls. -- Fine/Bevel/Radius Trimming Unit: (2) 1-1/2 HP- 12,000 RPM - 200 Cy HF motors; bevels 0° - 45°, Servo controls + SIKO digital readouts. -- Corner Rounding Unit: (2) "HF" Top motors & (2) "HF" bottom motors for trimming leading & trailing upper & lower edge/corners; trailing edge (4 x 3/4 HP - 12,000 RPM - 300 Cy HF motors; 2 mm or 3 mm radius cap. -- Profile Scraper Unit: "Super Duty" for positively smooth finishing thick PVC for radius range from 2 - 5 mm; vertical & horizontal tracing wheels, positioning enabled through (1) Servo motor function from Control Panel; SIKO readouts for easy setup. -- Buffing Unit: (2) Lateral buffing wheel positioning motors with Oscillating & Programmable Jump Action for cleaning & polishing of edges (two 0.25 HP - 3,600 RPM motors); tilts 0° - 5°, Servo controls.Equipped with and Includes: -- "PPC 231" Controller with 15" LCD color screen: 90% of all setups can be adjusted from the Control Panel; programmable for a large variety of edges like solid lumber, veneer strips or coils, HPL, thin & thick PVC; line control so there are no mechanical limit switches along the chain track. -- Variable feed speed from 8 - 20 MPM (26 - 65 FPM); panel overhang beyond chain 35 mm (1.38"); features automatic track pad lubrication. -- Factory Documentation: Operating & Spare Parts Manuals. -- Actual Model is: HOLZ-HER 1488 TRIATHLON + LIGMATECH ZR01

HOLZMA HPP-11-32 OPTIMAT FRONT LOAD PANEL SAW:Specifications & features: 3,200 mm (126") Cutting length & pull-back behind the cutting line; 125 mm (4.9") saw blade projection; 30 HP (22.3 kW) main & 3 HP (2.2 kW) scoring motor. -- Variable saw carriage travel speed from 0 - 410 FPM (0 - 125 MPM), constant return of 410 FPM (125 MPM). -- Equipped with: Main blade 18" (450 mm) dia. and scoring blade 8" (200 mm dia.). -- Electronically controlled overhead pusher fence, rack & pinion drive on both sides by AC Servo motor; forward speed from 0 - 262 FPM (0 - 80 MPM), return speed of 262 FPM (80 MPM); equipped with (8) gripper clamps (open up to 4.7"). -- HOLZMA CADmatic Operating system; 15" color monitor (displays cutting dimensions); data input by keyboard or 1.44 MB floppy disk drive & downloading from office PC is possible. -- Control panel mounted on double swiveling arm for ergonomic positioning by the operator. -- Includes: Combi-rollers rear machine table with profile rails, rollers spaced at 50 mm centers; front with (3) air floatation tables, 85" x 26" (2,159 x 660 mm) each. -- Complete with: Angular square fence, automatic side aligner for crosscutting, (2) aligning devices on program fence; "Quick Saw Changing System" for main & scoring blade.

HOLZMA - HPP 380 32/32: Front Load Automatic Panel SawSpecifications -- 126" (3,200 mm) Rip cutting capacity & pull back; 3.74" (95 mm) saw blade projection.18 HP (13.5 kW) Main saw motor and 3 HP (2.2 kW) scoring motor; scoring saw adjustment via "CADMATIC" control. -- Saw CarriageVariable saw carriage travel speed from: 16 - 426 FPM (5 - 130 MPM); constant return: 426 FPM (130 MPM). -- Pusher FenceElectronically controlled overhead program fence; equipped with: (6) Clamps that open up to 100 mm (3.9").Rack & Pinion driven on both sides; forward speed: 262 FPM (80 MPM); return speed: 262 FPM (80 MPM). -- Operator InterfaceHOLZMA Power Control with "CADMATIC" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory.TFT 17" Flat Screen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard; 1.44 MB Floppy & DVD R/W drives; capable of online operation via RS 232 or USB port for possible link to an office PC. -- Complete with:Automatic "CENTRIC" side aligner with front & rear forks; holding ripped strips squarely against the right-angle fence.(3) Front air flotation tables; 67" x 25" (1.700 mm x 650 mm). Rear support rails with non-marking roller modules. -- Options include:Label Printer as pictured & label printing software -- Actual model is HOLZMA HPP 380 32/32.

