JLT 78H-16W-84L-40H-M4 Pneumatic Pod Press w/adjustable Opening.Specifications: -- Pneumatic Vertical Clamping System features upper and lower 16" wide and up to 84" long steel platens for face gluing a variety of solid wood components. -- Powered by a total of (18) 20 square inch diaphragm cylinders. -- With it's modular design each section has its own pressure control and 40" opening. -- 16" Wide x 84" Long x 40" High with fixed clamping opening with 1-1/2" adjustable increments. -- Air-operated assembly, for face gluing of engineered stiles & rails, kickers, headers, and many other solid wood applications. -- Single lever valve operation with dial regulator pressure controls for quick & accurate clamping pressure. -- Up to 30 Ton max. clamping pressure @ 120 PSI.

JLT 78H-16W-42L Mini Air Pod PressThis Pneumatic Vertical Clamping System features upper and lower 16" wide and up to 42" long steel platens for face gluing a variety of solid wood components. With its modular design with each section having its own pressure control and 40" opening, Specifications: -- 16" Deep x 42" long clamping capacity. -- Air-operated assembly, for face gluing of engineered stiles & rails, kickers, headers, and many other solid wood applications. -- Single lever valve operation with dial regulator pressure controls for quick & accurate clamping pressure. -- Up to 30 Ton max. clamping pressure @ 120 PSI.

This Pneumatic Vertical Clamping System features upper and lower 12" wide and up to 126" long steel platens for face gluing a variety of solid wood components. With it's modular design with each section having its own pressure control and 40" opening. -- 12" Deep x 42" wide clamping cap. -- Air operated assembly, for face gluing of engineered stiles & rails, kickers, headers, and many other solid wood applications. -- Single lever valve operation with dial regulator pressure controls for quick & accurate clamping pressure. -- Up to 30 Ton max. clamping pressure @ 120 PSI.

This Pneumatic Vertical Clamping System features upper and lower 12" wide and up to 42" long steel platens for face gluing a variety of solid wood components. With its modular design with each section having its own pressure control and 40" opening, 13" daylight. -- 12" Deep x 42" long clamping cap. -- Air operated assembly, for face gluing of engineered stiles & rails, kickers, headers, and many other solid wood applications. -- Single lever valve operation with dial regulator pressure controls for quick & accurate clamping pressure. -- Up to 30 Ton max. clamping pressure @ 120 PSI.

JLT 79F-12-PC Multi Level Panel Clamp12' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (6) clamps per level (a total of 30) manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps have a 40" opening with a 3-1/2" high x 4" wide jaw.Available Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 144" x 78" x 52" high

JLT 79F-16-PC Multi Level Panel Clamp16' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (36) clamps total manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps # 302-40-H-R with 40" opening with a 3-1/2" high x 4" wide jaw. -- (72) # 80-1706 Rocker adaptor plates for up to 6" thick glue stock -- (1) Fastener and shim kit for precise clamp alignmentAvailable Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 16' x 52"W x 70" high

JLT 79F- 6-PC Multi Level Panel Clamp6' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (8) clamps manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps have a 40" opening with a 3-1/2" high x 4" wide jaw. (52" clamp available upon request)Available Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 75" x 70" x 48" high

JLT 79F-8-PC Multi Level Panel Clamp8' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (18) clamps manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps have a 40" opening with a 3-1/2" high x 4" wide jaw.Available Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 100" x 70" x 48" high

JLT 79K-10 Entry Panel & Door ClampVersatility: Leave the center squaring bar to do multiple doors at once or remove the bar to take advantage of the full capacity of the machine. -- Capacity for solid wood doors: 48" x 120". -- Quick release latches on the jaws; moveable squaring bar. -- Squaring mechanism can be recalibrated, if necessary. -- (2) Horizontal pneumatic clamps. -- (4) Vertical pneumatic clamps. -- 1-Lever operation. -- 1,000 Lbs Clamping force per cylinder. -- 3" Stroke from each cylinder.

JLT CLAMPS 718A-M2-12-M Panel and Door ClampBuddy System includes #79F-12-PC & #717CUnique all-in-one Panel Clamp & Cabinet Door Clamp. -- The DDC has a larger clamping area of 38" Deep x 98" Wide with a splitter for two (2) door clamping. -- Double door design, air operated assembly clamp specifically designed for entry doors, cabinet doors or windows. -- (2) Heavy Duty quick adjusting pneumatic clamping cylinders & (1) quick adjusting cross-clamp on the side. -- (1) Quick adjusting cross-clamp for the rails with (3) draw clamps for the stiles. -- 2" Deep squaring fence along left and bottom sides. -- Single-lever cylinders for quick & accurate clamping pressure. -- Shelf area to hold the pieces of the frame prior to clamping for all squaring components. -- 5-Tier self-supporting rack unit; each tier is 12' wide; total of (18) clamps on the rack. -- 32" or 40" Opening clamps available; must be specified when placing order. -- Clamps with 2-1/2" high jaws and manual movement & tightening. -- Additional clamps are available. -- 40 Sq. ft. footprint.

JLT CLAMPS 79F-M2-8-PC Panel and Door Clamp. An Industry standard for Cabinet doors and so much more. -- (5) Levels of 8' wide x 40" deep cap. -- Heavy tubular frame with (18) clamps. -- Manually adjustable bar clamps that easily set in place and move from side-to-side. -- 40" Clamp opening with a 3-1/2" high x 4" wide jaw. -- Additional opening clamps available.

JLT CLAMPS 79F-M2-6-PC Panel and Door ClampAn Industry standard for Cabinet doors and so much more. -- (5) Levels of 6' wide x 40" deep cap. -- Heavy tubular frame with (8) clamps. -- Manually adjusted bar clamps that easily set in place and move from side-to-side. -- 40" Clamp opening with a 3-1/2" high x 4" wide jaw. -- Additional clamps are available.

JLT 717C-DC Cabinet Door Clamp:Pneumatically operated Cabinet Door Clamp to square & clamp door in (1) Second. -- 26" Front-to-back x 62" left-to-right clamping capacity. -- Single row door clamp with (1) horizontal pneumatic clamp & (2) vertical pneumatic clamps. -- Special mount on a 30° angle for ease of loading & less operator fatigue. -- (3) Large diaphragm cylinders for quick clamping pressure with single lever operation. -- 40 PSI Air pressure to produce 500 Lbs of force on each clamp. -- Shelf to hold the pieces of the frame before pressing on all squaring components. -- 40 Sq. ft. floor space requirement.(Replaces: #717A-DC)

JLT CLAMPS 717C-M Panel and Door ClampPneumatically operated Cabinet Door Clamp to square & clamp a door in (1) Sec. -- 26" Front-to-back x 62" left-to-right clamping cap. -- Special design for mitered doors. -- Single row Door Clamp with (2) horizontal pneumatic clamp & (2) vertical pneumatic clamps. -- Special mount on a 30° angle for ease of loading & less operator fatigue. -- (4) Large diaphragm cylinders for quick clamping pressure with single lever operation. -- 40 PSI Air pressure to produce 500 Lbs. of force on each clamp. -- Shelf to hold the pieces of the frame before pressing on all squaring components. -- 40 Sq. ft. footprint.(Replaces #717A-M)

JLT CLAMPS 717C-DDC CLAMP, PANEL AND DOOR.Pneumatically operated Cabinet Door Clamp to square & clamp a door in (1) Sec. -- 38" Front-to-back x 98" left-to-right clamping capacity. -- Single row 2-station Door Clamp with (2) horizontal pneumatic clamps and (4) vertical pneumatic clamps. -- Special mount on a 30° angle for ease of loading & less operator fatigue. -- (6) Large diaphragm cylinders for quick clamping pressure with single-lever operation. -- 40 PSI Air pressure to produce 500 Lbs of force on each clamp. -- Shelf to hold the pieces of the frame before pressing for all squaring components. -- 60 Sq/ft footprint.(Replaces #717A-DDC)

JLT 79F-M2-12-PC Panel and Door Clamp An Industry standard for Cabinet doors that offers so much more. -- (5) Levels of 12' width x 40" depth cap. -- Heavy tubular frame with (6) clamps per level x (5) levels for a total of (30) clamps. -- Manually adjusted bar clamps that are easily set in place and can move from side-to-side. -- 40" Clamp opening with a 3-1/2" high jaw. -- Additional clamp openings available.

JLT CLAMPS 718A-M2-8 Panel and Door Clamp Buddy System includes #79F-8-PC & 717C Unique all-in-one Panel Clamp & Cabinet Door Clamp. Specifications: -- 26" Deep x 62" wide clamping cap. -- Single row door clamp, air operated assembly on a 70° angle for entry doors, cabinet doors or windows. -- (2) Heavy Duty quick adjusting pneumatic clamping cylinders. -- (1) Quick adjusting cross-clamp for the rails with (3) draw clamps for the stiles. -- 45° Working angle for easy access & less fatigue. -- 2" Deep squaring fence along left & bottom sides. -- Single lever cylinders for quick & accurate clamping pressure. -- Shelf area to hold the pieces of the frame prior to clamping for all squaring components. -- 5-Tier self-supporting rack unit; each tier is 8' wide; total of (18) clamps on rack unit. -- 32" or 40" Opening clamps available; must be specified when placing order. -- Clamps with 2-1/2" high jaws with manual movement and tightening. -- 40 Sq. ft. footprint.