HOLZMA - HPP 350 38/38: Front Load Automatic Panel Saw -- Specifications149.6" (3,800 mm) Cut length; 145.7" (3,700 mm) pull back; 3" (80 mm) saw blade projection. 18 HP (13.5 kW) Main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment is from the "CADMATIC 4.0" control. -- Saw CarriageTravel speed: 16 - 492 FPM (5 - 150 MPM); constant return 492 FPM (150 MPM). -- Pusher FenceOverhead program fence with: (7) Gripper clamps; clamps open up to 90 mm (3-1/2"); rack & pinion drive on both sides.Forward speed: 82 to 295 FPM (24 - 90 MPM); return speed: 295 FPM (90 MPM). -- Operator InterfaceHOLZMA "Power Control 22" with: "CADMATIC 4.0 PROFESSIONAL" + "Windows XP" operating system. Virtually unlimited cutting dimensions memory.TFT 19" flat Touchscreen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard; 1.44 MB Floppy & CD ROM drives; capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with front & rear forks holding ripped strips squarely against the right angle fence.(3) Front air floatation tables: 85" x 31.-1/2 (2,160 mm x 800 mm). -- Options Include:Label Printer as pictured. -- Actual model - HOLZMA HPP 350 38/38.

HOLZMA - HPP 350 31/31: Front Load, Automatic Panel Saw -- Specifications122" (3,100 mm) Cut length; 122" (3,100 mm) pull back; 3" (80 mm) saw blade projection.18 HP (13.5 kW) Main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment from the "CADMATIC 4.0" control. -- Saw CarriageTravel speed: 16 - 426 FPM (5 - 130 MPM); Constant return: 426 FPM (130 MPM). -- Pusher FenceElectronically controlled overhead program fence with: (6) Gripper clamps; clamps open up to 90 mm (3-1/2").Rack & Pinion drive on both sides; forward speed: 82 to 262 FPM (24 - 80 MPM); Return speed: 262 FPM (80 MPM). -- Operator InterfaceHOLZMA Power Control with: "CADMATIC 4.0" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory.17" TFT Flat screen monitor; REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard, 1.44 MB Floppy & DVD R/W drives; capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with: Front & rear forks holding ripped strips squarely against the right angle fence.(1) Front air floatation tables: 86" x 25" (2,160 mm x 650 mm); (2) front air floatation tables: 69" x 25" (1.760 mm x 650 mm); rear support rails with non-marking rollers. -- Options include: ZEBRA "Z4M" Plus thermal label printer; (4) sets main/scoring blades; miscellaneous spare parts. -- Actual model: HOLZMA HPP 350 31/31

HOLZMA - Optimat HPP 350 31/31: Front Load Automatic Panel SawSpecifications -- 122" (3,100 mm) Cut length; 122" (3,100 mm) pull back; (80 mm) main saw blade projection; 12 HP (9 kW) main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment from the "CADMATIC 4.0" control. Saw Carriage --Travel speed from: 16 - 426 FPM (5 - 130 MPM); constant return: 426 FPM (130 MPM). Pusher Fence -- Overhead program fence with: (6) Gripper clamps; clamps open up to 90 mm (3-1/2"); rack & pinion drive on both sides; forward speed from 82 - 262 FPM (24 - 80 MPM); return speed: 262 FPM (80 MPM). Operator & Machine Control -- HOLZMA Power Control with: "CADMATIC 4.0" + "Windows XP" Operating System; virtually unlimited cutting dimensions memory; TFT 17" flat screen monitor; REAL TIME moving graphics; panel grooving & numeric display. -- Industrial keyboard: 1.44 MB Floppy & CD ROM drives; capable of online operation via RS 232 or USB port for possible link to office PC.Complete with: -- Automatic "CENTRIC" side aligner with: front & rear forks holding ripped strips squarely against the right angle fence. -- (3) Front air floatation tables: 86" x 25" (2,160 mm x 650 mm). -- Actual model: HOLZMA - OPT. HPP 350 31/31

HOLZMA - HPP 350 38/38: Front Load Automatic Panel Saw -- Specifications149.6" (3,800 mm) Cut length; 3.7" (93.98 mm) saw blade projection. 28 HP (13.5 kW) Main saw motor; 3 HP (2.2 kW) scoring motor; scoring saw adjustment is from the "CADMATIC 4.0" control. -- Saw CarriageTravel speed: 16 - 492 FPM (5 - 150 MPM); constant return 492 FPM (150 MPM). -- Forward speed: 82 to 295 FPM (24 - 90 MPM); return speed: 295 FPM (90 MPM). -- Operator InterfaceHOLZMA "Power Control 22" with: "CADMATIC 4.0 PROFESSIONAL" + "Windows XP" operating system. Virtually unlimited cutting dimensions memory.TFT 19" flat Touchscreen monitor, REAL-TIME moving graphics; panel grooving & numeric display.Industrial keyboard; 1.44 MB Floppy & CD ROM drives; capable of online operation via RS 232 or USB port for possible link to office PC. -- Complete with: Automatic "CENTRIC" side aligner with front & rear forks holding ripped strips squarely against the right angle fence.(3) Front air floatation tables. -- Actual model - HOLZMA HPP 300 38/38.

KOCH BD-A BORING MACH. (FEED THRU CNC): -- Specifications: Model BD-A Boring Machine for straight rail-stock work pieces for Horizontal & Vertical Drilling; Infeed and outfeed pass height is 36.2" (920 mm) . The work pieces are transported through the working stations by means of a cam transport system.Stock is worked in clamped position. -- Stock dimensions: Stock length 9.8" - 59" (250 - 1500 mm), Stock width 1.50" - 9.8" (38 - 250 mm), Stock thickness 0.63" - 1.18" (16 - 30 mm) Note: The specified dimensions do not allow all possible combinations. -- Horizontal drilling station:Each side with (1) drilling unit with 2.7 HP (2 kW) - 3,400 RPM, Each horizontal boring heads with (3) Spindle Type D-1277 boring chucks on 16 mm centers;10 mm dia shank & 70 mm max bit lengthEach head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holesLinear path control for stock transport with low profile machine bed and linear guides, fixed stock stops,Adjustable working stations with motorized width adjustment. -- Vertical Drilling head with rotating device:(2) LH & (2) RH Type D -1277, 2.7 HP (2 kW) Adjustable vertical boring heads with dust extraction hoods & variable speed from 3,000 - 6,000 RPM; Each Drilling chuck with (1) Drilling Spindle per chuck. Drilling Chucks with KOCH "QC" (quick change) system & rotating device each head; 10 mm dia drill bit shank & 70 mm max bit lengthEach head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holesLinear path control for stock transport with low profile machine bed and linear guides, fixed stock stops,Mechanical digital read out for manual finite adjustment, (2) air hold down clamps, foot pedal control to start activation. -- Features:The stationary machine side is on the LH side (seen in transport direction) and not adjustable. The RH is adjustable via NC controlled "X" axis.The machine is equipped with Hopper Feed & has a part stack capacity of approx 9.8" (250 mm) & working capacity of approx 48 Pieces/Min.Stock infeed belts move the workpiece through an intermediate hopper to the stock support. Then the workpiece is transported through the working stations by means of transfer belts with lateral stock alignment; working pass height (36.2" (920 mm).Stock is worked in clamped position; There are stock outfeed belts at the machine outfeed. The workpiece is transferred to the out-feed hopper & removed manually. -- Operator & Machine Control:Beckoff SPS PLC for running the machine. -- Complete With: Open Station to add Dowel Inserting units at a later time ( Dowel units are not included) Manual Hand Pump Central Lubrication system for working units (1) NC controlled positioning of machine RH side (X), LH side is a fixed "0' point. Hopper Rail Feeding devices with capacity of approx 48 Work Pieces/Min. Separate drive for outfeed belt. Center Stock support. -- O

KOCH SPRINT PTP-2 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:Automatic step-by-step, boring, glue injection, and dowel insertion into panel components, drawer parts, chair pieces, etc. at random spacing.Programmed on a 12" color touchscreen monitor pad & stored in built-in CNC control using Windows XP Operating System with graphics & online diagnostic; serial interface & USB connection.Capacity: -- Panel width cap.: 20 mm (3/4") - 1,200 mm (47-1/4") Max. -- Panel Length:100 - 800 mm (4" - 31-1/2"). -- Material thicknes:14 mm - 60 mm (2.4") max. -- Max. boring depth: 50 mm (1-7/8"); standard for 8 mm dia. and 35 mm long dowels. -- 47" X-Axis divided into (2) work zones, 23-1/2" ea.; (1) part can be processed, while the other is being unloaded or loaded. Equipped with: -- (1) Horizontal boring spindle, 6,000 RPM, powered by 1 HP motor. -- (4) Stock clamping cylinders. -- High pressure patented "KOCH ELC" glue injection unit & dowel inserter head. -- Positioning speed of working units at 197 FPM; boring & insertion capacity up to (60) dowels/Min. Complete with: -- Overhead vibrating hopper for dowel feeding. -- "Airtight" pressurized 1:1 glue tank & "ELC" Electronic Glue Detection System (special patented "KOCH design" precision dosing valve w/digital adjustment). -- (2) Fixed fences (RH & LH side); 4-cycle start push buttons; (2) of them ready for center fence mounting to create (4) working fields for fast processing of narrow parts like stretchers, hangers or drawer parts, Center Fence is not included. -- CNC Control w/monitor & touchscreen pad, operator control cabinet, menu driven screen for function control, and graphic illustration of machine functions. NOTE: New glue valve, bucket, hoses & electronic safety sensor installed 2018. -- Actual Model is KOCH "SPRINT PTP-2".