JLT CLAMPS 718A-M2-12 Buddy System Panel and Door ClampBuddy System includes #79F-12-PC & #717CUnique Panel Clamp & Cabinet Door Clamp all-in-one. -- 38" Deep x 98" wide clamping cap. -- Air operated assembly, single row Clamp on a 70° angle specifically for entry doors, cabinet doors or windows. -- (2) Heavy Duty quick adjusting pneumatic clamping cylinders. -- (1) Quick adjusting cross-clamp for the rails with (3) draw clamps for the stiles. -- 45° Working angle for easy access & less fatigue. -- 2" Deep squaring fence along left & bottom sides. -- Single lever cylinders for quick & accurate clamping pressure. -- Shelf area to hold the pieces of the frame prior to clamping for all squaring components. -- 5-Tier self-supporting rack unit; each tier 12' wide for a total of (18) clamps. -- 32" or 40" Opening available; must be specified when placing order. -- Clamps with 2-1/2" high jaws with manual movement and tightening. -- Additional Clamps available. -- 40 Sq. ft. footprint.

JLT CLAMPS 138B Glue ApplicatorPlate type glue applicator with 8" wide x 48" long applicating capacity. -- Spreader frame is constructed of heavy perforated aluminum components. -- All glue application components such as the grid, glue pan and cover are constructed of steel. -- Foot treadle operated and the grid rises out of the reservoir of glue. -- The thickness of the glue is easily regulated by the operator. -- No daily clean-up is required, simply spray the surface of the glue with water and cover the unit for overnight storage. -- Several depressions of the foot treadle mixes the glue and can thin the glue when water is added.

LIMTECH ORION-512 Flat Table CNC Router with Tool Changer & Boring:5' x 12' Capacity, great for "Nested Base Manufacturing" or just about any type of 3-Axis work.Axes travel range & feed speed: -- X-Axis 61" (1,550 mm), Y-axis with 145" (3,700 mm) and Z-axis 11.8" (300 mm). -- Working Table: 61" (1,550 mm) x 145" (3,700 mm); includes (3) pop-up stops to aid in panel positioning & a manual valve controlled 6-zone special high flow vacuum table system. -- X- & Y-Axis speeds are 2,165 IPM and Z-axis is 1,000 IPM for quick traverse positioning that reduces total CNC machining time between cutting cycles. -- DELTA Servo Drive powers the axes movement.Machine bed/base: -- The welded structurally engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- X-, Y- and Z-Axis travel: The moving gantry bridge travels on 1.2" (30 mm) thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high speed traverse and accurate cutting. -- Tool gantry & bridge movement by 1" (25 mm) rack & pinion; the vertical Z-axis travels on precision ball screw for smooth consistent and highly accurate movement.Routing/Machining: -- (1) 12 HP (8.8 kW) Air cooled "HSD" Router spindle with: HSK Tool holders, variable programming speeds from 1,000 to 24,000 RPM. -- Tools are loaded into the "HSD" spindle by (1) 8-position, side mounted on the fly tool changer. -- Tool heights can be set using the Tool Length Setting Gauge (included); machine uses ER-32 tool collets.Drilling/Boring: -- (1) Vertical 9-head spindle drills in L-shape configuration for 32 mm contstruction hole & line boring.CNC Control & Operator Interface: -- The "SYNTEC" INDUSTRY CONTROL System provides the operator an easy to use interface and the flexibility to customize to user specifications; Network-ready via Ethernet and USB flash drive. -- Features: Canned cycle, tool length diameter compensation, work coordinates-offsets, spindle feed rate overrides, program size up to flash drive size, DNC or drip feed operation and unlimited offset registrations. -- Compatible with virtually all CAD/CAM programming software on the market; you choose the software that best suits your needs.Complete with & Includes: -- Dust hood with 6" manifold connection; (4) HSK tool holders; Tool Length Setting Gauge; MPG hand held wheel remote. -- Vacuum Pump; 8 kW (11.5 HP) Vacuum Pump with ON/OFF pre-plumbed to control panel. -- Other Features: Machine Central lubrication, safety light beams and automatic homing operation. -- Machine weighs approx. 8,500 Lbs; 15 CFM air consumption at 90 PSI; machine power supply is wired for 220 Volts, 60 Cy, 3-Phase. Includes: Installation & Training by Factory Technician, and (1) Year Parts & Labor Warranty.
